Juwent TROPIC-1 User guide

TROPIC
HEATING UNIT
Szymański, Nowakowski General Partnership
31 Lubelska Str., 08-500 Ryki
phone [phone], fax [phone]
POLAND
I. CONTACTS
II. ORIGINAL INSTRUCTION MANUAL
III. WARRANTY TERMS AND CONDITIONS
IV. UNIT STARTUP REPORT
V. INSPECTION AND MAINTENANCE DOCUMENT
VI. SERVICE NOTIFICATION
VII. LIST OF SUBASSEMBLIES INSTALLED IN THE UNIT
Please read this instruction manual carefully before beginning any work.
RYKI 2013
ISSUE 1 EN

2www.juwent.com.pl
I. CONTACTS
Szymański, Nowakowski General Partnership
31 Lubelska Str., 08-500 Ryki
phone [phone], fax [phone]
POLAND
Export department
mob.[phone]
mob.[phone]
[email protected]

3www.juwent.com.pl
II. ORIGINAL INSTRUCTION MANUAL
TROPIC HEATING UNITS
Size 1, 2

4www.juwent.com.pl
TABLE OF CONTENTS
1. INTENDED USE 5
2. DESIGNATIONS 5
3. DEVICE DESCRIPTION 5
4. TECHNICAL DATA 6
5. TRANSPORT 6
6. SAFETY RECOMMENDATIONS 7
7. MOUNTING 8
8. WATER INSTALLATION 9
9. ELECTRICAL INSTALLATION 10
10. AUTOMATICS 11
11. DEVICE STARTUP 14
12. REPAIR, MAINTENANCE AND WITHDRAWAL FROM SERVICE 15
13. TROUBLESHOOTING 16
14. INFORMATION 16

5www.juwent.com.pl
1. INTENDED USE
TROPIC heating units, size 1 and 2, are intended to heat such compartment as:
»shopping centres;
»fashion houses;
»churches;
»sports and entertainment facilities;
»car showrooms.
As well as in places where traditional heating units are used, i.e. in warehouses, factory halls,
workshops, greenhouses, etc.
The units cannot be used in the compartments with relative humidity larger than 90%
and air dust concentration over 3mg/m3.
The compartment can be served by one or larger number of the units, also by the units of different
sizes.
2. DESIGNATIONS
Heating unit TROPIC- 1 -II
Size 1; 2
Number of heater rows I; II
3. DEVICE DESCRIPTION
The units are adapted to operate in the horizontal position as ceiling units and in the vertical position
as wall units.
The heaters of the units are designed in such a way that they are completely vented both operating
in the horizontal and vertical position.
The unit includes:
»axial fan mounted on the rear wall of the unit with a net protecting the rotor.
»(I or II row) n water heater in the frame made of galvanized steel sheet.
»casing made of high quality plastic with a single-row outlet grid allowing adjusting a direction
of supplied air. The structure of grid blades protects against an automatic rearrangement of the
blades.
The n heater is made of copper pipes with external diameter D=12mm and aluminium ns with
spacing s=2,4mm.
The connection spouts of the units have external threads.
For the n water heaters the maximum temperature of heating medium is up to 150OC
and the maximum operational pressure is up to 1,5Mpa.
There is a risk of heating medium freeze in the heater in the compartments with
the temperature below 0OC.
The risk can be reduced using an antifreeze thermostat (delivered at request), using antifreeze
heating media or removing water from the unit.

6www.juwent.com.pl
4. TECHNICAL DATA
Unit size TROPIC-1 TROPIC-1
Dimensions
A[mm] 560 690
B[mm] 520 670
L[mm] 380 480
d1/2” 3/4”
Weight (I-row
exchanger) [kg] 15 32
Weight (II-row
exchanger) [kg] 17 33,5
Parameters of fans in units
Voltage [V] 230 230
Motor power [kW] 0,13 0,61
Current [A] 0,59 2,8
Revolutions [rpm] 1400 1310
Protection rating IP54 IP54
Insulation class F F
Operational
temperature do +70OCdo +60OC
Operational noise level
Noise level [dB(A)] 54* 60**
*operational noise level of the unit of the size 1 – acoustic pressure level taking dispersion factor of
compartment A=50m2 and directivity factor Q=2 at the distance of 5m into consideration.
**operational noise level of the unit of the size 2 – acoustic pressure level taking dispersion factor of
compartment A=100m2 and directivity factor Q=2 at the distance of 5m into consideration.
5. TRANSPORT
The delivered TROPIC units are completely assembled in the cardboard packets protecting them
against pollution and weather impacts.
The Product Manual is delivered along with the unit.
The automatics elements are delivered separately at the customer’s request.
The units should be transported maximally in two layers using separators preventing
mechanical damages.

