Johnson Controls FAC2513 User manual

FAC2513 Advanced Application Field Equipment
Controller Installation Guide
Application
The FAC2513 Advanced Application Field Equipment
Controller (FAC) is part of the Metasys® system Field
Equipment Controller (FEC) family. These controllers
run pre-engineered and user-programmed
applications and provides the inputs and outputs
required to monitor and control a wide variety of
HVAC and other facility equipment.
FAC25 field controllers operate on an RS-485
BACnet® MS/TP Bus as BACnet Application Specific
Controllers (B-AACs) and integrate into Johnson
Controls® and third-party BACnet systems. FAC25
controllers include an integral real-time clock, which
enables the controllers to monitor and control
schedules, calendars, and trends, and operate for
extended periods of time as stand-alone controllers
when offline from the Metasys system network. This
model does not support wireless applications.test
Communications Protocols
The FAC2513 field controllers can communicate
using BACnet MS/TP or N2. By default, the FAC2513
field controllers communicate using the standard
BACnet MS/TP protocol based on the ANSI/
ASHRAE 135-2016, Protocol Revision 15. The BACnet
protocol is a standard for ANSI, ASHRAE, and the
International Standards Organization (ISO) for
building controls.
The FEC Family Controllers, including the FAC2513,
can be used as functional replacements for
legacy N2 controllers. The N2-capable MS/TP
field controller models provide a cost-effective
upgrade and modernization path for customers
with existing N2 controllers. For installation and
commissioning support, and tips for efficient and
safe replacement, refer to the Modernization Guide
for Legacy N2 Controllers (LIT-12012005) and the
controller-specific documentation. For information
about mapping N2 Objects in controllers with
switchable communications protocols, refer to the
N2 Compatibility Options chapter of the Controller Tool
Help (LIT-12011147).
For more details on configuring FAC2513 controllers
to communicate using the N2 communications
protocol, see Configuring N2 Communications.
North American emissions
compliance
United States
This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when this equipment
is operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area
may cause harmful interference, in which case the
users will be required to correct the interference at
their own expense.
Canada
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte
toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
Installation
Observe the following guidelines when installing a
field controller:
• To minimize vibration and shock damage,
transport the controller in the original container.
• Verify that all parts shipped with the controller.
• Do not drop the controller or subject it to physical
shock.test
Parts included
• One FAC controller with removable terminal
blocks (Power, SA bus, and FC bus are removable)
• One installation instructions sheet
*24110236B*
Part No. 24-11023-6 Rev. B
2019-10-18
(barcode for factory use only)
MS-FAC2513

Materials and special tools needed
• Three fasteners appropriate for the mounting
surface (M4 screws or #8 screws)
• One 20 cm (8 in.) or longer piece of 35 mm DIN
rail and appropriate hardware for DIN rail mount
(only)
• Small straight-blade screwdriver for securing
wires in the terminal blocks
FAC2513 physical features
Figure 1: FAC2513 physical features
Table 1: Physical features
Physical features: description and references
1Device Address Dip Switch Block (see Setting the device
address)
2Configurable Output (CO) Terminal Block (see Table 3)
324 VAC, Class 2 Supply Power Terminal Block (see Supply
power terminal block)
4Field Controller (FC) Bus Terminal Block (see FC bus
terminal block)
5Sensor Actuator (SA) Bus Terminal Block (see SA bus
terminal block)
6Sensor Actuator (SA) Bus (RJ-12 6-pin Modular Jack) (see
SA Bus port)
7Binary Input (BI) Terminal Block (see Table 3)
8Universal Inputs (UI) Terminal Block (see Table 3)
9LED Status Indicators (see Table 8)
10 Binary Output (BO) Terminal Block (see Table 3)
11 Analog Outputs (AO) Terminal Block (see Table 3)
12 Cover lift tabs
FAC2513 Advanced Application Field Equipment Controller Installation Guide2

