Johnson Controls XA Series User manual

R-410A
XA SERIES
6-1/2 - 12-1/2 Ton
60 Hertz
267234-BIM-C-1208
TABLE OF CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preceding Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ductwork. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Condensate Drain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power And Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . 15
Optional Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Economizer And Power Exhaust Set Point Adjustments . 28
Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Air Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Checking Air Quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Cooling Sequence Of Operation. . . . . . . . . . . . . . . . . . . . 41
No Outdoor Air Options . . . . . . . . . . . . . . . . . . . . . . . . . 41
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . 42
Heating Sequence of Operation . . . . . . . . . . . . . . . . . . . . 43
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . 43
Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Charging The Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Unit Control Board Option Setup. . . . . . . . . . . . . . . . . . . . . . 46
Option Byte Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Heat Delay Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
LIST OF TABLES
1 XA-06 thru -12 Unit Limitations . . . . . . . . . . . . . . . . . . . . . 7
2 Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 XA-06 thru -12 Unit Accessory Weights . . . . . . . . . . . . . . 9
4 XA-06 thru -12 Unit Physical Dimensions . . . . . . . . . . . . 10
5 XA-06 thru -12 Unit Clearances . . . . . . . . . . . . . . . . . . . 10
6 Side Duct Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9 Electric Heat Minimum Supply Air. . . . . . . . . . . . . . . . . . 27
10 Supply Air Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
11 Altitude/Temperature Correction Factors . . . . . . . . . . . . 31
12 Airflow Performance - Side Duct Application . . . . . . . . . 33
13 Airflow Performance - Bottom Duct Application . . . . . . . 35
14 RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
15 Indoor Blower Specifications. . . . . . . . . . . . . . . . . . . . . . 37
16 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . 37
17 Motor Sheave Datum Diameters . . . . . . . . . . . . . . . . . . 39
18 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . 40
19 Electric Heat Limit Setting 50” Cabinet. . . . . . . . . . . . . . 44
20 Electric Heat Limit Setting 42” Cabinet. . . . . . . . . . . . . . 44
21 Electric Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . 44
22 Unit Control Board Flash Codes . . . . . . . . . . . . . . . . . . . 45
23 Heat Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
LIST OF FIGURES
1 Unit Shipping Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Condenser Covering . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Compressor Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 XA Component Location . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
6 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8 XA-03 thru -10 Physical Dimensions . . . . . . . . . . . . . . . . 9
9 XA-12 Physical Dimensions. . . . . . . . . . . . . . . . . . . . . . . 9
10 XA-06 thru -12 Unit Bottom Duct Openings . . . . . . . . . . 10
11 XA-06 thru -12 Unit Electrical Entry . . . . . . . . . . . . . . . . 11
12 XA-06 thru -10 Unit Side Duct Openings . . . . . . . . . . . . 11
13 XA-12 Unit Side Duct Openings. . . . . . . . . . . . . . . . . . . 12
14 XA-06 thru -12 Unit Left Duct Opening . . . . . . . . . . . . . 12
15 XA-06 thru -12 Roof Curb . . . . . . . . . . . . . . . . . . . . . . . 13
16 XA-06 thru -12 Transition Roof Curb . . . . . . . . . . . . . . . 13
17 Side Panels With Hole Plugs . . . . . . . . . . . . . . . . . . . . . 14
18 Return Downflow Plenum With Panel . . . . . . . . . . . . . . 14
19 Discharge Panel In Place. . . . . . . . . . . . . . . . . . . . . . . . 14
20 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
21 Field Wiring Disconnect - Cooling Unit With/
Without Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
22 Typical Electronic Thermostat Field Wiring . . . . . . . . . . 17
23 Typical Field Wiring 24 Volt Thermostat . . . . . . . . . . . . 17
24 Enthalpy Set Point Chart . . . . . . . . . . . . . . . . . . . . . . . . 29
25 Honeywell Economizer Control W7212 . . . . . . . . . . . . . 29
26 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
27 Altitude/Temperature Correction Factors. . . . . . . . . . . . 31
28 Dry Coil Delta P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
29 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

267234-BIM-C-1208
2Johnson Controls Unitary Products
General
UP XA heat pumps are single package, reverse cycle air
conditioners designed for outdoor installation on a rooftop or
slab and for non-residential use. These units can be equipped
with factory or field installed electric heaters for heating
applications.
These units are completely assembled on rigid, permanently
attached base rails. All piping, refrigerant charge, and electrical
wiring is factory installed and tested. The units require electric
power and duct connections. The electric heaters have nickel-
chrome elements and utilize single-point power connection.
Safety Considerations
This is a safety alert symbol. When you see this symbol on
labels or in manuals, be alert to the potential for personal injury.
Understand and pay particular attention the signal words
DANGER, WARNING or CAUTION.
DANGER indicates an imminently hazardous situation, which,
if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which,
if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if
not avoided may result in minor or moderate injury.It is also
used to alert against unsafe practices and hazards involving
only property damage.
Due to system pressure, moving parts, and electrical
components, installation and servicing of air conditioning
equipment can be hazardous. Only qualified, trained service
personnel should install, repair, or service this equipment.
Untrained personnel can perform basic maintenance functions
of cleaning coils and filters and replacing filters.
Observe all precautions in the literature, labels, and tags
accompanying the equipment whenever working on air
conditioning equipment. Be sure to follow all other applicable
safety precautions and codes including National Electric Code,
ANSI/NFPA No. 70 - latest edition U.S. A. and Canadian
Electric Code, CSA C22.1 in Canada.
Wear safety glasses and work gloves. Use quenching cloth and
have a fire extinguisher available during brazing operations.
Inspection
As soon as a unit is received, it should be inspected for possible
damage during transit. If damage is evident, the extent of the
damage should be noted on the carrier’s freight bill. A separate
request for inspection by the carrier’s agent should be made in
writing.
Improper installation may create a condition where the
operation of the product could cause personal injury or
property damage. Improper installation, adjustment,
alteration, service or maintenance can cause injury or
property damage. Refer to this manual for assistance or
for additional information, consult a qualified contractor,
installer or service agency.
This product must be installed in strict compliance with
the installation instructions and any applicable local,
state and national codes including, but not limited to
building, electrical, and mechanical codes.
Before performing service or maintenance operations on
unit, turn off main power switch to unit. Electrical shock
could cause personal injury. Improper installation,
adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to this manual.
For assistance or additional information consult a
qualified installer or service agency.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system. Gage sets, hoses, refrigerant
containers and recovery systems must be designed to
handle R-410A. If you are unsure, consult the equipment
manufacturer. Failure to useR-410A compatible servicing
equipment may result in property damage or injury.

