JR XP662 User manual

6-CHANNEL COMPUTER RADIO
INSTRUCTION MANUAL
FOR AIRPLANE AND
HELICOPTER

3
XP662 MANUAL Table of Contents
TABLE OF CONTENTS
I. INTRODUCTION
Introduction to the XP662 Radio System 4
Quick Start (Airplane) 5
Quick Start (Helicopter) 7
1. Using This Manual 9
2. Features 9
2.1 Transmitter Features 9
2.2 Receiver Features 9
2.3 Servo Features 10
2.4 Servo Layout 10
3. Specifications 11
3.1 System Specifications 11
3.2 Transmitter Specifications 11
3.3 Servo Specifications 11
3.4 Receiver Specifications 12
3.5 Charger Specifications 12
3.6 Airborne Battery Pack 12
4. Battery Charging 13
4.1 Transmitter/Receiver 13
4.2 Charger 13
5. Trainer System 14
II. AIRPLANE SECTION
1. Transmitter Controls 15
1.1 Control Identification and Location 15
1.2 Digital Trim Levers 15
1.3
Receiver Channel Assignment/Transmitter Throttle ATL 16
1.4 Transmitter Rear 16
1.5 Control Stick Length Adjustment 17
1.6 Direct Servo Control (DSC) 17
1.7 Neck Strap Attachment 17
2. Connections 18
2.1 Installation Requirements 18
2.2 Connections 18
3. Key Input and Display 19
4. Battery Alarm and Display 19
5. Input Mode and Function 20
5.1 Normal Display 20
5.2 Direct Trim Access Display 20
5.3 System Mode 20
5.4 Function Mode 21
5.5 Throttle Cut 21
6. Functions (System Mode) 22
6.1 Model Type Selection 22
6.2 Data Reset 23
6.3 Dual Rate Switch Selection 24
6.4 Wing Type Selection 25
6.5 Model Selection 27
6.6 Model Name Entry 28
6.7 Modulation Select 29
6.8 Fail-Safe/Hold 30
6.9 Fail-Safe/Hold Function in Z-PCM Modulation 30
6.10 Fail-Safe/Hold Function in S-PCM Modulation 32
7. Functions (Function Mode) 34
7.1 Servo Reversing 34
7.2 Dual Rate 35
7.3 Exponential 36
7.4 Sub-Trim 37
7.5 Travel Adjustment 38
7.6 Aileron-to-Rudder Mixing 39
7.7 Elevator-to-Flap Mixing 41
7.8 Differential 43
7.9 Flap-to-Elevator Offset Trim 44
7.10 Programmable Mixing (A, B, C) 45
8. Data Sheet 48
III. HELICOPTER SECTION
1. Transmitter Controls 49
1.1 Control Identification and Location 49
1.2
Receiver Channel Assignment/Transmitter Throttle ATL 49
1.3 Transmitter Rear 50
1.4 Control Stick Length Adjustment 51
1.5 Direct Servo Control (DSC) 51
1.6 Neck Strap Attachment 51
2. Connections 52
2.1 Installation Requirements 52
2.2 Connections 52
3. Key Input and Display 53
4. Battery Alarm and Display 53
5. Input Mode and Function 54
5.1 Normal Display 54
5.2 System Mode 54
5.3 Function Mode 55
6. Functions (System Mode) 56
6.1 Model Type Selection 56
6.2 Data Reset 57
6.3 Dual Rate Switch Selection 58
6.4 Gear/Gyro Switch Selection 59
6.5 Model Selection 60
6.6 Model Name Entry 61
6.7 Modulation Select 62
6.8 Fail-Safe/Hold 63
6.9 Fail-Safe/Hold Function in Z-PCM Modulation 63
6.10 Fail-Safe/Hold Function in S-PCM Modulation 65
7. Functions (Function Mode) 67
7.1 Servo Reversing 67
7.2 Dual Rate 68
7.3 Exponential 69
7.4 Sub-Trim 70
7.5 Travel Adjustment 71
7.6 Throttle Hold 72
7.7 Pitch Curve 73
7.8 Throttle Curve 74
7.9 Revolution Mixing 75
7.10 Programmable Mixing (A) 76
7.11 CCPM Swashplate mixing 79
7.12 CCPM Servo Connections 80
7.13 How 120 CCPM works 81
8. Data Sheet 83
IV. IMPORTANT INFORMATION
1. General Notes 93
2. Daily Flight Checks 93
3. Warranty Coverage 94
4. Repair Service Instructions 94
5. Frequency Chart 95