7www.juwent.com.pl
6. SAFETY RECOMMENDATIONS
The heating and ventilation units should be used only in compliance with the instruction
manual.
The start-up, mounting, connection, inspections and repairs of the unit should be
executed by an authorized installer, the electric works should be executed by a person
having required certicates authorized to carry out electric works.
All service and repair works should be executed when voltage is off.
In case of the unit failure it is necessary to switch off the power supply to the electric
motor of the fan and close the heating medium supply to the heater immediately.
The unit can be used only when electric safety devices operate correctly.
It must be permanently connected to the electric installation equipped with protective
(earth) terminal, residual current device and service switch.
Only original spare parts should be used.
The operation of the unit with the fan without a protective net is forbidden.
Note for the user!
The mounting or use of the heating and ventilation unit against the instruction manual makes
the threat of unit damage, creates the hazard to persons and property and causes the loss of
warranty.
Due to the structure the unit does not emit harmful radiation.
Although the unit was designed and manufactured in compliance with the requirements of the
standards, according to their state at the moment of production launch, a probability of injury or
health loss when using the unit is not to be avoided. This probability is connected with a frequency of
access to the unit in the course of its use, cleaning or repair, presence of persons within a dangerous
zone, acting against the safety rules specied in the instruction manual.
The gravity of body injury or deterioration of health condition depends on many factors that often
can be foreseen only partially, taking them into consideration in the structure of the unit, specifying
them and warning against them in the instruction manual.
Therefore there is a residual risk when the operator does not observe the recommendations and
guidelines included in the instruction manual.

8www.juwent.com.pl
7. MOUNTING
Suspension of the unit
The units can be hung on the wall or suspended to the ceiling.
A mounting console is used to install the unit on the wall.
The length of the bolts fastening the unit to the console – max. 20mm.
TROPIC-1
Side view Top view
TROPIC-2
Side view Top view
The units can be suspended to the ceiling using 4 bars with M8 thread with spacing according to
the following picture.
TROPIC-1 TROPIC-2

9www.juwent.com.pl
A minimal distance of the unit to the wall or ceiling necessary to ensure a free air supply
to the fan is: 18cm for TROPIC-1 units, 25cm for TROPIC-2 units
When it is necessary to hang the unit on a partition, e.g. made of steel sheets, stiffening
proles should be used to avoid vibrations of the partition generated by the unit
operation and the noise level increase in the compartment.
A minimal distance of the heating unit to the construction partition from the unit sides
is about 20cm.
8. WATER INSTALLATION
It is recommended:
»- to connect the unit to the heating network by means of the lower spout of the heater and
the return of the heating medium by means of the top spout;
»- to use cut-off valves upstream and downstream the unit to enable its dismounting without
the necessity to drain the supply installation.
The solenoid valves should be connected in the heating medium supply line from the unit.
The venting and draining of the heaters of the units is foreseen centrally in the network.
The vents and drain valves located in the installation outside the unit should be used.
The heaters of the units in the ceiling option mounting cannot be drained centrally.
The imprecise venting of the heater can be a reason for which the unit does not reach
planned parameters.
The weight of installation pipes should not rest on the spouts of the heater.
When connecting the heater to the heating network the spouts of the heater should be protected
against breaking in a way presented in the picture.
The heater damages arisen for the afore-mentioned reason are not covered by the
warranty.

