Jolly Mec Control Display User manual

SM096 EN REV03 2016_05
CONTROL
DISPLAY
USER MANUAL
To be kept by the purchaser
Control display for water heating products

Dear Customer,
thank you for having chosen to heat and save with a Jolly Mec product. Please carefully read and keep this sheet
before using the equipment.
The manual provides information and suggestions necessary for correct product use. Knowing and observing these
instructions will allow you to fully and safely enjoy the potential your equipment can offer you.

SM096 EN REV03 2016_05 3
ENGLISH
TABLE OF CONTENTS
CHAP.01 PREMISES...................................................................................................................................4
01.1 WARNINGS .................................................................................................................................................. 4
01.2 SYMBOLOGY............................................................................................................................................... 4
CHAP.02 USER INTERFACE...................................................................................................................... 5
02.1 CONTROL DISPLAY DESCRIPTION........................................................................................................... 5
02.2 KEY FUNCTIONS......................................................................................................................................... 5
02.3 ICON MEANINGS......................................................................................................................................... 6
CAP.03 OPERATING MODE ....................................................................................................................6
03.1 APPLIANCE OPERATIONS ......................................................................................................................... 6
03.2 MAIN STATUS MESSAGE MEANINGS ....................................................................................................... 7
03.3 MAIN SETTINGS.......................................................................................................................................... 8
CHAP.04 USER MENU................................................................................................................................9
04.1 FUNCTIONS................................................................................................................................................. 9
04.2 STRUCTURE.............................................................................................................................................. 10
CHAP.05 FAULT DIAGNOSIS AND TROUBLESHOOTING ....................................................................23
05.1 ALARM MESSAGES .................................................................................................................................. 23

4
CHAP.01 PREMISES
01.1 WARNINGS
• Werecommendyoucarefullyreadandfollowtheinstructionsinthismanualforcorrectuse.
• Itshouldbekeptwithcareandattentivelyconsultedsinceallthewarningsprovideimportantsafetyinstructions.
• Incorrectusecouldcausedamageandinjurytopeople,animalsorproperty,forwhichthemanufacturercannotnotbeheldliable.
• Theappliancemustbeusedonlyforitsintendedpurpose.Anyotheruseisdeemedimproperandthereforedangerous.
• Themanufacturerdeclinesanycontractualornon-contractualliabilityfordamagescausedbyerrorsininstallationoruseofthe
applianceorfailuretofollowtheinstructionscontainedinthismanual.
• AllrightsonthereproductionofthistechnicalmanualareownedbyJollyMecCaminettiS.p.A.
• Thedescriptionsandillustrationsprovidedinthefollowingpublicationarenotbinding.
• JollyMecCaminettiS.p.Areservestherighttomakeanymodicationsthatmaybedeemedappropriate.
• ThismanualcannotbegiventothirdpartiesforperusalwithoutthewrittenpermissionofJollyMecCaminettiS.p.A.
• Donotmakeanyunauthorisedmodicationtotheappliance.Anyunauthorisedmodicationwillautomaticallyinvalidatethewarranty
andreleasethemanufacturefromallliability.
• Useonlyoriginalsparepartsrecommendedbythemanufacturer.Originalsparepartsareavailablethroughretailers,specialised
TecnicalServiceCenters,ordirectlyattheheadofceofJollyMecCaminettiS.p.A.
01.2 SYMBOLOGY
In this manual, points of considerable importance are marked with the following symbology:
INSTRUCTION: Instructions regarding the correct use of the appliance.
WARNING: This point is particularly important.

