TECHNICAL GUIDE
LX SERIES
SPLIT SYSTEM
HEAT PUMPS
16 SEER – R-410A – 1 PHASE
1.5 THRU 5 NOMINAL TONS
MODELS: TH6B18 THRU 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.simplygettingthejobdone.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Extended 10-Years limited parts warranty.
Standard 10-year limited compressor warranty.
Extended 10-Years limited parts warranty requires
online registration within 90 days of purchase for replacement
or closing for new home construction.
*Does not apply to R-22 models, 3-Phase models, or internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR INSTALLATION IN ALL US REGIONS AND CANADA
Installation Allowed
®
TECHNICAL
GUIDE
TECHNICAL
GUIDE
DESCRIPTION
The TH6B models are part of our successful LX Series split sys-
tem heat pump lineup. These outdoor units are optimized for
the new 16 SEER / 9.0 HSPF Minimum Efficiency in all US
Regions, and are specifically designed to be matched with resi-
dential indoor coils, furnaces, and air handlers to provide a
complete system solution.
FEATURES
•Easier Installation - Independent panels provide quick
access for unit setup. Installation time is reduced by easy
power and control wiring access. All models utilize TXV's.
The factory installed stainless steel filter-drier and factory
charge for a 15-Ft lineset means less time spent brazing and
charging the system. The small base dimension and reduced
unit clearances make for easier retrofits.
•Accessible Information - QR code on unit provides quick
access to technical documents and warranty information.
• Durable Finish - The coated steel wire fan guard, coated
external fasteners, and pre-treated G90-equivalent galva-
nized steel chassis components resist corrosion and rust
creep. Titanium colored powdercoat paint further protects
external panels.
•Rugged Coil Protection - Coils are protected from mechan-
ical damage by a proven extruded louver steel coil guard
design.
•Quality Coils - Enhanced aluminum fins are mechanically
bonded to copper tubing.
•Protected Compressor - Compressors are protected inter-
nally by a high pressure relief valve and a temperature sen-
sor, and externally by the system high and low pressure
switches. The liquid line filter-drier is factory installed to pro-
tect the compressor against moisture and debris.
•Reliable Operation - Ball bearing fan motors provide supe-
rior performance in extreme temperatures. Factory installed
accumulator ensures proper functioning across a wide range
of conditions.
•Environmentally Friendly - CFC-free R-410A refrigerant
delivers environmentally friendly performance with zero
ozone depletion.
•Top Discharge - Warm air is blown up, away from the struc-
ture and any landscaping and allows compact location on
multi-unit applications.
•Low Operating Sound Levels - Developed using CFD and
FEA tools, the sturdy cabinet and top design provides sound
performance of 72 dBA or lower. Compatible accessories for
further sound reduction are also available.
•Better Service Access - Diagonal base valves with open
access for low-loss fittings, single panel access to the electri-
cal controls, full corner access, and removable fan guard
allow easy access for unit maintenance.
•Agency Listed - Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.

5599020-BTG-F-0520
2 Johnson Controls Ducted Systems
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . 3
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . . 4
SYSTEM CAPACITY - Single Piece and Modular Air Handlers . . 5
SYSTEM CAPACITY - Upflow, Downflow &
Horizontal Furnaces and Coils (Coil Only Ratings) . . . . . . . . . . . 9
SYSTEM CAPACITY - With High Efficiency Motor Furnaces . . . . 9
APPLICATION & ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . 36
SOUND POWER RATINGS - COOLING . . . . . . . . . . . . . . . . . . . . . 36
SOUND POWER RATINGS - HEATING . . . . . . . . . . . . . . . . . . . . . 37
MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 37
TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
ALTERNATIVE INSTALLATION CLEARANCES . . . . . . . . . . . . . . 39
PERFORMANCE DATA - 1.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 40
PERFORMANCE DATA - 2 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 45
PERFORMANCE DATA - 2.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 50
PERFORMANCE DATA - 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 55
PERFORMANCE DATA - 3.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 62
PERFORMANCE DATA - 4 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 68
PERFORMANCE DATA - 5 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 74
NOMENCLATURE
BRAND TT = Factory Branded
PRODUCT TYPE HH = Heat Pump
NOMINAL
SERIES EFFICIENCY
AND STAGING
66 = 16 SEER / 1-Stage
REFRIGERANT BB = R-410A
NOMINAL
UNIT CAPACITY
(MBH)
36
18 = 1.5 Ton 36 = 3 Ton
24 = 2 Ton 42 = 3.5 Ton
30 = 2.5 Ton 48 = 4 Ton
35 = 3 Ton 60 = 5 Ton
VOLTAGE
(Voltage-Phase-Hertz) 22 = 208/230-1-60
GENERATION
(MAJOR REVISION) 1
1 = 1st Gen
2 = 2nd Gen
etc
FACTORY OPTION SS = Standard (No Options)
STYLE LETTER
(Minor Revision)
Not Used for Ordering
A
A = Style A
B = Style B

5599020-BTG-F-0520
Johnson Controls Ducted Systems 3
‡ Adapter fitting must be field installed for the required 1-1/8” line set.
‡ Adapter fitting must be field installed for the required 1-1/8” line set.
All dimensions are in inches and are subject to change without notice.
Overall height is from bottom of base pan to top of fan guard.
Overall length and width include screw heads.
PHYSICAL AND ELECTRICAL DATA
MODEL TH6B1821S TH6B2421S TH6B3021S TH6B3621S TH6B4221SS TH6B4821S TH6B6021S
Unit Supply Voltage 208-230V, 1 60Hz
Normal Voltage Range 1
1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.
