TECHNICAL GUIDE
LX SERIES
SPLIT SYSTEM
AIR CONDITIONERS
13 SEER – R-410A – 1 PHASE
1.5 THRU 5 NOMINAL TONS
MODELS: TC3B18 THRU 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.simplygettingthejobdone.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Standard 5-Years limited parts warranty.
Standard 10-Years limited compressor warranty.
Extended 10-Years limited parts warranty when product is
registered online within 90 days of purchase for replacement
or closing for new home construction.
*Does not apply to R-22 models, 3-Phase models, or Internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR INSTALLATION ONLY IN
US NORTHERN REGION AND CANADA
Installation Allowed
®
TECHNICAL
GUIDE
TECHNICAL
GUIDE
5581712-BTG-C-0619
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The TC3B models are part of our successful LX Series split sys-
tem air conditioner lineup. Optimized for the 13 SEER Regional
Minimum Efficiency in the North US and Canada, these outdoor
units are specifically designed to be matched with Johnson
Controls Unitary Products indoor coils, furnaces, and air han-
dlers to provide a complete system solution.
FEATURES
•Small Footprint - Minimum footprint for easier handling,
transportation, and installation.
•Easier Installation - Independent panels provide quick
access for unit setup. Installation time is reduced by easy
power and control wiring access. Options are provided for
indoor piston or TXV. The factory installed filter-drier and fac-
tory charge for a 15-Ft lineset means less time spent brazing
and charging the system. The small base dimension and
reduced unit clearances make for easier retrofits.
•Accessible Information - QR code on unit provides quick
access to technical documents and warranty information.
•Durable Finish - The coated steel wire fan guard, coated
external fasteners, and pre-treated G90-equivalent galva-
nized steel chassis components resist corrosion and rust
creep. Titanium colored powdercoat paint further protects
external panels.
•Quality Coils - The high efficiency microchannel aluminum
coil is manufactured using an improved material system pro-
viding reliable performance and small unit size.
•Rugged Coil Protection - Coils are protected from mechan-
ical damage by a proven stamped steel coil guard design.
•Protected Compressor - Compressors are protected inter-
nally by a high pressure relief valve and a temperature sen-
sor, and externally by the system high pressure switch. The
liquid line filter-drier is factory installed to protect the com-
pressor against moisture and debris.
•Reliable Operation - Ball bearing fan motors provide supe-
rior performance in extreme temperatures.
•Environmentally Friendly - CFC-free R-410A refrigerant
delivers environmentally friendly performance with zero
ozone depletion.
•Top Discharge - Warm air is blown up, away from the struc-
ture and any landscaping and allows compact location on
multi-unit applications.
•Low Operating Sound Levels - Developed using CFD and
FEA tools, the sturdy cabinet and top design provides sound
performance of 77 dBA or lower. Compatible accessories for
further sound reduction are also available.
•Better Service Access - Diagonal base valves with open
access for low-loss fittings, single panel access to the electri-
cal controls, swing out control box for full corner access, and
removable fan guard allow easy access for unit mainte-
nance.
•Agency Listed - Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.

5581712-BTG-C-0619
2 Johnson Controls Ducted Systems
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . 3
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . . 4
COOLING CAPACITY - With Air Handler Coils . . . . . . . . . . . . . . . 5
COOLING CAPACITY - Upflow, Downflow &
Horizontal Furnaces and Coils (Coil Only Ratings) . . . . . . . . . . . 9
COOLING CAPACITY - With High Efficiency Motor Furnaces . . 11
APPLICATIONS AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . 62
SOUND POWER RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 63
TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
ALTERNATIVE INSTALLATION CLEARANCES . . . . . . . . . . . . . . 65
PERFORMANCE DATA - 1.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 66
PERFORMANCE DATA - 2 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 70
PERFORMANCE DATA - 2.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 77
PERFORMANCE DATA - 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 83
PERFORMANCE DATA - 3.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 92
PERFORMANCE DATA - 4 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 96
PERFORMANCE DATA - 5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 101
NOMENCLATURE
BRAND TT= Factory Branded
PRODUCT TYPE CC= Air Conditioner (US Northern or
Southeast Region)
NOMINAL
SERIES EFFICIENCY
AND STAGING 33= 13 SEER / 1-Stage (US Northern
Region)
REFRIGERANT BB= R-410A
NOMINAL
UNIT CAPACITY
(MBH) 36
18 = 1.5 Ton 42 = 3.5 Ton
24 = 2 Ton 48 = 4 Ton
30 = 2.5 Ton 60 = 5 Ton
36 = 3 Ton
VOLTAGE
(Voltage-Phase-Hertz) 22= 208/230-1-60
GENERATION
(MAJOR REVISION) 11= 1st Gen
2= 2nd Gen
etc
FACTORY OPTION SS= Standard (No Options)
H= Hard Start Kit
STYLE LETTER
(MINOR REVISION)
NOT USED
FOR ORDERING
AA= Style A
B= Style B

5581712-BTG-C-0619
Johnson Controls Ducted Systems 3
‡ Adapter fitting must be field installed for the required 1-1/8” line set.
All dimensions are in inches and are subject to change without notice.
Overall height is from bottom of base pan to top of fan guard.
Overall length and width include screw heads.
