SERVICE MANUAL
COPYRIGHT © 2010 Victor Company of Japan, Limited No.MA468<Rev.001>
2010/2
CD RECEIVER
MA468<Rev.001>20102SERVICE MANUAL
KD-AHD69J, KD-HDR60J
COPYRIGHT © 2010 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22

1-2 (No.MA468<Rev.001>)
SPECIFICATION
Designs & specifications are subject to change without notice.
AUDIO AMPLIFIER SECTION
Power Output 20 W RMS ×4 Channels at 4 Ωand < 1% THD+N
Signal-to-Noise Ratio 80 dBA (reference: 1 W into 4 Ω)
Load Impedance 4 Ω(4 Ωto 8 Ωallowance)
Equalizer Control Range Frequencies 45 Hz, 120 Hz, 315 Hz, 800 Hz, 2.4 kHz, 6.3 kHz, 15 kHz
Level ±10 dB
Frequency Response 40 Hz to 20 000 Hz
Line-Out Level/Impedance KD-AHD69 5.0 V/20kΩload (full scale)
KD-HDR60 2.5 V/20 kΩload (full scale)
Subwoofer-Out Level/Im-
pedance
KD-AHD69 5.0 V/20 kΩload (full scale)
KD-HDR60 2.5 V/20 kΩload (full scale)
Output Impedance 1 kΩ
Other Terminal USB input terminal, AUX (auxiliary) input jack, Expansion port, Steering
wheel remote input (only for KD-AHD69), Antenna input
TUNER SECTION (HD Radio System Compatible)
Frequency Range FM with channel interval set to 100 kHz or 200
kHz
87.5 MHz to 107.9 MHz
with channel interval set to 50 kHz 87.5 MHz to 108.0 MHz
AM with channel interval set to 10 kHz 530 kHz to 1 710 kHz
with channel interval set to 9 kHz 531 kHz to 1 602 kHz
FM Tuner Usable Sensitivity 8.3 dBf (0.7 µV/75 Ω)
50 dB Quieting Sensitivity 14.3 dBf (1.4 µV/75 Ω)
Alternate Channel Selectiv-
ity (400 kHz)
65 dB
Frequency Response 20 Hz to 20 000 Hz (HD Radio broadcast)
40 Hz to 15 000 Hz (Conventional broadcast)
Stereo Separation 70 dB (HD Radio broadcast)
50 dB (Conventional broadcast)
Capture Ratio 3.5 dB
AM Tuner Sensitivity 13 µV
Selectivity 80 dB
Frequency Response 40 Hz to 15 000 Hz (HD Radio broadcast)
Stereo Separation 70 dB (HD Radio broadcast)
CD PLAYER SECTION
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format: (MPEG1/2 Audio Layer 3) Max. Bit Rate: 320 kbps
WMA (Windows Media® Audio) Decoding Format Max. Bit Rate: 192 kbps
USB SECTION
USB Standards USB 2.0 Full Speed
Data Transfer Rate Full Speed: Maximum 12 Mbps
Low Speed: Maximum 1.5 Mbps
Compatible Device Mass storage class
Compatible File System FAT 32/16/12
Max. Current DC 5 V 500 mA
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C (32°F to 104°F)
Dimensions (W ×H ×D):
(approx.)
Installation Size 182 mm ×52 mm ×160 mm (7-3/16”×2-1/16”×6-5/16”)
Panel Size 188 mm ×58 mm ×5 mm (7-7/16”×2-5/16”×1/4”)
Mass 1.3 kg (2.9 lbs) (excluding accessories)

(No.MA468<Rev.001>)1-3
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

1-4 (No.MA468<Rev.001>)
1.5 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.6 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1M
Conductive material
(conductive sheet) or iron palate
(caption)
Anti-static wrist strap

(No.MA468<Rev.001>)1-5
1.7 Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the pickup unit.
• Apply solder to the short land sections before the card wire is disconnected from the connector on the servo board. (If the card wire
is disconnected without applying solder, the pickup may be destroyed by static electricity.)
• In the assembly, be sure to remove solder from the short land sections after connecting the card wire.
Mechanism control board
CN102
Pickup
Flexible wire
Short land section

1-6 (No.MA468<Rev.001>)
1.8 Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION OF LABELS and PRINT
!Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
WARNING LABEL and PRINT

