JVC KD-APD49 - CD/AM/FM/MP3/WMA Receiver User manual

ENGLISHESPAÑOLFRANÇAIS
CD RECEIVER KD-APD49/KD-PDR40
RECEPTOR CON CD KD-APD49/KD-PDR40
RÉCEPTEUR CD KD-APD49/KD-PDR40
For canceling the display demonstration, see page 6.
Para cancelar la demostración en pantalla, consulte la página 6.
Pour annuler la démonstration des affichages, référez-vous à la page 6.
For installation and connections, refer to the separate manual.
Para la instalación y las cone iones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
GET0483-001A
[J]
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet. Retain
this information for future
reference.
Model No.
Serial No.
Cover_KD-APD49[J]f.indd 1Cover_KD-APD49[J]f.indd 1 11/1/07 3:11:58 PM11/1/07 3:11:58 PM

2
ENGLISH
[European Union only]
Warning:
If you need to operate the unit while driving, be
sure to look around carefully or you may be involved
in a traffic accident.
Thank you for purchasing a VC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
INFORMATION (For U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Caution:
Changes or modifications not approved by VC could void the user’s authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: (For U.S.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
For saf ty...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
T mp ratur insid th car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
EN02-05_KD-APD49[J]f.indd 2EN02-05_KD-APD49[J]f.indd 2 11/1/07 3:11:13 PM11/1/07 3:11:13 PM

ENGLISH
3
How to r s t your unit
• Your preset adjustments will also be erased.
How to forcibly j ct a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
How to us th M MODE button
If you press M MODE, the unit goes into functions mode,
then the number buttons and 5/∞ buttons will work
as different function buttons.
Ex.: When number button 2 works as
MO (monaural) button.
To us th s buttons for th ir original functions
again aft r pr ssing M MODE, press M MODE again.
• Waiting for about 5 seconds without pressing any of
these buttons will automatically cancels the functions
mode.
KD-APD49 is equipped with the steering wheel
remote control function.
• See the Installation/Connection Manual (separate
volume) for connection.
CONTENTS
Control pan l — KD-APD49/KD-PDR40 ... 4
R mot controll r — RM-RK50 ........... 5
G tting start d ................................ 6
Basic operations ................................................... 6
Radio op rations ............................. 7
Disc op rations ................................ 8
Playing a disc in the unit ..................................... 8
iPod op rations ............................... 10
Sound adjustm nts .......................... 12
G n ral s ttings — PSM .................. 14
Oth r xt rnal compon nt
op rations ................................... 16
Titl assignm nt .............................. 16
Maint nanc ................................... 17
Mor about this unit ........................ 17
Troubl shooting .............................. 20
Sp cifications .................................. 22
The control panel illustrations used for explanation
in this manual is of KD-APD49.
D taching th control pan l
Attaching th control pan l
EN02-05_KD-APD49[J]f.indd 3EN02-05_KD-APD49[J]f.indd 3 11/1/07 3:11:15 PM11/1/07 3:11:15 PM

4
ENGLISH
1 5 (up) / ∞ (down) buttons
2 0 (eject) button
3 (standby/on attenuator) button
4 Control dial
5 Remote sensor
DO NO expose the remote sensor to strong light
(direct sunlight or artificial lighting).
6 BAND button
7 Loading slot
8 Display window
9 EQ (equalizer) button
p DISP (display) button
q (control panel release) button
w i (iPod) button
e 4 /¢ buttons
r SRC (source) button
t SEL (select) button
y M MODE button
u MO (monaural) button
i SSM (Strong-station Sequential Memory) button
o Number buttons
; RPT (repeat) button
a RND (random) button
s AUX (auxiliary) input jack
d Source display / Track number / Folder number /
Time countdown indicator
f Tr (track) indicator
g DISC indicator
h Playback mode / item indicators— RND (random),
(disc), (folder), RPT (repeat)
j Tuner reception indicators—ST (stereo),
MO (monaural)
k Sound mode (iEQ: intelligent equalizer) indicators
—CLASSIC, HIP HOP, AZZ, ROCK, POPS, USER
l LOUD (loudness) indicator
/ EQ (equalizer) indicator
z Disc information indicators—
TAG (Tag information), (folder), (track/file)
Main display
Parts id ntification
Control panel — KD-APD49 / KD-PDR40
Display window
EN02-05_KD-APD49[J]f.indd 4EN02-05_KD-APD49[J]f.indd 4 11/1/07 3:11:16 PM11/1/07 3:11:16 PM