PHYSICAL AND ELECTRICAL DATA
MODEL TC3B1822S TC3B2422S TC3B3022S TC3B3622S TC3B4222S TC3B4821S TC3B6021S
Unit Supply Voltage 208-230V, 1 60Hz
Normal Voltage Range 1
1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.
187 to 252
Minimum Circuit Ampacity 12.9 14.8 18.4 20.7 25.3 28.5 34.3
Max. Overcurrent Device Amps 2
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
20 25 30 35 40 50 60
Min. Overcurrent Device Amps 3
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
15 15 20 25 30 30 35
Compressor Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll Rated Load 9.7 11.2 14.1 15.4 19.2 21.8 26.4
Locked Rotor 46.0 60.8 73.0 83.9 123.9 117.0 134.0
Crankcase Heater No No No No No No No
Factory External Discharge Muffler No No No No No No No
HS Kit Required with TXV 4
4. See Hard Start Kit Accessory Installation Manual for Hard Start Kit part number for each model.
No No No No No No No
Fan Diameter Inches 18 18 18 18 22 22 22
Fan Motor
Rated HP 1/8 1/8 1/8 1/4 1/4 1/4 1/4
Rated Load Amps 0.80 0.80 0.80 1.50 1.30 1.30 1.30
Nominal RPM 1075 1075 1075 1100 850 850 850
Nominal CFM 1950 1950 2150 2575 2925 3225 3350
Coil Face Area Sq. Ft. 9.78 9.78 11.07 12.37 13.83 13.83 17.37 Rows Deep 1111111
Fins / Inch 23 23 23 23 23 23 23
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed) 5
5. For applications with non-standard vapor line sizes, see the “Applications & Accessories” section of this Technical Guide.
3/4 3/4 3/4 3/4 7/8 7/8 1-1/8‡
Unit Charge (Lbs. - Oz.) 6
6. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or subtract
the amount of refrigerant, using the difference in actual lineset length (not the equivalent length) multiplied by the per foot value.
2 - 13 3 - 1 3 - 10 3 - 11 4 - 8 4 - 8 5 - 6
Charge Per Foot, Oz. 0.62 0.62 0.62 0.62 0.67 0.67 0.75
Operating Weight Lbs. 115 115 130 145 165 165 190
&
%
$
$
DIMENSIONS
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A B C Liquid Vapor
TC3B1822S 26-3/4 24 24
3/8
3/4
TC3B2422S 26-3/4 24 24
TC3B3022S 30 24 24
TC3B3622S 33-1/4 24 24
TC3B4222S 30 29-1/4 29-1/4 7/8
TC3B4821S 30 29-1/4 29-1/4
TC3B6021S 36-1/4 29-1/4 29-1/4 7/8‡

5581712-BTG-C-0619
4 Johnson Controls Ducted Systems
CHARGING PROCEDURES:
1. Check the Factory Unit Charge listed on the unit nameplate to verify the refrigerant charge for the outdoor unit, the smallest matched indoor unit, and the 15 feet of
interconnecting lineset.
2. Verify the indoor metering device and additional charge required for the specific matched indoor unit in the system using the above table.
3. Add additional charge for the amount of interconnecting lineset tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.
4. For installations requiring additional charge, weigh in refrigerant for the specific matching indoor unit and actual lineset length.
5. Once the charge adders for matched indoor unit and for lineset have been weighed in, verify the system operation against the temperatures and pressures in the
Charging Chart for the outdoor unit. Locate Charging Charts on the outdoor unit and also in the Service Data Application Guide on
www.simplygettingthejobdone.com. Follow the Subcool or Superheat charging procedure in the Installation Manual according to the type of indoor metering device
in the system, and allow ten minutes after each charge adjustment for the system operation to stabilize. Record the charge adjustment made to match the Charging
Chart.
6. Permanently stamp the unit nameplate with the TOTAL SYSTEM CHARGE defined as follows: TOTAL SYSTEM CHARGE = Base Charge (as shipped) + charge
adder for matched indoor unit + charge adder for actual lineset length + charge adjustments to match the Charging Chart.
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS
Outdoor Unit TC3B1822S TC3B2422S TC3B3022S TC3B3622S TC3B4222S TC3B4821S TC3B6021S
Required Orifice or TXV 1,2
1. For applications requiring a TXV, use S1-1TVM*** series kit.
2. Approved orifice(s) shipped with outdoor unit.
0.049 / BH1 0.057 / BH1 0.061 / BA1 0.070 / BA1 0.075 / BC1 0.077 / BC1 0.084 / BD1
Indoor Unit 3,4,5
3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
4. CF coils cannot be used in horizontal applications.
5. Charge adders shown above do not indicate that coils are rated for every application. Refer to Performance Data Tables for actual performance for specified sys-
tem matches. Obtain certified system ratings from www.ahridirectory.org.