(No.MA468<Rev.001>)1-7
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

1-8 (No.MA468<Rev.001>)
SECTION 3
DISASSEMBLY
3.1 Main body
3.1.1 Removing the Bottom chassis (See Fig.1)
(1) Remove the two screws Aand one screw Battaching the
Heat sink.
(2) Remove the one screws Cand one screw Dattaching the
Bottom chassis.
Fig.1
3.1.2 Removing the Front chassis (See Fig.2)
(1) Disengage hour hooks aengaged Front chassis.
Fig.2
3.1.3 Removing the Main board (see Fig.3, 4, 5)
(1) Remove the one screw Eattaching the Top chassis. (See
Fig.3)
Fig.3
(2) Remove the two screws Fand one screw Gattaching the
Side plate. (See Fig.4)
Fig.4
(3) Remove the three screws Hattaching the Main board. (See
Fig.5)
(4) Disconnect the B-B connector connected CD mechanism
and Main board CN481 of the Main board. (See Fig.5)
Fig.5
3.1.4 Removing the CD mechanism (See Fig.6)
(1) Remove the three screws Jattaching the CD mechanism.
Fig.6
3.1.5 Removing the Switch board (See Fig.7)
(1) Remove the Volume knob.
(2) Remove the four screws Kattaching the Rear cover.
(3) Disengage eleven hooks bengaged Rear cover.
Fig.7
ABCD A
hook a
E
FG F
H
H
CN481
J
J
KK
hook b
hook b

(No.MA468<Rev.001>)1-9
3.2 CD MECHANISM assembly section
• Remove the CD MECHANISM assembly from the main body.
3.2.1
Removing the MECHANISM CONTROL BOARD
assembly (See Fig.
1 and 2 )
(1) From the bottom side of CD MECHANISM assembly,
remove the solders from the soldered sections (
a , b and
c ) on the MECHANISM CONTROL BOARD assembly.
(See Fig.
1 .)
(2) Remove the three screws Aattaching the MECHANISM
CONTROL BOARD assembly. (See Fig.1.)
(3) Solder the short land sections on the pickup. (See Fig.2.)
Caution:
• Solder the short land sections on the pickup before
disconnecting the flexible wire from the connector
CN102 on the MECHANISM CONTROL BOARD as-
sembly.
If the card wire is disconnected without attaching
solder, the pickup may be destroyed by static
electricity. (See Fig. 2 .)
• When attaching the MECHANISM CONTROL
BOARD assembly, remove the solders from the
short land sections after connecting the flexible
wire to the connector CN102 on the MECHANISM
CONTROL BOARD assembly.
Fig.1
Fig.2
A
CN102
Mechanism
control board
A
A
b
a
c
Mechanism control board
CN102
Pickup
Flexible wire
Short land section

1-10 (No.MA468<Rev.001>)
3.2.2 Removing the top cover (See Fig.3 to 5)
• Remove the MECHANISM CONTROL BOARD assembly.
(1) From the front side of the CD MECHANISM assembly,
change the hook position of the two roller springs. (See
Fig.3.)
(2) From the side of the CD MECHANISM assembly, remove
the six screws Battaching the top cover. (See Fig.3 and 4.)
(3) Take out the top cover in an upward direction. (See Fig.5.)
Fig.3
Fig.4
Fig.5
3.2.3 Removing the roller (See Fig.6)
• Remove the MECHANISM CONTROL BOARD assembly and
top cover.
(1) From the bottom side of the top cover, remove the screw C
attaching the gear holder.
(2) Remove the R.holder assembly from disc plate, and then
take out the roller from R.holder assembly in the direction
of the arrow.
Reference:
When attaching the R.ACT gear (2) and R.ACT gear (3),
apply grease to the section dof R.holder assembly.
Fig.6
B
Top cover
Roller spring Roller spring
B
B
Top cover
Top cover
Roller coller
Roller
R.ACT gear(3)
Roller gear
Gear holder
R.ACT gear(2)
R.holder assembly
Top cover Disc plate
Washer
C
d

