jobmate 060-2280-6 User manual

CORDLESS GRASS TRIMMER
TM
MC
CUS
218549
Operation and Safety Instructions
Toll Free Helpline:
1-877-888-3872
060-2280-6

SAFETYSIGNALS & SYMBOLS..................................................................................
BOX CONTENTS.........................................................................................................
GENERALINFORMATION.......................................................................................5-10
CORDLESS GRASS TRIMMER............................................................................11-12
ASSEMBLY............................................................................................................13-16
OPERATION..........................................................................................................17-19
MAINTENANCE......................................................................................................... 20
CHARGER.............................................................................................................21-23
BATTERY DISPOSAL................................................................................................24
WARRANTY...............................................................................................................25
PARTS LIST..........................................................................................................26-27
Replacement spool: 60-2267-0
Replacement battery: 60-2219-6
2
3
CONTENTS................................................................................................................. 2
TECHNICAL DATA...................................................................................................... 2
4
Contents
CORDLESS GRASS TRIMMER
Model Number................................................................................................060-2280-6
Type.......................................................................................Cordless, battery-operated
Speed..............................................................................................................9000 RPM
Trimmer Line...........................................1/16" (1.65 mm) diameter monofilament nylon
Cutting Circle Diameter.................................................................................8" (20.3 cm)
Overall Trimmer Length ..............................................................................43" (110 cm)
Weight (with battery pack).............................................................................4 lb (1.8 kg)
BATTERY PACK
Type.................................................................................Nickel-cadmium rechargeable
Output voltage...................................................................................................12 V DC
Charging time.......................................................................................approx. 3~5 hour
TECHNICAL DATA

3
Signals an EXTREME hazard.
Signals a serious hazard.
Signals a moderate hazard.
IMPORTANT! Signals special mechanical information.
NOTE: Signals additional important general information.
CAUTION
WARNING
DANGER
The purpose of safety signal statements and symbols is to attract your attention to possible
danger. Read them carefully to understand and practice proper accident prevention.
Failure to obey a safety DANGER signal WILL result in serious injury or death
to yourself or to others. Always follow the safety precautions to reduce the
risk of fire, electric shock, and personal injury.
Failure to obey a safety WARNING signal CAN result in serious injury to
yourself and to others. Always follow the safety precautions to reduce the risk
of fire, electric shock, and personal injury.
Failure to obey a safety CAUTION signal MAY result in property damage or
personal injury to yourself or to others. Always follow the safety precautions
to reduce the risk of fire, electric shock, and personal injury.
Type or a characteristic of current
Type or a characteristic of current
Designates double insulation
IMPORTANT!
~
SYMBOL NAME EXPLANATION
V Volt
A Amperes
Hz Hertz Frequency (cycles per second)
n0No load speed
.../min Movements Revolutions, strokes, surface speed, orbits, etc.
per minute
per minute
Some of the following symbols may be used on your tool. Please
study them and learn their meaning. Proper interpretation of these symbols will allow
you to operate the tool better and safer.
Potential voltage
Current
Rotational speed at no load
Alternating current
Direct current
Class II
- - -
Ni-Cad Battery Recycling Designates that this tool is in accordance with
Ni-Cad battery recycling program
Safety Signals
Safety Tool Symbols

4
By purchasing a battery-powered tool you have helped reduce the pollution level of
our environment.
Please check the contents of the carton with Fig. 1. Examine all the parts before using
the cordless grass trimmer and battery charger. If any parts are missing or damaged,
please call 1-877-888-3872 for assistance.
To reduce the risk of fire, electric shock, and personal injury:
• Read all instructions before using this tool. Basic safety precautions should
always be followed.
• Please keep these instructions safe for later use. The safety rules must be
followed to avoid injury when using the Cordless Grass Trimmer.
WARNING
Guard
Battery charger
Remote charger
Battery
Grass trimmer
(in folded position)
Fig. 1
Box Contents