10 www.juwent.com.pl
9. ELECTRICAL INSTALLATION
The electric installation and the connection of power to the unit must be executed according to the
relevant requirements of the standards and construction regulations..
The electric connections of the unit may be executed only by an authorized electrician
who got acquainted with the instruction manual.
Before the connection it is necessary to make sure whether the voltage value and power system
frequency are compliant with the data specied on the rating plates of the units. In case of
noncompliance the unit should not be connected.
The units are equipped with single (1~230 V/50 Hz) fans with internal thermal contacts TK (brought
to the terminal box or stuck in the motor circuit permanently). The electric connection of the fan
should be executed taking a service switch (WS) and overload and short-circuit protection devices in
the supply and control box into consideration.
The lack of required motor safety devices and non-connection of thermal contact TK to
the control circuit cause the loss of warranty
The lead powering the fan should be inserted to the terminal box and fastened to the protective net
or fan supports by means of clamp bands. The thermal contact of the fan should be connected to
the circuit that controls the power supply of the fan.
The electric connection of the motor must be compliant with the electric diagrams located on the
terminal box. The exemplary connection and control diagram of the units are presented in the
picture 1.
MOTOR LEAD DESIGNA-
TION:
U1 - brown
U2 - blue
Z1 - black
Z2 - orange
Tk - white
DIAGRAM DESIGNATIONS:
PT – Overcurrent protection of the motor
K – Contactor
PZ – Switch-on control button
PW – Switch-off control button
B1,B2 – Fuses
PE – Protective terminal
Tk – Thermal protection
Fig. 1. TROPIC unit connection and control diagram

11www.juwent.com.pl
10. AUTOMATICS
We can deliver the following items to the units:
- Supply and control box: Surface-mounted in the closed casing (equipped with a main switch,
overcurrent circuit breakers, short-circuit protection devices, signalling lamps), intended to
cooperate and control the elements of automatics.
One control box allows controlling a group of the units by means of single thermostat in the
AUTOMAT|MANUAL operation mode.
The supply and control box (1~230V/50Hz) should be from the main switchboard equipped with a
main switch and differential protection device.
When the automatics are ordered with the unit the electric diagrams of the unit and automatics are
delivered by the company as well.
The exemplary connection diagrams of the units with single-phase motors are presented in the
pictures 2, 3, 4 and 5.
- Rotational speed controllers of the fan: The transformer 5-step rotational speed controllers ARW
(1~230V/50Hz) allow controlling the air delivery and thermal power. The individual rotational speed
steps are selected manually.
Controller type ARW-1,2 ARW-3
PE-L1-N Input voltage (230V AC)
PE,U1,U2 Output (control) voltage
Voltage [V] 230 230
Protection rating 21 21
Height [mm] 123 173
Width [mm] 77 90
Depth [mm] 71 89
- Room thermostat: A room thermostat (on-off) TP allows setting the required temperature in the
room within the range of 8...30OC by means of a knob, however, the room thermostat (on-off) TPP
allows setting the required temperature in the room within the range of 8...35OC in the day and night
mode on the liquid-crystal display.
Termostat TP or TP/IP65
Supply voltage 24..250V AC 24..250V AC
L-Y1 Heating
L-Y2 Cooling
Measurement
range 8...+30OC8...+35OC
Contact rating 6(2)A 10(1,5)A
Protection
rating IP30 IP65
Thermostat with time programmer TPP
Supply voltage 2 batteries 1,5V
Q11-Q14 Heating
Q11-Q12 Cooling
Measurement range 5...+35OC
Contact rating 5(2)A
Protection rating IP30