Additional Charge, oz
AP18B 0 – – – – – –
AP24B 3 0 – – – – –
AP30B – 7 2 – – – –
AP36B – – – 0 – – –
AP36C – – 2 2 – – –
AP37C – – – 5 – – –
AP42C – – – – – – –
AP48C – – – 5 2 0 –
AP48D – – – – 2 0 –
AP60(C,D) – – – – – 2 0
AE18B 0 – – – – – –
AE24B 3 0 – – – – –
AE30B 8 5 0 – – – –
AE36(B,C) – 7 2 0 – – –
AE42C – – – 5 2 – –
AE48(C,D) – – – 5 2 0 –
AE60C – – – – 9 2 0
AE60D – – – – 29 oz TXV ONLY 22 oz TXV ONLY 20 oz TXV ONLY
AVC18B 0 – – – – – –
AVC24B 3 0 – – – – –
AVC30B 8 5 0 – – – –
AVC36(B,C) – 7 2 0 – – –
AVC42C – – – 5 2 – –
AVC48(C,D) – – – 5 2 0 –
AVC60C – – – – – 2 0
AVC60D – – – – 29 oz TXV ONLY 22 oz TXV ONLY 20 oz TXV ONLY
CF/CM/CU18(A,B) 0 – – – – – –
CF/CM/CU24(A,B) 3 0 – – – – –
CF/CM/CU30(A,B,C) 8 5 0 – – – –
CF/CM/CU36(A,B,C,D) 10 7 2 0 – – –
CF/CM/CU42(B,C,D) – 11 2 2 0 – –
CF/CM/CU48(C,D) – – – 5 2 0 –
CF/CM/CU60(C,D) – – – – 9 2 0
CF/CM64D – – – – 29 oz TXV ONLY 22 oz TXV ONLY 20 oz TXV ONLY
Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil
only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.
FOOTNOTES:

5581712-BTG-C-0619
Johnson Controls Ducted Systems 5
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
TC3B1822S AE18BX21 17.5 – 650 17.9 14.9 15.00 12.75
TC3B1822S AE24BX21 17.5 – 625 18.0 14.7 15.00 12.75
TC3B1822S AE30BX21 17.5 – 600 18.0 14.4 15.00 12.75
TC3B1822S AP18BX21 17.5 – 650 17.6 14.6 13.50 11.50
TC3B1822S AP24BX21 17.5 – 675 17.6 15.0 13.50 11.50
TC3B1822S AVC18BX21 17.5 – 650 17.9 14.9 15.00 12.75
TC3B1822S AVC24BX21 17.5 – 600 17.9 14.2 15.00 12.75
TC3B1822S AVC30BX21 17.5 – 625 18.0 14.5 15.00 12.75
TC3B1822S ME08BN21 17.5 CF/CM18B 575 17.7 13.9 15.00 12.75
TC3B1822S ME08BN21 17.5 CF/CM24B 575 17.8 14.0 15.00 12.75
TC3B1822S ME08BN21 17.5 CF/CM30B 600 18.0 14.4 15.00 12.75
TC3B1822S ME08BN21 17.5 CF/CM36B 575 18.0 14.1 15.00 12.75
TC3B1822S ME12BN21 17.5 CF/CM18B 675 18.0 15.2 15.00 12.75
TC3B1822S ME12BN21 17.5 CF/CM24B 675 18.0 15.4 15.00 12.75
TC3B1822S ME12BN21 17.5 CF/CM30B 675 18.0 15.0 15.00 12.75
TC3B1822S ME12BN21 17.5 CF/CM36B 675 18.0 15.0 15.00 12.75
TC3B1822S ME12CN21 21.0 CF/CM24C 600 17.9 14.2 15.00 12.75
TC3B1822S ME12CN21 21.0 CF/CM30C 600 18.0 14.4 15.00 12.75
TC3B1822S ME12CN21 21.0 CF/CM36C 600 18.0 14.3 15.00 12.75
TC3B1822S MVC08BN21 17.5 CF/CM18B 650 17.9 14.9 15.00 12.75
TC3B1822S MVC08BN21 17.5 CF/CM24B 650 18.0 14.9 15.00 12.75
TC3B1822S MVC08BN21 17.5 CF/CM30B 650 18.0 15.0 15.00 12.75
TC3B1822S MVC08BN21 17.5 CF/CM36B 650 18.0 14.9 15.00 12.75
TC3B1822S MVC12CN21 21.0 CF/CM24C 650 18.0 14.9 15.00 12.75
TC3B1822S MVC12CN21 21.0 CF/CM30C 650 18.0 15.0 15.00 12.75
TC3B1822S MVC12CN21 21.0 CF/CM36C 650 18.0 14.9 15.00 12.75
TC3B2422S AE24BX21 17.5 – 825 24.0 19.4 14.50 12.50
TC3B2422S AE30BX21 17.5 – 700 23.8 18.0 14.75 12.50
TC3B2422S AE36BX21 17.5 – 850 24.0 19.5 14.75 12.50
TC3B2422S AE36CX21 21.0 – 800 24.0 18.9 15.00 12.50
TC3B2422S AP24BX21 17.5 – 675 23.0 17.0 13.00 11.50
TC3B2422S AP30BX21 17.5 – 850 24.0 19.5 13.50 11.50