FAC2513 point type counts
The following table shows the different point types
and counts available in the FAC2513 and FAC26
Series controllers.
Note: The FAC2513 model is only available in
certain regions. Contact your local Johnson
Controls representative for more information.
Table 2: FAC2513 and FAC26 Series Point Type Counts per Model
Point Types Signals Accepted FAC2513 FAC2611
Universal Input (UI)
Analog Input, Voltage Mode, 0–10 VDC
Analog Input, Current Mode, 4–20 mA
Analog Input, Resistive Mode, 0–2k ohm, RTD
(1k NI [Johnson Controls], 1k PT, A99B SI), NTC
(10k Type L, 2.252k Type 2)
Binary Input, Dry Contact Maintained Mode
4 (Does not support Current
Mode) 6
Binary Input (BI)
Dry Contact Maintained Mode
Pulse Counter/Accumulator Mode (High
Speed), 100 Hz
6 2
Analog Output (AO) Analog Output, Voltage Mode, 0–10 VDC
Analog Output, Current Mode, 4–20 mA
2 (Does not support Current
Mode) 2
Binary Output (BO) 24 VAC Triac 2 (External Power only) 3
Configurable Output (CO) Analog Output, Voltage Mode, 0–10 VDC
Binary Output Mode, 24 VAC Triac 2 4
Mounting
Observe the following guidelines when mounting a
field controller:
• Ensure the mounting surface can support the
controller, DIN rail, and any user-supplied
enclosure.
• Mount the controller horizontally on 35 mm DIN
rail whenever possible.
• Mount the controller in the proper mounting
position (Figure 2).
• Mount the controller on a hard, even surface
whenever possible in wall-mount applications.
• Use shims or washers to mount the controller
securely and evenly on the mounting surface.
• Mount the controller in an area free of corrosive
vapors and observe the Ambient Conditions
requirements in Technical specifications.
• Provide for sufficient space around the controller
for cable and wire connections for easy cover
removal and good ventilation through the
controller (50 mm [2 in.] minimum on the top,
bottom, and front of the controller).
• Do not mount the controller on surfaces prone to
vibration, such as duct work.
• Do not mount the controller in areas where
electromagnetic emissions from other
devices or wiring can interfere with controller
communication.
Observe these additional guidelines when mounting
a field controller in a panel or enclosure:
• Mount the controller so that the enclosure walls
do not obstruct cover removal or ventilation
through the controller.
• Mount the controller so that the power
transformer and other devices do not radiate
excessive heat to the controller.
• Do not install the controller in an airtight
enclosure.
FAC2513 Advanced Application Field Equipment Controller Installation Guide 3

Figure 2: Mounting positions
Mounting features and dimensions
Figure 3: Back of Controller showing extended
mounting clips, DIN rail channel, and mounting
dimensions, mm (in.)
DIN rail mount applications
Mounting the field controller horizontally on 35 mm
DIN rail is the preferred mounting method.
To mount a controller on 35 mm DIN rail, complete
the following steps:
1. Securely mount a 20 cm (8 in.) or longer section
of 35 mm DIN rail horizontal and centered in
the appropriate location so that the controller
mounts in the horizontal position.
2. Pull the two bottom mounting clips outward
from the controller to the extended position.
3. Hang the controller on the DIN rail by the hooks
at the top of the (DIN rail) channel on the back
of the controller, and position the controller
snugly against the DIN rail.
4. Push the bottom mounting clips inward (up) to
secure the controller on the DIN rail.
To remove the controller from the DIN rail, pull the
bottom mounting clips out to the extended position
and carefully lift the controller off the DIN rail.
Wall mount applications
To mount a field controller directly on a wall or
other flat vertical surface, complete the following
steps:
1. Pull the two bottom mounting clips outward
and ensure they are locked in the extended
position.
2. Mark the mounting hole locations on the wall
in either the horizontal or vertical mounting
position. Or hold the controller up to the wall or
surface in a proper mount position and msark
the hole locations through the mounting clips.
3. Drill holes in the wall or surface at the marked
locations, and insert appropriate wall anchors
in the holes (if necessary).
4. Hold the controller in place, and insert the
screws through the mounting clips and into the
holes (or anchors). Carefully tighten all of the
screws.
Important: Do not overtighten the mounting
screws. Overtightening the screws may
damage the mounting clips.
FAC2513 Advanced Application Field Equipment Controller Installation Guide4

Wiring
CAUTION
Risk of Electric Shock
Disconnect the power supply before making electrical
connections to avoid electric shock.
ATTENTION
Risque de décharge électrique
Débrancher l'alimentation avant de réaliser tout rac-
cordement électrique afin d'éviter tout risque de
décharge électrique.
CAUTION
Risk of Property Damage
Do not apply power to the system before checking all
wiring connections. Short circuited or improperly con-
nected wires may result in permanent damage to the
equipment.
ATTENTION
Mise En Garde: Risque de dégâts matériels
Ne pas mettre le système sous tension avant d'avoir
vérifié tous les raccords de câblage. Des fils for-
mant un court-circuit ou connectés de façon incor-
recte risquent d'endommager irrémédiablement
l'équipement.
Important: Do not exceed the controller
electrical ratings. Exceeding controller electrical
ratings can result in permanent damage to the
controller and void any warranty.
Important: Use copper conductors only. Make
all wiring in accordance with local, national, and
regional regulations.
Important: Electrostatic discharge can
damage controller components. Use proper
electrostatic discharge precautions during
installation, setup, and servicing to avoid
damaging the controller.
For detailed information on configuring and
wiring an MS/TP Bus, FC bus, and SA bus, refer to
the MS/TP Communications Bus Technical Bulletin
(LIT-12011034). For detailed information on wiring
an N2 network, refer to the N2 Communications Bus
Technical Bulletin (LIT-636018)
Terminal blocks and bus ports
See Figure 1 for a terminal block and bus port
locations on the controller. Observe the following
guidelines for terminal blocks and bus ports when
you wire a controller.
Input and Output terminal blocks
The fixed input terminal blocks are mounted on the
bottom of the controller and the output terminal
blocks are mounted on the top of the controller. See
Figure 1 for more information about I/O terminal
functions, requirements, and ratings.
FC bus terminal block
The FC Bus terminal block is a blue, removable, 4-
terminal plug that fits into a board-mounted jack.
Wire the removable FC bus terminal block plugs on
the controller, and other controllers in a daisy-chain
configuration using 3-wire twisted, shielded cable as
shown below. See Table 5 for more information.
Figure 4: FC bus terminal block wiring
FAC2513 Advanced Application Field Equipment Controller Installation Guide 5