12 www.juwent.com.pl
- Three-way valves V: The directional valves found a wide application in the curtains for the
adjustment of heating medium ow through the heaters. The three-way directional valves with the
connection with internal threads V20 (on/off) are used. The valves should be installed in the supply
line, the ow is admissible only in the marked direction AB->A or AB->B.
Symbol DN kVS, m3/h t[oC] PN Unit type
V20 20 3,5 1...110 16 Tropic-1
Tropic-2
FITTINGS:
Z: cut-off valve: manual
P: circulating pump
MV: three-way control valve con-
trolled by servomotor
- Valve MV servomotors: The servomotors that allow controlling the valves “continuous-0÷10V
DC” (by means of controller RT) or “on-off” (by means of thermostat TP or TPP) are used for a direct
installation on the valves. Therefore a position (protrusion) of the servomotor stem is proportional
to the value of control signal from the controller or thermostat.
Servomotor type on/off continuous signal
Supply voltage 230V AC 24V AC
Closing / opening
time 180 s 150 s
Protection rating IP40 IP43
Servomotor [on-off] MV+V20
L-N Supply voltage 230V AC
Servomotor MV - continuous signal
Y Input control signal 0…10V DV
G0 System zero
G Phase, 24V AC
- Service switch WS: It is intended to switch off the fan motor in order to carry out service works.
The use of the switch WS prevents an unexpected activation of the motor that could cause the risk
during the service works.
Type WS-3
Poles 3-pole
Supply circuit switch 3-phase
Rated continuous current 25A
Protection rating IP 65

13www.juwent.com.pl
Exemplary connection and control electric diagrams of the TROPIC units
Fig. 2. Electric connection diagram without automatics
Fig. 3. Electric connection diagram with revolution controller
Fig. 4. Electric connection diagram with automatics (revolution controller, valve servomotor and fan operation
are controlled by thermostat)

14 www.juwent.com.pl
Fig. 5. Connection diagram of unit automatics without controller ARW
Fig. 6. Connection diagram of unit automatics with controller ARW
11. DEVICE STARTUP
Prior to the startup it is necessary to:
»check up the fastening state of the unit;
»check up the leak tightness of water or steam connections;
»check up the supply voltage according to the electric plate;
»check up the additional protection of the fan and unit casing;
»check up the correctness of the electric connection of the motor.
To switch on the unit it is necessary to:
»open the valves of heating medium;
»switch on the current supply to the electric motor;
»adjust the supply air stream direction and range by means of the outlet grid blades.
To switch off the unit it is necessary to:
»limit the heating medium ow to the heater of the unit;
»switch off the current supply to the electric motor of the fan.
In case of long standstills of the unit or breaks of heating network operation the heater
should be drained and the cut-off valves should be closed, if need be.

15www.juwent.com.pl
12. REPAIR, MAINTENANCE AND WITHDRAWAL FROM SERVICE
The applied rolling bearings of the fan do not require a periodical lubrication. However, it is
recommended to check periodically a condition of the motor bearings (the rotor of the fan should
rotate freely without excessive backlashes and knocks).
When the noise level of the unit operation is increased it is necessary to check up the correctness of
fastenings of the fan and the whole unit.
The rotor blades should be cleaned with a damp cloth after removing the protective net not to allow
unbalancing the rotor.
Do not use high pressure washers to clean the fan.
In case of any disturbances in the unit operation it is necessary to contact with the installer or the
service.
All repair and maintenance works should be executed when voltage is off. The unit
should be protected against an accidental activation by other persons as well.
The heater dust contamination state should be checked up periodically. In case of excessive dust
accumulation the heater should be blown through with compressed air.
The excessive heater contamination reduces the heating power and air efciency of the
unit.
After withdrawal from service the unit should be passed over to the specialized collection point of
recyclable materials.

