JUMO CEROS S01 M User manual

40510109T92Z001K000
V4.00/EN/00687084/2020-06-30
JUMO CEROS S01 M
Digital pressure measuring cell
Interface Description

Contents
Contents
1 General information and notes for the reader . . . . . . . . . . . . . . . . . . . . . 5
1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.2 Trademark information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.3 Symbols and signal words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.3.1 Warning symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.3.2 Note symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2 I²C - communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2 Interface connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2.1 Pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2.2 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2.3 Entire design of the I²C-bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.2.4 Connection to the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.3 Bit rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.4 Data structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.5 Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.6 WRITE Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.7 READ Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.8 Data bytes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3 Sensor data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Receive sensor data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3.1.1 Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3.1.2 Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3.1.3 Read NVM (Non-Volatile Memory) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
3.2 Interpretation of the sensor data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3.2.1 Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3.2.2 Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
4 PC software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.1 Brief description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4.2 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4.2.1 Hardware and software requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4.2.2 Starting installation via download file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4.3 Connection to the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4.4 Program start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
4.5 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
4.5.1 Connecting with sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
4.6 Sensor information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
4.6.1 Sensor details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
4.6.2 Versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
4.7 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Contents
4.7.1 Sensor configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
4.7.2 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
4.8 Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
4.8.1 Offset correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
4.9 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
4.10 Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
4.11 Error messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

5
1 General information and notes for the reader
1 General information and notes for the reader
1.1 General
This manual contains important information regarding the safe and proper use of this product.
Before starting any form of work using this product, this manual must be read and understood.
Only by observing all of the safety information and all safety/warning symbols in this manual can opti-
mum protection of both personnel and the environment, as well as safe and fault-free operation of the
device, be ensured.
In the interest of clarity, this manual does not contain all the detailed information about all product ver-
sions and cannot take into consideration every conceivable case involving the installation, operation, or
maintenance.
If you would like further information, or if problems occur that are not covered by this manual, the re-
quired information can be obtained from the manufacturer.
The contents of this manual are not part of and do not constitute a change to a previous or existing agree-
ment, assurance or legal relationship.
This manual is an integral component of the product and must be stored so that it is accessible to per-
sonnel at all times.
It is essential to observe any notes and symbols that are directly on the product. They may not be re-
moved and must be fully legible at all times.
1.2 Trademark information
• Microsoft® is a registered trademark of Microsoft Corp., Redmond, VA 98052-6399, US.
• Windows® is a registered trademark of Microsoft Corp., Redmond, VA 98052-6399, US.

1 General information and notes for the reader
6
1.3 Symbols and signal words
1.3.1 Warning symbols
DANGER!
The signal word "DANGER" indicates an immediate danger.
Non-observance will lead to death or serious injury.
The instructions in the warning notice must be observed and followed!
WARNING!
The signal word "WARNING" indicates an imminent danger.
Non-observance can lead to death or serious injury.
The instructions in the warning notice must be observed and followed!
CAUTION!
The signal word "CAUTION" indicates an imminent danger.
Non-observance can lead to minor or moderate injury.
The instructions in the warning notice must be observed and followed!
NOTICE!
The signal word "CAUTION" indicates possible damage to property.
Non-observance can lead to damage to devices, systems or the environment.
Observe the instructions in the note for avoiding damage!
1.3.2 Note symbols
NOTE!
This symbol refers to important information about the product, its handling, or additional benefits.
FURTHER INFORMATION!
This symbol is used in tables and indicates that further information is provided after the table.
?
REFERENCE!
This symbol refers to additional information in other sections, chapters, or other manuals.
DISPOSAL!
At the end of its service life, the device and any batteries present do not belong in the trash! Please en-
sure that they are disposed of properly and in an environmentally friendly manner.