267234-BIM-C-1208
Johnson Controls Unitary Products 3
Reference
Additional information is available in the following reference
forms:
• Technical Guide - ZU/XA-06 thru -12, 246826
• General Installation - XA-06 thru -12, 267234
• Pre-start & Post-start Check List
• Economizer Accessory -
Downflow Factory Installed
Downflow Field Installed
Horizontal Field Installed
• Motorized Outdoor Air Damper
• Manual Outdoor Air Damper (0-100%)
• Manual Outdoor Air Damper (0-35%)
• Electric Heater Accessory 50” cabinet
• Electric Heater Accessory 42” cabinet
Renewal Parts
Contact your local UP parts distribution center for authorized
replacement parts.
Approvals
Design certified by CSA as follows:
1. For use as a cooling only unit, cooling unit with
supplemental electric heat or a forced air furnace.
2. For outdoor installation only.
3. For installation on combustible material and may be
installed directly on combustible flooring or, in the U.S., on
wood flooring or Class A, Class B or Class C roof covering
materials.
This product must be installed in strict compliance with
the enclosed installation instructions and any applicable
local, state, and national codes including, but not limited
to, building, electrical, and mechanical codes.
Improper installation may create a condition where the
operation of the product could cause personal injury or
property damage.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system.

267234-BIM-C-1208
4Johnson Controls Unitary Products
Nomenclature
X A -10 C00 A T A AA 3 0 1 2 4 A
Product Category
X = HP, Single Pkg., R-410A
A = Std. Motor
Airflow
B = Std. Motor/Econo./Barometric Relief (Downflow
Only)
C = Std. Motor/Econo./Power Exhaust (Downflow Only)
D = Std. Motor/Motorized Damper (Downflow Only)
E = Std. Motor/Horizontal Economizer (No Baro.)
F = Std. Motor/Slab Econo./Power Exhaust
(Downflow Only)
G = Std. Motor/Slab Econo./Barometric Relief
(Downflow Only)
N = Hi Static
P = Hi Static/Econo./Barometric Relief
(Downflow Only)
Q = Hi Static/Econo./Power Exhaust
(Downflow Only)
R = Hi Static/Motorized Damper (Downflow Only)
S = Hi Static/Horizontal Economizer (No Baro.)
T = Hi Static/Slab Econo./Power Exhaust
(Downflow Only)
U = Hi Static/Slab Econo./Barometric Relief
(Downflow only)
3 = Third Generation
Product Generation
4 = Fourth Generation
C00 = Cooling Only. No heat installed
Heat Type and Nominal Heat Capacity
E09 = 9 KW
E18 = 18 KW
E24 = 24 KW
E36 = 36 KW
E54 = 54 KW
Electric Heat Options
-06 = 6.5 Ton
Nominal Cooling Capacity
-07 = 7.5 Ton
-08 = 8.5 Ton
-10 = 10.0 Ton
-12 = 12.5 Ton
Product Identifier
A = 11.0 EER HP
Voltage
T = 208/230-3-60
W = 460-3-60
X = 575-3-60
Product Style
A = Style A
B = Style B
A = No Options Installed
Installation Options
B=Option1
C = Option 2
D = Options 1 & 2
E=Option3
F = Option 4
G = Options 1 & 3
H = Options 1 & 4
J = Options 1, 2 & 3
K = Options 1, 2, & 4
L = Options 1,3 & 4
M = Options 1, 2, 3, & 4
N = Options 2 & 3
P = Options 2 & 4
Q = Options 2, 3, & 4
R = Options 3 & 4
S=Option5
T = Options 1 & 5
U = Options 1, 3, & 5
V = Options 1, 4, & 5
W = Options 1, 3, 4, & 5
X = Options 3 & 5
Y = Options 4 & 5
Z = Options 3, 4 & 5
1 = Disconnect
2 = Non-Pwr'd Conv. Outlet
3 = Smoke Detector S.A.
4 = Smoke Detector R.A.
5=Pwr'dConv.Outlet
Options
SS Drain Pan
Configuration Options (not required for all units)
These four digits will not be assigned until a quote is requested, or an order placed.
CPC Controller, DFS, APS
Johnson Controller, DFS, APS
Honeywell Controller, DFS, APS
Novar Controller, DFS, APS
Simplicity IntelliComfort Controller
Simplicity IntelliComfort Controller w/ModLinc
2" Pleated filters
BAS Ready Economizer (2-10 V.D.C. Actuator without a Controller)
Shipping Bag
Any Combination of Additional Options that Don’t Have an Option Code Pre-assigned
AA = None
AB = Phase Monitor
AC = Coil Guard
AD = Dirty Filter Switch
AE = Phase Monitor & Coil Guard
AF = Phase Monitor & Dirty Filter Switch
AG = Coil Guard & Dirty Filter Switch
AH = Phase Monitor, Coil Guard & Dirty Filter Switch
Additional Options
TA = Technicoat Condenser Coil
TJ = Technicoat Evaporator Coil
TS = Technicoat Evaporator & Condenser Coils
6.5-12.5 Ton Model Number Nomenclature
ZZ = If desired option combination is not listed above, ZZ will be assigned and configuration options will be
located in digits 15-18.