5
Work Area
• Keep your work area clean and well lit.
• Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases,
tool. Distractions can cause you to lose control.
or dust. Power tools create sparks which may ignite the dust
or fumes.
• Keep bystanders, children, and visitors a MINIMUM 30’ away while operating a power
Electrical Safety
• A battery-operated tool with integral batteries or a separate battery pack must be
recharged only with the specified charger for the battery. A charger that may be suit-
able for one type of battery may create a risk of fire when used with another battery.
• Use a battery-operated tool only with specified battery pack. Use of any other
batteries may create a risk of fire.
Personal Safety
• Stay alert, watch what you are doing, and use common sense when operating a
power tool. Do not use tool while tired or under the influence of drugs, alcohol, or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
• Dress properly. Do not wear loose clothing or jewellery. Contain long hair. Keep your
hair, clothing, and gloves away from moving parts. Loose clothes, jewellery, or long
hair can be caught in moving parts.
• Avoid accidental start-ups. Make sure the switch is in the locked or off position
before inserting battery pack. Carrying tools with your finger on the switch or
inserting the battery pack into a tool with the switch on invites accidents.
• Remove adjusting keys or wrenches before turning the tool on. A wrench or key that
is left attached to a rotating part of the tool may result in personal injury.
• Do not overreach. Keep proper footing and
• Against overloading the maximum capacity, using the tool as it was not intended.
balance at all times. Proper footing and
balance enable better control of the tool in unexpected situations.
READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious personal injury.
WARNING
General Information
General Safety Rules for All Battery-operated Tools
ALWAYS WEAR EYE PROTECTION.
A Cordless Grass Trimmer can throw foreign objects into your eyes
which couldcause permanent eye damage. ALWAYS wear safety
goggles (not glasses). Ordinary eyeglases have onlyimpact-resistant
lenses; they are NOT safety goggles.
SAVE THESE SAFETY RULES

6
Tool Use and Care
• Do not use tool if switch does not turn it on or off. A tool that cannot be controlled
with the switch is dangerous and must be repaired.
• Remove battery pack from tool before making any adjustments, changing accesso-
ries, or storing the the tool. Such preventive safety measures reduce the risk of
starting the tool accidentally.
• Store idle tools out of reach of children and other untrained persons. Tools are
dangerous in the hands of untrained users.
• When battery pack is not in use, keep it away from other metal objects like: paper
clips, coins, keys, nails, screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the battery terminals together may
cause sparks, burns, or a fire.
• Check for misalignment or binding of moving parts, breakage of parts, and any
other condition that may affect the tool’s operation. If damaged, have the tool
serviced before using. Many accidents are caused by poorly maintained tools.
• Use only accessories that are recommended by the manufacturer for your tool.
Accessories that may be suitable for one tool may create a risk of injury when used
on another tool.
Service
• Tool service must be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel may result in a risk of injury.
• When servicing a tool, use only identical replacement parts. Follow instructions in
the Maintenance section of this manual. Use of unauthorized parts or failure to follow
Maintenance Instructions may create a risk of shock or injury.
SAVE THESE SAFETY RULES
General Information

7
For ALL Garden Tools
• Avoid dangerous environments. Don’t use tool in damp or wet locations.
• Don’t use in rain.
• Keep bystanders and children away while operating.
• Dress properly. Do not wear loose clothing or jewellery. They can be caught in
moving parts. Use of rubber gloves and substantial footwear is recommended when
working outdoors.
• Avoid unintentional start-ups.
• Don’t grasp the exposed cutting line when picking up or holding the tool.
• Don’t force the tool. It will do the job better and with less likelihood of a risk of injury
at the rate for which it was designed.
• Don’t overreach. Keep proper footing and balance at all times.
• When not in use, tool should be stored indoors in dry, high, or a locked-up place-out
of reach of children.
• Maintain tool with care. Keep cutting line clean for best performance and to reduce
the risk of injury.
• Keep guards in place and in working order.
• Keep hands and feet away from cutting line.
• Always use eye protection.
For Cordless Grass Trimmer
• When lengthening new cutting line, be careful of the line cutter on the guard. It is
sharp.
• NEVER fit metal cutting elements or blades.
• Keep ventilation openings clear of debris. Keep handles dry, clean, and free of oil
and grease.
• Before using the Cordless Grass Trimmer, remove any stones, sticks, debris or
objects that could become entangled or thrown by the trimmer.
• DO NOT switch ON until the Cordless Grass Trimmer is in its normal operating
position. Do not press the lock-OFF button or squeeze the trigger while the Cordless
Grass Trimmer is inverted.
• NEVER reach under the Cordless Grass Trimmer (the cutting line area) until it has
completely stopped. The trimmer’s cutting line continues to rotate for 5 seconds after
being switched OFF.
• During operation, ensure that there are no other persons or animals within a radius
of 3’. Stop using the tool while people, especially children, or pets are nearby.
• Keep the cutting head and motor clean to reduce the risk of injury.
• Use only the specified size and type of cutting line. Do not substitute.
SAVE THESE SAFETY RULES
Specific Safety Rules
General Information

