Jon-Don EZ SPOT Guide

Make a copy of this card for future reference.
© 2016 All Rights Reserved Jon-Don, Inc.
New Equipment Warranty
Limited Warranty
Jon-Don, Inc. warrants new equipment against defects in material and workmanship
under normal use and service to the original purchaser. Any statutory implied
warranties, including any warranty of merchantability or tness for a particular
purpose, are expressly limited to the duration of this written warranty. Jon-Don,
Inc. will not be liable for any other damages, including but not limited to indirect or
special consequential damages arising out of or in connection with the furnishing,
performance, use or inability to use the machine. This remedy shall be the exclusive
remedy of the purchaser. The warranty period is subject to the conditions stated
below.
LifetimeWarranty on Body, 5Years on Vacuum Motors and Pump,
2 Years on Heater, 1 Year on All Electrical Parts, 90 Days on Tools
and Accessories
Jon-Don, Inc. warrants the roto-molded body to be free from defects in material and
workmanship, under normal use and service for a lifetime. Jon-Don, Inc. warrants
the motors and pump to be free from defects in material and workmanship, under
normal use and service for ve (5) years from the original date of sale, heater for
two (2) years and all electrical parts one (1) year. Parts replaced or repaired under
this warranty are warranted for the remainder of the original warranty period.
Service labor charges are covered for one (1) year from the date of purchase, when
performed by a Jon-Don Repair Center.
Labor is only provided by a Jon-Don Repair Center. If a Jon-Don Repair Center is
not near you, it is the purchaser’s responsibility to take their machine to a Jon-Don
Repair Center.
Normal wear items, such as capacitors, cords, nishes or switches, will be warranted
for manufacturing defects for ninety (90) days from the purchase date.
All warranties of motors and associated components will be voided: if the machine
is serviced by anyone other than a Jon-Don Repair Center; if the machine is
mechanically modied; if the machine is operated when not operating properly; or if
the machine is misused or abused.
The warranty starts on the purchase date by the original purchaser from Jon-Don,
Inc. subject to proof of purchase. The Machine Registration Card must be completed
and returned immediately at the time of purchase. If proof of purchase cannot be
identied, the warranty start date is ninety (90) days after the inventory stocking
date at the distributor’s warehouse.
400 Medinah Road, Roselle, IL 60172
Phone: [phone] | Fax: [phone] | www.jondon.com
Safety, Operation and Maintenance
Manual with Parts List
Please read before use!
3-Gallon Capacity
EZ Spot Extractor Series
Manufactured with
Pride in the U.S.A.
© 2016 Copy Rights Reserved Jon-Don, Inc.
Important Information and Safety Instructions
Serial No:

(2) 3-Gallon EZ Spot Extractor Series
Dear Valued Client,
Congratulations on the purchase of your 3-Gallon EZ Spot Extractor carpet and
upholstery machine! The world of carpet cleaning is becoming more high-tech and
competitive and we strive to provide you with the most innovative products. Our spot
extractor with heat is yet another example of this, bringing a new dimension to carpet
and upholstery cleaning with its cutting-edge features, quality and value.
Please review this manual, paying careful attention to the Safety Instructions section.
Keep in mind that any unnecessary damage, neglect or abuse of this machine will void
your warranty. You can be condent that simple maintenance will ensure that your
spot extractor with heat provides quality performance for many years to come.
If warranty questions arise, please consult your manual or contact your Jon-Don
representative Should you have any questions regarding maintenance, replacing parts
or ordering parts, please call your Jon-Don representative.
Before you begin using your EZ Spot Extractor, please thoroughly review the Owner’s
Manual.
Again, congratulations on the purchase of your 3-Gallon EZ Spot Extractor carpet and
upholstery machine!
Questions or Comments?
Phone: [phone]
Fax: [phone]
400 Medinah Road, Roselle, IL 60172
www.jondon.com
Warranty Registration
Mail to:
Jon-Don, Inc.
400 Medinah Road
Roselle, IL 60172
See reverse side for warranty information.
Make a copy of this card for future reference.
© 2016 All Rights Reserved Jon-Don, Inc.
Please take a moment to register your machine. Fill out the
information below and mail back to Jon-Don, Inc. immediately.