267234-BIM-C-1208
Johnson Controls Unitary Products 5
Installation
Installation Safety Information
Read these instructions before continuing this appliance
installation. This is an outdoor combination heating and cooling
unit. The installer must assure that these instructions are made
available to the consumer and with instructions to retain them
for future reference.
This equipment is not to be used for temporary heating of
buildings or structures under construction.
Preceding Installation
1. Remove the two screws holding the brackets in the front,
rear and compressor side fork-lift slots.
Figure 1: Unit Shipping Bracket
2. Turn each bracket toward the ground and the protective
plywood covering will drop to the ground.
3. Remove the condenser coil external protective covering
prior to operation.
4. Remove the toolless doorknobs and instruction packet
prior to installation.
Figure 2: Condenser Covering
Figure 3: Compressor Section
Limitations
These units must be installed in accordance with the following:
In U.S.A.:
1. National Electrical Code, ANSI/NFPA No. 70 - Latest
Edition
2. Local building codes, and
3. Local electric utility requirements
In Canada:
1. Canadian Electrical Code, CSA C22.1
2. Installation Codes, CSA - B149.1.
3. Local plumbing and waste water codes, and
4. Other applicable local codes.
Refer to unit application data found in this document.
If components are to be added to a unit to meet local codes,
they are to be installed at the dealer’s and/or customer’s
expense.
Size of unit for proposed installation should be based on heat
loss/heat gain calculation made according to the methods of Air
Conditioning Contractors of America (ACCA).
This furnace is not to be used for temporary heating of buildings
or structures under construction.
FIRE OR EXPLOSION HAZARD
Failure to follow the safety warning exactly could result
in serious injury, death or property damage.
Never test for gas leaks with an open flame. use a
commercially available soap solution made specifically
for the detection of leaks to check all connections. A fire
or explosion may result causing property damage,
personal injury or loss of life.
Bracket
Screws Turn down
Condenser
Coil External
Protective
Covering
Barometric
Relief Hood
in Shipping
Location
(if Included)
The Simplicity® control board used in this product will
effectively operate the cooling system down to 0°F when
this product is applied in a comfort cooling application
for people. An economizer is typically included in this
type of application. When applying this product for
process cooling applications (computer rooms,
switchgear, etc.), please reference applications bulletin
AE-011-07 or call the applications department for
Unitary Products @ 1-877-UPG-SERV for guidance.
Additional accessories may be needed for stable
operation at temperatures below 30° F.
Toolless
Doorknobs
Installation
Instruction
Packet

267234-BIM-C-1208
6Johnson Controls Unitary Products
Figure 4: XA Component Location
Compressor #1 Access
(High-Eff Compressor)
Toolless
Door Latch
Side entry power
and control wiring
knockouts
Slide-out drain pain
with steel 3/4” NPT,
Female Connection
Belt-drive
blower
motor
Condenser
section
Filter drier (solid core)
Filter access
(2” throw-away)
Disconnect location
(optional disconnect switch)
Compressor #2
Access (High-Eff
Compressor)
Simplicity®Control
board w/screw connec-
tors for T-stat wiring and
network connection
Roof curbs in eight- and
fourteen-inch heights. Roof
curbs for transitioning from
Sunline™ footprint to the
XA series footprint are also
available (field installed
accessory)
Base Rails w/ Fork-
lift Slots (3 Sides)
& Lifting Holes
Terminal block
for hi-voltage
connection
Dual stage cool-
ing for maximum
comfort (7-1/2 -
12-1/2 Only)
Second Model
Nameplate Inside
Control Door
Slide-out motor and
blower assembly for
easy adjustment and
service.

