drvn AX5100 Series Amplifiers
KS-AX5104
Bridgeable 4-Channel Power Amplifier
KS-AX5102
Bridgeable 2-Channel Power Amplifier
KS-AX5101D
Digital Mono Power Amplifier
Powerful drvn XX Series amplifiers reproduce dynamic sound, thanks to parallel MOS-FET power supply and high-capacity
output stage. One-side wiring design allows easy installation and control, with all terminals placed on a single side,
and a cover for a neat look. It is also easy to upgrade your system with additional components.
Key Benefits
Class-D
(KS-AX5101D)
Class-AB
(KS-AX5102/AX5104)
1000W Max.
(KS-AX5101D/AX5104)
600W Max.
(KS-AX5102)
Parallel Drive
MOS-FET
✹Dynamic Audio Delivery
Parallel drive MOS-FET power supply supports
high power and high sound pressure level.
✹For Easy Upgrade
One-Side
Wiring Pre-Output Variable Bass Boost
Max. 120A
+
-
Output
Stage
Power
Amplifier
MOS-FET
Power Supply
MOS-FET
Power Supply
• Variable Bass Boost Control (KS-AX5101D)
You can control your subwoofer’s bass boost level
(45Hz/0dB – -18dB) for a customized sound.
• Pre-Output
Pre-output terminals are available for easy upgrade
of your system.
KS-AX5104
KS-AX5101D
Easy Upgrade!
Easy Upgrade!

drvn AX5100 Series Amplifiers
NTK-0884-21
Key Specifications
KS-AX5101D KS-AX5102 KS-AX5104
Topic Features
Operation Channel 1 2 or 1 4, 3, or 2
Max. Power Output 1000W 600W 1000W
RMS Power Output @ 4ΩBridged - 300W RMS x 1 200W RMS x 2
CEA-2006 compliant @ 4Ω300W RMS x 1 100W RMS x 2 70W RMS x 4
@ 2Ω 500W RMS x 1 150W RMS x 2 100W RMS x 4
Circuit Class Class-D Class-AB Class-AB
Frequency Response (0, -3dB) 20 - 200Hz 5 - 50,000Hz 5 - 50,000Hz
THD (Total Harmonic Distortion) < 0.08% @ 4Ω, 100Hz < 0.04% @ 4Ω, 1kHz < 0.04% @ 4Ω, 1kHz
Line Input: Level/Impedance 2V/20kΩ2V/20kΩ2V/20kΩ
Pre-Output ✔(Through) ✔ (Through) ✔ (Through)
Crossover
HPF - 50 - 200Hz, -12dB/oct (Variable) 50 - 200Hz, -12dB/oct (Variable)
LPF 50 - 200Hz, -18dB/oct (Variable) 50 - 200Hz, -12dB/oct (Variable) 50 - 200Hz, -12dB/oct (Variable)
Subsonic Filter ✔(20Hz Fix) - -
Other Controls
Variable Bass Boost Control 45Hz, 0 - 18dB 45Hz, 0 - 18dB 45Hz, 0 - 18dB
Generals
Anti-Pop Circuit ✔✔ ✔
Side Covers ✔✔ ✔
Power On Indicator/Protector Indicator Power On (GREEN)/Protector (RED) Power On (GREEN)/Protector (RED) Power On (GREEN)/Protector (RED)
Dimensions (W x H x D) 10 1/4” x 2 3/8” x 11 13/16” 10
1/4” x 2 3/8” x 11 13/16” 12 1/14” x 2 3/8” x 11 13/16”
(260 x 60 x 300 mm) (260 x 60 x 300 mm) (310 x 60 x 300 mm)
Heatsink Dimensions (W x H x D) 7 7/8” x 2 5/16” x 11 1/16” 7 7/8” x 2 5/16” x 11 1/16” 9
7/8” x 2 5/16” x 11 1/16”
(200 x 58.5 x 280mm) (200 x 58.5 x 280 mm) (250 x 58.5 x 280 mm)
Weight 2.7kg (6.0 lbs.) 2.6kg (5.8 lbs.) 3.2kg (7.1 lbs.)
✹Easier Installation & Control with One-Side Wiring
Amplifiers are easy to install in various places, with terminals on one
side, and side covers for a neat look. One-side wiring also provides
easier control after installation.
Side Covers
One-Side Wiring
RCA InputSpeakerPower
Recommended System
KS-AX5101D
CS-GD1200
KD-R80BT
CS-ZX630 CS-ZX630
KS-AX5104
CS-ZX6940CS-ZX6940
Dimensions
KS-AX5101D
10-3/16 inch (258 mm) 11-1/16 inch (280 mm)
8-11/16 inch (220 mm)
7-7/8 inch (200 mm)
3/16 inch (4.5 mm) x
4 HOLES
10-1/4 inch (260 mm)
11-13/16 inch (300 mm)
2-3/8 inch
(60 mm)
2-5/16 inch
(58.5 mm)
KS-AX5102
2-3/8 inch
(60 mm)
2-5/16 inch
(58.5 mm)
10-3/16 inch (258 mm) 11-1/16 inch (280 mm)
8-11/16 inch (220 mm)
7-7/8 inch (200 mm)
3/16 inch (4.5 mm) x
4 HOLES
10-1/4 inch (260 mm)
11-13/16 inch (300 mm)
KS-AX5104
3/16 inch (4.5 mm) x
4 HOLES
10-3/16 inch (258 mm) 11-1/16 inch (280 mm)
10-11/16 inch (270 mm)
9-7/8 inch (250 mm)
12-1/4 inch (310 mm)
11-13/16 inch (300 mm)
2-5/16 inch
(58.5 mm)
2-3/8 inch
(60 mm)
