ENGINEERING GUIDE
VERTICAL STACKED
WATER SOURCE HEAT PUMPS
PREMIUM EFFICIENCY VPCS SERIES • 16 EER

FORM 145.18-EG2 (317)
2JOHNSON CONTROLS
CONTROL OPTIONS
Thermostat Location
Remote Whip Surface ADA Door
2-Speed Unit-
Mounted Switch M W P A
3-Speed Thermo-
stat Control 3 4 5 7
Nomenclature
VERTICAL STACKED WATER SOURCE HEAT PUMP - CABINET
VPB 12 M 1 D E A 2 2T 4 0 A
PRODUCT CATEGORY
VPB = Vertical Stacked Heat Pump - Standard
Cabinet Assembly
VPM = Vertical Stacked Heat Pump - Master
Cabinet Assembly
VPS = Vertical Stacked Heat Pump - Slave
Cabinet Assembly
VPT = Vertical Stacked Heat Pump - Standard
Cab Single Riser Assembly
UNIT CAPACITY
09 = .75 TON
12 = 1 TON
15 = 1.25 TON
18 = 1.5 TON
VOLTAGE
1 = 208/230-60-1
ELECTRICAL CONNECTION
O = None (Terminal Block)
D = Non-Fused Disconnect
F = Disconnect w/Fuses
BLOWER OPTIONS
E = ECM Blower
F = HI-Static ECM
G= ECM w/ Continuous Low Speed
H = HI-Static ECM w/ Continuous Low Speed
CABINET OPTIONS
CABINET HEIGHT NO OA
OPTIONS
LEFT
TOP OA ENTRY -
4" ROUND
LEFT
TOP OA ENTRY-
4" ROUND W/
MOTORIZED DAMPER
RIGHT
TOP OA ENTRY-
4" ROUND
RIGHT
TOP OA ENTRY
- 4" ROUND W/
MOTORIZED DAMPER
88" Cabinet A G L R W
80" Cabinet B H M T X
88" Cabinet w/ 2" Stand C J N U Y
80" Cabinet w/ 2" Stand E 1 3 5 7
80" Cabinet w/ 4" Stand D K P V Z
80" Cabinet w/ 8" Stand F 2 4 6 8
RISER ARRANGEMENT
1 = Right Hand Risers
2 = Left Hand Risers
3 = Back Risers
4 = R/Hand Risers With Cover
5 = L/Hand Risers With Cover
6 = Back Risers With Cover
SUPPLY AIR CONFIGURATION
1H = Single Horizontal Supply
2H = Double Horizontal Supply
3H = Triple Horizontal Supply
0T = Top Only
1T = Single Horizontal Supply + Top
2T = Double Horizontal Supply + Top
3T = Triple Horizontal Supply + Top
00 = Field Cut (No Openings)
HORIZONTAL DISCHARGE OPENING
ORIENTATION
00, 0T 1H, 1T 2H, 2T 3H, 3T
X = None B = Back 1 = Left +
Front
7 = Front + Left
+ Right
F = Front 2 = Left +
Back
8 = Front +
Right + Back
L = Left 3 = Left +
Right
9 = Front + Left
+ Back
R = Right 4 = Right
+ Back
5 = Right
+ Front
6 = Back
+ Front
DESIGN SERIES
A = Current
MISC. OPTIONS
Option Filters: MERV (Depth)
4 (1") 8 (1") 13 (2")
Galv Drain Pan 0 F G
SST Drain Pan S T U
Sealed Openings L M N
SST DP w/ Sealed C D E
24 = 2 TON
30 = 2.5 TON
36 = 3 TON

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 3
VERTICAL STACKED WATER SOURCE HEAT PUMP - CHASSIS
VPCS 12 A 1 0 0 A C 0
Nomenclature (Cont'd)
PRODUCT
CATEGORY
VPCS = Vertical Stacked HP Chassis R-410
DESIGN SERIES
A = Current
VOLTAGE
1 = 208/230-60-1
WATER VALVE & PUMP OPTIONS
VALVE OPTIONS VALVE
ONLY Y-STRAINER PUMP* Y-STRAINER & PUMP*
No Water Control Valve O S P B
Motorized 2-Way Shut-Off Valve M Y
Motorized 3-Way Shut-Off Valve N V
*Only available with single riser cabinet (VPT)
MISC. OPTIONS
0 = NPSH Water Connection
C = JIC Water Connection
S = Quiet Chassis
B = Quiet Chassis w/ JIC Water
Connection
WATERSIDE OPTIONS
C = Standard Water Coil
N = Cupro-Nickel Water Coil
AIRSIDE OPTIONS
A = Standard Airside Coil
C = Dipped Electrofin Coating
AUTO-FLOW
REGULATOR
0 = No Flow Control Valve
B = 1.5 USGPM
C = 2.0 USGPM
D = 2.5 USGPM
E = 3.0 USGPM
F = 3.50 USGPM
H = 4.0 USGPM
J = 4.5 USGPM
K = 5.0 USGPM
L = 6.0 USGPM
M = 7.0 USGPM
N = 8.0 USGPM
P = 9.0 USGPM
R = 10.0 USGPM
Approvals
UNIT CAPACITY
09 = .75 TON
12 = 1 TON
15 = 1.25 TON
18 = 1.5 TON
24 = 2 TON
30 = 2.5 TON
36 = 3 TON

FORM 145.18-EG2 (317)
4JOHNSON CONTROLS
Table Of Contents
NOMENCLATURE ....................................................................................................................................................2
APPROVALS ............................................................................................................................................................3
TABLE OF CONTENTS ............................................................................................................................................4
INTRODUCTION.......................................................................................................................................................5
PRODUCT OVERVIEW ............................................................................................................................................6
STANDARD AND OPTIONAL FEATURES ..............................................................................................................7
PHYSICAL DATA ....................................................................................................................................................10
AHRI/ISO 13256-1 PERFORMANCE DATA........................................................................................................... 11
PERFORMANCE DATA - EC MOTOR ...................................................................................................................12
PERFORMANCE DATA..........................................................................................................................................19
RISER SELECTION AND DATA.............................................................................................................................20
BLOWER PERFORMANCE ...................................................................................................................................21
ELECTRICAL DATA ...............................................................................................................................................22
DIMENSIONAL DATA .............................................................................................................................................23
HOSE KITS - NPSH WATER CONNECTION .........................................................................................................31
HOSE KITS - JIC WATER CONNECTION .............................................................................................................32
DISCHARGE CONFIGURATIONS .........................................................................................................................33
WIRING DIAGRAM.................................................................................................................................................36
SPECIFICATIONS...................................................................................................................................................37