TC3B2422S AVC24BX21 17.5 – 750 23.8 18.3 14.50 12.50
TC3B2422S AVC30BX21 17.5 – 750 24.0 18.6 14.75 12.50
TC3B2422S AVC36BX21 17.5 – 750 24.0 18.3 14.75 12.50
TC3B2422S AVC36CX21 21.0 – 875 24.0 19.8 15.00 12.50
TC3B2422S ME08BN21 17.5 CF/CM24B 800 24.0 19.1 14.50 12.50
TC3B2422S ME08BN21 17.5 CF/CM30B 800 24.0 19.1 14.75 12.50
TC3B2422S ME08BN21 17.5 CF/CM36B 800 24.0 18.9 14.75 12.50
TC3B2422S ME08BN21 17.5 CF42B 775 24.0 18.8 14.75 12.50
TC3B2422S ME12BN21 17.5 CF/CM24B 875 24.0 19.8 14.75 12.50
TC3B2422S ME12BN21 17.5 CF/CM30B 875 24.0 19.8 15.00 12.50
TC3B2422S ME12BN21 17.5 CF/CM36B 875 24.0 19.8 15.00 12.50
TC3B2422S ME12BN21 17.5 CF42B 850 24.0 19.4 15.00 12.50
TC3B2422S ME12CN21 21.0 CF/CM24C 850 24.0 19.5 14.75 12.50
TC3B2422S ME12CN21 21.0 CF/CM30C 850 24.0 19.6 15.00 12.50
TC3B2422S ME12CN21 21.0 CF/CM36C 850 24.0 19.5 15.00 12.50
TC3B2422S ME12CN21 21.0 CF/CM42C 850 24.0 19.4 15.00 12.50
TC3B2422S ME14DN21 24.5 CF/CM36D 875 24.0 19.8 15.00 12.50
TC3B2422S ME14DN21 24.5 CF/CM42D 875 24.0 19.6 15.00 12.50
TC3B2422S MVC08BN21 17.5 CF/CM24B 725 23.6 18.0 14.50 12.50
TC3B2422S MVC08BN21 17.5 CF/CM30B 725 24.0 18.3 14.75 12.50
TC3B2422S MVC08BN21 17.5 CF/CM36B 700 24.0 17.8 14.75 12.50
TC3B2422S MVC08BN21 17.5 CF42B 725 24.0 18.2 15.00 12.50

5581712-BTG-C-0619
6 Johnson Controls Ducted Systems
TC3B2422S MVC12BN21 17.5 CF/CM24B 875 24.0 19.8 14.50 12.50
TC3B2422S MVC12BN21 17.5 CF/CM30B 775 24.0 18.8 14.75 12.50
TC3B2422S MVC12BN21 17.5 CF/CM36B 875 24.0 19.8 14.75 12.50
TC3B2422S MVC12BN21 17.5 CF42B 775 24.0 18.8 15.00 12.50
TC3B2422S MVC12CN21 21.0 CF/CM24C 875 24.0 19.8 15.00 12.50
TC3B2422S MVC12CN21 21.0 CF/CM30C 875 24.0 19.8 15.00 12.50
TC3B2422S MVC12CN21 21.0 CF/CM36C 875 24.0 19.8 15.00 12.50
TC3B2422S MVC12CN21 21.0 CF/CM42C 875 24.0 19.6 15.00 12.50
TC3B2422S MVC14DN21 24.5 CF/CM36D 875 24.0 19.7 15.00 12.50
TC3B2422S MVC14DN21 24.5 CF/CM42D 875 24.0 19.6 15.00 12.50
TC3B3022S AE30BX21 17.5 – 875 28.8 21.8 14.00 12.25
TC3B3022S AE36BX21 17.5 – 825 28.8 21.2 14.25 12.25
TC3B3022S AE36CX21 21.0 – 975 29.6 23.2 14.50 12.50
TC3B3022S AP30BX21 17.5 – 825 28.8 23.6 13.00 11.50
TC3B3022S AP36CX21 21.0 – 1125 29.6 24.6 13.00 11.50
TC3B3022S AVC30BX21 17.5 – 825 28.6 21.0 14.25 12.25
TC3B3022S AVC36BX21 17.5 – 850 29.0 21.4 14.25 12.25
TC3B3022S AVC36CX21 21.0 – 900 29.4 22.2 14.50 12.50
TC3B3022S ME08BN21 17.5 CF/CM30B 875 28.8 21.8 14.00 12.25
TC3B3022S ME08BN21 17.5 CF/CM36B 900 29.2 22.2 14.25 12.25
TC3B3022S ME08BN21 17.5 CF42B 875 29.2 22.0 14.25 12.25
TC3B3022S ME12BN21 17.5 CF/CM30B 850 28.8 21.6 14.25 12.25
TC3B3022S ME12BN21 17.5 CF/CM36B 850 29.0 21.4 14.50 12.50
TC3B3022S ME12BN21 17.5 CF42B 850 29.0 21.6 14.50 12.50
TC3B3022S ME12CN21 21.0 CF/CM30C 1000 29.4 23.2 14.50 12.50
TC3B3022S ME12CN21 21.0 CF/CM36C 1000 29.6 23.4 14.50 12.50
TC3B3022S ME12CN21 21.0 CF/CM42C 825 29.0 21.2 14.50 12.50
TC3B3022S ME14DN21 24.5 CF/CM36D 1025 29.8 24.0 14.75 12.50