4XP662 MANUAL Introduction
Included with the XP662 Radio System is a
switch/function decal sheet. These decals have been
provided as a guide to specific switch positions,
functions, and abbreviations used when operating the
XP662.
The four small decals help identify switch positions and
use for helicopter and aircraft modes.
The large decal at the bottom of the sheet gives
abbreviations and definitions for all of the aircraft and
helicopter functions. The functions decal will prove to be
a helpful guide for making program changes to your
XP662 both in the shop and at the flying field.
We strongly encourage all prospective and current R/C
aircraft pilots join the Academy of Model Aeronautics. The
AMA is a non-profit organization which provides services
to model aircraft pilots. As an AMA member you will
receive a monthly magazine entitled Model Aviation, as
well as a liability insurance plan to cover against possible
accident or injury. All AMA charter aircraft clubs require
individuals to hold a current AMA sporting license prior to
operation of their models. For further information you can
contact the AMA at:
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302
[phone]
Thank you for purchasing the JR XP662 6-Channel Radio
System. This unit has been designed to provide the
modeler with a high quality, user friendly radio system
that can be depended upon for years to come.
It is important that you carefully read this manual before
attempting to operate your XP662 System. Please pay
particular attention to Page 13, Chapter 4 Charging Your
XP662 Radio System, prior to Installing.
XP662 SWITCH FUNCTION DECAL SHEET
AMA INFORMATION
FLAP
UP
DOWN
OFF
ON
MIX OR
GEAR
DOWN
UP
OFF
ON
MIX
OR
THROTTLE HOLD
NORMAL
HOLD
FLIGHT MODE
NORMAL
STUNT
72MHz
FM TX
REV – Servo Reversing
AIRPLANE
D/R – Dual Rates
SB-TRIM – Sub-Trim
TRV ADJ – Travel Adjustment
MIX A-R – Ailer./Rudder Mixing
MIX E-F – Elevator/Flap Mixing
OFFSET – Landing Elev. Offset
REV – Servo Reversing
D/R – Dual Rates
SB-TRIM – Sub-Trim
HLD – Throttle Hold
HELICOPTER
TRV ADJ – Travel Adjustment
PLN
P2N
PHN
PLS
P2S
PHS
PLH
P2H
PHH
TLN
T2N
THN
TLS
T2S
MIX
RVU
RVD
OFFSET – Rudder Offset
– Pitch Low Normal
– Pitch Med. Normal
– Pitch High Normal
– Pitch Low Stunt
– Pitch Med. Stunt
– Pitch High Stunt
– Pitch Low Hold
– Pitch Med. Hold
– Pitch High Hold
– Throttle Low Norm.
– Throttle Med. Norm.
– Throttle High Norm.
– Throttle Low Stunt
– Throttle Med. Stunt
– Revo Mixing
– Revo Mixing Up
– Revo Mixing Down
DECAL SHEET
HELICOPTER
DECAL POSIITON
Top View (Mode II)
AIRPLANE
DECAL POSITION
Top View (Mode II)
REAR DECAL POSITION
Airplane and Helicopter
INTRODUCTION TO THE XP662 RADIO SYSTEM • Introduction
XP662 FUNCTION GUIDE
TX BACK
HELI
TOP
LEFT NORMAL
STUNT
FLIGHT MODE NORMAL
STUNT
THROTTLE HOLD
AIR
TOP
LEFT
HELI
TOP
RIGHT
AIR
TOP
RIGHT
MIX OR FLAP
DOWN OFF
UP ON OFF DOWN ON UP
GEAR OR MIX
Airplane
REV Servo Reversing
D/R Dual Rates
EXP Exponential
SB-TRIM Sub-Trim
TRV ADJ Travel Adjustment
MIX A-R Aileron/Rudder Mix
MIX E-F Elevator/Flap Mixing
MIX DIF Differential
OFFSET Flap/Elevator Offset
MIX A Programmable Mix A
MIX B Programmable Mix B
MIX C Programmable Mix C
Helicopter
REV Servo Reversing
D/R Dual Rates
EXP Exponential
SB-TRIM Sub-Trim
TRV ADJ Travel Adjustment
HLD Throttle Hold
PLN Pitch Low Normal
P2N Pitch Med. Normal
PHN Pitch High Normal
PLS Pitch Low Stunt
P2S Pitch Med. Stunt
PHS Pitch High Stunt
PLH Pitch Low Hold
P2H Pitch Med. Hold
PHH Pitch High Hold
TLN Throttle Low Norm.
T2N Throttle Med. Norm.
THN Throttle High Norm.
TLS Throttle Low Stunt
T2S Throttle Med. Stunt
MIX Revo Mixing
RVU Revo Mixing Up
RVD Revo Mixing Down
MIX A Programmable Mix A
CCP CCPM Swashplate Mix
XP6 62 FUNCTION GUIDE
Tx BACK
HELI
TOP
LEFT NORMAL
STUNT
FLIGHT MODE NORMAL
STUNT
THROTTLE HOLD
AIR
TOP
LEFT
HELI
TOP
RIGHT
AIR
TOP
RIGHT
MIX OR FLAP
DOWN OFF
UP ON OFF DOWN ON UP
GEAR OR MIX
Airplane
REV ServoReversing
D/R DualRates
EXP Exponential
SB-TRIM Sub-Trim
TRVADJ Travel Adjustment
MIXA-R Aileron/RudderMix
MIXE-F Elevator/Flap Mixing
MIXDIF Differential
OFFSET Flap/ElevatorOffset
MIXA ProgrammableMix A
MIXB ProgrammableMix B
MIXC ProgrammableMix C
OFFSET TrimOffset Memory
Helicopter
REV ServoReversing
D/R DualRates
EXP Exponential
SB-TRIM Sub-Trim
TRVADJ Travel Adjustment
HLD ThrottleHold
PLN PitchLowNormal
P2N PitchMed.Normal
PHN PitchHigh Normal
PLS Pitch Low Stunt
P2S Pitch Med. Stunt
PHS PitchHigh Stunt
PLH Pitch Low Hold
P2H Pitch Med. Hold
PHH PitchHigh Hold
TLN Throttle Low Norm.
T2N Throttle Med. Norm.
THN ThrottleHigh Norm.
TLS Throttle Low Stunt
T2S Throttle Med. Stunt
MIX Revo Mixing
RVU RevoMixing Up
RVD RevoMixing Down
MIXA ProgrammableMix A
STT Stunt Trim
CCP CCPM Swashplate Mix
Offset TrimOffset Memory