ENGLISH
CHAP.02 USER INTERFACE
02.1 CONTROL DISPLAY DESCRIPTION
The control display lets you communicate with the control unit. The keys are used to transmit commands to the control unit while the
display informs the user on stove operating status. Programming mode displays the various settings that can be edited using the keys.
02.2 KEY FUNCTIONS
Key Description Mode Action
1Temperature selection QUICK ACCESS Rapid access to adjust Set ambient temperature
Increase EDIT VALUE Increases the selected setting value
Chronothermostat ACTIVATE CRONO Pressed together with button 2 activates the Timer function.
2Temperature selection QUICK ACCESS Rapid access to adjust Set Water temperature in the appliance
Decrease EDIT VALUE Decreases the selected setting value
Chronothermostat ACTIVATE CRONO Pressed together with button 2 activates the Timer function
3On/Off - Esc - REsEt OFF Turns on
WORK Turns off
ALARM Resets the alarm
MENU Returns to the previous level
4Access Menu/Conrm OFF Opens the menu
WORK Opens the menu
MENU Conrms changed settings and moves to the next Menu page
5Output selection QUICK ACCESS Rapid access to set the power
Increase EDIT VALUE Increases output value
Decrease page MENU Change page within the Menu
6Temperature selection QUICK ACCESS Rapid inlet to regulate Set Temperature Puffer and Boiler
Decrease EDIT VALUE Decreases output value
Increase page MENU Changes page within the menu
1
23
4
6
5
5
Display
IR receiver
Component reference icons

6
02.3 ICON MEANINGS
A segment may or may not be found next to each icon on the display to indicate whether or not the relevant component and/or function
is enabled. The functions or components associated with the various icons are:
The image below depicts an example of a display screen which indicates that the chronothermostat function is running and the auger
gear motor and electrical resistance are running.
The rst row on the display shows the current time, the second row shows, from the left, room temperature and water temperature, whilst
the third and fourth rows show, respectively, the device status and operating output.
Room probe request Auger gear motor
Chronothermostat Fume fan
Electrical resistance Water circulator
Auxiliary circulator Alarm
CAP.03 OPERATING MODE
03.1 APPLIANCE OPERATIONS
When the appliance is OFF, press and hold down Key 3 on the display for several seconds to turn it on. Next, the start-up message will
appear on the display indicating that the switch-on procedure is made up of various phases dened in technical parameter settings and
to be set by a specialised Technical Service Center. After the normal switch-on time, the device normally reaches the RUNNING condition
at the set output unless fume temperature reaches the minimum admitted value and the relevant alarm message is displayed. In normal
conditions the device maintains work status, running the BASKET CLEANING mode at set intervals until the set room temperature is
reached (or other temperature according to the probe or set system conguration). Afterwards, it switches to ECO MODULAT- mode
running at reduced regime. If STAND-BY mode is on, the device turns off after a period of time in economy mode or after this condition
led to a certain increase in the reference temperature. The length of this period and the temperature increase can be set in MENU 5 –
STAND BY. In STAND-BY mode, the stove automatically turns back on when the reference temperature drops under the set value. To
manually turn off the stove, simply press and hold down Key 3 for several seconds. Next, FINAL CLEANING is run.

ENGLISH
03.2 MAIN STATUS MESSAGE MEANINGS
During normal operations, the screen displays the time, room temperature, water temperature and a message that indicates device status
when the message is displayed. An illustration of the main display screen appears below.
The main messages that can appear on the display and their meanings are summarised in the following table:
MESS-
TEXT Description
OFF
Message displayed when the appliance is off. It can be switched on in manual mode, using a
GPRS system or chronothermostat settings.
INITIAL
ventil-
Message displayed during the initial ventilation phase during the rst start-up phase.
PRELOAD
PELLET
Message displayed during the initial pellet preload phase.
WAIT
FLAME
Message is displayed during the stand-by time before the pellets are ignited. The fumes
temperature must reach a set value for the device to be considered ON.
fLAME
ON
Message displayed when the device is on. This message remains on the screen for a short
period of time while the ame stabilises and pellet ignition in the brazier is completed.
RUNNING
p0
Message displayed during device operations in work mode, meaning until the temperature read by
the room probe or water probe reaches the set value.
The number indicated next to the letter P indicates the output level at which the device is running.
If the number ashes, the device is increasing or decreasing output.
BASKET
CLEANING
Message displayed during the clean brazier automatic cycle that is run at regular intervals
while the stove is running. A forced ventilation cycle of the fumes extractor removes any excess
unburned materials from the brazier.
final
CLEANING
Message displayed during the shutdown phase.
eco
modulaT-
Message displayed when the room and/or water temperature value is reached. The appliance
automatically switches to economy mode.
OK
STAND-BY
The previous screen is alternated when, after a period of running in ECONOMY mode, the
device enters STAND-BY and shutdown conditions are met.
OFF
WAITING
Message displayed when, during the start phase, the switch off button is pressed. Device
shutdown during the switch-on phase is not permitted. Therefore, the command is saved and
will be run at the end of the stabilisation phase.
WAITING
COOLING
Message displayed during the shutdown phase for STAND-BY mode
WAIT
RESTART
Message displayed when, during the shutdown phase, the switch on button is pressed. Device
start during the shutdown phase is not permitted. Therefore, the command is saved and run
when the fume temperature drops under 80°C.
STAND-BY The device is OFF, waiting to be automatically restarted by a probe signal that requests heat.
The device is not completely switched off in STAND-BY status, but is OFF waiting to restart.
ORDINARY
SERVICE
The device has reached the periodic servicing warning signal, to be reset with the heating stove
OFF by pressing Key 3 on the home page.
7