The warranty starts on the purchase date by the original purchaser, subject to proof
of purchase. Please immediately register your machine by returning this Machine
Registration Card at the time of purchase. If proof of purchase cannot be identied,
the warranty start date is ninety (90) days after the inventory stocking date at the
distributor’s warehouse.
Machine Model Purchase Date
Motor Type Serial No.
Place of Purchase
Shipped To
Your Name Phone
E-mail Fax
Address Line 1
Address Line 2
City State Zip
Comments:

3-Gallon EZ Spot Extractor Series (3)© 2016 Copy Rights Reserved Jon-Don, Inc.
Please ll out the following information:
Model No:
Serial No:
Distributor Name:
Distributor Phone No:
Date of Purchase:
EZ Spot ExtractoR Series
By Jon-Don, Inc.
400 Medinah Road, Roselle, IL 60172
Phone: [phone] | Fax: [phone]
www.jondon.com
New Equipment Warranty
Lifetime on body, 5 years on vacuum motors and pump, 2 years on heater, 1 year on all
electrical components, 90 days on tools and accessories.
Warranty Policy
All equipment is inspected and tested before shipping from the manufacturer. All parts are
warranted to be new and free from defects in workmanship and material, under normal use to the
original retail purchaser. This warranty limits manufacturer’s liability for defects in workmanship
or materials for replacement of defective parts only. The manufacturer accepts no liability for
incidental or consequential damages arisen from the use of any equipment, defective or not. This
warranty is in lieu of all expressed or implied warranties and is extended only to the original retail
purchaser. Manufacturer sales and service representatives are not authorized to waive or alter
the terms of this warranty, or to increase the obligations of the manufacturer under the warranty.
Parts replaced or repaired under this warranty are warranted for the remainder of the original
warranty period.
Labor is only provided by a Jon-Don Repair Center. If a Jon-Don Repair Center is not near you, it is
the purchaser’s responsibility to take their machine to a Jon-Don Repair Center.
The manufacturer covers up to one (1) year (365 days) of service labor at the manufacturer’s
calculated hourly labor rate/repair time when performed by a Jon-Don Repair Center.
Ultimately, labor reimbursement costs are at the discretion of the manufacturer. At no time is
the manufacturer responsible for travel time to complete on-call repairs. After one (1) year, the
original retail purchaser is responsible for all labor costs with no manufacturer reimbursement.
The original purchaser must contact the manufacturer to follow correct RMA/warranty procedures.
They must include a copy of the RMA Sheet enclosed in the box with the returned item. No returns
shall be authorized unless the proper RMA procedures are followed. It is the responsibility of the
distributor to repair the client’s equipment as soon as possible.
Items being returned must be new, unused, free of damage and are only good for up to 30 days.
After 30 days, the manufacturer does not accept the return of any items for a store credit.
Authorized warranty replacement parts need to come directly from the manufacturer. Any use of
any other parts will void warranty. The manufacturer does not reimburse for parts used by client
that were not supplied directly for the machine under warranty.
The client must contact the manufacturer prior to working on or changing out any parts, etc. The
manufacturer must issue an RMA Sheet containing approved labor time and replacement parts.
Do not send parts or equipment back to the manufacturer without an RMA Number and approval.
No labor will be paid for, nor parts cost paid for or reimbursed, that have not previously been
approved by the manufacturer. All warranty work must be approved and authorized to qualify,
and appropriate warranty procedures must be followed.
The warranty starts on the purchase date by the original purchaser from Jon-Don, subject to
proof of purchase. The Machine Registration Form must be completed and sent to the original
manufacturer at the time of purchase. If proof of purchase cannot be identied, the warranty start
date is ninety (90) days after the date of sale to an authorized distributor.

(4) 3-Gallon EZ Spot Extractor Series 3-Gallon EZ Spot Extractor Series (13)
1.0 Safety Instructions
WARNING: PLEASE READ AND SAVE! FOLLOW THESE PRECAUTIONS
WHEN USING YOUR SPOT EXTRACTOR.
• DONOToperatethisunitifanypartoftheunitappearstobedamaged.