5
XP662 MANUAL Introduction
QUICK START
AIRPLANE
Model Type Selection
Servo Reversing
REV◆NORM
THR
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
AC
TYP
AC
TYP
9.7V
ACI
AC
TYP
In this manual you will find in-depth instructions that
detail all the steps and procedures you should follow in
order to program each of the XF662’s features. For
modelers who want to get into the air fast, we have
provided Quick Start. Quick Start covers the basic
programming information necessary to get you airborne.
Later, when you want to learn more about specific
features of the XP662, turn to the appropriate page(s) in
this manual for more detailed programming information.
If AC appears on the screen procede directly to
Step 4. If HE appears press the INCREASE or
DECREASE button until “AC” appears, then
press the SCROLL and INCREASE buttons
simultaneously to store the model type change.
Press the SCROLL and INCREASE
buttons simultaneously and hold
while turning on the transmitter.
Press the SCROLL button until
“TYP” appears on the screen.
Turn the transmitter off and then on again.
Digital Trim Settings Check to ensure that the aileron, elevator, and
rudder trim values are set to the 0 (neutral) position.
Next, set the throttle value to the full low (-40)
position by pressing the throttle trim lever down.
1 2
3 4
5
6
With the transmitter on, press the
SCROLL and INCREASE buttons
upward simultaneously until a
beep is heard.
REV◆NORM
THR
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
7
Press the SCROLL button (if necessary)
until “REV-NORM” appears on
the screen.
REV◆NORM
THR
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
8
Press the
CHANNEL
button to select
the channel you
want to reverse.
Press the INCREASE or
DECREASE button to
reverse the direction of
the channel you selected.

6XP662 MANUAL Introduction
AIRPLANE
Travel Adjustment
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
TRV ADJ. AIL
+I00
%
9
Press the SCROLL
button until
“TRV ADJ” appears
on the screen.
Press the CHANNEL
button to select the
channel on which you
want the travel adjusted.
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
TRV ADJ. AIL
+I00
%
10
INCREASE
To increase the travel,
move the stick (i.e.aileron)
to the right then press the
INCREASE button to
adjust the right travel.
Release the INCREASE
button and move the same
stick to the left.Press the
INCREASE button to
adjust the left travel.
DECREASE
To decrease the travel,
move the stick (i.e.aileron)
to the right then press the
DECREASE button to
adjust the right travel.
Release the DECREASE
button and move the same
stick to the left.Press the
DECREASE button to
adjust the
left travel.
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
TRV ADJ. AIL
+I00
%
11
Press the SCROLL and INCREASE buttons
upwards simultaneously to return to the main
screen and exit the Function mode.
Throttle Auto Cut
Before the initial start of your model, please check to
ensure that when the THROTTLE CUT button is pressed,
the engine’s carburetor barrel will move to the fully closed
(engine off) position.
This safety feature ensures that the engine can be shut off
immediately in case of a problem or safety concern.
Please note that the throttle cut button is only active when
the throttle stick is below 1/2 throttle, and a trim value has
been added to the throttle trim lever.
12
QUICK START
THROTTLE CUT BUTTON

7
XP662 MANUAL Introduction
HELICOPTER QUICK START
Model Type Selection
Servo Reversing
REV◆NORM
THR
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
AC
TYP
AC
TYP
9.7V
ACI
AC
TYP
If “HE”appears on the screen, procede directly
to Step 4. If “AC”appears, press the INCREASE
or DECREASE button until “HE”appears, then
press the SCROLL and INCREASE buttons
simultaneously to store the model type change.
Press the SCROLL and INCREASE
buttons simultaneously and hold
while turning on the transmitter.
Press the SCROLL button until
“TYP”appears on the screen.
Turn the transmitter off and then on again.
Digital Trim Settings Check to ensure that the aileron, elevator, and
rudder trim values are set to the 0 (neutral)
position. Next, set the throttle value to the full
low (-40) position by pressing the throttle trim
lever down.
1 2
3 4
5
6
With the transmitter on, press the
SCROLL and INCREASE buttons
upward simultaneously until a
beep is heard.
REV◆NORM
THR
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
7
Press the SCROLL button (if necessary)
until “REV-NORM”appears on
the screen.
REV◆NORM
THR
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
8
Press the
CHANNEL
button to select
the channel you
want to reverse.
Press the
INCREASE or
DECREASE
button to reverse
the direction of
the channel you
selected.

