Johnson Controls VFD67 Series User manual

24-10511-7
www.johnsoncontrols.com
2.
1 Operate the VFD67 drive from the keypad
Keypad mode is used to operate the drive completely from the keypad. This is the default setting of the VFD67 and this procedure is written as the drive would
be delivered from the factory.
STEP 1: (required) Ensure the control signals B2, B4, B5, and B6 are DISCONNECTED. (Drive modes will not change if these control signals are connected).
STEP 2: Wire the mains and motor, and power the drive (See Figure 1).
STEP 3: Use the MODE key in combination with the UP and DOWN keys on the keypad to set parameters 1 to 4 for the desired frequency limits
and ramp values. (See front cover of the VFD67 drive for parameter descriptions).
STEP 4: Set Pr 05 to PAd (default setting).
STEP 5: Set Pr 06 to motor rated current.
STEP 6: Press the MODE key button (2 times) on the keypad until is displayed.
STEP 7: Close or jumper terminal B2 to B4. (See Figure 2). Display will change from to
STEP 8: Press the green START key on the drive keypad to run the drive (The display will read and the motor will be at zero speed).
STEP 9: Press the UP key to increase the speed, press the DOWN key to decrease the speed. The STOP/RESET key is used to stop and reset the
drive.
2 Operate the VFD67 drive with a 0 to 10Vdc control signal
STEP 1: (required) Ensure the control signals B2, B4, B5, and B6 are DISCONNECTED. (Drive modes will not change if these control signals are connected).
STEP 2: Wire the mains and motor, and power the drive (See Figure 1).
STEP 3: Use the MODE key in combination with the UP and DOWN keys on the keypad to set parameters 1 to 4 for the desired frequency limits
and ramp values. (See front cover of the VFD67 drive for parameter descriptions).
STEP 4: Set Pr 05 to (this is the analog voltage mode).
STEP 5: Set Pr 06 to motor rated current.
STEP 6: Wire the control terminals (See Figure 3).
3 Operate the VFD67 drive with a 4-20mA control signal
STEP 1: (required) Ensure the control signals B2, B4, B5, and B6 are DISCONNECTED. (Drive modes will not change if these control signals are connected).
STEP 2: Wire the mains and motor, and power the drive (See Figure 1).
STEP 3: Use the MODE key in combination with the UP and DOWN keys on the keypad to set parameters 1 to 4 for the desired frequency limits
and ramp values. (See front cover of the VFD67 drive for parameter descriptions).
STEP 4: Set Pr 05 to (this is the analog current mode).
STEP 5: Set Pr 06 to motor rated current.
STEP 6: Wire the control terminals (See Figure 4).
VFD67 Quick Start Commissioning:
M
M
M
M

24-10511-7
www.johnsoncontrols.com
Figure 1 Power terminal connections
Figure 2 Keypad operation Figure 3 0 to 10Vdc operation
Figure 4 4 to 20mA operation
Optional ground
connection
Supply
ground
Optional
EMC filter
Optional
line reactor
Fuses
Mains supply
L3/N* U V WL1 L2**
+
PE PE***
_
Internal
EMC filter
Start/
Reset
Braking
resistor
Optional
Thermal
protection
device
Stop
*
* Not applicable on size A
** On size A this is L2/N
*** The other PE terminal can
be used for connecting cable
shields to ground if required
T1
T2T3T4
B1
B2B3B4B5B6B7
+24Vdc output (100mA) Drive Enable/Reset
T = Top row
B = Bottom row
T1
T2T3T4
B1
B2B3B4B5B6B7
+24Vdc output (100mA)
T = Top row
B = Bottom row
Remote speed
ref input
Optional external
24V power supply
Open = Stop
Closed = Run
0 to 10Vdc analog input Common
T1
T2T3
T4
B1
B2B3
B4
B5B6
B7
+24Vdc output (100mA)
T = Top row
B = Bottom row
Remote speed
ref input
Open = Stop
Closed = Run
Common
4 to 20mA analog input
Optional external
24V power supply