TC3B3022S ME14DN21 24.5 CF/CM42D 1025 29.8 24.0 14.75 12.50
TC3B3022S ME16CN21 21.0 CF/CM30C 900 29.0 22.2 14.25 12.25
TC3B3022S ME16CN21 21.0 CF/CM36C 900 29.4 22.2 14.50 12.50
TC3B3022S ME16CN21 21.0 CF/CM42C 900 29.4 22.4 14.50 12.50
TC3B3022S MVC08BN21 17.5 CF/CM30B 825 28.6 21.0 14.25 12.25
TC3B3022S MVC08BN21 17.5 CF/CM36B 825 28.8 21.2 14.25 12.25
TC3B3022S MVC08BN21 17.5 CF42B 850 29.0 21.6 14.25 12.25
TC3B3022S MVC12BN21 17.5 CF/CM30B 875 28.8 21.6 14.25 12.25
TC3B3022S MVC12BN21 17.5 CF/CM36B 875 29.2 22.0 14.25 12.25
TC3B3022S MVC12BN21 17.5 CF42B 875 29.2 22.0 14.50 12.50
TC3B3022S MVC12CN21 21.0 CF/CM30C 975 29.4 23.2 14.50 12.50
TC3B3022S MVC12CN21 21.0 CF/CM36C 1000 29.8 23.6 14.75 12.50
TC3B3022S MVC12CN21 21.0 CF/CM42C 975 29.8 23.2 14.75 12.50
TC3B3022S MVC14DN21 24.5 CF/CM36D 1000 29.8 23.6 14.75 12.50
TC3B3022S MVC14DN21 24.5 CF/CM42D 1000 29.8 23.4 14.75 12.50
TC3B3022S MVC16CN21 21.0 CF/CM30C 925 29.0 22.6 14.50 12.50
TC3B3022S MVC16CN21 21.0 CF/CM36C 1025 29.8 24.0 14.50 12.50
TC3B3022S MVC16CN21 21.0 CF/CM42C 925 29.4 22.6 14.75 12.50
TC3B3622S AE36BX21 17.5 – 975 35.0 25.4 14.00 12.00
TC3B3622S AE36CX21 21.0 – 975 35.2 25.6 14.25 12.25
TC3B3622S AE42CX21 21.0 – 1150 36.0 28.2 14.25 12.25
TC3B3622S AE48CX21 21.0 – 1050 35.8 26.8 14.50 12.25
TC3B3622S AE48DX21 24.5 – 1050 36.0 26.8 14.50 12.25
TC3B3622S AP36BX21 17.5 – 1150 35.4 27.2 13.25 11.25
TC3B3622S AP36CX21 21.0 – 1125 35.4 27.2 13.00 11.25
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5581712-BTG-C-0619
Johnson Controls Ducted Systems 7
TC3B3622S AP37CX21 21.0 – 1125 35.6 27.4 13.00 11.25
TC3B3622S AP48CX21 21.0 – 1300 36.0 29.4 13.00 11.25
TC3B3622S AVC36BX21 17.5 – 1000 35.2 25.6 14.00 12.00
TC3B3622S AVC36CX21 21.0 – 1075 35.8 26.8 14.25 12.25
TC3B3622S AVC42CX21 21.0 – 1050 35.8 26.8 14.50 12.25
TC3B3622S AVC48CX21 21.0 – 1025 35.8 26.4 14.50 12.25
TC3B3622S AVC48DX21 24.5 – 1225 36.0 28.8 14.50 12.25
TC3B3622S ME12BN21 17.5 CF/CM36B 1050 35.6 26.4 14.25 12.00
TC3B3622S ME12BN21 17.5 CF42B 1050 35.6 26.4 14.25 12.00
TC3B3622S ME12CN21 21.0 CF/CM36C 1000 35.4 25.8 14.25 12.25
TC3B3622S ME12CN21 21.0 CF/CM42C 1000 35.6 26.0 14.50 12.25
TC3B3622S ME12CN21 21.0 CF/CM48C 1000 35.6 26.0 14.50 12.25
TC3B3622S ME14DN21 24.5 CF/CM36D 1025 35.6 26.2 14.50 12.25
TC3B3622S ME14DN21 24.5 CF/CM42D 1200 36.0 28.4 14.50 12.25
TC3B3622S ME14DN21 24.5 CF/CM48D 1025 35.8 26.4 14.75 12.25
TC3B3622S ME16CN21 21.0 CF/CM36C 1100 35.8 27.2 14.25 12.25
TC3B3622S ME16CN21 21.0 CF/CM42C 1100 36.0 27.2 14.50 12.25
TC3B3622S ME16CN21 21.0 CF/CM48C 1100 36.0 27.6 14.50 12.25
TC3B3622S ME20DN21 24.5 CF/CM36D 1275 36.0 29.2 14.75 12.25
TC3B3622S ME20DN21 24.5 CF/CM42D 1275 36.0 29.2 14.75 12.25
TC3B3622S ME20DN21 24.5 CF/CM48D 1275 36.0 29.2 14.75 12.25
TC3B3622S MVC08BN21 17.5 CF/CM36B 1000 35.2 25.6 14.00 12.00
TC3B3622S MVC08BN21 17.5 CF42B 1000 35.4 26.0 14.00 12.00
TC3B3622S MVC12BN21 17.5 CF/CM36B 1075 35.6 26.6 14.25 12.00
