JRC JCX-161 User manual

01ETM ISO 9001, ISO 14001 Certified
Printed in Japan
Marine Service Department
[phone]
[phone]
[email protected]
Telephone :
Facsimile :
e-mail :
AMSTERDAM Branch
Telephone :
Facsimile :
e-mail :
[phone]
[phone]
[email protected]
SEATTLE Branch
Telephone :
Facsimile :
e-mail :
[phone]
[phone]
[email protected]
CODE No.7ZPNA4321CODE No.7ZPNA4321
OCT. 2013 Edition 1 JRCOCT. 2013 Edition 1 JRC
Not use the asbestos
For further information,contact:
URL http://www.jrc.co.jp
JCXJCX-161161
INSTALLATIONINSTALLATION
MANUALMANUAL
Bridge NavigationalBridge Navigational Watch Alarm SystemWatch Alarm System

Revision history
JCX-161 BNWAS Installation Manual
i
7ZPNA4321
Revision history
Revision Content Date
--- Initial version 2013-07-19

Attention in use
JCX-161 BNWAS Installation Manual
ii
7ZPNA4321
Warning Symbols
In this Installation Manual and on the product, we use various pictorial indications to
handle the product safely and correctly and to prevent you from harming yourself and
other people or damaging those properties beforehand.
Meanings of the indications are shown below. Understand the meanings of signs
before proceeding to read the main text.
Examples
Electrical Shock
marks indicate CAUTION (including DANGER and WARNING).
Detailed contents of CAUTION (“Electric Shock” in the example on left)
are shown in the mark.
Disassembly
Prohibited
marks indicate prohibition.
Detailed contents of prohibited actions (“Disassembling Prohibited” in
the example on left) are shown in the mark.
●marks indicate a specific action that must be followed or instruction.
Detailed contents of instructions (“Ensure the ground wire is connected
to a grounded terminal” in the example to the left.)
For Warning Label
The warning label is sticked on the top panel of the control unit (NCK-175). Do not remove,
damage, or modefy the waring label.
This indication is shown where any person is supposed to be in
danger of being killed or seriously injured if this indication is neglected
or equipment is not operated correctly.
WARNING
This indication is shown where any person is supposed to be injured
or any property damage is supposed to occur if this indication is
neglected or equipment is not operated correctly.
CAUTION
DANGER
This indication is shown where any person is supposed to be in danger of
being killed or seriously injured if this indication is neglected or equipment is
not operated correctly.

Attention in use
JCX-161 BNWAS Installation Manual
iii
7ZPNA4321
Do not disassemble or modify this equipment.
It may result in a fire, electrical shock, or equipment malfunction.
Do not use a power supply voltage other than the one specified.
It may result in a fire, electrical shock, or equipment malfunction.
Turn off the power supply switch before connecting or disconnecting cables to any
external equipment. Not turning it off may result in a fire or electrical shock.
If the power supply cable is damaged, ask for an exchange from the Japan Radio Co.,
Ltd (JRC) sales department, a nearby branch office, business office, or any JRC
agents.
The use of damaged cables may result in a fire or electrical shock.
If water leaks into the equipment, shut off the power, disconnect the plug from the
outlet, and contact the JRC sales department, a nearby branch office, business office,
or any JRC agents. Continued use of water-damaged equipment may result in a fire,
electrical shock, or equipment malfunction.
Do not attempt inspections or repairs on internal parts of the equipment.
Ask for internal inspections or equipment repairs by contacting the JRC sales
department, a nearby branch office, business office, or any JRC agents.
Inspections or repairs by non-qualified maintenance personnel may result in a fire or
electrical shock.
If equipment malfunctions, shut off the power and contact the JRC sales department, a
nearby branch office, business office, or any JRC agents. Continued use of the
equipment may result in a fire or electrical shock.
Do not attempt to exchange of the fuse by yourself.
For an exchange of the fuse, contact the JRC sales department, a nearby branch
office, business office, or any JRC agent.
Exchange by non-qualified maintenance personnel may result in a fire, electrical
shock, or equipment malfunction.