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 5
Introduction
Performance, Value and Stainability in a Labor-Saving Package.
The Vertical Stacked Water Source Heat Pumps (VPCS) from Johnson Controls offer
the ultimate in multi-story HVAC design flexibility. The VPCS Series is a compact, con-
cealed system, capable of providing total heating and cooling functions for a single zone
or multiple rooms. These units offer the flexibility of a four-pipe fan coil system at the
cost of a two-pipe system, with the added flexibility of individual tenant metering. VPCS
Series units are ideally suited for the total heating and cooling needs of any two-plus story
building with a consistent floor plan.
• Hotels
• High-Rise Apartments / Condominiums
• Hospitals / Nursing homes
• Dormitories
• Renovatedofcespace
The space saving VPCS unit is a two-part system featuring a self-supporting, pre-piped
cabinet, and a removable heat pump chassis. The cabinet, complete with supply/return/
drain risers, is installed during the intermediate phase of building construction. The cabi-
net is framed-in, and covered with drywall, as part of the interior wall structure. The
finished equipment installation is hidden from view, blending with the decor of the room.
Access to the mechanical components of the unit can be made entirely through the front/
return air panel.
The provision for as many as three cabinet supply air outlets allows for maximum design
flexibility and cost savings. One strategically located unit can serve up to three sepa-
rate rooms without the need for ductwork. The ease of removal and replacement of the
heat pump chassis offers enhanced serviceability. A chassis that requires service may be
quickly removed, replaced with a back-up chassis, and serviced at a more convenient
time or place.
All units are tested and certified by AHRI / ISO 13256-1 and ETL for United States and
Canada. Johnson Controls stacked heat pump design exceeds ASHRAE 90.1 require-
ments at all rating conditions, making the VPCS series an excellent choice for water-loop
and geothermal applications.

FORM 145.18-EG2 (317)
6JOHNSON CONTROLS
Refrigerant
R-410A
Sizes
0.75 – 3 Tons (2.6 – 10.6 kW)
Models Available
Cabinets:
VPB Standard Assembly
VPM Master Assembly
VPS Slave Assembly
VPT Standard Single Riser Assembly
Chassis:
VPCS Heat Pump Assembly
Product Overview
1
2
3
4
5
6
7
8
9
10
1112
Features
1. Terminal box
2. Double-deectiondischargegrille
(optional: opposed blade damper)
3. Sight/sound discharge bafes on all
horizontal openings
4. Type M copper risers (optional: Type L)
5. Non-fused electrical disconnect
6. EC motor
7. Stainless steel braided hoses
8. Copper tube aluminum n refrigerant-
to-air coil (optional: dipped electron
coated coil)
9. MERV4throw-awaylter
(optional: MERV 8)
10. Microprocessor control box
11. ASHRAE 62.1 compliant removable
double-sloped drain pan
(optional: stainless steel)
12. Acoustic perimeter return air intake
door (locking options available)
LD19510

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 7
STANDARD FEATURES
Construction
• AHRI/ISO13256-1certiedandlabeled
• Galvanized steel construction
• ½”thickberglassinsulation
• Integrallterrackwith1”throwawaylter
Decorator Front Panel
• Perimeter intake return air door
• Durable powder coat paint
• Magnetic latches
Supply Air
• Front, back, side, and/or top outlets
• Sightandsoundbafes
Air-to-Refrigerant Coils
• R-410A direct expansion air coil
• 3/8” O.D. seamless copper tubes
• Highefciencyaluminumnsurfaceforoptimizingheattransfer,pressuredrop,and
carryover
• Easily removable for service
Water-to-Refrigerant Coils
• Coaxial heat exchanger with convoluted inner tube design
• Capableofoperationwithanenteringuidtemperaturerangeof20°Fto110°F
• Riser connection with stainless steel braided hoses
Drain Pans
• Single wall, galvanized steel
• Fully insulated
• P-trap factory installed
• Condensate switch
Standard and Optional Features

FORM 145.18-EG2 (317)
8JOHNSON CONTROLS
Fan Assemblies
• Forward curved, DWDI centrifugal type blowers
• 208/230V, single phase, EC motors
Electrical
• cETL listed for safety compliance
• Electricalenclosurewithaccessdoorforeldwiringterminations
• Microprocessor controller handles reversing valve operation (no heat pump thermo-
stat needed)
• Terminalblockforeldconnections
• Single point power connection
OPTIONAL FEATURES
Construction
• Master/Slave arrangements
• 1”MERV8lter
Decorator Front Panel
• Quarter turn or key lock
Supply Air
• Doubledeectiondischargegrille
• Opposed blade damper
Outside Air
• 4” round connection on top left/right of cabinet
• Motorized damper
Drain Pans
• Stainless steel construction
Fan Assemblies
• High-static EC motors
Electrical
• Non-fused disconnect or disconnect with fusing
Piping Options
• 2-way and 3-way motorized valves
• Fixedowcontrolvalves
• P/T ports and Y-strainers
Standard and Optional Features (Cont'd)

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 9
Thermostats
• Digital display
• Non-programmable or programmable
• Fan speed control
• ADA height thermostat mounting
• Communicating thermostat options
Risers
• Type M or L copper with swaged connections
• ¾” to 3” diameters
• ½” and ¾” closed cell insulation
• Type M copper condensate riser
• Riser extensions
• Riser cover
• Ship in advance risers
Standard and Optional Features (Cont'd)

FORM 145.18-EG2 (317)
10 JOHNSON CONTROLS
Physical Data
TABLE 1 - VPCS SERIES
PREMIUM SERIES MODEL 09 12 15 18 24 30 36
Nominal Cooling (Ton) 10.75 1.0 1.25 1.5 2.0 2.5 3.0
COMPRESSOR TYPE ROTARY SCROLL
Refrigerant Charge (Oz) 37 39 45 47 51 52 58
AIR COIL-TYPE ENHANCED COPPER TUBES, ENHANCED ALUMINUM FINS
Face Area (Sq Ft) 1.83 1.83 2.72 2.72 3.14 3.38 3.38
Rows/Fpi 2/14 3/14 3/14 3/14 3/14 3/14 3/14
WATER COIL-TYPE HIGH EFFICIENCY GREEN SURFACE CO-AXIAL
ECM BLOWER/MOTOR DWDI FORWARD-CURVED CENTRIFUGAL / ECM DIRECT-DRIVE
Diameter X Width (In) 9x4T 9x4T 9x7T 9x7T 10x7T 9x8 9x8
Motor Hp 0.33 0.33 0.33 0.33 0.33 0.50 0.50
FILTER QUANTITY-SIZE (IN) 1-14x25x1 1-14x25x1 1-16x30x1 1-16x30x1 1-20x30x1 1-20x30x1 1-20x30x1
FLEXIBLE HOSE SIZE 1/2" 1/2" 1/2" 1/2" 3/4" 3/4" 3/4"
CONDENSATE CONNECTION SIZE 7/8" ID 7/8" ID 7/8" ID 7/8" ID 7/8" ID 7/8" ID 7/8" ID
CABINET WEIGHT (LB) 2145 145 145 145 175 175 175
CHASSIS WEIGHT (LB) 104 110 117 137 156 165 172
NOTES:
1. Nominal Capacity calculated in accordance with ARI / ISO Standard 13256-1 for Water Loop Application
2. Cabinet weight is approximate and does not include weight of risers
TABLE 2 - OPERATING LIMITS*
COOLING HEATING
MIN. ENTERING WATER 30 ºF 20 ºF
MAX. ENTERING WATER 110 ºF 90 ºF
*Units are capable of operation with an entering fluid temperature range of 20 ºF to 110 ºF

