JVC ADV5580 User manual

ENGLISHESPAÑOLFRANÇAIS
Instructions DVD/CD RECEIVER KD-ADV5580/KD-DV5500
EN, SP, FR
1108DTSMDTJEIN
© 2008 Victor Company of Japan, Limited
DVD/CD RECEIVER
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
GET0587-001A
[J]
For canceling the display demonstration, see page 11.
Para cancelar la demostración en pantalla, consulte la página 11.
Pour annuler la démonstration des affichages, référez-vous à la page 11.
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
KD-ADV5580/KD-DV5500
KD-ADV5580/KD-DV5500
KD-ADV5580/KD-DV5500
RECEPTOR CON DVD/CD
RÉCEPTEUR DVD/CD
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet. Retain
this information for future
reference.
Model No.
Serial No.
Having TROUBLE with operation?
Please reset your unit
Refer to page of How to reset your unit
Still having trouble??
USA ONLY
Call 1-800-252-5722
http://www.jvc.com
We can help you!
CoverRear_KD-ADV5580[J]1.indd 1CoverRear_KD-ADV5580[J]1.indd 1 10/30/08 10:16:45 AM10/30/08 10:16:45 AM

2
ENGLISH
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
INFORMATION (For U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
Caution:
Changes or modifications not approved by JVC could void the user’s authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: (For U.S.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
[European Union only]
EN02-11_KD-ADV5580[J]1.indd 2EN02-11_KD-ADV5580[J]1.indd 2 10/30/08 3:20:26 PM10/30/08 3:20:26 PM

3
ENGLISH
Detaching the control panel
Attaching the control panel
How to reset your unit
• Your preset adjustments will also be erased.
How to forcibly eject a disc
• You can forcibly eject the loaded disc even if the disc is
locked. To lock/unlock the disc, see page 13.
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
WARNINGS:
(To prevent accidents and damage)
• DO NOT install any unit or wire any cable in a
location where;
– it may obstruct the steering wheel and
gearshift lever operations.
– it may obstruct the operation of safety
devices such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
• If you need to operate the unit while
driving, be sure to look around carefully.
• The driver must not watch the monitor
while driving.
If the parking brake is not engaged, “DRIVER
MUST NOT WATCH THE MONITOR WHILE
DRIVING.” appears on the monitor, and no
playback picture will be shown.
– This warning appears only when the
parking brake lead is connected to the
parking brake system built in the car
(refer to the Installation/Connection
Manual).
This mark is used to indicate...
Turn the control dial to make a
selection, then press to confirm the
selection.
EN02-11_KD-ADV5580[J]1.indd 3EN02-11_KD-ADV5580[J]1.indd 3 10/30/08 3:20:28 PM10/30/08 3:20:28 PM

4
ENGLISH
Indication language:
In this manual, English indications are used for
purposes of explanation. You can select the
indication language on the monitor on the
“LANGUAGE” setting (see page 33).
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
KD-ADV5580 is equipped with the steering wheel
remote control function.
• See the Installation/Connection Manual (separate
volume) for connection.
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product
may not be recommended.
Caution on volume setting
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc to
avoid damaging the speakers by the sudden increase of
the output level.
EN02-11_KD-ADV5580[J]1.indd 4EN02-11_KD-ADV5580[J]1.indd 4 10/30/08 3:20:29 PM10/30/08 3:20:29 PM

5
ENGLISH
CONTENTS
Detaching the control panel...................................................................................................... 3
Attaching the control panel ...................................................................................................... 3
How to reset your unit .............................................................................................................. 3
How to forcibly eject a disc........................................................................................................ 3
INTRODUCTIONS
Playable disc type ..................................................................................................................... 6
OPERATIONS
Basic operations........................................................................................................................ 7
• Using the control panel.................................................................................................................... 7
• Using the remote controller (RM-RK255)......................................................................................... 8
Preparation............................................................................................................................... 11
Listening to the radio................................................................................................................ 11
Disc operations.......................................................................................................................... 13
• Operations using the control panel.................................................................................................. 14
• Operations using the remote controller (RM-RK255)....................................................................... 16
EXTERNAL DEVICES
Listening to the CD changer...................................................................................................... 22
Listening to the satellite radio .................................................................................................. 23
Listening to the iPod................................................................................................................. 25
Listening to the other external components............................................................................. 26
SETTINGS
Selecting a preset sound mode ................................................................................................. 27
Menu operations....................................................................................................................... 29
Title assignment ....................................................................................................................... 32
Disc setup menu........................................................................................................................ 33
REFERENCES
More about this unit ................................................................................................................. 35
Maintenance............................................................................................................................. 39
Troubleshooting........................................................................................................................ 40
Specifications............................................................................................................................ 44
EN02-11_KD-ADV5580[J]1.indd 5EN02-11_KD-ADV5580[J]1.indd 5 10/30/08 3:20:29 PM10/30/08 3:20:29 PM

