Air Fryer Oven
INSTRUCTION MANUAL
KX26-V581-US01
KX26-V581-CA01

21
Contents
Important Safeguards ---------------------------------------------------------2
Getting to know your Air Fryer Oven --------------------------------------------4
Main Component -----------------------------------------------------------4
Feature --------------------------------------------------------------- -----5
Technical Specification-----------------------------------------------------5
LED Control Panel ---------------------------------------------------------6
Before using your Air Fryer Oven -----------------------------------------------8
Operation Guide-----------------------------------------------------------------9
Cooking Functions Quick Reference Chart--------------------------------------9
Replacing the light ----------------------------------------------------- -------10
Care, Cleaning & Store---------------------------------------------------------11
Troubleshooting ---------------------------------------------------------------14
Preface
Thank you for choosing our Steel Man Air Fryer Oven Pro. We have written
this manual to aid you in using and maintaining this product safely and properly.
Please read this manual carefully before using and keep it for your reference.
Important Safeguards
When using an electrical appliance, basic safety precautions should always be
followed, including the following:
1. READ ALL INSTRUCTIONS BEFORE USE.
2. Unplug from outlet when not in use and before cleaning. Allow to cool before
cleaning or handling, putting on or taking off parts.
3. Do not touch hot surfaces. Use mittens to avoid burns, use extreme caution
when moving an appliance containing hot oil or other hot liquids.
4. Do not immerse cord, plug or any parts of airfryer oven in water or other
liquid to prevent against electrical hazard.
5. This appliance should not be used by or near children.
6. Do not operate any appliance with a damaged cord or plug. After appliance
malfunctions or is dropped or damaged in any manner.
7. The use of accessory attachments not recommended by the appliance
manufacturer may cause hazard or injury.
8. Do not use outdoors.
9. Do not let cord hang over the edge of the table or countertop, where it
could be pulled on inadvertently by children or pets, or touch hot surfaces,
which could damage the cord.
10. Do not place on or near a hot gas or electric burner.
11. Do not use this appliance for other than intended use.
12. Extreme caution should be exercised when using containers constructed of
materials other than metal or glass in the air fryer oven.
13. When not in use, always unplug the unit. Do not store any materials other
than manufacturer’s recommended accessories in this appliance when
not in use.
14. Do not place any of the following materials in this appliance: cardboard,
plastic, paper, or anything similar.

3 4
15. Do not cover crumb tray or any part of the air fryer oven with metal foil.
This will cause overheating of the air fryer oven.
16. Oversized foods, metal foil packages or utensils must not be inserted in an
air fryer oven as they may involve a risk of fire or electric shock.
17. A fire may occur if the appliance is covered or touching flammable
materials such as curtains, draperies or walls, when in operation. Do not
store any items on top of the appliance when in operation. Do not operate
under wall cabinets.
18. Do not clean with metal scouring pads. Pieces can break off the pad and
touch electrical parts, involving a risk of electric shock.
19. Warning: To avoid possibility of fire, never leave the appliance unattended
during use.
20. Use recommended temperature settings for all function.
21. Do not rest cooking utensils or baking dishes on glass door.
22. Do not operate your appliance in an appliance garage or under a wall
cabinet. When storing in an appliance garage, always unplug the unit from
the electrical outlet. Not doing so could create a risk of fire.
23. Before plugging into a socket, check that the voltage in your home
corresponds with the voltage printed on the appliance.
24. Always attach plug to appliance first, then plug cord into the wall outlet. To
disconnect, turn any control to″off,″then remove plug from wall outlet.
25. A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.
26. This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit into a polarized
outlet only one way.If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician. Do not attempt to
modify the plug in any way.
FOR HOUSEHOLD USE ONLY
NOT FOR COMMERCIAL USE
GETTING TO KNOW YOUR AIR FRYER OVEN
MAIN COMPONENT
LED Control Panel
Door Handle
Oven Light
Visible Door
(Double Glass)
Air Fry oven light
Tap the "light" button to turn the light on or off .To save energy, the light will
turn off automatically after 5 minutes.
Oven Rack x1
Ideal for toasting, grilling meats &
vegetables, pizzas, snacks, and more.
Air Fryer Basket x1
Ideal for smaller foods like fries, wings,
other vegetables, snacks, and dehydrating
fruits, meats, and herbs.
Drip tray or baking pan x1
Mostly used as a drip tray to protect the
lower heating coils and catch excess oil and
grease for easy cleanup. It can also be used
for baking cookies and desserts.

