Johnson Controls Tyco Bentel Security PowerG BW-PGH User manual
Installation Guide
French...............13
Spanish.............25
Italian.................37
WARNING: ThisManualcontains informationonlimitations regarding product use andfunctionandinform-
ationonthe limitationsasto liabilityof the manufacturer.The entire manualshouldbe carefully read.
BW-PGH PowerG Transceiver
Specifications and Features
lCurrent Draw: 60mA
lVoltage: Draws current from the Absoluta Plus/Absoluta 630 alarm controller (10.8VDC to
12.5VDC) - (Limited Power Supply)
lFrequency: 868MHz (BW-PGH)
lZones - can receive signals from up to 128 wireless zones. Also supports up to 32 wireless keys
lSupervisory - programmable supervisory window
lCan be wired up to 230 m from the main panel with 0.34 mm2wire
lConnects to Tranceiver Bus
lCompatibility: The BW-PGH is used with Absoluta Plus/Absoluta 630 alarm panels
lOperating temperature: EU= -10°C – +55°C
lRelative humidity: 93% non-condensing
lSeparate, built-in wall and case tampers
Compatible Wireless Devices
Refer to the Bentel website for updated list of compatible control panels and PowerG wireless devices.
- 3 -
Safety Instructions
lThis equipment must be installed by Service Persons only (a service person is defined as a person
having the appropriate technical training and experience necessary to be aware of hazards to
which that person may be exposed in performing a task and of measures to minimize the risks to
that person or other persons). It must be installed and used within a non-hazardous, indoor envir-
onment only (pollution degree max 2, over voltages category II).
lThe installer is responsible for instructing the system user in regards to electrical safety pre-
cautions when using a system which includes this equipment and also in regards to each of the fol-
lowing:
lDo not attempt to service this product. There are no user serviceable parts inside. If ser-
vicing is required, it shall be referred to service persons only.
lUsing adequate mounting means (e.g., plastic/metal anchors), secure the transceiver to the building
structure before applying power.
lInternal wiring must be routed in a manner that prevents:
lExcessive strain on wire and on terminal connections;
lLoosening of terminal; connections;
lDamage to conductor insulation.
- 4 -
Introduction
The BW-PGH two-way wireless transceiver adds wireless capability to Absoluta Plus/Absoluta 630
alarm controllers, model ABS-18, ABS-48, ABS-128, ABS-128G3 or ABS-630. This manual describes
how to install, program and maintain the BW-PGH.
Controls and Indicators
Status LEDs
The LEDs on the front of the BW-PGH provide feedback regarding the installation, operation and
troubleshooting of the unit. The LEDs function as follows:
RedLED Operation
Module Power Up: Onsteadyduringmodule power-upsequencethenoff.
Firmware Update: Slow flashing = update in progress
Rapid flashing = update failed
TroubleCondition: lNo trouble: 1 rapid flash every 10 seconds.
If troublesare present,a seriesofflashesoccurevery2seconds.
Eachseriesofflashesindicatetroublesasfollows:
l1 flash: Module not enrolled
l2 flashes: Loss of contact with module for over 60 seconds
l3 flashes: Tranceiver Bus low voltage
l8 flashes: RF interference (jam condition)
Module Confirmation: Flashesrapidlyduringmodule confirmationprocess.
PlacementTest: Onsteadywhenlocationisbad.Offwhenlocationisgood.
Green LED Operation
PlacementTest: On steady when location is suitable. Off when location is unsuit-
able.
Tamper
The BW-PGH has separate built-in wall and case tampers.
Enable or disable the wall tamper by fastening the breakaway wall tamper bracket securely to the wall
using one of the supplied screws.
The case tamper activates when the case is opened and restores when the case is closed. The wall
tamper on the back of the unit is depressed by the mounting surface when properly installed. If the unit
is removed, the tamper activates. Ensure the mounting surface is smooth and free of obstructions that
block access to the rear of the unit. Electrical wires should not run over or under the module when it is
mounted.
Mounting
Note: Permanently mount the BW-PGH receiver and wireless devices AFTER placement testing each
device.
Find a place that is:
ldry,
lwithin operating temperature range,
lcentral to the proposed placement of all wireless devices,
las high as possible. The range is reduced if mounted below ground level,
- 5 -
lfar from sources of interference, including: electrical noise (computers, televisions, electric
motors, appliances, heating and air conditioning units), large metal objects like heating ducts and
plumbing which may shield the electro-magnetic waves,
lsmooth and free of obstructions that block access to the rear of the unit.
Connect the BW-PGH
Caution: Remove all power (AC, DC, telephone lines) from the system while connecting modules to
the Tranceiver Bus.
To connect the BW-PGH:
1. With the alarm panel powered down, connect the BW-PGH to the four-wire Tranceiver
Bus of the alarm panel according to Figure 1.
2. Once the wiring is complete, power up the security system.
Figure: 1 Wiring Diagram: 1) Control Panel; 2) Tranceiver Bus to BW-PGH
Enroll The BW-PGH
The BW-PGH must be enrolled onto the alarm panel before any wireless devices can be enrolled.
Refer to the control panel's instructions for the procedure.
Permanently Mount
Once a suitable location is found, mount the BW-PGH as follows:
1. Pull the Tranceiver Bus wires through the holes at the back of the cabinet.
2. Mount the cabinet securely to the wall using the three screws supplied.
3. To enable the wall tamper, fasten the breakaway wall tamper bracket securely to the wall
using the supplied screw.