• DONOToperateifgroundplugisbroken.
• DONOToperateiftheunitisinstandingwater.
• DONOTusevolatilesubstancesoroperatewherevolatilesubstancesexist.
• DONOTservicewhileunitisrunningorconnectedtoelectricity.Unplugtheunit!
• DONOTusewatermorethan120degreesFahrenheit.
• DONOTusesolventswiththisunit.
• DONOTuseasadryvacuum.
• DONOTuseunitunlesscompletelyassembled.
• Useonlyliquiddetergents.Powdersdonotfullydissolveanddamagemotor.
• Alwaysusedefoamer.Foamwillsuspendmoistureparticlesthatdamagemotor.
2.0 Setup / Prepare Unit for Use
DO NOT EXPOSE TO RAIN. STORE INDOORS.
• Allspotextractors–nomatterwhatthetimeofyear–areshippedwithantifreeze
inthepumpandsolutionlines.Priortorstuse,llthetankwithonequartofwarm
water.Attachthehoseandusingthehandtool,ushoutthesystembysprayingthe
onequartofwaterthroughthepump.
• Attachthe1-1/2-inchvacuumhoseandthebrassquickdisconnect.
• Fillthebaseunit(therecoverytankmustberemoved)withwarmwater(lessthan
100degreesFahrenheit).Filltoapproximately4inchesfromthetop.Usealiquid
detergentmadeforcarpetcleaningorupholstery.Readandmixtothedilutionratios
asdirected.
• DONOTturnheateronuntiltheheaterisfullofwater.
• NEVERrunthevacuumonlywiththepumponformorethan3minutes.Water/
solutionneedstorunthroughpumpatalltimestokeepthepumpcoolwhileinuse.
Failuretodosowillvoidthewarranty.
• Besuretoreplaceanyltersbackintothemachinepriortouse.
• Donotusecitrusacid,buterolorharshdegreasersinsidethemachine.
11.0 Wiring Diagram - all Models
CAUTION – Electrical wire colors may vary. Determine start and end point of
each wire to conrm connection point.
9.0 Problem Solving
Neveroperatethisspotextractorwhentheequipmentisnotperformingasexpected,
orwhenanypartisvisiblydamaged.Whenrepairisneeded,taketheequipmenttoan
authorizedservicecenter.
Spotter will not run
• Checkpowerconnection.Movethegroundedplugtoanoutletthatisworking.Verify
thattheplugisworkingbyplugginginanotherelectricalcomponentsuchaslamp,
hairdryerordrill.
• Inspectthepowercordfordamage.
Loss of vacuum
• Makesuretheoatisatthebottomoftheunit.Openthescrewcapandpushtheoat
down.
• Checkthatthehosecuffissecurelyattachedtothefrontoftheextractor.
Loss of solution pressure
• Verifythatthepumpison.Removejetfromendofhandtoolandpresstriggeron
wand.
• Cleanthesolutionintakeinthesolutiontank.Checkquick-disconnectfordebris.
• Ifpumpisstillnotworking,seekauthorizedrepairservices.

(12) 3-Gallon EZ Spot Extractor Series 3-Gallon EZ Spot Extractor Series (5)
2.0 Setup / Prepare Unit for Use
Vacuum Shut-Off
Thespotextractorisdesignedwithavacuumrestrictor
toreducethevacuumwhentherecoverytankisfull.
Whenthevacuumisrestricted,theliquidwillnottravel
upthenozzleofthehandtool.Themotorspeedsup
(thesoundofthemotorwillchange)andthisisyour
warningtodisposeofrecoveredsolution.Therestrictor
isafoamoatthatslidesupanddownthevacuumtube
intherecoverytank.
3.0 Maintenance
Following Each Use
Removethevacuumhosefromtheupperbody.Un-clipandrotatethelatchontheback
oftheunitandremovetheuppersectionofthespotter.Disposeoftheusedsolution
bypouringthesolutionoutofthevacuuminlet(notthehatchcover)intothetoiletor
janitor’sclosetsink.
IMPORTANT!Besuretothoroughlydrainwateroutofheaterlinespriortostoragein
colderclimates.Thisheaterwillfreezeandpossiblycrack,voidingyourwarranty.