5 6
Roast Chicken Fork
It is mainly used for whole or large pieces of
meat, When baking, keep rotating, can make
food heated evenly, baked food better,
delicious.
FEATURE
By using all-new 360° HOT AIR CIRCULATION technology, The Air Fryer Oven
can offer you more delicious and healthier cuisine.
Door Sensor
If the door is opened during cooking, the cooking will pause. When the door is
closed, resume cooking. Please make sure to keep the oven door closed during
cooking.
Cord Storage
Cord storage design at the back. Takes up excess cord and keep countertop
neat.
TECHNICAL SPECIFICATION
Power Supply Rated Power Capacity Package Dimension
120V/60Hz 1800W 28QT 22.0*17.4*18.9inch
TOUCHSCREEN CONTROL PANEL
1 4 6 8
532 7 9
Preset
Air
Pizza
Rib
Chicken
Seafood
Roast
Broil
450ºF
330ºF
275ºF
430ºF
320ºF
375ºF
400ºF
19min
13min
60min
24min
10min
14min
10min
340ºF
95ºF
136ºF
450ºF
300ºF
400ºF
55min
60min
4h
6min
---
45min
Icont Temp Time Preset Icont Temp Time
Cake
Ferment
Dehydrate
Toast
Preheat
Rotisserie
Note: The times and temperatures above are suggestions - They may vary on the
amount of your food, the source, thaw, and other factors, you can also
fine-tune time and temperature.
1Preset Settings

7 8
2Temp Increase & Decrease
Tap the temperature Decrease or the temperature lncrease icon to
adjust to your desired temperature.
Note: Hold your finger on the icon for a faster cycling.
3Time Increase & Decrease
Tap the time decrease or the time lncrease icon to adjust to your
desired time.
Note: Hold your finger on the icon for a faster cycling.
4Oven Light
Tap the light icon to turn the Oven light On/Off.
Note: To conserve energy it will turn off after 5 min.Simply tap icon again to
turn it back on.
5Toast
Tap the toast icon to toast food.
6Preheat
Tap the preheat icon to preheat the oven.
7Power On/Off
Tap the power icon to turn the Oven On/Off.
8Rotisserie
When the Rotisserie function is cooking, the icon flashes. When the door is
opened or cooking is finished, the icon stops flashing.
BEFORE USING YOUR AIR FRYER OVEN
Some moisture may appear on your oven door during the cooking. This is
normal. For best results, we recommend that you preheat the Air Fryer Oven
1. Remove all packaging around and inside the
oven.
2. Place on a stable, level, heat- resistant
surface, away from anything that can be
damaged by heat. Keep at least 4.33inch
distance between the electrical outlet and
the wall, furniture, etc.
3. Wash all accessories and clean the interior
of the Air Fryer Oven. Dry and place
accessories back in oven.
4. Check the power, socket, and reconfirm can be meet the products requested,
then plug into a suitable power outlet.
5. First used, the Air Fryer Toaster Oven will emit odor or smoke, which is cause
by the heat of the protective film on heater, this is normal. It is necessary to
run the oven empty for 18 minutes at the highest temperature (450 F) to
sterilize and remove odor

9 10
1
3
2
4
OPERATION GUIDE
1
Insert the corresponding power supply, the full screen lights up once and
then goes out. Touch POWER to turn on the air oven, and the screen will
light up.
2
Touch "PREHEAT" icon, set your desired temperature. When preheat is
finished, it will beep to signal that you can put the food in the oven.
Note: Dehydrate function no need to preheat.
3Function
Tap the required menu icon to set the function. When the function is
selected, the function will flash, and the screen will display the default
temperature and time of the function. It can also adjust the required
temperature and time separately.
4Accessories position
Insert the accessories with food into the desired position, then close the
door. There are four groove positions, Please refer to the above rack
position diagrams to place the accessories.
REPLACING THE LIGHT
ATTENTION: Be sure to unplug the Air Fryer Oven and allow it to cool
completely before replacing the oven light.
SPECIFICATION:25W halogen bulb.
1. Rotate the light cover counterclockwise to
remove it.
2. Remove the used bulb by pulling it directly.
5
Touch the START/STOP icon to begin cooking, and the display will show
the timer counting down. It will beep 5 times and the display will show “END”
with all menu icons will light upagain when cooking finished.
Note: when the cooking cycle is finished, the buzzer will sound five alarms 5
seconds before the end of the cooking cycle, and the word "end" will be
displayed. The fan will stop after 1 minute of normal operation, and then
enter the standby mode. If there is no operation within 1 minute, it will enter
the shutdown mode
Note: When cooking fatty foods (e.g. chicken wings) with Oven Rack or Air
Fryer Basket, It is necessary to put the Baking Pan into next layer to prevent
the oil dripping on the stainless steel heater.

