JRC NSVS1252 User manual

NSVS1252 Oct. 2008
Application
433.92MHz R.K.E.
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications
Spec. Typ.
- 433.92MHz
Filter Bandwidth -3dB Band Width 800kHz min. 1050 kHz
Minimum Insertion Loss 3.5dB max. 3.0dB
Input Output VSWR f0±125kHz 2.0 max. 1.5
Ripple f0±125kHz 1.5dB max. 0.75dB
Attenuation f0± 1.0MHz 20dB min. 30dB
f0± 10.7MHz 60dB min. 65dB
f0± 21.4MHz 60dB min. 65dB
Operating Temperature Range : (-40～+85℃)
Item
Nominal Center Frequency (f0)
Maximum Rating: (Table 2)
Mechanical Specifications: (Fig.2)
Package is designed as small as 3.0x3.0x1.15[mm3] for SMD (Surface Mount Device) type.
Notice:
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Table 2. Maximum Ratings
Item Rating
Maximum Input Power +5dBm
Operating Temperature Range -40~+85ºC
Storage Temperature -40~+85ºC
JRC SAW FILTER
NSVS1252
Communications Equipment Division
Communications Equipment Marketing Department
10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku,
Tokyo, 160-8328 Japan
Tel. [phone]
Fax. [phone]
http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese)
http://www.jrc.co.jp/eng/product/saw/index.html(English)

NSVS1252 Oct. 2008
Marking
(1) Lot Number
(a) Year
(b) Month
*Oct.--- X
Nov.--- Y
Dec.--- Z
(c) Date
1-9--- 0
10-19--- 1
20-31--- 2
(2) Part Number Mark
Pin no. Connection
1 GND
2 IN
3 GND
4 GND
5 OUT
6 GND
(0.6)
(0.25)
(0.6)
(0.53)
(0.75)
(0.45)
1
2
34
6
1. 1 5 ± 0. 1 5
3. 0 ± 0. 1 5
3. 0 ± 0. 1 5
(a)
(1)
(b)
(2)
(1.80)
5
[2x]
[4x]
[4x]
(c)
Fig.1 Measuring circuit
Fig.2 Package dimensions (in mm)
Fig.3 Desirable land area (in mm)
8X1
ＳＯ
0.93
0.6
0.93
3.8
3.8
2.2 1.15
1.15
1
2
34
5
6
S A W
IN OUT
50 Ω
Ω
50
0.3pF
68nH 68nH
0.3pF

NSVS1252 Oct. 2008
Notice
1. Use this component within operating temperature range. It might not be
satisfied with electrical specification without operating temperature range.
When it is used less than -40ºC or more than +85ºC, it might be a cause of
degradation or destruction of the component. Even if it endures during a short
time, it causes degradation of qualification.
2. When soldering iron is used, solder with the temperature at the tip of soldering
iron: 350ºC max., the time of soldering: 10 seconds max., the power of
soldering iron: 30W max..
3. Notice that the allowed time of soldering with soldering iron is accumulated
time, when soldering is repeated.
4. As rapid temperature change for cleaning after reflow soldering might be a
cause of destruction clean this component after confirming that temperature of
this component goes down to room temperature.
5. Confirm that there are not any influence for qualification to this component in
mounting on PCB when this component is cleaned.
6. As it might be a cause of degradation of destruction to apply static electricity to
this component, do not apply static electricity or excessive voltage while
assembling and measuring. And do not transport this component with bare
hand.
Note
1. This specification specifies the quality of this component as a single unit.
Make sure that this component is evaluated and confirmed against this
specification when it is mounted to your products.
2. The information contained herein may be changed without prior notice. It is
therefore advisable to contact Japan Radio Company before proceeding with
the design of equipment incorporating this product.
3. The products are designed to be used with ordinary electronic equipment
(data and communications equipment, office equipment, audio-video
equipment, measuring instruments, etc). Japan Radio Company does not
assume any liability for the case using the products with the application
required high reliability or safety extremely (such as space equipment,
sea-bottom equipment, medical equipment etc). When intending to use any
our product please contact our sales representatives in advance.

0
20
40
60
80
100
S21
Insertion Loss [dB]
0
2
4
6
8
10
CH1 : center 433.92 span 50
CH2 : center 433.92 span 2
Insertion Loss [dB]
FREQUENCY CHARACTERISTICS
NSVS1252 Oct. 2008
S11 S22
S11 S22
1 1
3 3
5 5
7 7
9 9
11 11
432.9 432.9434.9 434.9
Frequency [MHz] Frequency [MHz]
VSWR VSWR
InsertionLoss [dB]
0
20
40
60
80
100
0 3000
S21
Frequency [MHz]
NSVS971 Dec-04
Fig.1 Measuring circuit
13.30±0.20
6.5±0.20
(R0.3)
[4×]
(0.76)
(2.54)
(1.4)
(0.8)
[12×]
(2.54±0.15)
Pin No. Connection
1GND(PKG)
2GND(PKG)
3 GND(PKG)
4GND(PKG)
5OUT/IN
6 GND(signal)
7GND(PKG)
8GND(PKG)
9GND(PKG)
10 GND(PKG)
11 IN/OUT
12 GND(signal)
2.0 max.
(1)
(a) (b)
(3)
Marking
(1) Manufacture's Mark
(2) Lot Number
(a) Year
(b) Month
*Oct.--- X
Nov.--- Y
Dec.--- Z
(c) Date
1-9--- 0
10-19 --- 1
20-31 --- 2
(3) Part Number Mark
(1.26±0.13)
[12×]
[12×]
(2.54)
(R0.3)
(2.54±0.15)
(2)
12345
6
7
8
910
11
12
(C)
Fig.2 Package dimensions(in mm)
J4Y1
VS971
１２３４
10
９８７
11
12
６
５
OUT
50O
IN
50O
SAW
*27nH
*27nH
39pF
33pF
*murata LQW18A series