(No.MA468<Rev.001>)1-11
3.2.4 Removing the PHOTO BOARD assembly (See Fig.7
and 8)
• Remove the MECHANISM CONTROL BOARD assembly and
top cover.
(1)
From the bottom side of the top cover, release the
projection
e from the notch of the disc plate. (See
Fig.
7 .)
(2) Take out the disc plate in the direction of the arrow. (See
Fig.7.)
(3) From the reverse side of the disc plate, remove the screw
Dattaching the PHOTO BOARD assembly. (See Fig.8.)
Fig.7
Fig.8
3.2.5 Removing the mechanism section (See Fig.9 and 10)
• Remove the MECHANISM CONTROL BOARD assembly and
top cover.
(1) From the top side of the CD MECHANISM assembly,
remove the two screws
E attaching the loading motor
assembly. (See Fig.
9 .)
(2) Remove the two roller springs on the top side of the mecha
frame. (See Fig.9.)
(3) Remove the four SUS springs on the top side of the mecha
frame. (See Fig.9.)
(4) Remove the link spring on the top side of the mecha frame.
(See Fig.10.)
(5) Release section fof the three dampers from the mecha
frame. (See Fig.10.)
Reference:
When attaching the roller spring and SUS spring, keep
direction before remove.
(6)
Move the slide cam (R) assembly in the direction of the
arrow, and then take out the mechanism section in an
upward direction. (See Fig.
10 .)
Reference:
When attaching the mechanism section, apply grease to
the section g. (See Fig.10.)
Fig.9
Fig.10
Top cover Disc plate
e
e
Photo board
Disc plate
D
E
Mechanism section
Mecha frame
Roller spring
Loading motor assembly
SUS
spring
SUS
spring
SUS
spring
SUS
spring
Mecha frame
Cam cover
F

1-12 (No.MA468<Rev.001>)
3.2.6 Removing the slide cam (L) (See Fig.11 to 13)
• Remove the MECHANISM CONTROL BOARD assembly, top
cover and mechanism section.
(1) From the top side of the mecha frame, remove the screw F
attaching the cam cover. (See Fig.11.)
(2)
Take out the cam cover from mecha frame in an upward
direction. (See Fig.
11 .)
(3) Take out the slide cam (L) in the direction of the arrow.
(See Fig.12.)
Reference:
When attaching the slide cam (L), apply grease to the
section h. (See Fig.13.)
Fig.11
Fig.12
Fig.13
Mecha frame
Cam cover
F
Mecha frame
Slide cam(L)
Slide cam(L)
Slide cam(L)
h
h
h
h
h
hh
h

(No.MA468<Rev.001>)1-13
3.2.7 Removing the F.lock lever and slide cam (R) (See
Fig.14 and 15)
• Remove the MECHANISM CONTROL BOARD assembly, top
cover and mechanism section.
(1) From the top side of the mecha frame, take out the slide
cam (R) assembly in an upward direction. (See Fig.14.)
(2) Rotate the F.lock lever in the direction of the arrow 1, and
then take out the direction of the arrow 2. (See Fig.14.)
Reference:
When attaching the slide cam (R) assembly, the f.lock
lever and the link arm apply grease to the section
h .
(See Fig.
14 and 15 .)
Fig.14
Fig.15
3.2.8 Removing the damper (See Fig.16)
• Remove the MECHANISM CONTROL BOARD assembly, top
cover and mechanism section.
From the mechanism section, pull out the three dampers in the
direction of the arrow.
Reference:
Before inserting the shaft to the dampers, apply IPA to the
pocket jof damper.
Fig.16
3.2.9 Removing the clamper assembly (See Fig.17)
• Remove the MECHANISM CONTROL BOARD assembly, top
cover and mechanism section.
(1) From the top side of the mechanism section, release the
clamper spring.
(2) Move the clamper assembly in the direction of the arrow,
and then release the joints (kand m).
(3)
Take out the clamper assembly from the T.M chassis
assembly.
Fig.17
h
hh
h
h
h
Mecha frame
Link arm
F.lock lever 2
1
Slide cam(R) assembly
Slide cam(R) assembly
h
h
h
h
h
h
Slide cam(R) assembly
j
j
j
Damper (Brown)
Damper (Brown)
Damper (Gray)
k
m
Clamper assembly
Clamper spring
T.M. chassis assembly