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 11
AHRI/ISO 13256-1 Performance Data
TABLE 3 - EC MOTORS (ECM)
MODEL
FLOW
RATE
(USGPM)
COOLING HEATING WATER LOOP CONDITIONS1GROUND WATER CONDITIONS2GROUND LOOP CONDITIONS3
COOLING HEATING COOLING HEATING COOLING HEATING
AIR FLOW (SCFM) CAPACITY
(BTUH)4EER CAPACITY (BTUH)5COP CAPACITY (BTUH)4EER CAPACITY (BTUH)5COP CAPACITY (BTUH)4EER CAPACITY (BTUH)5COP
09 2.4 375 400 9,700 15.6 12,800 5.2 11,400 25.0 10,300 4.4 10,000 17.5 7,900 3.5
12 2.8 450 500 11,900 15.5 15,000 5.0 13,900 22.5 12,200 4.3 12,400 17.5 9,600 3.5
15 3.75 520 580 14,800 16.4 16,900 5.1 17,100 23.5 14,000 4.6 15,500 18.5 10,600 3.6
18 5 700 750 18,400 16.0 21,400 5.6 21,600 24.4 17,800 4.7 19,000 18.0 13,700 3.7
24 6.2 850 950 24,300 16.0 28,900 5.7 27,000 24.8 23,800 4.9 25,300 18.5 18,600 4.0
30 7.5 1075 1075 30,100 16.6 34,000 5.6 34,200 24.4 27,900 4.8 31,300 18.5 21,800 3.8
36 9 1100 1250 36,300 15.3 44,000 5.1 40,800 23.2 35,900 4.4 37,400 17.0 27,800 3.6
NOTES:
1. Water Loop capacities are rated at 86 °F EWT Cooling, 68 °F EWT Heating.
2. Ground Water capacities are rated at 59 °F EWT Cooling, 50 °F EWT Heating.
3. Ground Loop capacities are rated at 77 °F EFT Cooling, 32 °F EFT Heating.
4. All Cooling capacities based upon 80.6 °F DB, 66.2 °F WB entering air temperature.
5. All Heating capacities based upon 68 °F DB, 59 °F WB entering air temperature.

FORM 145.18-EG2 (317)
12 JOHNSON CONTROLS
Performance Data - EC Motor
TABLE 4 - VPCS09 - EC MOTOR (ECM)- COOLING AIRFLOW: 375 CFM AND HEATING AIRFLOW: 400 CFM
EWT GPM WPD COOLING HEATING
PSI FT TC SC SHR KW HR EER HTG KW HE LAT COP
20 3.2 5.7 13.1 5.8 0.55 4.2 81.4 3.1
30
1.6 1.9 4.5 12.7 9.3 0.73 0.34 13.6 37.7 7.0 0.59 5.3 84.1 3.5
2.4 3.4 7.9 12.9 9.4 0.73 0.34 13.8 38.6 7.3 0.59 5.6 84.9 3.6
3.2 5.5 12.7 13.0 9.5 0.73 0.33 13.9 39.4 7.5 0.60 5.8 85.4 3.7
40
1.6 1.9 4.3 12.2 9.1 0.75 0.38 13.2 32.2 9.0 0.63 7.2 88.8 4.2
2.4 3.3 7.6 12.3 9.1 0.74 0.37 13.3 33.8 9.0 0.63 7.2 88.9 4.2
3.2 5.3 12.2 12.4 9.2 0.74 0.36 13.4 34.5 9.2 0.63 7.3 89.2 4.2
50
1.6 1.8 4.1 11.6 8.8 0.76 0.43 12.8 27.1 9.7 0.65 7.8 90.4 4.4
2.4 3.1 7.2 11.8 8.9 0.76 0.41 12.9 28.7 10.0 0.66 8.1 91.2 4.5
3.2 5.1 11.7 11.8 8.9 0.75 0.40 12.9 29.4 10.3 0.66 8.3 91.8 4.5
60
1.6 1.7 3.9 11.1 8.6 0.78 0.49 12.5 22.7 10.9 0.67 8.9 93.3 4.8
2.4 3.0 6.9 11.2 8.6 0.77 0.47 12.6 23.9 11.4 0.67 9.4 94.4 5.0
3.2 4.8 11.1 11.3 8.7 0.77 0.46 12.6 24.4 11.8 0.67 9.8 95.2 5.2
70
1.6 1.6 3.7 10.6 8.4 0.79 0.56 12.2 19.0 12.3 0.67 10.3 96.5 5.4
2.4 2.9 6.6 10.7 8.5 0.79 0.54 12.3 19.9 12.9 0.67 10.9 97.9 5.6
3.2 4.6 10.6 10.8 8.4 0.78 0.53 12.3 20.4 13.4 0.68 11.4 99.0 5.8
80
1.6 1.5 3.6 10.1 8.2 0.81 0.63 11.9 16.1 13.8 0.69 11.7 99.9 5.9
2.4 2.7 6.3 10.2 8.3 0.81 0.61 12.0 16.8 14.5 0.70 12.4 101.6 6.1
3.2 4.4 10.1 10.3 8.2 0.80 0.60 12.0 17.2 15.0 0.72 12.9 102.8 6.2
90
1.6 1.5 3.4 9.6 8.0 0.84 0.70 11.7 13.7 15.3 0.72 13.1 103.4 6.2
2.4 2.6 6.0 9.7 8.0 0.83 0.68 11.7 14.3 16.1 0.73 13.9 105.2 6.5
3.2 4.2 9.6 9.8 8.0 0.82 0.67 11.8 14.6 16.7 0.75 14.5 106.6 6.6
100
1.6 1.4 3.2 9.0 7.8 0.86 0.78 11.4 11.6
2.4 2.5 5.7 9.2 7.8 0.85 0.76 11.5 12.1
3.2 4.0 9.1 9.2 7.8 0.85 0.75 11.5 12.4
110
1.6 1.3 3.0 8.5 7.4 0.88 0.86 11.1 9.8
2.4 2.3 5.3 8.6 7.5 0.87 0.84 11.2 10.2
3.2 3.7 8.6 8.7 7.5 0.86 0.83 11.2 10.4
• Cooling Performance is tabulated at 80.6 °F DB and 66.2 °F WB entering air. Heating performance tabulated at 68 °F EAT
• Tabulated data does not include AHRI/ISO corrections for fan and pump power.
• All capacities are expressed in MBH.
• Insulated water circuit is recommended for operation below 60 °F EWT.
• Operation below 60 °F EWT is based on 15% methanol.
• See performance correction tables for conditions beyond what is listed.
• Extrapolation is not permissible.
• Shaded areas indicate conditions where operation is not recommended.
• All performance is based on 208V on 208-230V units.