8
Output settings
03.3 MAIN SETTINGS
Use the specic keys on the control display to directly access from the main page the room, stove and, according to the adopted system
conguration, the puffer and/or boiler output and temperature settings pages.
Temperature settings
To change the operating output, press Key 5on the main page to immediately open the
screen where you can use the Keys 5 or 6 to select from the ve settable output settings.
After selecting the required output level, press Key 3to return to the main page.
To change the required temperatures, press Key 1,2 or 6 on the main page to immediately open the relevant section. The set values
can be changed using keys 1 and 2 in each screen. If diagram 7 is set, press key 6 once to access the set Puffer settings, press key 6
twice to access the set Boiler settings.
After selecting the required output level, press Key 3to return to the main page.
Key 1
For all Conguration
Key 2
For all Conguration
Key 6
With Conguration 5 or 7 set.
The second row represents the temperature read by
the probe.
Key 6
With Conguration 6 or 7 set.
The second row represents the temperature read by
the probe.

ENGLISH
CHAP.04 USER MENU
04.1 FUNCTIONS
The display is divided into menus and sub-menus that can be scrolled using the control display keys. In short, main menus and their
functions are:
MENU Description
1 - SET CLOCK Lets you set the current date and time, required for correct chronothermostat operations
2 - SET CHRONO Lets you turn the chronothermostat and its programs on or off. The delay programme is enabled on
crono page, that independently from the crono, can be used to delay start-ups and switch-offs.
3 - SET LANGUAGE Lets you set the menu language
4 - SET PROBE Lets you set the type of room probe to be used.
• Set THERMOSTAT probe type to use a thermostat to control the appliance. If a retail thermostat
is used, the device must be used with clean contacts to the appliance. The Jolly Mec thermostat
module is also considered a thermostat. Therefore, if an original Jolly Mec device is used, set
THERMOSTAT as probe type.
• Set PROBE type to use the probe installed on the stove or a remote same type of probe in another
room. In the latter case, the probe installed on the stove must be disconnected from the electronic
card (to be done by a specialised Technical Service Center).
5 - SET STAND-BY STAND-BY mode lets you turn off the appliance when room or water temperature requests, according
to the set conguration, are met. In STAND-BY (display message) the appliance is awaiting room or
accumulation tank thermostat requests to restart a switch-on cycle. The delay time delays shutdown
from the moment when the requests are met. If PROBE type was set in MENU 4, the appliance will
only shutdown after running in ECONOMY mode for a period of time equal to DELAY OFF time after
requests are met while if THERMOSTAT type is set, the appliance will run in ECONOMY mode for twice
as long as the set DELAY OFF time.
6 - SET DISPLAY Allows you to change the device acoustic signals settings and delay the switch-off of the back-lighting.
7 - PELLET LOAD Lets you start manual pellet load. It can be used after the completely empty tank was lled with fuel,
to ll the burner.
8 - STATE STOVE Allows you to check the actual operating status scrolling through the various pages using Keys 5 or 6.
9 - TECHNIC SETTINGS This menu contains the appliance settingspages that only the specialised Technical Service Center can
access using a specic password.
A - REGULATE SETTING Lets you change pellet loading and fume exhaust settings
B - COUNTER MEMORY Lets you read some data stored in the control unit memory
C - SEASON Lets you set either winter or summer operating mode
9