16 www.juwent.com.pl
13. TROUBLESHOOTING
Trouble
description Possible trouble cause Troubleshooting
heat exchanger le-
akage
mechanical damage of heat exchanger (it may easy
appear when the unit is connected to the installation
without taking care
use a locking spanner to mount with the installation de-
nitely
exceedance of admissible heating medium para-
meters
connect the unit with the heating installation protected
against the excessive pressure and temperature growth
heat exchanger freeze
use an antifreeze thermostat, antifreeze heating uids or
remove water from the unit within the period of standstill
and freeze risk
use of the unit in the aggressive environment
too load operation
of the unit
minimum distance from the wall or ceiling is not
maintained use distances recommended in the instruction manual
improper revolution direction execute a proper electric connection
improper parameters of the mains use the unit only when the parameters of the mains and
the unit are compliant
air outlet is blocked by outlet grid louvres avoid a signicant closing of outlet grid louvres at high
speed ratios
fan vibrations, the blades rub against xed elements check up the correctness of the fan and fastening reliabi-
lity of other elements of the unit
not centric fastening of the fan in its bearing plate
fan does not work
incorrect or unreliable electric connections check up or correct:
1) compliance of electric connections according to the
diagrams specied in the instruction manual
2) reliability of connections on electric terminals
3) parameters of the mains
improper parameters of the mains (lack of three
phases in three-phase motors)
fan motor is damaged
fan operation control elements are damaged
Revolution con-
troller
ARW/RTRD does
not work
correctness of electric connections (whether the le-
ads are just clamped in the electric terminals)
check up or correct:
1) compliance of electric connections according to the
diagrams specied in the instruction manual
2) reliability of connections on electric terminals
3) parameters of the mains
only 1 controller can be connected to 1 unit
Servomotor does
not open the valve
correctness of thermostat operation (characteristic
“tick” when switching)
check up or correct:
1) compliance of electric connections according to the
diagrams specied in the instruction manual
2) reliability of connections on electric terminals
3) parameters of the mains
4) whether the servomotor reacts to an electric pulse. If
the servomotor damage is stated, the damaged element
should be claimed.
Room thermostat
does not apply the
signal
more than one unit is connected directly to the
thermostat (larger number means the thermostat
overload)
check up or correct:
1) compliance of electric connections according to the
diagrams specied in the instruction manual
2) reliability of connections on electric terminals
3) parameters of the mains
4) if there is no characteristic “tick”, the thermostat is me-
chanically damaged and should be claimed.
mounting place of the thermostat in the room
14. INFORMATION
As to all issues concerning the TROPIC heating units please contact JUWENT Production Plant or
Representatives