- 6 -
Figure: 2 Mounting the BW-PGH
Wireless Device Setup and Programming
Refer to the control panel instruction to setup and programming the wireless devices.
- 7 -
LIMITED WARRANTY
Digital Security Controls warrants the original purchaser that for a
period of twelve months from the date of purchase, the product shall
be free of defects in materials and workmanship under normal use.
During the warranty period, Digital Security Controls shall, at its
option, repair or replace any defective product upon return of the
product to its factory, at no charge for labour and materials. Any
replacement and/or repaired parts are warranted for the remainder of
the original warranty or ninety (90) days, whichever is longer. The
original purchaser must promptly notify Digital Security Controls in
writing that there is defect in material or workmanship, such written
notice to be received in all events prior to expiration of the war-
ranty period. There is absolutely no warranty on software and all
software products are sold as a user license under the terms of the
software license agreement included with the product. The Customer
assumes all responsibility for the proper selection, installation, oper-
ation and maintenance of any products purchased from DSC. Custom
products are only warranted to the extent that they do not function
upon delivery. In such cases, DSC can replace or credit at its option.
International Warranty
The warranty for international customers is the same as for any cus-
tomer within Canada and the United States, with the exception that
Digital Security Controls shall not be responsible for any customs
fees, taxes, or VAT that may be due.
Warranty Procedure
To obtain service under this warranty, please return the item(s) in
question to the point of purchase. All authorized distributors and
dealers have a warranty program. Anyone returning goods to Digital
Security Controls must first obtain an authorization number. Digital
Security Controls will not accept any shipment whatsoever for which
prior authorization has not been obtained.
Conditions to Void Warranty
This warranty applies only to defects in parts and workmanship relat-
ing to normal use. It does not cover:
ldamage incurred in shipping or handling
ldamage caused by disaster such as fire, flood, wind, earth-
quake or lightning;
ldamage due to causes beyond the control of Digital Security
Controls such as excessive voltage, mechanical shock, water
damage;
ldamage caused by unauthorized attachment, alterations, modi-
fications or foreign objects;
ldamage caused by peripherals (unless such peripherals were
supplied by Digital Security Controls Ltd.);
ldefects caused by failure to provide a suitable installation
environment for the products;
ldamage caused by use of the products for purposes other than
those for which it was designed;
ldamage from improper maintenance;
ldamage arising out of any other abuse, mishandling or
improper application of the products.
Items Not Covered by Warranty
In addition to the items which void the Warranty, the following
items shall not be covered by Warranty: (i) freight cost to the
repair centre; (ii) products which are not identified with DSC's
product label and lot number or serial number; (iii) products dis-
assembled or repaired in such a manner as to adversely affect per-
formance or prevent adequate inspection or testing to verify any
warranty claim. Access cards or tags returned for replacement under
warranty will be credited or replaced at DSC's option. Products not
covered by this warranty, or otherwise out of warranty due to age,
misuse, or damage shall be evaluated, and a repair estimate shall be
provided. No repair work will be performed until a valid purchase
order is received from the Customer and a Return Merchandise
Authorization number (RMA) is issued by DSC's Customer Service.
Digital Security Controls Ltd.’s liability for failure to repair the
product under this warranty after a reasonable number of attempts
will be limited to a replacement of the product, as the exclusive
remedy for breach of warranty. Under no circumstances shall Digital
Security Controls be liable for any special, incidental, or con-
sequential damages based upon breach of warranty, breach of con-
tract, negligence, strict liability, or any other legal theory. Such
damages include, but are not limited to, loss of profits, loss of the
product or any associated equipment, cost of capital, cost of sub-
stitute or replacement equipment, facilities or services, down time,
purchaser’s time, the claims of third parties, including customers, and
injury to property. The laws of some jurisdictions limit or do not
allow the disclaimer of consequential damages. If the laws of such a
jurisdiction apply to any claim by or against DSC, the limitations
and disclaimers contained here shall be to the greatest extent per-
mitted by law. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so that the above may not
apply to you.
Disclaimer of Warranties
This warranty contains the entire warranty and shall be in lieu of
any and all other warranties, whether expressed or implied (including
all implied warranties of merchantability or fitness for a particular
purpose) and of all other obligations or liabilities on the part of
Digital Security Controls. Digital Security Controls neither assumes
responsibility for, nor authorizes any other person purporting to act
on its behalf to modify or to change this warranty, nor to assume
for it any other warranty or liability concerning this product. This
disclaimer of warranties and limited warranty are governed by the
laws of the province of Ontario, Canada.
WARNING: Digital Security Controls recommends that the entire sys-
tem be completely tested on a regular basis. However, despite fre-
quent testing, and due to, but not limited to, criminal tampering or
electrical disruption, it is possible for this product to fail to perform
as expected.
Out of Warranty Repairs
Digital Security Controls will at its option repair or replace out-of-
warranty products which are returned to its factory according to the
following conditions. Anyone returning goods to Digital Security Con-
trols must first obtain an authorization number. Digital Security Con-
trols will not accept any shipment whatsoever for which prior
authorization has not been obtained.