7
2 I²C - communication
2 I²C - communication
2.1 General
The digital pressure measuring cell is equipped with a digital I²C interface and optionally an analog out-
put.
The communication via the I²C interface is described in the following chapters. This includes the correct
electrical connection, the entire design as an I²C-bus with master, slave and pull-up resistors. Addition-
ally, the digital communication is described to read out the pressure value, as well as other device infor-
mation. Finally the correct interpretation and conversion of the digital value into a decimal pressure- or
temperature value is depicted. Furthermore configuration possibilities of the digital pressure measuring
cell are described by using the corresponding software see chapter 4 "PC software", Page 19.
NOTE!
Additional information can be found in the data sheet 40510100T10Z001K000 and in the I
2
C-bus spec-
ification and user manual UM10204 on www.nxp.com.
2.2 Interface connection
2.2.1 Pin assignment
2.2.2 Cabling
NOTE!
Be careful with cabling over more than a few centimetres.
The I
2
C-bus is not a field-bus and only EMC safe if the interconnections are short or screened by the
surrounding housing of the whole application or a suitable cable.
Electrical
connec-
tion
05 24 39
Pins Braids JST-plug (Type BM05B-
SRSS-TB)
A
out
2YE5
GND 3 BK 4
U
B
4RD3
SCL 6 WH 2
SDA 7 BU 1

2 I²C - communication
8
2.2.3 Entire design of the I²C-bus
The following figure shows a entire design by way of example, including a master, three digital pressure
measuring cells as slaves and pull-up resistors. The signal wires SDA and SCL are connected by pull-
up resistors to U
B
. A pull-up resistor in the range of 1 to 10 kΩ is recommended. In order to optimize the
data rate or low power consumption, other resistance values are possible.
Scheme of a I²C-bus structure:
I²C is designed as a Master-Slave-bus. A data transfer is initiated by a master and the slave, which is
addressed, reacts on it. Every slave in a bus structure needs a different address to avoid collisions. The
address is stored in the memory of the device. For the communication between master and slave the
bus needs two signal wires: SCL as a clock wire and SDA as a data wire.
Every device connected to SCL and SDA has an open-collector-output. Combined with the pull-up re-
sistors it results in a wired-and circuit. Additional series resistors can be placed directly at the devices to
get more security.
The I²C-bus has a positive logic, what means that a high level at SDA corresponds to a logical '1' and a
low level corresponds to a logical '0'.
The transmission protocol of I²C starts with a start-bit, the address and a R/W- bit (Read/Write) sent by
the master. This will be confirmed by the addressed slave with an ACK-bit. Dependent on the R/W-bit
data is written (data to slave) or read (data to master). The confirmation with the ACK-bit is sent by the
slave when writing and by the master when reading. The last byte of a reading access is confirmed with
a NACK-bit by the master, to show the end of a transmission. The transmission is finished with a stop-bit.
The bit rate of the data transfer is set by the master.
The maximum bit rate, supported by the digital pressure measuring cell, is shown in the following chap-
ter.
Addr: 0x29
Addr: 0x28
1st slave
Addr: 0x2A
Addr: 0x28
2nd slave
Addr: 0x2B
Addr: 0x28
nth slave
R
Pullup
R
Pullup
UBSCL SDA 0V
μC
Master

9
2 I²C - communication
2.2.4 Connection to the computer
NOTE!
The digital pressure measuring cell can be connected with a PC/Notebook via PC-Interface with Con-
verter USB/I²C TO39.
see chapter 4.3 "Connection to the computer", Page 19
2.3 Bit rate
The digital pressure measuring cell works over two sets of bitrates (transfer speed). The maximum clock
frequency is 400 kbit/s. Furthermore the maximum bit rate depends on the cable length and the pull-up
resistors. So it is recommended to start with lower bit rates and test the maximum possible bit rate by
increasing it.
2.4 Data structure
•Idle period
During inactivity of the bus, SDA and SCL are pulled-up to the supply voltage VDDA.
•Start condition
Every data frame starts with a start condition. A high-to-low transition on SDA while SCL is at the high
level indicates a start condition. Every command must be initiated by a start condition sent by a master.
Mode Max. bit rate Direction
Standard mode (Sm) 100 kbit/s bidirectional
Fast mode (Fm) 400 kbit/s bidirectional
SCL
SDA
start
condition
valid data proper
change
of data
stop
condition