187 to 252
Minimum Circuit Ampacity 14 15.5 19.6 22 28.7 25.9 32.4
Max. Overcurrent Device Amps 2
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
20 25 30 35 45 40 50
Min. Overcurrent Device Amps 3
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
15 20 20 25 30 30 35
Compressor Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll
Compressor
Amps
Rated Load 9.0 11.8 13.4 15.4 20.7 18.5 23.68
Locked Rotor 47.5 62.9 72.5 83.9 123.9 124 152.5
Crankcase Heater Yes Yes Yes Yes Yes Yes Yes
Factory External Discharge Muffler Yes Yes Yes Yes Yes Yes Yes
HS Kit Required with TXV No No No No No No No
HS Kit Part Number (S1-2SA067*****)4
4. Use S1-2SA067***** series kit. See Hard Start Kit Accessory Installation Manual.
21806 10106 10106 10106 10106 10106 10106
Fan Diameter Inches 22 24 24 24 26 26 26
Fan Motor
Type ECM PSC ECM ECM ECM ECM ECM
Rated HP 1/3 1/8 1/3 1/3 1/3 1/3 1/3
Rated Load Amps 2.8 0.80 2.8 2.8 2.8 2.8 2.8
Nominal RPM 682 1075 682 682 682 834 834
Nominal CFM 2850 2995 2995 3715 3715 4100 4100
Coil
Face Area Sq. Ft. 17.9 23.8 23.8 23.8 26.4 31.2 31.2
Rows Deep 1 112222
Fins / Inch 22 22 22 18 18 18 18
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed)5
5. For applications with non-standard vapor line sizes, see the “Applications & Accessories” section of this Technical Guide.
3/4 3/4 3/4 3/4 7/8 7/8 1-1/8‡
Unit Charge (Lbs. - Oz.) 6
6. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or subtract
the amount of refrigerant, using the difference in actual lineset length (not the equivalent length) multiplied by the per foot value.
6 - 2 9 - 7 8 - 9 11 - 6 13 - 14 14 - 10 16 - 13
Charge Per Foot, Oz. 0.62 0.62 0.62 0.62 0.67 0.67 0.75
Operating Weight Lbs. 165 175 175 230 235 300 300
&
%
$
$
DIMENSIONS
Unit
Model
Dimensions
(Inches)
Refrigerant Connection
Service Valve Size
A B C Liquid Vapor
TH6B1821S 36-1/4 35-1/4 31-3/4
3/8
3/4
TH6B2421S 39-1/2 35-1/4 31-3/4
TH6B3021S 39-1/2 35-1/4 31-3/4
TH6B3621S 39-1/2 35-1/4 31-3/4
TH6B4221S 39-1/2 38 34-1/4 7/8
TH6B4821S 46 38 34-1/4
TH6B6021S 46 38 34-1/4 7/8‡

5599020-BTG-F-0520
4 Johnson Controls Ducted Systems
CHARGING PROCEDURES:
1. Check the Factory Unit Charge listed on the unit nameplate to verify the refrigerant charge for the outdoor unit, the smallest matched indoor unit, and the 15 feet
of interconnecting lineset.
2. Verify the indoor metering device and additional charge required for the specific matched indoor unit in the system using the above table.
3. Add additional charge for the amount of interconnecting lineset tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.
4. For installations requiring additional charge, weigh in refrigerant for the specific matching indoor unit and actual lineset length.
5. Once the charge adders for matched indoor unit and for lineset have been weighed in, verify the system operation against the temperatures and pressures in the
Charging Chart for the outdoor unit. Locate Charging Charts on the outdoor unit and also in the Service Data Application Guide on
www.simplygettingthejobdone.com. Follow the Subcool or Superheat charging procedure in the Installation Manual according to the type of indoor metering device
in the system, and allow ten minutes after each charge adjustment for the system operation to stabilize. Record the charge adjustment made to match the Charging
Chart.
6. For Downflow and Horizontal-Right Installations, some indoor units require additional charging adjustments to ensure proper equipment operation. Refer to the
outdoor unit installation manual.
7. Permanently stamp the unit nameplate with the TOTAL SYSTEM CHARGE defined as follows: TOTAL SYSTEM CHARGE = Base Charge (as shipped) + charge
adder for matched indoor unit + charge adder for actual lineset length + charge adjustments to match the Charging Chart.
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS
Outdoor Unit TH6B1821S TH6B2421S TH6B3021S TH6B3621S TH6B4221S TH6B4821S TH6B6021S
Required TXV 1,2
1. For applications requiring a TXV, use S1-1TVM*** series kit.
2. A TXV kit must be used with these indoor units to obtain system performance.
BA1 BA1 BA1 BA1 or BB1 BC1 BC1 BC1 or BD1
Defrost Jumper Pin Setting 2222211
Indoor Unit 3,4,5
3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
4. CF coils cannot be used in horizontal applications.
5. Charge adders shown above do not indicate that coils are rated for every application. Refer to Performance Data Tables for actual performance for specified
system matches. Obtain certified system ratings from www.ahridirectory.org.
Additional Charge, oz
AP18B –––––––
AP24B 0––––––
AP30B –38––––
AP36B –––––––
AP36C –––––––
AP37C –––––––
AP42C –––––––
AP48(C,D) ––––0––
AP60(C,D) –––––––
AE18B –––––––
AE24B 0––––––
AE30B 28 0 0 – – – –
AE36(B,C) –380–––
AE42C – – – 25 0 – –
AE43C ––––17––
AE48(C,D) – – – 25 0 – –
AE60C ––––200–
AE60D –––––520
AVC18B –––––––
AVC24B 0––––––
AVC30B 28 0 0 – – – –
AVC36(B,C) –380–––
AVC42C – – – 25 0 – –
AVC48(C,D) – – – 25 0 – –
AVC49C – – – 17 –
AVC60C ––––200–
AVC60D –––––520
CF/CM/CU18(A,B) –––––––
CF/CM/CU24(A,B) 0––––––
CF/CM/CU30(A,B,C) 28 0 0 – – – –
CF/CM/CU36(A,B,C) –380–––
CF/CM/CU42(B,C,D) –––––––
CF/CM/CU48(C,D) – – – 25 0 – –
CF/CM50C –––––47–
CF/CM/CU60(C,D) ––––200–
CF/CM61D –––––47–
CF/CM64D –––––520
Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil
only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.