Note: The FC bus Shield (SHLD) terminal is
isolated and can be used to connect (daisy
chain) the shields for FC bus wiring.
SA bus terminal block
The SA Bus terminal block is a brown, removable, 4-
terminal plug that fits into a board-mounted jack.
Wire the removable SA Bus terminal block plugs on
the controller and other SA Bus devices in a daisy-
chain configuration using 4-wire twisted, shielded
cable as shown in the following figure. See Table 5
for more information.
Figure 5: SA bus terminal block wiring
Note: The SA PWR terminal supplies 15 VDC.
The SA PWR terminal can be used to connect
(daisy chain) the 15 VDC power leads on the SA
bus.
SA Bus port
The Sensor (SA Bus) port on the bottom of the
controller (Figure 1) is an RJ-12, 6-position modular
jack that provides a connection for the Mobile
Access Portal (MAP) Gateway, the Bluetooth®
Commissioning Converter (BTCVT), the VAV
Balancing Tool, specified network sensors, or other
SA Bus devices with RJ-12 plugs.
The Sensor port is connected internally to the
SA bus terminal block. See Table 5 for more
information.
Note: The MAP Gateway serves as a
replacement for the BTCVT, which is no longer
available for purchase, but continues to be
supported.
Figure 6: Pin number assignments for sensor
and SA bus ports on Controllers
Supply power terminal block
The 24 VAC supply power terminal block is a gray,
removable, 3-terminal plug that fits into a board-
mounted jack on the top right of the controller.
Wire the 24 VAC supply power wires from the
transformer to the HOT and COM terminals on
the terminal plug as shown below. Do not use the
middle terminal on the supply power terminal block.
See Table 5 for more information about the Supply
Terminal Block.
Figure 7: 24 VAC supply power terminal block
wiring
Note: The supply power wire colors may
be different on transformers from other
manufacturers. Refer to the transformer
manufacturer’s instructions and the project
installation drawings for wiring details.
FAC2513 Advanced Application Field Equipment Controller Installation Guide6

Important: Connect 24 VAC supply power to
the controller and all other network devices so
that transformer phasing is uniform across the
network devices. Powering network devices
with uniform 24 VAC supply power phasing
reduces noise, interference, and ground loop
problems. The field controller does not require
an earth ground connection.
Terminal Wiring Guidelines,
Functions, Ratings, and
Requirements
Input and Output wiring guidelines
Table 3 provides information and guidelines about
the functions, ratings, and requirements for the
controller input and output terminals. This table
also references guidelines for determining proper
wire sizes and cable lengths.
In addition to the wiring guidelines in the table,
observe the following guidelines when you wire
controller inputs and outputs:
• Run all low-voltage wiring and cables separate
from high-voltage wiring.
• All input and output cables, regardless of wire
size or number of wires, should consist of
stranded, insulated, and twisted copper wires.
• Shielded cable is not required for input or output
cables.
• Shielded cable is recommended for input
and output cables that are exposed to high
electromagnetic or radio frequency noise.
• Inputs/outputs with cables less than 30 m (100 ft)
typically do not require an offset in the software
setup. Cable runs over 30 m (100 ft) may require
an offset in the input/output software setup.
FAC2513 Advanced Application Field Equipment Controller Installation Guide 7