ENGLISH
5
Remote controller — RM-RK50
Installing the lithium coin battery
(CR2025)
For USA-California Only:
This product contains a CR Coin Cell Lithium Battery
which contains erchlorate Material—special
handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
Aim the remote controller directly at the remote
sensor on the unit. Make sure there is no obstacle
in between.
arning:
• Do not install any battery other than CR2025 or its
equivalent; otherwise, it may explode.
• Do not leave the remote controller in a place
(such as the dashboard) exposed to direct
sunlight for a long time; otherwise, it may
explode.
• Store the battery in a place where children cannot
reach to avoid the risk of accidents.
• To prevent the battery from over-heating,
cracking, or starting a fire:
– Do not recharge, short, disassemble, heat the
battery, or dispose of it in a fire.
– Do not leave the battery with other metallic
materials.
– Do not poke the battery with tweezers or
similar tools.
– Wrap the battery with tape and insulate when
throwing away or saving it.
Main elements and features
1 (standby/on/attenuator) button
• Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
2 5 U (up) / D (down) ∞ buttons
• Changes the FM/AM bands with 5 U.
• Changes the preset stations with D ∞.
• Changes the folder of the M 3/WMA discs.
• While listening to an Apple i od.
– Enters the main menu if pressed and held.
(Now 5 U/D ∞/2 R/F 3 work as the menu
selecting buttons.)
• While listening to an i od (in menu selecting
mode):
– Returns to the previous menu if pressed 5 U
briefly.
– Selects an item if pressed D ∞ briefly. (Then,
press and hold D ∞ to play back the selection
directly.)
3 VOL – / VOL + buttons
• Adjusts the volume level.
4 SOUND button
• Selects the sound mode (iEQ: intelligent equalizer).
5 SOURCE button
• Selects the source.
6 2 R (reverse) / F (forward) 3 buttons
• Searches for stations if pressed briefly.
• Fast-forwards or reverses the track if pressed and
held.
• Changes the track if pressed briefly.
• While listening to an i od (in menu selecting
mode):
– Accelerated file search: Hold 2 R/F 3 to fast
skip during song search in the main menu.
EN02-05_KD-APD49[J]f.indd 5EN02-05_KD-APD49[J]f.indd 5 11/20/07 10:20:29 AM11/20/07 10:20:29 AM

6
ENGLISH
To drop the volume in a
moment (ATT)
To restore the sound, press
the button again.
To turn off the power
Basic settings
• See also “General settings — PSM” on pages
14 and 15.
1
2
1 Canceling the display demonstrations
Select “ EMO,” then “ EMO OFF.”
2 Setting the clock
Select “CLOCK HOUR,” then adjust the hour.
Select “CLOCK MIN” (minute), then adjust the
minute.
3 Finish the procedure.
To check the current clock time while the
power is turned off
Clock time is shown on the display for
about 5 seconds. See also page 14.
Getting started
Basic operations
~ Turn on the power.
Ÿ
*1 You cannot select “CD” as the playback source
if there is no disc in the unit.
*2 “NO IPOD” appears if an iPod is not connected.
! For F /A tuner
⁄ Adjust the volume.
@ Adjust the sound as you want. (See
pages 12 and 13.)
Caution on volume setting:
iscs produce very little noise compared with other
sources. Lower the volume before playing a disc
to avoid damaging the speakers by the sudden
increase of the output level.
Volume level appears.
EN06-13_KD-APD49[J]f.indd 6EN06-13_KD-APD49[J]f.indd 6 11/1/07 3:11:26 PM11/1/07 3:11:26 PM

7
ENGLISH
Radio operations
~
Ÿ
! Start searching for a station.
When a station is received, searching stops.
To stop searching, press the same button
again.
To tune in to a station manually
In step ! above...
1
2 Select a desired station frequency.
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
When an F stereo broadcast is hard to
receive
Reception improves, but the stereo effect will be lost.
To restore the stereo effect, repeat the same
procedure. “MONO OFF” appears and the MO indicator
goes off.
Storing stations in memory
You can preset six stations for each band.
F station automatic presetting —
SS (Strong-station Sequential
emory)
1 Select the F band (F 1 – F 3) you want to
store into.
2
3
“SSM” flashes, then disappears when automatic
presetting is over.
Local FM stations with the strongest signals are
searched and stored automatically in the FM band.
Lights up when monaural mode is activated.
EN06-13_KD-APD49[J]f.indd 7EN06-13_KD-APD49[J]f.indd 7 11/1/07 3:11:28 PM11/1/07 3:11:28 PM