Attention in use
JCX-161 BNWAS Installation Manual
iv
7ZPNA4321
When disposing of this unit, abide by local laws and regulations.
Do not insert or drop any foreign objects such as metals into air vents or orifices. A fire,
electric shock or malfunction may occur.
If a strange smell, smoke, or unusual heat is emitted from any equipment, shut off the
power immediately and disconnect the power cable. Then contact the JRC sales
department, a nearby branch office, business office, or any JRC agent. Continued use
of the equipment may result in a fire or electrical shock.
Do not allow any loose wires or metal objects to fall inside of equipment. This may
result in a fire, electrical shock, or equipment malfunction.
’
Do not install the system near to a water source or in the area with humidity,
steam, dust, oil or smoke.
A fire, electric shock or machine failure may occur.
Do not touch the system with a hand or glove wet with fresh water or sea water.
Otherwise, An electrical shock or machine failure may occur.
When disconnecting the power cable, make sure to grab the plug.
Pulling on the cable may damage the cable, resulting in a fire or electrical
shock.
Do not connect or disconnect the power cable with a wet hand.
An electrical shock may occur.
CAUTION

Attention in use
JCX-161 BNWAS Installation Manual
v
7ZPNA4321
When the system is exposed to fresh water or seawater, wipe it immediately.
Otherwise, a failure or malfunction may occur.
When cleaning the system surface, do not use any organic solvent such as
thinner or benzine; these solvents damage the surface coating.
To clean the surface, remove dust and debris and then wipe it with a clean dry
cloth.
Connect the ground wire to a grounded terminal. Otherwise, an electric shock
may occur as the result of a failure or earth leakage.
Avoid sharing a power source with a system (such as an air conditioner) that
generates a large amount of electronic noise. The system may not function
properly because of short - time voltage drop or noise carried from power
source.
Do not place the system on an unstable place such as a wobbly rack or incline.
The system may drop or fall, resulting in personal injuries and/or equipment
failure.
Do not place the system in a place exposed to direct sunlight. Otherwise it may
cause damage on the paint or seal on the surface.
Do not install the equipment near any radio equipment. Otherwise it may cause
a signal reception affected.
CAUTION

Attention in use
JCX-161 BNWAS Installation Manual
vi
7ZPNA4321
Do not bring the system into a warm room while it is cool. Dew condensation
may occur inside, leading to a machine failure.
Before turning on the power switch again, make sure that the screen of the
display unit goes out. If the power switch is turnd on immediately after turned
off, it may cause malfunction.
Do not touch the system if your hand is wet.
An electrical shock may occur.
Do not press buttons of the reset button units and the display unit by
unnecessary strong force. Equipment malfunction may occur.
Do not rub absolutely with hard things such as screw drivers, files, etc. at
cleaning. Wipe the surface lightly with a soft cloth. Otherwise it may cause
damage on the paint or seal on the surface.
CAUTION

Contents
JCX-161 BNWAS Installation Manual
vii
7ZPNA4321
Contents
1 Specifications ................................................................................................................................1
1.1 Functions.................................................................................................................................1
1.1.1 Purpose of the system .....................................................................................................1
1.1.2 Operational mode.............................................................................................................1
1.1.3 Operation sequence of displays and alarms .................................................................2
1.2 Features ...................................................................................................................................3
1.2.1 Versatile functions with standard configuration............................................................3
1.2.2 Various reset devices and number of inputs .................................................................3
1.2.3 Output to external device ................................................................................................3
1.2.4 Remote maintenance function ........................................................................................4
1.3 Composition ............................................................................................................................5
1.4 Spare parts...............................................................................................................................6
1.4.1 Fuse for Control unit (NCK-175)......................................................................................6
1.4.2 Fuse for LCD Display unit (NWZ-4650) ...........................................................................7
1.5 Connection Diagram...............................................................................................................8
1.6 Vocabularies............................................................................................................................9
1.7 General specifications..........................................................................................................10
1.7.1 IEC60945 environment specification ............................................................................10
1.7.2 Power supply ..................................................................................................................10
1.7.3 Compass safe distance..................................................................................................11
1.8 Unit specifications ................................................................................................................12
1.8.1 Control unit (NCK-175)...................................................................................................12
1.8.2 LCD Display unit (NWZ-4650) ........................................................................................13
1.8.3 Reset button unit (NCJ-895) ..........................................................................................13
1.8.4 Reset button unit (Waterproof) (NCJ-896) ....................................................................14
1.8.5 Buzzer unit (NVS-785) ....................................................................................................14
1.8.6 Motion sensor (NYG-5)...................................................................................................15
1.8.7 LED warning lamp unit (NCD-2257) ..............................................................................15
2 Installation....................................................................................................................................16
2.1 Guidelines for BNWAS Installation......................................................................................16
2.2 Control unit (NCK-175) .........................................................................................................17
2.2.1 Installation space ...........................................................................................................17
2.2.2 Installation ......................................................................................................................18
2.3 LCD Display unit (NWZ-4650)...............................................................................................19