Input and Output wiring guidelines
table
Table 3: I/O Terminal Blocks, Functions, Ratings, Requirements, and Cables
Terminal block label Terminal label Function, ratings, requirements Determine wire size and
maximum cable length
+15 V
15 VDC Power Source for active (3-wire) input
devices connected to the Universal INn terminals.
Provides 100 mA total current
Same as (Universal) INn
Note: Use 3-wire cable for
devices that source power
from the +15 V terminal.
See Guideline A in Table 4.Analog Input - Voltage Mode (0–10 VDC)
10 VDC maximum input voltage
Internal 75k ohms pull-down See Guideline B in Table 4.
Analog Input - Resistive Mode (0–600k ohms)
Internal 12 V 15k ohms pull up
Qualified Sensors: 0–2k ohms potentiometer, RTD
(1k Nickel [Johnson Controls sensor], 1k Platinum,
and A99B Silicon Temperature Sensor) Negative
Temperature Coefficient (NTC) Sensor (10k Type L,
10k JCI Type II, 2.252k Type II)
See Guideline A in Table 4.INn
Binary Input - Dry Contact Maintained Mode
1 second minimum pulse width
Internal 12 V 15k ohms pull up
See Guideline A in Table 4.
UNIVERSAL
(Inputs)
ICOMn
Universal Input Common for all Universal Input
terminals
Note: All Universal ICOMn terminals share
a common, which is isolated from all other
commons, except the SA bus common.
Same as (Universal) INn
Binary Input - Dry Contact Maintained Mode
0.01 second minimum pulse width
Internal 18 V 3k ohms pull up
INnBinary Input - Pulse Counter/Accumulator Mode
0.01 second minimum pulse width
(50 Hz at 50% duty cycle)
Internal 18 V 3k ohms pull up
BINARY
(Inputs)
ICOMn
Binary Input Common for all Binary Input (IN)
terminals
Note: All Binary ICOMn terminals share a
common, which is isolated from all other
commons, except the Configurable Output
(CO) common (OCOMn) when the CO is defined
as an Analog Output.
See Guideline A in Table 4.
OUTn
Analog Output - Voltage Mode (0–10 VDC)
10 VDC maximum output voltage
10 mA maximum output current
Required an external load of 1,000 ohms or more.
Note: The Analog Output (AO) operates in the
Voltage Mode when connected to devices with
impedances greater than 1,000 ohms. Devices
that drop below 1,000 ohms may not operate
as intended for Voltage Mode applications.
ANALOG
(Outputs)
OCOMn
Analog Output Signal Common for all Analog OUT
terminals.
Note: All Analog Output Common terminals
(OCOMn) share a common, which is isolated
from all other commons.
See Guideline C in Table 4.
FAC2513 Advanced Application Field Equipment Controller Installation Guide8

Table 3: I/O Terminal Blocks, Functions, Ratings, Requirements, and Cables
Terminal block label Terminal label Function, ratings, requirements Determine wire size and
maximum cable length
OUTn
Binary Output - 24 VAC Triac (Internal Power
Source)
Sources internal 24 VAC power (24~ HOT).
BINARY
(Output)
OCOMn
Binary Output - 24 VAC Triac (Internal Power
Source)
Connects OCOMn to 24~ when activated.
Internal Power Source:
30 VAC maximum output voltage
0.5 A maximum output current
1.3 A at 25% duty cycle
40 mA minimum load current
See Guideline C in Table 4.
Analog Output - Voltage Mode (0–10 VDC)
10 VDC maximum output voltage
10 mA maximum output current
Required an external load of 1,000 ohms or more.
See Guideline A in Table 4.
OUTn
Binary Output - 24 VAC Triac (External Power Source
only)
Connects OUTn to OCOMn when activated.
External Power Source Requirements:
30 VAC maximum output voltage
0.5 A maximum output current
1.3 A at 25% duty cycle
40 mA minimum load current
See Guideline C in Table 4.
Analog Output Signal Common All Configurable
Outputs (COs) defined as Analog Outputs (AOs) share
a common, which is isolated from all other commons
except the Binary Input common.
CONFIGURABLE
(Outputs)
OCOMnBinary Output Signal Common All Configurable
Outputs (COs) defined as Binary Outputs are
isolated from all other commons, including other CO
commons.
Same as (Configurable) OUTn.
Cable and wire length guidelines
Table 4 defines cable length guidelines for the
various wire sizes that may be used for wiring low-
voltage (30V) input and outputs.
Note: The required wire sizes and lengths
for high voltage (>30 V) Relay Outputs are
determined by the load connected to the relay,
and local, national, or regional electrical codes.
Table 4: Cable length guidelines for recommended wire sizes for low-voltage (<30 V) Inputs and
Outputs
Guideline Wire size/Gauge and type Maximum cable length and
type Assumptions
1.0 mm (18 AWG) stranded
copper 457 m (1,500 ft) twisted wire
0.8 mm (20 AWG) stranded
copper 297 m (975 ft) twisted wire
0.6 mm (22 AWG) stranded
copper 183 m (600 ft) twisted wire
A
N/A (24 AWG) stranded copper 107 m (350 ft) twisted wire
100 mV maximum voltage drop
Depending on cable and the connected input
or output device, you may have to define an
offset in the setup software for the input or
output point.
FAC2513 Advanced Application Field Equipment Controller Installation Guide 9