FOOTNOTES:

5599020-BTG-F-0520
Johnson Controls Ducted Systems 5
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER COIL
MODEL3
RATED
CFM
COOLING 1HEATING 2
MODEL WIDTH NET MBH SEER EER NET MBH HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
TH6B1821S AE24BX21 17.5 – 625 18.0 12.6 17.00 13.00 18.0 11.9 10.00 8.15 4.80 3.24
TH6B1821S AE30BX21 17.5 – 600 18.0 12.8 17.00 13.00 18.0 11.4 10.00 8.15 4.58 3.08
TH6B1821S AP24BX21 17.5 – 675 18.0 13.3 16.00 13.00 18.0 12.4 9.50 7.95 4.34 2.96
TH6B1821S AVC24BX21 17.5 – 600 18.0 12.2 17.00 13.00 18.0 11.7 10.00 8.30 4.62 3.14
TH6B1821S AVC30BX21 17.5 – 675 18.0 13.8 17.00 13.00 17.2 10.2 9.50 8.40 4.22 2.74
TH6B1821S ME08BN21 17.5 CF/CM24B 575 18.0 12.1 17.00 13.00 18.0 11.7 10.00 8.30 4.54 3.10
TH6B1821S ME08BN21 17.5 CF/CM30B 600 18.0 12.8 17.00 13.00 18.0 11.4 10.00 8.25 4.52 3.06
TH6B1821S ME12BN21 17.5 CF/CM24B 675 18.0 12.9 17.00 13.00 18.0 11.9 10.00 8.15 4.80 3.24
TH6B1821S ME12BN21 17.5 CF/CM30B 675 18.0 13.4 17.00 13.00 18.0 11.6 10.00 8.15 4.68 3.14
TH6B1821S ME12CN21 21.0 CF/CM24C 600 18.0 12.2 17.00 13.00 18.0 11.7 10.00 8.25 4.62 3.14
TH6B1821S ME12CN21 21.0 CF/CM30C 600 18.0 12.8 17.00 13.00 18.0 11.4 10.00 8.25 4.52 3.06
TH6B1821S MVC08BN21 17.5 CF/CM24B 625 18.0 12.5 17.00 13.00 18.0 11.8 10.00 8.20 4.68 3.18
TH6B1821S MVC08BN21 17.5 CF/CM30B 650 18.0 13.2 17.00 13.00 18.0 11.5 10.00 8.15 4.64 3.10
TH6B1821S MVC12CN21 21.0 CF/CM24C 650 18.0 12.7 17.00 13.00 18.0 11.8 10.00 8.20 4.78 3.22
TH6B1821S MVC12CN21 21.0 CF/CM30C 650 18.0 13.2 17.00 13.00 18.0 11.5 10.00 8.15 4.66 3.14
TH6B2421S AE30BX21 17.5 – 900 24.0 18.7 16.00 13.00 23.0 13.5 8.50 6.85 3.86 2.36
TH6B2421S AE36BX21 17.5 – 850 23.8 18.4 16.00 13.00 23.2 14.2 9.00 7.25 4.04 2.58
TH6B2421S AE36CX21 21.0 – 800 23.4 17.6 16.00 13.00 23.0 14.1 9.00 7.25 4.10 2.60
TH6B2421S AP30BX21 17.5 – 850 23.2 18.3 15.00 12.25 23.6 14.7 9.00 7.45 3.82 2.46
TH6B2421S AVC30BX21 17.5 – 900 24.0 18.8 16.00 13.00 23.0 13.5 8.50 6.90 3.76 2.30
TH6B2421S AVC36BX21 17.5 – 825 23.6 18.1 16.00 13.00 23.2 14.3 9.00 7.70 3.84 2.50
TH6B2421S AVC36CX21 21.0 – 950 24.0 19.2 17.00 13.00 23.2 14.3 10.00 8.10 4.32 2.70
TH6B2421S ME08BN21 17.5 CF/CM30B 900 24.0 18.7 16.00 13.00 23.0 13.5 8.50 6.90 3.78 2.30
TH6B2421S ME08BN21 17.5 CF/CM36B 900 24.0 18.9 16.00 13.00 23.2 14.3 9.00 7.30 4.08 2.60
TH6B2421S ME12BN21 17.5 CF/CM30B 875 24.0 18.5 16.00 13.00 22.8 13.4 8.20 6.60 3.74 2.30
TH6B2421S ME12BN21 17.5 CF/CM36B 875 24.0 18.6 17.00 13.00 23.2 14.2 9.00 7.30 4.04 2.58
TH6B2421S ME12CN21 21.0 CF/CM30C 850 24.0 18.4 16.00 13.00 22.8 13.3 8.20 6.65 3.68 2.26
TH6B2421S ME12CN21 21.0 CF/CM36C 850 23.8 18.4 17.00 13.00 23.0 14.2 9.00 7.30 3.98 2.56
TH6B2421S ME16CN21 21.0 CF/CM30C 925 24.0 18.9 16.00 13.00 23.0 13.4 8.50 6.80 3.90 2.36
TH6B2421S ME16CN21 21.0 CF/CM36C 925 24.0 19.0 17.00 13.00 23.2 14.3 9.00 7.20 4.22 2.66
TH6B2421S MVC08BN21 17.5 CF/CM30B 800 23.8 17.9 15.00 13.00 22.8 13.3 8.20 6.75 3.52 2.20
TH6B2421S MVC08BN21 17.5 CF/CM36B 800 23.4 17.8 16.00 13.00 23.0 14.2 9.00 7.45 3.82 2.46
TH6B2421S MVC12BN21 17.5 CF/CM30B 950 24.0 19.1 16.00 13.00 23.0 13.5 9.00 7.30 3.96 2.38
TH6B2421S MVC12BN21 17.5 CF/CM36B 950 24.0 19.2 17.00 13.00 23.4 14.4 10.00 8.15 4.28 2.68