6INTRODUCTIONS
ENGLISH
Playable disc type
Disc type Recording format, file type, etc Playable
DVD DVD-Video (Region Code: 1)*1
DVD-Audio/DVD-ROM
DVD Recordable/Rewritable
(DVD-R/-RW*2, +R/+RW*3)
• DVD Video: UDF bridge
• DVD-VR
• MPEG-1/MPEG-2/MP3/WMA/
WAV: ISO 9660 level 1, level 2,
Romeo, Joliet
DVD-Video
DVD-VR
MPEG1/MPEG2
MP3/WMA/WAV
AAC/JPEG/MPEG4/DivX/DVD+VR/DVD-RAM
Dual Disc DVD side
Non-DVD side
CD/VCD Audio CD/CD Text (CD-DA)
VCD (Video CD)
DTS-CD/SVCD (Super Video CD)/CD-ROM/
CD-I (CD-I Ready)
CD Recordable/Rewritable
(CD-R/-RW)
• ISO 9660 level 1, level 2, Romeo,
Joliet
CD-DA
VCD (Video CD)
MPEG1/MPEG2
MP3/WMA/WAV
AAC/JPEG/MPEG4/DivX
*1If you insert a DVD Video disc of an incorrect Region Code, “REGION CODE ERROR” appears on the monitor.
*2DVD-R recorded in multi-border format is also playable (except for dual layer discs). DVD-RW dual layer discs are not
playable.
*3It is possible to play back finalized +R/+RW (Video format only) discs. +RW double layer discs are not playable.
EN02-11_KD-ADV5580[J]1.indd 6EN02-11_KD-ADV5580[J]1.indd 6 10/30/08 3:20:29 PM10/30/08 3:20:29 PM

7OPERATIONS
ENGLISH
Basic operations
Using the control panel
q• Change the display information (if the power is
turned on).
• Check the current clock time (if the power is
turned off).*5
w• FM/AM/SIRIUS/XM: Search for station/channel.
• DISC: Select chapter/track.
• CD-CH/IPOD: Select track.
eReturn to the previous menu.
rRemote sensor
tAUX (auxiliary) input jack
*1Also known as “Control dial” in this manual.
*2You cannot select these sources if they were disabled
in the Menu (see “SRC SELECT” in “Menu
operations” on page 31).
*3You cannot select these sources if they are not ready
or not connected.
*4You can still adjust the volume during pause when
the selected source is DISC.
Before resume playback, check to be sure that you
have not raise the volume level too much.
*5The current clock time is displayed if “CLOCK
DISP” is set to “CLOCK OFF” (see page 29).
1• FM/AM: Select preset station.
• SIRIUS/XM: Select category.
• DISC: Select title/program/playlist/folder.
• CD-CH: Select folder.
• IPOD: Enter the main menu/Pause playback/
Confirm selection.
2• Turn on the power.
• Attenuate the sound (if the power is on).
• Turn off the power [Hold].
3Select the source.
FM =AM*2=SIRIUS*3/XM*3=DISC*3=
CD-CH*3/IPOD*3(or EXT INPUT) =AUX IN*2
=(back to the beginning)
4• Enter list operations.
• Enter Menu setting [Hold].
5• Control the volume*4or select items [Turn].
• Confirm the selection [Press].
• FM: Enter SSM preset mode [Hold].
• DISC: Pause/resume playback*4[Press].
• DISC/CD-CH/IPOD: Enter playback mode [Hold].
6Loading slot
7Display window
8Eject disc.
9Select the sound mode.
pDetach the panel.
Continued on the next page
EN02-11_KD-ADV5580[J]f.indd 7EN02-11_KD-ADV5580[J]f.indd 7 12/2/08 10:35:14 AM12/2/08 10:35:14 AM