8
For Battery Pack and Charger
SAVE THESE SAFETY RULES
Specific Safety Rules
DANGER
To avoid serious injury, risk of fire, explosion and danger of electric shock or
electrocution:
• DO NOT probe the charger with conductive materials. The charging terminals
hold 120 V.
• If the battery pack case is cracked or damaged, DO NOT insert into the
charger. Replace the battery pack.
• DO NOT charge these battery packs with any other type of charger.
• Charge only the Cordless Grass Trimmer battery pack provided.
• DO NOT allow liquid inside the charger.
• DO NOT try to use the charger for any other purpose than what is presented
in this manual.
WARNING
If the battery fluid gets in your eyes, flush immediately with clean water for at
least 15 minutes. Get immediate medical attention. Do not charge the battery
pack in rain or in wet conditions. Do not immerse the tool, battery pack, or
charger in water or other liquid.
• Do not allow the battery pack or charger to overheat. If they are hot, allow them to
cool down. Recharge only at room temperature.
• Do not allow small metal items or material such as steel, wool, aluminum foil, or
other foreign particles come in contact with battery.
• Unplug the charger before cleaning and when there is no battery pack in the cavity.
• Do not place the battery charger or the battery pack in the sun or in a hot environ-
ment. Keep at normal room temperature.
• Do not try to connect two chargers together.
• The battery pack cells may develop a small leak under extreme usage or tempera-
ture conditions. If the outer seal is broken and the leakage gets on your skin:
– Use soap and water to wash immediately.
– Neutralize with lemon juice, vinegar, or other mild acid.
General Information

9
Electrical Safety Rules for Battery Pack and Charger
WARNING
READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow safety rules
listed below may result in electric shock, fire, and/or personal injury:
• Do not abuse the cord. Never use the cord to carry the tool. Never pull on the cord
to remove the plug from the power outlet. Keep cords away from heat, oil,
sharp edges, or moving parts. Replace damaged cords immediately. They may create
a fire. Do not use.
• Do not place the charger where the power cord might be stepped on, tripped on, or
subjected to damage.
• A battery-operated tool with integral batteries or a separate battery pack must be
recharged only with the specified charger for the battery. A charger that may be
suitable for one type of battery may create a risk of fire when used with another
battery.
• Use a battery-operated tool only with the specifically designated battery pack. Use
of any other batteries may create a risk of fire.
Grounding (Fig. 2)
In the event of a malfunction or breakdown, grounding provides the path of least
resistance for electric current, and reduces the risk of electric shock. This battery
charger is double insulated and has a two-prong non-polarized plug (one blade is
wider than the other). This plug will fit into a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet. DO NOT change the plug in any way. IN ALL
cases make sure the outlet is properly grounded. If you are not sure, have a certified
electrician check the power outlet.
Minimum Gauge for Extension Cords (AWG)
(when using 120 V only)
Ampere Rating Total Length of Cord in Feet (metres)
More Than Not More Than 25' (7.6 m) 50' (15 m) 100' (30.4 m) 150' (45.7 m)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
General Information

10
Extension Cords (Fig. 3)
Do not use an extension cord for the charger unless absolutely necessary. If you use
an extension cord make sure the cord is in good condition.
Use one heavy enough to carry the current your charger will draw. An undersized
extension cord will cause a drop in line voltage resulting in loss of power and
overheating. The table below shows the correct size of extension cord to use,
depending on cord length and the charger's ampere rating listed on the nameplate. If
in doubt, use the next heavier gauge. The smaller the gauge number is, the heavier
the cord.
Make sure your extension cord is properly wired and in good condition. Always
replace a damaged cord or have it repaired by a qualified electrician. Protect your
extension cord from sharp objects, excessive heat and damp or wet areas. Use a
separate electric circuit for your tools. Never use any other voltage or power source
than common household 120 V electrical power. The circuit must not be less than a
#14 wire and should be protected with a 15 A time-lag fuse. Before connecting the
charger to the power line, make sure the electric current is rated the same as the
current stamped on the charger nameplate. To reduce the risk of disconnection of
charger cord from the extension cord during operation make a knot (Fig. 3).
2 Prong
Polarized Plug
Properly
Grounded
Outlet
Fig. 2
Properly-grounded outlet
2-prong
polarized plug
Fig. 3
General Information

11
IMPORTANT! The battery pack is not charged when the grass trimmer is purchased.
Charge the battery pack for a full 24 hours before using for the first time. (See
Battery Charger instructions)
To avoid possible injury:
• The battery pack must always be removed before assembling the guard,
adjusting, or installing cutting line spools.
Trimmer.
• The protective guard cannot be removed after installation.
• Do not operate the grass trimmer without the protective guard.
• Read and understand this owner’s manual before operating the Cordless Grass
WARNING
Cordless Grass Trimmer
Functions (Fig.4)
Lock-OFF button
Front handle
Trigger
handle
Cutting spool
housing
Battery
pack
Protective guard
Fig. 4
Cutting line spool