Contents
JCX-161 BNWAS Installation Manual
viii
7ZPNA4321
2.3.1 Installation space and installation position..................................................................19
2.3.2 Desktop installation .......................................................................................................21
2.3.3 Flush mounting installation...........................................................................................22
2.3.4 Removing the LCD Display unit for flash mounting installation ................................23
2.4 Reset button unit (NCJ-895).................................................................................................24
2.4.1 Installation ......................................................................................................................24
2.4.2 Flush mounting installation...........................................................................................24
2.4.3 Wall mounting installation .............................................................................................25
2.5 Reset button unit (Waterproof) (NCJ-896)...........................................................................27
2.5.1 Installation outline..........................................................................................................27
2.5.2 Installation ......................................................................................................................27
2.6 Buzzer unit (NVS-785)...........................................................................................................28
2.6.1 Installation ......................................................................................................................28
2.6.2 Flush mounting installation...........................................................................................28
2.6.3 Wall mounting installation .............................................................................................29
2.7 Motion sensor (NYG-5) .........................................................................................................31
2.7.1 Installation space ...........................................................................................................31
2.7.2 Installation ......................................................................................................................33
2.8 LED warning lamp unit (NCD-2257).....................................................................................35
2.8.1 Installation ......................................................................................................................35
2.8.2 Flush mounting installation...........................................................................................35
2.8.3 Wall mounting installation .............................................................................................36
3 Wiring ...........................................................................................................................................38
3.1 Interconnection wiring..........................................................................................................38
3.2 Wiring cable...........................................................................................................................41
3.3 Control unit (NCK-175) .........................................................................................................42
3.3.1 Arrangement figure of terminal blocks.........................................................................42
3.3.2 Setting of DIP switch......................................................................................................45
3.3.3 Power supply terminal block (CBJ-165 TB1) ...............................................................46
3.3.4 Visual indication (LED warning lamp unit) / audible alarm (buzzer unit) connection
terminal block (CDJ-2486 TB1)...............................................................................................48
3.3.5 Reset button unit connection terminal block (CDJ-2486 TB2) ...................................51
3.3.6 Reset button unit / motion Sensor / external navigation equipment connection
terminal block (CDJ-2486 TB3)...............................................................................................53
3.3.7 External navigation equipment/ CAS (Central Alarm System)/ VDR connection
terminal block (CDJ-2486 TB4)...............................................................................................54
3.3.8 LCD Display unit connection terminal block (CDJ-2486 TB5) ....................................55

