JMGO DLP-Link GL1800 User manual

DLP-Link 3D Glasses
UserManual
Product Overview
Thank you for your choosing JmGO qualty 3D product. The 3D glasses in thepackage are
designed to which 3D contents with DLP 3D readyprojectors and DLP 3D TVs which using
DLP-Link synchronization technology.The 3D glasses powered byadvanced LCD shutter
technologyand anti-interence communcation technologywill bring you a vivid and
wonderful 3D experience.
Glasses Cloth
User Manual
3D Glasses
USB Cable
Package Content
Package Feature
USB Interface
USB Interface
LCD lens
LED Light
LED Light
LED Light
Power Button
Power Button
ON:Press thePower Buttonone time.
OFF:Keep pressing the power buttonfor 3seconds.
Blue LED lightabout 1.5 second: Powered on;
Blue LED flash 3times: Powered off;
Blue LED lightflashes 2 times each 10s after 5 times: Low battery,please charge;the red LED light
appear red when rechasrge,while the red LED is off when thebattery is full.
In order to ensure better reception,try being on the projector or DLP television transmitters, and
to ensure no foreign objects when using front
Do not scratch thesurface of the liquid crystal shutters with a sharp tooland do not clean it using
chemicals.
Portable folding design for easystorage.
SingalRecevier
SingalRecevier
Earpieces
Earpieces
Charge the 3D glasses by connecting the USB port of your TV or computer with the USB cable.
Operation Guide
Turn ON the 3D glasses:press and releasethepower buttin,Blue LED lights onfor 1.5s indicating
that the3D glasses arepowered on;
Turn OFF the 3D glasses:press and hold the power button for 1.5s,Blue LED lights flashes 3times
indicating thatthe 3D glasses arepowered on;
Low battery warning:Blue LED light fflashes 2times each 10s after 5 times;
L/R eye Rotation:in theworking mode,press thepower button,then the left and right eyes are
rotatied.
Brightness
contrast
Power supply
Workable time
Environment
requirement
Signal
Transmission
1000:1±200
Working current
N.W.
Rechargeable
Li-ion Battery
Around 40 hours/charge
96Hz/100Hz/120Hz/144Hz
Work temperature 0~45℃
-10~60℃Stock temperature
38±2%
34.5g
<1.2mA
Use range
DLP-Link
8m
Shutters Liquid Crystal
Frequency
Notice:For a better performance of the battery,pleasefull chargethe 3D glasses before
thefirst time using and chargetheglasses at lest one time within 6 months.
Glasses Specification
Troubleshooting
1.The 3D glasses are used for 3D content viewing only.Do not use them for general eye
wear purpose,such as sunglasses and general eye wear,Doing so many result in injury.
2.The glasses are powered by a rechargeable lithium-polymer battery,please charge the
glasses with a standard 5V USB connection and do not damage the battery or may result
in injury or fire.
3.Do not place the glasses in a location exposed to direct sunlight,heat,fire or water,this
may result in product malfunction or fire.
4.Clean the 3D glasses with a clean,lint free,dry,soft cloth.Any chemical cleaning agent
spray on the 3D glasses may damage the product surface or cause product malfunction.
5.Do not apply force to the 3D glasses.Dropping or bending may damage the product.
6.When watching a 3D video,do not place anything fragile nearby.Involuntary movement or
surprised reaction may occur as a result of certain 3D content which result in surrounding
objects being broken or hurt yourself.
7.Please watch 3D content in the signal covered area and make sure no object is placed
close to the front of your glasses.
8.50Hz or 60Hz magnetic fluorescent lamp may cause flicker to your 3D glasses.Turn off
the lamp if this happens.
9.Do not use the 3D glasses if there are any wire exposed or cracks to the lens.
10.Do not let your child to remove the battery of 3D glasses and swallow it.if this happen,
consult a doctor immediately.
1.We recommend pregnant women,people with heart disease or epilepsy and people who
are easily nauseous should not watch 3D content.
2.Due to the stereoscopic effects and the uncompleted visual development of younger
children under 3 years of age we recommend you not allow them to watch 3D content.
Watching 3D for a long time may affect there visual develppment.
3.Watching 3D content for a long time may cause headache or eyestrain to you,please stop
watching if you have any uncomfotable feeling and take a rest immediately.Please
consult a doctor if the feeling do not release.
4.Some indiviauals may experience seizure or other complications when exposed to certain
visual images,including flashing lights or patterns that may appear in a video or games.If
you or any of your relatives have a history of seizures or epilepsy consult a doctor before
watching.
The 3D glasses will activate their Auto OFF and Auto run intelligently in the following
conditions.
1.The 3D glasses are standby(for a period of 5 minutes)when powered on and they will turn
into working mode once received the 3D SYNC signal during standby mode.otherwise,the
glasses will automatically turn off with the blue LED flashes 3 times.
2.If the 3D glasses become disconnected with the signal because of:1>incorrect distance
and or angle.2>input source changed.3>switched to 2D mode,they will automatically work
for a period of 3s.The glasses will resume working once a 3D SYNC signal is signal is
received.otherwise,the glasses will enter into standby mode(for 5 minutes).
Q1:What can i do if there is no 3D effect after i put on and turn on the 3D glasses?
Try this:
1.please check if the DLP projector/DLP TV setup is in 3D mode or not.
2.Check the battery volume of your 3D glasses,please charge it in time if low in power.
3.Make sure your position is in the SYNC signal coverage so that the glasses can receive
the signal.
Q2:Why do the lenses flash when watching 3D films?
Try this:
1.Please charge the 3D glasses immediately if the battery is seriously low.
2.If there is light or other signal interference in the watching surroundings,please turn off
interference source.
Caution
Safety Precaution
Kindly Reminder