TH6B2421S MVC12CN21 21.0 CF/CM30C 875 24.0 18.5 16.00 13.00 22.8 13.3 8.50 6.90 3.78 2.32
TH6B2421S MVC12CN21 21.0 CF/CM36C 875 24.0 18.7 17.00 13.00 23.0 14.2 9.50 7.80 4.10 2.60
TH6B2421S MVC16CN21 21.0 CF/CM30C 925 24.0 18.8 16.00 13.00 22.8 13.4 9.00 7.30 3.92 2.38
TH6B2421S MVC16CN21 21.0 CF/CM36C 925 24.0 18.9 17.00 13.00 23.2 14.2 9.50 7.65 4.24 2.68

5599020-BTG-F-0520
6 Johnson Controls Ducted Systems
TH6B3021S AE30BX21 17.5 – 1125 30.0 22.4 17.00 13.00 28.4 17.2 9.50 7.90 4.12 2.74
TH6B3021S AE36BX21 17.5 – 1100 30.0 22.0 16.00 13.00 28.6 17.9 9.00 7.55 3.96 2.68
TH6B3021S AE36CX21 21.0 – 1175 30.0 22.2 16.00 13.00 28.6 17.9 9.00 7.50 4.12 2.76
TH6B3021S AP30BX21 17.5 – 1075 30.0 22.0 15.00 12.25 29.0 18.3 9.00 7.65 3.76 2.56
TH6B3021S AVC30BX21 17.5 – 1100 30.0 22.2 16.00 13.00 28.2 17.2 9.00 7.50 4.04 2.72
TH6B3021S AVC36BX21 17.5 – 1025 30.0 22.0 16.00 13.00 28.2 17.6 9.00 7.80 3.82 2.62
TH6B3021S AVC36CX21 21.0 – 1100 30.0 21.8 16.00 13.00 28.4 17.6 9.00 7.55 4.00 2.70
TH6B3021S ME12BN21 17.5 CF/CM30B 1050 30.0 21.8 17.00 13.00 27.8 16.9 9.00 7.45 4.06 2.74
TH6B3021S ME12BN21 17.5 CF/CM36B 1050 30.0 21.6 16.00 13.00 28.2 17.6 9.00 7.60 3.90 2.66
TH6B3021S ME12CN21 21.0 CF/CM30C 1000 30.0 21.6 17.00 13.00 27.6 16.7 9.00 7.45 4.06 2.76
TH6B3021S ME12CN21 21.0 CF/CM36C 1000 30.0 21.2 16.00 13.00 28.0 17.4 9.00 7.60 3.90 2.66
TH6B3021S ME16CN21 21.0 CF/CM30C 1100 30.0 22.2 17.00 13.00 28.0 16.9 9.00 7.40 4.16 2.80
TH6B3021S ME16CN21 21.0 CF/CM36C 1100 30.0 21.8 16.00 13.00 28.4 17.6 9.00 7.55 4.00 2.70
TH6B3021S MVC12BN21 17.5 CF/CM30B 1125 30.0 22.2 17.00 13.00 28.2 17.1 9.00 7.40 4.14 2.76
TH6B3021S MVC12BN21 17.5 CF/CM36B 1075 30.0 21.8 16.00 13.00 28.4 17.7 9.00 7.55 3.94 2.66
TH6B3021S MVC12CN21 21.0 CF/CM30C 1175 30.0 22.4 17.00 13.00 28.2 17.0 9.50 7.85 4.28 2.84
TH6B3021S MVC12CN21 21.0 CF/CM36C 1125 30.0 22.0 16.00 13.00 28.4 17.6 9.00 7.50 4.06 2.74
TH6B3021S MVC16CN21 21.0 CF/CM30C 1125 30.0 22.2 17.00 13.00 28.0 16.9 9.50 7.90 4.24 2.82
TH6B3021S MVC16CN21 21.0 CF/CM36C 1125 30.0 22.0 16.00 13.00 28.4 17.6 9.00 7.50 4.06 2.74
TH6B3621S AE36BX21 17.5 – 975 35.0 22.8 15.00 13.00 35.0 22.8 9.00 7.85 3.68 2.62
TH6B3621S AE36CX21 21.0 – 975 35.2 23.0 16.00 13.00 35.0 22.6 9.00 7.80 3.74 2.66
TH6B3621S AE42CX21 21.0 – 950 36.0 23.0 16.00 13.00 36.0 22.8 9.00 7.70 3.76 2.62
TH6B3621S AE48CX21 21.0 – 1075 36.0 25.0 17.00 13.00 35.6 22.8 9.00 8.15 3.74 2.62
TH6B3621S AE48DX21 24.5 – 1050 36.0 23.6 16.50 13.00 36.0 22.8 9.00 7.60 3.90 2.66
TH6B3621S AVC36BX21 17.5 – 925 34.8 22.4 15.00 13.00 34.8 22.6 9.00 7.90 3.60 2.58
TH6B3621S AVC36CX21 21.0 – 900 35.0 22.2 16.00 13.00 34.6 22.4 9.00 7.85 3.62 2.60
TH6B3621S AVC42CX21 21.0 – 925 36.0 22.8 16.00 13.00 36.0 22.8 9.00 7.75 3.68 2.58
TH6B3621S AVC48CX21 21.0 – 925 36.0 22.8 16.00 13.00 36.0 22.8 9.00 7.75 3.70 2.58
TH6B3621S AVC48DX21 24.5 – 975 36.0 23.2 16.00 13.00 36.0 22.8 9.00 7.75 3.76 2.62
TH6B3621S ME12BN21 17.5 CF/CM36B 1050 35.4 23.8 15.25 13.00 35.2 22.8 9.00 7.80 3.72 2.64
TH6B3621S ME12CN21 21.0 CF/CM36C 1000 35.2 23.2 16.00 13.00 35.0 22.6 9.00 7.80 3.70 2.64
TH6B3621S ME12CN21 21.0 CF/CM48C 1000 36.0 23.4 16.00 13.00 36.0 22.8 9.00 7.70 3.76 2.60
TH6B3621S ME14DN21 24.5 CF/CM36D 1025 35.4 23.6 16.00 13.00 35.0 22.6 9.00 7.75 3.74 2.66