TC3B3622S MVC12BN21 17.5 CF42B 975 35.2 25.6 14.25 12.00
TC3B3622S MVC12CN21 21.0 CF/CM36C 1125 36.0 27.4 14.50 12.25
TC3B3622S MVC12CN21 21.0 CF/CM42C 1050 35.8 26.8 14.75 12.25
TC3B3622S MVC12CN21 21.0 CF/CM48C 1050 36.0 26.8 14.75 12.25
TC3B3622S MVC14DN21 24.5 CF/CM36D 1100 36.0 27.2 14.75 12.25
TC3B3622S MVC14DN21 24.5 CF/CM42D 1100 36.0 27.2 14.75 12.25
TC3B3622S MVC14DN21 24.5 CF/CM48D 1100 36.0 27.6 14.75 12.25
TC3B3622S MVC16CN21 21.0 CF/CM36C 1125 36.0 27.4 14.50 12.25
TC3B3622S MVC16CN21 21.0 CF/CM42C 1125 36.0 27.6 14.75 12.25
TC3B3622S MVC16CN21 21.0 CF/CM48C 1125 36.0 27.6 14.75 12.25
TC3B3622S MVC20DN21 24.5 CF/CM36D 1175 36.0 28.6 14.75 12.25
TC3B3622S MVC20DN21 24.5 CF/CM42D 1175 36.0 28.0 14.75 12.25
TC3B3622S MVC20DN21 24.5 CF/CM48D 1275 36.0 29.0 14.75 12.25
TC3B4222S AE42CX21 21.0 – 1350 41.0 31.8 13.75 12.00
TC3B4222S AE48CBC21 21.0 – 1200 40.5 30.2 14.25 12.25
TC3B4222S AE48CX21 21.0 – 1200 40.5 30.2 14.25 12.25
TC3B4222S AE48DBC21 24.5 – 1250 41.0 31.0 14.50 12.25
TC3B4222S AE48DX21 24.5 – 1250 41.0 31.0 14.50 12.25
TC3B4222S AE60CX21 21.0 – 1200 41.0 30.8 14.00 12.25
TC3B4222S AE60CX22 21.0 – 1200 40.0 29.8 14.00 12.00
TC3B4222S AE60DX21 24.5 – 1350 42.0 32.8 14.25 12.25
TC3B4222S AP48CBC21 21.0 – 1300 40.5 31.0 13.00 11.25
TC3B4222S AP48CX21 21.0 – 1300 40.5 31.0 13.00 11.25
TC3B4222S AP48DX21 24.5 – 1475 40.5 32.6 13.00 11.25
TC3B4222S AVC42CX21 21.0 – 1250 40.5 30.8 13.75 12.00
TC3B4222S AVC48CX21 21.0 – 1200 40.5 30.2 14.00 12.00
TC3B4222S AVC48DX21 24.5 – 1225 41.0 30.8 14.25 12.25
TC3B4222S AVC60DX21 24.5 – 1200 41.5 30.8 14.00 12.25
TC3B4222S ME12BN21 17.5 CF42B 1225 40.0 30.2 13.50 11.50
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5581712-BTG-C-0619
8 Johnson Controls Ducted Systems
TC3B4222S ME12CN21 21.0 CF/CM42C 1225 40.5 30.4 14.00 12.00
TC3B4222S ME12CN21 21.0 CF/CM48C 1225 40.5 30.4 14.00 12.25
TC3B4222S ME12CN21 21.0 CF/CM60C 1225 40.0 30.0 14.00 12.00
TC3B4222S ME14DN21 24.5 CF/CM42D 1200 40.5 30.2 14.25 12.25
TC3B4222S ME14DN21 24.5 CF/CM48D 1200 40.5 30.0 14.25 12.25
TC3B4222S ME14DN21 24.5 CF/CM64D 1200 41.5 30.8 14.00 12.25
TC3B4222S ME16CN21 21.0 CF/CM42C 1325 40.5 31.6 14.00 12.00
TC3B4222S ME16CN21 21.0 CF/CM48C 1325 41.0 31.6 14.00 12.00
TC3B4222S ME16CN21 21.0 CF/CM60C 1325 40.5 31.2 14.00 12.00
TC3B4222S ME20DN21 24.5 CF/CM42D 1275 41.0 31.4 14.50 12.25
TC3B4222S ME20DN21 24.5 CF/CM48D 1275 41.0 31.2 14.50 12.25
TC3B4222S ME20DN21 24.5 CF/CM60D 1275 40.5 30.8 14.50 12.25
TC3B4222S ME20DN21 24.5 CF/CM64D 1250 41.5 31.4 14.25 12.50
TC3B4222S MVC12BN21 17.5 CF42B 1175 40.0 29.8 13.50 11.50
TC3B4222S MVC12CN21 21.0 CF/CM42C 1175 40.5 30.0 14.25 12.25
TC3B4222S MVC12CN21 21.0 CF/CM48C 1175 40.5 29.8 14.25 12.25
TC3B4222S MVC12CN21 21.0 CF/CM60C 1175 40.0 29.6 14.25 12.25
TC3B4222S MVC14DN21 24.5 CF/CM42D 1250 40.5 31.0 14.50 12.25
TC3B4222S MVC14DN21 24.5 CF/CM48D 1175 40.5 29.8 14.50 12.25
TC3B4222S MVC14DN21 24.5 CF/CM64D 1350 42.0 32.8 14.50 12.50
