JVC KD-AR870 User manual

ENGLISH
ESPAÑOL
FRANÇAIS
CD RECEIVER KD-AR870/KD-G820
RECEPTOR CON CD KD-AR870/KD-G820
RECEPTEUR CD KD-AR870/KD-G820
For canceling the display demonstration, see page 8.
Para cancelar la demostración en pantalla, consulte la página 8.
Pour annuler la démonstration des affichages, référez-vous à la page 8.
For installation and connections, refer to the separate manual.
Para la instalación y las cone iones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet.
Retain this information
for future reference.
Model No.
Serial No.
GET0359-001A
[J]
Cover_KD-AR870_820[J]1.indd 2Cover_KD-AR870_820[J]1.indd 2 5/12/05 4:54:26 pm5/12/05 4:54:26 pm

2
ENGLISH
How to forcibly eject a disc
“Please Eject” appears on the display.
• If this does not work, reset your unit.
• Be careful not to drop the disc when it ejects.
How to reset your unit
Your preset adjustments will also be erased.
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your co plete understanding and to
obtain the best possible perfor ance fro the unit.
INFORMATION (For U.S.A.
This equip ent has been tested and found to co ply with the li its for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These li its are designed to provide reasonable protection
against har ful interference in a residential installation. This equip ent generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
ay cause har ful interference to radio co unications. However, there is no guarantee that
interference will not occur in a particular installation. If this equip ent does cause har ful
interference to radio or television reception, which can be deter ined by turning the equip ent
off and on, the user is encouraged to try to correct the interference by one or ore of the
following easures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equip ent and receiver.
– Connect the equip ent into an outlet on a circuit different fro that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to bea .
Caution:
Changes or odifications not approved by JVC could void the user ’s authority to operate the
equip ent.
EN02-07KD-AR870G820[J]2.indd 2EN02-07KD-AR870G820[J]2.indd 2 9/12/05 4:38:38 pm9/12/05 4:38:38 pm

ENGLISH
3
CONTENTS
Control panel — KD-AR870 and KD-G820 ....... 5
Remote controller — RM-RK50 ................. 6
Getting started ................................. 7
Basic operations ................................................... 7
Radio operations ..............................
Disc/USB memory operations ............. 11
Playing a disc in the unit ...................................... 11
Playing discs in the CD changer ............................ 11
Playing a USB memory ......................................... 12
Sound adjustments ........................... 16
General settings — PSM ................... 18
Title assignment ............................... 27
Satellite radio operations .................. 28
iPod®/D. player operations ................ 32
Other external component
operations .................................... 34
More about this unit ......................... 35
Maintenance .................................... 3
Troubleshooting ............................... 40
Specifications ................................... 45
For safety...
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• Stop the car before performing any
complicated operations.
Temperature inside the car...
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in
the car becomes normal before operating the
unit.
How to use the MODE/SEL button
If you use MOD or S L (select), the display
and some controls (such as the number buttons,
4/¢ buttons, 5/∞ buttons, and the
control dial) enter the corresponding control
mode.
x.: When you press number button 1 after
pressing MOD , to operate the FM
tuner.
Works as time countdown indicator.
To use these controls for original functions
again, wait for 15 seconds without pressing any
of these buttons until the control is cleared.
• Pressing MOD again also restores original
functions. However, pressing S L makes the
unit enters a different mode.
EN02-07KD-AR870G820[J]2.indd 3EN02-07KD-AR870G820[J]2.indd 3 9/12/05 10:55:07 am9/12/05 10:55:07 am