11 12
CARE, CLEANING&STORE
Before cleaning, remove the power plug from the power outlet. Allow the oven
and all accessories to cool completely before disassembling and cleaning.
Cleaning the outer body and door
Wipe the outer body with a soft, damp sponge. A non-abrasive liquid cleanser
or mild spray solution may be used to avoid build-up of stains. Apply the
cleanser to the sponge, not the oven surface, before cleaning.
To clean the glass door, use a glass cleaner or mild detergent and a soft, damp
sponge or soft plastic scouring pad. Do not use an abrasive cleanser or metal
scouring pad as these will scratch the oven surface.
Wipe the LED screen with a soft damp cloth,and apply cleanser to the cloth.
Please do not apply cleanser directly to the LED surface.Cleaning with dry cloth
or abrasive cleaners may scratch the surface.
Let all surfaces dry thoroughly prior to inserting the power plug into a power
outlet and turning the oven on.
WARNING: Do not immerse the body, power cord or power plug in water
or any other liquid as this may cause electrocution.
3. Insert the new bulb.
4. Rotate the light cover clockwise to tighten it.
Cleaning the crumb tray
After each use, slide out the crumb tray and discard crumbs. Wipe the tray with
a soft, damp sponge. Anon-abrasive liquid cleanser or mild spray solution may
be used to avoid build-up of stains. Apply the cleanser to the sponge, not the
tray, before cleaning. Dry thoroughly.
To remove the baked-on grease, soak the tray in warm soapy water then wash
with a soft sponge or soft plastic scouring pad. Rinse and dry thoroughly.
Always ensure to re-insert the crumb tray into the oven after cleaning and prior
to inserting the power plug into a power outlet and turning the oven on.
Cleaning the oven rack, dehydrate rack, baking pan
and fry basket
Wash all accessories in warm soapy water with a soft sponge or soft plastic
scouring pad. Rinse and dry thoroughly. Do not use abrasive cleansers, metal
scouring pads or metal utensils to clean any of the accessories as they may
damage the surfaces.
To extend the life of your accessories, we do not recommend that these be
placed in the dishwasher.
Cleaning the interior
WARNING: Use extreme caution when cleaning the heating elements.
Allow the oven to cool completely, and then gently rub a soft, damp
sponge or cloth along the length of the heating element. Do not use any
type of cleanser or cleaning agent. Let all surfaces dry thoroughly prior
to inserting the power plug into a power outlet and turning the oven on.
To clean any spattering that may occur while cooking, wipe the walls with a
soft, damp sponge. An on-abrasive liquid cleanser or mild spray solution may
be used to avoid build-up of stains. Apply the cleanser to the sponge, not the
oven surface, before cleaning.
Let all surfaces dry thoroughly prior to inserting the power plug into a power
outlet and turning the oven on.

13 14
TROUBLESHOOTING
Possible Problem Possible Cause Solution
The oven does NOT
Work
Steam is coming out
from the top of the
oven door
The appliance is not plugged in Make sure the oven is plugged in
You have not turned on the oven Press “ON/OFF" button to power on
The door is not closed properly Make sure the door is closed well
You are cooking high moisture
content foods
This is normal. The door is vented to
release steam created from high
-moisture content foods such as
frozen breads.
White smoke is coming
out of the oven
Dark smoke is coming
out of the oven
This is the first time to use oven
This is normal. The oven may
produce some white smoke when
you use if for the first time. We
suggest to set the highest
temperature in function working
18~20 minutes without food to
eliminate smoke.
You're cooking the greasy food
This is normal. Frying greasy foods
will cause oil to leak into the heaters
or crumb tray or baking pan, the oil
will produce white smoke, and
should not affect cooking.
Baking pan or crumb tray or
heaters still contains grease
residues or oil from previous use
Make sure you clean these parts
properly after each use.
Food is burning Immediately turn off the oven, be
careful when you take out the food.
The ingredients are
not done cooked with
the oven
Foods are cooked
unevenly
Foods are not crispy
after Air Frying
Too much amount of Food Reduce the amount of food for single
cooking
Setting temperature too low or
time too short Set the temperature higher or time longer
Choose the incorrect function Make sure you cook with the proper
function
Ingredients are stacked or close
to each other during cooking Make sure ingredients spread out evenly
Baking pan, Air Fry basket or
oven rack position is not adjusted
Before or during cooking, adjust
these accessories on the proper
position
Ingredients with highly moisture. Spraying or brushing a small amount of oil on food evenly can
increase crispiness.
Display shows Error
Code "E1" There is a short circuit in the temperature monitor
Remove the power cord from the
power outlet. Contact Customer
Support.
Display shows Error
Code "E2"
Remove the power cord from the
power outlet. Contact Customer
Support.
Storage
Remove the power plug from power outlet. Allow the oven and all accessories
to cool completely before disassembling and cleaning.
Ensure the oven and all accessories are clean and dry.
Ensure the door is closed.
Store the appliance in an upright position standing level on its support legs. Do
not store in a wet or hot condition.
Extension Cord：
A short power-supply cord (or detachable power-supply cord) is provided to
reduce risks resulting from becoming entangled in or tripping over a longer cord.
Longer detachable power-supply cords or extension cords are available and
may be used if care is exercised in their use.
If a long detachable power-supply cord or extension cord is used,
the marked electrical rating of the detachable power-supply cord or extension
cord should be at least as great as the electrical rating of the appliance.
The longer cord should be arranged so that it will not drape over the counter
top or table top where it can be pulled on by children or trippe.
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. Do not modify the plug in any way.
There is a open circuit in the
temperature monitor

The temperature monitor or
heaters is in inoperative
13
Display shows Error
Code "E3"
Remove the power cord from the
power outlet. Contact Customer
Support.
Display shows Error
Code "E4" The communication protocol is abnormal
Remove the power cord from the
power outlet. Contact Customer
Support.
