Johnson Controls PN-TP10L User manual

1
1. Applicable Unit
Model: PN-TP10L
This protection net is to protect the outdoor unit heat exchanger from external damages such as being hit
by a ball. Install it following the directions below.
NOTE:
7KHDSSOLFDEOHRXWGRRUXQLWPD\EHGLIIHUHQWGHSHQGLQJRQWKHSURGXFWVHULHV%HVXUHWRFRQ¿UPZLWK
the product catalog before installation.
Name Protection Net (for Left Side Installation)
Model PN-TP10L
Required Qty. 1
Applicable Outdoor Unit Top Flow Type
72,000 to 120,000 Btu/h
2. Installation Work
(1) Be sure to securely tighten the protection net with the supplied screws (accessories).
If the screws are not securely tightened, it may cause vibration or abnormal sound.
If they are over-tightened, the screw thread will be broken. When tightening the screws, make sure to
follow the tightening torque below.
Ɣ7LJKWHQLQJ7RUTXH06FUHZ+0.7 ftƔOEV+1.0 NƔm)
(2) Apply touch-up coating at the screw holes of the outdoor unit in order to prevent rusting
¿HOGVXSSOLHG
(3) Secure enough service space with consideration for attaching/detaching the protection net.
Ɣ6HUYLFH6SDFHZLWK3URWHFWLRQ1HW6HUYLFH6SDFHIRU2XWGRRU8QLW0LQLQFKPP
(4) Do not step on the protection net or the outdoor unit in order to prevent falls resulting in injury.
 )DOOHQOHDYHVRUVRPHRWKHUREMHFWVPD\EHFDXJKWE\WKHSURWHFWLRQQHWDQGSLOHGXS%HVXUHWR
check for accumulation and clean the protection net periodically.
(6) The protection net may freeze in cold weather.
(7) It is not possible to use the snow protection hood along with the left side inlet.
IMPORTANT NOTICE:
Ɣ 5HDGDQGXQGHUVWDQGWKLVPDQXDOEHIRUHXVLQJWKLVprotection net.
Ɣ 3HUIRUPWKHWHVWUXQDIWHULQVWDOODWLRQWRFKHFNIRUDEQRUPDOLWLHV
Ɣ )RUZDUGWKLVLQIRUPDWLRQWRWKHEXLOGLQJRZQHUDQGUHTXHVWWKDWWKH\PDLQWDLQDOOWKHHTXLSPHQWPDQXDOV
Ɣ 6LJQDOZRUGVDUHXVHGWRLGHQWLI\OHYHOVRIKD]DUGVHULRXVQHVV
'H¿QLWLRQVIRULGHQWLI\LQJKD]DUGOHYHOVDUHSURYLGHGEHORZZLWKWKHLUUHVSHFWLYHVLJQDOZRUGV
: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
Installation Manual for Protection Net
(for Left Side Installation of Outdoor Unit)

2
Unit: inch (mm)
No. Accessory Qty. Remarks
PN-TP10L
1
Protection Net
(for Left Side
Installation)
Top
Bottom
1
2Screw 0[//
(with Washer)
9
(1) (1): Spare
3. Before Installation
Check that all the following accessories are packed with the unit before installation.
4. Installation Procedures
%HIRUHLQVWDOODWLRQFRQ¿UPWKHRXWGRRUXQLWPRGHO,IWKHSURWHFWLRQQHWLVDYDLODEOHWRLQVWDOOIROORZWKH
installation procedures.
(1) Remove the two screws for the bottom parts of the
RXWGRRUXQLWOHIWVLGHFRYHUVHHWKH¿JXUHRQWKHULJKW
Outdoor Unit
Screws for Bottom Parts of
Outdoor Unit Left Side Cover
(2) Tighten loosely two screws 2at the top of the outdoor unit left side, and set the protection net (for
left side installation) 1over the top. Securely tighten the other six screws 2except for the top two
VFUHZVDQG¿QDOO\WLJKWHQWKHWRSWZRVFUHZVVHFXUHO\
Protection Net
(For Left Side Installation)
(For Left Side Installation)
Outdoor Unit
Screws
(Accessories)
2
2
1

5. Installation Appearance
Protection Net
(for Right Side
Installation)
(Other Protection
Net Option)
Protection Net
(for Rear Side
Installation)
(Other Protection
Net Option)
Protection Net
(for Left Side
Installation)
Outdoor Unit
Screws
(Accessories)
< Right Side > < Rear Side > < Left Side >
3-15/16
(100)
3-15/16
(100)
3-15/16
(100)
Unit: inch (mm)
68-1/8 (1730)
29-1/2
(750)
Available Combinations
Applicable Outdoor Unit
Model
Top Flow Type
72,000 Btu/h
Top Flow Type
96,000 and 120,000 Btu/h
Protection Net for Rear Side PN-TP10BA PN-TP10BB
Protection Net for Left Side PN-TP10L
Protection Net for Right Side PN-TP10R
NOTES:
Ɣ 7KLVLQVWDOODWLRQPDQXDODSSOLHVRQO\WRWKHFRPELQDWLRQLQGLFDWHGZLWK .
For other protection net options, refer to each installation manual.
Ɣ ,QVWDOOWKHUHTXLUHGSURWHFWLRQQHWGHSHQGLQJRQWKHLQVWDOODWLRQFRQGLWLRQ
© 2015 Johnson Controls, Inc.
P5415542
Code No. LIT-12012106
Issued June, 2015