TH6B3621S ME14DN21 24.5 CF/CM48D 1025 36.0 23.4 16.00 13.00 36.0 22.8 9.00 7.70 3.78 2.62
TH6B3621S ME16CN21 21.0 CF/CM36C 1100 35.6 24.2 15.25 13.00 35.4 22.8 9.00 7.75 3.78 2.66
TH6B3621S ME16CN21 21.0 CF/CM48C 1100 36.0 24.0 16.00 13.00 36.0 23.0 9.00 7.65 3.82 2.62
TH6B3621S ME20DN21 24.5 CF/CM36D 1275 36.0 26.0 16.00 13.00 35.8 23.0 9.00 7.60 4.02 2.76
TH6B3621S ME20DN21 24.5 CF/CM48D 1275 36.0 25.0 16.00 13.00 36.0 22.8 9.00 7.50 4.02 2.70
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER COIL
MODEL3
RATED
CFM
COOLING 1HEATING 2
MODEL WIDTH NET MBH SEER EER NET MBH HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

5599020-BTG-F-0520
Johnson Controls Ducted Systems 7
TH6B3621S MVC12BN21 17.5 CF/CM36B 950 35.0 22.6 15.25 13.00 34.8 22.6 9.00 7.85 3.64 2.60
TH6B3621S MVC12CN21 21.0 CF/CM36C 1000 35.4 23.4 16.00 13.00 34.8 22.6 9.00 7.80 3.72 2.66
TH6B3621S MVC12CN21 21.0 CF/CM48C 975 36.0 23.2 16.00 13.00 36.0 22.8 9.00 7.75 3.74 2.62
TH6B3621S MVC14DN21 24.5 CF/CM36D 1100 35.8 24.4 16.00 13.00 35.2 22.6 9.00 7.70 3.84 2.70
TH6B3621S MVC14DN21 24.5 CF/CM48D 1000 36.0 23.2 16.50 13.00 36.0 22.8 9.00 7.70 3.78 2.62
TH6B3621S MVC16CN21 21.0 CF/CM36C 1025 35.4 23.6 16.00 13.00 35.0 22.6 9.00 7.75 3.74 2.66
TH6B3621S MVC16CN21 21.0 CF/CM48C 1025 36.0 23.4 16.00 13.00 36.0 22.8 9.00 7.70 3.78 2.62
TH6B3621S MVC20DN21 24.5 CF/CM36D 1175 36.0 25.2 16.00 13.00 35.4 22.8 9.00 7.70 3.92 2.74
TH6B3621S MVC20DN21 24.5 CF/CM48D 1175 36.0 24.4 16.50 13.00 36.0 22.8 9.00 7.60 3.94 2.68
TH6B4221S AE42CX21 21.0 – 1150 41.0 27.2 16.00 13.00 42.0 25.4 9.00 7.25 3.76 2.64
TH6B4221S AE43CX21 21.0 – 1200 41.5 28.4 16.00 13.00 40.5 25.6 9.50 7.90 3.84 2.76
TH6B4221S AE48CX21 21.0 – 1200 41.0 27.4 16.00 13.00 42.0 25.6 9.00 7.00 3.84 2.70
TH6B4221S AE48DX21 24.5 – 1250 41.5 28.2 16.50 13.00 42.0 25.6 9.50 7.80 3.90 2.74
TH6B4221S AE60CX21 21.0 – 1200 41.5 28.4 16.00 13.00 41.5 27.2 9.50 7.80 3.84 2.84
TH6B4221S AE60CX22 21.0 – 1200 41.5 28.4 16.00 13.00 41.5 27.2 9.50 7.80 3.84 2.84
TH6B4221S AP48CX21 21.0 – 1300 40.5 28.2 15.00 12.25 42.0 26.8 9.00 7.35 3.68 2.60
TH6B4221S AVC42CX21 21.0 – 1250 41.0 28.0 16.00 13.00 42.0 25.8 9.00 7.10 3.78 2.66
TH6B4221S AVC48CX21 21.0 – 1200 41.0 27.6 16.00 13.00 42.0 25.6 9.00 7.15 3.78 2.66
TH6B4221S AVC48DX21 24.5 – 1225 41.0 27.6 16.50 13.00 42.0 25.4 9.00 7.05 3.82 2.70
TH6B4221S AVC49CX21 21.0 – 1200 41.5 29.0 16.00 13.00 41.5 26.4 9.50 8.55 3.76 2.78
TH6B4221S ME14DN21 24.5 CF/CM48D 1200 41.0 27.4 16.00 13.00 42.0 25.4 9.00 7.10 3.80 2.66
TH6B4221S ME14DN21 24.5 CF/CM60D 1200 41.5 28.4 16.50 13.00 41.0 27.0 9.50 7.80 3.82 2.86
TH6B4221S ME16CN21 21.0 CF/CM48C 1325 41.0 28.4 16.00 13.00 42.0 26.2 9.00 7.05 3.82 2.70
TH6B4221S ME16CN21 21.0 CF/CM60C 1325 41.5 29.6 16.00 13.00 42.0 27.4 9.00 6.80 3.86 2.82
TH6B4221S ME20DN21 24.5 CF/CM48D 1275 41.5 28.4 16.50 13.00 42.0 25.6 9.00 6.95 3.86 2.72
TH6B4221S ME20DN21 24.5 CF/CM60D 1275 42.0 29.4 16.50 13.00 41.5 27.0 9.50 7.70 3.90 2.86
TH6B4221S MVC14DN21 24.5 CF/CM48D 1250 41.5 28.2 16.50 13.00 42.0 25.6 9.00 6.90 3.86 2.72
TH6B4221S MVC14DN21 24.5 CF/CM60D 1250 42.0 29.2 16.50 13.00 41.0 27.0 9.50 7.70 3.90 2.88
TH6B4221S MVC16CN21 21.0 CF/CM48C 1275 41.5 28.4 16.00 13.00 42.0 25.8 9.00 6.90 3.84 2.70