8XP662 MANUAL Introduction
HELICOPTER
Pitch Curve
Press the
SCROLL
button until
“PLN”appears
on the screen.
0%
Press the
CHANNEL button
to select stick
position (point
location).
Press the INCREASE
or DECREASE button
to adjust the point
value at the selected
stick position.
0%
STICK POSITION
(POINT LOCATION)
L=Low
2 = Center
H= High
PRESET VALUES
L= 0%
2 = 50%
H = 100%
RECOMMENDED INITIAL
PITCH SETTINGS
(Please refer to your helicopter kit
instruction for pitch settings if available)
L = 0°Pitch
2 = 5°Pitch
H = 9°Pitch
QUICK START
Travel Adjustment
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
TRV ADJ. AIL
+I00
%
9
Press the SCROLL
button until
“TRV ADJ”appears
on the screen.
Press the CHANNEL
button to select the
channel on which you
want the travel adjusted.
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
TRV ADJ. AIL
+I00
%
10
INCREASE
To increase the travel,
move the stick (i.e.aileron)
to the right then press the
INCREASE button to
adjust the right travel.
Release the INCREASE
button and move the same
stick to the left.Press the
INCREASE button to
adjust the left travel.
DECREASE
To decrease the travel,
move the stick (i.e.aileron)
to the right then press the
DECREASE button to
adjust the right travel.
Release the DECREASE
button and move the same
stick to the left.Press the
DECREASE button to
adjust the
left travel.
Throttle Auto Cut
Before the initial start of your model, please
check to ensure that when theTHROTTLE
CUT button is pressed, the engine’s
carburetor barrel will move to the fully
closed (engine off) position.
This safety feature ensures that the engine
can be shut off immediately in case of a
problem or safety concern.
Please note that the THROTTLE CUT button is only active
when the throttle stick is below 1/2 throttle, and a trim value
has been added to the throttle trim lever.
13
11 12
THROTTLE CUT BUTTON
CHANNEL
SCROLL INCREASE
DECREASE
ENTER

9
XP662 MANUAL Introduction
The XP662 is a full feature introductory computer
radio for airplanes and/or helicopters. This manual is
divided into two main sections: airplanes and
helicopters. You need only refer to the section that
pertains to the type of model you are programming—
e.g., if you are programming your XF662 for helicopters,
follow the instructions in the helicopter section.
Blank data sheets are included at the end of both
sections. Once you have input all the necessary data
into your transmitter for a particular model, we
strongly recommend that you immediately write
that information down on a copy of the data sheet
provided. This is to insure that, in the rare case of
a memory failure, you will not lose your data.
Airplane and Helicopter Mode
• Easy-to-read LCD screen
• 6-model name entry
• 6-model memory
• Dual rates on aileron and elevator
• Dual rates can be combined on one switch
• Exponential rate on aileron and elevator
• Trainer system compatible with most JR radios
• Easy-access programming buttons
• Computer designed ergonomically styled case
• Adjustable stick length
• Throttle trim only affects idle position
• Two speed scrolling: press and hold the
appropriate button to scroll quickly or press and
release to scroll in steps
• FM/PCM selectable
• Fail-safe/fail-safe memory (PCM only)
• Digital trims for precise adjustment
Airplane Mode
• Aileron to rudder mixing
• Elevator to flap mixing
• Flap to elevator mixing
• Flaperons mixing
• Delta wing mixing
• Aileron differential
• V-tail mixing
• Three programmable mixes
• Mixing differential
Helicopter Mode
• Two 3-point throttle curves
• Two 3-point pitch curves (three when throttle
hold is activated)
• Flight mode switch can combine throttle curve,
pitch curve, dual rates, and gyro sensitivity
• Throttle hold
• Revolution mixing up and down
• Programmable mixing
• Optional 120° CCPM Swashplate mixing
• Separate trim setting for all flight modes
R700 Slimline Receiver
• The R700’s extremely compact “slimline” design
allows it to fit easily in limited spaces.
• An independent laboratory ranked the R700
Receiver with JR’s patented ABC&W circuitry as
one of the best receivers ever tested in terms of
3IM, 2IM, signal-to-noise ratio, adjacent channel
rejection, and on-channel capture point.
• The R700 is compatible with all JR FM
transmitting radios.
• A special “unwanted interference limiter” ignores
signals outside of the R700’s band width when
the receiver is on and the transmitter is off.
The limiter also prevents servos from random
glitching when other transmitters are operating
in close proximity.
• The electrical circuitry is state-of-the-art surface
mount technology (SMT). These SMT components
draw less current, thus increasing flying time.
Flush mounting of these components also
reduces the risk of vibration, wear, and damage.
CHAPTER 1:USING THIS MANUAL • Introduction
USING THIS MANUAL
1
CHAPTER 2:FEATURES
TRANSMITTER FEATURES
2.1
RECEIVER FEATURES
2.2