Table 4: Cable length guidelines for recommended wire sizes for low-voltage (<30 V) Inputs and
Outputs
Guideline Wire size/Gauge and type Maximum cable length and
type Assumptions
1.0 mm (18 AWG) stranded
copper 229 m (750 ft) twisted wire
0.8 mm (20 AWG) stranded
copper 137 m (450 ft) twisted wire
0.6 mm (22 AWG) stranded
copper 91 m (300 ft) twisted wire
B
N/A (24 AWG) stranded copper 61 m (200 ft) twisted wire
100 mV maximum voltage drop
Depending on cable and the connected input
or output device, you may have to define an
offset in the setup software for the input or
output point.
C
See Figure 8 to select wire size/
gauge. Use stranded copper
wire
See Figure 8 to determine cable
length. Use twisted wire cable. N/A
Maximum cable length versus load
current
Use Figure to estimate the maximum cable length
relative to the wire size and the load current (in mA)
when you wire inputs and outputs.
Note: Figure applies to low-voltage (<30 V)
inputs and outputs only.
Figure 8: Maximum wire length for low-voltage
(<30 V) Inputs and Outputs by current and wire
size
Communications bus and supply
power wiring guidelines
Table 5 provides information about the functions,
ratings, and requirements for the communication
bus and supply power terminals. The table also
provides guidelines for wire sizes, cable types, and
cable lengths for when you wire the controller's
communication buses and supply power.
In addition to the guidelines in Table 5, observe the
following guidelines when you wire an SA or FC bus
and the 24 VAC supply power:
• Run all low-voltage wiring and cables separate
from high-voltage wiring.
• All SA and FC bus cables, regardless of wire size,
should be twisted, insulated, stranded copper
wire.
• Shielded cable is strongly recommended for all SA
and FC bus cables.
• Refer to the MS/TP Communications Bus
Technical Bulletin (LIT-12011034) for detailed
information regarding wire size and cable length
requirements for the SA and FC buses.
Communications bus and supply
power terminal blocks, ratings, and
requirements
Note: The SA Bus and FC bus wiring
recommendations in this table are for MS/TP
bus communications at 38.4k baud.
Table 5: Communications Bus and Supply Power Terminal Blocks, Functions, Ratings, Requirements,
and Cables
Terminal block/
Port label
Terminal
labels Function, electrical ratings/Requirements Recommended cable type
+
-FC Bus Communications
COM Signal Reference (Common) for Bus communications
FC BUS
SHLD Isolated terminal (optional shield drain connection)
0.6 mm (22 AWG) stranded, 3-wire
twisted, shielded cable recommended
FAC2513 Advanced Application Field Equipment Controller Installation Guide10

Table 5: Communications Bus and Supply Power Terminal Blocks, Functions, Ratings, Requirements,
and Cables
Terminal block/
Port label
Terminal
labels Function, electrical ratings/Requirements Recommended cable type
+
-SA Bus Communications
COM SA Bus Signal Reference and 15 VDC Common
SA BUS
SA PWR 15 VDC Supply Power for Devices on the SA Bus
(Maximum total current draw for SA Bus is 240 mA.)
0.6 mm (22 AWG) stranded, 4-wire
(2 twisted-pairs), shielded cable
recommended.
Note: The + and - wire are one
twisted pair, and the COM and
SA PWR are the second twisted
pair of wires.
Sensor Sensor
RJ-12 6-Position Modular Connector provides:
SA Bus Communications
SA Bus Signal Reference and 15 VDC Common
15 VDC Power for devices on the SA bus and Wireless
Commissioning Converter
24 AWG 3-pair CAT3 cable <30.5 m
(100 ft)
HOT 24 VAC Power Supply - Hot
Supplies 20–30 VAC (Nominal 24 VAC)
24~
COM
24 VAC Power Supply Common (Isolated from all other
Common terminals on controller)
35 VA
0.8 mm to 1.0 mm
(18 AWG) 2-wire
Note: The SA Bus and FC Bus wiring
recommendations in this table are for MS/TP
bus communications at 38.4k baud. For more
information, refer to MS/TP communications
Bus Technical Bulletin (LIT-12011034).
Termination details
A set of Johnson Controls termination diagrams
provides details for wiring inputs and outputs to the
controllers. See the figures in this section for the
applicable termination diagrams.
Table 6: Termination details
Type of field
device
Type of
Input/
Output
Termination diagrams
Temperature
Sensor UI
FAC2513 Advanced Application Field Equipment Controller Installation Guide 11