8
ENGLISH
Disc operations
Playing a disc in the unit
All tracks will be played repeatedly until you change the
source or eject the disc.
To stop play and eject the disc
• Press SRC to listen to another
playback source.
[Hold] To fast-forward or reverse the
track
[Press] To go to the next or previous
track
[Press] To go to the next or previous
folder (only for MP3 or WMA
discs)
To locate a particular track (for CD) or folder
(for P3 or W A discs) directly
To select a number from 01 – 06:
To select a number from 07 – 12:
anual presetting
Ex.: Storing the FM station of 92.50MHz into preset
number 4 of the FM1 band.
1
2
3
Listening to a preset station
1
2 Select the preset station (1 – 6) you want.
or
To check other information while listening
to the radio
Frequency = Clock =
Station name * = (back to the
beginning)
* If no title is assigned to a station, “NO N ME” appears.
To assign a title to a station, see page 16.
Preset number flashes for a while.
EN06-13_KD-APD49[J]f.indd 8EN06-13_KD-APD49[J]f.indd 8 11/1/07 3:11:29 PM11/1/07 3:11:29 PM

9
ENGLISH
• To use direct folder access on MP3/WMA discs, it
is required that folders are assigned with 2-digit
numbers at the beginning of their folder names—
01, 02, 03, and so on.
To select a particular track in a folder
(for MP3 or WMA discs):
Other main functions
Skipping tracks quickly during play
• For MP3 or WMA discs, you can skip tracks within the
same folder.
Ex.: To select track 32 while playing a track whose
number is a single digit (1 to 9)
1
2
Each time you press the button, you can skip 10
tracks.
• After the last track, the first track will be selected
and vice versa.
3
Prohibiting disc ejection
You can lock a disc in the loading slot.
“EJECT LOCK” flashes on the display.
To cancel the prohibition, repeat the same
procedure.
Changing the display information
While playing an audio CD or CD Text
A = B = Disc title/performer *1 = Track
title *1 [ ] = (back to the beginning)
While playing an P3 or a W A track
• When “TAG DISPLAY” is set to “TAG ON”
(see page 15)
A = B = Album name/performer (folder
name *2) [ ] = Track title (file
name *2) [ ] = (back to the beginning)
• When “TAG DISPLAY” is set to “TAG OFF”
A = B = Folder name [ ] = File name
[ ] = (back to the beginning)
A : Current track number with the elapsed playing
time
B : Current track number with the clock time
[ ] : Corresponding indicator lights up on the display.
*1 If the current disc is an audio CD, “NO N ME” appears.
*2 If an MP3/WM file does not have Tag information,
folder name and file name appear. In this case, the
T G indicator will not light up.
EN06-13_KD-APD49[J]f.indd 9EN06-13_KD-APD49[J]f.indd 9 11/1/07 3:11:30 PM11/1/07 3:11:30 PM

10
ENGLISH
Selecting the playback modes
You can use only one of the following playback modes
at a time.
1
2 Select your desired playback mode.
7 Repeat play
ode Plays repeatedly
TRACK RPT : The current track. [ ]
FOLDER RPT * : All tracks of the current folder.
[ ]
RPT OFF : Cancels.
7 Random play
ode Plays at random
FOLDER RND * : All tracks of the current folder,
then the tracks of the next folder
and so on. [ ]
ALL RND : All tracks of the current disc.
[ ]
RND OFF : Cancels.
* Only while playing an MP3 or a WM disc.
[ ] : Corresponding indicator lights up on the
display.
iPod operations
You can play songs in an Apple iPod by connecting it
with the supplied direct connection cable for iPod.
You can control playback from the unit or from your
iPod.
• isconnecting the iPod will stop playback. Press SRC
to listen to another playback source.
Caution:
• Avoid using the iPod if it might hinder your safety
while driving.
• Make sure all important data has been backed up
to avoid losing the data.
• For connection, see the Installation/Connection
Manual (separate volume).
• For details, refer also to the manual supplied for your
iPod.
~ Connect an iPod.
If an iPod has been connected...
To directly select “IPO ” as the source
while listening to another source or
when the power is turned off.
Playback starts automatically from where it had
been paused previously.
Ÿ Adjust the volume.
irect connection
cable for iPod
EN06-13_KD-APD49[J]f.indd 10EN06-13_KD-APD49[J]f.indd 10 11/1/07 3:11:31 PM11/1/07 3:11:31 PM