TH6B4221S MVC16CN21 21.0 CF/CM60C 1275 42.0 29.4 16.50 13.00 41.5 27.2 9.50 7.75 3.88 2.86
TH6B4221S MVC20DN21 24.5 CF/CM48D 1275 41.5 28.2 16.50 13.00 42.0 25.6 9.00 6.85 3.88 2.72
TH6B4221S MVC20DN21 24.5 CF/CM60D 1275 42.0 29.4 16.50 13.00 41.5 27.0 9.50 8.10 3.92 2.88
TH6B4821S AE60CX22 21.0 – 1400 45.5 31.8 15.50 13.00 46.0 29.6 9.00 7.75 3.86 2.84
TH6B4821S AE60DX21 24.5 – 1350 47.5 32.2 16.00 13.00 46.5 27.0 9.00 7.40 4.06 2.74
TH6B4821S AVC60DX21 24.5 – 1425 47.5 32.8 16.00 13.00 47.0 27.6 9.00 7.40 4.06 2.74
TH6B4821S ME16CN21 21.0 CF/CM50C 1475 48.0 36.4 16.00 13.00 45.5 27.8 8.50 7.30 3.54 2.54
TH6B4821S ME16CN21 21.0 CF/CM60C 1500 45.5 32.4 15.00 13.00 46.5 30.0 9.00 7.75 3.88 2.84
TH6B4821S ME20DN21 24.5 CF/CM60D 1500 46.0 32.4 16.00 13.00 46.0 29.6 9.00 7.70 3.98 2.90
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER COIL
MODEL3
RATED
CFM
COOLING 1HEATING 2
MODEL WIDTH NET MBH SEER EER NET MBH HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

5599020-BTG-F-0520
8 Johnson Controls Ducted Systems
3. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
— = Not applicable.
* Notates “Hot Heat Pump” performance. These ratings are not AHRI listed.
MP Modular Air Handlers use Coil Only Ratings.
TH6B4821S ME20DN21 24.5 CF/CM61D 1450 48.0 35.8 16.00 13.00 45.0 27.4 8.50 7.25 3.62 2.60
TH6B4821S ME20DN21 24.5 CF/CM64D 1475 47.5 33.0 16.50 13.00 47.0 27.6 9.00 7.40 4.14 2.82
TH6B4821S MV20DN21 24.5 CF/CM61D 1400 46.0 33.2 16.00 13.00 46.5 29.6 9.00 8.15 3.76 2.76
TH6B4821S MVC16CN21 21.0 CF/CM50C 1425 48.0 35.8 16.00 13.00 45.0 27.6 8.50 7.30 3.58 2.58
TH6B4821S MVC16CN21 21.0 CF/CM60C 1,400 45.5 31.8 16.00 13.00 46.0 29.4 9.00 7.75 3.86 2.84
TH6B4821S MVC20DN21 24.5 CF/CM60D 1,375 46.0 31.8 16.00 13.00 45.5 29.2 9.00 7.75 3.90 2.88
TH6B4821S MVC20DN21 24.5 CF/CM64D 1,550 48.0 34.0 16.00 13.00 47.5 28.2 9.00 7.40 4.20 2.86
TH6B6021S AE60DX21 24.5 – 1,550 57.5 38.5 15.00 12.50 58.0 36.0 9.00 7.40 3.78 2.60
TH6B6021S AVC60DX21 24.5 – 1,600 57.5 39.5 15.00 12.50 58.0 36.8 9.50 7.95 3.76 2.60
TH6B6021S ME20DN21 24.5 CF/CM64D 1,675 57.5 39.5 15.00 12.50 58.0 37.0 9.50 – 3.88 2.68
TH6B6021S MVC20DN21 24.5 CF/CM61D 1,625 53.0 37.2 14.00 12.00 55.5 35.0 8.20 7.40 3.46 2.30
TH6B6021S MVC20DN21 24.5 CF/CM64D 1,575 57.5 39.0 15.50 13.00 58.0 36.0 9.50 – 3.84 2.64
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
1. Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in watt-hours during the same period.
2. Heating MBH based on AHRI standards of 70°F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping and no supplemental electric heat operation.
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input during the same period.
COP (Coefficient of Performance) equals Heating MBH output divided by (total KW input x 3.412).
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER COIL
MODEL3
RATED
CFM
COOLING 1HEATING 2
MODEL WIDTH NET MBH SEER EER NET MBH HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

5599020-BTG-F-0520
Johnson Controls Ducted Systems 9
— = Not Applicable.
MP Modular Air Handlers use Coil Only Ratings.
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
SYSTEM CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL CFM RANGE
(MIN.-MAX.)
