joke mikromat 600 eco User manual

mikromat 600 eco
Fine Dry Blasting Unit
Instruction Manual

1
List of contents
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
2
1 List of contents .................................................................................... Page 02
2 Tips on using the manual................................................................... Page 03
3 Safety instructions ............................................................................... Page 04
4 Warranty .............................................................................................. Page 07
5 Device overview................................................................................. Page 08
6 Technical data.................................................................................... Page 14
7 Processing instructions ....................................................................... Page 15
8 Troubleshooting .................................................................................. Page 16
9 Care and maintenance.................................................................... Page 18
10 Blasting shot......................................................................................... Page 19
11 Telefax form ......................................................................................... Page 21

2
Tips on using the manual
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
3
This manual has been written for the device user to ensure a prob-
lem-free operation, care and maintenance.
Important instructions and information concerning safety and op-
erational reliability have been highlighted.
The symbols used in the manual have the following meanings:
Working and operating processes which must be observed to the
letter to exclude any risk to persons.
CAUTION!
IMPORTANT! Working and operating processes which must be observed to the
letter to avoid any damage to the device.
INFORMATION! Technical information to which the device operator must give spe-
cial attention.
The illustrations and diagrams are numbered in sequence within each
chapter. Some of these illustrations have keys. References to illustrations
within the text e. g. (5.1/2) have the following meaning:
5.1 = Figure 5.1
2 = Position 2 in the key to the figure.
Please feel free to call our customer service department at any time should
you encounter technical problems which are not dealt with in this manual:
Telephone [phone] / 8 39 - 0
Telefax +49 (0) 22 04 / 8 39 - 86
INFORMATION! www.joke.de
Spare parts lists and instruction manuals for our products can be found on
the Internet.

3
Safety instructions
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
4
This device has been built according to the latest technical stan-
dards and generally accepted safety regulations. Nevertheless, it
can constitute a risk to the operator or third parties and a hazard to
the device itself or other equipment during use.
IMPORTANT! (1) Only use the device if in perfect working order and for its in-
tended purpose. You must always pay attention to the instruc-
tion manual and safety instructions therein and be aware of the
risks! Repair any faults which could affect the device’s safety
immediately by yourself or have these repaired.
The device is intended exclusively for fine dry blasting of work-
pieces made of metal, non-ferrous metals and plastics. Any
other use will be deemed to be contrary to its intended pur-
pose. The manufacturer cannot be held liable for any resulting
damages. The risk is borne solely by the user.
Correct use also includes compliance with the instruction man-
ual and an observation of the care and maintenance condi-
tions.
(2) Keep the instruction manual handy at the device’s place of
use.
(3) Pay attention to and observe generally applicable statutory
and otherwise binding regulations relating to accident preven-
tion and environmental protection in addition to the information
provided in the instruction manual!
CAUTION!
(4) All personnel commissioned to work on or with the device must
have read this instruction manual, and particularly the safety in-
structions chapter, before starting work. This applies especially
for personnel who only work with the device occasionally.
(5) Stop the device immediately should you notice changes to the
device or its operating behaviour that are relevant to its safety.
Have these remedied.
IMPORTANT! (6) Observe safety instructions on the device and ensure they re-
main legible.
(7) Stop the device immediately should you notice changes to the
device or its operating behaviour that are relevant to its safety.
Have these remedied.

3
Safety instructions
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
5
(8) Do not carry out any modifications, additions or conversions to
the device!
This also applies to the installation and adjustment of safety
equipment..
IMPORTANT!
(9) Spare parts must meet the technical requirements specified by
the manufacturer. This can only be guaranteed with original
JOKE spare parts.
(10) Any work on/with the device may only be carried out by quali-
fied, appropriately trained and authorised personnel. Pay atten-
tion to minimum statutory age limits!
(11) Personnel undergoing training or in a general apprenticeship
should only be allowed to work with the machine under the
constant supervision of an experienced operator!
(12) Work on the electrical equipment of the device may be per-
formed only by an electrical specialist according to electro-
technical regulations.
(13) Refrain from any type of work that could jeopardise your safety.
(14) The device may only be used if all protective and safety
equipment is in place and in proper working order.
(15) Do not leave the device unattended when switched on!
(16) Stop and secure the device immediately in the event of mal-
functions! Faults must remedied at once.
(17) Observe processes for switching on and off and control indica-
tors according to the instruction manual!
(18) The mains cable, foot switch cable and compressed-air line
must be laid so as to be tension free and not hinder the user.
Nothing must be allowed to stand on the cables.
(19) The device must be operated only in dry rooms and must not
under any circumstances be exposed to moisture.
The device has no explosion protection!