4
ENGLISH
How to read this manual
• Button operations are ainly explained with
the illustrations in the table below.
• So e related tips and notes are explained in
“More about this unit” (see pages 35 – 38).
Press briefly.
Press repeatedly.
Press either
one.
Press and hold until your
desired response begins.
Press and hold both
buttons at the sa e ti e.
The following arks are used to indicate...
: Built-in CD player operations.
: External CD changer operations.
: External USB e ory operations.
Caution:
If the te perature inside the car is below
0°C, the ove ent of ani ation and text
scroll will be halted on the display to prevent
the display fro being blurred.
appears on the display.
When the te perature increases, and the
operating te perature is resu ed, these
functions will start working again.
Warning:
If you need to operate the unit while driving,
be sure to look ahead carefully or you ay be
involved in a traffic accident.
Caution on volume setting:
Discs produce very little noise co pared
with other sources. Lower the volu e
before playing a disc to avoid da aging
the speakers by the sudden increase of the
output level.
EN02-07KD-AR870G820[J]1.indd 4EN02-07KD-AR870G820[J]1.indd 4 5/12/05 4:52:28 pm5/12/05 4:52:28 pm

ENGLISH
5
1 BAND button
2 • Control dial
• (standby/on attenuator) button
3 DISP (display) button
4 Remote sensor
• DO NOT expose the remote sensor to
strong light (direct sunlight or artificial
lighting).
5 Display window
6 5 (up) / ∞ (down) buttons
Parts i entification
Control panel — KD-AR870 and KD-G820
7 EQ (equalizer) button
8 0 (eject) button
9 USB (Universal Serial Bus) input terminal
p SRC (source) button
q (control panel release) button
w SEL (select) button
e MODE button
r Number buttons
t 4/¢ buttons
How to etach/attach the control panel
Detaching... Attaching...
CAUTION:
The lever comes out if you pressed the 0 button while
the panel is detached If this happens, push the lever back
into lock position before attaching the panel
ever
EN02-07KD-AR870G820[J]2.indd 5EN02-07KD-AR870G820[J]2.indd 5 9/12/05 9:50:35 am9/12/05 9:50:35 am

6
ENGLISH
Caution:
Main elements and features
1 (standby/on/attenuator) button
• Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
2 5 U (up) / D (down) ∞ buttons
• Changes the FM/AM bands with 5 U.
• Changes the preset stations with D ∞.
• Changes the folder of the MP3/WMA/
USB.
• While playing an MP3 disc on an
MP3-co patible CD changer:
– Changes the disc if pressed briefly.
– Changes the folder if pressed and held.
• While listening to the satellite (SIRIUS or
XM) radio:
– Changes the categories.
Remote controller — RM-RK50
Installing the lithium coin battery
(CR2025
Aim the remote controller directly at the
remote sensor on the unit. Make sure there is
no obstacle in between.
Warning:
• Do not install any battery other than
CR2025 or its equivalent; otherwise, it ay
explode.
• Store the battery in a place where children
cannot reach to avoid risk of accident.
• To prevent the battery fro over-heating,
cracking, or starting a fire:
– Do not recharge, short, disasse ble,
heat the battery, or dispose of it in a fire.
– Do not leave the battery with other
etallic aterials.
– Do not poke the battery with tweezers or
si ilar tools.
– Wrap the battery with tape and insulate
when throwing away or saving it.
EN02-07KD-AR870G820[J]1.indd 6EN02-07KD-AR870G820[J]1.indd 6 5/12/05 4:52:30 pm5/12/05 4:52:30 pm