COOLING HEATING
MODEL WIDTH RATED
CFM
NET MBH SEER 1EER NET MBH HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
TH6B1821S CF/CM/CU24A 14.5 450 - 750 600 18.0 12.7 16.00 13.00 18.0 12.3 9.50 8.05 4.18 2.86
TH6B1821S CF/CM/CU24B 17.5 450 - 750 600 18.0 12.7 16.00 13.00 18.0 12.3 9.50 8.05 4.18 2.86
TH6B1821S CF/CM24C 21.0 450 - 750 600 18.0 12.7 16.00 13.00 18.0 12.3 9.50 8.05 4.18 2.86
TH6B3021S CF/CM/CU30A 14.5 800 - 1200 825 28.8 20.2 15.00 13.00 27.6 17.0 8.20 6.95 3.62 2.50
TH6B3021S CF/CM/CU30B 17.5 800 - 1200 1000 29.4 21.6 15.00 13.00 28.4 17.4 8.50 7.15 3.76 2.56
TH6B3021S CF/CM30C 21.0 800 - 1200 1000 29.4 21.6 15.00 13.00 28.4 17.4 8.50 7.15 3.76 2.56
TH6B4221S CF/CM/CU48C 21.0 1200-1600 1400 42.0 30.2 14.00 12.00 42.0 25.6 8.20 7.15 3.54 2.46
TH6B4221S CF/CM/CU48D 24.0 1200-1600 1400 42.0 30.2 14.00 12.00 42.0 25.6 8.20 7.15 3.54 2.46
TH6B4221S CF/CM/CU60C 21.0 1200-1600 1400 42.0 31.1 15.00 13.00 41.0 26.8 9.00 7.50 3.58 2.54
TH6B6021S CF/CM64D 24.5 1520 - 1920 1850 57.5 41.5 14.00 12.00 58.0 39.5 9.00 7.50 3.86 2.70
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
SYSTEM CAPACITY - With High Efficiency Motor Furnaces1
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING HEATING
MODEL WIDTH RATED
CFM
NET MBH SEER EER NET MBH HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
TH6B1821S TM8V060A12MP12C 14.5 CF/CM/CU24A 575 18.0 12.1 17.00 13.00 18.0 11.7 10.00 8.30 4.50 3.06
TH6B1821S TM8V060A12MP12C 14.5 CF/CM/CU24B 575 18.0 12.1 17.00 13.00 18.0 11.7 10.00 8.35 4.52 3.08
TH6B1821S TM8V060A12MP12C 14.5 CF/CM/CU30A 575 18.0 12.6 17.00 13.00 18.0 11.4 10.00 8.25 4.38 2.98
TH6B1821S TM8V060A12MP12C 14.5 CF/CM/CU30B 625 18.0 13.1 17.00 13.00 18.0 11.5 10.00 8.20 4.52 3.04
TH6B1821S TM8V080B12MP12C 17.5 CF/CM/CU24B 625 18.0 12.5 17.00 13.00 18.0 11.9 10.00 8.30 4.58 3.10
TH6B1821S TM8V080B12MP12C 17.5 CF/CM/CU30B 550 18.0 12.4 17.00 13.00 18.0 11.4 10.00 8.35 4.32 2.94
TH6B1821S TM8V080B12MP12C 17.5 CF/CM24C 625 18.0 12.5 17.00 13.00 18.0 11.9 10.00 8.30 4.58 3.12
TH6B1821S TM8V080B12MP12C 17.5 CF/CM30C 625 18.0 13.1 17.00 13.00 18.0 11.5 10.00 8.25 4.48 3.02
TH6B1821S TM8X060A12MP11 14.5 CF/CM/CU24A 625 18.0 12.5 17.00 13.00 18.0 11.9 10.00 8.30 4.58 3.10
TH6B1821S TM8X060A12MP11 14.5 CF/CM/CU24B 650 18.0 12.8 17.00 13.00 18.0 11.9 10.00 8.30 4.66 3.14
TH6B1821S TM8X060A12MP11 14.5 CF/CM/CU30A 625 18.0 13.1 17.00 13.00 18.0 11.6 10.00 8.25 4.48 3.02
TH6B1821S TM8X060A12MP11 14.5 CF/CM/CU30B 650 18.0 13.3 17.00 13.00 18.0 11.6 10.00 8.20 4.56 3.06
TH6B1821S TM8X080B12MP11 17.5 CF/CM/CU24B 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.25 4.72 3.18
TH6B1821S TM8X080B12MP11 17.5 CF/CM/CU30B 675 18.0 13.5 17.00 13.00 18.0 11.6 10.00 8.15 4.62 3.10
TH6B1821S TM8X080B12MP11 17.5 CF/CM24C 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.20 4.74 3.20
TH6B1821S TM8X080B12MP11 17.5 CF/CM30C 675 18.0 13.5 17.00 13.00 18.0 11.6 10.00 8.15 4.64 3.10
TH6B1821S TM8X080C16MP11 21.0 CF/CM24C 700 18.0 13.1 17.00 13.00 18.0 12.0 10.00 8.20 4.84 3.24
TH6B1821S TM8X080C16MP11 21.0 CF/CM30C 700 18.0 13.7 17.00 13.00 18.0 11.6 10.00 8.10 4.72 3.16

5599020-BTG-F-0520
10 Johnson Controls Ducted Systems
TH6B1821S TM8X100C16MP11 21.0 CF/CM24C 700 18.0 13.1 17.00 13.00 18.0 12.0 10.00 8.20 4.84 3.24
TH6B1821S TM8X100C16MP11 21.0 CF/CM30C 700 18.0 13.7 17.00 13.00 18.0 11.6 10.00 8.10 4.72 3.16
TH6B1821S TM8Y060A12MP11 14.5 CF/CM/CU24A 625 18.0 12.5 17.00 13.00 18.0 11.9 10.00 8.30 4.58 3.10
TH6B1821S TM8Y060A12MP11 14.5 CF/CM/CU24B 650 18.0 12.8 17.00 13.00 18.0 11.9 10.00 8.30 4.66 3.14