10 XP662 MANUAL Introduction
CHAPTER 2:FEATURES • Introduction
537 Servo
• An ultra-tight deadband amplifier ensures
accurate neutral centering
• Low-current drain
• Ball bearing supported ouput shaft with new
wide spacing for improved precision
• An indirect drive feedback potentiometer gives
additional protection from vibration
SERVO FEATURES2.3
SERVO LAYOUT
2.4
Servo Mounting Flange
Rubber Grommets
Rubber Grommets
Servo Case
Servo Lead w/Connector
Servo Output Shaft
Servo Mounting Flange
Servo Arm/Horn
Servo Arm Retaining Screw
Servo Eyelet
Top View

11
XP662 MANUAL Introduction
CHAPTER 3:SPECIFICATIONS • Introduction
SYSTEM SPECIFICATIONS
TRANSMITTER SPECIFICATIONS
3.1
3.2
SYSTEM NAME XP662A XP662H
TRANSMITTER BODY NET-XP662A NET-XP662H
RECEIVER R700 R700
CHARGER NEC-221 NEC-222
AIRBORNE BATTERY 4N-600 4N-1000
SERVOS NES-537BBX4 NES-537BBX5
ACCESSORIES Mini Switch Mini Switch
12" Aileron Extension 12" Aileron Extension
Servo Accessories Servo Accessories
Instruction Manual Instruction Manual
Function Guide Function Guide
TYPE AIRPLANE HELICOPTER
MODEL NUMBER NET-XP662A NET-XP662H
ENCODER 6-Channel Computer System 6-Channel Computer System
RF 50/72MHz 50/72MHz
MODURATION PPm (FM), PCM (S,Z) PPm (FM), PCM (S,Z)
OUTPUT POWER Approximately 1 Watt Approximately 1 Watt
CURRENT DRAIN 200mA 200mA
POWER SOURCE 1.2Vx8 Ni-Cd (9.6V) 600mAh 1.2Vx8 Ni-Cd (9.6V) 600mAh
OUTPUT PULSE 1000-2000 (1500 Neutral) 1000-2000 (1500 Neutral)
TYPE AIRPLANE HELICOPTER
SERVO SPECIFICATIONS3.3
TORQUE (oz/in) 43 oz
SPEED .25
WEIGHT 1.37
SIZE (in) (W x L x H) 0.73 x 1.52 x 1.32
BB YES
MOTOR 3-Pole Ferite
TYPE 537BB

12 XP662 MANUAL Introduction
RECEIVER SPECIFICATIONS
3.4
CHARGER SPECIFICATIONS
AIRBORNE BATTERY PACK
3.5
3.6
MODEL NUMBER NER-700
TYPE 7-Channel/FM Slimline ABC & W Circuitry
FREUENCY 50/72MHz
SENSITIVITY (Microseconds) 5µs Minimum
SELECTIVITY 8KHz/50dB
WEIGHT(oz) 0.64 oz
SIZE(in) (W x L x H) 1.84 x 0.98 x 0.16
RECEIVER ANTENNA 39" For All Aircraft Frequencies
TYPE R700 FM
MODEL NUMBER
INPUT VOLTAGE
OUTPUT CURRENT
CHARGING TIME
NEC-211
AC 100-120V
50mAh TX/50mAh RX
15 Hours
NEC-222
AC 100-120V
50mAh TX/150mAhRX
15 Hours
TYPE AIRPLANE HELICOPTER
MODEL NUMBER
VOLTAGE
SIZE (in) (W x L x H)
WEIGHT (oz)
4n-600
4.8V
2.24 x 0.59 x 2.05
3.3
4N-1000
4.8V
2.60 x 0.63 x 1.70
4.9
TYPE AIRPLANE HELICOPTER
CHAPTER 3:SPECIFICATIONS • Introduction