11
ENGLISH
Selecting a track from the menu
1 Enter the main menu.
Now the 5/∞/4 /¢ /number
buttons work as the menu selecting buttons.
2 Select the desired menu.
PLAYLIST Ô ARTIST Ô ALBUM Ô S NG
Ô P DCASTÔ GENRE Ô C MP SER
Ô AUDI B K Ô (back to the beginning)
• Pressing the number buttons can directly select
the desired menu (see the left column for
details).
3 Confirm the selection.
To move back to the previous
menu press 5.
• Holding the button will start play back the
selected item directly.
• If a track is selected playback starts
automatically.
• If the selected item has another layer you will
enter the layer. Repeat steps 2 and 3 until the
desired track is played.
• Accelerated file search: Hold 4 /¢
to fast skip during song search in the main menu.
! Adjust the sound as you want. (See
pages 12 and 13.)
To control playback from your iPod
“IPOD MODE” appears on the
display.
• Press and hold this button again to control playback
from the unit. “HEAD MODE” appears on the display.
Playback control from the unit
[Press] Go to the next or previous
track
[Hold] Fast-forward or reverse the
track during playback
Fast-skip the menu items of
the main menu
[Hold] Enter the main menu (see the
right column).
[Press] Pause/resume playback.
[Press] Go to the top menu of “PLAYLIST ” “ARTIST ”
“ALBUM ” “SONG ” “PODCAST ” or “GENRE” in
the main menu (see the right column).
[Hold] Go to the top menu of “COMPOSER” or
“AUDIOBOOK” in the main menu (see the
right column).
or
Continued on the next page
EN06-13_KD-APD49[J]f.indd 11EN06-13_KD-APD49[J]f.indd 11 11/20/07 10:24:03 AM11/20/07 10:24:03 AM

12
ENGLISH
To check other information while listening
to an iPod
Current track number with the elapsed
playing time = Current track number with
the clock time = Track title * = Album name/
performer * = (back to the beginning)
* When “TAG DISPLAY” is set to “TAG OFF” (see page 15),
fi e name and fo der name appear.
Sound adjustments
You can select a preset sound mode suitable to the
music genre (iEQ: intelligent equalizer).
Adjusting the sound
You can adjust the sound characteristics to your
pre erence.
• The adjustment you make will be stored or the
currently selected sound mode (iEQ) including
“USER.”
1
2
Indication, [ ange]
FADE *2, [R06 to F06]
Adjust the ront and rear speaker balance.
BALANCE *3, [L06 to R06]
Adjust the le t and right speaker balance.
To exit from menu selecting mode
or
* The menu selecting mode will be canceled:
– I no operations are per ormed or about
10 seconds.
– When you con irm the selection o a track.
– Pressing some other buttons such as DISP, SEL,
MODE, or EQ.
Selecting the playback modes
1
2 Select your desired playback mode.
7 epeat play
Mode Playback functions (as on iPod)
ONE PT : Same as “Repeat One.” [ ]
ALL PT : Same as “Repeat All.” [ ]
PT OFF : Cancels.
7 andom play
Mode Playback functions (as on iPod)
SONG ND : Same as “Shu le Songs.” [ ]
ALBUM ND * : Same as “Shu le Albums.”
[ ]
ND OFF : Cancels.
* Functions on y if you se ect “ALL” in “ALBUMS” of
the main menu.
[ ] : Corresponding indicator lights up on the
display.
EN06-13_KD-APD49[J]f.indd 12EN06-13_KD-APD49[J]f.indd 12 11/20/07 11:49:09 AM11/20/07 11:49:09 AM