Prevent Mineral Deposit Buildup
Vinegarmaybeusedtopreventmineraldepositbuildupinyourmachine’slinesand
pump.Failuretodosomayclogyourlinesandpump.Everytwoweeks,pourvinegar
intothesolutiontank(dilutewith1/2water).Runthepump,whilesqueezingyourwand
orupholsterytool’striggeruntilyousmellvinegarornoticeitcomingoutofthetool.Let
themachinesitovernight,andnolonger,withthevinegarinitslines.Thenextday,ush
themachinewith1gallonofcleanwateroruntilyoudonotsmellvinegaranylonger.
PLEASENOTE:IfyouchoosetouseCLR,followthedirectionsonthebottle.DO
NOTleaveCLRinthemachine’slines.Besuretoushthoroughly.CLRmaycorrode
themachine’scomponentsandVOIDyourwarranty.Ifyouchoosetousevinegar,you
MUSTdilutewith1/2water.Failuretodosomaydamagethemachine’scomponentsand
VOIDyourwarranty.
9.0 Machine Parts List Continued - with Heat
Drawing No. Item ID Item Description Qty. Needed
65 10-0027 Pigtail Strain Relief 1.00
66 10-0448 20-Foot Spotter/Air Mover Cord 1.00
67 10-0025 On/Off Switch 3.00
68 10-1026 Switch Plate for 3-Gallon w/ Heat 1.00
69 10-0400-C Keeper Latch for Sniper 1.00
70 80-0022-A Screw for 500 PSI Panel 2.00
71 10-0204 Motor Mount Back-Up Washer 2.00
10.0 Hoses and Hand Tool Drawing and Parts List
10-0501 Stainless Steel Hand Tool for Machines with Heat
Parts List
Drawing No. Item No. Item Description Qty. Needed
1 10-0501 4” Stainless Steel Upholstery Tool 1.00
2 10-0463 Black Slip Hose Cuff for Spotter 2.00
3 50-1008 15-Foot Black Hose 1-1/4” 1.00
4 10-0868 1/4” Female QD for Spotter 1.00
5 80-8007 1/4” x 15-Foot Extractor Hose 1.00
6 10-0388 Velcro Strap 1.00
7 10-0870 1/4” Male QD 1.00
8 10-0507 8” Black Hose for Stainless Steel Hand Tool 1.00
9 10-0506 Valve Clamp for Stainless Steel Hand Tool 1.00
10 10-0504 Valve for Stainless Steel Hand Tool 1.00
11 10-0502 Jet for Stainless Steel Hand Tool 1.00

(6) 3-Gallon EZ Spot Extractor Series 3-Gallon EZ Spot Extractor Series (11)
4.0 Grounding Instructions
DANGER: IMPROPER INSTALLATION OF THE GROUNDING PLUG CAN
RESULT IN A RISK OF ELECTRIC SHOCK!
Thisproductmustbegrounded.In
theeventofanelectricalshortcircuit,
groundingreducestheriskofelectric
shockbyprovidinganescapewirewithan
appropriategroundingplug.Theplugmust
bepluggedintoanoutletthatisinstalled
properlyandgroundedinaccordancewith
alllocalcodesandordinances.
Checkwithaqualiedelectricianorservicemanifthegroundinginstructionsarenot
completelyunderstood,orifindoubtastowhethertheproductisgroundedproperly.
DONOTmodifytheplugprovided.Ifitwillnottintotheoutlet,haveaproperoutlet
installedbyaqualiedelectrician.
Thiselectricequipmentisforuseonanormal120voltcircuit.Ithasagroundedplug
thatlooksliketheplugillustratedin(FigA).TheuseofatemporaryadaptorisNOT
recommended.
NOTE:InCanada,theuseofatemporaryadapterisnotpermittedbytheCanadian
ElectricalCode.