ENGLISH
7
Getting started
Basic operations
~ Turn on the power.
Ÿ
*1 Only for KD-AR870.
*2 You cannot select these sources if they
are not ready or not connected.
!
• For FM/AM tuner
• For S R US tuner
• For XM tuner
⁄ Adjust the volume.
@ Adjust the sound as you want. (See
pages 16 – 18.)
• While listening to an Apple iPod® or a
JVC D. player:
– Pauses/stops or resu es playback with
D ∞.
– Enters the ain enu with 5 U. (Now
5 U/D ∞/2 R/F 3 work as the enu
selecting buttons.)*
3 VOL – / VOL + buttons
• Adjusts the volu e level.
4 SOUND button
• Selects the sound ode (i-EQ: intelligent
equalizer).
5 SOURCE button
• Selects the source.
6 2 R (reverse) / F (forward) 3 buttons
• Searches for stations if pressed briefly.
• Fast-forwards or reverses the track if
pressed and held.
• Changes the tracks if pressed briefly.
• While listening to the satellite radio:
– Changes the channels if pressed briefly.
– Changes the channels rapidly if pressed
and held.
• While listening to an iPod or a D. player
(in enu selecting ode):
– Selects an ite if pressed briefly. (Then,
press D ∞ to confir the selection.)
– Skips 10 ite s at a ti e if pressed and
held.
* 5 U: Returns to the previous menu.
D ∞: Confirms the selection.
Continued on next page...
EN02-07KD-AR870G820[J]1.indd 7EN02-07KD-AR870G820[J]1.indd 7 5/12/05 4:52:31 pm5/12/05 4:52:31 pm

8
ENGLISH
To check the current clock time when the
power is turned off
Changing the display pattern
Ex.: When tuner is selected as the source
Source operation display
“SMALL” (CD jac et image) graphic*1 is displayed.
“LARGE” (full display size) graphic*1 is displayed.
Audio level meter is displayed (see “LevelMeter” on page 19).
Goes bac to the initial display pattern.
*1 You can use your edited file for graphic screen
(see pages 22 – 25).
Depending on a downloaded file, it may take
a longer time to show it on the display.
*2 The information ar will disappear if no
operation is performed for five seconds.
To drop the volume in a moment (ATT)
To restore the sound, press it
again.
To turn off the power
Basic settings
• See also “General settings — PSM” on pages
18 – 21.
1
2-1 Canceling the display
demonstrations
Turn the control dial to set “ emo/Link”
to “Off.”
2-2 Setting the clock
1 Press number button 4 ( ).
“Clock Hr” (hour) appears. Then,
turn the control dial to adjust the
hour.
2 Press ¢ to select “Clock Min”
(minute). Then, turn the control
dial to adjust the minute.
3 Press ¢ to select “24H/12H.”
Then, turn the control dial to select
“12Hours” or “24Hours,” time
display mode.
3 Exit from the setting.
*2
EN08-15KD-AR870G820[J]f.indd 8EN08-15KD-AR870G820[J]f.indd 8 20/12/05 3:44:53 pm20/12/05 3:44:53 pm

9
ENGLISH
When an FM stereo roadcast is hard to
receive
1
2
3 Exit from the setting.
lights up on the display.
Reception improves, but stereo effect will
be lost.
To restore the stereo effect, select “Mono Off”
in step 2. goes off.
Storing stations in memory
You can preset six stations for each band.
FM station automatic presetting —
SSM (Strong-station Sequential
Memory)
1 Select the FM band (FM1 FM3) you
want to store into.
2
Radio operations
~
Ÿ
! Start searching for a station.
When a station is received, searching
stops.
• When receiving an FM stereo broadcast
with sufficient signal strength,
lights up on the display.
To stop searching, press the same button
again.
To tune in to a station manually
In step ! above...
1
2 Select a desired station frequency.
Continued on next page...
EN08-15KD-AR870G820[J]1.indd 9EN08-15KD-AR870G820[J]1.indd 9 5/12/05 4:52:47 pm5/12/05 4:52:47 pm

10
ENGLISH
3 Select “SSM.”
4
Local FM stations with the strongest signals are
searched and stored automatically in the FM
band.
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset
number 4 of the FM1 band.
Using the num er uttons
1
2
3
Using the Preset Station List
• When appears on the display, you can
move back to the previous display by pressing
number button 3.
1 Follow steps 1 and 2 on left column.
• By holding 5 / ∞, the Preset Station List
will appear (go to step 4 below).
2
3 Display the Preset Station List.
4 Select the preset number you want to
store into.
• You can move to the lists of the other FM
bands by pressing number button 5
() or 6 ( ) repeatedly.
5 Store the station.
EN08-15KD-AR870G820[J]1.indd 10EN08-15KD-AR870G820[J]1.indd 10 5/12/05 4:52:48 pm5/12/05 4:52:48 pm

