JOHN BLUE 8L Parts list manual

OVAL TUBE
SQUEEZE TUBE PUMPS
PARTS AND
INSTRUCTION MANUAL
JOHN BLUE COMPANY
DIVISION OF ADVANCED SYSTEMS TECHNOLOGY, INC.
165 Electronics Blvd, Huntsville, AL 35824
Telephone: [phone] - FAX: [phone]
Toll Free: 1-800-253
www.johnblue.com
-2583
Copyright 2016 John Blue Company
Printed in U.S.A. 12-M-30 Rev 9/19
Model 8L Shown

2
TABLE OF CONTENTS
Note to the Owner........................................................................................................................................... 2
Safety Precautions.......................................................................................................................................... 2
Pump Specifications ....................................................................................................................................... 3
Installation....................................................................................................................................................... 4
Maintenance ................................................................................................................................................... 6
Drive Factor Equations ................................................................................................................................... 6
Parts Lists ....................................................................................................................................................... 8
Warranty ......................................................................................................................................................... 12
SAFETY PRECAUTIONS
xSafety equipment such as gloves, goggles, etc. should be worn at all times while performing any
repairs, adjustments, or maintenance to the pumping system
xA careful operator is the best insurance against an accident.
xOnly trained and responsible people should operate equipment.
xCheck all valves, fittings, hose clamps, etc. for wear / leaks before admitting process fluid
to the system. Also, check again at regular intervals.
xReplace hoses when worn, cracked, or if leaking.
WARNING: USE OF THIS PRODUCT FOR ANY PURPOSES OTHER THAN ITS ORIGINAL INTENT, ABUSE OF
THE PRODUCT, AND/OR MODIFICATION TO THE ORIGINAL PRODUCT IS STRICTLY PROHIBITED BY JOHN
BLUE COMPANY. JOHN BLUE COMPANY RESERVES THE RIGHT TO DENY WARRANTY OR LIABILITY
CLAIMS IN ANY/ALL SITUATIONS INVOLVING MISUSE, ABUSE OR MODIFICATION.
THE ORIGINAL INTENT OF THIS PRODUCT DOES NOT INCLUDE USE WHERE THE MAXIMUM
ALLOWED SPEED, PRESSURE, OR TEMPERATURE IS EXCEEDED, AND IT DOES NOT INCLUDE
APPLICATIONS UTILIZING FLUIDS THAT ARE NOT COMPATIBLE WITH THE PRODUCT’S COMPONENT
MATERIALS. DO NOT USE THIS PRODUCT WITH FLAMMABLE OR COMBUSTIBLE FLUIDS SUCH AS
GASOLINE, KEROSENE, DIESEL, ETC…, AND DO NOT USE IN EXPLOSIVE ATMOSPHERES. FAILURE TO
FOLLOW THIS NOTICE MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE AND WILL VOID
THE PRODUCT WARRANTY. IF IN DOUBT ABOUT YOUR APPLICATION, CONTACT YOUR STOCKING
DEALER OR THE JOHN BLUE TECHNICAL STAFF AT 1-800-253-2583.
WARNING: THIS PRODUCT CAN EXPOSE YOU TO CERTAIN CHEMICALS, WHICH ARE KNOWN TO THE STATE
OF CALIFORNIA TO CAUSE CANCER OR BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE
INFORMATION GO TO: www.P65Warnings.ca.gov.
To The Owner
This manual has been prepared and illustrated to assist you in the maintenance of your JOHN BLUE PUMP.
Enter your serial number and the date of the purchase in the space provided below for future reference in service
information or for ordering parts. Because our engineering department is constantly improving products, we
reserve the right to make design and specification changes without notice.
Model Number: Serial Number: Purchase Date:

3
PUMP SPECIFICATIONS
Maximum Output per Hose:
3/8” Diameter Hose –
0.63 gpm
5/8” Diameter Hose –
1.26 gpm
Maximum Speed:
100
RPM Maximum Pressure:
6 psi
Rate Range GPA:
3/8” Diameter Hose –
1.5 to 25*
5/8” Diameter Hose –
3 to 50*
Part
Number
Metering
Discharge
Suction
Number
of Rows
Hose Size
Hose Size
Hose Size
Standard Pump Models
8B-1
8
3/8”
3/8”
11/4” FNPT
8L
8
5/8”
1/2”
1 1/4” FNPT
12B-1
12
3/8”
3/8”
1 1/4” FNPT
12L
12
5/8”
1/2”
1 1/4” FNPT
16B-1
16
3/8”
3/8”
1 1/4” FNPT
16L
16
5/8”
1/2”
1 1/4” FNPT
24B-1
24
3/8”
3/8”
1 1/4” FNPT
Hydraulic Pump Models
8B-1H
8
3/8”
3/8”
1 1/4” FNPT
8L-H
8
5/8”
1/2”
1 1/4” FNPT
12B-1H
12
3/8”
3/8”
1 1/4” FNPT
12L-H
12
5/8”
1/2”
1 1/4” FNPT
16B-1H
16
3/8”
3/8”
1 1/4” FNPT
16L-H
16
5/8”
1/2”
1 1/4” FNPT
Combination Pump Models
8B-1/8L
12B-1/8L
16
20
3/8 & 5/8”
3/8 & 5/8”
3/8 & 1/2”
3/8 & 1/2”
11/4” FNPT
1 1/4” FNPT
Double Pump Models
24LD
24
5/8”
1/2”
1 1/4” FNPT
32BD-1
32
3/8”
3/8”
1 1/4” FNPT
40BD-1
40
3/8”
3/8”
1 1/4” FNPT
48BD-1
48
3/8”
3/8”
1 1/4” FNPT
Note:
* GPA rating based on 5 MPH, 30 inch rows.
• B-1 pumps have stainless steel fittings.
• L pumps have plastic fittings.
• Combination pumps have B-1 pump at front (input drive end).

4
INSTALLATION INSTRUCTIONS
1. Pump Location
The John Blue Squeeze Tube Pump should always be mounted even with or lower than the
fertilizer tank for accurate metering. The pump can be mounted to any flat surface. There is no
need to have the pump mounted in the middle of the equipment. The pump creates enough
pressure to place it at the end of the implement. Make sure all connections, filters and
couplings are tight so the pump can lift and pull product to it. The speed should not exceed 100
RPM.
Any shaft that turns in ratio to the ground can be considered to drive the pump. The pump only
requires a small amount of torque to turn it. Typically it is one of the seed shafts, which can be
used, but try to have it before the transmission so that if you change seed population the
fertilizer rate remains unchanged.
2. Pump Mounting
Two angle iron bars with holes are supplied and can be bolted to each side of the pump. Undo
the frame end plate bolts, match up the holes in the angle iron and retighten the nuts. The
hook bolts supplied can be used over the angle iron or the frame channel to bolt the pump to
your equipment.
3. Pump Mounting of Combination Pumps
The mounting of combination and double pumps
is not different than what is described above as to
location and drive system. The exception is when
you want
to keep the starter fertilizer always at the same
rate and want to use the coned sprockets to
vary the nitrogen rates. Figure 1 shows this
type of system, where you drive both sides of
the pump.
(Picture A)
Special plumbing is needed because both manifolds will have product flowing to it. If two
different products are to be pumped, two independent plumbing systems must be used. As the
center manifold is fed through the chain it is important to check the clearance with the hose and
fittings used.
Note: The sprockets that come on
the side across from the coned
sprockets are not used and must
be removed.
(FIGURE 1)