Table 6: Termination details
Type of field
device
Type of
Input/
Output
Termination diagrams
Voltage Input
- External
Source
UI
Voltage Input
- Internal
Source
UI
Voltage
Input (Self-
Powered)
UI
Feedback
from
EPP-1000
UI
Dry Contact
(Binary
Input)
UI or BI
FAC2513 Advanced Application Field Equipment Controller Installation Guide12

Table 6: Termination details
Type of field
device
Type of
Input/
Output
Termination diagrams
0–10 VDC
Output to
Actuator
(Internal
Source)
CO or AO
0–10 VDC
Output to
Actuator
(External
Source)
CO or AO
Voltage
(Analog
Output)
AO
24 VAC Triac
Output
(Switch Low,
External
Source)
CO
FAC2513 Advanced Application Field Equipment Controller Installation Guide 13

Table 6: Termination details
Type of field
device
Type of
Input/
Output
Termination diagrams
Incremental
Control to
Actuator
(Switch Low,
Externally
Sourced)
(Triac
Jumpers
Where
Applicable)
BO
24 VAC Binary
Output
(Switch Low,
Externally
Sourced)
(Triac
Jumpers
Where
Applicable)
BO
24 VAC Binary
Output
(Switch High,
Externally
Sourced)
(Triac
Jumpers
Where
Applicable)
BO
Incremental
Control to
Actuator
(Switch High,
Externally
Sourced)
(Triac
Jumpers
Where
Applicable)
BO
FAC2513 Advanced Application Field Equipment Controller Installation Guide14

Table 6: Termination details
Type of field
device
Type of
Input/
Output
Termination diagrams
Network Stat
with Phone
Jack (Fixed
Address =
199)
SA Bus
Note: The bottom jack (J2) on the TE-700 and TE-6x00 Series Sensors is
not usable as a zone bus or a SAB connection.
Network
Stat with
Terminals
Addressable
SA Bus
Network
Stat with
Terminals
(Fixed
Address =
199)
SA Bus
Setup and Adjustments
Configuring N2 Communications
N2-capable controllers support the full range of
possible N2 device addresses provided by the N2
protocol standard (1–254).
To configure a controller to communicate using the
N2 protocol, complete the following steps:
1. Disconnect the 24 VAC supply from the
controller.
FAC2513 Advanced Application Field Equipment Controller Installation Guide 15

2. Set the address switches to the desired N2
address. For details about setting a device
address, see Setting the device address.
3. Reconnect the 24 VAC supply to the controller.
4. Using an SA bus connection, download the
firmware and controller application file
configured for N2 to the controller.
Switching the Communications Protocol
from N2 to MS/TP
For N2 sites that are converting to BACnet MS/TP,
you can switch the communications protocol of N2-
configured MS/TP controllers back to BACnet MS/TP.
To switch an FAC2513 field controller operating in
N2 mode back to BACnet MS/TP mode, complete the
following steps:
1. Disconnect the 24 VAC supply from the
controller.
2. Set the address switches to the desired BACnet
MS/TP address. For details about setting a
device address, see Setting the device address.
3. Ensure the DIP switch 128 is set to OFF.
4. Reconnect the 24 VAC supply to the controller.
5. Using an SA Bus connection, download a
controller application file configured for BACnet
MS/TP to the controller.
Setting the device address
Metasys field controllers are master devices on
MS/TP (SA or FC) buses. Before you operate field
controllers on a bus, you must set a valid and
unique device address for each controller on the
bus. You set a controller's device address by setting
the positions of the switches on the DIP switch
block at the top of the controller. Device addresses
4 through 127 are the valid addresses for these
controllers on an MS/TP FC bus.
The following table describes the FC bus and SA
bus device addresses for Johnson Controls MS/TP
communications bus applications.
Table 7: SA/FC bus device address descriptions
Device address Use on descriptions
0
(Switch 128 Off)
Reserved for FC Bus Supervisory
Controller (not for use on
controllers or expansion
modules).
1-3
(Switch 128 Off)
Reserved for peripheral devices
(not for use on controllers or
expansion modules).
4-127
(Switch 128 Off)
Used for MSTP master devices
(controllers and expansion
modules) that are hardwired to
an SA bus or FC bus.
The DIP switch block has eight switches numbered
128, 64, 32, 16, 8, 4, 2, and 1. Switches 64 through
to 1 are device address switches. Switch 128 must
be set to OFF for all hard-wired SA and FC bus
applications.
Figure 9: Device Address DIP Switch Block Set to
Address 21
Note: Metasys field controllers ship with
switch 128 ON and the remaining address
switches off rendering the controllers wired
subordinate devices, which do not operate
on MSTP buses, but do not interfere with
bus operation.Set a valid and unique device
address on the controller before applying
power to the controller on the bus.
To set the device addresses on Metasys field
controllers, complete the following steps:
1. Set all of the switches on the address DIP
switch block (128 through 1) to OFF.
2. Set one or more of the seven address switches
(64 though 1) to ON, so that the sum of the
switch numbers set to ON equals the intended
device address. Ensure that switch 128 remains
set to OFF.
FAC2513 Advanced Application Field Equipment Controller Installation Guide16