Products which Digital Security Controls determines to be repairable
will be repaired and returned. A set fee which Digital Security Con-
trols has predetermined and which may be revised from time to
time, will be charged for each unit repaired.
Products which Digital Security Controls determines not to be repair-
able will be replaced by the nearest equivalent product available at
that time. The current market price of the replacement product will
be charged for each replacement unit.
WARNING – READ CAREFULLY
Note to Installers
This warning contains vital information. As the only individual in
contact with system users, it is your responsibility to bring each
item in this warning to the attention of the users of this system.
System Failures
This system has been carefully designed to be as effective as pos-
sible. There are circumstances, however, involving fire, burglary, or
other types of emergencies where it may not provide protection. Any
alarm system of any type may be compromised deliberately or may
fail to operate as expected for a variety of reasons. Some but not
all of these reasons may be:
Inadequate Installation
A security system must be installed properly in order to provide
adequate protection. Every installation should be evaluated by a
security professional to ensure that all access points and areas are
covered. Locks and latches on windows and doors must be secure
and operate as intended. Windows, doors, walls, ceilings and other
building materials must be of sufficient strength and construction to
provide the level of protection expected. A reevaluation must be
done during and after any construction activity. An evaluation by
the fire and/or police department is highly recommended if this ser-
vice is available.
Criminal Knowledge
This system contains security features which were known to be
effective at the time of manufacture. It is possible for persons with
criminal intent to develop techniques which reduce the effectiveness
of these features. It is important that a security system be reviewed
periodically to ensure that its features remain effective and that it
be updated or replaced if it is found that it does not provide the
protection expected.
Access by Intruders
Intruders may enter through an unprotected access point, circumvent
a sensing device, evade detection by moving through an area of
insufficient coverage, disconnect a warning device, or interfere with
or prevent the proper operation of the system.
Power Failure
Control units, intrusion detectors, smoke detectors and many other
security devices require an adequate power supply for proper oper-
ation. If a device operates from batteries, it is possible for the bat-
teries to fail. Even if the batteries have not failed, they must be
charged, in good condition and installed correctly. If a device oper-
ates only by AC power, any interruption, however brief, will render
that device inoperative while it does not have power. Power inter-
ruptions of any length are often accompanied by voltage fluctuations
which may damage electronic equipment such as a security system.
After a power interruption has occurred, immediately conduct a com-
plete system test to ensure that the system operates as intended.
Failure of Replaceable Batteries
This system’s wireless transmitters have been designed to provide sev-
eral years of battery life under normal conditions. The expected bat-
tery life is a function of the device environment, usage and type.
Ambient conditions such as high humidity, high or low temperatures,
or large temperature fluctuations may reduce the expected battery
life. While each transmitting device has a low battery monitor
which identifies when the batteries need to be replaced, this monitor
may fail to operate as expected. Regular testing and maintenance
will keep the system in good operating condition.
Compromise of Radio Frequency (Wireless) Devices
Signals may not reach the receiver under all circumstances which
could include metal objects placed on or near the radio path or
deliberate jamming or other inadvertent radio signal interference.
System Users
A user may not be able to operate a panic or emergency switch pos-
sibly due to permanent or temporary physical disability, inability to
reach the device in time, or unfamiliarity with the correct oper-
ation. It is important that all system users be trained in the correct
operation of the alarm system and that they know how to respond
when the system indicates an alarm.
Smoke Detectors
Smoke detectors that are a part of this system may not properly
alert occupants of a fire for a number of reasons, some of which fol-
low. The smoke detectors may have been improperly installed or
positioned. Smoke may not be able to reach the smoke detectors,
such as when the fire is in a chimney, walls or roofs, or on the
other side of closed doors. Smoke detectors may not detect smoke
from fires on another level of the residence or building.
Every fire is different in the amount of smoke produced and the
rate of burning. Smoke detectors cannot sense all types of fires
equally well. Smoke detectors may not provide timely warning of
fires caused by carelessness or safety hazards such as smoking in
bed, violent explosions, escaping gas, improper storage of flammable
materials, overloaded electrical circuits, children playing with
matches or arson.
Even if the smoke detector operates as intended, there may be cir-
cumstances when there is insufficient warning to allow all occupants
to escape in time to avoid injury or death.
Motion Detectors
Motion detectors can only detect motion within the designated areas
as shown in their respective installation instructions. They cannot dis-
criminate between intruders and intended occupants. Motion detectors
do not provide volumetric area protection. They have multiple
beams of detection and motion can only be detected in unobstructed
areas covered by these beams. They cannot detect motion which
occurs behind walls, ceilings, floor, closed doors, glass partitions, glass
doors or windows. Any type of tampering whether intentional or unin-
tentional such as masking, painting, or spraying of any material on
the lenses, mirrors, windows or any other part of the detection sys-
tem will impair its proper operation.
Passive infrared motion detectors operate by sensing changes in tem-
perature. However their effectiveness can be reduced when the ambi-
ent temperature rises near or above body temperature or if there are
intentional or unintentional sources of heat in or near the detection
area. Some of these heat sources could be heaters, radiators, stoves,
barbeques, fireplaces, sunlight, steam vents, lighting and so on.
Warning Devices
Warning devices such as sirens, bells, horns, or strobes may not warn
people or waken someone sleeping if there is an intervening wall or
door. If warning devices are located on a different level of the res-
idence or premise, then it is less likely that the occupants will be
alerted or awakened. Audible warning devices may be interfered
with by other noise sources such as stereos, radios, televisions, air
conditioners or other appliances, or passing traffic. Audible warning
devices, however loud, may not be heard by a hearing-impaired per-
son.