5
Tube tension needs to be put on both rollers, see section 7. Rates of application are the same as
for a single pump and are detailed in the rate chart. Remember, “L” tubes apply twice as much
product as “B” tubes at the same RPM. You must calculate the effect of the sprockets for both.
4. Hose Arrangement
When you do not require all the squeeze tubes to be used, remove the tubes uniformly starting in
the middle taking onetube first from one side then the other. The plugs supplied should be installed
in the manifold in place of the tubes.
5. Plumbing
John Blue Company recommends using 1-1/4” ID hose between the tank and the pump. Smaller lines
may starve the pump reducing the application rate. Filters are recommended, but when rates are
lower than anticipated many times it is a filter that is clogged or the strainer mess is too small.
Aloop at the end of the delivery line will prevent product from draining as it will stop air from entering
the hose to displace product. Since the pump is holding the product all that will drain is the small
amount that can be displaced by air up to the loop in the line. A ball valve should be used to shut
off any system when not in use to ensure no leakage occurs.
Always use Teflon tape or pipe joint compound on all connections. Never over tighten fittings as this
may cause them to crack. Check the squeeze tube screw clamps, as they may need to be retightened.
The screw clamps when installed on new squeeze tubes can cause the tubes to extrude slightly
under pressure of the clamp. As this occurs over time it is best to retighten the screw clamps slightly
before starting a new pump. Only retighten the screw clamps on the inlet side where the tube
is attached to the manifold. Do not retighten the fittings in the manifold; they are sealed at
the factory.
6. Chain Adjustment
The chain between the John Blue Squeeze Tube coned sprockets is adjusted by removing the
master link and moving the chain to the correctposition.
7. Tube Tension Adjustment
The oval-shaped tubes need to be stretched
across the four rollers in order to perform
efficiently. To tighten the tension on the tubes
insert the handle, supplied with the pump, on
the tube tension bar #1 (see drawing). Using
the handle pull forward toward the manifold #2
until the latch #3 engages into the notch on the
frame end plate. When engaged the outlet fitting
rack #4 will have been pushed forward and will
stay in the forward position. There are two
notches on the frame end plate, use only the
minimum tension to stop product from flowing
through the pump. For new pumps this is the
first notch. The pump will not work without tube
tension. When the pump is not being used, the
tension should be taken off the tubes by releasing
the latch #3.

6
Check the filter size to make sure product can flow easily, open the ball valve and check for
leaks. Before going to the field, always check the rates as there can be variables that can cause a
difference between calculated rates and actual rates.
8. Hydraulic Pumps
Tractor hydraulics can be used to power the John Blue Squeeze Tube Pumps. Hydraulic pumps
come with the hydraulic motor and control valve, which is connected with standard hose and
fittings. There are many power take-off options associated with different tractor manufacturers
so it is best to consult your local tractor supplier for proper installation.
MAINTENANCE
When the pump is not in use, always take the tension off the tubes by releasing the latch. See
#7, Tube Tension Adjustment instructions.
DRIVE FACTOR EQUATIONS
The information and charts are provided to assist you in the initial set up of your squeeze tube
pump. The attached information provides the basic calculations for a squeeze pump
installation. This information is also available online at www.johnblue.com under “Calculate your
Rates.” It is highly recommended that you take advantage of the website to assist you in your
rate calculations.
COMPLETE THE FOLLOWING FOR ALL APPLICATIONS
Row Spacing =actual distance in inches between each point of application.
GPA Desired = amount of material to be applied in gallons per acre (GPA).
Wheel Diameter = ground wheel diameter in inches.
(If using a rub wheel measure the rub wheel diameter.)
Speed = the speed you will be traveling in MPH.
Step 1 Finding Pump RPM
.134 for B pump or
xx .067 for Lpump =
Row Spacing GPA Desired RPM of Mainshaft
Example: Row spacing is 12 inches; you want 29 GPA using an “L” pump.
Correct answer: 12 x 29 x.067 = 23 RPM (Round off to whole number)
Never operate the pumps over 100 RPM, this is affected by ground speed; see “Adjustment for
Speed.”
** For Hydraulic Driven Pumps; see “Adjustment for Speed.” **