Note: Set the highest number switch that
is less than or equal to the intended device
address to ON. Then continue setting lower
numbered switches until the total equals the
intended address. For example, if the intended
device address is 21, set switch 16 to ON first,
then set switch 4 ON, followed by switch 1
(16+4+1= 21). See Figure .
3. Set a unique and sequential device address for
each of the field controllers connected on the
SA or FC bus starting with device address 4.
Note: To ensure the best bus performance, set
sequential device addresses with no gaps in the
device address range (4, 5, 6, 7, 8, 9, and so on).
The controllers do not need to be physically
connected on the bus in their numerical device
address order.
4. Write each controller's device address on the
white label below the DIP switch block on the
controller's cover.
Removing the controller cover
Important: Electrostatic discharge can
damage controller components. Use proper
electrostatic discharge precautions during
installation, setup, and servicing to avoid
damaging the controller.
Important: Disconnect all power sources to
the controller before you remove the cover and
change the position of any jumper or the EOL
switch on the controller. Failure to disconnect
power before changing a jumper or EOL switch
position can result in damage to the controller
and void any warranties.
The controller cover is held in place by four
plastic latches that extend from the base and
snap into slots on the inside of the housing
cover.
To remove the controller cover, complete the
following steps:
1. Place your fingernails under the two cover lift
tabs on the sides of the housing cover and
gently pry the top of the cover away from the
base to release the cover from the two upper
latches.
2. Pivot the top of the cover further to release it
from the lower two latches.
3. Replace the cover by placing it squarely over
the base, and then gently and evenly push the
cover on to the latches until they snap into the
latched position.
Figure 10: FAC2513 with cover removed EOL
switch
Setting the End-of-Line (EOL) switch
Each controller has an EOL switch, which, when set
to ON, sets the controller as a terminating device on
the bus. See Figure for the EOL switch location. The
default EOL switch position is OFF.
Figure 11: End-of-Line switch positions
To set the EOL switch on a field controller, complete
the following steps:
1. Determine the physical location of the
controller on the FC bus.
2. Determine if the controller must be set as a
terminating device on the bus.
FAC2513 Advanced Application Field Equipment Controller Installation Guide 17

Note: Refer to the MS/TP Communications Bus
Technical Bulletin (LIT-12011034) for detailed
information regarding EOL termination rules
and EOL switch settings on FC buses.
3. If the controller is a terminating device on
the FC bus, set the EOL switch to ON. If the
controller is not a terminating device on the
bus, set the EOL switch to OFF.
When a field controller is connected to power with
its EOL switch set to ON, the amber EOL LED on the
controller cover is lit.
Setting up a local display
The FAC2513 model does not have an integral
display, but you can connect the controller to a
DIS1710 Local Controller Display. For detailed
information about setting up and operating either
an integral user interface or a remotely connected
DIS1710 display, refer to the DIS1710 Local Controller
Display Technical Bulletin (LIT-12011270)
Input and Output validation
The FAC controllers ship with a default state that
can assist in validating the wiring of the input and
output terminals prior to download of an application
file. When the controller is powered on in this state,
the Fault LED will flash in a pattern of two quick
blinks and then a long pause (see LED Status and
States).
To make use of this feature, ensure the DIP switches
are set to the desired address and wire the input
and output terminals. Apply power to the FAC
controller and connect to the device with either a
MAP Gateway or MS-DIS1710-0 Local Display to view
the points in the controller. The FAC controller will
report an Operational status even though there is
no true application loaded. CCT will not be able to
commission or upload the device as a result until
a true application is downloaded. The application
name displayed will be the address of the controller
followed by the model of the controller and “Default
State”.
For example, a FAC controller whose DIP switches
are set to 8 would have the default state application
name of 8-FAC2513 Default State.
The default state creates I/O points for all
connections on the input and output terminals.
It assumes all Universal Inputs (UIs) are Nickel
temperature sensors. All Configurable Outputs
(COs) are treated as Binary Outputs (BOs) with an
initial value of 0. The default state also takes input
from a Network Sensor at address 199. If there is
no connected Network Sensor, the startup of this
default state will be delayed by 30 seconds as the
controller attempts to establish connection with the
sensor.
Commissioning Field Controllers
You commission controllers with the Controller
Configuration Tool (CCT) software.You can connect
the controller using NxE Passthru (with network
engines (NxEs) at release 9.0.2 or above), MAP
4.2+/BACnet Router (Mobile Access Portal (MAP)
Gateway at version 4.2 or above), or through
Bluetooth (using BTCVT). Refer to the Controller Tool
Help (LIT-12011147) for detailed information about
commissioning controllers.
Note:
• You can use the Bluetooth connection
to Transfer to Computer (Upload) and
commission the controller, but you cannot
use the Bluetooth connection to Transfer to
Device (Download).
• The MAP Gateway serves as a replacement
for the BTCVT, which is no longer available
for purchase, but continues to be supported.
Firmware Package File
The MS-FCP-0 equipment controller firmware
package files are required for CCT to configure
and commission the controllers. The firmware
package files also allow you to upgrade an existing
controller to the latest firmware release available
for that controller. Beginning at CCT Release 13, the
firmware package files are orderable separately;
they are not included with CCT. They are obtained
from the Metasys software licensing portal, and are
loaded and licensed on the computer/server that is
running CCT. For additional information about the
firmware package files, refer to the CCT Installation
Instructions (LIT-12011259).
FAC2513 Advanced Application Field Equipment Controller Installation Guide18

