JL Audio Stealthbox SB-N-TTCRW/10W3v2 User manual

➔
➔
➔
➔
Stealthbox®
INSTALLATION GUIDE
SB-N-TTCRW/10W3v2, JL AUDIO, Inc 2004 Sheet SKU#01192 Revision 10/9/2004Page 1
for the
SB-N-TTNCRW/210W3v2
(04-Up Nissan Titan Crew Cab)
This Stealthbox is a product which
requires professional installation skills and
tools.
Please read this installation guide thor-
oughly before beginning the project. It
will guide you step by step through the
installation. Several of the steps in this
process may require two people to
accomplish.
It is absolutely vital that the enclosure
be properly mounted to the vehicle
according to these instructions. Failure
to mount the enclosure properly pres-
ents two problems: 1) The sub-bass
performance will suffer due to the
movement of the enclosure caused by
the force exerted by the woofer(s) and
2) A loose enclosure presents a serious
safety hazard in the event of a collision
or sudden deceleration.
Please enjoy your JL Audio Stealthbox
responsibly.
STEP 1: The wax square needs to be placed
into the curvature of the floor bulk head.
STEP 2: With the passenger side rear seat
lifted, out of the way.
Measure 8” from the left floor corner to the
middle of the placed wax square.
Once placement is found, remove the paper
backing and adhere to the carpet.
STEP 3: Place the supplied socket cup set
screw into the enclosure, leaving 1/4”
exposed.
STEP 4: Place the enclosure into position and
press down firmly.
Make sure that the enclosure does not move
around when placing the enclosure into posi-
tion.
Once the wax square is marked, remove the
enclosure out of vehicle.
STEP 5: *CAUTION*
Before drilling, make sure that you are not going to
be drilling into any gas lines, brake lines, transmission
lines, electrical wiring, transfer case(4x4 vehicles) or
anything else that might cause a reduction in your
weekly pay. Always wear eye protection when drilling.
With the use of a 1/2” drill bit and drill. Drill out the
floor at the impression on the wax square.
STEP 6: With the enclosure removed out of
the vehicle, expose 1-1/2” of the socket cup
set screw.
START
HERE
Continued on Next Page ➔
www.jlaudio.com
➔
➔

Specifications:
Enclosure Type: Sealed
Driver Type: 2) 10W3v2-D4
Nominal Impedance: 4Ω
Cont. Power Handling: 600Watts
JL Audio recommends using a high quality amplifier such as the JL Audio 500/1. The diagram below shows the recommended
crossover, infrasonic filter and equalizer settings for the 500/1 when being used to power your Stealthbox®.
Included Hardware:
1) Wax Square
1) 3/8” x 2-1/4” Fender Washer
1) 3/8” Flat Washer
1) 3/8” Split Lock Washer
1) 3/8”-16 Hex Nut
1) 3/8”-16 x 2-1/4” Socket Cup Screw
10369 N. Commerce Pkwy, Miramar, Florida 33025-392 Phone: [phone] Fax: [phone]
+12VDC RemoteGround
JL AUDIO 500/1
five-channel system amplifier
+_
_
+
Subwoofer Output
MONO OUTPUT ONLY
40
45
55
65
85
120
200
Filter Freq. (Hz)
Mode / Slope
Off / 12dB / 24dB
Amp LP Filter
Infrasonic Freq. (Hz)
15
18
25
30
40
50
60
Off / 30Hz
Infrasonic Filter
0.5
0.7
1.1
1.6
2.7
4.3
"Q"
20
25
35
45
55
70
85
Center Freq.
0
+4
+10
+13
+15
Boost (dB)
Off / On
Bass EQ
Remote Bass Port
Advanced
Bass
Control
Preamp Output Section
Full Range / Amp Filter / Out Filter
Output Mode Filter Slope
12dB / 24dB
40
45
55
65
85
120
200
Filter Freq. (Hz)
Left Ch. Right Ch.
Filter Mode
LP / HP
Amplifier Input Section
Input Sens.
Left Ch. Right Ch.
Signal Sensing
Off / On
Input Voltage
Low / High
The JL Audio 500/1 is a very versatile audio component. Please consult the owner’s manual for detailed information
about installing and tuning this amplifier.
➔➔
STEP 7: Run and attach speaker wire from the
amplifier location to the enclosure.
STEALTHBOX WALL THREADED INSERT
VEHICLE SHEET METAL
FENDER WASHER SOCKET CUP SET SCREW
LOCK WASHER
FLAT WASHER
HEX NUT
STEP 8: With the socket cup set screws protrud-
ing through the floor of the vehicle. Place the sup-
plied fender washer, flat washer, lock washer and hex
nut in this order.
Secure tightly.
➔
SB-T-TTNCRW/10W3v2, JL AUDIO, Inc 2004 Sheet SKU#01192 Revision 10/9/2004Page 2
www.jlaudio.com
Mid/High Frequency Driver Information:
CONGRATULATIONS!
INSTALL COMPLETE.
VR075-CT
VR690-CXi
VR650-CSi
Dash Location Driver Size:
2.5”
Applicable JL Audio Products:
TR050-CT,VR075-CT, XR100-CT
*mounting plate is needed
Front Location Driver Size:
6” x 9”
Applicable JL Audio Products:
TR690-TXi,VR690-CXi
*mounting plate is needed
Rear Location Driver Size:
6.5” separates
Applicable JL Audio Products:
TR,VR, XR, ZR 650-CSi
*mounting plate is needed
Cont.
From
Previous
Page
Difficulty Of Installation:
