Joivi Wicker JOV-13 User manual

Wicker Sofa Set
sku:JOV-13
W
A
R
R
A
N
T
Y
1
Y
E
A
R
1
Thank you for choosing Joivi!
Our goal is to provide high quality outdoor furniture with
outstanding customer service-all at an affordable price.
Please let us know how we are doing!
Problems?
(Missing pieces, wrong pieces...)
We will fix it immediately. Send us an email at
[email protected].
Happy?
Please leave us a review!
You can make others happy too!

IMPORTANT, RETAIN FOR
FUTURE REFERENCE:
READ CAREFULLY.
Safety
For domestic use only.
Don't tighten all the bolts before the product is fully assembled.



Periodic structural checks of this product should be
It would be useful to ask someone to help you assemble
the product.
undertaken, do not use if you have any doubts about its
Do not stand on the seat and table.
Do not sit on the armrest and table.
Do not let children play with this product.
Maximum load per seat: 250 lbs.
At the beginning of the season

product are secure, do not use if you have any doubts
At the end of the season
This product should be stored under cover during
prolonged spells of adverse weather (wet or cold) and
also during the winter (ideally in a garden shed or
garage).
Always clean and dry thoroughly before storage.
- 1 -

Tips for Cushions
1
3
OK
2
In order to compress the package, we put the cushions in
the gap of some parts. So there may be crinkle on the fabric.
Don’t worry. Just flap every corner of the cushion evenly and
it will get back into its original shape soon.
- 2 -

- 3 -
Item
no.
Reference
Image Description Qty.
P
O
J
K
E
D
L
Table side
Panel
Table side
Panel
Table Glass
COMPONENT LIST - TABLE
Table top
frame
2
2
1
1
12
12
1
Washer
M6X35
Head Cap Screws
Allen Key
NOTE:
Do NOT tighten any screws fully first until you have tightened all the
screws.
This may cause the frame to warp.
If there is still wobbles or screw holes cannot be aligned, loosen the
screws and tighten sequentially.
If the Table is not stable it could lead to damage to the product.

Attach the Table side Panel (P) to the Table side Panel (O) by securing with
M6X35 Head Cap Screws (E) and Washers (D). Do this in 8 places.
1
- 4 -
x8
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
8
O
O
P
P
DE

Attach the Table side Panel (O) to the Table Top frame (J) by securing with
M6X35 Head Cap Screws (E) and Washers (D). Do this in 4 places.
2
- 5 -
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
4
O
J
P
DE

- 6 -
Put the Table Glass (K) on the Table.
Your table is ready for use.
3
x12
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.
Tighten all 12 Screws into place with
Allen Key (L).
4
K

D38
Washer
- 7 -
Item
no.
Reference
Image Description Qty.
A
B
C
R
Seat Back
Side Panel
COMPONENT LIST - SOFA SET
Armrest
Seat Base
1
A1 Seat Back 1
1
1
1
GSide Panel 2
B1 Armrest 1
C1 Seat Base 1
MSide Panel 1

E26
M6X35
Head Cap Screws
F6
M6X50
Head Cap Screws
L
Q
N
1
6
1
Allen Key
NOTE:
Do NOT tighten any screws fully first until you have tightened all the
screws.
This may cause the frame to warp.
If there is still wobbles or screw holes cannot be aligned, loosen the
screws and tighten sequentially.
If the Sofa Set is not stable it could lead to damage to the product.
- 8 -
Item
no.
Reference
Image Description Qty.
HSeat Cushion
COMPONENT LIST - SOFA SET
2
IBack Cushion 3
Wrench
Nut

- 9 -
Option 2: Chaise on the left
Option 1: Chaise on the right
Note:This chaise can be assembled on the
left or on the right like picture shown. You
can choose the way you like to assemble.

Assembly: Chaise on the right
- 10 -
Attach the Seat Back (A) to the Armrest (B) by securing with M6*35 Head Cap
Screws (E) and Washers (D). Do this in 2 places.
1
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
2
B
ADE

- 11 -
Attach the Seat Base (C) to the Seat Back (A) and the Armrest (B) by securing
with M6*35 Head Cap Screws (E) and Washers (D). Do this in 4 places.
2
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
4
B
A
C
DE

- 12 -
A
2
Attach the Side Panel (R) to the Seat Base (C) by securing with M6*35 Head
Cap Screws (E) and Washers (D). Do this in 2 places.
3
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
B
C
R
DE

- 13 -
A
G
6
B
C
R
G
Attach the Side Panel (G) to the Side Panel (R) and the Armrest (B) by
securing with M6*35 Head Cap Screws (E) and Washers (D). Do this in 4
places.
And attached the other Side Panel (G) to the Side Panel (R) by securing with
M6*35 Head Cap Screws (E) and Washers (D). Do this in 2 places.
4
x6
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
DE

5
x14
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.
Tighten all 14 Screws into place with Allen Key (L).
Chaise is completed.
- 14 -

- 15 -
2
A1
B1
Attach the Seat Back (A1) to the Armrest (B1) by securing with M6*35 Head
Cap Screws (E) and Washers (D). Do this in 2 places.
6
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
DE

- 16 -
5
A1
B1
C1
Attach the Seat Base (C1) to the Seat Back (A1) and the Armrest (B1) by
securing with M6*35 Head Cap Screws (E) and Washers (D). Do this in 5
places.
7
x5
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
DE

- 17 -
5
B1
M
A1
C1
Attach the Side Panel (M) to the Seat Base (C1) and the Armrest (B1) by
securing with M6*35 Head Cap Screws (E) and Washers (D). Do this in 5
places.
8
x5
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
DE

9
x12
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.
Tighten all 12 Screws into place with Allen Key (L).
Loveseat is completed.
- 18 -

I
H
- 19 -
6
Attach the loveseat to the assembly by threading M6*50 Head Cap Screws
(F) with Washers (D) through the chaise and securing into place
with Washers (D) and Nut (Q).Tighten into place with Allen Key (L)
and Wrench (N). Do this in 6 places.
10
Place the sofa on a level surface.
Place Seat Cushions (H) and Back Cushions (I) on the sofa.
Chaise on the right assembly is completed and your sofa is ready for use.
11
DDQ
F