7
Step 2 Finding Sprocket Ratio
The sprocket ratio is used to
determine the size sprocket needed
on the ground wheel and pump
jackshaft.
1681 =
RPM Main Shaft x Wheel Diameter Ratio Pump Jackshaft to
Ground Wheel
Example: RPM is 23 (from step 1) and your wheel diameter is 30 inches.
Correct answer:1681 = 2.4: Divide 1681 by 23 then divide the answer 73 by 30 = 2.4
(23)(30)
Step 3 Finding Actual Sprockets to Use
Count the number of teeth on the
driving sprocket you are using. The driving x =
sprocket is the sprocket on the ground
wheel, rub wheel or existing shaft.
Ratio from Step 2Teeth on Driving Teeth on Jack
Sprocket Shaft Sprocket
Example: The number of teeth on your driving sprocket is 10.
Correct Answer: 2.4 x 10 = 24 tooth sprocket on pump’s jackshaft.
Note that you may also use the coned sprockets to adjust the sprocket ratio between the
Jack (input) shaft and Main shaft according to this chart:
Sprocket Pair #
Main shaft speed vs. Jack
1
0.45
2
0.60
3
0.77
4
1.00 (default)
5
1.28
6
1.66
7
2.20
Direct Couple to Existing Shaft
When you want to turn the pump’s jackshaft directly from an existing shaft, complete Step 1 to
find the main shaft RPM for the desired GPA. At the desired speed of application count the RPM of
the existing shaft and divide that number by the mainshaft RPM to find the sprocket ratio.
RPM of Existing Shaft =
Mainshaft RPM from Step 1Ratio Jackshaft to Existing Shaft
Example: RPM from Step 1 is 40 and your shaft turns 80 RPM’s at 5 MPH.
Correct Answer: 80 divided by 40 =2.0 This is the ratio between the pump’s jackshaftand your
driving shaft. Use this factor in Step 3above to select the correct cone sprocket position.
Adjusting for Speed
All calculations are based on 5 MPH. You need to adjust for the speed you plan to travel for
hydraulic driven pumps to get the right RPM. For ground driven pumps we need to insure that the
pump operates fewer than 100 RPM’s at the speed you travel. Take the RPM from Step 1 or if you
use the coned sprockets the adjusted RPM and multiply as follows:
3 MPH
RPM x 0.6 =
7 MPH
RPM x 1.4 =
4 MPH
RPM x 0.8 =
8 MPH
RPM x 1.6 =
5 MPH
RPM x 1.0 =
9 MPH
RPM x 1.8 =
6 MPH
RPM x1.2 =
10 MPH
RPM x 2.0 =

8
PARTS LIST: STANDARD SQUEEZE TUBE PUMP
Item #
Description
24B-1
16L
16B-1
12L
12B-1
8L
8B-1
1
Base Channel (2)
01-2410
01-1620
01-1610
01-1220
01-0820
01-0820
01-0810
2
Frame End Support
02-2410
02-1620
02-1610
02-1220
02-0820
02-0820
02-0810
3
Frame End Plate (2)
03-2410
03-2410
03-1610
03-2410
03-1610
03-1610
03-1610
4
Outlet Fitting Rack
04-2410
04-1620
04-1610
04-1220
04-1210
04-0820
04-0810
5
Tube Tension Rack
05-2410
05-1620
05-1610
05-1220
05-1210
05-0820
05-0810
6
Push Rod (2)
06-0011
06-0021
06-0011
06-0021
06-0011
06-0021
06-0011
7
Supply Manifold
07-2410
07-1620
07-1610
07-1220
07-1210
07-0820
07-0810
8
Manifold Clamp (2)
07-9002
07-9002
07-9001
07-9002
07-9001
07-9001
07-9001
9
Squeeze Tube*
08-0010
08-0020
08-0010
08-0020
08-0010
08-0020
08-0010
10
Inlet Fitting * Plastic
n/a
08-0021
n/a
08-0021
n/a
08-0021
n/a
Inlet Fitting * SS
08-0015
n/a
08-0015
n/a
08-0015
n/a
08-0015
11
Outlet Fitting *
n/a
08-0022
n/a
08-0022
n/a
08-0022
n/a
Outlet Fitting * SS
08-0013
n/a
08-0013
n/a
08-0013
n/a
08-0013
12
SS Screw Clamps*
08-9003
08-9004
08-9003
08-9004
08-9003
08-9004
08-9003
13
Jack Shaft
10-2411
10-1621
10-1611
10-1221
10-0821
10-0821
10-0811
Manifold Plug*
08-9001
08-9002
08-9001
08-9002
08-9001
08-9002
08-9001
*Requirements based on number of outlets

