Jorg Gray JG Series User manual

1
Introduction 2-3
Miyota2-handwithandwithoutdatedisplay          4
Miyota3-hand,off-setsecondhandanddatedisplay   5
Miyota3-handwithdatedisplay
Miyota3-handwithdate(anddayoftheweek)display      6-7
MiyotaRetrograde/DualTime                     8
MiyotaChronograph(11hours59minutesand59seconds)     9-10
MiyotaChronograph(59minutesand59seconds)        11-12
Tachometer13
Importantwatchinformation–waterrelateduse       14
WarrantyandRegistration                      15-16
CareSuggestions17
English 1-17
Japanese 19-35
Arabic 37-53
Korean 55-71
Chinese 73-89




2
CongratulationsonthepurchaseofyourJorgGray
TimepieceWeappreciatethetrustyouhavejustplacedinour
watchcollection
Toobtainserviceunderwarranty,youwillberequiredtollout
thefollowingandpresentproofofpurchasewhensendingin
yourwatchforservice
NameofOfcialJorgGrayJeweler:________________________
________________________________________________________
NameandaddressofPurchaser:__________________________
________________________________________________________
________________________________________________________
________________________________________________________
Dateofpurchase: _______________________________________
Month|Day|Year
[ STAMP ]

3

AtJorgGray,wechallengeourselvestocreatetimepieces
thatpeoplelovenotonlyfordesignbutalsoforthehigh
levelofquality
Visuallystriking,boldindesign,ourtimepiecescombine
styling,materialsandcolorsthatappealtotoday’smen
andwomen,whilemaintainingarespectfortraditional
valuesofprecisionandattentiontodetail
JorgGraywatchesareengineeredusinghighquality
materialsandconstructedwitheitherprecisionSwiss
orJapanesemovements
JorgGray—designedtochangethewayweviewtime


4
Hour hand
2nd position
1st position
*Date
Minute hand
Normal crown
position
7



*Datedisplaymaybelocatedatdifferentposition,depending
oneachindividualwatchmodel

1Pullthecrownouttothe2ndposition
2Turnthecrowntosethourandminutehands

1Pullthecrownouttothe1stposition
2Turnthecrowncounter-clockwisetosetthedate
*Ifthedateissetbetweenthehoursofaround9:00PMand
2:00AM,thedatemaynotchangeonthefollowingday
3Afterthedatehasbeenset,pushthecrownbacktothe
normalposition

5



*Datedisplaymaybelocatedatdifferentposition,depending
oneachindividualwatchmodel

1Pullthecrownouttothe2ndposition
2Turnthecrowntosethourandminutehands
3Whenthecrownispushedbacktothenormalposition,
smallsecondhandbeginstorun

1Pullthecrownouttothe1stposition
2Turnthecrowncounter-clockwisetosetthedate
*Ifthedateissetbetweenthehoursofaround9:00PMand
2:00AM,thedatemaynotchangeonthefollowingday
3Afterthedatehasbeenset,pushthecrownbacktothe
normalposition
|
|
|
|
|
|
|
|
|
|
|
60
30
15
45
7
Off-set second hand
Normal crown position
2nd position
1st position
Minute hand
Date
Hour hand

6




*Somefeaturesmightbedifferent,dependingoneach
individualwatchmodel
Hour hand
Second hand
2nd position
1st position
*Date
Minute hand
Normal crown
position
Hour hand
Second hand
2nd position
1st position
*Date
Day of the week
Minute hand
Normal crown
position

7

1Pullthecrownouttothe2ndposition
2Turnthecrowntosethourandminutehands
3Whenthecrownispushedbacktothenormalposition,
smallsecondhandbeginstorun

1Pullthecrownouttothe1stposition
2Turnthecrowncounter-clockwisetosetthedate
*Ifthedateissetbetweenthehoursofaround9:00PMand
1:00AM,thedatemaynotchangeonthefollowingday
3Afterthedatehasbeenset,pushthecrownbacktothe
normalposition

1Pullthecrownouttothe1stposition
2Turnthecrownclockwisetothedayoftheweek
*Ifthedateissetbetweenthehoursofaround9:00PM
and1:00AM,thedayoftheweekmaynotchangeonthe
followingday
3Afterthedayoftheweekhasbeenset,pushthecrown
backtothenormalposition

8




1Pullthecrownouttothe2ndposition
2Turnthecrownouttosethourandminutehands
3Whenthecrownispushedbacktothenormalposition,
secondhandbeginstorun

1Pullthecrownouttothe1stposition
2Turnthecrownclockwisetosetthedate
*Ifthedateissetbetweenthehoursofaround9:00PMand
2:00AM,thedatemaynotchangeonthefollowingday
3Afterthedatehasbeenset,pushbacktothenormalposition

1Pullthecrownouttothe1stposition
2Turnthecrowncounter-clockwisetosetthe2ndtime(24hr)
3Afterthe2ndtime(24hr)hasbeenset,pushbacktonormal
position
Minute hand
1st position
2nd position
Normal crown position
2nd Time
(0 hour to 24 hours)
Second hand
Hour hand
Date (1-31)
24 hour hand

9


ChronographFunction:Centersecondhandchronograph1/1sec
Timingupto11hours59minutes59seconds


1Pullthecrownouttothe2ndposition
2Turnthecrowntosethourandminutehands
3Whenthecrownispushedbacktothenormalposition,
smallsecondhandbeginstorun

1Pullthecrownouttothe1stposition
2Turnthecrownclockwisetosetthedate
*Ifthedateissetbetweenthehoursofaround9:00PMand
1:00AM,thedatemaynotchangeonthefollowingday
3Afterthedatehasbeenset,pushthecrownbacktothe
normalposition
1st position
2nd position
Normal crown
position
Chronograph
minute hand
FS20 Display and Buttons
FS10 Display and Buttons
Chronograph
second hand
24 hour hand
Minute hand
Button (A)
Button (B)
Date
Hour
hand
Second hand
Chronograph
minute hand
Chronograph
second hand
Minute hand
Button (A)
Button (B)
Date
Hour
hand
Second hand
FS10
24 hour hand
1st position
2nd position
Normal crown
position

10

Thischronographisabletomeasureanddisplaytimein1/1second
uniteduptomaximumof11hours59minutes59seconds
Thechronographsecondhandkeepscontinuouslyfor11hours
59minutes59secondsafterstarting

1Thechronographcanbestartedandstoppedeachtime
button“A”ispressed
2Pressingbutton“B”resetsthechronographandthe
chronographsecondhandandchronographminutehand
returnstozero/12o’clockposition

Thisprocedureshouldbeperformedwhenthechronograph
secondhanddoesnotreturntozeropositionafterthechronograph
hasbeenreset,andincludingafterthebatteryhasbeenreplaced
1Pullthecrownouttothe2ndposition
2Pressbutton“A”tosetthechronographsecondhandto
thezeropositionThechronographhandcanbeadvanced
rapidlybycontinuouslypressingbutton“A”
3Oncethehandshavebeenzeroed,resetthetimeandreturn
thecrowntoitsnormalposition
*Donotpushcrowntonormalpositionwhilethechronograph
secondhandreturnsto12:00(zero)positionHandstopsonthe
waywhencrownisreturnedtonormalpositionanditspositionis
recognizedas12:00(zero)position
RESET STOPTIME MEASUREMENT
“A”
“A”
“A”
“B” “B”

11


ChronographFunction:Centersecondhandchronograph1/1sec
Timingupto59minutes59seconds


1Pullthecrownouttothe2ndposition
2Turnthecrowntosethourandminutehands
3Whenthecrownispushedbacktothenormalposition,
smallsecondhandbeginstorun

1Pullthecrownouttothe1stposition
2Turnthecrownclockwisetosetthedate
*Ifthedateissetbetweenthehoursofaround9:00PMand
1:00AM,thedatemaynotchangeonthefollowingday
3Afterthedatehasbeenset,pushthecrownbacktothe
normalposition
6
0
I
I
i
l
5
I
I
l
l
1
0
I
I
l
l
1
5
I
I
l
l
2
0
I
I
l
l
2
5
I
I
l
l
3
0
I
I
l
l
3
5
I
I
l
l
4
0
I
I
l
l
4
5
I
I
l
l
5
0
I
I
l
l
5
5
l
I
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
60
30
10
20
50
40
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
60
30
10
20
50
40
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
24
12
4
816
20
Hour hand
Chronograph
minute hand
Small Second hand Calendar
Button B
Normal crown
position
2nd position
1st position
Button A
Minute hand
Chronograph
second hand
24 hour hand

12

Thischronographisabletomeasureanddisplaytimein1/1
seconduniteduptomaximumof59minutes,59seconds
Thechronographsecondhandkeepscontinuouslyfor59
minutes,59secondsafterstarting

1Thechronographcanbestartedandstoppedeachtime
button“A”ispressed
2Pressingbutton“B”resetsthechronographandthe
chronographsecondhandandchronographminutehand
returnstozeroposition

Thisprocedureshouldbeperformedwhenthechronograph
secondhanddoesnotreturntozero/12o’clockpositionafter
thechronographhasbeenreset,andincludingafterthebattery
hasbeenreplaced
1Pullthecrownouttothe2ndposition
2Pressbutton“A”tosetthechronographsecondhandto
thezeropositionThechronographhandcanbeadvanced
rapidlybycontinuouslypressingbutton“A”
3Oncethehandshavebeenzeroed,resetthetimeandreturn
thecrowntoitsnormalposition
*Donotpushcrowntonormalpositionwhilethechronograph
secondhandreturnsto12:00(zero)positionHandstopson
thewaywhencrownisreturnedtonormalpositionandits
positionisrecognizedas12:00(zero)position
RESET STOPTIME MEASUREMENT
“A”
“A”
“A”
“B” “B”

13

Atachometer(ortachymeter)isadevicethatmeasures
averagespeedoverasetdistanceItcanbeusedtocheck
accuracyofacar’sspeedometer,forexample
Aroaddistanceof1Kilometeror1mileisgenerallytaken
asabasis

1Asthecarpassespoint  ,startthechronographby
pressingbutton“A”
2Themomentthecarpassespoint
 ,ieafter1mileor1
Kilometer,pressbutton“A”againThechronographwillstop
3Ontheoutertachometricscale,thechronographsecond
handindicatesagurethatrepresentstheaveragespeed
inmilesorKilometerperhour,accordingtothedistance
basisselected
 
1 Mile/km

14
INDICATION WATER RELATED USE
Depth Case back
marking
Light spray,
rain,
respiration
etc
Bathing
etc.
Swimming
etc. Diving Water-resistant characteristics
- - NO NO NO NO NONwaterresistant;mustbekept
awayfromwater
- Water-resistant OK NO NO NO Ordinarywaterresistance
3ATM
(3bar)
Water-resistant
30m
OK NO NO NO Normaldailywatercontact
5ATM
(5bar)
Water-resistant
50m
OK OK OK NO SwimmingandBathing:Yes
Diving:No
10ATM-20ATM
(10bar-20bar)
Water-resistant
100m-200m
OK OK OK OK Suitableforskindiving
 •Whenwatchisunderwaterorwet,neverusethepushers/bezel,orsetthetime! •PleasedonottakeyourJorgGraywatchintohottubsorsaunasThecombinationof
extremeheatandwatermaycauseyourwatchtolosesomeofitswater-resistance!


15

JorgGraywillwarrantyeverywatchsoldforaperiodoftwo(2)
yearsfromdateofpurchaseWewillrepairorreplace(atJorg
Gray’sdiscretion)themovementofyourJorgGraytimepiece
freeofchargeifthemovementprovestobedefectivein
materialorworkmanshipundernormaluse

Thiswarrantyisvoidifalteration,serviceorrepairisperformed
byanypartyotherthanJorgGrayTimepiecesorAuthorized
ServiceCentersOtheritemsnotcoveredunderthiswarranty
include:batteries,bracelets/strapsorcrystalsInaddition,this
warrantydoesnotcoverdamagearisingfromnormalwear,
scratches,accidentsormisuse

Thiswarrantyisvoidifthetimepiecewasnotpurchased
fromanAuthorizedJorgGrayDealer,asevidencedbyyour
registrationonlineatwwwjorggraycom/registration

Legalrightsvary,regardingwarranties,fromStatetoStateand
CountrytoCountryThiswarrantyprovidesyouwithspecic
legalrights;youmayalsohaveadditionallegalrightsunder
applicablelawsforyourregion,andwhicharenotaffectedby
thetermsofthiswarranty
To activate your warranty, register your timepiece at
www.jorggray.com/registration

16

ShouldyourJorgGraytimepiecerequireserviceorrepair,you
maysendittotheJorgGrayAuthorizedServiceCenterlisted
belowForthemostcurrentandcompletelistofJorgGray
AuthorizedServiceCentersworldwide,visitusonlineat
wwwjorggraycom/authorized-service-center

ToobtainserviceundertheJorgGrayWarranty,youmust
haveactivatedyourwarrantybyregisteringyourtimepiece
atwwwjorggraycom/registration

Inordertoutilizewarrantyservice,youwillberequired
topresentproofofpurchaseindicatingthenameofthe
authorizedJorgGrayDealerincludinghissignatureandthe
dateofthepurchasePleasesendinyourwatch,withproofof
purchase,includingacompletedJorgGraywatchrepairform
(availableatwwwjorggraycom/returnstotheaddresslisted
below(seeAuthorizedServiceCenter)Additionalchargesfor
domesticandinternationalshippingwillapply
Incaseofnon-manufacturerdefectorexpiredwarranty,charges
forrepair,handlingandshippingmayapplyForcurrentrepair
rates,pleasecontactourAuthorizedServiceCenterlistedbelow
AuthorizedServiceCenter:

17

Toviewacompleteworldwidelistingofourmostcurrent
authorizeddealers,pleasegoto:
 wwwjorggraycom/authorized-dealers
YourJorgGrayTimepiecehasbeendesignedand
craftedwiththehighestqualitycomponentstogiveyou
yearsofenjoymentandexcellentservice
Pleasefollowsimplecaresuggestions:
1 Ifyourquartzwatchstops,thebatterymaybe
replacedbyyourlocaljewelerorwatchrepairservice
center
2 Haveyourwatchcleanedonaregularbasis
3 Avoidunnecessarilyroughtreatment
4 Replacebrokenorcrackedcrystalimmediately
5 Donotopenthebackofthecaseyourselftoadjust
orregulate


18