2 I²C - communication
10
•Valid data
Data is transmitted in bytes (8 bits) starting with the most significant bit (MSB). Each byte transmitted is
followed by an acknowledge bit. Transmitted bits are valid if, after a start condition, SDA remains at a
constant level during the high period of SCL. The SDA level may change only when the clock signal at
SCL is low.
•Acknowledge
An acknowledge after a transmitted byte is obligatory. The master must generate an acknowledge-relat-
ed clock pulse. The receiver (slave or master) pulls down the SDA line during the acknowledge clock
pulse. If no acknowledge is generated by the receiver, a transmitting slave will become inactive. A trans-
mitting master can abort the transmission by generating a stop condition and can repeat the command.
A receiving master may signal the end of the transfer to the transmitting slave by not generating an ac-
knowledge-related clock pulse at SCL. The digital pressure measuring cell changes to inactive interface
mode when processing internal command routines started by a previously sent command.
After every transferred byte (in both directions) the receiver of the byte gives feedback with the acknowl-
edge bit.The slave should always confirm the bytes by an ACK. If the slave does not respond with a LOW
level after the 8th bit, the master detects an exception (for example caused by requesting to the wrong
slave address). A NACK from the master’s side is not always an exception. It is also needed to terminate
a read data frame.
•Stop condition
Every data frame ends with a stop condition. A low-to-high transition on SDA while SCL is at the high
level indicates a stop condition. A command must be closed by a stop condition to start processing the
command routine in the digital pressure measuring cell.
2.5 Addressing
The first byte of every data frame contains the slave address and a R/W bit (Write = 0/Read = 1).
The default slave address (standard adress) of the digital pressure measuring cell transmitters is: 0x28,
another address can be set by using the software (see chapter 4.7.2 "Communication", Page 28). The
7 bit address of a I²C-device allows 112 bus addresses in general, because 16 of the 128 possible ad-
dresses are reserved for special purposes.
The digital pressure measuring cell has a fixed 5 bit-address, with a 2 bit-subadress, which is configu-
rable, but the device always answers to 0x28. So it is possible to use three digital pressure measuring
cells on one bus without getting collisions at the maximum. Possible addresses for the slaves in a bus
structure with one slave are 0x28, 0x29, 0x2A, 0x2B, in a bus structure with more than one slave 0x29,
0x2A, 0x2B. Other devices with other addresses (e.g. temperature sensors) can be added to the bus
too, as long as the maximum number of 112 devices is not exceeded.
Examples:
ADDR is 0x28 - data transfer from the master to the slave (write)
ADDR is 0x2B - data transfer from the slave to the master (read)
011 0 0000
0x00 (write)
0x28 (address)
0x50 (first byte)
011 0 0111
0x01 (read)
0x2B (address)
0x57 (first byte)