TC3B4222S MVC16CN21 21.0 CF/CM42C 1275 40.5 31.0 14.25 12.25
TC3B4222S MVC16CN21 21.0 CF/CM48C 1275 41.0 31.2 14.25 12.25
TC3B4222S MVC16CN21 21.0 CF/CM60C 1275 40.5 30.6 14.25 12.25
TC3B4222S MVC20DN21 24.5 CF/CM42D 1275 41.0 31.4 14.50 12.25
TC3B4222S MVC20DN21 24.5 CF/CM48D 1300 41.0 31.4 14.50 12.25
TC3B4222S MVC20DN21 24.5 CF/CM64D 1275 41.5 31.8 14.50 12.50
TC3B4821S AE48CX21 21.0 – 1425 47.5 35.0 14.25 12.25
TC3B4821S AE48DX21 24.5 – 1425 48.0 35.5 14.50 12.25
TC3B4821S AE60CX21 21.0 – 1425 48.0 35.5 14.50 12.25
TC3B4821S AE60DX21 24.5 – 1400 48.0 35.0 14.75 12.25
TC3B4821S AP48CX21 21.0 – 1300 46.0 32.5 13.25 11.50
TC3B4821S AP48DX21 24.5 – 1475 47.5 35.0 13.00 11.00
TC3B4821S AP60CX21 21.0 – 1500 48.0 35.5 13.00 11.25
TC3B4821S AP60DX22 24.5 – 1475 47.5 34.8 13.25 11.25
TC3B4821S AVC48CX21 21.0 – 1350 47.5 34.5 14.25 12.00
TC3B4821S AVC48DX21 24.5 – 1400 48.0 35.0 14.50 12.25
TC3B4821S AVC60CX21 21.0 – 1350 48.0 34.5 14.25 12.25
TC3B4821S AVC60DX21 24.5 – 1475 48.0 35.5 14.50 12.25
TC3B4821S ME14DN21 24.5 CF/CM60D 1425 48.0 35.0 14.50 12.25
TC3B4821S ME14DN21 24.5 CF/CM64D 1375 48.0 34.5 14.75 12.25
TC3B4821S ME16CN21 21.0 CF/CM48C 1475 48.0 35.5 14.50 12.25
TC3B4821S ME16CN21 21.0 CF/CM60C 1450 48.0 35.5 14.50 12.25
TC3B4821S ME20DN21 24.5 CF/CM48D 1475 48.0 35.5 14.50 12.25
TC3B4821S ME20DN21 24.5 CF/CM60D 1425 48.0 35.0 14.50 12.25
TC3B4821S ME20DN21 24.5 CF/CM64D 1425 48.0 35.5 14.75 12.25
TC3B4821S MVC14DN21 24.5 CF/CM48D 1325 47.5 33.5 14.50 12.25
TC3B4821S MVC14DN21 24.5 CF/CM60D 1350 47.5 34.0 14.25 12.25
TC3B4821S MVC14DN21 24.5 CF/CM64D 1325 48.0 34.0 14.75 12.25
TC3B4821S MVC16CN21 21.0 CF/CM48C 1425 48.0 35.0 14.25 12.25
TC3B4821S MVC16CN21 21.0 CF/CM60C 1650 48.0 37.0 15.00 12.50
TC3B4821S MVC20DN21 24.5 CF/CM48D 1450 48.0 35.5 14.25 12.00
TC3B4821S MVC20DN21 24.5 CF/CM60D 1475 48.0 35.5 14.50 12.25
TC3B4821S MVC20DN21 24.5 CF/CM64D 1375 48.0 34.5 14.75 12.25
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5581712-BTG-C-0619
Johnson Controls Ducted Systems 9
— = Not applicable.
MP ModularAir Handlers use Coil Only Ratings.
TC3B6021S AE60CX21 21.0 – 1625 56.0 40.0 13.25 11.25
TC3B6021S AE60DX21 24.5 – 1775 57.0 41.5 13.25 11.25
TC3B6021S AP60CX21 21.0 – 1525 54.5 38.0 13.00 10.75
TC3B6021S AP60DX22 24.5 – 1525 55.0 38.0 13.00 10.75
TC3B6021S AVC60CX21 21.0 – 1750 56.0 41.0 13.00 11.25
TC3B6021S AVC60DX21 24.5 – 1650 56.5 40.5 13.50 11.25
TC3B6021S ME16CN21 21.0 CF/CM60C 1625 56.0 40.0 13.50 11.25
TC3B6021S ME20DN21 24.5 CF/CM60D 1650 56.0 40.0 13.50 11.25
TC3B6021S ME20DN21 24.5 CF/CM64D 1625 56.5 40.5 13.50 11.50
TC3B6021S MVC16CN21 21.0 CF/CM60C 1650 56.5 40.5 14.25 12.00
TC3B6021S MVC20DN21 24.5 CF/CM60D 1700 56.0 40.0 13.50 11.25
TC3B6021S MVC20DN21 24.5 CF/CM64D 1700 56.5 40.0 13.50 11.25
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total
electric power input in watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER 1EER
TOTAL SENS.