11
ENGLISH
Listening to a preset station
Using the num er uttons
1
2 Select the preset station (1 6) you
want to listen to.
or
Using the Preset Station List
1 Display the Preset Station List, then
select the preset station you want to
listen to.
2 Change to the selected station.
Disc/USB memory
operations
Playing a disc in the unit
All tracks will be played repeatedly until you
change the source or eject the disc.
To stop play ack and eject the disc
Playing discs in the CD changer
All discs in the magazine will be played
repeatedly until you change the source.
• Ejecting the magazine will also stop playback.
~
* If you have changed the external input
setting to “Ext In” (see page 21), you
cannot select the CD changer.
Ÿ Select a disc.
For disc number from 01 – 06:
For disc number from 07 – 12:
EN08-15KD-AR870G820[J]1.indd 11EN08-15KD-AR870G820[J]1.indd 11 5/12/05 4:52:51 pm5/12/05 4:52:51 pm

12
ENGLISH
Track and folder information (CD/CD Text/
MP3/WMA/USB)
Once you insert a disc or attach a USB
memory, the total track number/total
playing time (for C /C Text) and total
folder number/total track number (for MP3/
WMA/USB) appears, then the following
information appears...
Ex.: When “CD-CH” is selected as the source
• For the audio C or C Text:
Disc name*4 and Trac name*5
• For the MP3/WMA/USB:
Folder name and File name, or
Album/performer*6 and Trac name*6
• When playing C changer, the total
numbers will not appear.
*1 isplayed only when an MP3/WMA
track is played back.
*2 isplayed only when “C -CH” is selected
as the source.
*3 Either MP3 or WMA indicator lights up
depending on the detected file.
*4 Appears only for C Texts and C s if
it has been recorded or assigned. (“No
Name” appears if no name is recorded or
assigned.)
*5 Appears only for C Texts. (“No Name”
appears if no name is recorded.)
*6 Appears only when “Tag” is set to “On”
(see page 20).
Playing a USB memory
This unit can play MP3/WMA tracks stored in a
USB memory.
All tracks in the USB memory will be played
repeatedly until you change the source.
• Removing the USB memory will also stop
playback.
~
Ÿ
If a USB memory has been attached...
Playback starts from where it has been stopped
previously.
• If a different USB memory is currently
attached, playback starts from the beginning.
To detach the USB memory, straightly pull it
out from the unit.
Cautions:
• Avoid using the USB memory if it might
hinder your safety driving.
• Make sure all the important data has been
backed up to avoid losing the data.
USB input terminal
USB memory
File type*1*3
Current disc number*2
Current folder number*1
Current trac number
Elapsed playing time
EN08-15KD-AR870G820[J]1.indd 12EN08-15KD-AR870G820[J]1.indd 12 5/12/05 4:52:52 pm5/12/05 4:52:52 pm