3
Safety instructions
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
6
IMPORTANT! (20) It is essential to observe the manufacturer’s processing instruc-
tions in handling the blasting shot
(21) Working with explosive blasting shots is forbidden.
CAUTION!
(22) Workpieces that result in explosive dusts must not be processed
with this unit.
CAUTION!
CAUTION! (23) Working with poisonous substances or blasting shots that give off
poisonous substances is not allowed.
CAUTION! (24) Workpieces that release poisonous substances must not be
processed.
(25) Do not start the blasting process with the foot pedal until having
locked the flap door and reaching with both hands through the
hand holes.
End the blasting process only using the foot pedal and not by
raising the flap door.
CAUTION! (26) Do not wear any synthetic clothing on the body, in order to
avoid static charge. Wear appropriate conductive working
shoes. Depending on the blasting shot and weather, wear anti-
static armbands earthed to the unit.
CAUTION! (27) Do not remove blasting shot from the unit manually or by com-
pressed air, but exclusively with aid of a tool.
(28) Dispose of or replace used blasting shot environment-
consciously and in accordance with regulations.
(29) Immediately replace windows that are damaged or have be-
come opaque.
(30) Replace damaged gloves immediately.

4
Warranty
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
7
Joisten & Kettenbaum warrant the correct manufacture of every
Joisten & Kettenbaum product which is delivered in accordance
with the terms of contract and delivery.
This warranty does not cover wearing parts or components carrying
blasting shot as well as damages caused by normal wear and tear,
incorrect handling, negligent use, the fitting of non-original spare
parts, inadequate care and/or a failure to comply with this techni-
cal manual.
The device may only be used by appropriately trained personnel. If
it is not, all warranty claims will be forfeited according to the terms of
delivery.

5
Device overview
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
8
Intended use
The device is intended for abrasive material processing by fine blast-
ing with various blasting media.
Among others, the following blasting processes are possible:
• Scale removing after hardening.
• Smoothing of plastic and diecasting moulds, compression
moulding dies and embossing dies.
• Shot peening of wearing parts.
• Derusting and removing of lacquer of/from components.
• Deburring of metal components after machining (e.g. turn-
ing, drilling, milling) and of duroplastic mouldings from injec-
tion moulding and shaped casting).
• Cleaning of plastic and rubber moulds, welds and soldered
parts.
• Preparation of surfaces for paint spraying, gluing and elec-
troplating.
• Matting and brightening (decorative blasting).
The application possibilities are versatile by:
• Use of mixed grit and glass bead blasting shots.
• Use of different grid sizes:
The precisely balanced relationship between the dosing cup
and blasting gun in addition to the special filter system allows
the use of all commercially available blasting media. Grit sizes
of between 1 mm (approx. 20 mesh) and 0.01 mm (approx.
400 mesh) can be processed.

5
Device overview
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
9
Installation and starting the unit for the first time
Installation site
The unit must not be installed in an environment where there is a risk
of explosion or in rooms with a risk of explosion.
The unit must not be installed in damp rooms or in rooms with high
relative humidity.
Machine connections
Only connect the unit via a plug connector that allows disconnec-
tion from the electrical mains. The electrical connection must be
made according to the details on the rating plate and this operat-
ing manual.
The compressed air supply (input pressure) must not exceed 8 bar.
The unit operator must provide for a shutoff valve in the compressed
air connection line on the customer’s side, allowing disconnection of
the unit from the supply network.

5
Device overview
E®instruction manual
Fine dry blasting unit mikromat 600 eco
10
Overview of entire unit
Fig. 5.1
JOK
1 Main switch
2 Start button and indicator light
3 Working pressure controller
4 Working pressure gauge
5 Air inlet
6 Run-off container
7 Afterfilter with cartridge, 120 x 1000 m
8 Microblast blasting device
9 Microblast foot switch
10 Blasting unit foot switch
11 Filter cartridges, 240 x 600 mm
12 Dust bag

5
Device overview
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
11
Installation and starting the unit for the first time
In order to prevent the blasting shot contained in the cabin from
absorbing humidity, the unit should always be installed in a dry
place. This of course also applies to the storage place of the blasting
shot.
Before using the unit for the first time, the air treatment unit must be
installed on the right-hand side of the machine. The hand crank of
the filter-dust removal device must also be installed on the shaker
rod axle on the left-hand side.
1. A water separator is incorporated in the air treatment unit
in order to eliminate the water in the compressed air.
Care should be taken during installation that the water
separator is in the upright position.
2. The pressure gauge is screwed to the air treatment unit.
The desired blasting pressure is set at the pressure relief
valve. This pressure can be read on the pressure gauge.
3. The electrical connection is single phase, 220 V light cur-
rent. The green/yellow cable forms the earth lead.
4. The entire unit is switched on and off using the main
switch. In the “0” position, the unit is switched off. In the
“1” position, the unit and cabin lighting are switched on
simultaneously. In the “2” position, the fan is activated. The
latter creates negative pressure inside the cabin and en-
sures a clear view during the blasting process.
The fan must be switched off when the cabin remains
open for a prolonged period, during cleaning the main fil-
ter and when changing the blasting shot.
5. The control light only illuminates when the fan is switched
on. It simultaneously serves as a fuse holder and is
equipped with a 2 A / 250 V fine fuse. In case of overload,
the fine fuse burns out and the control light goes out. The
cap with the fuse holder can be unscrewed and the fuse
can be replaced by turning anticlockwise while simulta-
neously applying pressure to the front panel.
6. The electric foot switch operates the solenoid valve incor-
porated in the machine, which releases the compressed
air to the blasting gun. This only works with the fan running.