Telephone Lines
If telephone lines are used to transmit alarms, they may be out of
service or busy for certain periods of time. Also an intruder may cut
the telephone line or defeat its operation by more sophisticated
means which may be difficult to detect.
Insufficient Time
There may be circumstances when the system will operate as inten-
ded, yet the occupants will not be protected from the emergency
due to their inability to respond to the warnings in a timely man-
ner. If the system is monitored, the response may not occur in time
to protect the occupants or their belongings.
Component Failure
Although every effort has been made to make this system as reli-
able as possible, the system may fail to function as intended due to
the failure of a component.
Inadequate Testing
Most problems that would prevent an alarm system from operating
as intended can be found by regular testing and maintenance. The
complete system should be tested weekly and immediately after a
break-in, an attempted break-in, a fire, a storm, an earthquake, an
accident, or any kind of construction activity inside or outside the
premises. The testing should include all sensing devices, keypads, con-
soles, alarm indicating devices and any other operational devices
that are part of the system.
Security and Insurance
Regardless of its capabilities, an alarm system is not a substitute for
property or life insurance. An alarm system also is not a substitute
for property owners, renters, or other occupants to act prudently to
prevent or minimize the harmful effects of an emergency situation.
IMPORTANT - READ CAREFULLY: DSC Software pur-
chased with or without Products and Components is
copyrighted and is purchased under the following
license terms:
lThis End-User License Agreement (“EULA”) is a legal agree-
ment between You (the company, individual or entity who
acquired the Software and any related Hardware) and Digital
Security Controls, a division of Tyco Safety Products Canada Ltd.
(“DSC”), the manufacturer of the integrated security systems and
the developer of the software and any related products or com-
ponents (“HARDWARE”) which You acquired.
lIf the DSC software product (“SOFTWARE PRODUCT” or
“SOFTWARE”) is intended to be accompanied by HARDWARE,
and is NOT accompanied by new HARDWARE, You may not
use, copy or install the SOFTWARE PRODUCT. The SOFTWARE
PRODUCT includes computer software, and may include asso-
ciated media, printed materials, and “online” or electronic doc-
umentation.
lAny software provided along with the SOFTWARE PRODUCT
that is associated with a separate end-user license agreement is
licensed to You under the terms of that license agreement.
lBy installing, copying, downloading, storing, accessing or oth-
erwise using the SOFTWARE PRODUCT, You agree uncon-
ditionally to be bound by the terms of this EULA, even if this
EULA is deemed to be a modification of any previous arrange-
ment or contract. If You do not agree to the terms of this
EULA, DSC is unwilling to license the SOFTWARE PRODUCT
to You, and You have no right to use it.
SOFTWARE PRODUCT LICENSE
The SOFTWARE PRODUCT is protected by copyright laws and inter-
national copyright treaties, as well as other intellectual property
laws and treaties. The SOFTWARE PRODUCT is licensed, not sold.
1. GRANT OF LICENSE This EULA grants You the following rights:
(a) Software Installation and Use - For each license You acquire,
You may have only one copy of the SOFTWARE PRODUCT
installed.
(b) Storage/Network Use - The SOFTWARE PRODUCT may not be
installed, accessed, displayed, run, shared or used concurrently on or
from different computers, including a workstation, terminal or other
digital electronic device (“Device”). In other words, if You have sev-
eral workstations, You will have to acquire a license for each work-
station where the SOFTWARE will be used.
(c) Backup Copy - You may make back-up copies of the
SOFTWARE PRODUCT, but You may only have one copy per
license installed at any given time. You may use the back-up copy
solely for archival purposes. Except as expressly provided in this
EULA, You may not otherwise make copies of the SOFTWARE
PRODUCT, including the printed materials accompanying the
SOFTWARE.
2. DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS
(a) Limitations on Reverse Engineering, Decompilation and Disas-
sembly - You may not reverse engineer, decompile, or disassemble
the SOFTWARE PRODUCT, except and only to the extent that such
activity is expressly permitted by applicable law notwithstanding this
limitation. You may not make any changes or modifications to the
Software, without the written permission of an officer of DSC. You
may not remove any proprietary notices, marks or labels from the
Software Product. You shall institute reasonable measures to ensure
compliance with the terms and conditions of this EULA.
(b) Separation of Components - The SOFTWARE PRODUCT is
licensed as a single product. Its component parts may not be sep-
arated for use on more than one HARDWARE unit.
(c) Single INTEGRATED PRODUCT - If You acquired this
SOFTWARE with HARDWARE, then the SOFTWARE PRODUCT is
licensed with the HARDWARE as a single integrated product. In this
case, the SOFTWARE PRODUCT may only be used with the
HARDWARE as set forth in this EULA.
(d) Rental - You may not rent, lease or lend the SOFTWARE
PRODUCT. You may not make it available to others or post it on a
server or web site.
(e) Software Product Transfer - You may transfer all of Your rights
under this EULA only as part of a permanent sale or transfer of the
HARDWARE, provided You retain no copies, You transfer all of the
SOFTWARE PRODUCT (including all component parts, the media
and printed materials, any upgrades and this EULA), and provided
the recipient agrees to the terms of this EULA. If the SOFTWARE
PRODUCT is an upgrade, any transfer must also include all prior ver-
sions of the SOFTWARE PRODUCT.
f) Termination - Without prejudice to any other rights, DSC may ter-
minate this EULA if You fail to comply with the terms and con-
ditions of this EULA. In such event, You must destroy all copies of
the SOFTWARE PRODUCT and all of its component parts.
(g) Trademarks - This EULA does not grant You any rights in con-
nection with any trademarks or service marks of DSC or its sup-
pliers.
3. COPYRIGHT - All title and intellectual property rights in and to
the SOFTWARE PRODUCT (including but not limited to any
images, photographs, and text incorporated into the SOFTWARE
PRODUCT), the accompanying printed materials, and any copies of
the SOFTWARE PRODUCT, are owned by DSC or its suppliers. You
may not copy the printed materials accompanying the SOFTWARE
PRODUCT. All title and intellectual property rights in and to the
content which may be accessed through use of the SOFTWARE
PRODUCT are the property of the respective content owner and may
be protected by applicable copyright or other intellectual property
laws and treaties. This EULA grants You no rights to use such con-
tent. All rights not expressly granted under this EULA are reserved
by DSC and its suppliers.
4. EXPORT RESTRICTIONS - You agree that You will not export or
re-export the SOFTWARE PRODUCT to any country, person, or
entity subject to Canadian export restrictions.
5. CHOICE OF LAW - This Software License Agreement is governed
by the laws of the Province of Ontario, Canada.
6. ARBITRATION - All disputes arising in connection with this
Agreement shall be determined by final and binding arbitration in
accordance with the Arbitration Act, and the parties agree to be
bound by the arbitrator’s decision. The place of arbitration shall be
Toronto, Canada, and the language of the arbitration shall be Eng-
lish.
7. LIMITED WARRANTY
(a) NO WARRANTY - DSC PROVIDES THE SOFTWARE “AS IS”
WITHOUT WARRANTY. DSC DOES NOT WARRANT THAT THE
SOFTWARE WILL MEET YOUR REQUIREMENTS OR THAT
OPERATION OF THE SOFTWARE WILL BE UNINTERRUPTED OR
ERROR-FREE.
(b) CHANGES IN OPERATING ENVIRONMENT - DSC shall not be
responsible for problems caused by changes in the operating char-
acteristics of the HARDWARE, or for problems in the interaction of
the SOFTWARE PRODUCT with non-DSC-SOFTWARE or
HARDWARE PRODUCTS.
(c) LIMITATION OF LIABILITY; WARRANTY REFLECTS
ALLOCATION OF RISK - IN ANY EVENT, IF ANY STATUTE
IMPLIES WARRANTIES OR CONDITIONS NOT STATED IN THIS
LICENSE AGREEMENT, DSC’S ENTIRE LIABILITY UNDER ANY
PROVISION OF THIS LICENSE AGREEMENT SHALL BE LIMITED
TO THE GREATER OF THE AMOUNT ACTUALLY PAID BY YOU
TO LICENSE THE SOFTWARE PRODUCT AND FIVE CANADIAN
DOLLARS (CAD$5.00). BECAUSE SOME JURISDICTIONS DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
(d) DISCLAIMER OF WARRANTIES - THIS WARRANTY
CONTAINS THE ENTIRE WARRANTY AND SHALL BE IN LIEU
OF ANY AND ALL OTHER WARRANTIES, WHETHER EXPRESSED
OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE)
AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON THE
PART OF DSC. DSC MAKES NO OTHER WARRANTIES. DSC
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON
PURPORTING TO ACT ON ITS BEHALF TO MODIFY OR TO
CHANGE THIS WARRANTY, NOR TO ASSUME FOR IT ANY
OTHER WARRANTY OR LIABILITY CONCERNING THIS
SOFTWARE PRODUCT.
(e) EXCLUSIVE REMEDY AND LIMITATION OF WARRANTY -
UNDER NO CIRCUMSTANCES SHALL DSC BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT
DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF
CONTRACT, NEGLIGENCE, STRICT LIABILITY, OR ANY OTHER
LEGAL THEORY. SUCH DAMAGES INCLUDE, BUT ARE NOT
LIMITED TO, LOSS OF PROFITS, LOSS OF THE SOFTWARE
PRODUCT OR ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL,
COST OF SUBSTITUTE OR REPLACEMENT EQUIPMENT,
FACILITIES OR SERVICES, DOWN TIME, PURCHASERS TIME,
THE CLAIMS OF THIRD PARTIES, INCLUDING CUSTOMERS, AND
INJURY TO PROPERTY.
WARNING: DSC recommends that the entire system be completely
tested on a regular basis. However, despite frequent testing, and due
to, but not limited to, criminal tampering or electrical disruption, it
is possible for this SOFTWARE PRODUCT to fail to perform as
expected.
Simplified EU Declaration of Conformity
Hereby, Bentel Security S.r.l. declares that the radio equipment type BW-PGH is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
BW-PGH: www.bentelsecurity.com/dc
Frequency band and Maximum power
868.0 MHz - 868.6 MHz: 10 mW
868.7 MHz - 869.2 MHz: 10 mW
European single point of contact: Bentel Security, via Gabbiano 22, 64013 Corropoli (TE), Italy.