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 13
TABLE 5 - VPCS12 - EC MOTOR (ECM) - COOLING AIRFLOW: 450 CFM AND HEATING AIRFLOW: 500 CFM
EWT GPM WPD COOLING HEATING
PSI FT TC SC SHR KW HR EER HTG KW HE LAT COP
20 3.8 7.0 16.2 8.1 0.70 6.1 83.0 3.4
30
1.9 2.5 5.7 14.6 10.7 0.73 0.40 15.7 36.4 9.0 0.71 6.9 84.6 3.7
2.8 4.4 10.2 14.7 10.7 0.73 0.39 15.7 37.9 9.1 0.71 7.1 84.9 3.8
3.8 6.8 15.8 15.1 10.9 0.72 0.38 16.1 39.5 9.3 0.72 7.2 85.2 3.8
40
1.9 2.3 5.2 14.2 10.5 0.74 0.45 15.5 31.5 10.1 0.73 7.9 86.7 4.1
2.8 4.2 9.7 14.4 10.5 0.73 0.44 15.5 32.9 10.4 0.73 8.2 87.2 4.2
3.8 6.6 15.2 14.4 10.5 0.73 0.43 15.6 33.7 10.6 0.73 8.4 87.6 4.2
50
1.9 2.0 4.7 13.8 10.4 0.75 0.51 15.3 26.9 11.3 0.74 9.2 89.0 4.5
2.8 4.0 9.2 14.0 10.3 0.74 0.49 15.3 28.2 11.7 0.74 9.5 89.7 4.6
3.8 6.4 14.8 14.0 10.4 0.74 0.48 15.4 29.0 12.1 0.74 9.9 90.3 4.8
60
1.9 1.8 4.2 13.4 10.2 0.76 0.58 15.0 23.0 12.8 0.75 10.6 91.7 5.0
2.8 3.8 8.7 13.5 10.1 0.75 0.56 15.1 24.0 13.3 0.75 11.1 92.6 5.2
3.8 6.2 14.3 13.6 10.2 0.75 0.55 15.1 24.6 13.7 0.76 11.5 93.5 5.3
70
1.9 1.6 3.7 12.9 9.9 0.77 0.66 14.8 19.5 14.4 0.76 12.1 94.6 5.5
2.8 3.6 8.2 13.0 10.0 0.77 0.64 14.9 20.4 15.1 0.77 12.8 95.9 5.7
3.8 6.0 13.8 13.1 10.1 0.77 0.63 14.9 20.9 15.6 0.77 13.3 97.0 5.9
80
1.9 1.4 3.2 12.3 9.6 0.78 0.74 14.6 16.6 16.2 0.78 13.8 97.9 6.1
2.8 3.4 7.7 12.5 9.7 0.78 0.72 14.6 17.4 17.0 0.79 14.7 99.5 6.3
3.8 5.8 13.3 12.6 9.8 0.78 0.71 14.7 17.8 17.8 0.80 15.4 100.9 6.5
90
1.9 1.2 2.7 11.8 9.4 0.80 0.83 14.3 14.1 18.1 0.81 15.7 101.6 6.6
2.8 3.1 7.2 11.9 9.4 0.79 0.81 14.4 14.8 19.2 0.82 16.7 103.5 6.8
3.8 5.6 12.8 12.0 9.5 0.79 0.80 14.4 15.1 20.1 0.84 17.6 105.2 7.0
100
1.9 1.0 2.2 11.2 9.2 0.82 0.93 14.0 12.1
2.8 2.9 6.7 11.3 9.2 0.81 0.90 14.1 12.6
3.8 5.3 12.3 11.4 9.3 0.81 0.89 14.2 12.9
110
1.9 0.7 1.7 10.6 8.9 0.84 1.03 13.7 10.3
2.8 2.7 6.3 10.7 8.9 0.83 1.00 13.8 10.7
3.8 5.1 11.8 10.8 9.0 0.83 0.99 13.9 11.0
• Cooling Performance is tabulated at 80.6 °F DB and 66.2 °F WB entering air. Heating performance tabulated at 68 °F EAT
• Tabulated data does not include AHRI/ISO corrections for fan and pump power.
• All capacities are expressed in MBH.
• Insulated water circuit is recommended for operation below 60 °F EWT.
• Operation below 60 °F EWT is based on 15% methanol.
• See performance correction tables for conditions beyond what is listed.
• Extrapolation is not permissible.
• Shaded areas indicate conditions where operation is not recommended.
• All performance is based on 208V on 208-230V units.