5
Device overview
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
12
7. The safety end switch serves to interrupt the blasting proc-
ess if the cabin hood is open. If the cabin is opened during
blasting, the blasting process is interrupted automatically
in order to avoid accidents.
8. The dosing system and run-off container is equipped with
a patent quick-release lock.
9. The two screws on the cabin lid secure the window frame
and must be loosened in order to replace the viewing or
protection pane.
10. The dust collection containers are held firmly closed by
the clamping levers fitted to the sides. If the machine is in
constant use, the drawers should be checked daily for
overfilling.

5
Device overview
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
13
Filter system
The system consists of different types of filter:
1. The air supply rosettes allows the air aspirated by the fan to
enter the blasting chamber. Negative pressure results, which
prevents the blasting shot from escaping during blasting.
2. The air filter aspirates fresh air through the air supply rosettes,
thereby establishing a flow rate. Suspended matter and shat-
tered blasting shot can therefore be sucked into the two filter
cartridges before they re-emerge in the blasting chamber.
Only clean the filter with the fan switched off.
IMPORTANT!
Changing the filter cartridges
1. Open the rear maintenance hatch.
2. Unscrew the M10 securing nuts under the cartridges, unscrew
the threaded rods and remove the cartridge.
Installation is performed in reverse order.
INFORMATION!

6
Technical data
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
14
Power supply
Supply voltage 400 V AC 50 Hz
Connected load 0.55 W
Fusing 16 A
Load factor 100 %
Type of protection IP 30
Compressed-air connection
External air pressure k max. 8 bar
Compressed-air control range 0.5 – 8 bar
Compressed-air connection thread 1/2“
Performance data
Support grid load bearing capacity 75 kg
Air consumption with 2 mm air noz- approx. 240 l/min at 5 bar
Air consumption with 2.5 mm air approx. 380 l/min at 5 bar
Air consumption with 3.4# mm air approx. 460 l/min at 5 bar
Fan capacity approx. 500 m3/h
Filter area (main filter) 8 m2
Dimensions and weight
Width 760 mm
Height, closed 1.650 mm
Depth 870 mm
Working surface 620 mm wide, 400 mm deep
Working height (internal height) 450 mm
Weight approx. 150 kg
Ambient data
Sound pressure level < 72 dBA
Sound pressure level with afterfilter < 65 dBA
Lighting 1 x 15 W

7
Processing instructions
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
15
Notes concerning blasting shot
The suitable blasting shot can be found in the JOKE®catalogue in
the “cleaning and blasting equipment” chapter. Take care to use
the shot in the dry state and free of lumps.
The suitable blasting shot for the various different requirements
can be selected and ordered directly from JOKE ®, stating the
order number.
Use of silicone-based or quartz-based blasting shot may cause se-
vere damage to the respiratory tract!
CAUTION
Use of quartz-based blasting shot is forbidden!
Do not use silicone-based blasting shot! Wear breathing protection!
Notes on blasting
It is advisable to hold the blasting gun at a distance of
approx. 40 - 60 mm from the workpiece and at an angle of 45 - 60°.
The gun should be passed evenly over larger areas in order to avoid
cloud formation. Under certain circumstances, finally blast the entire
surface again, but with a greater gun distance.
Fine profiling and sharp edges must only be blasted with fine grits
and at low pressure.
If surface improvement is to be achieved, work must be performed
several times with different grit sizes (from coarse to fine). The blast-
ing shots MK 40/90, followed by MK 90/150 and finally MK 245 are
recommended for this purpose. Subsequent blasting with GPF fine
glass beads results in a silk gloss.
Restoration work is mainly performed at low pressure with the use of
glass beads, high-grade corundum and walnut shells.