13
ENGLISH
Indication, [Range]
L UD *4 (loudness) [LOUD ON or LOUD OFF]
Boost low and high frequencies to produce a
well-balanced sound at a low volume level.
SUBW FER *1 [00 to 08 initial: 04]
Adjust the subwoofer output level.
V L ADJ (volume adjust) [–05 to +05 initial: 00]
Adjust the volume level of each source (except FM) in
relation to the FM volume level. The volume level will
automatically increase or decrease when you change
the source.
• Before making an adjustment select the source you
want to adjust.
V LUME [00 to 50 or 00 to 30 ]*5
Adjust the volume.
*1 Displayed only when “L/O MODE” is set to “SUB.W”
(see page 1 ).
*2 If you are using a two-speaker system, set the fader
level to “00.”
*3 This adjustment will not affect the subwoofer output.
*4 The adjustment made (LOUD ON/LOUD OFF) will be
applied to all sound modes.
*5 Depending on the amplifier gain control setting. (See
page 1 for details.)
Storing your own sound mode
You can adjust the sound modes and store your own
adjustments in memory.
1 Select a sound mode.
2 Enter the adjustment mode.
• If no operation is done within
5 seconds this mode is canceled.
3 Select a sound characteristic.
4 Adjust the sound elements of the selected
sound characteristic.
1 Adjust the frequency.
2 Adjust the level.
3 Adjust the quality slope (Q).
Sound
elements
Range/selectable items
BASS MID TRE
Frequency 60 Hz
80 Hz
100 Hz
120 Hz
500 Hz
1.0 kHz
1.5 kHz
2.5 kHz
7.5 kHz
10.0 kHz
12.5 kHz
15.0 kHz
Level –06 to
+06
–06 to
+06
–06 to
+06
Q (Q-slope) Q0.5
Q1.0
Q1.5
Q2.0
Q0.75
Q1.0
Q1.25
Q1.5
Q0.75
Q1.25
BASS: Bass MID: Mid-range TRE: Treble
5 The adjustment made will be stored
automatically. Repeat steps 3 and 4 to adjust
other sound characteristics.
EN06-13_KD-APD49[J]f.indd 13EN06-13_KD-APD49[J]f.indd 13 11/20/07 10:24:06 AM11/20/07 10:24:06 AM

14
ENGLISH
Indications Item
( : Initial)
Setting, [reference page]
DEMO
Display
demonstration
• DEMO ON
• DEMO OFF
: The display demonstration will be activated automatically if no
operation is done for about 20 seconds, 6].
: Cancels.
CLOCK DISP *1
Clock display
• CLOCK ON
• CLOCK OFF
: The clock time is shown on the display at all times when the power is
turned off.
: Cancels; pressing DISP will show the clock time for about 5 seconds
when the power is turned off, 6].
CLOCK HO R
Hour adjustment
1 – 12 Initial: 1 (1:00)], 6].
CLOCK MIN
Minute adjustment
00 – 59 Initial: 00 (1:00)], 6].
DIMMER
Dimmer
• ON
• OFF
: Dims the display and button illumination.
: Cancels.
*1 If the power supply is not interrupted by turning off the ignition key of your car, it is recommended that you select
“CLOCK OFF” to sa e the car’s battery.
General settings — PSM
You can change PSM (Preferred Setting Mode) items
listed in the table below and on page 15.
1
2 Select a PSM item.
3 Adjust the PSM item selected.
4 Repeat steps 2 and 3 to adjust other PSM
items if necessary.
5 Finish the procedure.
EN14-23_KD-APD49[J]f.indd 14EN14-23_KD-APD49[J]f.indd 14 11/1/07 3:11:43 PM11/1/07 3:11:43 PM

ENGLISH
15
Indications Item
( : Initial)
Setting, [reference page]
A DIOBOOKS *2
Speed control of
“Audiobook”
• NORMAL
• FASTER
• SLOWER
: You can select the playback speed of the “Audiobook” sound file in
your iPod.
SCROLL *3
Scroll
• ONCE
• A TO
• OFF
: Scrolls the displayed information once.
: Repeats scrolling (at 5-second intervals).
: Cancels.
• Pressing DISP for more than one second can scroll the display
regardless of the setting.
L/O MODE
Line output mode
• REAR
• S B.W
: Select if the REAR LINE OUT terminals are used for connecting the
speakers (through an external amplifier).
: Select if the REAR LINE OUT terminals are used for connecting a
subwoofer (through an external amplifier).
S B.W FREQ *4
Subwoofer cutoff
frequency
• LOW
• MID
• HIGH
: Frequencies lower than 90 Hz are sent to the subwoofer.
: Frequencies lower than 135 Hz are sent to the subwoofer.
: Frequencies lower than 180 Hz are sent to the subwoofer.
TAG DISPLAY
Tag display
• TAG ON
• TAG OFF
: Shows the Tag information while playing MP3/WMA tracks, 9].
: Cancels.
AMP GAIN
Amplifier gain
control
• LOW POWER
• HIGH POWER
: VOLUME 00 – VOLUME 30. (Select this if the maximum power of the
speaker is less than 50 W to avoid damaging the speaker.)
: VOLUME 00 – VOLUME 50.
IF BAND
Intermediate
frequency band
• A TO
• WIDE
: Increases the tuner selectivity to reduce interference noise between
close stations. (The stereo effect may be lost.)
: Subject to interference noise from adjacent stations, but the sound
quality will not be degraded and the stereo effect will remain.
AREA
Tuner channel
interval
• AREA S
• AREA E
• AREA SA
: When using in North/Central/South America. AM/FM intervals are
set to 10 kHz/200 kHz.
: When using in any other areas. AM/FM intervals are set to 9 kHz/
50 kHz (100 kHz during auto search).
: When using in South American countries where FM interval is
100 kHz. AM interval is set to 10 kHz.
*2 Displayed only when an iPod is connected and playback is controlled from the unit.
*3 Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*4 Displayed only when “L/O MODE” is set to “SUB.W.”
EN14-23_KD-APD49[J]f.indd 15EN14-23_KD-APD49[J]f.indd 15 11/1/07 3:11:45 PM11/1/07 3:11:45 PM

16
ENGLISH
Other external component
operations
You can connect an external component to the AUX
(auxiliary) input jack on the control panel.
~
Ÿ Turn on the connected component and
start playing the source.
! Adjust the volume.
⁄ Adjust the sound as you want. (See
pages 12 and 13.)
To check other information while listening
to an external component
Portable audio player, etc.
3.5 mm stereo mini
plug (not supplied)
Clock Ô A X IN
Title assignment
You can assign names to 30 station frequencies (FM and
AM) and up to 8 characters for each station name.
1 Select FM/AM.
2 Show the title entry screen.
3 Assign a title.
1 Select a character.
2 Move to the next (or previous) character
position.
3 Repeat steps 1 and 2 until you finish
entering the title.
4 Finish the procedure.
To erase the entire title
In step 2 above...
EN14-23_KD-APD49[J]f.indd 16EN14-23_KD-APD49[J]f.indd 16 11/1/07 3:11:46 PM11/1/07 3:11:46 PM

ENGLISH
17
Maintenance
How to clean the connectors
Frequent detachment will deteriorate the connectors.
To minimize this possibility, periodically wipe the
connectors with a cotton swab or cloth moistened with
alcohol, being careful not to damage the connectors.
Moisture condensation
Moisture may condense on the lens inside the unit in
the following cases:
• After starting the heater in the car.
• If it becomes very humid inside the car.
Should this occur, the unit may malfunction. In this
case, eject the disc and leave the unit turned on for a
few hours until the moisture has evaporated.
How to handle discs
When removing a disc from its
case, press down the center holder
of the case and lift the disc out,
holding it by the edges.
• Always hold the disc by the edges. Do not touch its
recording surface.
When storing a disc in its case, gently insert the
disc around the center holder (with the printed surface
facing up).
• Make sure to store discs in cases after use.
To keep discs clean
A dirty disc may not play correctly.
If a disc does become dirty, wipe it with
a soft cloth in a straight line from center
to edge.
• Do not use any solvents (for example, conventional
record cleaner, spray, thinner, benzine, etc.) to clean
discs.
Connectors
Center holder
To play new discs
New discs may have some rough spots
around the inner and outer edges. If
such a disc is used, this unit may reject
the disc.
To remove these rough spots, rub the edges with a
pencil or ball-point pen, etc.
More about this unit
Basic operations
Turning on the power
• By pressing SRC (source) or i (iPod) button on the
unit, you can also turn on the power. If the source is
ready, playback also starts.
Turning off the power
• If you turn off the power while listening to a track,
playback will start from where it had been stopped
previously next time you turn on the power.
Warped disc
Sticker and
sticker residue Stick-on label
Do not use the following discs:
Unusual shape
Single CD
—8 cm (3-3/16”) disc
Continued on the next page
EN14-23_KD-APD49[J]f.indd 17EN14-23_KD-APD49[J]f.indd 17 11/1/07 3:11:47 PM11/1/07 3:11:47 PM

18
ENGLISH
General
• If you change the source while listening to a disc or
an iPod, playback stops.
Next time you select “C ” or “IPO ” as the playback
source, playback will start from where it had been
stopped/paused previously.
• After ejecting a disc or disconnecting an iPod,
“NO ISC” or “NO IPO ” appears and you cannot
operate some of the buttons. Insert another disc,
connect an iPod, or press SRC to select another
playback source.
Tuner operations
Storing stations in memory
• uring SSM search...
– All previously stored stations are erased and the
stations are stored anew.
– Received stations are preset in No. 1 (lowest
frequency) to No. 6 (highest frequency).
– When SSM is over, the station stored in No. 1 will
be automatically tuned in.
• When storing a station manually, the previously
preset station is erased when a new station is stored
in the same preset number.
Disc operations
Caution for DualDisc playback
• The Non- V side of a “ ual isc” does not comply
with the “Compact isc igital Audio” standard.
Therefore, the use of Non- V side of a ual isc on
this product may not be recommended.
General
• This unit has been designed to reproduce
C s/C Texts, and C -Rs (Recordable)/C -RWs
(Rewritable) in audio C (C - A), MP3 and WMA
formats.
• When a disc is inserted upside down, “PLEASE” and
“EJECT” appear alternately on the display. Press 0 to
eject the disc.
• MP3 and WMA “tracks” (words “file” and “track” are
used interchangeably) are recorded in “folders.”
• While fast-forwarding or reversing on an MP3 or
WMA disc, you can only hear intermittent sounds.
Playing a CD-R or CD-RW
• Use only “finalized” C -Rs or C -RWs.
• This unit can only play back files of the same type as
those which are detected first if a disc includes both
audio C (C - A) files and MP3/WMA files.
• This unit can play back multi-session discs; however,
unclosed sessions will be skipped while playing.
• Some C -Rs or C -RWs may not play back on this
unit because of their disc characteristics, or for the
following reasons:
– iscs are dirty or scratched.
– Moisture condensation has occurred on the lens
inside the unit.
– The pickup lens inside the unit is dirty.
– The files on the C -R/C -RW are written using the
“Packet Write” method.
– There are improper recording conditions (missing
data, etc.) or media conditions (stained, scratched,
warped, etc.).
•
C -RWs may require a longer readout time since the
reflectance of C -RWs is lower than that of regular C s.
• o not use the following C -Rs or C -RWs:
– iscs with stickers, labels, or a protective seal stuck
to the surface.
– iscs on which labels can be directly printed by an
ink jet printer.
Using these discs under high temperature or high
humidity may cause malfunctions or damage to the
unit.
Playing an MP3/WM disc
• This unit can play back MP3/WMA files with the
extension code <.mp3> or <.wma> (regardless of
the letter case—upper/lower).
• This unit can show the names of albums, artists
(performer), and Tag (Version 1.0, 1.1, 2.2, 2.3, or
2.4) for MP3 files and for WMA files.
• This unit can display only one-byte characters. No
other characters can be correctly displayed.
• This unit can play back MP3/WMA files meeting the
conditions below:
– Bit rate: 8 kbps — 320 kbps
– Sampling frequency:
48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)
24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)
EN14-23_KD-APD49[J]f.indd 18EN14-23_KD-APD49[J]f.indd 18 11/2/07 3:11:46 PM11/2/07 3:11:46 PM