W.E.E.E. Product Recycling Declaration
For information regarding the recycling of this product you must contact the company from which you originally pur-
chased it. If you are discarding this product and not returning it for repair then you must ensure that it is returned as
identified by your supplier. This product is not to be thrown away with everyday waste. Directive 2012/19/EU Waste
Electrical and Electronic Equipment.
© 2020 Johnson Controls. All rights reserved. JOHNSON CONTROLS, TYCO and BENTEL SECURITY are trademarks of
Johnson Controls.
www.bentelsecurity.com.
- 12 -
Guide d’installation
AVERTISSEMENT: Le présent manuelcontient des informations relativesaux limitationsconcernant l'uti-
lisationet lesfonctionnalités duproduit ainsique leslimitationsde la responsabilité dufabricant. Lisez atten-
tivement le manueldanssonintégralité.
Émetteur-récepteur PowerG BW-PGH
Table des Matières
Spécificationset caractéristiques 15
Dispositifssansfilcompatibles 15
Mesuresde sécurité 16
Introduction 17
Commandesetindicateurs 17
Voyants d'état 17
Fixation 18
Attribuer leBW-PGH 18
Attribuer leBW-PGH 19
Fixerde façon permanente 19
Programmationet configuration de dispositif sansfil 19
- 14 -
Spécifications et caractéristiques
lCourant absorbé: 60mA
lTension: l’alimentation est fournie par la centrale d’alarme Absoluta Plus/Absoluta 630
(10,8VDC à 12,5VDC) - (Alimentation électrique limitée)
lFréquence: 868 MHz (BW-PGH)
lZones: peut recevoir les signaux de 128 zones sans fil. Peut aussi prendre en charge jusqu’à 32
clés sans fil
lSupervision: fenêtre de supervision programmable
lPeut être câblé jusqu'à 230 m de la centrale avec un câble de calibre 0,34 mm2
lSe connecte au bus Tranceiver Bus
lCompatibilité: L'émetteur-récepteur BW-PGH est utilisé avec les centrales d'alarme Absoluta
Plus/Absoluta 630
lTempérature de fonctionnement: EU = -10°C à +55°C
lHumidité relative: 93% sans condensation
lContacts anti-sabotage séparés de boîtier et à montage mural intégré
Dispositifs sans fil compatibles
Reportez-vous au site Web de Bentel pour la liste mise à jour des appareils radio PowerG et des unités
de contrôle compatibles.
- 15 -
Mesures de sécurité
lL'équipement doit être installé uniquement par des agents de service (un agent de service est une
personne qui a reçu une formation technique adéquate et qui a l'expérience nécessaire des risques
encourus lors de l'installation et de l'utilisation de cet équipement pour réduire les risques pour soi
ou pour les autres personnes). Il doit être installé et utilisé uniquement dans un environnement inté-
rieur non dangereux (de pollution de type2 au max. et de catégorieII de surtension).
lL’installateur est responsable de l’instruction de l’utilisateur du système en ce qui concerne les
mesures de sécurité électriques à respecter lors de l’utilisation d’un système qui inclut cet équi-
pement et aussi en ce qui concerne chacun des points suivants:
lN’essayez pas de réparer ce produit. Cet appareil ne contient aucune pièce réparable par
l'utilisateur. Toute réparation doit être confiée uniquement à des techniciens qualifiés.
lIl faut utiliser des moyens de montage adéquats (par ex.: chevilles en plastique/métal) pour fixer
l'émetteur sur la structure du bâtiment avant de mettre sous tension.
lLe câblage interne peut être placé de manière à empêcher :
lUne tension excessive sur les fils et les bornes;
lLe desserrage des bornes;
lL’endommagement de l’isolant du conducteur.
- 16 -
Introduction
L’émetteur-récepteur sans fil bidirectionnel BW-PGH ajoute des capacités de transmission sans fil aux
centrales d’alarme Absoluta Plus/Absoluta 630, modèles ABS-18, ABS-48, ABS-128, ABS-128G3 ou
ABS-630. Ce manuel décrit la méthode d'installation, de programmation et de maintenance du module
BW-PGH.
Commandes et indicateurs
Voyants d'état
Les voyants lumineux en façade du module BW-PGH fournissent des indications sur l'installation, le
fonctionnement et le dépannage de l'unité. La fonction des voyants est indiquée comme suit:
Voyantrouge Fonctionnement
Mise soustensionde module: Estalluméencontinulorsde laséquencededémarragedumodule puis
s'éteint.
Mise à jourdumicrologiciel: Clignotement lent = mise à jour en cours
Clignotement rapide = échec de la mise à jour
Problème: lAucun problème: 1 clignotement rapide toutes les 10
secondes.
Sidesproblèmessontprésents,une sériedeclignotementssepro-
duittoutesles2secondes.Chaque série declignotementsindique
unproblèmecomme suit:
l1 clignotement: Module sans attribution
l2 clignotements: Perte de contact avec le module pendant
plus de 60 secondes
l3 clignotements: Basse tension du Tranceiver Bus
l8 clignotements: Interférence RF (état de brouillage)
Confirmationde module: Clignoterapidementpendantle processusde confirmationde module.
Testdepositionnement: Reste alluméquandl'emplacementestmauvais.Éteintquandl'em-
placementestbon.