1-14 (No.MA468<Rev.001>)
3.2.10 Removing the feed motor (See Fig.18 and 19)
• Remove the MECHANISM CONTROL BOARD assembly, top
cover, mechanism section and clamper assembly.
(1) From the bottom side of the T.M chassis assembly, remove
the two screws Gattaching the feed motor assembly. (See
Fig.18.)
(2)
Remove the two screws H attaching the feed motor to
f.motor holder. (See Fig.
19 .)
Reference:
When attaching the f. wheel gear, trigger arm and feed
motor, apply grease to the sections (n, pand q). (See
Fig.18 and 19.)
3.2.11 Removing the SWITCH BOARD assembly (See
Fig.18)
• Remove the MECHANISM CONTROL BOARD assembly, top
cover, mechanism section, clamper assembly and feed motor
assembly.
From the bottom side of the T.M chassis assembly, take out
the SWITCH BOARD assembly in an upward direction from
T.M chassis assembly.
Fig.18
Fig.19
3.2.12 Removing the loading motor (See Fig.20)
• Remove the MECHANISM CONTROL BOARD assembly, top
cover, mechanism section and clamper assembly.
(1) From the right side of the L.M base assembly, remove the
two screws Jattaching the loading motor.
(2) Take out the loading motor in the direction of the arrow
from the L.M base assembly.
Reference:
When attaching the loading motor, apply grease to the
section r.
Fig.20
n
Feed motor assembly
Switch board
F.wheel gear
T.M. chassis assembly
Trigger arm
p
G
q
Comp. spring
F.motor holder
H
F.worm gear
Feed motor
r
Loading moto
r
L.M. base assembly
J
L.worm gear

(No.MA468<Rev.001>)1-15
3.2.13 Removing the pickup assembly (See Fig.21 to 22)
• Remove the MECHANISM CONTROL BOARD assembly, top
cover, mechanism section, clamper assembly and feed motor
assembly.
Caution:
• Do not touch section uon the pickup assembly. (See Fig.21
and 22.)
(1) From the bottom side of the T.M chassis assembly, move
the pickup assembly in the direction of the arrow from the
T.M chassis assembly. (See Fig.21.)
(2) Pull out the main shaft. (See Fig.21.)
(3) Remove the screw Kattaching the pickup to the rack plate.
(See Fig.22.)
Reference:
When attaching the loading motor, apply grease to the
sections sand t. (See Fig.21.)
Fig.21
Fig.22
3.2.14 Removing the spindle motor (See Fig.23 and 24)
•
Remove the MECHANISM CONTROL BOARD assembly,
top cover, mechanism section, clamper assembly, feed motor
assembly and pickup assembly.
(1) From the top side of the T.M chassis assembly, remove the
CD T.table assembly from the spindle motor. (See Fig.23.)
(2) Remove the two screws Lattaching the spindle motor.
(See Fig.23.)
(3) Take out the spindle motor from the bottom side of the T.M
chassis assembly. (See Fig.23.)
Reference:
When attaching the CD T.table assembly to the spindle
motor shaft, apply loctite 460 to inside the CD T.table
assembly. (See Fig. 24 .)
Fig.23
Fig.24
s
u
t
Main shaft
Pick up assembly
T.M. chassis assembly
u
Rack plate
Pick up
K
CD T.table assembly
T.M.chassis assembly
Spindle motor
LL
CD T.table assembly
Spindle motor
Loctite

1-16 (No.MA468<Rev.001>)
SECTION 4
ADJUSTMENT
4.1 Test instruments required for adjustment
(1) Digital oscilloscope (100MHz)
(2) Digital tester
(3) Test Disc JVC :CTS-1000
(4) Extension cable for check
EXTSH002-22P x 1
4.2 Standard measuring conditions
Power supply voltage DC14.4V(10.5 to 16V)
Load impedance 20K.(2 Speakers connection)
Output Level Line out 2.5V (Vol. MAX)
4.3 Standard volume position
Balance and Bass &Treble volume : lndication"0"
Loudness : OFF
4.4 Dummy load
Exclusive dummy load should be used for AM,and FM.
For FM dummy load, there is a loss of 6dB between SSG
outputand antenna input.
The loss of 6dB need not be considered sincedirect read-
ing offigures are applied in this working standard.
4.5 How to connect the extension cable for adjusting
Caution:
Be sure to attach the heat sink and rear bracket onto the power amplifier IC and regulator IC respectively, before supply
the power.
If voltage is applied without attaching these parts, the power amplifier IC and regulator IC will be destroyed by heat.
Extension cable
EXTSH002-22P

(No.MA468<Rev.001>)1-17
4.6 SERVICE MODE
4.6.1 Service mode setting
(1) Push POWER BUTTON (Power ON)
(2) Set to service mode
Keep this state more 3 seconds while continuing pressing the [MENU] button and [DISC DOWN] button scquentially.
*Exchanging of operate a menu of a service mode with the [FF] button and [REW] button.
Operate choice of a menu with a [ENT] button.
SERVICE MODE
DATA DELETE INIT ALL
CDERR DEL
CHERR DEL
Initialize EEPROM data
CD ERROR Read CD error history
DSP ERROR Read DSP error history
CH ERROR Read CD changer error history
: The error history saved on the CD changer is read out.
RUNNING MODE 1 For use in running tests
TUBUYAKI Only the factory setup. No use.
ERROR READ
ROMVERxx ROM correction versionROM CORRE
CDLD ON xx yy zz CD laser illumination and electric current (mA)
xx : Early current value
yy : Current current value
zz : Difference value
MODE 2 For use in running tests
Clear CD error history
Clear changer error history
: The error history saved in the CD changer is cleared.
Clear DSP error history
Note : A disc is inseted, and it is displayed only at the timer of CD function.
DSPERR DEL

1-18 (No.MA468<Rev.001>)
AUTO ADJ
MANUAL ADJ
POWER
ADJ1
Only factory setup. No use.TUNER ADJ
1. FM DAA
87.5 40dBuV 0%
Press OK
1. FM DAA
87.5 40dBuV 0%
No signal
ADJ2
2. FM DAA
97.9 40dBuV 0%
Press OK
2. FM DAA
97.9 40dBuV 0%
No signal
ADJ3
3. FM DAA
108.0 40dBuV 0%
Press OK
3. FM DAA
108.0 40dBuV 0%
No signal
ADJ4
4. FM S Meter
97.9 30dBuV 0%
Press OK
4. FM S Meter
97.9 30dBuV 0%
High or Low or No signal
ADJ5
5. FM S Meter
97.9 60dBuV 0%
Press OK
5. FM S Meter
97.9 60dBuV 0%
High or Low or No signal
ADJ6
6. FM Full Sepa
97.9 70dBuV 0%
Lch Press OK
6. FM Full Sepa
97.9 60dBuV 0%
Adjust NG or No signal
ADJ7
7. FM IF Counter
97.9 70dBuV 0%
Press OK
7. FM IF Counter
97.9 60dBuV 0%
Adjust NG or No signal
ADJ8
8. AM S Meter
999 26dBuV 0%
Press OK
8. FM IF Counter
999 26dBuV 0%
High or Low or No signal
ADJ9
9. AM S Meter
999 56dBuV 0%
Press OK
9. AM S Meter
999 56dBuV 0%
High or Low or No signal
ADJ10
10. AM IF Counter
999 56dBuV 0%
Press OK
10. AM IF Counter
999 56dBuV 0%
Adjust NG or No signal
Manual Adjust
COMPLETED
POWER OFF
(Adjust Mode FINISH)