13
ENGLISH
A out MP3 and WMA tracks
MP3 and WMA “tracks” (words “file” and
“track” are used interchangeably) are recorded
in “folders.”
When an MP3/WMA folder in an MP3/
WMA disc includes an image <jtw> file
edited by Image Converter (Ver 3.0)—
supplied in the C -ROM, you can show the
image on the display while the tracks in the
folder are played back—Image Link. (See
pages 19 and 37 for details.)
A out the CD changer
It is recommended to use a JVC MP3-
compatible C changer with your unit.
• You can also connect MP3-incompatible
C changers. These units, however, are not
compatible with MP3 discs.
• You cannot use the CH-X99, CH-X100, and
K -MK series C changers with this unit.
• You cannot play any WMA disc in the C
changer.
• isc text information recorded in the C
Text can be displayed when a JVC C Text
compatible C changer is connected.
• For connection, see Installation/Connection
Manual (separate volume).
To fast-forward or reverse the track
To go to the next or previous tracks
To go to the next or previous folders (only for
MP3/WMA/USB)
For MP3 tracks:
For WMA tracks:
For the main unit:
• Holding either of the buttons can display the
Folder List (see page 14).
For C changer:
• Holding either of the buttons can display the
isc List (see page 14).
To locate a particular track (for CD) or folder
(for MP3/WMA/USB) directly
To select a number from 01 – 06:
To select a number from 07 – 12:
• To use direct folder access on MP3/WMA/
USB, it is required that folders are assigned
with 2-digit numbers at the beginning of their
folder names—01, 02, 03, and so on.
To select a particular track in a folder (for
MP3/WMA/USB):
EN08-15KD-AR870G820[J]1.indd 13EN08-15KD-AR870G820[J]1.indd 13 5/12/05 4:52:55 pm5/12/05 4:52:55 pm

14
ENGLISH
5 Change to the selected item.
• The list disappears and playback starts.
Skipping tracks quickly during play
Only possible on JVC
MP3-compatible CD changer
• For MP3/WMA/USB, yo can skip tracks
within the same folder.
Ex.: To select track 32 while playing a track
whose n mber is a single digit (1 to 9).
1
2
Each time yo press the b tton, yo can
skip 10 tracks.
• After the last track, the first track will be
selected and vice versa.
3
Other main unctions
Selecting a disc/ older/track on the list
• When appears on the display, yo can
move back to the previo s display by pressing
n mber b tton 3.
1
2 Select “LIST.”
3 Select the list type.
*1 Selectable only when the source is
“CD-CH.”
*2 Selectable only when the media is MP3,
WM , or USB.
4 Select an item.
EX.: When “File” is selected in step 3
• Yo can move to the other lists by
pressing n mber b tton 5 ( ) or
6 ( ) repeatedly.
EN08-15KD-AR870G820[J]f.indd 14EN08-15KD-AR870G820[J]f.indd 14 12/28/05 7:29:59 PM12/28/05 7:29:59 PM

15
ENGLISH
Prohibiting disc ejection
You can lock a disc in the loading slot.
• “No Eject” appears on the display.
To cancel the prohibition, repeat the same
procedure.
• “Eject OK” appears on the display.
Selecting the playback modes
You can use only one of the following play ack
modes at a time.
1
2 Select your desired playback mode.
7 Intro play
Mode Plays beginning 15 seconds of...
Track: All tracks of the current disc or
USB memory [ ].
Folder*1: First tracks of all folders
[].
Disc*2: First tracks of all the inserted
discs [ ].
Off: Cancels.
7 Repeat play
Mode Plays repeatedly
Track: The current track [ ].
Folder*1: All tracks of the current folder
[].
Disc*2: All tracks of the current disc
[].
Off: Cancels.
7 Random play
Mode Plays at random
Folder*1: All tracks of the current folder,
then tracks of the next folder
and so on [ ].
Disc *3 : All tracks of the current disc
[].
All*4: All tracks of the inserted discs
or USB memory [ ].
Off: Cancels.
*1 Only while playing a media (MP3/WMA/
USB).
*2 Only while playing discs in the C
changer.
*3 Only while playing a disc.
*
4 Only while playing discs in the C
changer or playing a USB memory.
• You can also cancel the play ack mode y
pressing num er utton 4 ( ) in step 2.
EN08-15KD-AR870G820[J]f.indd 15EN08-15KD-AR870G820[J]f.indd 15 20/12/05 3:45:46 pm20/12/05 3:45:46 pm