Voyantvert Fonctionnement
Testdepositionnement: Reste allumé quand l'emplacement convient. Éteint quand l'em-
placement ne convient pas.
Contact anti-sabotage
Le module BW-PGH possède des contacts anti-sabotage séparés de boîtier et à montage mural intégré.
Activez ou désactivez le contact anti-sabotage mural en serrant solidement le support détachable au
mur à l'aide d'une des vis fournies.
Le contact anti-sabotage de boîtier est activé quand le boîtier est ouvert et il est rétabli quand le boîtier
est refermé. Le contact anti-sabotage mural sur l'arrière de l'unité est enfoncé par la surface d'appui
quand il est correctement installé. Si l'unité est détachée, le contact anti-sabotage est activé. Vérifiez
que la surface d'appui est lisse et sans obstacles qui bloqueraient l'accès à l'arrière de l'unité. Les câbles
électriques ne devraient pas passer sur ou sous le module quand il est fixé.
- 17 -
Fixation
Remarque: Fixez de façon permanente le récepteur du module BW-PGH et les dispositifs sans fil
APRÈS avoir testé leur emplacement.
Trouvez un emplacement qui est:
lsec,
ldans la plage de température de fonctionnement,
lau centre de la position prévue de tous les autres dispositifs sans fil,
lle plus haut possible. La portée est réduite si le montage est réalisé au niveau du sol,
lloin des sources d'interférence, y compris: bruit électrique (ordinateurs, téléviseurs, moteurs et
appareils électriques, appareils de chauffage ou climatiseurs d'air), objets métalliques imposants
comme les conduites de chauffage ou de plomberie qui peuvent masquer les ondes élec-
tromagnétiques,
llisse et sans obstacles qui bloqueraient l'accès à l'arrière de l'unité.
Attribuer le BW-PGH
Prudence: Supprimez toutes les sources d'alimentation (secteur, continue, lignes téléphonique) du sys-
tème lors de la connexion des modules au bus Tranceiver Bus.
Attribuer le BW-PGH
1. La centrale d’alarme étant hors tension, connectez le module BW-PGH aux quatre fils du
bus Tranceiver Bus de la centrale d'alarme selon la Figure 1.
2. Une fois le câblage complété, mettez sous tension le système de sécurité.
Figure: 1 Schéma de câblage : 1) Centrale; 2) Tranceiver Bus vers BW-PGH
- 18 -
Attribuer le BW-PGH
Le module BW-PGH doit être attribué sur la centrale d'alarme avant que tout dispositif sans fil puisse
être attribué.
Reportez-vous aux instructions de l’unité d’alarme pour la procédure.
Fixer de façon permanente
Une fois l'emplacement convenable trouvé, fixez le module BW-PGH comme suit:
1. Faites passer les câbles Tranceiver Bus à travers les trous à l'arrière de l'armoire.
2. Fixez solidement l'armoire au mur à l'aide des trois vis fournies.
3. Pour activer le contact anti-sabotage mural, serrez solidement son support détachable au
mur à l'aide des vis fournies.
Figure : 2 Fixation du module BW-PGH
Programmation et configuration de dispositif sans fil
Reportez-vous aux instructions de l’unité d’alarme pour la procédure.
- 19 -
GARANTIE LIMITÉE
Digital Security Controls garantit le produit contre toute défec-
tuosités matérielles et d'assemblage dans des conditions normales
d'utilisation, à l'acheteur original pendant une période de douze mois
à partir de la date d'achat. Pendant la période de garantie, Digital
Security Controls s'engage, à son choix, à réparer ou à remplacer
tout matériel défectueux dès son retour à un dépôt de réparation,
sans frais de main d'œuvre et matériels. Tout remplacement et/ou
réparation sont garantis pendant le reste de la durée de la garantie
originale ou quatre-vingt dix (90) jours, selon la plus longue. L'ache-
teur original doit avertir Digital Security Controls par courrier que
le matériel ou l'assemblage est défectueux ; dans tous les cas, cette
notification doit être reçue avant l'expiration de la période de garan-
tie. Il n'y a absolument aucune garantie sur les logiciels et tous les
logiciels sont vendus comme licence d'utilisateur dans le cadre des
termes du contrat de licence du logiciel fourni avec le produit. Le
client assume toute la responsabilité pour la sélection, installation,
et l'entretien de tout produit acheté auprès de DSC. Les produits per-
sonnalisés ne sont garantis que dans la mesure où ils ne fonctionnent
pas à la livraison. Dans ce cas, DSC peut, à son choix, remplacer le
produit ou crédit le client.
Garantie internationale
La garantie pour les clients internationaux est la même que pour
tous les clients au Canada et aux Etats-Unis, sauf que Digital Secu-
rity Controls ne sera pas tenu responsable des frais de douanes, taxes
ou TVA qui pourraient être dus.
Procédure pour la garantie
Pour obtenir un service sous garantie, veuillez retourner les produit(s)
en question au point d'achat. Tous les distributeurs et vendeurs auto-
risés ont un programme de garantie. Quiconque retourne des mar-
chandises à Digital Security Controls doit obtenir au préalable un
numéro d'autorisation. Digital Security Controls n'acceptera aucun
envoi pour lequel une autorisation préalable n'aura pas été obtenue.
