1. INTRODUCTION
Thank you for using JPE’s Cryo & Nano Products!
This User Manual describes the handling and use of Cryo Bearing Stage (CBS), from here on described as
positioner).
Please read this document carefully prior to installation and (initial)
operation of the controller, (stand-alone) positioners, actuators and
stages. Failure to observe the safety regulations results in a risk of electric
shock and/or damage to the controller(s), positioner(s), actuator(s) and/or
stage(s)!
JPE shall not be liable for damage or injury resulting from misuse of the
controller(s), positioner(s), actuator(s) and/or stage(s) or unauthorized
alterations to either of those.
All products mentioned in this manual are intended for use in a laboratory and/or scientific research
environment only and may only be installed, maintained and used by higher educated, technical skilled
personnel (from here on described as operators).
Please note that all content in this document is superseded by any new versions of this document. Visit
the JPE website (www.jpe-innovations.com) to obtain the most recent version. All images in this
document are for illustrative purposes only.
1.1 Prerequisites
Before continuing with this user manual, please make sure to read and understand the contents of the
(latest version of the) Cryo & Nano Positioning Products Getting Started Guide (MAN00).

MAN01-03 –CRYO BEARING STAGE (CBS) USER MANUAL
Cryo & Nano Products
Page 5 / 11
Property of: JPE
Last update: 2021-07-05
Author: JPE
Revision: 03
Filename: CNP_MAN01-03_R03_CBS.docx
Doc status: Released
2. INSIDE THE BOX
Positioners will be delivered in a white-colored (membrane) polypropylene box (one or more
positioner(s) per box). The inner part of the polypropylene box can be taken out and bend in such way
that the positioner(s) can be easily unpacked.
Do not cut the membrane plastic. Keep the box in case products need to be returned.
Figure 1: Example packaging with 3x CBS5-RLS
Figure 2: Example packaging with 3x CBS10-RLS
For XY(Z) configurations, the positioners will be delivered pre-configured as such. In these situations, the
XY or XYZ configuration will be fixed onto the inner part of the polypropylene box using fasteners
instead of being locked underneath the membrane plastic.
Figure 3: Example packaging with 1x CBS10-RLS XYZ configuration
Unpacking XY(Z) configuration require a bit more attention as it can be easy to damage cabling (flex
PCB) or connectors.

MAN01-03 –CRYO BEARING STAGE (CBS) USER MANUAL
Cryo & Nano Products
Page 6 / 11
Property of: JPE
Last update: 2021-07-05
Author: JPE
Revision: 03
Filename: CNP_MAN01-03_R03_CBS.docx
Doc status: Released
3. MOUNTING INSTRUCTIONS
Consult the Interface Drawing for detailed dimensions and mounting interfaces.
Note that the moving sample table must be at the end of the stroke to be able to have access to the
mounting holes.
Make sure the wiring to the Connector Interface PCB and/or Sensor (product type option -RLS) does not
get damaged or stuck in the setup when mounting the positioner in the customer setup. All connectors
must be mounted properly prior to connecting the positioner to the electronics!
An XY configuration is possible without any the use of additional parts. For an XYZ configuration, an
additional Z-bracket (I1-CBS10) can be purchased. In either configuration (XY or XYZ), the positioners
will be delivered already pre-configured as such.

MAN01-03 –CRYO BEARING STAGE (CBS) USER MANUAL
Cryo & Nano Products
Page 7 / 11
Property of: JPE
Last update: 2021-07-05
Author: JPE
Revision: 03
Filename: CNP_MAN01-03_R03_CBS.docx
Doc status: Released
4. CONNECTING TO THE CONTROLLER
Consult the Connection Overview application note for a simple and clear overview on how to connect
positioners to the controller.
4.1 Drive signal
All positioners are assembled with ~150[mm] Kapton coated wire and a Connector Interface PCB at the
end with a 2-pin 2.54mm pitch header mounted (Molex KK 22-05-7028). There are two mounting holes
available for M2 bolts.
Figure 4: Connector Interface PCB (left) on a CBS10-RLS
Figure 5: Connector Interface PCB (top view)
The Ambient Cable (ACL) or Cryostat Cable (CCL) can be connected directly to the Connector Interface
PCB. If any custom cabling is required, please consult the Getting Started Guide (MAN00) or the
Connection Overview application note (APN01).
Pin configuration
Pin
Name
Note
1
(Piezo) Signal
Routes to the pad labeled “S” or “SIG” on the positioner
2
(Piezo) REF
Routes to the pad labeled “R” or “REF” on the positioner
Make sure that there is no force applied to the wires connected to the positioner!
Please note that (Piezo) REF is NOT the same as (system) GND or PE, so do not connect these to each
other and do not use standard oscilloscope probes!
Because of design constraints, open voltage contacts are present!

