Elmdene ELM-PA-G3 series User manual

ELM-PA-G3-X Panic Button Guide
Specifications
Contact
Power Handling 10VA
Voltage Rating 30Vdc
Current Rating 1.0A Max
Resistance <300mohms
Operating Life >1 x 10 operations
8
Temperature Range -10
Dimensions 62 x 80 x 27mm
°C to+40°C
X is colour code: ELM-PA-G3-W White, ELM-PA-G3-B Brass, ELM-PA-G3-SS Steel
ELM-PA-G3-BK Black
2015 Elmdene International Ltd PAK200464 Feb 2015 Iss 03C Page 1
Technical Support Line + 44 (0) 2392 696638
Setting reed - Normally Open (N.O.) or Normally Closed (N.C.)
Default is set to Normally closed. Please skip this section if this is the required setting.
1. Tab
Tab
Follow steps 1&2 in reverse order to re-assemble. Take care not to damage the reed switch.
Wall Mounting
1. Press both buttons to move mechanism out of the way and gain access to the bottom fixing hole.
2. Mark positions of holes on the wall.
3. Drill holes to required depth and use appropriate wall plugs or fixings (No. 6 / 5mm).
4. Drive bottom screw through base and into wall.
5. Insert top screw through PCB and plastic and screw into wall.
6.
7. Angle lid as shown above. Slide upward pushing lid closed. Fasten lid shut with screw.
countersunk
pan head
before
Take care not to snap
the PCB tamper breakout.
Use friction adjustment screw to ensure sliding mechanism does not move without being pushed
by buttons or reset key. DO NOT OVERTIGHTEN
Use of the PA button
Correct Use of PA Buttons
1. Push both buttons together to operate. After use
indicator will be red (latched).
2. To reset insert the key into the slot as shown.
3. Turn key clockwise as far as it will turn (about 120
degrees) to reset the PA.
4. Turn the key anticlockwise back to the start and remove it.
5. Indicator will now be yellow (ready).
PA buttons should be installed in accordance with any applicable
regulations relating to panic alarms. Potential users should be advised in
the use of the PA.
Page 2
Top mounting
screw hole
Bottom mounting
screw hole
2. 3.
Friction
Adjustment
Screw
Normally Closed
(Factory Default)
Normally
Open
1. Remove PCB by gently
bending the two tabs back
and pull the board up and
out.
2. Remove the sliding
mechanism (you may need
to loosen the friction
adjustment screw).
3. Push out magnet from other
side and swap to desired
position.
ELMDENE INTERNATIONAL LIMITED
3 KEEL CLOSE
INTERCHANGE PARK
PORTSMOUTH
HAMPSHIRE
PO3 5QD, UK
TEL: [phone]
FAX: [phone]
www.elmdene.co.uk
Features include:
• Silent two button operation
• Compliant with PD6662: 2010, and the requirements of EN 50131-1:2006, Security
grade 3, Environmental class II.
• Suitable for use under the ACPO “10 point plan” for false PA reduction
• Integral, selectable resistor values for easy FSL connection to most alarm control
panels.
• Alternative double pole wiring option
• Spare terminals for connection of multiple units
• Key operated mechanical reset
• Selectable normally open or normally closed alarm contacts
• Cover and removal from wall tamper (normally closed)
• Visual indication of ready or latched state
Panic alarm trigger device with two push buttons
Meets the requirements of 10 at Grade 3, Environmental Class II
A range of aesthetically pleasing two button panic alarm (PA) devices available with black,
white, brass or stainless steel appearance covers. Suitable for commercial and domestic
installation
PD6662: 20 and EN
50131-1:2006.
.

To
Control
Panel 6
5
4
3
2
1
6
5
4
3
2
1
6
5
4
3
2
1
6
5
4
3
2
1
Multiple PA (Parallel Resistor Configuration)
FSL Wiring Two PA (Series Resistor Configuration)
Shunt R
EOL R
LX
ü
û
û
Shunt R
EOL R
LX
û
ü
ü
Single PA (Parallel or Series)
Two PA (Parallel Resistor Configuration)
Follow Instructions
ü
û
= Fit jumper shown
= Do Not Fit jumper
LX = Link near terminal 1
For additional PAs, connect as “Other PAs”
Shunt R
EOL R
LX
ü
û
ü
Jumper
Settings
PA 1 PA 2
To
Control
Panel
6
5
4
3
2
1
To
Control
Panel
6
5
4
3
2
1
6
5
4
3
2
1
Jumper
Settings
PA 1 PA 2
Jumper
Settings
Shunt R
EOL R
LX
ü
ü
ü
Multiple PA (Series Resistor Configuration)
To
Control
Panel
6
5
4
3
2
1
6
5
4
3
2
1
6
5
4
3
2
1
Shunt R
EOL R
LX
û
ü
ü
Last PA
Shunt R
EOL R
LX
û
û
û
Other PAs
Shunt R
EOL R
LX
ü
û
û
Shunt R
EOL R
LX
û
û
û
Jumper
Settings
First PA Second PA
6
5
4
3
2
1
To
Control
Panel 6
5
4
3
2
1
6
5
4
3
2
1
For additional PAs, connect as “Other PAs”
Shunt R
EOL R
LX
û
û
û
Last PA
Shunt R
EOL R
LX
û
û
û
Last but one PA
Shunt R
EOL R
LX
ü
û
ü
Shunt R
EOL R
LX
û
û
û
Jumper
Settings
First PA
Shunt R
EOL R
LX
û
û
û
6
5
4
3
2
1
Two PA
PA 1
Tamper
Circuit
6
5
4
3
2
1
Alarm
Circuit
PA 2
Wiring the PA Button
Connections to the PA button are made via the screw terminals numbered 1 to 6.
Configuration of the resistor values to match the alarm panel is by link jumpers.
See the table below to find the resistor values and series or parallel option
needed.
Shunt and EOL Resistors by Control Panel Manufacturer
Control Panel Shunt EOL Configuration
Resistor Resistor
ADE, Bosch, Castle, Menvier, Pyronix, Scantronic, Texecom 4k7 2k2 Series
Honeywell (Galaxy) 1k0 1k0 Series
Guardall 8k2 8k2 Parallel
GE, Aritech, Pyronix 4k7 4k7 Series
Gardtec 6k8 4k7 Series
Bosch, Europlex 2k2 2k2 Series
DSC 5k6 5k6 Series
FSL Wiring (Shunt and EOL Resistor)
Location of Configuration Parts
1
2
3
4
5
6
Terminal
Connections
EOL Resistor
(Chosen by link jumper)
Shunt Resistor
(Chosen by link jumper)
Configuration LX
(See text and diagrams)
= LX Jumper Not Fitted
= LX Jumper Fitted
Double Pole Wiring - REMOVE ALL JUMPERS
Double Pole Wiring - REMOVE ALL JUMPERS
Single PA
Tamper
Circuit
6
5
4
3
2
1
Alarm
Circuit
6
5
4
3
2
1
Multiple PA
First PA
Tamper
Circuit
6
5
4
3
2
1
Alarm
Circuit
6
5
4
3
2
1
6
5
4
3
2
1
Other PAs Last PA
For additional PAs, connect
as “Other PAs”
Last but one PA
Other PAs
= LX Jumper Not Fitted
= LX Jumper Fitted
Page 4
Page 3