9.0 Machine Parts List - with Heat
Drawing No. Item ID Item Description Qty. Needed
1 SP-3-ST-BLKGRAN 3-Gallon Solution Tank - Black Granite 1.00
2 SP-3-RT-BLUGRAN 3-Gallon Recovery Tank - Blue Granite 1.00
3 10-0383 6-32 x 1/4” Phil Pan Screw 6.00
4 10-0400-D Latch for Sniper 1.00
5 10-0412 C-Channel for Spotter Handle 2.00
6 10-0414 Rivet for Spotter Handle 4.00
7 10-0384 .125 Thick Nylon Washer 4.00
8 10-0385 .06 Thick Nylon Washer 4.00
9 10-0074 Flat Washer #8 SAE 11.00
10 10-0216 Allen Head Screw for Backpack 4.00
11 10-0379 8-32 x 3/8” Screw 4.00
12 10-0405 1-1/2” PVC SCH40 Slip Thread 1.00
13 10-0302-A Hatch Cover Gasket for Spotter 1.00
14 10-0416-A 1-1/2” Black ABS Stand Pipe 1.00
15 10-0304 Spotter Cap and Float Assembly 1.00
16 10-0419 Screw for Spotter Hatch 6.00
17 SP-3-HS-BLKGRAN 3-Gallon Heater Skirt - Black Granite 1.00
18 10-0831 S/R Bracket for Sniper 1.00
19 10-0832 S/R Strap Bolts 2.00
20 10-0300 55 PSI Pump for Spotter 1.00
21 10-0403-M 1/8” Brass Male Nipple 1.00
22 10-0901 175 PSI Relief Valve for Heater 1.00
23 10-0510 1/8” Brass Plug 1.00
24 80-0017 Bulk Head tting for Sniper 2.00
25 80-0024-B 1/4” MPT x 3/8” Barb 4.00
26 10-0826 3/4” Hose Clamp for Sniper 6.00
27 10-0843 3/8” Black Hose for Sniper 1.00
28 10-0434 Threaded Hose for Spotter 1.00
29 10-0407 1/8” Strait Nylon Barb NPT 2.00
30 10-0845-2 1/8” Strainer for Spotter 1.00
31 10-0301 L Bracket for Spotter 1.00
32 10-0828 90 Degree Brass Fitting for Sniper 1.00
33 10-0022 Shoulder and Waist Belt Screw 3.00
34 10-0017 Deector Screw 1.00
35 T-C-011 Female Terminal Connector 10.00
36 T-WPUR Purple Wire
37 80-0011-2 90 Degree Street Elbow 1.00
38 80-0010 1/4” Brass Tee 1.00
39 10-0843 3/8” Black Hose for Sniper 1.00
40 10-0852 1/4” 90 Degree Brass Elbow 1.00
41 80-0101-M 1/4” Male Check Valve 1.00
42 80-0014 3/8” B x 1/4” F 90 Degree 1.00
43 10-0479 1/4” Male Close Nipple 1.00
44 10-0870 1/4” Male QD 1.00
45 10-1500-B Heater Element 600 Watt 1.00
46 10-0814 Senor for Sniper Heater 1.00
47 10-0814-B Manual Sensor for Heater 1.00
48 10-0907 Strain Relief for Tube Heater 1.00
49 10-0906 Box for Tubular Heater 1.00
50 10-0900 Heater Body Tubular 1.00
51 10-0801-G Pipe Wrap Insulation for Heater 1.00
52 SP-3-H-BLK 3-Gallon Spotter Handle - Black 1.00
53 10-0387 5/16” x 1” Spotter Wheel Bolt 2.00
54 10-0303 Roller Blade Wheel for Spotter 2.00
55 10-0822 Exhaust Grate for Sniper 2.00
56 10-0419-A Screw for Sniper Hatch 2.00
57 10-0014 Motor Screw 2.00
58 10-0380 10-32 x 3/8” Screw 2.00
59 10-1024 Motor Mount Plate for Spotter 1.00
60 10-0354 3 Gallon Spotter Motor 1.00
61 10-0386 Stamped Motor Screen 1.00
63 10-1030 Spotter Motor Gasket 1.00
64 10-0027-A Strain Relief Nut 1.00
65 T-WBLA Black Wire

(10) 3-Gallon EZ Spot Extractor Series 3-Gallon EZ Spot Extractor Series (7)