(No.MA468<Rev.001>)1-19
4.7 Confirmation method of a micon version
(1) Push POWER BUTTON (Power ON).
(2) Set this set at tuner mode.
(3) Keep this state more than 3 seconds while continuing pressing the [ENT] button and [MENU] button sequentially.
(4) It is displayed as follows by a display window.
4.8 Error code tables
4.8.1 Mechanism error code
4.8.2 Disc error code
Error contents Details Error code Detailed error code
Disc loading error
(1) B1 time out
(2) C1 time out
(3) B2 time out
09
09
09
0011
0012
0015
Eject error
(1) B1 time out
(2) C2 time out
(3) B2 time out
01
01
01
0023
0026
0027
Compulsion eject error
(1) E1 compulsion eject error
(2) E2 compulsion eject error
(3) E3 compulsion eject error
(4) E5 compulsion eject error
(5) E7 compulsion eject error
(6) E8 compulsion eject error
(7) E9 compulsion eject error
01
01
01
01
01
01
01
0041
0042
0043
0045
0047
0048
0049
Error contents Details Error code Detailed error code
TOC read error TOC lead movement of a CD is not completed. 84 0059
First track access error Even if TOC reading passes after the end with CD running mode
for 30 seconds, the first track access is not finished.
80 0060
Last track access error Even if TOC reading passes after the end with CD running mode
for 30 seconds, the first track access is not finished.
80 0061
NO DISC judgment Judgment without disc. 80 0090
It is NO DISC by start failure Start is impossible. 80 0091
It is stopped by playback inability Stop in running mode playback 80 0093
Logic format NG Logic format analysis inability or non-correspondence logic format. 80 0094
MAIN V䌸䌸䌸 Main micon version
CD V䌸䌸䌸-䌸䌸 CD module version and ROM corre version
CH V䌸䌸䌸 CH micon version (It is displayed only in changer connection.)
BTC-䌸䌸 Software version of BT core (It is displayed in bluetooth adaptor connection.)
BHH-䌸䌸䌸 Hardtware version of BT Module (It is displayed in bluetooth adaptor connection.)
BHS-䌸䌸䌸 Software version of BT Module (It is displayed in bluetooth adaptor connection.)
BHC-䌸䌸䌸 Software version of BT Hideaway controller (It is displayed in bluetooth adaptor connection.)
ADR-䌸䌸䌸䌸䌸䌸 BT Address (It is displayed in bluetooth adaptor connection.)
HD-xxxx-xxx HD decoder firmware version
Change each indication with the [FF] button and [REW] button.

1-20 (No.MA468<Rev.001>)
4.8.3 CD changer mechanism error code
*"Position is not stable in WAIT position," "Position is not stable in PLAY position," and "Position is not stable in absolute position,"
and "Improper EJECT position" are all Position Motor TIME OVER.
Error contents Details Error code Detailed error code
Tray eject error
(1) TRAYINSW time over
(TRAYINSW:L,TRAYOUTSW:H)
(2) TRAYOUTSW time over
(TRAYINSW:H,TRAYOUTSW:H)
(3) TRAYINSW time over
(TRAYINSW:L,TRAYOUTSW:L)
(4) MAGIN SW:L→H
Tray motor time over Tray motor does not operate.
Tray stops.
TRAYINSW NG etc.
Magazine is ejected while Tray is being ejected.
03
03
03
03
0011
0012
0013
0014
Tray return error
(1) TRAYOUTSW time over
(TRAYINSW:H,TRAYOUTSW:L)
(2) TRAYINSW time over
(TRAYINSW:H,TRAYOUTSW:H)
(3) TRAYIN/OUTSW time over
(TRAYINSW:L,TRAYOUTSW:L)
(4) MAGIN SW:L→H
Tray motor time over Tray motor does not operate.
Tray stops.
TRAYINSW NG etc.
Magazine is ejected while Tray is being ejected.
03
03
03
03
0016
0017
0018
0019
Lifter up error
(1) WAIT position time over
(2) WAIT position time over
(3) WAIT position time over
Position motor time over Position motor does not operate.
Position is not stable in fine adjustment mode.
Other condition
02
02
02
0021
0022
0023
Lifter down error
(1) WAIT position time over
(2) WAIT position time over
(3) WAIT position time over
Position motor time over Position motor does not operate.
Position is not stable in fine adjustment mode.
Other condition
02
02
02
0026
0027
0028
Chucking error
(1) Play position time over
(2) Play position time over
(3) Play position time over
Position motor time over Position motor does not operate.
Position is not stable in fine adjustment mode.
Other condition
02
02
02
0031
0032
0033
Unchucking error
(1) WAIT position time over
(2) WAIT position time over
(3) WAIT position time over
Position motor time over Position motor does not operate.
Position is not stable in fine adjustment mode.
Other condition
02
02
02
0036
0037
0038
Eject error
(1) Eject position time over
(2) Eject position time over
(3) MAGINSW time over
Eject cannot be carried out.
Position motor does not operate.
Improper EJECT position.*
Magazine is not ejected.
02
02
01
0041
0042
0043
Initialize error
(1) Eject position time over
(2) Eject position time over
TRAYINSW and TRAYOUTSW are L.
Position is not stable in absolute position.*
03
02
0046
0047