8
ENGLISH
Installing the batteries
Insert the batteries into the remote controller by
matching the polarity (+ and –) correctly.
Display window
1Tr (track) indicator
2Source display / Track number / Folder number /
Disc number / Title number / PBC indicator / Time
countdown indicator
3Playback source indicators—CH (CD changer), DISC
4Sound mode indicators —CLASSIC, HIP HOP, JAZZ,
ROCK, POPS, USER
5Playback mode / item indicators— RND (random),
(disc), (folder), RPT (repeat)
6EQ (equalizer) indicator
7LOUD (loudness) indicator
8Disc information indicators—
TAG (Tag information), (track/file), (folder)
9Main display (Time, menu, playback information)
pTuner reception indicators—ST (stereo),
MO (monaural)
Using the remote controller (RM-RK255)
R03/LR03/AAA
Caution:
• Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
If the effectiveness of the remote controller
decreases, replace the batteries.
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
EN02-11_KD-ADV5580[J]1.indd 8EN02-11_KD-ADV5580[J]1.indd 8 10/30/08 3:20:30 PM10/30/08 3:20:30 PM

9OPERATIONS
ENGLISH
• IPOD:
– 5: Enters the main menu (then 5/∞/
4/¢work as menu
selecting buttons.)
5: Returns to the previous menu.
∞: Confirms the selection.
– ∞: Pauses or resumes playback.
4/ ¢buttons
• FM/AM:
– Searches for stations automatically if pressed
briefly.
– Searches for stations manually if pressed and
held.
• SIRIUS/XM:
– Changes the channels if pressed briefly.
– Changes the channels rapidly if pressed and
held.
• DISC/CD-CH:
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed and
held.
• IPOD:
– Reverse skip/forward skip if pressed briefly.
– Reverse search/forward search if pressed and
held.
In menu selecting mode:
– Selects an item if pressed briefly. (Then, press
∞to confirm the selection.)
– Skips 10 items at a time if pressed and held.
3VOL (volume) + / – buttons
• Adjusts the volume level.
2nd VOL (volume) buttons
• Not applicable for this unit.
4* ASPECT button
• Not applicable for this unit.
5PHONE button
• Not applicable for this unit.
6* SETUP button
• Enters disc setup menu (during stop).
1button
• Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
25/∞buttons
• FM/AM: Selects the preset stations.
• SIRIUS/XM: Selects the categories.
• DISC:
– DVD-Video: Selects the title.
– DVD-VR: Selects the program/playlist.
– MPEG Video/MP3/WMA/WAV: Selects the
folders if included.
Continued on the next page
EN02-11_KD-ADV5580[J]1.indd 9EN02-11_KD-ADV5580[J]1.indd 9 10/30/08 3:20:31 PM10/30/08 3:20:31 PM

10
ENGLISH
u* %/fibuttons
• DVD-Video: Makes selection/settings.
• CD-CH: Changes discs in the magazine.
@/#buttons
• DVD-Video: Makes selection/settings.
• MPEG Video: Skips back or forward by about five
minutes.
ENT (enter) button
• Confirms selection.
i* DUAL button
• Not applicable for this unit.
oDIRECT button
• DISC: Enters direct search mode for chapter/
title/program/playlist/folder/track when pressed
with SHIFT button (see page 17 for details).
CLR (clear) button
• DISC: Erases the misentry when pressed with
SHIFT button.
* Functions as number buttons/* (asterisk)/# (hatch)
when pressed with SHIFT button.
– DISC: Enters chapter/title/program/playlist/folder/
track number after entering search mode by pressing
SHIFT and DIRECT (see page 17 for details).
7* TOP MENU button
• DVD-Video: Shows the disc menu.
• DVD-VR: Shows the Original Program screen.
• VCD: Resumes PBC playback.
8* OSD (on-screen display) button
• Shows the on-screen bar.
9SHIFT button
• Functions with other buttons.
pDISP (display) button
• Changes the display information (if the power is
turned on).
• Checks the current clock time (if the power is
turned off).
q1/¡buttons
• DVD-Video: Slow motion playback (during
pause).
• DVD-VR/VCD: Forward slow motion playback
(during pause).
• MPEG Video/MP3/WMA/WAV: Reverse search/
forward search.
wSOURCE button
• Selects the source.
e3(play) / 8(pause) button
• DISC: Starts/pauses playback.
r(end call) button
• Not applicable for this unit.
7(stop) buttons
• DISC: Stops playback.
t* RETURN button
• VCD: Returns to the PBC menu.
y* DVD MENU button
• DVD-Video: Shows the disc menu.
• DVD-VR: Shows the Playlist screen.
• VCD: Resumes PBC playback.
EN02-11_KD-ADV5580[J]1.indd 10EN02-11_KD-ADV5580[J]1.indd 10 10/30/08 3:20:31 PM10/30/08 3:20:31 PM