5.0 Machine Schematic Drawing - no Heat
8.0 Machine Schematic Drawing - with Heat

(8) 3-Gallon EZ Spot Extractor Series 3-Gallon EZ Spot Extractor Series (9)
6.0 Machine Parts List - No Heat
Drawing No. Item ID Item Description Qty. Needed
1 SP-3-ST-BLKGRAN 3-Gallon Solution Tank - Black Granite 1.00
2 SP-3-R-BLUGRAN 3-Gallon Recovery Tank - Blue Granite 1.00
3 10-0383 6-32 x 1/4” Phil Pan Screw 6.00
4 10-0400-D Latch for Sniper 1.00
5 10-0412 C-Channel for Spotter Handle 2.00
6 10-0414 Rivet for Spotter Handle 4.00
7 10-0384 .125 Thick Nylon Washer 4.00
8 10-0385 .06 Thick Nylon Washer 4.00
9 10-0074 Flat Washer #8 SAE 5.00
10 10-0216 Allen Head Screw for Backpack 4.00
11 10-0379 8-32 x 3/8” Screw 4.00
12 10-0405 1-1/2” PVC SCH40 Slip Thread 1.00
13 10-0302-A Hatch Cover Gasket for Spotter 1.00
14 10-0416-A 1-1/2” Black ABS Stand Pipe 0.60
15 10-0304 Spotter Cap and Float Assembly 1.00
16 10-0419 Screw for Spotter Hatch 6.00
17 SP-3-H-BLK 3-Gallon Spotter Handle - Black 1.00
18 10-0406 Nylon Barb 90 1/8” NPT 1/4” 2.00
19 80-0017-2 Bulk Head tting for Spotter 1.00
20 10-0403 1/8” Brass Female Coupler 1.00
21 10-0402 1/8” Male QD 1.00
22 10-0434 Threaded Hose for Spotter 2.50
23 10-0407 1/8” Strait Nylon Barb NPT 4.00
24 10-0845-2 1/8” Strainer for Spotter 1.00
25 10-0300 55 PSI Pump for Spotter 1.00
26 10-0301 L Bracket for Spotter 1.00
27 10-0435 Oetiker Clamp 4.00
28 10-0303 Roller Blade Wheel for Spotter 2.00
29 10-0387 5/16” x 1” Spotter Wheel Bolt 2.00
30 10-0022 Shoulder and Waist Belt Screw 1.00
31 10-0017 Deector Screw 1.00
32 10-1028 Bottom Base Plate for Spotter 1.00
33 10-0492 Screw for Plates on Spotter 2.00
34 10-0014 Motor Screw 2.00
35 10-0380 10-32 x 3/8” Screw 2.00
36 10-1024 Motor Mount Plate for Spotter 1.00
37 10-0354 3-Gallon Spotter Motor 1.00
38 10-0386 Stamped Motor Screen 1.00
39 10-1030 Spotter Motor Gasket 1.00
40 10-0027-A Strain Relief Nut 1.00
41 10-1026 Switch Plate for 3-Gallon w/ Heat 1.00
42 10-0027 Pigtail Strain Relief 1.00
43 10-0448 20-Foot Spotter Cord 1.00
44 10-0025 On/Off Switch 2.00
45 10-0400-C Keeper Latch for Spotter 1.00
7.0 Hoses and Hand Tool Drawing and Parts List
10-0505 4” Stainless Steel Hand Tool with Clear View Head for
Machines with No Heat
Parts List
Drawing No. Item No. Item Description Qty. Needed
1 10-0505 4” Stainless Steel Hand Tool
with Clear View Head 1.00
2 10-0463 Black Slip Hose Cuff for Spotter 2.00
3 50-1007 7-Foot Black Hose for Spotter 1.00
4 10-0474 1/8” Female QD for Spotter 1.00
5 10-0475 Solution Hose for Spotter 1.00
6 10-0388 Velcro Strap 1.00
7 10-0402 1/8” Male QD for Stainless Steel Hand Tool 1.00
8 10-0403 1/8” Brass Female Coupler 1.00
9 10-0506 Valve Clamp for Stainless Steel Hand Tool 1.00
10 10-0504 Valve for Stainless Steel Hand Tool 1.00
11 10-0502 Jet for Stainless Steel Hand Tool 1.00