Contents
JCX-161 BNWAS Installation Manual
ix
7ZPNA4321
3.4 LCD Display unit (NWZ-4650)...............................................................................................56
3.5 Reset button unit (NCJ-895 TB1) .........................................................................................62
3.6 Reset button unit (Waterproof) (NCJ-896 TB1)...................................................................66
3.7 Buzzer unit (NVS-785 TB1) ...................................................................................................71
3.8 Motion sensor (NYG-5 TB1) .................................................................................................76
3.9 LED warning lamp unit (NCD-2257 TB1) .............................................................................79
4 Installation setting.......................................................................................................................82
4.1 Changing to maintenance mode..........................................................................................83
4.2 Setting BUZZER CH ..............................................................................................................84
4.3 Setting NMEA COMM (COMMUNICATION)..........................................................................85
4.4 Setting RMS OUTPUT ...........................................................................................................87
4.5 MAINTENANCE function ......................................................................................................88
4.5.1 EXTERNAL INPUT function ...........................................................................................88
4.5.2 INPUT DATA function .....................................................................................................89
4.5.3 Self-diagnosis (DIAGNOSIS) function ..........................................................................90
4.5.4 Firmware version and serial number display function................................................91
4.5.5 Password reset function................................................................................................93
4.6 MASTER RESET function.....................................................................................................93
4.7 SOFT UPDATE function........................................................................................................95
4.7.1 Updating..........................................................................................................................95
4.7.2 Software update procedure ...........................................................................................96
5 Operation check ........................................................................................................................106
5.1 Operation check of the control unit (NCK-175) ................................................................106
5.1.1 Operation check by voltage.........................................................................................106
5.2 Operation check of other units ..........................................................................................108
5.3 Operation check with external equipment ........................................................................109
5.3.1 VDR output....................................................................................................................109
5.3.2 Navigation equipment alarm .......................................................................................113
6 Outline drawing ......................................................................................................................... 114
6.1 Control unit (NCK-175) .......................................................................................................114
6.2 LCD Display unit (NWZ-4650)............................................................................................. 115
6.3 Reset button unit (NCJ-895)...............................................................................................116
6.4 Reset button unit (Waterproof) (NCJ-896) (Option)..........................................................117
6.5 Buzzer unit (NVS-785)......................................................................................................... 118
6.6 Motion sensor (NYG-5) (Option) ........................................................................................119
6.7 LED warning lamp unit (NCD-2257) (Option) ....................................................................120

Contents
JCX-161 BNWAS Installation Manual
x
7ZPNA4321

1. Specification
JCX-161 BNWAS Installation Manual
1
7ZPNA4321
1 Specifications
1.1 Functions
The system is a Bridge Navigational Watch Alarm System (BNWAS) consisting of a control unit, a
display unit, buzzer units, and reset devises. It is designed to prepare for any contingency in
which a duty officer is disabled to fulfill his duties due to a nap, health problem, or other reason.
Upon such an event, the system alerts other officers.
1.1.1 Purpose of the system
The purpose of the Bridge Navigational Watch Alarm System (BNWAS) is to monitor the motions
of the duty officer in the bridge and detect any his behavior disorder that may lead to a marine
accident.
To achieve the purpose, dormant period is set. If no reset operation is performed within the
dormant period, the system recognizes that the duty officer cannot fulfill his duties and outputs an
alarm in the bridge. If no response is given even after that, it alerts the captain or other qualified
officer for its situation.
1.1.2 Operational mode
BNWAS includes the following operation modes.
1) Auto Mode (Automatic mode)
While the ship's heading control system or the track control system is active, the
dormant period count down operates automatically. When their systems are not
activated, the countdown will not operate.
2) Manual On
The dormant period countdown operates continuously.
3) Manual Off
The dormant period countdown does not operate.
The Manual Off only stops the dormant period countdown. It operates the emergency
call, other call functions, and the bridge alarm transfer function.
Except in anchorage or in-bay navigation, operate the unit with “Manual On”.

1. Specification
JCX-161 BNWAS Installation Manual
2
7ZPNA4321
1.1.3 Operation sequence of displays and alarms
Depending on the operation mode, the unit is activated and the dormant period countdown
starts. When the countdown ends, the following displays and alarms are triggered.
1) Visual Indication
At the end of this dormant period, the alarm system initiates a visual indication on the
bridge. The visible display is a blinking manner.
2) First Stage Bridge audible alarm (1st Stage Bridge audible alarm)
If not reset within 15 seconds since the visual indication is initiated, the BNWAS
additionally sounds a 1st stage bridge audible alarm on the bridge.
3) Second Stage Remote audible alarm (2nd Stage Remote audible alarm)
If not reset within 15 seconds since the 1st stage bridge audible alarm is initiated, the
BNWAS additionally sounds a 2nd stage remote audible alarm in the back-up officer's
and/or Master's location.
4) Third Stage Remote audible alarm (3rd Stage Remote audible alarm)
If not reset within 90 seconds (which can be set 0s, or between 90 ~ 180s) since the 2nd
stage remote audible alarm is initiated, the BNWAS additionally sounds a 3rd stage
remote audible alarm at the locations of further crew members.
Alarm sequence without acknowledgements