FORM 145.18-EG2 (317)
14 JOHNSON CONTROLS
TAblE 6 - VPCS15 - EC MOTOR (ECM) - COOLING AND HEATING AIRFLOW: 520 CFM
EWT GPM WPD COOLING HEATING
PSI FT TC SC SHR KW HR EER HTG KW HE LAT COP
20 5.0 11.5 26.5 8.1 0.72 6.0 86.3 3.3
30
2.5 3.4 7.8 17.3 13.5 0.78 0.48 18.6 36.1 10.3 0.80 7.9 86.6 3.8
3.8 6.9 15.9 17.4 13.6 0.78 0.42 18.5 41.7 10.5 0.80 8.1 86.9 3.8
5.0 11.1 25.7 17.5 13.6 0.78 0.39 18.5 44.8 10.6 0.80 8.2 88.5 3.9
40
2.5 3.2 7.5 16.9 13.4 0.79 0.55 18.5 30.8 11.5 0.82 9.0 89.0 4.1
3.8 6.6 15.2 17.1 13.5 0.79 0.48 18.4 35.7 11.8 0.82 9.3 89.4 4.2
5.0 10.6 24.4 17.1 13.5 0.79 0.44 18.3 38.6 12.0 0.83 9.5 91.0 4.3
50
2.5 3.1 7.1 16.5 13.2 0.80 0.60 18.2 27.6 12.9 0.84 10.4 91.7 4.5
3.8 6.3 14.4 16.6 13.3 0.80 0.54 18.1 30.7 13.3 0.85 10.8 92.3 4.6
5.0 10.1 23.3 16.7 13.3 0.80 0.52 18.1 32.4 13.6 0.85 11.1 93.8 4.7
60
2.5 2.9 6.7 15.8 12.8 0.81 0.68 17.8 23.1 14.5 0.86 11.9 94.7 4.9
3.8 5.9 13.7 16.1 13.1 0.81 0.64 18.0 25.2 15.0 0.87 12.4 95.5 5.0
5.0 9.5 22.0 16.2 13.1 0.81 0.62 18.0 26.1 15.4 0.88 12.8 96.8 5.1
70
2.5 2.8 6.4 15.4 12.8 0.83 0.79 17.8 19.6 16.2 0.89 13.5 98.0 5.3
3.8 5.6 12.9 15.6 12.8 0.82 0.75 17.8 20.7 16.8 0.90 14.1 98.9 5.5
5.0 9.0 20.8 15.7 12.8 0.82 0.74 17.8 21.2 17.4 0.90 14.6 100.0 5.6
80
2.5 2.6 6.0 14.8 12.5 0.84 0.89 17.5 16.7 18.0 0.91 15.2 101.4 5.8
3.8 5.3 12.2 15.0 12.6 0.84 0.86 17.6 17.4 18.8 0.92 16.0 102.6 6.0
5.0 8.5 19.6 15.1 12.6 0.84 0.85 17.6 17.8 19.4 0.93 16.6 103.4 6.1
90
2.5 2.4 5.6 14.2 12.2 0.86 1.00 17.2 14.2 19.9 0.93 17.0 105.1 6.3
3.8 5.0 11.4 14.3 12.3 0.86 0.97 17.3 14.7 20.8 0.94 18.0 106.4 6.5
5.0 8.0 18.4 14.4 12.4 0.86 0.96 17.3 15.0 21.6 0.95 18.7 68.0 6.7
100
2.5 2.3 5.3 13.5 12.0 0.89 1.11 16.9 12.2
3.8 4.6 10.7 13.6 12.0 0.88 1.08 17.0 12.6
5.0 7.5 17.2 13.7 12.1 0.88 1.07 17.0 12.8
110
2.5 2.1 4.9 12.7 11.7 0.92 1.22 16.6 10.4
3.8 4.3 9.9 12.9 11.7 0.91 1.19 16.6 10.8
5.0 6.9 16.0 13.0 11.8 0.91 1.18 16.7 11.0
• Cooling Performance is tabulated at 80.6 °F DB and 66.2 °F WB entering air. Heating performance tabulated at 68 F EAT
• Tabulated data does not include AHRI/ISO corrections for fan and pump power.°
• All capacities are expressed in MBH.
• Insulated water circuit is recommended for operation below 60 °F EWT.
• Operation below 60 °F EWT is based on 15% methanol.
• See performance correction tables for conditions beyond what is listed.
• Extrapolation is not permissible.
• Shaded areas indicate conditions where operation is not recommended.
• All performance is based on 208V on 208-230V units.
Performance Data - EC Motor (Cont'd)

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 15
TABLE 7 - VPCS18 - EC MOTOR (ECM) - COOLING AND HEATING AIRFLOW: 700 CFM
EWT GPM WPD COOLING HEATING
PSI FT TC SC SHR KW HR EER HTG KW HE LAT COP
20 6.8 22.9 52.9 11.2 1.00 8.3 82.8 3.3
30
3.4 4.6 10.7 23.8 17.9 0.75 0.51 25.1 46.4 12.6 1.01 9.6 84.6 3.6
5.0 13.2 30.5 23.9 17.7 0.74 0.50 25.1 47.5 12.8 1.01 9.9 85.0 3.7
6.8 22.0 50.8 24.0 17.8 0.74 0.49 25.2 49.5 13.1 1.02 10.1 85.3 3.8
40
3.4 4.4 10.2 22.8 17.3 0.76 0.60 24.3 38.2 14.4 1.03 11.4 87.0 4.1
5.0 12.7 29.3 22.9 17.4 0.76 0.59 24.4 39.0 14.8 1.03 11.8 87.5 4.2
6.8 21.1 48.7 23.0 17.5 0.76 0.57 24.5 40.3 15.1 1.03 12.1 88.0 4.3
50
3.4 4.2 9.8 21.9 17.1 0.78 0.68 23.7 32.2 16.4 1.04 13.3 89.7 4.6
5.0 12.1 28.0 21.9 17.1 0.78 0.67 23.7 32.7 17.0 1.05 13.9 90.5 4.7
6.8 20.2 46.5 22.1 17.2 0.78 0.66 23.8 33.6 17.5 1.05 14.4 91.1 4.9
60
3.4 4.0 9.3 21.0 16.8 0.80 0.79 23.2 26.5 18.7 1.06 15.5 92.7 5.1
5.0 11.6 26.7 21.1 16.6 0.79 0.79 23.3 26.8 19.4 1.07 16.2 93.7 5.3
6.8 19.3 44.4 21.2 16.7 0.79 0.77 23.3 27.5 20.0 1.07 16.9 94.5 5.5
70
3.4 3.9 8.9 20.2 16.3 0.81 0.91 22.8 22.1 21.1 1.08 17.9 95.9 5.7
5.0 11.0 25.4 20.2 16.4 0.81 0.90 22.8 22.4 22.0 1.09 18.8 97.1 5.9
6.8 18.3 42.3 20.3 16.5 0.81 0.89 22.9 22.9 22.8 1.10 19.5 98.1 6.1
80
3.4 3.7 8.4 19.3 16.1 0.83 1.04 22.4 18.6 23.7 1.10 20.4 99.3 6.3
5.0 10.5 24.2 19.4 16.1 0.83 1.03 22.4 18.8 24.8 1.11 21.5 100.8 6.5
6.8 17.4 40.2 19.5 16.2 0.83 1.02 22.5 19.2 25.7 1.12 22.4 102.0 6.7
90
3.4 3.5 8.0 18.5 15.7 0.85 1.18 22.0 15.7 26.4 1.12 23.0 102.9 6.9
5.0 9.9 22.9 18.6 15.6 0.84 1.17 22.1 15.8 27.7 1.13 24.3 104.6 7.2
6.8 16.5 38.1 18.7 15.7 0.84 1.15 22.1 16.2 28.8 1.14 25.4 106.1 7.4
100
3.4 3.3 7.5 17.6 15.5 0.88 1.34 21.7 13.2
5.0 9.4 21.6 17.7 15.4 0.87 1.33 21.7 13.3
6.8 15.6 36.0 17.8 15.5 0.87 1.31 21.8 13.6
110
3.4 3.1 7.1 16.7 15.0 0.90 1.52 21.4 11.0
5.0 8.8 20.4 16.7 15.0 0.90 1.51 21.4 11.1
6.8 14.7 33.9 16.8 15.1 0.90 1.49 21.4 11.3
• Cooling Performance is tabulated at 80.6 °F DB and 66.2 °F WB entering air. Heating performance tabulated at 68 F EAT
• Tabulated data does not include AHRI/ISO corrections for fan and pump power.°
• All capacities are expressed in MBH.
• Insulated water circuit is recommended for operation below 60 °F EWT.
• Operation below 60 °F EWT is based on 15% methanol.
• See performance correction tables for conditions beyond what is listed.
• Extrapolation is not permissible.
• Shaded areas indicate conditions where operation is not recommended.
• All performance is based on 208V on 208-230V units.