11
2 I²C - communication
2.6 WRITE Operation
An I²C WRITE operation is initiated by the master sending the slave an address byte including a data
direction bit set to ‘0’ (WRITE). The address byte is followed by a command byte, and for applicable com-
mands two additional data bytes (optional). The digital pressure measuring cell’s internal micro-controller
evaluates the received command and processes the related routine. In the following a WRITE command
with two data bytes and another WRITE command without data bytes is illustrated.
WRITE Command Byte and 2 Data Bytes
WRITE Command Byte and no Data Bytes
2.7 READ Operation
A data request from a master to a slave is initiated by sending an address byte including a data direction
bit set to ‘1’ (READ). The slave answers by sending data from the interface output registers. The master
must generate the transmission clock for the following: SCL, acknowledges after each data byte (except
after the last one), and the stop condition at the end. A data request is handled by thedigital pressure
measuring cell’s interface module and consequently does not interrupt the current process of the internal
micro-controller.
Read 2 (+n) Data Bytes
2.8 Data bytes
The data registers of the digital pressure measuring cell consists always of 2 bytes. The device always
returns a status byte before sending the data bytes. The status byte can be for example the reading com-
mand. So the slave returns 3 bytes when reading one register.
543210WA76503210A15 14 13 12 11 10 9 8 A76543210ASS 6
Device Slave Address [6:0]
Command Byte [7:0] Data Byte [15:8] Data Byte [7:0]
543210WA76503210AS6
Device Slave Address [6:0]
Command Byte [7:0]
S
SStart/Stop condition 6Device slave address (example: Bit 5) WRead/Write Bit (example: Write=0)
5Command Bit (example: Bit 5) 4Data Bit (example: Bit 4) AAcknowledge (ACK)
543210RAS615 14 13 12 11 10 9 8 A76543210A76543210NS
Device Slave Address [6:0]
Data Byte [15:8] Data Byte [7:0] n Data Byte
th
obligatory optional obl.
SStart/Stop condition 6Device slave address (example: Bit 6) WRead/Write Bit (example: Write=1)
5Command/Data Bit (example: Bit 5) AAcknowledge (ACK) NNo Acknowledge (NACK)

2 I²C - communication
12

13
3 Sensor data
3 Sensor data
3.1 Receive sensor data
The chart states the combination of address and function in the default settings.
3.1.1 Pressure
1. Requesting pressure value (4 bytes from master)
2. Reading pressure value (1 byte from master, 3 bytes from slave)
NOTE!
The first byte returns the command 0x2E (read RAM), Byte 2 and 3 make the 15 bit digital count of the
actual pressure value in common: P[u15] = data [Byte 2; Byte 3].
3.1.2 Temperature
1. Requesting temperature value (4 bytes from master)
2. Reading temperature value (1 byte from master, 3 bytes from slave)
NOTE!
The first byte returns the command 0x2E (read RAM), Byte 2 and 3 make the 15 bit digital count of the
actual pressure value in common: T[u15] = data [Byte 2; Byte 3].
ADDR default 0x28
W (Write): 0  ADDR | W default 0x50
R (Read): 1  ADDR | R default 0x51

3 Sensor data
14
3.1.3 Read NVM (Non-Volatile Memory)
NOTE!
The NVM can only be read out in Command Mode. A measured value can only be read out in Normal
Mode. Changes of NVM registers have influence on the checksum and the function of the cell and are
therefore not allowed!
1. Command Mode (4 bytes from master)
2. Request NVM Word (4 bytes from master)
a
registry adresses  see table "Registry adresses ", Page 15
3. Read NVM Word (1 bytes from Master, 3 bytes from Slave)
4. Normal Mode (4 bytes from Master)
0x72 0xF5 0xA2
0x24 0x00 0xXX
a
0x24
master
0x01 0xF5
0xA2

15
3 Sensor data
Registry adresses
Sensor specification
Manufacturing data
Registry Description
0x49 Measuring range start
[15] - Unit: 1 = bar, 0 = mbar
[14] - Prefix sign: 1 = negative, 0 = positive
[13:0] - Value: 0 to 16383
0x4A Measuring range end
[15] - Unit: 1 = bar, 0 = mbar
[14] - Prefix sign: 1 = negative, 0 = positive
[13:0] - Value: 0 to 16383
0x4B Sensor type
[15:1] - free
[0] - Type: 1 = absloute pressure, 0 = relative pressure
Registry Description
0x3E Part number highword [31:16]
0x3F Part number lowword [15:0]
0x40 FA number (production order number) highword [31:16]
0x41 FA number (production order number) lowword [15:0]
0x42 Production location – 010 (dec) for JUMO Fulda
0x43 Production date – year [15:8] / calendar week [7:0]
0x44 Counter number (serial number) 000 to 999
0x45 T
offset
(value range floating point value from 0 to -1024)
Value 0 = 0
Value 65535 = -1024
0x45 T
slope
(value range floating point value from 0 to 0.05)
Value 0 = 0
Value 65535 = 0.05
Offset = -T * 1024
offset
65535
Slope = T * 0.05
slope
65535