TH6B1821S TM8Y060A12MP11 14.5 CF/CM/CU30A 625 18.0 13.1 17.00 13.00 18.0 11.6 10.00 8.25 4.48 3.02
TH6B1821S TM8Y060A12MP11 14.5 CF/CM/CU30B 650 18.0 13.3 17.00 13.00 18.0 11.6 10.00 8.20 4.56 3.06
TH6B1821S TM8Y080B12MP11 17.5 CF/CM/CU24B 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.25 4.72 3.18
TH6B1821S TM8Y080B12MP11 17.5 CF/CM/CU30B 675 18.0 13.5 17.00 13.00 18.0 11.6 10.00 8.15 4.62 3.10
TH6B1821S TM8Y080B12MP11 17.5 CF/CM24C 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.20 4.74 3.20
TH6B1821S TM8Y080B12MP11 17.5 CF/CM30C 675 18.0 13.5 17.00 13.00 18.0 11.6 10.00 8.15 4.64 3.10
TH6B1821S TM8Y080C16MP11 21.0 CF/CM24C 700 18.0 13.1 17.00 13.00 18.0 12.0 10.00 8.20 4.84 3.24
TH6B1821S TM8Y080C16MP11 21.0 CF/CM30C 700 18.0 13.7 17.00 13.00 18.0 11.6 10.00 8.10 4.72 3.16
TH6B1821S TM8Y100C16MP11 21.0 CF/CM24C 700 18.0 13.1 17.00 13.00 18.0 12.0 10.00 8.20 4.84 3.24
TH6B1821S TM8Y100C16MP11 21.0 CF/CM30C 700 18.0 13.7 17.00 13.00 18.0 11.6 10.00 8.10 4.72 3.16
TH6B1821S TM9E040A10MP11 14.5 CF/CM/CU24A 675 18.0 13.2 17.00 13.00 18.0 12.3 10.00 8.35 4.46 3.04
TH6B1821S TM9E040A10MP11 14.5 CF/CM/CU24B 700 18.0 13.4 17.00 13.00 18.0 12.3 10.00 8.30 4.54 3.08
TH6B1821S TM9E040A10MP11 14.5 CF/CM/CU30A 675 18.0 13.7 16.00 13.00 18.0 11.9 9.50 7.80 4.38 2.94
TH6B1821S TM9E040A10MP11 14.5 CF/CM/CU30B 700 18.0 13.9 16.00 13.00 18.0 11.9 9.50 7.80 4.46 2.98
TH6B1821S TM9E060B12MP11 17.5 CF/CM/CU24B 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.25 4.66 3.16
TH6B1821S TM9E060B12MP11 17.5 CF/CM/CU30B 675 18.0 13.5 17.00 13.00 18.0 11.7 10.00 8.20 4.56 3.06
TH6B1821S TM9E060B12MP11 17.5 CF/CM24C 675 18.0 13.0 17.00 13.00 18.0 12.0 10.00 8.25 4.66 3.16
TH6B1821S TM9E060B12MP11 17.5 CF/CM30C 675 18.0 13.5 17.00 13.00 18.0 11.7 10.00 8.20 4.58 3.06
TH6B1821S TM9E080B12MP11 17.5 CF/CM/CU24B 700 18.0 13.2 17.00 13.00 18.0 12.0 10.00 8.20 4.76 3.20
TH6B1821S TM9E080B12MP11 17.5 CF/CM/CU30B 700 18.0 13.8 17.00 13.00 18.0 11.7 10.00 8.15 4.66 3.12
TH6B1821S TM9E080B12MP11 17.5 CF/CM24C 700 18.0 13.2 17.00 13.00 18.0 12.0 10.00 8.20 4.78 3.20
TH6B1821S TM9E080B12MP11 17.5 CF/CM30C 700 18.0 13.8 17.00 13.00 18.0 11.7 10.00 8.15 4.66 3.12
TH6B1821S TM9E080C16MP11 21.0 CF/CM24C 600 18.0 12.3 17.00 13.00 18.0 11.8 10.00 8.30 4.58 3.12
TH6B1821S TM9E080C16MP11 21.0 CF/CM30C 600 18.0 12.8 17.00 13.00 18.0 11.4 10.00 8.25 4.48 3.04
TH6B1821S TM9E100C16MP11 21.0 CF/CM24C 625 18.0 12.6 17.00 13.00 18.0 11.8 10.00 8.25 4.62 3.14
TH6B1821S TM9E100C16MP11 21.0 CF/CM30C 625 18.0 13.0 17.00 13.00 18.0 11.5 10.00 8.20 4.52 3.06
TH6B1821S TM9V040A10MP12C 14.5 CF/CM/CU24A 575 18.0 12.1 17.00 13.00 18.0 11.9 10.00 8.40 4.40 3.00
TH6B1821S TM9V040A10MP12C 14.5 CF/CM/CU24B 575 18.0 12.2 17.00 13.00 18.0 11.8 10.00 8.40 4.42 3.02
TH6B1821S TM9V040A10MP12C 14.5 CF/CM/CU30A 575 18.0 12.7 16.00 13.00 18.0 11.5 9.50 7.85 4.30 2.92
TH6B1821S TM9V040A10MP12C 14.5 CF/CM/CU30B 575 18.0 12.7 16.50 13.25 18.0 11.5 9.00 7.35 4.32 2.94
TH6B1821S TM9V060B12MP12C 17.5 CF/CM/CU24B 600 18.0 12.3 17.00 13.00 18.0 11.8 10.00 8.30 4.54 3.10
TH6B1821S TM9V060B12MP12C 17.5 CF/CM/CU30B 550 18.0 12.4 17.00 13.00 18.0 11.3 10.00 8.30 4.34 2.96
TH6B1821S TM9V060B12MP12C 17.5 CF/CM24C 650 18.0 12.8 17.00 13.00 18.0 11.9 10.00 8.25 4.64 3.14
SYSTEM CAPACITY - With High Efficiency Motor Furnaces1
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING HEATING
MODEL WIDTH RATED
CFM
NET MBH SEER EER NET MBH HSPF
Region IV
HSPF
Region V
COP
TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD
