Joyolight CON-MULTI-4Z User manual

Five-year warranty
Contact us for complete terms
and conditions.
Joyolight reserves the rights change our products and specifications
at anytime without prior notice and such modification shall be effective
immediately. Contact Joyolight for the latest product information.
JOYOLIGHT GROUP INC.
#12, 5200 Dixie road
Mississauga, ON, L4W 1E4
www.joyolight.ca
[e-mail]
1-877-849-1942 (US)
647-496-8107 (CA)
INS 2022-05
CON-MULTI-4Z
CON-MULTI-4Z USER MANUAL
DIM/CCT/RGB/RGBW/RGB2W
2022-05
#12, 5200 Dixie Rd,
Mississauga, ON
Canada L4W 1E4
www.joyolight.ca
[email protected]
4 ZONE CONTROLLER
B+B-
S+S-
M
w
Zone
*
SET

Five-year warranty
Contact us for complete terms
and conditions.
Joyolight reserves the rights change our products and specifications
at anytime without prior notice and such modification shall be effective
immediately. Contact Joyolight for the latest product information.
JOYOLIGHT GROUP INC.
#12, 5200 Dixie road
Mississauga, ON, L4W 1E4
www.joyolight.ca
[email protected]
1-877-849-1942 (US)
647-496-8107 (CA)
INS 2022-05
CON-MULTI-4Z
Technical Parameters
Voltage: 3V (2* AAA battery)
RF Frequency: 2.4GHz
Remote Control Distance: up to 20m
Size: L150*W40*H20mm
Net weight: 95g
CONTROL FUNCTION
1. Single color 2. CCT (CW+WW)
CONTROLLER 4
CON-MULTI-4Zones
For DIM/CCT/RGB/RGBW/RGB2W
B+B-
S+S-
M
w
Zone
*
SET
B+B-
S+S-
M
w
Zone
*
SET
Installation of remote control’s bracket:
1. Accessories include: bracket 1pc, 3M foam sponge glue 1pc,
screw 2pcs, expansion tube 2pc.
2. There are 2 options for bracket installation:
1) Using screw and expansion tube for drilling
installation (suitable for uneven and ash surfaces);
2) Using 3M foam sponge glue for free drilling
installation (suitable for at and no ash surface).
ON ONOFF OFF
Dimming ring CCT ring
Brightness-
5 levels(10%, 30%,
50%, 70%, 100%)
Brightness-
5 levels(10%, 30%,
50%, 70%, 100%)
Brightness+
5 levels(10%, 30%,
50%, 70%, 100%)
Brightness+
5 levels(10%, 30%,
50%, 70%, 100%)
Brightness+
(1024 levels. long press
for fast adjusting)
Brightness+
(1024 levels. long press
for fast adjusting)
Speed+
(Speed down for dy-
namic mode.100 levels.
long press for fast
adjusting)
Speed+
(Speed down for dy-
namic mode.100 levels.
long press for fast
adjusting)
Zone indicator Zone indicator
Zone Selector
long press 2s
to ALL control
Zone Selector
long press 2s
to ALL control
Brightness-
(1024 levels. long press
for fast adjusting)
Brightness-
(1024 levels. long press
for fast adjusting)
Speed-
(Speed down for dynamic
mode.100 levels. long press
for fast adjusting)
Speed-
(Speed down for dynamic
mode.100 levels. long press
for fast adjusting)
Set Key Set KeyRF signal indicator RF signal indicator
Mode Mode

Five-year warranty
Contact us for complete terms
and conditions.
Joyolight reserves the rights change our products and specifications
at anytime without prior notice and such modification shall be effective
immediately. Contact Joyolight for the latest product information.
JOYOLIGHT GROUP INC.
#12, 5200 Dixie road
Mississauga, ON, L4W 1E4
www.joyolight.ca
[email protected]
1-877-849-1942 (US)
647-496-8107 (CA)
INS 2022-05
CON-MULTI-4Z
3. RGB
5. RGB+CCT
4. RGBW
B+B-
S+S-
M
w
Zone
*
SET
B+B-
S+S-
M
w
Zone
*
SET
B+B-
S+S-
M
w
Zone
*
SET
ON
RGB-ON
RGB-ONOFF
RGB-OFF
RGB-OFF
Color ring
White hot key
CW-ON/OFF
W- ON/OFF
Color ring
Color ring
6 colors hot key-
(6 static color: cyan - purple
- yellow - blue - green - red)
CW/CCT-
Balance to warm white.
Long-press can get fast
adjusting
W-Brightness-
6 colors hot key+
(6 static colors: red - green -
blue - yellow - purple - cyan)
CW/CCT+
Balance to cool white. Long
press can get fast adjusting
W-Brightness+
Brightness+
(1024 levels. long press
for fast adjusting)
RGB/CCT-Brightness+
(for RGB/CCT static colors. long
press for fast adjusting)
Brightness+
(1024 levels. long press
for fast adjusting)
Speed+
(Speed down for dy-
namic mode.100 levels.
long press for fast
adjusting)
Speed+
(Speed down for dy-
namic mode.100 levels.
long press for fast
adjusting)
Speed+
(Speed down for dy-
namic mode.100 levels.
long press for fast
adjusting)
Zone indicator
Zone indicator
Zone indicator
Zone Selector
long press 2s
to ALL control
Zone Selector
long press 2s
to ALL control
Zone Selector
long press 2s
to ALL control
Brightness-
(1024 levels. long press
for fast adjusting)
RGB/CCT-Brightness-
(for RGB/CCT static colors. long
press for fast adjusting)
Brightness-
(1024 levels. long press
for fast adjusting)
Speed-
(Speed down for dynamic
mode.100 levels. long press
for fast adjusting)
Speed-
(Speed down for dynamic
mode.100 levels. long press
for fast adjusting)
Speed-
(Speed down for dynamic
mode.100 levels. long press
for fast adjusting)
Set Key
Set Key
Set KeyRF signal indicator
RF signal indicator
RF signal indicator
Mode
Mode(8 dynamic modes)
Mode
# Mode Marks
1White breathe
adjustable speed
brightness is
unadjustable
23 colors jumpy
37 colors jumpy
43 colors fade
57 colors fade
6R/G cross fade
7R/B cross fade
8G/B cross fade
About “all-control”
This system is available to achieve mixed control, like zone 1-single
color, zone 2-CCT, zone 3- RGB, zone 4- RGBW.
The all buttons’ functions are active in all-control mode, the effect
for each zone will according to the output type setting of each
receiver( 4 in 1 controller); RGB+CCT type has a special controller
item for it, no need to set.

Five-year warranty
Contact us for complete terms
and conditions.
Joyolight reserves the rights change our products and specifications
at anytime without prior notice and such modification shall be effective
immediately. Contact Joyolight for the latest product information.
JOYOLIGHT GROUP INC.
#12, 5200 Dixie road
Mississauga, ON, L4W 1E4
www.joyolight.ca
[email protected]
1-877-849-1942 (US)
647-496-8107 (CA)
INS 2022-05
CON-MULTI-4Z
Connecting the load to
the receiver and power
on it.
1. It is necessary to clear
the code if the receiver was
coded before.
2. Batch operation can be
performed within the remote
control range.
Connecting the load to
the receiver and power
on it.
1. The clearing operation
should be nished within 1
minute after the receiver is
powered on
2. Batch operation can be
performed within the remote
control range.
Remote control A: Press
and hold “ON” on the
remote control for 5 sec
1. It enters the pairing code
transmission when the load
light ashes quickly.
2.It will also automatically
exit code transmission status
after 60 sec. or pressing any
key to exit.
Select Area
Select the area with the “Zone”
key and the corresponding indi-
cator lights up
Press and hold the remote
control “Off” for 5 sec.
There is no need to select
the corresponding area
when clearing code.
1.It enters the clearing code
transmission when the load
light ashes quickly.
2.It will also automatically exit
code transmission status after
60 sec. or pressing any key
to exit.
Remote control B: long
press “mode key” for 5 sec
1.It enters the code receiving
status when the indicator light
changes from 100% to off.
2.It will also automatically exit
code receiving status after 30
sec. or exit after learning the
code value successfully.
Press and hold “ON” on
the remote control for 5
sec
1.It enters the clearing code
transmission when the load
light ashes quickly.
2.It will also automatically
exit code transmission status
after 60 sec. or pressing any
key to exit.
See the load light ashes
3 times and return to the
initial state
Pairing coding nishes
successfully
See the load light ashes
3 times and return to the
initial state
Clearing coding nishes
successfully
See the remote control
B indicator light ash 3
times
Code copying nishes and
the controller exits code
value receiving status.
Code Matching
Code Clearing
Code Learning
4
Used to unify system code values or copy a new remote control. Since each
remote control has its own unique code at the time of delivery, when there are
multiple remote controls in one system, one of them (for example, remote control
A) must be selected as the system code value, and the code value
of the rest remote controls (for example, remote control
B) should be copied to the same one.

Five-year warranty
Contact us for complete terms
and conditions.
Joyolight reserves the rights change our products and specifications
at anytime without prior notice and such modification shall be effective
immediately. Contact Joyolight for the latest product information.
JOYOLIGHT GROUP INC.
#12, 5200 Dixie road
Mississauga, ON, L4W 1E4
www.joyolight.ca
[email protected]
1-877-849-1942 (US)
647-496-8107 (CA)
INS 2022-05
CON-MULTI-4Z
Cut off the power of re-
ceiver which is controlled
by the controller
Long press “mode “ for
20 seconds
The remote indicator light
dims down and ashes
continuously until the 20th
second and then back to
100% light. Means this step
is nished.
Long press “mode key” for
5 sec
It will also automatically exit
code receiving status after 30
sec. or exit after learning the
code value successfully.
Press the “OFF” to conrm,
the remote indicator light
ashes 3 times
Restore factory settings
successfully.
Power on the receiver.
Code copying nishes when
remote control indicator light
ashes 3 times.
The controller exits code
value receiving status.
Code Copying
Restore the
Factory Setting
A new remote control can also copy code from any one of the receivers in the whole
system, after the successful operation, the new remote control can replace the original
remote (if it is lost).
The remote control will be restored to the factory’s unique code value.
* For security of the system, the distance from remote control to the one receiver should be less than 2 meters in this operation.
*Only one time operation is requested for the whole system, no need different operation for different zones.