Conditions d'annulation de la garantie
Cette garantie ne s'applique qu'aux vices de matériels et d'as-
semblage liés à une utilisation normale. Elle ne couvre pas :
lles dommages encourus lors de l'expédition ou la manu-
tention ;
lles dommages causés par un désastre tel qu'un incendie, inon-
dation, vent, tremblement de terre ou foudre ;
lles dommages dus à des causes hors de contrôle de Digital
Security Controls tels qu'une tension excessive, choc méca-
nique ou dégât des eaux ;
lles dommages causés par attachement non autorisé, chan-
gements, modifications ou objets étrangers ;
lles dommages causés par des périphériques (à moins que de
tels périphériques n'aient été fournis par Digital Security Con-
trols Ltd.) ;
lles défauts causés par l'impossibilité de fournir un envi-
ronnement d'installation adapté aux produits ;
lles dommages causés par l'utilisation des produits pour des
usages autres que ceux pour lesquels ils ont été conçus ;
lles dommages découlant d'un mauvais entretien ;
lles dommages provenant de tout autre mauvais traitement,
manutention ou utilisation des produits.
Éléments non couverts par la garantie
En plus des éléments qui annulent la garantie, la garantie ne cou-
vrira pas: (i) les frais de transport au centre de réparation ; (ii) les
produits qui ne sont pas identifiés avec l'étiquette de produit de
DSC et un numéro de lot ou un numéro de série ; (iii) les produits
démontés ou réparés de manière qui affecte la performance ou qui
empêche une inspection ou un test adéquats afin de vérifier toute
réclamation au titre de la garantie. Les cartes d'accès ou insignes
renvoyés pour être remplacées au titre de la garantie seront rem-
placées ou créditées selon le choix de DSC. Les produits qui ne sont
pas couverts par cette garantie ou qui ne sont plus garantis parce
qu'ils sont trop vieux, qu'ils ont été mal utilisés ou endommagés,
seront examinés et une devis de réparation sera fourni. Aucune répa-
ration ne sera effectuée avant la réception d'un bon de commande
valable envoyé par le client et d'un numéro d'autorisation de renvoi
de marchandise (RMA) envoyé par le service client de DSC.
S'il y a un problème de réparation du produit après un nombre rai-
sonnable de tentatives au titre de la présente garantie, les obli-
gations contractuelles de la société Digital Security Controls seront
limitées au remplacement du produit, comme seule réparation de
l'inobservation de la garantie. En aucun cas Digital Security Controls
ne sera tenu responsable des dommages particuliers, accidentels ou
indirects basés sur l'inobservation de la garantie, une rupture de
contrat, une négligence, une responsabilité stricte ou sur toute autre
théorie juridique. De tels dommages incluent, mais ne sont pas limi-
tés à, une perte de profit, une perte de produit ou tout autre équi-
pement associé, au coût du capital, coût de remplacement de
l'équipement, à l'aménagement ou services, à l'indisponibilité, au
temps de rachat, aux réclamations des tiers, notamment les clients,
aux dommages et intérêts à la propriété. Dans certaines juridictions,
la loi limite ou ne permet pas une exonération de garantie en cas
de dommages indirects. Si les lois d'une telle juridiction s'appliquent
à une réclamation par ou contre DSC, les limites et les exonérations
contenues dans la présente garantie respecteront la loi. Certains
Etats ne permettent pas l'exonération ou la limite de dommages
accidentels ou indirects, la déclaration ci-dessus pourrait donc ne pas
s'appliquer à votre cas.
Stipulation d'exonération de garanties
Cette garantie contient l'entière garantie et remplace toutes les
autres garanties, qu'elles soient explicites ou implicites (notamment
toutes les garanties implicites de marchandise ou aptitude pour un
usage particulier) et de toute autre obligation ou responsabilité de
Digital Security Controls. Digital Security Controls n'assume et n'au-
torise aucune autre personne prétendant agir en son nom de modifier
ou changer cette garantie, n'assume pour cela aucune autre garantie
ou responsabilité concernant ce produit. Cette exonération de garan-
ties et garantie restreinte sont gouvernées par les lois de la province
de l'Ontario, Canada.
AVERTISSEMENT: Digital Security Controls recommande que la
totalité du système soit testé régulièrement. Toutefois, même si vous
faites des tests périodiques, il peut arriver que le fonctionnement du
produit ne soit pas conforme aux spécifications en raison notamment,
mais pas exclusivement, d’interventions criminelles ou de panne de
courant.
Réparations en dehors de la garantie
Digital Security Controls réparera à son choix ou remplacera en
dehors de la garantie les produits renvoyés à son usine dans les
conditions suivantes. Quiconque retourne des marchandises à Digital
Security Controls doit obtenir au préalable un numéro d'autorisation.
Digital Security Controls n'acceptera aucun envoi pour lequel une
autorisation préalable n'aura pas été obtenue.
Les produits que Digital Security Controls juge être réparables seront
réparés et renvoyés. Les frais prédéterminés par Digital Security Con-
trols et sujets à une révision périodique, seront facturés pour chaque
unité réparée.
Les produits que Digital Security Controls juge ne pas être répa-
rables seront remplacés par le produit équivalent le plus proche dis-
ponible à ce moment. Le prix du marché en cours du produit de
remplacement sera facturé pour chaque unité de remplacement.
Table of contents
Languages:
Other Johnson Controls Transceiver manuals