10
04.2 STRUCTURE
To open the various menus, press Key 4when the main page is displayed on the remote control. To scroll the various menu pages, use
Keys 5and 6.
M1-001 DAY
To select the current day of the week, use Keys 1and
2and press Key 4to set the displayed value and move
to the next page.
M1-002 HOUR CLOCK
To set the hour, use Keys 1and 2and press Key 4to set
the displayed value and move to the next page.
M1-003 MINUTES CLOCK
To set the minutes, use Keys 1and 2and press Key 4
to set the displayed value and move to the next page.
M1-004 DAY CLOCK
To select the current day, use Keys 1and 2and press
Key 4 to set the displayed value and move to the next
page.
M1-005 MONTH CLOCK
To select the current month, use Keys 1and 2 and press
Key 4 to set the displayed value and move to the next
page.
M1-006 YEAR CLOCK
To select the current year, use Keys 1and 2 and press
Key 4 to set the displayed value and move to the next
page.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
MENU 1 - SET CLOCK
4
3
3
3
3
3
3
4 5
4 5
4 5
4 5
4 5
4

ENGLISH
MENU 2 - SET CHRONO
M2-2 ENABLE CHRONO
Lets you turn the chronothermostat function on or off.
M2-1 DELAY
Lets you set a switch-on or shutdown delay time.
M2-3 PROGRAM DAY
Lets you set two time ranges enabled every day of the
week.
M2-4 PROGRAM WEEK
Lets you set four time ranges that can be enabled as
needed during the various days of the week.
M2-5 PROGRAM WEEK-END
Lets you set two time ranges that can only be enabled
on Saturday and Sunday.
M2-1-001 DELAY
Use Keys 1and 2to adjust the delay time. When the
appliance is OFF, set DELAY ON for deferred appliance
start or, with the appliance in RUNNING, set DELAY
OFF to program shutdown. The function is disabled
when set to 00:00. Once the required delay is set, press
Key 4 to conrm the selection and open the next page.
With DELAY ON (or OFF) set, the main screen displays
the time countdown until the set switch-on (or shutdown).
The appliance can be switched on (or shutdown) at any
time even in this situation by using the normal procedure.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the next level page
automatically opens.
4
4
4
4
4
6
6
4
3
3
3
3
3
6
6
4
3
5
5
5
5
5
11

12
M2-2-001 ENABLE CHRONO
Use Keys 1and 2to select to enable or disable the
chronothermostat function and press Key 4 to conrm
the selection and move to the next page. This function
can be accessed more rapidly by Keys 1 and 2 on the
main page.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
M2-3-002 START 1 DAY
Use Keys 1and 2 to set the start time for the rst
operating time range permitted by the function and
press Key 4 to conrm the selection and move to the
next page. Set OFF to disable the time range.
M2-3-001 CHRONO DAY
Use Keys 1and 2to select to enable or disable the DAY
TIMER function and press Key 4 to conrm the selection
and move to the next page.
M2-3-003 STOP 1 DAY
Use Keys 1and 2 to set the end time for the rst
operating time range permitted by the function and
press Key 4 to conrm the selection and move to the
next page.
M2-3-004 SET ROOM T PROG- 1
Use Keys 1and 2to set the room temperature value to
be reached in the rst time range and then press Key
4 to conrm the selection and move to the next page*.
The next three screens, similar to the previous three, let
you set the same parameters for the second operating
time range permitted by the function.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
* The room set value is not considered if THERMOST was set as the room probe in MENU 4.
NOTE
4
4
3
4
3
3
3
3
3
4
5
5
5
5
4
4
4
4
M2-3-005: START 2
M2-3-006: STOP 2
M2-3-007: PROG- 2

