Juicebox Gold Mount Battery JBGM-95 User manual

Gold mount battery
JBGM-95, JBGM-150
Thanks for purchasing a Juicebox!
To ensure best results, please
read the following instructions
before use.
juicebox.direct

Charging
The Juicebox gold mount battery can be charged
with the included smart charger. Just connect the
smart charger to the battery via the battery’s d-tap
port. The charger’s LED light should glow red to in-
dicate that the battery is charging. When the battery
reaches full charge, the charger light will glow green.
From full discharge, the Juicebox battery will reach
full charge in approximately 3-4 hours.
Because the Juicebox battery is equipped with
overcharge protection, it is okay to leave your gold
mount battery connected to the charger when not
in use. This will ensure that the battery remains
charged even when inactive for extended periods of
time.
The Juicebox Gold Mount can also be safely charged
with any standard gold mount or d-tap charger de-
signed for use with lithium ion (li-ion) battery cells.
Some rapid chargers, however, require smart battery
functionality, meaning these rapid chargers will not
charge a battery that does not output charge level
information to the charger. These chargers will not
charge Juicebox gold mount batteries. To determine
compatibility, please check your charger’s documen-
tation to see if it requires a capacity readout (smart
battery technology) in order to charge.
12
setup
When attaching the gold mount battery to a gold
mount plate, slide the battery from left to right, onto
the plate, until the battery “clicks” into place. The
gold mount is designed to attach firmly and secure-
ly without vibration or movement. This mechanism
can require a moderate amount of force to lock into
place.
To check the charge level of the battery, press and
release the indicator button on the side of the bat-
tery, located just below the led indicator lights.
76% - 100% Charge Remaining
51% - 75% Charge Remaining
26% - 50% Charge Remaining
1% - 25% Charge Remaining
LED INDICATOR

3 4
USE
Juicebox’s Gold Mount batteries are compatible with
all standard gold mount systems, both in voltage
and fit.
The Juicebox Gold Mount battery is compatible with
many non-gold-mount camera systems, as well,
including Blackmagic Cinema Cameras, Blackmagic
Production Cameras, Blackmagic Pocket Cinema
Cameras and Blackmagic Micro Cameras. Check your
camera’s documentation; if it can accept inputs be-
tween 14-17 volts (i.e. the Blackmagic Cinema Cam-
era’s requirement of 12-30 volts), it is compatible
with our gold mount battery. In many cases, a power
adapter cable is necessary. Please see your camera’s
documentation on power input to find requirements
for the necessary cable/adapter.
The Juicebox Gold Mount battery can also be used
with low power devices, such as field monitors and
DSLR cameras, with the use of a stepdown converter.
Some gold mount plates feature built-in low voltage
outputs, allowing for use with DSLR cameras, field
monitors and other accessories.
Never connect the gold mount, d-tap or DC ports to
devices that cannot accept at least 14.8 volts. Doing
so may damage connected devices.
Automatic Shut Off: Juicebox gold mount batteries
are designed with overcharge and over-discharge
protection. If the power draw on the battery exceeds
10.4 amps, the battery will shut off. To reset the bat-
tery, connect it to the charger. If the Juicebox shuts
off during use, it’s likely that connected devices are
drawing too much power from the battery.
To power on the USB port, with your USB device
connected to the battery, press the LED indicator
button on the side of the battery. This button also
serves as a power button for the USB port.The USB
port outputs 5v and 2.1 amps and can be used
simultaneously with the battery’s gold mount and
d-tap outputs.
The d-tap port functions as both a power input and
output. Both the d-tap port and DC port have the
same output (14.8V and 10.4A) as the gold mount
connection. The Juicebox gold mount battery can be
charged through either the gold mount connection
or the d-tap port.
Note: Connecting auxilary devices to the battery’s
USB, DC and d-tap ports will add to the overall pow-
er draw of the battery. If this power draw exceeds
10.4 amps, the battery will automatically shut down
and requires connection to the battery charger in
order to reset.

D-Tap Port
Input: 14-17V
Output: 14.8V, 10.4A
USB Port
Output: 5V, 2.1A
Gold Mount Connection
Input: 14-17V
Output: 14.8V, 10.4A
DC Port
Output: 14.8V, 10.4A
6
Specifications
Voltage: 14.8V nominal, 16.8V max
JBGM-150 Capacity: 150Wh (10400mAh)
JBGM-95 Capacity: 95Wh (6600mAh)
Amperage: 10.4A maximum
JBGM-150 Cell Type: LG 2600mAh 18650 x 16
JBGM-95 Cell Type: LG 3300mAh 18650 x 8
Composition: Lithium Ion
D-tap & DC Outputs: 14.8V nominal, 10.4A max
D-tap Input: 13-17V, 1.5 - 4.5A
USB Output: 5V, 2.1A
Charger Output: 16.8V, 4.5A
JBGM-150 Weight: 2.2 lbs
JBGM-95 Weight: 1.25 lbs
JBGM-150 Dimensions: 6.00 x 3.75 x 2.25 inches
JBGM-95 Dimensions: 6.00 x 3.75 x 1.50 inches
If you have any issues, questions or feedback, please visit
our support page at Juicebox.Direct/Support. For more
products, including gold mount batteries and compati-
ble hardware, visit our online store at Juicebox.Direct.
Please take the time to review us online! As a small, in-
dependent company producing cost-effective film gear,
your feedback is essential to our growth. Thank you!
support