12
IMPORTANT! The battery pack is not charged when it is purchased. Before using the
Cordless Grass Trimmer for the first time, place the battery pack in the battery charger
and charge for a full 24 hours. Make sure you read all safety precautions, and follow the
instructions in the Battery Charger section of the manual. With regular use it will need
shorter charging times. After prolonged storage time, charge the battery pack for at least
24 hours again. Nickel-cadmium batteries can develop a memory for usage and storage
times.
To Remove
1. Press in and hold the latch buttons (1) on both sides of the battery pack.
2. Grasp the trigger handle (2) firmly. Pull the battery packout of the handle.
NOTE: The battery pack fits snugly into the handle to prevent accidental dislodging. It
may require a strong pull to remove.
To Install
1. Align the tongue (3) of the battery pack with the cavity in the handle housing.
2. Grasp the trigger handle (2) firmly.
3. Push the battery pack into the handle until both sides lock. The latch buttons will
click when they lock.
4. Do not use force when inserting the battery pack. It should slide into place and click.
WARNING
To avoid injury and to reduce the risk of electrical shock or fire:
• Replace the battery pack or charger immediately if the battery case or charger
cord is damaged.
• Always make sure the Cordless Grass Trimmer switch is OFF before inserting
or removing the battery pack.
• Always make sure the battery pack is removed and the switch turned OFF,
before replacing spools or adjusting the line.
• Read, understand, and follow the Battery Charger instructions.
1
3
2
Fig. 5
Battery Pack (Fig. 5)
Cordless Grass Trimmer

13
1. Slide the upper handle over the top of the middle handle, lining up the locking ball
with the hole on the upper handle. Push them together to lock.
2. Slide the middle handle over the top of the lower handle, lining up the locking ball
with the hole on the middle handle. Push them together to lock.
Fig. 6
Connect the handle (Fig. 6)
Assembly

14
To avoid injury, always remove the battery pack before installing the guard, changing
a cutting line, or making any adjustments. If the guard is damaged, do not use the
grass trimmer until it is replaced.
NOTE: Install the protective guard before operating the grass trimmer. It cannot be
removed or disassembled.
1. Remove the battery pack.
2. Invert the grass trimmer to access the trimmer head.
3. Using a cross-head screwdriver, remove the pre-installed screw (1) from the
trimmer head.
4. Place the guard (2) on to the trimmer head and turn the guard 90° following the
track on the head.
5. Align the screw hole on the guard with the screw hole on the trimmer head.
6. Insert the screw into the trimmer head, fastening the guard in place.
Fig. 7
Guard (Fig. 7)
Assembly
2
1
(1) DOWN

15
WARNING
To avoid injury, always remove the battery pack before
installing the guard, changing a cutting line, or making any adjustments.
A spool of monofilament cutting line is preinstalled on the Cordless Grass Trimmer.
When the cutting line needs replacing, insert a new spool.
To remove the spool:
1. Disconnect trimmer from the power supply.
2. Turn grass trimmer over to access the spool.
3. Remove spool cover by pressing on two tabs parallel to each other on the side of
the cover (2).
4. Remove the spool (1) from the spool housing (3).
To replace the spool (Replacement spool: 60-2267-0):
1. Replace the spool (1) with a new pre-wound spool.
2. Insert the end of line through the opening (4) in the spool housing (3).
3. Align the tabs on the spool cover with the slots in the spool housing on the trimmer head.
4. Push down on the spool cover, locking it to the spool housing.
5. To advance the line when initially installed, you must pull the line while pressing
the black line release button on the side of the spool housing (3).
Fig. 8
Cutting Line (Fig. 8)
4
3
1
2
Assembly

16
To Refill the Spool (Fig. 9)
1. Cut a length of 1/16" (1.65 mm) nylon monofilament line (1) approximately 18’
(5.5 m) long.
2. Insert end of line into the small hole (2) to anchor the line.
3. Wind the line evenly and tightly in a clockwise direction.
4. DO NOT wind the line beyond the edge (3) of the spool.
5. Insert the line through hole (4) in the spool housing.
6. Position line spool (5) in spool housing (6).
Fig. 9
4
6
5
2
3
1
Assembly