13
XP662 MANUAL Introduction
CHAPTER 4:BATTERY CHARGING • Introduction
The pilot lamps should always be on during the
charging operation. If they are not, check to make
sure you have turned off both the transmitter
and receiver.
Do not use the charger for equipment other than JR.
The charging plug polarity may not be the same and
equipment damage may result.
Do not use other manufacturers’ after-market
accessories that plug into the transmitter’s charging
jack. If you do, any damage that results will not be
covered by warranty. If you are unsure of
compatibilities with your radio, seek expert advice
before doing anything to avoid possible damage.
During the charging operation, the charger’s
temperature is slightly elevated. This is normal.
CHARGER4.2
It is imperative that you fully charge both the
transmitter and the receiver battery packs prior to
each day of flying. For the initial charge, leave the
charger and batteries hooked up for 20–24 hours in
order to fully charge both battery packs to peak
capacity. For subsequent charges, leave the charger
and batteries hooked up overnight (approximately
16 hours).
The charger supplied with this system is designed to
recharge your transmitter battery at a rate of 50mA.
The receiver battery pack will charge at 50mA for the
600mAh airplane battery pack and at 150mA for the
1000mAh helicopter battery pack.
Transmitter Only
The center pin on all JR remote control systems is
negative. Therefore, the center pin on all JR
chargers is negative, not positive. This is different
from any other manufacturers’ chargers and radio
systems. Beware of improper connections based on
“color code” wire leads, as they do not apply in
this instance. You must make certain that the
center pin of your JR transmitter is always connected
to the negative voltage for correct polarity hookup.
CENTER
PIN IS
NEGATIVE
OUTSIDE IS POSITIVE
RIGHT SIDE OF TRANSMITTER
CHARGER PIGTAIL FOR RECEIVER
CHARGER PIGTAIL FOR TRANSMITTER
BLACK TO POSITIVE
RED TO NEGATIVE
RED–POSITIVE / BROWN–NEGATIVE / ORANGE–SIGNAL
TRANSMITTER/RECEIVER4.1

14 XP662 MANUAL Introduction
The XP662 features a built-in trainer system. The
transmitter can be used as either a master (trainer) or
as a slave (trainee). The XP662 is compatible with all
other current JR radios that have built-in trainer
systems. An optional Trainer Cord (JRPA130)
is needed .
1. Match the servo reversing and trims of both radios.
2. Plug the optional trainer cord into both transmitters.
3. Turn on the master transmitter.
(Note: The slave radio must be left off.)
4. Test all the control functions on your aircraft with
the master radio.
5. Push the trainer button on the master
transmitter and check all the control functions
with the slave radio.
CHAPTER 5:TRAINER SYSTEM • Introduction
TRAINER SYSTEM5
D.S.C. TRAINER
CORD INPUT
ON
TRAINERELEVATOR D/R
0
1
0
1
AILERON D/R
SCROLL
CHANNEL INCREASE
DECREASE
622
FUNCTION 3-4 1-4 FUNCTION 1-2 2-3
MULTI
DATA
DISPLAY
VOLTAGE
INDICATOR
ON
TRAINERELEVATOR D/R
FLIGHT MODE
GEAR/MIX
0
1
THROTTLE HOLD
FLAP/MIX
0
1
AILERON D/R
SCROLL
CHANNEL INCREASE
DECREASE
622
XP662
FUNCTION 3-4 1-4 FUNCTION 1-2 2-3
MULTI
DATA
DISPLAY
VOLTAGE
INDICATOR
TRAINER
BUTTON
OPTIONAL
TRAINER CORD
(JRPA130)
MASTER TX
POWER SWITCH ON SLAVE TX
POWER SWITCH OFF
THROTTLE CUT
DIGITAL TRIM EQUIPPED 6 CHANNEL
MULTI-DATA DISPLAY SYSTEM
ENTER ENTER
XP662
DIGITAL TRIM EQUIPPED 6 CHANNEL
MULTI-DATA DISPLAY SYSTEM
THROTTLE CUT
FLIGHT MODE
GEAR/MIX THROTTLE HOLD
FLAP/MIX
Operating the Trainer System

AUX 1/FLAP MIXING
AILERON DUAL RATE
ANTENNA
LCD SCREEN
GEAR SWITCH
ELEVATOR DUAL RATE
TRAINER BUTTON
AILERON/ELEVATOR STICK
THROTTLE/RUDDER STICK
POWER SWITCH
AILERON TRIM
ELEVATOR TRIM
THROTTLE TRIM
RUDDER TRIM
NECK STRAP EYELET
INPUT KEYS
CARRYING HANDLETHROTTLE CUT BUTTON
15
XP662 MANUAL Airplane
The XP662 features four digital trim levers with a
direct trim display feature for ultra precise
adjustments. When a trim input is given, the display
screen will automatically change to show the trim
value for current channel being adjusted. Once the
trim change has been completed, the screen will
automatically return to the previous screen display
after 2–3 seconds.
A significant feature found only with Digital Trims is
the ability for the XP662 to automatically store the
trim values in the system memory. This eliminates
the need for previously found software functions like
Trim Offset Memory, Rudder Offset Memory (Heli),
and Stunt Trim (Heli).
In Heli mode, the XP662's digital trims provide a
separate set of trim values for each Flight mode
(Normal, Stunt, and Throttle Hold), which takes the
place of the previously needed Stunt Trim function.
With this feature, the trim levers are active in all
flight modes, and will store the trim values for each
mode independantly. This feature also takes the
place of the previously needed rudder offset
function, since there is now a completely separate
set of trim setting for the Throttle Hold mode.
DIGITAL TRIM LEVERS1.2
CONTROL IDENTIFICATION AND LOCATION •Mode II
CHAPTER 1:TRANSMITTER CONTROLS •Airplane
1.1