16
ENGLISH
Sound adjustments
Adjusting the sound
You can adjust the sound characteristics to your
preference.
• When appears on the display, you can
move back to the previous display by pressing
number button 3.
1
2
• For “EQ” setting, see the following.
3 Adjust the selected setting item.
A Fad/Bal (Fader/Balance)
1 Press number button 1 ) to
move to the “Fad/Bal” adjustment
display.
2 Adjust the speaker output balance
by pressing:
5 / ∞: between the front and rear
speakers. [F06 to R06]
4/¢ :
between the left and right
speakers. [L06 to R06]
B Subwoofer
1 Press number button 1 ) to
move to the “Subwoofer” adjustment
display.
2 Use 4/¢ to select a
cutoff frequency to the subwoofer.
• 80Hz: Frequencies higher than
80 Hz are cut off.
• 120Hz: Frequencies higher than
120 Hz are cut off.
• 160Hz: Frequencies higher than
160 Hz are cut off.
3 Turn the control dial to adjust the
subwoofer output level. [0 to 8]
C VolAdjust
Turn the control dial to adjust the input
level of each source except FM).
[–5 to +5]
Adjust to match the input level of the
FM sound level.
• Before making an adjustment, select a
source you want to adjust.
D Loudness
Turn the control dial to activate or
deactivate the loudness to produce a
well-balanced sound at low volume
levels. [Off or On]
4 Exit from the setting.
Selecting preset sound modes
(i-EQ: intelligent equalizer)
You can select a preset sound mode suitable to
the music genre.
Available sound modes
FLAT No sound mode is applied), H.RO K
Hard rock), R & B Rhythm & blues),
POP, JAZZ, DAN E, OUNTRY, REGGAE,
LASSI , USER 1, USER 2, USER 3
EN16-27KD-AR870G820[J]2.indd 16EN16-27KD-AR870G820[J]2.indd 16 17/12/05 2:55:04 pm17/12/05 2:55:04 pm

ENGLISH
17
Storing your own sound modes
You can adjust the sound modes and store your
own adjustments in memory.
• When appears on the display, you can
move back to the previous display by pressing
number button 3.
1
or
Follow steps 1 and 2 on page 16.
• In step 2, select “ Q.”
2 Select a sound mode.
To display the rest
3 Select a frequency range.
4 Adjust the sound elements of the
selected frequency range.
1 Use 5 / ∞ to adjust the level.
2 Press number button 2 ( ),
then turn the control dial to select the
frequency.
3 Press number button 2 ( ), then
turn the control dial to select the band
width.
Sound
elements
Range/selectable items
Low Mid High
Level –06 to
+06
–06 to
+06
–06 to
+06
FR Q
(Frequency)
60 Hz
80 Hz
100 Hz
200 Hz
500 Hz
1 kHz
1.5kHz
2.5kHz
10 kHz
12.5kHz
15 kHz
17.5kHz
Q (Band
width)
Q1.0
Q1.25
Q1.5
Q2.0
Q0.5
Q0.75
Q1.0
Q1.25
Fix
5 Repeat steps 3 and 4 to adjust other
frequency ranges.
6 Store the adjustments.
EN16-27KD-AR870G820[J]f.indd 17EN16-27KD-AR870G820[J]f.indd 17 20/12/05 3:49:36 pm20/12/05 3:49:36 pm