267234-BIM-C-1208
Johnson Controls Unitary Products 7
Location
Use the following guidelines to select a suitable location for
these units:
1. Unit is designed for outdoor installation only.
2. Condenser coils must have an unlimited supply of air.
Where a choice of location is possible, position the unit on
either north or east side of building.
3. Suitable for mounting on roof curb.
4. For ground level installation, use a level concrete slab with
a minimum thickness of 4 inches. The length and width
should be at least 6 inches greater than the unit base rails.
Do not tie slab to the building foundation.
5. Roof structures must be able to support the weight of the
unit and its options/accessories. Unit must be installed on a
solid, level roof curb or appropriate angle iron frame.
6. Maintain level tolerance to 1/2” across the entire width and
length of unit.
Clearances
All units require particular clearances for proper operation and
service. Refer to Table 5 for clearances required for
construction, servicing, and proper unit operation.
Rigging And Handling
Exercise care when moving the unit. Do not remove any
packaging until the unit is near the place of installation. Rig the
unit by attaching chain or cable slings to the lifting holes
provided in the base rails. Spreader bars, whose length
exceeds the largest dimension across the unit, MUST be used
across the top of the unit.
Units may be moved or lifted with a forklift. Slotted openings in
the base rails are provided for this purpose.
LENGTH OF FORKS MUST BE A MINIMUM OF 60 INCHES.
Table 1: XA-06 thru -12 Unit Limitations
Size
(Tons) Model Unit Voltage Unit Limitations
Applied Voltage Outdoor DB Temp
Min Max Max (°F)
-06
(6.5) XA 208/230-3-60 187 252 125
460-3-60 432 504 125
575-3-60 540 630 125
-07
(7.5) XA 208/230-3-60 187 252 125
460-3-60 432 504 125
575-3-60 540 630 125
-08
(8.5) XA 208/230-3-60 187 252 125
460-3-60 432 504 125
575-3-60 540 630 125
-10
(10) XA 208/230-3-60 187 252 125
460-3-60 432 504 125
575-3-60 540 630 125
-12
(12.5) XA 208/230-3-60 187 252 125
460-3-60 432 504 125
575-3-60 540 630 125
Do not permit overhanging structures or shrubs to
obstruct condenser air discharge outlet, combustion air
inlet or vent outlets.
If a unit is to be installed on a roof curb other than a UP
roof curb, gasketing must be applied to all surfaces that
come in contact with the unit underside.
Before lifting, make sure the unit weight is distributed
equally on the rigging cables so it will lift evenly.
All panels must be secured in place when the unit is
lifted.
The condenser coils should be protected from rigging
cable damage with plywood or other suitable material.

267234-BIM-C-1208
8Johnson Controls Unitary Products
Figure 5: Unit 4 Point Load Weight Figure 6: Unit 6 Point Load Weight
Figure 7: Center of Gravity
D
A
CB
LEFT
FRONT
D
A
C
B
E
F
LEFT
FRONT
XY
LEFT FRONT
Table 2: Weights and Dimensions
Size
(Tons) Model Weight (lbs.) Center of Gravity 4 Point Load Location (lbs.) 6 Point Load Location (lbs.)
ShippingOperatingX Y ABCDABCDEF
-06
(6.5) XA 925 920 38 23 206 153 240 322 144 117 97 152 184 225
-07
(7.5) XA 925 920 38 23 206 153 240 322 144 117 97 152 184 225
-08
(8.5) XA 1140 1135 38 25.5 281 209 275 369 197 160 133 175 211 259
-10
(10) XA 1140 1135 38 25.5 281 209 275 369 197 160 133 175 211 259
-12
(12.5) XA 1405 1400 51 25.5 258 347 456 339 164 198 243 319 260 216

267234-BIM-C-1208
Johnson Controls Unitary Products 9
Figure 8: XA-03 thru -10 Physical Dimensions
Figure 9: XA-12 Physical Dimensions
Table 3: XA-06 thru -12 Unit Accessory Weights
Unit Accessory Weight (lbs.)
Shipping Operating
Economizer 90 85
Power Exhaust 155 150
Electric Heat180 80
1. Weight given is for the maximum heater size available (54KW).
See detail A for drain location
See detail A for drain location

267234-BIM-C-1208
10 Johnson Controls Unitary Products
Detail A
Figure 10: XA-06 thru -12 Unit Bottom Duct Openings
Table 4: XA-06 thru -12 Unit Physical Dimensions
Unit Model Number Dimension (in.)
ABCDEF
XA-06 42 89 22 1/8 18 3/16 15 3/16 6 3/16
XA-07 42 89 22 1/8 18 3/16 15 3/16 6 3/16
XA-08 50 3/4 89 30 3/16 24 3/16 17 3/16 6 3/16
XA-10 50 3/4 89 30 3/16 24 3/16 17 3/16 6 3/16
XA-12 50 3/4 119 1/2 30 3/16 24 3/16 17 3/16 6 3/16
5-3/8
Table 5: XA-06 thru -12 Unit Clearances
Direction Distance (in.) Direction Distance (in.)
Top1
1. Units must be installed outdoors. Over hanging structure or shrubs should not obscure condenser air discharge outlet.
72 Right 12
Front 36 Left 36
Rear 36 Bottom2
2. Units may be installed on combustable floors made from wood or class A, B or C roof covering materials.
0

267234-BIM-C-1208
Johnson Controls Unitary Products 11
Figure 11: XA-06 thru -12 Unit Electrical Entry
Figure 12: XA-06 thru -10 Unit Side Duct Openings
Disconnect Swith Cover
Power Entry Ø 2-1/2
Control Entry Ø 7/8
Power Entry Ø 2-1/2
Convenience Outlet Cover
Convenience Outlet
Power Entry Ø 7/8
FRONT
Dot Plugs
5-5/32
31-11/16
2-31/32
18-1/4
Return
Air
Supply
Air
A
B
C
D

267234-BIM-C-1208
12 Johnson Controls Unitary Products
Figure 13: XA-12 Unit Side Duct Openings
Figure 14: XA-06 thru -12 Unit Left Duct Opening
Dot Plugs
2-7/8
5-5/32
D
C 31-5/8
18-1/4
B
A
Table 6: Side Duct Dimensions
Unit Model Number Dimension (in.)
ABCD
XA-06 27 3/4 12 1/16 27 1/2 16
XA-07 27 3/4 12 1/16 27 1/2 16
XA-08 28 1/4 18 1/16 28 1/4 18 1/4
XA-10 28 1/4 18 1/16 28 1/4 18 1/4
XA-12 28 1/4 18 1/16 28 1/4 18 1/4
4-5/16
30-3/8