3 Sensor data
16
3.2 Interpretation of the sensor data
3.2.1 Pressure
The conversion of the digital values to decimal pressure values is realized by a linear function defined
by two points (P
min
and P
max
).
The minimum and maximum pressure values are stated in the order confirmation. Additionally, the pres-
sure range of the digital pressure measuring cell is stored in its memory and can be read by the software
(see chapter 4.6.1 "Sensor details", Page 22).
The output range is 10 % to 90 % of the 15 bit data. This way concurrently over- and underpressure is
measurable and the resulting 26214 full scale guarantee a very high resolution.
Calculating pressure value
In standard configuration the actual pressure can be calculated with the following formula:
MSP (measuring span) = P
min
(measuring range start) - P
max
(measuring range end)
Example:
Calculation
pressure range: -1 to +15 bar  span: 16 bar
P[u15] P[bar] P[bar] example
P
10%
: 3277 (10 % of 15 bit) P
min
-1
P
90%
: 29491 (90 % of 15 bit) P
max
+15

17
3 Sensor data
3.2.2 Temperature
The interpretation of the digital temperature values follows a linear function. To interpret the digital values
of the temperature it is necessary to read the parameters T
slope
and T
offset
once from NVM (0x45 and
0x46), by using the commands (see chapter 3.1.3 "Read NVM (Non-Volatile Memory)", Page 14) or
using the software, or manually by reading the protocol. Every digital pressure measuring cell has its in-
dividual parameters T
slope
and T
offset
.
Calculate temperature value
In standard configuration the actual temperature can be calculated with the following formula:

3 Sensor data
18

19
4 PC software
4 PC software
4.1 Brief description
The PC software was developed for communication between PC and digital pressure measuring cell.
Using the PC software, the user can adjust the digital pressure measuring cell (offset) and set various
parameters within the device.
Communication between PC and digital pressure measuring cell is via PC-Interface with Converter USB/
I²C TO39, which also provides the operating voltage for the connected pressure cell.
The PC software is designed for online operation. The data to be set are read out from the connected
digital pressure measuring cell, displayed, modified by the user and written back into the device.
It is not necessary to save data in a file on the PC, and a printout is also not required.
4.2 Installation
4.2.1 Hardware and software requirements
For operation and the installation of the PC software the following hardware and software requirements
have to be met:
• Notebook or Desktop-PC
• Microsoft Windows 7 or newer
• USB interface
• PC-Interface with Converter USB/I²C TO39 (Part no. 00695325)
4.2.2 Starting installation via download file
NOTE!
The PC software was developed for communication between PC and digital pressure measuring cell and
is available as a free download at www.jumo.net.
1. Start the installation file after the download via Windows Explorer.
2. Follow the installation instructions.
4.3 Connection to the computer
To use the PC software, the digital pressure measuring cell must be connected to the PC/Notebook via
PC-Interface with Converter USB/I²C TO39.
(1) PC/Notebook – setup software installed
(2) PC-Interface with Converter USB/I²C TO39 (Part no. 00695325)
(3) Digital pressure measuring cell

4 PC software
20
4.4 Program start
Windows Start Menu
1. Make sure the digital pressure cell is connected to the PC/notebook.
see chapter 4.3 "Connection to the computer", Page 19
2. Start the PC software via the Windows Start Menu.
The start screen of the PC software appears.
Start screen
(1) Menu bar
(2) Toolbar
(3) Sensor - Quick info
(4) Dialogue box
(5) Status bar