16 XP662 MANUAL Airplane
CRYSTAL
CARRYING HANDLE
TRAINER JACK
BATTERY
TRANSMITTER
CASE SCREW
TRANSMITTER
CASE SCREW
TRANSMITTER
CASE SCREW
TRANSMITTER
CASE SCREW
TRANSMITTER
CASE SCREW
TRANSMITTER
CASE SCREW
TRANSMITTER1.4
Note: Your transmitter has a 5-year lithium battery
to protect your pre-programmed data against main
transmitter battery failure. If your system reads
0.0 volts or has an unfamiliar display (service mode)
or your data resets to the factory defaults, return
your transmitter to Horizon Service Center (see
page 85) for lithium battery replacement.
BATTERY CONNECTOR
Use caution when disconnecting/removing the
transmitter battery pack as if the connector is not
properly disconnected, damage to the connector
and/or the radio system can result.
1. THRO Throttle Channel
2. AILE Aileron Channel
3. ELEV Elevator Channel
4. RUDD Rudder Channel
5. GEAR Gear Channel
6. AUX 1 Auxiliary 1 Channel (Flap)
Transmitter Throttle ALT
The Throttle ALT function makes the throttle stick
trim active only when the throttle stick is less than
half throttle. This gives easy, accurate idle adjustments
without affecting the high throttle position.
RECEIVER CHANNEL ASSIGNMENT/TRANSMITTER THROTTLE ALT1.3
(Factory Installed)
Transmitter Crystal Replacement Notice
The Federal Communications Commission (FFC) requires that
changes in transmitter frequency must be performed only by an
authorized service technician (Horizon Service Center).Any
transmitter frequency change made by non-certified technician
may result in a violation of the FCC rules.
CHAPTER 1:TRANSMITTER CONTROLS •Airplane

17
XP662 MANUAL Airplane
CHAPTER 1:TRANSMITTER CONTROLS •Airplane
To adjust the control stick length, use a 2mm Allen
wrench to unlock the set screw located inside the end
of the control stick. Turn the set screw counterclockwise
to loosen it, then turn the knurled portion of the stick
to adjust the length. Counterclockwise will lengthen
the stick and clockwise will shorten it. After the
control stick(s) has been adjusted to suit your flying
style, tighten the set screw.
For proper DSC hook-up and operation:
1. Leave the transmitter power switch off. The
transmitter will not transmit any radio
frequency (RF) in this position.
2. Plug the optional DSC Cord (JRPA132) into the
DSC port in the rear of the transmitter.
3. The encoder section of the transmitter will now
be operational and the LCD display will be lit.
4. Plug the other end of the DSC Cord into
the receiver charge receptacle. Turn on the
switch harness.
Note: When installing the optional charging
jack (JRPA024), be sure to hook the charging jack
receptacle securely into the switch harness
charge cord.
Why you should use the DSC function:
1. The DSC enables you to check the control
surfaces of your airplane without drawing the
fully operational 200mAh from your transmitter
battery pack. Instead, you will only draw 70mAh
when using the DSC function.
Note: You will need to purchase (separately)
both the DSC Cord (JRPA132) and the JR Deluxe
Switch Harness (JRPA001) to make use of the
XP662 DSC function.
2. The DSC function allows you to make final
adjustments to your airplane or helicopter
without transmitting any radio signals.
Therefore, if another pilot is flying on your
frequency, you can still adjust your aircraft and
not interfere with the other aircraft.
Note: Under no circumstances should you
attempt to fly your aircraft with the DSC Cord
plugged in! This feature is for bench checking
your aircraft only.
There is an eye hook on the front of the transmitter
for attaching an optional neck strap (JRPA023). The
eye hook is precisely positioned (see Section 1.1)
so that the transmitter will be perfectly balanced
when a neck strap is used.
CONTROL STICK LENGTH ADJUSTMENT1.5
LOOSEN
TIGHTEN
SET SCREW
DIRECT SERVO CONTROL (DSC)1.6
A
B
C
A—Charge Cord/DSC Receptacle
B—Switch Harness Lead
C—Charger/DCS Cord
NECK STRAP ATTACHMENT1.7