ENGLISH
*The room set value is not considered if THERMOST was set as the room probe in MENU 4.
NOTE
M2-4-002 START PROG- 1
Use Keys 1and 2 to set the start time for the rst
operating time range permitted by the function and
press Key 4 to conrm the selection and move to the
next page.
M2-4-001 CHRONO WEEK
Use Keys 1and 2to select to enable or disable the
CHRONO WEEK function and press Key 4 to conrm
the selection and move to the next page.
M2-4-003 STOP PROG- 1
Use Keys 1and 2 to set the end time for the rst
operating time range permitted by the function and
press Key 4 to conrm the selection and move to the
next page.
M2-4-004 SET ROOM T PROG- 1
Use Keys 1and 2to set the room temperature value to
be reached in the rst time range and then press Key
4 to conrm the selection and move to the next page*.
M2-4-005 MONDAY PROG-1
Use Keys 1and 2to select to enable or disable the
program created for the displayed day and press Key
4 to conrm and move on to programming the following
days of the week.
Continuing through the menu you can set, with a similar
sequence, the other three programmable time ranges.
The following screens let you make the same selections
for the following days of the week.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
4
3
3
3
3
3
3
3
4
5
5
5
5
5
5
4
4
4
4
4
4
13
M2-4-006→011
TUESDAY→SUNDAY
M2-4-012→021 PROG-2
M2-4-022→031 PROG-3
M2-4-032→041 PROG-4

14
*The room set value is not considered if THERMOST was set as the room probe in MENU 4.
NOTE
M02-05-002 START 1 WEEK-END
Use Keys 1and 2 to set the start time for the rst
operating time range permitted by the function and
press Key 4 to conrm the selection and move to the
next page.
M02-05-001 CHRONO WEEK-END
Use Keys 1and 2to select to enable or disable the
CHRONO WEEK-END function and press Key 4to
conrm the selection and move to the next page.
M02-05-003 STOP 1 WEEK-END
Use Keys 1and 2 to set the end time for the rst
operating time range permitted by the function and
press Key 4 to conrm the selection and move to the
next page.
M02-05-004 SET ROOM T PROG- 1
Use Keys 1and 2to set the room temperature value to
be reached in the rst time range and then press Key
4 to conrm the selection and move to the next page*.
The next three screens, similar to the previous three, let
you set the same parameters for the second operating
time range permitted by the function.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
M3-003 LANGUAGE
Use Keys 1and 2to select the required language
from the four available European languages (ITALIAN,
ENGLISH, GERMAN and FRENCH) and press Key 4
to conrm.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
MENU 3 - SET LANGUAGE
4
3
3
3
3
3
4
4
5
5
5
5
4
4
4
4
4
3
M2-5-005: START 2
M2-5-006: STOP 2
M2-5-007: PROG- 2

ENGLISH
We do not recommend you enable STAND-BY mode when the appliance is repeatedly turned on and off during
the day. Turning a pellet fuelled water heating product on and off more than four times a day is considered less benecial
than continuous operations in economy mode.
NOTE
M4-001 PROBE
Use Keys 1 and 2to select the required probe type from
those available (PROBE, THERMOST) and press Key
4 to conrm.
M5-001 ENABLE STAND-BY
Use Keys 1and 2 to enable stand-by and press Key 4to
conrm and move to the next page. STAND-BY in system
congurations 5 and 7, summer and winter mode, and in
conguration 6, summer mode, is automatically enabled.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
MENU 4 - SET PROBE
MENU 5 - SET STAND-BY
M5-002 DELTAOFF STAND-BY
Use Keys 1and 2to set the temperature delta between
the actual and set room and stove water temperatures
that must be reached to permit shutdown. Next press
Key 4 to conrm.
Min. 0,0°C, Max. 15,0°C, Recommended 2,0°C
M5-003 STAND-BY OFF LAG
Use Keys 1and 2to set shutdown delay time and press
key 4 to conrm.
Min. 3 min, Max. 120 min. Recommended 10 min
4
4
3
3
4
4
3
3
5
5
4
4
15

16
M6-001 SET BUZZER
Use Keys 1and 2 to mute the buzzer when alarms
occur and press Key 4 to conrm and move to the next
page. In this case, no buzzer will sound when the stove
malfunctions.
M7-001 P1 TO LOAD
Press Key 1 to conrm pellet load start.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
MENU 6 - SET DISPLAY
MENU 7 - PELLET LOAD
When nished loading, message CLEAN BRAZIER
appears on the main screen to remind the user to clean
the brazier before re-igniting the stove.
The electrical contact installed between the device body
and the door detects the open door status. If it is not
opened, it is not possible to reset the CLEAN BRAZIER
message. After opening the door and cleaning the
rebox, press Key 3 to cancel the message and return
to the main page that will display the OFF message.
The maximum load time is 90 seconds, according to
software settings.
This operation can be interrupted by pressing Key 3.
The pellet loader must be used when the auger is empty, after a NO PELLETS alarm, or after maintenance or
cleaning of the container.
After loading the pellets, it is mandatory to open the device door and empty the rebox.
THE BRAZIER MUST BE FULLY EMPTY EACH TIME THE STOVE IS TURNED ON.
NEVER pour the pellets removed from the rebox into the device hopper.
WARNING
M6-002 DISPLAY OFF LAG
Use Keys 1and 2 to set the display back-lighting
shutdown delay time. When a 0 value is set, the display
will always remain on.
4
4
3
3
4
1
3
4
3
5

