Jorgenson Lockers Gladiator Installation guide

Assembly Instructions
1
Jorgenson Ball Storage Gladiator Lockers
Tip: Ensure that the
bolts are installed
on the outside of
locker and nuts
are secured on the
inside of the locker.
TIP:
Identify Parts
Start Assembling
Remove unassembled locker parts from the packaging.
Next, locate and identify each part based on the
images show below:
• Position the back panel on straight, even ooring or pair of saw horses.
• Gently bolt the left and right side panels to the inside of the back panel ange.
(1) Front Frame (1) Back Panel (2) Side Panels (2) Top/Bottom
Panels
Bolt the tamper-proof
screw on the inside
of the locker. Only the
screw heads should
be visible from the
outside of the locker.
Left Side Panel
Right Side Panel
Top holes are
1/2” at the top
of each panel
shown.
(1) Bottom Shelf (1) Top Shelf
(with number plate)
(1) Ball Storage
Cord
View of locker with back panel at
on oor or saw horses
The left and right side panels
must be placed inside the back
panel anges.
Side Panels
Back Panel

Assembly Instructions
2
Jorgenson Ball Storage Gladiator Lockers
Continued Assembly
• Slightly bolt the top/bottom panels and shelves inside the side and back panel.
• Proceed to bolt the front frame on the outside of the left, right and bottom panels.
Note:
Top and bottom panels have two (2)
round, pre-drilled holes that can be found
on the back ange and are designed to
bolt to the back panel.
Stringing the Cord
• Feed the cord through the hole in the top left
corner.
• Weave the cord up and down through the holes,
starting in the left and moving to the right (as
shown by the path of the arrows).
• End on the bottom right hole.
• Tie knots on both ends of cord to secure in
place.

Assembly Instructions
3
Jorgenson Ball Storage Gladiator Lockers
Insert Front Door Frame
• Place locker in the upright position and make sure locker is level.
•Tighten all bolts.
• To instill proper safety measures, we highly advise anchoring the locker to the oor or wall to avoid injury
or theft.