9
PARTS LIST: DOUBLE SQUEEZE TUBE PUMPS
Item Description 24LD 32BD-1 40BD-1 48BD-1
1
Base Channel (3)
01-1220
01-1610
01-1620
01-2410
2
Frame Support Bar (2)
02-1220
02-1610
02-1620
02-2410
3
Outlet Fitting Rack (2)
04-1220
04-1610
04-2010
04-2410
4
Tube Tension Bar (2)
05-1220
05-1610
05-2010
05-2410
5
Push Rod (4)
06-0021
06-0011
06-0011
06-0011
6
Manifold -Front
07-1220
07-3211
07-2010
07-2410
7
Manifold -Center
07-2420
07-3212
07-4010
07-4812
8
Squeeze Tube*
08-0020
08-0010
08-0010
08-0010
9
Outlet Fitting * Plastic
08-0022
n/a
n/a
n/a
Outlet Fitting * SS
n/a
08-0013
08-0013
08-0013
10
Inlet Fitting * Plastic
08-0021
n/a
n/a
n/a
Inlet Fitting * SS
n/a
08-0015
08-0015
08-0015
11
SS Screw Clamps
08-9004
08-9003
08-9003
08-9003
Manifold Plug*
08-9002
08-9001
08-9001
08-9001
*Requirements based on number of outlets

10
PARTS LIST: COMBINATION SQUEEZE TUBE PUMPS
Item
Description
8B-1 / 8L
12B-1 / 8L
1
Base Channel (3)
01-0820
01-0820
2
Frame Support Bar (2)
02-0820
02-0820
3
Outlet Fitting Rack (2)
8B 04-1210
12B 04-1210
8L 04-0820
8L 04-0820
4
Tube Tension Bar (2)
8B 05-1210
12B 05-1210
8L 05-0820
8L 05-0820
5
Push Rod (4)
8B 06-0011
12B 06-0011
8L 06-0021
8L 06-0021
6
Manifold -Front
07-1611
07-1610
7
Manifold -Center
07-1622
07-1622
8
Squeeze Tube*
B08-0010
B08-0010
L08-0020
L08-0020
9
Outlet Fitting * SS
B08-0013
B08-0013
Outlet Fitting * Plastic
L08-0022
L08-0022
10
Inlet Fitting * SS
B08-0015
B08-0015
Inlet Fitting * Plastic
L08-0021
L08-0021
11
SS Screw Clamps
B08-9003
B08-9003
L08-9004
L08-9004
Manifold Plug*
L08-9002
L08-9002
B08-9001
B08-9001
*Requirements based on number of outlets