ENGLISH
M8-001 TEMP FUME
Fume temperature is displayed in this page.
M8-002 FUME SPEED
Fume fan speed (rpm) is displayed in this page.
M8-003 AUGER ON TIME
Pellet load auger operating time is displayed in this
page.
M8-004 TEMP H20
Water temperature in the appliance is displayed in this
page.
M8-005 BUFF- HI TEMP-
Puffer high temperature is displayed in this page.
M8-007 DHW TANK TEMP-
Boiler low temperature is displayed in this page.
M8-008 H2O PRESSURE
Water pressure in the appliance is displayed in this page.
MENU 8 - STATE STOVE
M8-005 BUFF- HI TEMP-
Puffer low temperature is displayed in this page.
M8-007 DHW TANK TEMP-
Boiler high temperature is displayed in this page.
3
3
3
3
3
5
5
5
5
4
4
4
4
4
3
54
3
4 5
4
3
5
4
3
5
4 5
17

18
M8-011 PELLET TEMP-
Safety temperature is displayed in this page.
M8-012 ZONE MODULE 1
Zones in request in the rst zone module are displayed
in this page.
M8-016 SET FLOW
The comburent air ow control status is displayed in this
page (for models with these settings).
M8-017 FLOW RATE M/S
The comburent air ow is displayed in this page (for
models with these settings).
M8-018 TEMP- FLOW
The debimeter heated sensor temperatures are
displayed in this page (for models with these settings).
M8-011 BOARD TEMP-
Electronic board temperature is displayed in this page.
M8-012 ZONE MODULE 2
Zones in request in the second zone module are
displayed in this page.
M8-012 ZONE MODULE 3
Zones in request in the third zone module are displayed
in this page.
M8-012 ZONE MODULE 4
Zones in request in the fourth zone module are displayed
in this page.
3
3
3
5
5
5
5
4
4
4
4
3
3
5
5
4
4
54
54
3
3
3
3
54

ENGLISH
M8-019 AIR TEMP-
The debimeter inlet air temperature is displayed in this
page (for models with these settings).
M8-020 SYSTEM DIAGRAM
The set system conguration is displayed in this page.
M8-021 DATA
The active database is displayed in this page.
M8-022 STATE STOVE
Appliance status is displayed in this page.
MENU 9 - TECHNIC SETTINGS
Password protected Menu reserved to the Jolly Mec
Customer Service (CAT) technician.
The service technician can update all stove functional settings in MENU 9 - TECHNIC SETTINGS. Each
intervention of this type resets factory settings with the consequent loss of all user settings. .
NOTE
3
3
3
3
5
5
5
4
4
4
4
3
19

20
MA-001 REGULATE PELLET
Use Keys 1and 2to adjust the quantity of pellets
between -09 and -09 corresponding to ±3% each unit
and press Key 4 to conrm and move to the next page.
When nished, the message DONE will be displayed
to conrm correct data entry. Next, the level page
automatically returns to the Menu Page.
MENU A - REGULATE SETTING
MA-002 REGULATE CHIMNEY
Use Keys 1and 2 to adjust fume exhaust speed between
-09 and -09 corresponding to ±3% each unit and press
Key 4 to conrm and move to the next page.
MENU B - COUNTER MEMORY
Mb-001 TOTAL HOURS
Total operating hours are displayed in this page.
Mb-002 PARTIAL HOURS
Partial operating hours are displayed in this page.
Mb-003 NUMBER START
The number of starts is displayed in this page.
Mb-004 RESET PARTHOUR
The number of partial hour resets is displayed in this
page.
4
3
4
3
54
3
3
3
3
5
5
5
5
6
6
6
6
4