ENGLISH
19
– Disc format: ISO 9660 Level 1/Level 2, Romeo,
Joliet, Win ows long file name
• The maximum number of characters for file/fol er
names vary epen ing on the isc format use
(inclu es 4 extension characters—<.mp3> or
<.wma>).
– ISO 9660 Level 1: up to 12 characters
– ISO 9660 Level 2: up to 31 characters
– Romeo: up to 128 characters
– Joliet: up to 64 characters
– Win ows long file name: up to 128 characters
• This unit can recognize a total of 512 files,
255 fol ers, an 8 hierarchical levels.
• This unit can play back files recor e in VBR (variable
bit rate).
Files recor e in VBR have a iscrepancy in the
elapse time isplay, an o not show the actual
elapse time. In particular, this ifference becomes
noticeable after performing the search function.
• This unit cannot play back the following files:
– MP3 files enco e in MP3i an MP3 PRO format.
– MP3 files enco e in an inappropriate format.
– MP3 files enco e with Layer 1/2.
– WMA files enco e in lossless, professional, an
voice format.
– WMA files which are not base upon Win ows
Me ia® Au io.
– WMA files copy-protecte with DRM.
– Files which have ata such as AIFF, ATRAC3, etc.
• The search function works but search spee is not
constant.
Ejecting a disc
• If the ejecte isc is not remove within 15 secon s,
it is automatically inserte into the loa ing slot again
to protect it from ust. Playback starts automatically.
iPod operations
• Controllable iPo :
– iPo mini
– iPo G4
– iPo photo
– iPo nano (1st & 2n Generation)
– iPo with vi eo (5th Generation)
• Up ate your iPo to the latest software version
before using it with this unit.
• When you turn on this unit, the iPo is charge
through this unit.
• While connecting an iPo with Vi eo:
– No vi eo shows on the iPo ’s isplay or the
external monitor (only the au io part is available).
– It is not possible to browse vi eo files on the
“Vi eo“ menu. (If you connect the iPo uring
the playback or pausing of a vi eo file, resuming
playback will not work.)
• iPo shuffle cannot be use with this unit.
• You can control the iPo from this unit when “JVC” or
“” appears on the iPo isplay after connection.
• The song or er isplaye on the selection menu of
this unit may iffer from that of the iPo .
• If playback is stoppe , select a track from the
selection menu or press BAND to playback the same
track again.
• The text information may not be isplaye correctly:
– Some characters such as accente letters cannot be
shown correctly on the isplay.
– Communication between the iPo an the unit is
not stable.
• If the text information inclu es more than
11 characters, it scrolls on the isplay. This unit can
isplay up to 64 characters.
Notice:
When operating an iPo , some operations may not
be performe correctly or as inten e . In this case,
visit the following JVC web site:
<http://www.jvc-victor.co.jp/english/car/>
General settings—PSM
• If you change the “AMP GAIN” setting from
“HIGH POWER” to “LOW POWER” while the
volume level is set higher than “VOLUME 30,” the
unit automatically changes the volume level to
“VOLUME 30.”
Continued on the next page
EN14-23_KD-APD49[J]f.indd 19EN14-23_KD-APD49[J]f.indd 19 11/13/07 4:37:20 PM11/13/07 4:37:20 PM

20
ENGLISH
Symptoms Remedies/Causes
General
• Sound cannot be heard from the speakers. • Adjust the volume to the optimum level.
• Check the cords and connections.
• The unit does not work at all. Reset the unit (see page 3).
FM/AM
• SSM automatic presetting does not work. Store stations manually.
• Static noise while listening to the radio. Connect the antenna firmly.
Disc playback
• Disc cannot be played back. Insert the disc correctly.
• CD-R/CD-RW cannot be played back.
• Tracks on the CD-R/CD-RW cannot be skipped.
• Insert a finalized CD-R/CD-RW.
• Finalize the CD-R/CD-RW with the component which
you used for recording.
• Disc can neither be played back nor ejected. • Unlock the disc (see page 9).
• Eject the disc forcibly (see page 3).
• Disc sound is sometimes interrupted. • Stop playback while driving on rough roads.
• Change the disc.
• Check the cords and connections.
• “NO DISC” appears on the display.
• “PLEASE” and “EJECT“ appear alternately on
the display.
Insert a playable disc into the loading slot.
Troubleshooting
What appears to be trouble is not always serious. Check the following points before calling a service center.
Preset value setting for each sound mode
Sound mode
Preset value
BASS (bass) MID (mid-range) TRE (treble) LO D
(loudness)
Freq. Level Q Freq. Level Q Freq. Level Q
SER 60 Hz 00 Q1.0 1.0 kHz 00 Q1.25 7.5 kHz 00 Q1.25
OFF
ROCK 100 Hz +03 Q1.0 1.0 kHz 00 Q1.25 10.0 kHz +02 Q1.25
CLASSIC 80 Hz +01 Q1.0 1.0 kHz 00 Q1.25 10.0 kHz +03 Q1.25
POP 100 Hz +02 Q1.0 1.0 kHz +01 Q1.25 10.0 kHz +02 Q1.25
HIP HOP 60 Hz +04 Q1.0 1.0 kHz –02 Q1.0 10.0 kHz +01 Q1.25
JAZZ 80 Hz +03 Q1.0 1.0 kHz 00 Q1.25 10.0 kHz +03 Q1.25
Freq.: Frequency Q: Q-slope
EN14-23_KD-APD49[J]f.indd 20EN14-23_KD-APD49[J]f.indd 20 11/1/07 3:11:50 PM11/1/07 3:11:50 PM