17www.juwent.com.pl
III. WARRANTY TERMS AND CONDITIONS
1. JUWENT Szymański, Nowakowski General Partnership, headquartered in Ryki at 31 Lubelska Str., hereinafter referred to as the
Warrantor, grants the Customer a warranty of proper operation of the unit with reservation of the requirement of its use in accordance
with the conditions determined in the instruction manual and the terms and conditions specied below.
2. The warranty has been granted for a period of 24 months from the purchase date demonstrated in this warranty document with
a possibility of its special extension according to a separate agreement and specied in the Special Warranty Terms and Conditions.
3. The warranty covers the removal of technical defects of the unit arisen as a result of its use in accordance with the instruction
manual, revealed within the warranty period. The warranty provisions are valid in the territory of the Republic of Poland.
4. By virtue of the granted warranty the Warrantor is not liable for the loss of expected prots and costs resulting from a periodical
impossibility of the use of the unit incurred by the Customer.
5. To realize the Customer’s rights resulting from the warranty it is required to deliver the claimed unit with the warranty document
to the Warrantor at his expense.
6. The claimer delivers the unit in an original factory packing, in case there is no factory packing the claimed unit should be delive-
red by the Customer for the repair in a way ensuring a safe transport. The risk of accidental damage of the unit during the transport
burdens always the party that dispatches the parcel.
7. The defects revealed with the warranty period will be removed by the Warrantor free of charge. A method selection of the reali-
zation of obligations resulting from the warranty granted to the Customer belongs to the Warrantor that may remove a defect by the
repair or the replacement of the damaged subassembly or by the replacement of the unit. The property of the unit withdrawn from
service and / or defective subassemblies is transferred to the Warrantor.
8. The warranty is extended by a period for which the Customer has been deprived of a possibility to use the unit.
9. The Warrantor will make efforts that the repair is executed without further delay within the time-limit of up to 14 working days
from the delivery date of the unit. In reasonable cases of which the Customer will be informed by the Warrantor, this time-limit may
be extended, e.g. by the time of provision import or when there is a necessity to execute an expertise or laboratory tests in specialized
institutions.
10. The Warrantor is liable exclusively for the defects inherent in the sold unit. The damages arisen after its sale for other reasons are
not covered by the warranty, in particular:
a) mechanical damages (including also damages caused by microparticles occurring in the working environment of the unit),
thermal damages, chemical damages and aleatory damages or damages caused by the atmospheric factors,
b) damages occurred as a result of non-observance of typical rules or the rules required by the instruction manual related to the
operation and mounting of the unit or the use of the unit against the intended use and other damages caused by the Customer’s
activity or omission,
c) damages being a result of defective operation of the system in which the unit has been built or used,
d) damages occurred as a result of non-execution of the actions to which the Customer has been obliged in accordance with the
instruction manual, e.g. periodical cleaning, maintenance, adjustment, etc.,
e) damages occurred due to the use of materials or parts subject to a normal operational wear other than the materials recom-
mended by the Warrantor in the instruction manual,
f) damages being a result of use of power supply of the unit (of the system in which this unit functions) incompliant with the
standard, and in case the unit is also supplied with water, damages being a result of use of water (supply water and / or boiler
water) with parameters other than the parameters foreseen in the valid standard (PN-93/C-04607),
g) damages occurred as a result of operation and / or maintenance of the unit in a way incompliant with the instruction manual
and / or executed by the unauthorized persons.
11. The warranty does not cover as well:
a) activities executed by the Customer in accordance with the recommendations included the instruction manual of the unit within
the framework of normal maintenance and inspections,
b) travel and work costs of the Warrantor’s service or an entity delegated by the Warrantor in case when a warrant call turns out
to be groundless.
12. An annotation made by a trained employee in the Inspection and Maintenance Document of the unit is a conrmation of time-
-limit holding and range of activities foreseen for the maintenance of the unit.
13. The Warrantor is not liable for damages incurred by the Customer or third parties caused the run of the unit occurred in particular
as a result of non-observance of the afore-mentioned terms and conditions by the Customer.
14. In case the service works are executed by the Warrantor at the place where the unit is mounted, the Customer will make available
a free access to the rooms where the units are located to the Warrantor.
15. In case the units are mounted at the height making an access from the oor surface impossible, the Customer will ensure the
scaffolding compliant with the OHS regulations or mobile lifting platforms and vertical transport equipment.
16. The equipment from the electric and / or hydraulic system is disassembled by the Customer.
17. The claims should be lodged at the Warrantor’s address in writing / by fax / email using a service notication form.
18. The Warrantor refuses to execute the warranty activities (periodical service works or repair) in case the price for the unit or pre-
vious service work is not paid for the benet of the Warrantor.
DATE OF SALE STAMP AND SIGNATURE
Special Warranty Terms and Conditions:
Warranty period extension up to ........... months.
Other:
STAMP AND SIGNATURE

18 www.juwent.com.pl
TYPE OF UNIT:
FACTORY NUMER:
YEAR OF PRODUCTION:
IV. UNIT STARTUP REPORT
Date of
startup
Executor of startup
stamp / name and signature
Motor
current
[A]
User’s representative
stamp / name and signature Remarks
V. INSPECTION AND MAINTENANCE DOCUMENT
Date of
inspection
Executor of inspection
stamp / name and signature Service activity range Remarks
* Inspection of the unit in accordance with the section “Repair and Maintenance” in the instruction manual

19www.juwent.com.pl
VI. SERVICE NOTIFICATION
Date:
Notication type WARRANTY POST-WARRANTY PAID
Unit’s user (name)
Contact person
User’s address
Phone, fax. and email
Type of unit
Factory No.
Year of production
Startup executed by
Description of defect:
NOTE: AFTER COPYING AND FILLING IN SEND THE NOTIFICATION BY FAX OR EMAIL TOGETHER WITH A
COPY OF THE STARTUP REPORT.
JUWENT Company accepts notications lled legibly and completely.
When the lodged claim is not justied, the claimer will be burdened with service costs.
Date of warranty issue Order No. (company’s stamp)
......................................................... ...........................

VII. LIST OF SUBASSEMBLIES INSTALLED IN THE UNIT
No. Name of subassembly *)
1Axial fan with single-phase motor
2 Metal louvre I-row heat exchanger
3Metal louvre II-row heat exchanger
*) - mark proper box corresponding with the equipment variant