267234-BIM-C-1208
Johnson Controls Unitary Products 13
Figure 15: XA-06 thru -12 Roof Curb
Figure 16: XA-06 thru -12 Transition Roof Curb
Ductwork
Ductwork should be designed and sized according to the
methods in Manual D of the Air Conditioning Contractors of
America (ACCA) or as recommended by any other recognized
authority such as ASHRAE or SMACNA.
A closed return duct system should be used. This will not
preclude use of economizers or outdoor fresh air intake. The
supply and return air duct connections at the unit should be
made with flexible joints to minimize noise.
The supply and return air duct systems should be designed for
the CFM and static pressure requirements of the job. They
should NOT be sized to match the dimensions of the duct
connections on the unit.
Refer to Figure 10 for bottom air duct openings. Refer to
Figures 12, 13 and Table 6 for side air duct openings.
8 or 14
50-1/2
30
20
20
80-5/8
6
2 TYP.
INSULATED DECK UNDER
COMPRESSOR SECTION
INSULATED DECK UNDER
CONDENSER SECTION
FRONT
RIGHT
SUPPLY
RETURN
76-5/8
94
50-1/2 30-1/2
64-1/4
59-1/4
10
23 4
26 80-5/8
2TYP
FRONT RIGHT
SUPPLY
RETURN

267234-BIM-C-1208
14 Johnson Controls Unitary Products
Duct Covers
Units are shipped with the side duct openings covered and a
covering over the bottom of the unit. For bottom duct
application, no duct cover changes are necessary. For side
duct application, remove the side duct covers and install over
the bottom duct openings. The panels removed from the side
duct connections are designed to be reused by securing each
panel to its respective downflow opening. But keep in mind that
the supply panel is installed with the painted surface UP, facing
the heat exchanger, while the return panel is installed with the
painted surface DOWN, facing the downflow duct opening. The
supply panel is secured with the bracket (already in place from
the factory) and two screws. It’s a snug fit for the panel when
sliding it between the heat exchanger and unit bottom, but there
is room. The return panel is secured with four screws.
Figure 17: Side Panels With Hole Plugs
NOTE: Orientation. Panel is “insulation” side up.
Figure 18: Return Downflow Plenum With Panel
Figure 19: Discharge Panel In Place
Condensate Drain
The side condensate drain is reversible and maybe re-oriented to
the rear of the cabinet to facilitate condensate piping. A
condensate drain connection is available through the base pan
for piping inside the roof curb. Trap the connection per Figure 20.
The trap and drain lines should be protected from freezing.
Plumbing must conform to local codes. Use a sealing compound
on male pipe threads. Install condensate drain line from the 3/4
inch NPT female connection on the unit to an open drain.
Figure 20: Condensate Drain
Compressors
The scroll compressor used in this product is specifically
designed to operate with R-410A Refrigerant and cannot be
interchanged.
The compressor also uses a polyolester (POE oil), Mobil 3MA
POE. This oil is extremely hygroscopic,meaning it absorbs water
readily. POE oil can absorb 15 times as much water as other oils
When fastening ductwork to side duct flanges on unit,
insert screws through duct flanges only. DO NOT insert
screws through casing. Outdoor ductwork must be
insulated and water-proofed.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system.
OPTIONAL COIL
GUARD
3" Minimum

267234-BIM-C-1208
Johnson Controls Unitary Products 15
designed for HCFC and CFC refrigerants. Take all necessary
precautions to avoid exposure of the oil to the atmosphere.
POE (polyolester) compressor lubricants are known to cause
long term damage to some synthetic roofing materials.
Procedures which risk oil leakage include, but are not limited to,
compressor replacement, repairing refrigerant leaks, replacing
refrigerant components such as filter drier, pressure switch,
metering device or coil.
Units are shipped with compressor mountings which are
factory-adjusted and ready for operation.
Filters
Two-inch filters are supplied with each unit. One-inch filters may
be used with no modification to the filter racks. Filters must
always be installed ahead of evaporator coil and must be kept
clean or replaced with same size and type. Dirty filters reduce
the capacity of the unit and result in frosted coils or safety
shutdown. Refer to physical data tables, for the number and
size of filters needed for the unit. The unit should not be
operated without filters properly installed.
Power And Control Wiring
Field wiring to the unit, fuses, and disconnects must conform to
provisions of National Electrical Code (NEC), ANSI/NFPA No.
70 – Latest Edition (in U.S.A.), current Canadian Electrical
Code C221, and/or local ordinances. The unit must be
electrically grounded in accordance with NEC and CEC as
specified above and/or local codes.
Voltage tolerances which must be maintained at the
compressor terminals during starting and running conditions are
indicated on the unit Rating Plate and Table 1.
The internal wiring harnesses furnished with this unit are an
integral part of the design certified unit. Field alteration to
comply with electrical codes should not be required. If any of
the wire supplied with the unit must be replaced, replacement
wire must be of the type shown on the wiring diagram and the
same minimum gauge as the replaced wire.
A disconnect must be utilized for these units. Factory installed
disconnects are available. If installing a disconnect (field
supplied or UP supplied accessory), refer to Figure 4 for the
recommended mounting location.
NOTE: Since not all local codes allow the mounting of a
disconnect on the unit, please confirm compliance with
local code before mounting a disconnect on the unit.
Electrical line must be sized properly to carry the load. USE
COPPER CONDUCTORS ONLY. Each unit must be wired with
a separate branch circuit fed directly from the meter panel and
properly fused.
Refer to Figures 21, 22 and 23 for typical field wiring and to the
appropriate unit wiring diagram mounted inside control doors
for control circuit and power wiring information.
Do not leave the system open to the atmosphere. Unit
damage could occur due to moisture being absorbed by
the POE oil in the system. This type of oil is highly
susceptible to moisture absorption
Exposure, even if immediately cleaned up, may cause
embrittlement (leading to cracking) to occur in one year
or more. When performing any service that may risk
exposure of compressor oil to the roof, take precautions
to protect roofing.
Do not loosen compressor mounting bolts.
Make sure that panel latches are properly positioned on
the unit to maintain an airtight seal.
208/230-3-60 and 380/415-3-50 units control
transformers are factory wired for 230v and 415v power
supply respectively. Change tap on transformer for 208-
3-60 or 380-3-50 operation. See unit wiring diagram.
Avoid damage to internal components if drilling holes for
disconnect mounting.
When connecting electrical power and control wiring to
the unit, water-proof connectors must be used so that
water or moisture cannot be drawn into the unit during
normal operation. The above water-proofing conditions
will also apply when installing a field supplied disconnect
switch.