Troubleshooting Field Controllers
Observe the Status LEDs on the front of the
field controller and see the following table to
troubleshoot the controller. To troubleshoot a
local controller display, refer to the DIS1710 Local
Controller Display Technical Bulletin (LIT-12011270).
LED status and states
Table 8: Status LEDs and description of LED states
LED label LED color Normal LED state Description of LED states
POWER Green On Steady
Off Steady = No Supply Power or the controller’s polyswitch/resettable fuse is
open. Check Output wiring for short circuits and cycle power to controller.
On Steady = Power Connected
FAULT Red Off Steady
Off Steady = No Faults
On Steady = Device Fault; no application loaded; Main Code download required, if
controller is in Boot mode
Blink - 2 Hz = Download or Startup in progress, not ready for normal operation
SA BUS Green Blink - 2 Hz
Blink - 2 Hz = Data Transmission (normal communication)
Off Steady = No Data Transmission (N/A - auto baud not supported)
On Steady = Communication lost, waiting to join communication ring
FC BUS Green Blink - 2 Hz
Blink - 2 Hz = Data Transmission (normal communication)
Off Steady = No Data Transmission (auto baud in progress)
On Steady = Communication lost, waiting to join communication ring
EOL Amber
Off (Except on
terminating
devices)
On Steady = EOL switch in ON position
Off Steady = EOL switch in Off position
Repair information
If a controller fails to operate within its
specifications, replace the controller. For a
replacement controller, contact your Johnson
Controls representative.
FAC2513 Advanced Application Field Equipment Controller Installation Guide 19

Accessories
See the following table for controller accessories
ordering information.
Table 9: Accessories ordering information
Product Code Number Description
IOM Series Controllers Refer to the Metasys® System Field Equipment Controllers and Related Products Product Bulletin
(LIT-12011042) for a complete list of available IOM Series Modules.
Mobile Access Portal (MAP)
Gateway
Refer to the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the appropriate
product for your region.
Note: The MAP Gateway serves as a replacement for the BTCVT, which is no longer
available for purchase, but continues to be supported.
NS Series Sensors Refer to the NS Series Network Sensors Product Bulletin (LIT-12011574) for a complete list of
available NS Series Sensors.
TL-CCT-0 Metasys Controller Configuration Tool (CCT) Software
MS-FCP-0 Metasys Field Controller Firmware Package Files for CCT
MS-DIS1710-0 Local Controller Display
TP-2420 Transformer, 120 VAC Primary to 24 VAC secondary, 20 VA, Wall Plug
Y65T31-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount, 8 in. (20.32 cm)
Primary Leads and Secondary Screw Terminals, Class 2
Note: Additional Y6x-x Series transformers are also available. Refer to the Series Y63, Y64,
Y65, Y66, and Y69 Transformers Product Bulletin (LIT-125755) for more information.
AS-XFR050-0 Power transformer (Class 2, 24 VAC, 50 VA maximum output), no enclosure
AS-CBLTSTAT-0 Cable adapter for connecting to 8-pin TE-6700 Series sensors
AP-TBK4SA-0 Replacement SA Bus Terminal Blocks, 4-Position, Brown, Bulk Pack of 10
AP-TBK4FC-0 Replacement FC Bus Terminal Blocks, 4-Position, Blue, Bulk Pack of 10
AP-TBK3PW-0 Replacement Power Terminal Blocks, 3-Position, Gray, Bulk Pack of 10
FAC2513 Advanced Application Field Equipment Controller Installation Guide20