11
Parts List
Complete Roller Assembly
Standard Squeeze Tube Pump
Item
Description
24B-1
16L
16B-1
12L
12B-1
8L
8B-1
1
Regular Roller
09-2410
09-1620
09-1610
09-1220
09-0820
09-0820
09-0810
2
Modified Roller
09-2412
09-1622
09-1612
09-1222
09-0822
09-0822
09-0812
3
Regular Mainshaft
10-2410
10-1620
10-1610
10-1220
10-0820
10-0820
10-0810
4
Modified Mainshaft
10-2412
10-1622
10-1612
10-1222
10-0822
10-0822
10-0812
5
Rollers (4)
09-2411 09-1621 09-1611 09-1221 09-0821 09-0821 09-0811
Double and Combination Squeeze Tube Pumps
24LD 32BD-1 40BD-1 48BD-1
Item
Description
Front
Center
Front
Center
Front
Center
Front
Center
1
Regular Roller Assem
09-2423
09-2424
09-3213
09-3214
09-4010
09-4011
09-4813
09-4814
2
Modified Roller
09-2423
09-2424
09-3213
09-3214
09-4010
09-4011
09-4810
09-4811
3
Regular Mainshaft
10-2423
10-2424
10-3212
10-3214
10-3223
10-3224
10-4813
10-4814
4
Modified Mainshaft
10-2423
10-2424
10-3212
10-3214
10-3223
10-3224
10-4813
10-4814
5
Rollers (4)
09-1221
09-1221
09-1611
09-1611
09-1621
09-1621
09-2411
09-2411
8B-1 / 8L 12B-1 / 8L
Item
Description
Front
Center
Front
Center
1
Regular Roller
09-1623
09-1624
09-1623
09-1624
2
Modified Roller
09-1623
09-1624
09-1623
09-1624
3
Regular Mainshaft
10-1623
10-1624
10-1623
10-1624
4
Modified Mainshaft
10-1623
10-1624
10-1623
10-1624
5
Rollers (4)
09-0821 09-0821 09-0821 09-0821

LIMITED WARRANTY
THIS WARRANTY IS IN LIEU OF ALL OTHER WRITTEN OR EXPRESS WARRANTIES AND REPRESENTATIONS.
ANY IMPLIED WARRANTIES INCLUDING MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE
ARE EXPRESSLY LIMITED TO THIS WRITTEN WARRANTY. JOHN BLUE COMPANY SHALL NOT BE LIABLE
FOR CONSEQUENTIAL DAMAGES.
Use of this product for any purpose other than its original intent, abuse of the product, and/or any modification to the
original product is strictly prohibited by the manufacturer, John Blue Company. Any modification to the product should
be approved by John Blue Company prior to use. John Blue Company will deny Warranty claims and liability in any
situation involving misuse, abuse or modification.
Each new machine or component manufactured by John Blue Company through original buyer is warranted by John
Blue Company to buyer and to any party or parties to whom buyer may resell, lease or lend the equipment to be free
from defects in material and workmanship under normal use and service. This obligation of John Blue Company under
this warranty is limited to the repair or replacement of defective parts or correction of improper workmanship of any
parts of such equipment which shall within one year from the date of John Blue’s original delivery thereof, be returned
to John Blue’s factory, transportation charges prepaid and which John Blue Company shall determine to its satisfaction
upon examination thereof to have been thus defective. When it is impractical to return the defective parts of such
equipment to John Blue’s factory, then John Blue shall have no liability for the labor cost involved in repairing or
replacing any such parts and shall be liable solely for supplying the material necessary to replace or repair the
defective parts, provided that prior thereto John Blue Company shall have determined to its satisfaction that any such
parts are thus defective.
This warranty shall not apply to any equipment which shall have been repaired or altered outside John Blue’s factory in
anyway so as to affect its durability, nor which has been subjected to misuse, abuse, negligence or accident, or
operated in any manner other than in accordance with operating instructions provided by John Blue Company. This
warranty does not extend to repairs made necessary by the use of inferior or unsuitable parts or accessories, or parts
or accessories not recommended by John Blue Company.
John Blue Company makes no warranties in respect to parts, accessories or components not manufactured by John
Blue Company, same ordinarily being warranted separately by their respective manufacturers.
DIVISION OF ADVANCED SYSTEMS TECHNOLOGIES HUNTSVILLE, AL [phone]
John Blue Company
Division of Advanced Systems Technology
165 Electronics Blvd, Huntsville, AL 35824
Telephone: [phone] -Fax [phone]
Toll Free 1-800-253-2583
www.johnblue.com
YOUR LOCAL DEALER