267234-BIM-C-1208
16 Johnson Controls Unitary Products
Power Wiring Detail
Units are factory wired for the voltage shown on the unit
nameplate. Refer to Electrical Data Table 8 to size power
wiring, fuses, and disconnect switch.
Power wiring is brought into the unit through the side of the unit
or the basepan inside the curb.
Figure 21: Field Wiring Disconnect - Cooling Unit With/Without Electric Heat
Thermostat Wiring
The thermostat should be located on an inside wall
approximately 56 inch above the floor where it will not be
subject to drafts, sun exposure or heat from electrical fixtures or
appliances. Follow the manufacturer's instructions enclosed
with thermostat for general installation procedure. Seven (7)
color-coded, insulated wires should be used to connect the
thermostat to the unit. Refer to Table 7 for control wire sizing
and maximum length.
THREE
PHASE
POWER
SUPPLY
FACTORY OR FIELD
SUPPLIED DISCONNECT
GROUND
LUG
TERMINAL BLOCK TB1
Table 7: Control Wire Sizes
Wire Size Maximum Length1
1. From the unit to the thermostat and back to the unit.
18 AWG 150 Feet

267234-BIM-C-1208
Johnson Controls Unitary Products 17
Figure 22: Typical Electronic Thermostat Field Wiring
Figure 23: Typical Field Wiring 24 Volt Thermostat
W2
RC
RH
Y1
Y2
W1
G
C
X1
X3
X4
A1
A2
T
T
W2
Y1
Y2
W1
G
C
OCC
X
R
2
TO REMOTE SENSOR
2ET04701324 IF USED
24 Volt
Transformer
THERMOSTAT1
TERMINALS UNIT TERMINALS
STRIP TB1
1Electronic programmable Thermostat 2ET0770010024 (includes subbase).
2Terminals A1 and A2 provide a relay output to close the outdoor economizer
dam
p
ers when the thermostat switches to the set-back
p
osition.
OCC
W1
W2
Y1
G
Y2
X
R
SD
C
REMOTE MIN POS
W1
W2
Y1
G
Y2
C
RH
RC
UNIT CONTROL
BOARD
T-STAT
208/230-3-60 and 380/415-3-50 units control
transformers are factory wired for 230v and 415v power
supply respectively. Change tap on transformer for 208-
3-60 or 380-3-50 operation. See unit wiring diagram.