FORM 145.18-EG2 (317)
16 JOHNSON CONTROLS
TABLE 8 - VPCS24 - EC MOTOR (ECM) - COOLING AIRFLOW: 850 CFM AND HEATING AIRFLOW: 950 CFM
EWT GPM WPD COOLING HEATING
PSI FT TC SC SHR KW HR EER HTG KW HE LAT COP
20 8.2 12.1 27.8 14.9 1.35 11.0 82.5 3.2
30
4.1 4.5 10.3 29.5 20.9 0.71 0.75 31.5 39.5 16.6 1.36 12.7 84.2 3.6
6.2 7.2 16.6 29.7 21.1 0.71 0.71 31.6 41.8 17.0 1.36 13.0 84.6 3.7
8.2 11.5 26.6 29.8 20.9 0.70 0.70 31.6 42.8 17.3 1.36 13.3 84.9 3.7
40
4.1 4.1 9.5 28.8 20.7 0.72 0.87 31.1 33.3 18.9 1.38 14.9 86.5 4.0
6.2 6.9 15.8 29.0 20.6 0.71 0.83 31.2 34.9 19.6 1.38 15.5 87.1 4.2
8.2 11.0 25.3 29.1 20.7 0.71 0.82 31.3 35.7 20.0 1.38 15.9 87.5 4.2
50
4.1 3.8 8.7 28.0 20.1 0.72 0.99 30.8 28.4 21.6 1.39 17.5 91.6 4.5
6.2 6.5 15.0 28.2 20.3 0.72 0.95 30.9 29.7 22.5 1.40 18.3 92.5 4.7
8.2 10.4 24.0 28.3 20.4 0.72 0.94 30.9 30.3 23.2 1.40 18.9 93.2 4.8
60
4.1 3.4 7.8 27.1 19.8 0.73 1.12 30.3 24.3 24.7 1.41 20.5 92.0 5.1
6.2 6.1 14.2 27.4 20.0 0.73 1.08 30.5 25.4 25.8 1.42 21.6 93.2 5.3
8.2 9.8 22.6 27.5 20.1 0.73 1.06 30.5 25.9 26.6 1.43 22.4 94.0 5.5
70
4.1 3.0 7.0 26.2 19.4 0.74 1.26 29.9 20.8 27.9 1.44 23.7 95.2 5.7
6.2 5.8 13.4 26.3 19.4 0.74 1.22 29.8 21.6 29.4 1.45 25.1 96.6 5.9
8.2 9.3 21.3 26.6 19.7 0.74 1.20 30.1 22.2 30.4 1.45 26.1 97.6 6.1
80
4.1 2.7 6.2 25.2 19.1 0.76 1.42 29.4 17.7 31.4 1.46 27.0 98.6 6.3
6.2 5.4 12.6 25.4 19.1 0.75 1.37 29.5 18.6 33.1 1.47 28.8 100.3 6.6
8.2 8.7 20.0 25.6 19.2 0.75 1.35 29.6 18.9 34.4 1.48 30.0 101.5 6.8
90
4.1 2.3 5.4 24.1 18.5 0.77 1.61 29.0 15.0 35.1 1.49 30.6 102.2 6.9
6.2 5.1 11.7 24.4 18.8 0.77 1.55 29.1 15.7 37.1 1.51 32.6 104.2 7.2
8.2 8.1 18.7 24.5 18.6 0.76 1.53 29.2 16.0 38.6 1.52 34.1 105.6 7.5
100
4.1 2.0 4.6 22.9 18.1 0.79 1.82 28.6 12.6
6.2 4.7 10.9 23.3 18.4 0.79 1.76 28.7 13.2
8.2 7.6 17.4 23.4 18.2 0.78 1.74 28.7 13.5
110
4.1 1.6 3.8 21.7 17.6 0.81 2.08 28.2 10.4
6.2 4.4 10.1 22.0 17.9 0.81 2.01 28.3 11.0
8.2 7.0 16.1 22.2 17.7 0.80 1.98 28.3 11.2
• Cooling Performance is tabulated at 80.6 °F DB and 66.2 °F WB entering air. Heating performance tabulated at 68 F EAT
• Tabulated data does not include AHRI/ISO corrections for fan and pump power.°
• All capacities are expressed in MBH.
• Insulated water circuit is recommended for operation below 60 °F EWT.
• Operation below 60 °F EWT is based on 15% methanol.
• See performance correction tables for conditions beyond what is listed.
• Extrapolation is not permissible.
• Shaded areas indicate conditions where operation is not recommended.
• All performance is based on 208V on 208-230V units.
Performance Data - EC Motor (Cont'd)