18 XP662 MANUAL Airplane
Please read and carefully follow these suggestions.
1. For added protection, wrap the RX and the RX
Ni-Cd in foam rubber that is at least 1/4” thick.
2. Run the RX antenna through the fuselage and
make sure it is fully extended. Never cut or
bundle your RX antenna—this will decrease
range and performance.
3. Rubber servo grommets are included with your
radio system and should be installed in the servo
flanges. The servos should then be mounted on
either hardwood rails or a plywood tray with the
mounting screws provided. Do not overtighten
the mounting screws. The flange of the brass
eyelets should face down (toward the wood).
4. All servos must be able to move freely over the
full range of their travel. Make sure the linkages
do not impede servo travel. A stalled servo will
drain the battery pack within a few minutes.
5. Before installing servo output arms, make sure
the servo is in its neutral position.
6. In the case of gas-powered model aircraft, mount
the receiver power switch on the side of the fuselage
opposite the muffler to protect the switch from
exhaust residue. With other types of models,
mount the switch in the most convenient place.
Make sure that the switch operates freely and is
capable of traveling its full distance.
7. With your model sitting on the ground and
the transmitter antenna collapsed, check
that your system works at a distance of
75 to 100 feet.
If your system stops functioning at a distance
that is shorter than listed above, please contact
the Horizon Service Center for further
information prior to flying your model.
INSTALLATION REQUIREMENTS
CHAPTER 2:CONNECTIONS •Airplane
CONNECTIONS2.2
2.1
ON
OFF
AUXILIARY 1 (FLAP)
GEAR
RUDDER
ELEVATOR
AILERON
THROTTLE
ON/OFF SWITCH HARNESS
(JRPA003)
RECEIVER BATTERY
4N-600
226X RECEIVER
NEW ABC & W SYSTEM
6 CHANNEL RECEIVER BATT
AUX 1
GEAR
RUDD
ELEV
AILE
THRO
NER-226X
JAPAN REMOTE CONTROL CO., LTD
MADE IN JAPAN
72MHz
ANTENNA
GEAR
7 CH 72MHz FM SLIMLINE
RECEIVER
ABC&W INTERFERENCE
PROTECTION SYSTEM
BATT
RUDD
ELEV
AILE
THRO
AUX1
R700 RECEIVER
ANTENNA
Optional
Optional

19
XP662 MANUAL Airplane
CHAPTER 4:BATTERY ALARM AND DISPLAY •Airplane
CHAPTER 3:KEY INPUT AND DISPLAY •Airplane
KEY INPUT AND DISPLAY3
When the transmitter battery drops below 9.0 volts,
the display will start to flash “BAT” and an audible
alarm will sound for eight beeps. These warnings
mean you should land your aircraft immediately.
Note: During the period that the battery alarm is
flashing, the input buttons will not function. If you
are currently in the function mode, the transmitter
will exit automatically and return to the normal
display (see Section 5.1).
BATTERY ALARM AND DISPLAY4
BAT
8.9V
FLASHING
V
Two input keys are located at the lower right and left
faceplate of the XP662 transmitter. The keys are used
to access and program the transmitter. Each key can
be moved up or down using your thumbs.
CHANNEL
SCROLL INCREASE
DECREASE
ENTER
Left button up........SCROLL —Used to advance
through the menus
Left button down...CHANNEL —Used to advance
through the channels or features
in a given function
Right button up........INCREASE —Increases value
or changes setting
(e.g., Reverse Normal)
Right button down...DECREASE —Decreases
value or changes setting
(e.g., Reverse Normal)

20 XP662 MANUAL Airplane
When the power switch is turned on, the
screen will read as shown here in the
diagram. This screen is referred to as the
normal display.
The Direct Trim function of the XP662 can
be accessed through the use of any of the
four digital trims levers (throttle, aileron,
elevator, or rudder).
When a trim input is given, the screen will
automatically change to show the trim
value for that particular channel. Once the
trim adjustment has been made, the
screen will automatically return to the
previous screen setting after 2–3 seconds.
The maximum trim value for each channel
is +/- 40 in increments of 2.
DIRECT TRIM ACCESS DISPLAY
CHAPTER 5:INPUT MODE AND FUNCTION •Airplane
5.2
I0.4V
AC I MODEL NUMBER
AC = FIXED WING AIRCRAFT
HE = HELICOPTER
BATTERY VOLTAGE
NORMAL DISPLAY5.1
I
MDL
I
ACI
I
PPM
CL
FSM
AC
TYP
AC
RST
E.A
SW
D/R
OF
WNG
MIX
MODEL TYPE SELECTION Page 22
DATA RESET Page 23
DUAL RATE
SWITCH SELECTION Page 24
Page 25
WING TYPE
SELECTION
FPR FLAPERON
MODEL SELECTION Page 27
MODEL NAME ENTRY Page 28
MODULATION SELECTION Page 29
FAIL-SAFE
(Z-PCM MODE ONLY) Page 30
FAIL-SAFE MEMORY
(S-PCM MODE ONLY) Page 32
V
OF
FSI
To enter the system mode, press the
SCROLL and INCREASE buttons
simultaneously while you turn on the
transmitter. You can now select any of
7 system mode functions shown here in
the flow chart. To exit the system mode,
press the SCROLL and INCREASE
buttons simultaneously or turn off the
transmitter. Press the SCROLL button to
move through the system mode functions.
Information for each function is located
on the page number listed next to the
function name.
SYSTEM MODE5.3
Only visible when S or Z PCM
modulation is selected