8
Troubleshooting
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
16
Malfunction Possible cause Remedy
 Worn, damp or
lumpy blasting shot
 Change blasting
shot
 Prefilter blocked  Check whether the
dust collection
chamber is over-
filled.
• Excessive dust is
generated
 Main filter blocked  Check whether the
dust collection
drawer has been in-
stalled firmly sealed.
 Too little blasting shot
in the cabin
 Refill blasting shot
 No air pressure  Set air pressure on
the pressure relief
valve to at least
0.5 bar.
• No blasting shot
emerges from the
blasting gun
 Foreign body in the
unit
 Large burrs, scales
and lacquer, etc.
may deposit them-
selves in both the
dosing cup and in
the blasting gun.
Both are to be re-
moved by loosening
the hose clamps
and inspecting for
foreign bodies. The
air and blasting noz-
zle must be screwed
out if necessary. The
suction pipe must
likewise be re-
moved.

9
Care and maintenance
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
17
Care
Only clean the device with a soft brush or dry cloth if required.
Clean the inside and outside of the window.
Do not damp clean!
IMPORTANT!
Maintenance work
The maintenance work must only be performed by appropriately
trained specialists.
IMPORTANT!
CAUTION! Risk of injury!
Pull out the mains cable from the socket before beginning the main-
tenance work.

10
Blasting shot
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
18
Order no.
Applications Grit size
in
Description 5 l contai-
ner
25 kg
bag
50 kg bag
Mixed grits
Improving of surfaces, cleaning, deburring, descaling and preparation of surfaces
coarse, stock-removing
medium, stock-removing
fine, stock-removing
very fine, stock-removing,
polishing
budget-priced, medium,
good stability
coarse, tenacious, good
stability
fine, tenacious, efficient
500-150
150-75
70-50
50-40
200-100
300-250
125-75
MK 40/90
MK 90/150
MK 245
MK 300
RM K
MK 60/90
MK 120/150 S
0 955 102
0 955 122
0 955 132
0 955 142
0 955 202
0 955 112
0 955 212
0 955 205
Cleaning of moulds and dies with stubbornly adhering dirt
fine, tenacious, efficient,
quick, stock-removing, polish-
ing
finer, smoother, with higher
polishing effect
110-70
110-40
MK 245/S/G
MK-GPF/Si
0 955 222
0 955 232
Glasperlen
Polieren, Dekorieren, Entgraten, Verfestigen aller Werkstoffe einschließlich Nichtei-
sen- und Edelmetallen sowie Kunststoffen
Glass beads
Polishing, decorating, de-
burring, surface hardening of
all materials, including non-
ferrous, precious metals and
plastics.
800-400
400-300
200-100
110-70
70-40
GPSG
GPG
GPM
GPF
GPFF
0 955 302
0 955 312
0 955 322
0 955 332
0 955 342
0 955 304
0 955 314
0 955 324
0 955 334
0 955 344
Aluminium shot
Deburring and cleaning of aluminium and light alloys
Tenacious, efficient 850-400 AL 70 0 955 242
Hard blasting shot
Cleaning, descaling, deburring of metals, mainly steels - no formation of dust
Round, long service life
Edged, long service life
150-100
200-100
HST 120
HST 121
0 955 402
0 955 412
0 955 404
0 955 414

10
Blasting shot
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
19
Order no.
Applications Grit size
in
Description 5 l contai-
ner
25 kg
bag
50 kg bag
Ruby
Fine deburring, removal of insulating layers, cleaning of non-ferrous and precious metals, decoration
High purity, tenacious hard
dito. finer
150-125
105-75
RUB 100
RUB 150
0 955 502
0 955 512
0 955 505
0 955 515
Corundum
General cleaning jobs, descaling, decorating, matting, good stock removal, medium hard
coarse
medium
fine
420-297
105-75
88-62
KOR 46
KOR 150
KOR 180
0 955 632
0 955 602
0 955 612
0 955 635
0 955 605
0 955 615
Walnut shells, ground
Cleaning and deburring of soft metals and plastics, especially duroplastics
medium
fine
750-300
< 300
WS 2
WS 3
0 955 712
0 955 722
0 955 715
0 955 725
Silicon carbide
Blasting of tungsten carbide and spark-eroded moulds
Aggressive, high stock-
removal
aggressive, high stock-
removal
105-75
88-62
SIC 150
SIC 180
0 955 902
0 955 912
0 955 905
0 955 915

11
Telefax form
JOKE®instruction manual
Fine dry blasting unit mikromat 600 eco
20
Aggressive, high stock-removal
aggressive, high stock-removal
Company
Name
Street
Postcode – town/city
Please send us the spare parts drawing and
parts list for the following equipment:
0as a printout (see address overleaf),
0by fax, ____________________________
0as a pdf file to my e-mail address
_____________________________
mikromat 50 eco Order no. 0 951 100-5 0
mikromat 600 eco Order no. 0 952 000 0
mikromat 800 Order no. 0 950 400 0
mikromat 1100 eco Order no.. 0 952 001 0
Date Signature