17
WARNING
To avoid injury:
• Do not push down the Lock-OFF button or squeeze the trigger while the grass
trimmer is inverted.
• Do not carry the Cordless Grass Trimmer with your finger on the switch. Avoid -
unintentional starting.
Always allow 5 seconds or more after releasing the trigger
switch for the spool to stop rotating. Do not invert the Cordless Grass Trimmer,
or place your hands under the protective guard, until the grass trimmer spool has
come to a complete stop.
To Turn On:
1. Press the Lock-OFF button (1) and hold.
2. Squeeze the trigger switch (2).
3. Release the Lock-OFF button. The Cordless Grass Trimmer will stay ON as long as
the trigger switch is squeezed.
To Turn Off:
1. Release the trigger switch (2).
2. Allow at least 5 seconds for the spool to stop rotating. The Cordless Grass Trimmer
will be locked OFF until you press the Lock-OFF button again.
Fig. 10
On–Off Switch (Fig. 10)
1
2
CAUTION
Operation

18
While the Cordless Grass Trimmer is operating, the cutting line gets worn down and
becomes shorter. This trimmer is equipped with Automatic Line Advancement, which
automatically feeds additional line to the correct length as it wears down. If the line does
not automatically advance, the trimmer line may be tangled or empty.
(To replace the spool, see Page 15)
To advance the line, restart the Cordless Grass Trimmer. Upon starting, the line will
automatically advance.
Fig. 11
Lengthening the Line (Fig. 11)
Operation

19
Before each use
• Make sure the protective guard is tightly installed. Tighten the guard screw.
• Make sure the battery is fully charged and that the charger is disconnected before
using or storing theCordless Grass Trimmer.
• Do not store the Cordless Grass Trimmer in sunlight, in an excessively warm place,
or near a furnace. The battery life will be shortened.
• Before trimming, inspect the area for string, wire, branches or other material that
may become entangled in the cutting line and thrown.
During use
• Trim only when the grass and weeds are dry.
• Do not trim grass at night. Always make sure you have adequate lighting.
• Hold the Cordless Grass Trimmer by both the switch handle and the auxiliary handle
for best control and balance.
• Stand with the cutting head tipped down at an angle in front, guiding the Cordless
Grass Trimmer in a semicircular motion around you.
• If possible, guide the Cordless Grass Trimmer to the left to cut. The line will cut as
soon as it leaves the guard, and the clippings are thrown away from you.
• To produce a smoothly trimmed area, move the Cordless Grass Trimmer, in and out
of the area being cut with consistent speed and height.
• Use only the tip of the cutting line to do the trimming, especially near walls and
fences. Trimming with the side of the cutting line may overload the motor, wear out
the line faster, and break the line more often.
• Do not rest the trimmer spool on the ground while trimming. This will cause spool
wear and battery drain.
• If the grass is higher than 6” (15 cm), trim in small stages.
• When the Cordless Grass Trimmer is turned off and the spool stops rotating, the
cutting line will relax and may recede. Feed extra cutting line before storing the trimmer
to prevent losing the line completely into the spool.
• If the diameter of the cutting area gets smaller, the line is worn down and needs to
be advanced more often.
• If the Cordless Grass Trimmer is not cutting correctly, the cutting line may not be
feeding properly. Remove and rewind the line spool.
Trimmer Tips
Operation

20
Battery Pack
• Store the battery pack fully charged.
• Recharge the battery pack any time you notice there is less power. Never let the
battery pack become completely discharged.
• Never recharge a battery pack that is already fully charged. Overcharging shortens
the battery life.
• Always recharge at a temperature of 10 to 40˚C (50 to 104˚F). If the battery pack is
hot, let it cool down before recharging.
• After charging, the battery pack may be stored in the charger as long as the charger
is not plugged in.
Cutting Line
• Replace the cutting line only with nylon monofilament 1/16" (1.65 mm) line, or with
pre-wound replacement spools. (See The Cutting Line).
• Always wind the line in the same direction as the arrow on the spool. (See To Refill
the Spool).
Cleaning
1. Wipe the outside of the Cordless Grass Trimmer, with a dry soft cloth. Do not hose down or
wash with water.
2. Scrape the guard and spool area to remove dried clippings and mud.
3. Brush or blow dust, debris, and grass clippings out of the air vents. Keep them free
of obstruction.
Lubrication
No lubrication is needed.
WARNING
To avoid risk of fire, electric shock, or electrocution:
• Do not use a damp cloth or detergent on the battery or battery charger.
• Always remove the battery pack before cleaning, inspecting, or performing
any maintenance on the Cordless Grass Trimmer.
CAUTION
Do not use strong solvents or detergents on the plastic housing or plastic
components. Certain household cleaners may damage and may also cause a
shock hazard.
Maintenance