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 17
TABLE 9 - VPCS30 - EC MOTOR (ECM) - COOLING AND HEATING AIRFLOW: 1075 CFM
EWT GPM WPD COOLING HEATING
PSI FT TC SC SHR KW HR EER HTG KW HE LAT COP
20 7.5 8.7 20.1 18.4 1.64 13.4 83.8 3.3
30
3.8 4.4 10.2 35.7 25.0 0.70 1.00 38.4 35.8 20.7 1.66 15.7 85.8 3.6
5.7 6.5 15.0 36.1 24.9 0.69 0.91 38.6 39.6 21.0 1.66 16.0 86.1 3.7
7.5 8.4 19.3 36.4 25.1 0.69 0.87 38.7 41.9 21.3 1.67 16.3 86.3 3.7
40
3.8 4.2 9.8 34.6 24.2 0.70 1.17 37.9 29.7 23.1 1.69 18.0 87.9 4.0
5.7 6.2 14.3 35.1 24.6 0.70 1.09 38.2 32.4 23.7 1.70 18.5 88.4 4.1
7.5 8.0 18.5 35.4 24.7 0.70 1.05 38.3 33.8 24.1 1.70 18.9 88.8 4.1
50
3.8 4.1 9.3 33.6 23.8 0.71 1.33 37.4 25.2 25.9 1.73 20.7 90.3 4.4
5.7 5.9 13.7 34.1 24.2 0.71 1.25 37.7 27.2 26.8 1.74 21.5 91.1 4.5
7.5 7.7 17.7 34.3 24.4 0.71 1.21 37.8 28.3 27.4 1.75 22.1 91.6 4.6
60
3.8 3.9 8.9 32.5 23.4 0.72 1.50 36.9 21.6 29.2 1.77 23.8 93.1 4.8
5.7 5.7 13.1 33.0 23.8 0.72 1.42 37.2 23.3 30.3 1.79 24.9 94.1 5.0
7.5 7.3 16.9 33.3 23.9 0.72 1.38 37.3 24.1 31.2 1.80 25.7 94.8 5.1
70
3.8 3.7 8.5 31.4 23.2 0.74 1.69 36.4 18.6 32.8 1.82 27.2 96.2 5.3
5.7 5.4 12.4 31.9 23.3 0.73 1.59 36.7 20.0 34.2 1.84 28.6 97.5 5.5
7.5 7.0 16.1 32.2 23.5 0.73 1.55 36.8 20.7 35.3 1.85 29.6 98.4 5.6
80
3.8 3.5 8.1 30.1 22.6 0.75 1.89 35.9 16.0 36.6 1.87 30.9 99.5 5.7
5.7 5.1 11.8 30.7 23.1 0.75 1.79 36.2 17.2 38.4 1.90 32.6 101.1 5.9
7.5 6.6 15.2 31.0 22.9 0.74 1.74 36.3 17.8 39.7 1.92 33.8 102.2 6.1
90
3.8 3.3 7.6 28.9 22.2 0.77 2.12 35.4 13.6 40.7 1.93 34.8 103.0 6.2
5.7 4.9 11.2 29.5 22.7 0.77 2.00 35.7 14.7 42.8 1.96 36.8 104.9 6.4
7.5 6.3 14.4 29.8 22.6 0.76 1.95 35.8 15.3 44.3 1.99 38.2 106.2 6.5
100
3.8 3.1 7.2 27.5 21.7 0.79 2.39 35.0 11.5
5.7 4.6 10.6 28.2 22.0 0.78 2.25 35.2 12.5
7.5 5.9 13.6 28.5 22.2 0.78 2.19 35.3 13.0
110
3.8 2.9 6.8 26.0 21.3 0.82 2.70 34.5 9.6
5.7 4.3 9.9 26.7 21.7 0.81 2.53 34.7 10.6
7.5 5.6 12.8 27.1 21.7 0.80 2.47 34.8 11.0
• Cooling Performance is tabulated at 80.6 °F DB and 66.2 °F WB entering air. Heating performance tabulated at 68 F EAT
• Tabulated data does not include AHRI/ISO corrections for fan and pump power.°
• All capacities are expressed in MBH.
• Insulated water circuit is recommended for operation below 60 °F EWT.
• Operation below 60 °F EWT is based on 15% methanol.
• See performance correction tables for conditions beyond what is listed.
• Extrapolation is not permissible.
• Shaded areas indicate conditions where operation is not recommended.
• All performance is based on 208V on 208-230V units.

FORM 145.18-EG2 (317)
18 JOHNSON CONTROLS
TABLE 10 - VPCS36 - EC MOTOR (ECM) - COOLING AIRFLOW: 1100 CFM AND HEATING AIRFLOW: 1250 CFM
EWT GPM WPD COOLING HEATING
PSI FT TC SC SHR KW HR EER HTG KW HE LAT COP
20 9.0 11.7 27.1 22.3 2.18 15.8 84.5 3.0
30
4.5 3.1 7.2 43.9 29.9 0.68 1.27 47.3 34.7 25.8 2.21 19.3 87.1 3.4
6.8 7.1 16.4 44.3 30.1 0.68 1.19 47.5 37.1 26.4 2.22 19.8 87.5 3.5
9.0 10.9 25.2 44.6 30.3 0.68 1.15 47.6 38.9 26.8 2.22 20.2 87.8 3.5
40
4.5 2.9 6.8 42.7 29.5 0.69 1.47 46.8 29.1 29.0 2.25 22.3 89.5 3.8
6.8 6.6 15.3 43.1 29.8 0.69 1.40 47.0 30.8 29.9 2.26 23.2 90.1 3.9
9.0 10.2 23.6 43.4 29.9 0.69 1.36 47.1 31.9 30.5 2.26 23.8 90.6 3.9
50
4.5 2.7 6.3 41.5 29.0 0.70 1.66 46.2 25.0 32.7 2.29 25.8 92.2 4.2
6.8 6.2 14.3 41.9 28.9 0.69 1.60 46.4 26.2 33.8 2.30 27.0 93.1 4.3
9.0 9.5 21.9 42.1 29.1 0.69 1.56 46.6 27.1 34.7 2.31 27.8 93.7 4.4
60
4.5 2.5 5.8 40.2 28.5 0.71 1.86 45.6 21.6 36.7 2.33 29.7 95.1 4.6
6.8 5.7 13.2 40.6 28.4 0.70 1.79 45.8 22.6 38.2 2.35 31.2 96.3 4.8
9.0 8.8 20.3 40.9 28.6 0.70 1.75 45.9 23.3 39.3 2.36 32.2 97.1 4.9
70
4.5 2.3 5.4 38.8 27.6 0.71 2.07 45.0 18.8 40.9 2.38 33.8 98.3 5.0
6.8 5.3 12.1 39.3 27.9 0.71 2.00 45.2 19.6 42.8 2.40 35.6 99.7 5.2
9.0 8.1 18.7 39.5 28.1 0.71 1.96 45.3 20.2 44.2 2.42 37.0 100.8 5.4
80
4.5 2.1 4.9 37.4 27.3 0.73 2.30 44.3 16.3 45.5 2.43 38.1 101.7 5.5
6.8 4.8 11.1 37.8 27.2 0.72 2.22 44.5 17.0 47.7 2.46 40.3 103.4 5.7
9.0 7.4 17.0 38.1 27.4 0.72 2.18 44.6 17.5 49.4 2.48 41.9 104.6 5.8
90
4.5 1.9 4.4 35.8 26.5 0.74 2.57 43.6 14.0 50.2 2.49 42.7 105.2 5.9
6.8 4.4 10.0 36.3 26.5 0.73 2.48 43.8 14.6 52.8 2.52 45.2 107.1 6.1
9.0 6.7 15.4 36.6 26.7 0.73 2.43 44.0 15.1 54.8 2.55 47.1 108.6 6.3
100
4.5 1.7 3.9 34.1 25.9 0.76 2.88 43.0 11.9
6.8 3.9 9.0 34.6 26.0 0.75 2.78 43.2 12.5
9.0 6.0 13.8 34.9 26.2 0.75 2.72 43.3 12.8
110
4.5 1.5 3.5 32.3 25.2 0.78 3.24 42.4 10.0
6.8 3.4 7.9 32.8 25.3 0.77 3.13 42.6 10.5
9.0 5.3 12.2 33.2 25.5 0.77 3.06 42.7 10.8
• Cooling Performance is tabulated at 80.6 °F DB and 66.2 °F WB entering air. Heating performance tabulated at 68 F EAT
• Tabulated data does not include AHRI/ISO corrections for fan and pump power.°
• All capacities are expressed in MBH.
• Insulated water circuit is recommended for operation below 60 °F EWT.
• Operation below 60 °F EWT is based on 15% methanol.
• See performance correction tables for conditions beyond what is listed.
• Extrapolation is not permissible.
• Shaded areas indicate conditions where operation is not recommended.
• All performance is based on 208V on 208-230V units.
Performance Data - EC Motor (Cont'd)