1. Specification
JCX-161 BNWAS Installation Manual
3
7ZPNA4321
1.2 Features
1.2.1 Versatile functions with standard configuration
1）BNWAS function
When dormant period are measured, and the confirmation is not done, warning is
output with the visual indication and the alarms according to the sequence of 1.1.3.
2）Support of emergency call function and bridge alarm transfer function
The emergency call function is offered without optional equipment. The bridge alarm
can transfer an unacknowledged alarm with the serial interface that uses the
IEC61162-1 ALR sentence.
1.2.2 Various reset devices and number of inputs
1) Reset devices
A maximum of 6 pushbutton reset devices (NCJ-895 and NCJ-896) can be provided so
that the dormant period can be reset within 15 s in anywhere since the visual indication
starts. The reset function is equipped also in the LCD Display unit (NWZ-4650).
2) Motion sensor type reset device (option)
The motion sensor (NYG-5) which performs automatic reset by human presence and
motions can be installed.
3) Reset by external unit
The system supports the reset signal from other navigational equipment. The reset
signal can be input via. an IEC 61162 serial interface or a contact input.
1.2.3 Output to external device
1）System Failure output by contact signal
The system can output the System Failure to CAS by contact signal.
2）VDR output by serial interface
The system can output machine status or alarm situation to VDR by the serial interface
using the IEC61162-1 ALR sentence.

1. Specification
JCX-161 BNWAS Installation Manual
4
7ZPNA4321
1.2.4 Remote maintenance function
When connected with a VDR provided remote maintenance from our company, the unit allows
you to monitor its status from a remote place.

1. Specification
JCX-161 BNWAS Installation Manual
5
7ZPNA4321
1.3 Composition
Component list of bridge navigational watch alarm system (BNWAS)
No. Item Model Q'ty
(exp.)
Mass (kg) Remarks
Standard configuration
1 Control unit NCK-175 1 4.5
2 LCD Display unit NWZ-4650 1 0.6
Attached the operation
card (7ZPNA4319) ,power
cable(CFQ-5766B),data
cable(CFQ-5951B),Fuse(1
A, 2piece)
3 Buzzer unit NVS-785 8 0.2
4 Reset button unit NCJ-895 3 0.2
Option
5 Motion sensor NYG-5 1 0.4
6 LED warning lamp unit NCD-2257 1 0.2
7 Reset button unit
(Waterproof) NCJ-896 1 0.5 IP56
8 Instruction manual 7ZPNA4317 1 0.3
9 Spare parts 7ZXNA4012 1 0.04 Fuse for NCK-175
(2A, 1A, 1 piece each)
10 Spare parts 7ZXNA4013 1 0.04 Fuse for NWZ-4650
(1A, 2piece )
11
External Navigational
equipment connection
cable
CFQ-5767 1 0.1

1. Specification
JCX-161 BNWAS Installation Manual
6
7ZPNA4321
1.4 Spare parts
1.4.1 Fuse for Control unit (NCK-175)
Ship
No. Standard spare part Device name Qty
Model: JCX-161 BNWAS （ Bridge Navigational Watch Alarm System ）
Qty Remarks
Service qty Spec.
No. Item
name
Outer dimension
diagram (mm) Qty/
device
Qty/
ship
Spare JRC code
Spare
part
box
No.
MF60 NR 250V 2
1 Fuse
1 1
(5ZFGD00010)
MF60 NR 250V 1
2 Fuse
1 1
(5ZFGD00205)
3
4
5
6
7
8
Manufacturer JAPAN RADIO CO.,LTD. Spare
part code 7ZXNA4012
30
󳔏6.4
30
󳔏6.4

1. Specification
JCX-161 BNWAS Installation Manual
7
7ZPNA4321
1.4.2 Fuse for LCD Display unit (NWZ-4650)
Ship
No. Standard spare part Device name Qty
Model: NWZ-4650 BNWAS （ Bridge Navigational Watch Alarm System ）
Qty Remarks
Service qty Spec.
No. Item
name
Outer dimension
diagram (mm) Qty/
device
Qty/
ship
Spare JRC code
Spare
part
box
No.
MF60 NR 250V 1
1 Fuse
2 6
(5ZFGD00205)
2
3
4
5
6
7
8
Manufacturer JAPAN RADIO CO.,LTD. Spare
part code 7ZXNA4013
30
󳔏6.4

1. Specification
JCX-161 BNWAS Installation Manual
8
7ZPNA4321
1.5 Connection Diagram