TC3B1822S CF/CM/CU18A 14.5 450 - 750 600 17.2 13.0 13.00 11.50
TC3B1822S CF/CM/CU18B 17.5 450 - 750 600 17.2 13.8 13.00 11.50
TC3B1822S CF/CM/CU24A 14.5 450 - 750 600 17.4 13.9 13.00 11.50
TC3B1822S CF/CM/CU24B 17.5 450 - 750 600 17.4 13.9 13.00 11.50
TC3B1822S CF/CM/CU30A 14.5 450 - 750 600 17.6 14.1 13.00 11.50
TC3B1822S CF/CM/CU30B 17.5 450 - 750 600 17.6 14.1 13.00 11.50
TC3B1822S CF/CM/CU36B 17.5 450 - 750 600 17.6 14.0 13.25 11.75
TC3B1822S CF/CM/CU36C 21.0 450 - 750 600 17.6 14.0 13.25 11.75
TC3B1822S CF/CM24C 21.0 450 - 750 600 17.4 13.9 13.00 11.50
TC3B1822S CF/CM30C 21.0 450 - 750 600 17.6 14.1 13.00 11.50
TC3B1822S CF/CM36A 14.5 450 - 750 600 17.6 14.0 13.25 11.75
TC3B1822S CF/CM36D 24.5 450 - 750 600 17.6 14.0 13.25 11.75
TC3B2422S CF/CM/CU24A 14.5 600 - 1000 800 23.0 16.1 13.00 11.50
TC3B2422S CF/CM/CU30A 14.5 600 - 1000 800 23.0 18.3 13.00 11.50
TC3B2422S CF/CM/CU30B 17.5 600 - 1000 800 23.0 18.3 13.00 11.50
TC3B2422S CF/CM/CU36B 17.5 600 - 1000 800 23.4 18.5 13.00 11.50
TC3B2422S CF/CM/CU36C 21.0 600 - 1000 800 23.4 18.5 13.00 11.50
TC3B2422S CF/CM/CU42C 21.0 600 - 1000 800 23.6 18.7 13.00 11.50
TC3B2422S CF/CM30C 21.0 600 - 1000 800 23.0 18.3 13.00 11.50
TC3B2422S CF/CM36A 14.5 600 - 1000 800 23.6 18.7 13.00 11.50
TC3B2422S CF/CM36D 24.5 600 - 1000 800 23.4 18.5 13.00 11.50
TC3B2422S CF/CM42D 24.5 600 - 1000 800 23.6 18.7 13.00 11.50
TC3B2422S CF42B 17.5 600 - 1000 800 23.4 18.5 13.00 11.50
TC3B3022S CF/CM/CU30B 17.5 800 - 1200 1000 28.6 21.4 13.00 11.00
TC3B3022S CF/CM/CU36B 17.5 800 - 1200 1000 29.0 23.0 13.00 11.25
TC3B3022S CF/CM/CU36C 21.0 800 - 1200 1000 29.0 23.0 13.00 11.25
TC3B3022S CF/CM/CU42C 21.0 800 - 1200 1000 29.0 22.8 13.00 11.25
TC3B3022S CF/CM30C 21.0 800 - 1200 1000 28.8 22.8 13.00 11.00
TC3B3022S CF/CM36D 24.5 800 - 1200 1000 29.0 23.0 13.00 11.25

5581712-BTG-C-0619
10 Johnson Controls Ducted Systems
— = Not Applicable.
MP ModularAir Handlers use Coil Only Ratings.
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
TC3B3022S CF/CM42D 24.5 800 - 1200 1000 29.0 22.8 13.00 11.25
TC3B3622S CF/CM/CU36B 17.5 1000 - 1400 1200 35.2 26.0 13.00 11.00
TC3B3622S CF/CM/CU36C 21.0 1000 - 1400 1200 35.2 27.6 13.00 11.00
TC3B3622S CF/CM/CU42C 21.0 1000 - 1400 1200 35.4 28.0 13.00 11.00
TC3B3622S CF/CM/CU48C 21.0 1000 - 1400 1200 35.6 28.0 13.25 11.25
TC3B3622S CF/CM/CU48D 24.5 1000 - 1400 1200 35.6 28.0 13.25 11.25
TC3B3622S CF/CM36D 24.5 1000 - 1400 1200 35.2 27.6 13.00 11.00
TC3B3622S CF/CM42D 24.5 1000 - 1400 1200 35.4 28.0 13.00 11.00
TC3B3622S CF42B 17.5 1000 - 1400 1200 35.4 28.0 13.00 11.00
TC3B4222S CF/CM/CU42C 21.0 1200 - 1600 1400 40.0 28.6 13.00 11.00
TC3B4222S CF/CM/CU48C 21.0 1200 - 1600 1400 40.0 31.6 13.00 11.25
TC3B4222S CF/CM/CU48D 24.5 1200 - 1600 1400 40.0 31.6 13.00 11.25
TC3B4222S CF/CM/CU60C 21.0 1200 - 1600 1400 40.0 31.4 13.00 11.25
TC3B4222S CF/CM42D 24.5 1200 - 1600 1400 40.0 31.8 13.00 11.00
TC3B4222S CF/CM64D 24.5 1200 - 1600 1400 41.0 32.8 13.00 11.25
TC3B4821S CF/CM/CU48C 21.0 1400 - 1800 1600 46.0 33.5 13.00 11.00
TC3B4821S CF/CM/CU48D 24.5 1400 - 1800 1600 46.0 33.5 13.00 11.00
TC3B4821S CF/CM/CU60C 21.0 1400 - 1800 1600 48.0 36.0 13.00 11.25
TC3B4821S CF/CM/CU60D 24.5 1400 - 1800 1600 48.0 36.0 13.00 11.25
TC3B4821S CF/CM64D 24.5 1400 - 1800 1600 48.0 36.0 13.00 11.25
TC3B6021S CF/CM/CU60C 21.0 1520 - 1920 1720 55.0 40.0 13.00 11.00
TC3B6021S CF/CM/CU60D 24.5 1520 - 1920 1725 55.0 40.0 13.00 11.00
TC3B6021S CF/CM64D 24.5 1520 - 1920 1725 56.5 41.0 13.00 11.00
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. Requires a S1-2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings) (Continued)
UNIT MODEL
COIL CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER 1EER
TOTAL SENS.