FORM 145.18-EG2 (317)
JOHNSON CONTROLS 19
Performance Data
TABLE 11 - ANTIFREEZE CORRECTION
ANTIFREEZE CONCENTRATION
5% 10% 15% 20% 25% 30% 40%
ETHYLENE
GLYCOL
TC, SC 0.998 0.995 0.993 0.991 0.989 0.987 0.984
HTG 0.995 0.990 0.985 0.980 0.974 0.969 0.964
WPD 1.040 1.055 1.080 1.105 1.135 1.165 1.210
PROPYLENE
GLYCOL
TC, SC 0.995 0.992 0.987 0.983 0.979 0.975 0.970
HTG 0.989 0.982 0.975 0.967 0.958 0.951 0.943
WPD 1.035 1.055 1.100 1.145 1.200 1.260 1.320
METHANOL
TC, SC 0.999 0.995 0.990 0.986 0.982 0.980 0.978
HTG 0.989 0.985 0.979 0.971 0.963 0.954 0.946
WPD 1.050 1.072 1.094 1.116 1.140 1.165 1.196
TABLE 12 - AIRFLOW CORRECTION
AIRFLOW % COOLING HEATING
TC SC KW HR HTG KW HE
70 0.931 0.847 0.964 0.946 0.942 1.075 0.940
75 0.941 0.872 0.969 0.956 0.953 1.059 0.949
80 0.950 0.896 0.979 0.961 0.960 1.039 0.958
85 0.966 0.923 0.983 0.971 0.970 1.023 0.969
90 0.977 0.948 0.989 0.981 0.979 1.015 0.979
95 0.989 0.974 0.995 0.990 0.989 1.007 0.989
100 1.000 1.000 1.000 1.000 1.000 1.000 1.000
105 1.008 1.025 1.006 1.010 1.009 0.994 1.010
110 1.018 1.048 1.013 1.017 1.019 0.992 1.018
115 1.026 1.070 1.019 1.026 1.029 0.991 1.028
TABLE 13 - COOLING PERFORMANCE CORRECTION
EAT WB (F) TC EAT DB (F) - SC HR
70 75 80.6 85 90 95
60 0.845 0.86 1.1 1.305 S S S 0.904
65 0.948 0.628 0.865 1.082 1.312 S S 0.979
66.2 1 0.539 0.777 1 1.22 1.475 S 1
70 1.061 0.631 0.855 1.081 1.331 1.543 1.039
75 1.162 0.618 0.848 1.09 1.296 1.107
S = Sensible cooling is equal to Total Cooling
TABLE 14 - HEATING PERFORMANCE CORRECTION
EAT DB (F) HTG KW HE
45 1.101 0.785 1.162
50 1.080 0.832 1.125
55 1.059 0.878 1.079
60 1.039 0.926 1.064
65 1.019 0.960 1.023
68 1.000 1.000 1.000
70 0.990 1.028 0.983
75 0.974 1.064 0.957
80 0.951 1.111 0.918

FORM 145.18-EG2 (317)
20 JOHNSON CONTROLS
Riser Selection and Data
RISER APPLICATION AND SIZING
Technical information on heat transfer, fluid flow and pipe sizing can be found in the
ASHRAE Fundamentals Handbook and various other technical documents and publica-
tions. Some of the factors affecting riser application and sizing are noise, tube erosion and
economics. The Friction Loss For Risers chart (next page) displays riser tube diameter
sizes as a function of flow (GPM), friction loss and water velocity. For maximum riser ve-
locity on pressure drop per 100 ft., refer to ASHRAE 2001 Fundamentals 35.3 Table 6 for
Riser Sizing. Riser sizes can be of a single diameter on low rise buildings, or varying sizes
on medium to high rise buildings. Generally, riser copper type, size, length and insulation
thickness are determined by the location of the unit in the building.
Risers are available in Type-M or Type-L copper, varying diameters from 3/4" to 3", and
with either 1/2" or 3/4" thick closed cell foam insulation. Condensate risers are available
in Type-M copper, varying diameters from 3/4" to 1 1/4", and with 3/8" thick closed cell
foam insulation.
RISER EXPANSION
Generally, in medium to high rise buildings, allowance must be made for pipe expansion.
Model VPCS vertical stacked water source heat pumps are furnished with hoses which act
as expansion loops integral to the unit. The hose will allow for +/- 1½" of riser expansion
and contraction. Additional expansion compensation must be made in the riser system in
the field where movement is expected to exceed the factory allowances. The Allowable
Riser Lengths Between System Expansion Loops chart displays the expansion character-
istics of risers compared to water temperature difference. Technical information on pipe
expansion, contraction and anchoring can be found in the ASHRAE HVAC Systems and
Equipment Handbook and various other technical documents and publications.