MAN01-03 –CRYO BEARING STAGE (CBS) USER MANUAL
Cryo & Nano Products
Page 8 / 11
Property of: JPE
Last update: 2021-07-05
Author: JPE
Revision: 03
Filename: CNP_MAN01-03_R03_CBS.docx
Doc status: Released
4.2 Position sensor signal
If the positioner is equipped with a Resistive Linear Sensor (product type option –RLS), the positioner will
be assembled with an additional ~150[mm] Kapton FPC (flexible PCB) that can connect directly to the
Cryostat Cable for RLS (CCR) or Ambient Connector Kit for RSM (I1-RSM).
If any custom cabling is required, please consult the Getting Started Guide (MAN00) or the Connection
Overview application note (APN01).
Figure 6: FPC (left) connected to ZIF connectors on the CCR
Figure 7: CBS10-RLS FPC can be seen on the right
Pin configuration
Pin
Name
RLS PCB Reference
1
Wiper Negative
A
2
Excitation Positive
B
3
Wiper Positive
C
4
Excitation Negative
D
Make sure that there is no force applied to the FPC connected to the sensor! The FPC is designed for
easy connection at (re-)installation; however, it’s recommended to disconnect or reconnect only when
required.
4.3 Connecting to Controller
Controller with Plug-in Modules 1
Module
Slot #
CBSx(-RLS)
CADM2 Output
1
CBSx-RLS
RSM Input A
2
CBSx(-RLS) XY –(X)
CADM2 Output
1
CBSx(-RLS) XY –(Y)
CADM2 Output
2
CBSx-RLS XY –(X)
RSM Input A
3
CBSx-RLS XY –(Y)
RSM Input B
CBSx(-RLS) XYZ –(X)
CADM2 Output
1
1
For available Modules see CNP-Products MAN01-09 (CPSC).

MAN01-03 –CRYO BEARING STAGE (CBS) USER MANUAL
Cryo & Nano Products
Page 9 / 11
Property of: JPE
Last update: 2021-07-05
Author: JPE
Revision: 03
Filename: CNP_MAN01-03_R03_CBS.docx
Doc status: Released
CBSx(-RLS) XYZ –(Y)
CADM2 Output
2
CBSx(-RLS) XYZ –(Z)
CADM2 Output
3
CBSx-RLS XYZ –(X)
RSM Input A
4
CBSx-RLS XYZ –(Y)
RSM Input B
CBSx-RLS XYZ –(Z)
RSM Input C

MAN01-03 –CRYO BEARING STAGE (CBS) USER MANUAL
Cryo & Nano Products
Page 10 / 11
Property of: JPE
Last update: 2021-07-05
Author: JPE
Revision: 03
Filename: CNP_MAN01-03_R03_CBS.docx
Doc status: Released
5. SENSOR CALIBRATION
If the positioner is equipped with a Resistive Linear Sensor (product type option –RLS), the device will be
delivered pre-calibrated. This calibration is done to determine the (maximum) stroke the sensor can
measure as well as the center (nominal) position.
Calibration is done in cooperation with the Resistive Sensor Module (RSM). This means that the
calibration settings for a specific RLS will be stored for a specific input channel of the RSM.
For that reason, or for a re-calibration, it is also possible to do a (manual) calibration. This involves
moving the positioner through its range (free movement required) and storing measurement calibration
values. This can all be done with the user software, please read the Software User Manual (MAN02) on
how to do this.

MAN01-03 –CRYO BEARING STAGE (CBS) USER MANUAL
Cryo & Nano Products
Page 11 / 11
Property of: JPE
Last update: 2021-07-05
Author: JPE
Revision: 03
Filename: CNP_MAN01-03_R03_CBS.docx
Doc status: Released
6. DECLARATION OF CONFORMITY
Manufacturer
:
JPE B.V.
Address
:
Aziëlaan 12
6199 AG Maastricht-Airport
The Netherlands
The manufacturer hereby declares that the product:
Product Name
:
Cryo Bearing Stage (CBS)
Product Description
:
Linear stage for allround applications in a vacuum and cryogenic
environment.
Product Number
:
C181046
Complies with the following European directives:
2014/35/EU
Low Voltage Directive
2014/30/EU
EMC Directive
2011/65/EU
RoHS
A copy of the Technical file for this equipment is available at JPE.
Maastricht-Airport, 29 June 2018
Ir. H. Janssen
Founder & CEO
JPE B.V.
The Netherlands
