JOHN BLUE CS-155RG User manual


12-M-80 1 Rev. 10/2021
WARNING: USE OF THIS PRODUCT FOR ANY PURPOSES OTHER THAN ITS ORIGINAL INTENT, ABUSE OF THE PRODUCT, AND/OR MODIFICATION TO THE ORIGINAL PRODUCT IS
STRICTLY PROHIBITED BY JOHN BLUE COMPANY. JOHN BLUE COMPANY RESERVES THE RIGHT TO DENY WARRANTY OR LIABILITY CLAIMS IN ANY/ALL SITUATIONS INVOLVING
MISUSE, ABUSE OR MODIFICATION.
THE ORIGINAL INTENT OF THIS PRODUCT DOES NOT INCLUDE USE WHERE THE MAXIMUM ALLOWED PRESSURE OR TEMPERATURE IS EXCEEDED, AND IT DOES NOT
INCLUDE APPLICATIONS UTILIZING FLUIDS THAT ARE NOT COMPATIBLE WITH THE PRODUCT’S COMPONENT MATERIALS. DO NOT USE THIS PRODUCT WITH FLAMMABLE OR
COMBUSTIBLE FLUIDS SUCH AS GASOLINE, KEROSENE, DIESEL, ETC... FAILURE TO FOLLOW THIS NOTICE MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE AND WILL
VOID THE PRODUCT WARRANTY. IF IN DOUBT ABOUT YOUR APPLICATION, CONTACT YOUR STOCKING DEALER OR THE JOHN BLUE TECHNICAL STAFF AT 1-800-253-2583.
WARNING: This product can expose you to certain chemicals, which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information go to:
www.P65Warnings.ca.gov.
SAFETY PRECAUTIONS: EQUIPMENT SHOULD BE OPERATED BY RESPONSIBLE PEOPLE. A CAREFUL OPERATOR IS THE BEST INSURANCE AGAINST AN ACCIDENT.
FILL SYSTEM WITH WATER FIRST AND CHECK FOR LEAKS – REPLACE HOSES WHEN WORN OR CRACKED.
The CS-155 Centrifugal spray pump is available in a Gas Engine Drive configuration:
Pump Specifications and Performance:
Max flow: 115 gpm @ 3600 RPM
Max pressure: 78 psi @ 3600 RPM
Shaft Size 3/4” Inner Diameter
Pump Port size: 1-1/2” FPT & 220 Flange Inlet
1-1/4” FPT & 200 Flange Outlet
Installation and
Operation Manual
CS‐155RG
Cast Iron Wet-Seal 1-1/2” x 1-1/4”
Centrifugal Spray Pump


© 2021 John Blue Co.2
Installation:
The CS-155RG pump is configured for use with a Honda GX-160 gas engine (John Blue Part Number: 113798-01). The
pump can also be purchased assembled to the Honda engine (John Blue Part Number: CS-155RG-5H).
**Note that any plumbing must be supported so that its weight does not hang off of the pump – this will void the warranty.
Storage:
After use, flush the pump with a solution that will neutralize the fluid you have been pumping, and then drain. Use RV
Antifreeze for Storage.
Maintenance:
Inspect the seal reservoir fluid level using the sight window – the fluid level should be above the middle of the window. If
the fluid is dirty, drain the pump by vacuum or turning upside down, then replace with 50/50 premixed ethylene glycol
antifreeze. If fluid is cloudy, impeller side seal may be leaking.
Pump Components:


© 2021 John Blue Co.3
Pump Troubleshooting:



ISSUE PROBABLE CAUSE
Pump makes rattling noise while running Cavitation or pump starvation (suction lift is too high or
the inlet line is too restrictive)
Reduced pump output or pressure Clogged impeller or inlet piping (including strainer)
Leaks in suction line or at inlet gasket
Collapsed suction line
Trapped air in sections of suction line
Suction lift is too great – flooded inlet recommended
Discharge lift is too great
Worn or damaged parts (impeller or volute)
Pump fails to prime or slow prime Leaks in suction line or at inlet gasket
Suction lift is too great – flooded inlet recommended
Collapsed suction line
Seal reservoir fluid changes level Leak at the input shaft seal if level is low
Leak at the impeller side seal if level is high


© 2021 John Blue Co.4

Note to the Owner
The pump should be inspected annually for any wear or damage to any of the components in order to ensure proper
operation. Enter the date of installation in the space provided for future reference. This information will be required for
ordering replacement parts or servicing your pump.
Our engineering department constantly improves its products. We reserve the right to make design and specification
changes without notice.
DATE OF INSTALLATION: ___________
John Blue Company
Division of Advanced Systems Technology
165 Electronics Blvd., Huntsville AL 35824
Telephone: [phone] Fax [phone]
Toll Free 1-800-253-2583
www.johnblue.com
   YOURLOCALDEALER
LIMITED WARRANTY
THIS WARRANTY IS IN LIEU OF ALL OTHER WRITTEN OR EXPRESS WARRANTIES AND REPRESENTATIONS. ANY IMPLIED
WARRANTIES INCLUDING MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE ARE EXPRESSLY LIMITED TO THIS
WRITTEN WARRANTY. JOHN BLUE COMPANY SHALL NOT BE LIABLE FOR CONSEQUENTIAL DAMAGES.
Use of this product for any purpose other than its original intent, abuse of the product, and/or any modification to the original product is
strictly prohibited by the manufacturer, John Blue Company. Any modification to the product should be approved by John Blue Company
prior to use. John Blue Company will deny Warranty claims and liability in any situation involving misuse, abuse or modification.
Each new machine or component manufactured by John Blue Company through original buyer is warranted by John Blue Company to buyer
and to any party or parties to whom buyer may resell, lease or lend the equipment to be free from defects in material and workmanship
under normal use and service. This obligation of John Blue Company under this warranty is limited to the repair or replacement of defective
parts or correction of improper workmanship of any parts of such equipment which shall within one year from the date of John Blue’s original
delivery thereof, be returned to John Blue’s factory, transportation charges prepaid and which John Blue Company shall determine to its
satisfaction upon examination thereof to have been thus defective. When it is impractical to return the defective parts of such equipment to
John Blue’s factory, then John Blue shall have no liability for the labor cost involved in repairing or replacing any such parts and shall be
liable solely for supplying the material necessary to replace or repair the defective parts, provided that prior thereto John Blue Company shall
have determined to its satisfaction that any such parts are thus defective.
This warranty shall not apply to any equipment which shall have been repaired or altered outside John Blue’s factory in any way so as to
affect its durability, nor which has been subjected to misuse, abuse, negligence or accident, or operated in any manner other than in
accordance with operating instructions provided by John Blue Company. This warranty does not extend to repairs made necessary by the
use of inferior or unsuitable parts or accessories, or parts or accessories not recommended by John Blue Company.
John Blue Company makes no warranties in respect to parts, accessories or components not manufactured by John Blue Company, same
ordinarily being warranted separately by their respective manufacturers.
DIVISION OF ADVANCED SYSTEMS TECHNOLOGIES HUNTSVILLE, AL [phone]