267234-BIM-C-1208
18 Johnson Controls Unitary Products
Table 8: Electrical Data
XA-06 thru -12 Standard Motor - Without Powered Convenience Outlet
Size
(Tons) Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet Electric Heat Option MCA1
(Amps)
MCA1
w/Pwr
Exh
(Amps)
Max Fuse2/
Breaker3
Size
(Amps)
Max Fuse1/
Breaker3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
-06
(6.5)
208 14.1 95.0 22.0 1.5 6.2 5.5 0.0
None---40.946.450 60
E09 6.8 1 18.9 64.5 70.0 70 70
E18 13.5 2 37.5 87.8 93.3 90 100
E24 18.0 2 50.0 103.4 108.9 110 110
E36 25.5 2 70.8 129.4 134.9 150 150
230 14.1 95.0 22.0 1.5 6.2 5.5 0.0
None---40.946.450 60
E09 9.0 1 22.6 68.0 73.5 70 80
E18 18.0 2 45.2 95.1 100.6 100 110
E24 24.0 2 60.2 113.1 118.6 125 125
E36 34.0 2 85.3 143.2 148.7 150 150
460 6.4 45.0 10.0 0.8 3.1 2.2 0.0
None---19.121.325 25
E09 9.0 1 11.3 32.6 34.8 35 35
E18 18.0 2 22.6 46.2 48.4 50 50
E24 24.0 2 30.1 55.2 57.4 60 60
E36 34.0 2 42.7 70.2 72.4 80 80
575 5.4 38.0 8.5 0.6 2.4 1.8 0.0
None---15.817.620 20
E09 9.0 1 9.0 26.6 28.4 30 30
E18 18.0 2 18.1 37.4 39.2 40 40
E24 24.0 2 24.1 44.6 46.4 45 50
E36 34.0 2 34.1 56.6 58.4 60 60
-07
(7.5)
208 15.6 83.1 21.4 1.5 6.2 5.5 0.0
None---44.349.850 60
E09 6.8 1 18.9 67.9 73.4 70 80
E18 13.5 2 37.5 91.1 96.6 100 100
E24 18.0 2 50.0 106.8 112.3 110 125
E36 25.5 2 70.8 132.8 138.3 150 150
230 15.6 83.1 21.4 1.5 6.2 5.5 0.0
None---44.349.850 60
E09 9.0 1 22.6 71.4 76.9 80 80
E18 18.0 2 45.2 98.4 103.9 100 110
E24 24.0 2 60.2 116.5 122.0 125 125
E36 34.0 2 85.3 146.5 152.0 150 175
460 6.9 41.0 9.7 0.8 3.1 2.2 0.0
None---20.222.425 25
E09 9.0 1 11.3 33.8 36.0 35 40
E18 18.0 2 22.6 47.3 49.5 50 50
E24 24.0 2 30.1 56.3 58.5 60 60
E36 34.0 2 42.7 71.3 73.5 80 80
575 5.4 33.0 7.5 0.6 2.4 1.8 0.0
None---15.817.620 20
E09 9.0 1 9.0 26.6 28.4 30 30
E18 18.0 2 18.1 37.4 39.2 40 40
E24 24.0 2 24.1 44.6 46.4 45 50
E36 34.0 2 34.1 56.6 58.4 60 60
-08
(8.5)
208 16.7 120.0 26.0 1.5 8.2 5.5 0.0
None---48.854.360 70
E09 6.8 1 18.9 72.4 77.9 80 80
E18 13.5 2 37.5 95.6 101.1 100 110
E24 18.0 2 50.0 111.2 116.7 125 125
E36 25.5 2 70.8 137.3 142.8 150 150
230 16.7 120.0 26.0 1.5 8.2 5.5 0.0
None---48.854.360 70
E09 9.0 1 22.6 75.8 81.3 80 90
E18 18.0 2 45.2 102.9 108.4 110 110
E24 24.0 2 60.2 120.9 126.4 125 150
E36 34.0 2 85.3 151.0 156.5 175 175
460 8.7 60.0 13.5 0.8 4.1 2.2 0.0
None---25.327.530 35
E09 9.0 1 11.3 38.8 41.0 40 45
E18 18.0 2 22.6 52.3 54.5 60 60
E24 24.0 2 30.1 61.4 63.6 70 70
E36 34.0 2 42.7 76.4 78.6 80 80
575 6.7 42.0 10.5 0.6 3.6 1.8 0.0
None---19.921.725 25
E09 9.0 1 9.0 30.7 32.5 35 35
E18 18.0 2 18.1 41.5 43.3 45 45
E24 24.0 2 24.1 48.7 50.5 50 60
E36 34.0 2 34.1 60.8 62.6 70 70

267234-BIM-C-1208
Johnson Controls Unitary Products 19
-10
(10)
208 17.9 120.0 28.0 1.5 8.2 5.5 0.0
None---51.557.060 70
E18 13.5 2 37.5 98.3 103.8 100 110
E24 18.0 2 50.0 113.9 119.4 125 125
E36 25.5 2 70.8 140.0 145.5 150 150
E54 40.6 2 112.7 151.1 158.0 175 175
230 17.9 120.0 28.0 1.5 8.2 5.5 0.0
None---51.557.060 70
E18 18.0 2 45.2 105.6 111.1 110 125
E24 24.0 2 60.2 123.6 129.1 125 150
E36 34.0 2 85.3 153.7 159.2 175 175
E54 54.0 2 135.6 153.7 159.2 175 175
460 9.6 70.0 15.0 0.8 4.1 2.2 0.0
None---27.329.535 35
E18 18.0 2 22.6 54.4 56.6 60 60
E24 24.0 2 30.1 63.4 65.6 70 70
E36 34.0 2 42.7 78.4 80.6 80 90
E54 54.0 2 67.8 78.4 80.6 80 90
575 7.4 53.0 11.5 0.6 3.6 1.8 0.0
None---21.523.325 30
E18 18.0 2 18.1 43.1 44.9 45 45
E24 24.0 2 24.1 50.3 52.1 60 60
E36 34.0 2 34.1 62.3 64.1 70 70
E54 54.0 2 54.2 62.3 64.1 70 70
-12
(12.5)
208 23.1 160.0 36.0 1.5 10.9 5.5 0.0
None---68.974.490 90
E18 13.5 2 37.5 115.7 121.2 125 125
E24 18.0 2 50.0 131.3 136.8 150 150
E36 25.5 2 70.8 157.4 162.9 175 175
E54 40.6 2 112.7 157.4 162.9 175 175
230 23.1 160.0 36.0 1.5 10.9 5.5 0.0
None---68.974.490 90
E18 18.0 2 45.2 123.0 128.5 125 150
E24 24.0 2 60.2 141.0 146.5 150 150
E36 34.0 2 85.3 171.1 176.6 175 200
E54 54.0 2 135.6 171.1 176.6 175 200
460 12.2 87.0 19.0 0.8 5.3 2.2 0.0
None---36.038.245 50
E18 18.0 2 22.6 63.0 65.2 70 70
E24 24.0 2 30.1 72.0 74.2 80 80
E36 34.0 2 42.7 87.1 89.3 90 90
E54 54.0 2 67.8 87.1 89.3 90 90
575 8.7 62.0 13.5 0.6 4.1 1.8 0.0
None---26.127.930 35
E18 18.0 2 18.1 47.7 49.5 50 50
E24 24.0 2 24.1 54.9 56.7 60 60
E36 34.0 2 34.1 67.0 68.8 70 70
E54 54.0 2 54.2 67.0 68.8 70 70
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
XA-06 thru -12 Standard Motor - Without Powered Convenience Outlet (Continued)
Size
(Tons) Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet Electric Heat Option MCA1
(Amps)
MCA1
w/Pwr
Exh
(Amps)
Max Fuse2/
Breaker3
Size
(Amps)
Max Fuse1/
Breaker3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps

267234-BIM-C-1208
20 Johnson Controls Unitary Products
XA-06 thru -12 Hi Static Motor - Without Powered Convenience Outlet
Size
(Tons) Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet Electric Heat Option MCA1
(Amps)
MCA1
w/Pwr
Exh
(Amps)
Max Fuse2/
Breaker3
Size
(Amps)
Max Fuse2/
Breaker3
Size w/ Pwr
Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
-06
(6.5)
208 14.1 95.0 22.0 1.5 8.2 5.5 0.0
None - - - 42.9 48.4 50 60
E09 6.8 1 18.9 66.5 72.0 70 80
E18 13.5 2 37.5 89.8 95.3 90 100
E24 18.0 2 50.0 105.4 110.9 110 125
E36 25.5 2 70.8 131.4 136.9 150 150
230 14.1 95.0 22.0 1.5 8.2 5.5 0.0
None - - - 42.9 48.4 50 60
E09 9.0 1 22.6 70.0 75.5 70 80
E18 18.0 2 45.2 97.1 102.6 100 110
E24 24.0 2 60.2 115.1 120.6 125 125
E36 34.0 2 85.3 145.2 150.7 150 175
460 6.4 45.0 10.0 0.8 4.1 2.2 0.0
None - - - 20.1 22.3 25 25
E09 9.0 1 11.3 33.6 35.8 35 40
E18 18.0 2 22.6 47.2 49.4 50 50
E24 24.0 2 30.1 56.2 58.4 60 60
E36 34.0 2 42.7 71.2 73.4 80 80
575 5.4 38.0 8.5 0.6 3.6 1.8 0.0
None - - - 17.0 18.8 20 20
E09 9.0 1 9.0 27.8 29.6 30 30
E18 18.0 2 18.1 38.6 40.4 40 45
E24 24.0 2 24.1 45.8 47.6 50 50
E36 34.0 2 34.1 57.8 59.6 60 60
-07
(7.5)
208 15.6 83.1 21.4 1.5 10.9 5.5 0.0
None - - - 49.0 54.5 60 70
E09 6.8 1 18.9 72.6 78.1 80 80
E18 13.5 2 37.5 95.8 101.3 100 110
E24 18.0 2 50.0 111.5 117.0 125 125
E36 25.5 2 70.8 137.5 143.0 150 150
230 15.6 83.1 21.4 1.5 10.9 5.5 0.0
None - - - 49.0 54.5 60 70
E09 9.0 1 22.6 76.1 81.6 80 90
E18 18.0 2 45.2 103.1 108.6 110 110
E24 24.0 2 60.2 121.2 126.7 125 150
E36 34.0 2 85.3 151.2 156.7 175 175
460 6.9 41.0 9.7 0.8 5.3 2.2 0.0
None - - - 22.4 24.6 25 30
E09 9.0 1 11.3 36.0 38.2 40 40
E18 18.0 2 22.6 49.5 51.7 50 60
E24 24.0 2 30.1 58.5 60.7 60 70
E36 34.0 2 42.7 73.5 75.7 80 80
575 5.4 33.0 7.5 0.6 4.1 1.8 0.0
None - - - 17.5 19.3 20 20
E09 9.0 1 9.0 28.3 30.1 30 35
E18 18.0 2 18.1 39.1 40.9 40 45
E24 24.0 2 24.1 46.3 48.1 50 50
E36 34.0 2 34.1 58.3 60.1 60 70
-08
(8.5)
208 16.7 120.0 26.0 1.5 10.9 5.5 0.0
None - - - 51.5 57.0 60 70
E09 6.8 1 18.9 75.1 80.6 80 90
E18 13.5 2 37.5 98.3 103.8 100 110
E24 18.0 2 50.0 113.9 119.4 125 125
E36 25.5 2 70.8 140.0 145.5 150 150
230 16.7 120.0 26.0 1.5 10.9 5.5 0.0
None - - - 51.5 57.0 60 70
E09 9.0 1 22.6 78.5 84.0 80 90
E18 18.0 2 45.2 105.6 111.1 110 125
E24 24.0 2 60.2 123.6 129.1 125 150
E36 34.0 2 85.3 153.7 159.2 175 175
460 8.7 60.0 13.5 0.8 5.3 2.2 0.0
None - - - 26.5 28.7 35 35
E09 9.0 1 11.3 40.0 42.2 45 45
E18 18.0 2 22.6 53.5 55.7 60 60
E24 24.0 2 30.1 62.6 64.8 70 70
E36 34.0 2 42.7 77.6 79.8 80 80
575 6.7 42.0 10.5 0.6 4.1 1.8 0.0
None - - - 20.4 22.2 25 25
E09 9.0 1 9.0 31.2 33.0 35 35
E18 18.0 2 18.1 42.0 43.8 45 45
E24 24.0 2 24.1 49.2 51.0 50 60
E36 34.0 2 34.1 61.3 63.1 70 70