18
ENGLISH
The list below shows the preset value setting for each sound mode:
Sound
modes
Preset values
Low Mid High
Level FREQ
(Fre uency)
Q (Band
width)
Level FREQ
(Fre uency)
Q (Band
width)
Level FREQ
(Fre uency)
Q (Band
width)
FLAT 00 60 Hz Q1.25 00 1 kHz Q1.25 00 10 kHz
Fix
H.ROCK +03 100 Hz Q1.0 00 1 kHz Q1.25 +02 10 kHz
R & B +03 80 Hz Q1.25 +01 1 kHz Q1.25 +03 15 kHz
POP +02 100 Hz Q1.25 +01 1 kHz Q1.25 +02 10 kHz
JAZZ +03 80 Hz Q1.25 00 1 kHz Q1.25 +03 10 kHz
DANC +04 60 Hz Q1.0 -02 1 kHz Q1.0 +01 10 kHz
COUNTRY +02 60 Hz Q1.0 00 1 kHz Q1.0 +02 12.5kHz
R GGA +03 60 Hz Q1.25 +02 1 kHz Q1.25 +02 12.5kHz
CLASSIC +01 80 Hz Q1.25 00 1 kHz Q1.25 +03 10 kHz
General settings — PSM
Basic procedure
You can change PSM (Preferred Setting Mode)
items listed (except “Sirius ID”) in the table that
follows.
1
An item previously selected appears on the
display.
2 Select a PSM category.
To display the rest
3 Select a PSM item.
• By pressing either of the buttons
repeatedly, you can also move to the item
of the other categories.
4 Adjust the selected PSM item.
5 Repeat steps 2 to 4 to adjust other
PSM items if necessary.
6 xit from the setting.
EN16-27KD-AR870G820[J]f.indd 18EN16-27KD-AR870G820[J]f.indd 18 20/12/05 3:49:39 pm20/12/05 3:49:39 pm

ENGLISH
19
Category Indications Selectable settings, [reference page]
MOVIE
Demo/Link
Display
demonstration
Demo: [Initial]; Display demonstration will be
activated automatically, [8].
Image Link: To show a still image while playing MP /
WMA tracks, [1 , 7].
Off: Cancels.
• Still image appears if no operation is done for about
20 seconds.
LevelMeter
Audio level meter
You can select the different level meter patterns.
Meter 1 [Initial] O Meter 2
• Press DISP repeatedly to show the selected level meter.
Pict
Pictures
Download: [Initial]; Download files, [22].
Set: Activate the stored files, [25]
Delete: Delete the stored files, [2 ].
CLOCK
Clock Hr
Hour adjustment
1 – 12AM/1 – 12PM ( – 23), [8]
[Initial: 1 (1:00AM)]
Clock Min
Minute adjustment
– 59, [8]
[Initial: 00 (1:00AM)]
24H/12H
Time display mode
12Hours – 24Hours, [8]
[Initial: 12Hours]
Clock Adj*1
Automatic clock
adjustment
Auto: [Initial]; The built-in clock is automatically
adjusted using the clock data provided via
the satellite radio channel.
Off: Cancels.
Time Zone*1*2
Time zone
Select your residential area from one of the following time
zones for clock adjustment.
Eastern [Initial] O Atlantic O Newfndlnd (Newfoundland)
O Alaska O Pacific O Mountain O Central O (back to
the beginning)
DST*1*2
Daylight saving time
Activate this if your residential area is subject to DST.
On: [Initial]; Activates daylight savings time.
Off: Cancels.
DISPL Y
Scroll
Scroll
Once: [Initial]; Scrolls the track information once.
Auto: Repeats scrolling (5-second intervals).
Off: Cancels.
• Pressing DISP for more than one second can scroll the
display regardless of the setting.
*1 Displayed only when SI IUS Satellite radio or XM Satellite radio is connected.
*2 Adjustable only when “Clock Adj” is set to “Auto.” Press number button 1 ( ) to show the
setting display.
Continued on next page...
EN16-27KD-AR870G820[J]f.indd 19EN16-27KD-AR870G820[J]f.indd 19 12/28/05 6:46:11 PM12/28/05 6:46:11 PM

20
ENGLISH
Category Indications Selectable settings, [reference page]
DISPLAY
Dimmer
Dimmer
From – To*3:
Auto: [Initial]; Dims the display when you turn on
the headlights.
Off: Cancels.
On: Activates dimmer.
Time Set: Set the timer for dimmer, [25].
Any hour – Any hour
[Initial: 6PM – 7AM]
ontrast
Contrast
1 – 10: [Initial: 5]; Adjust the display contrast to
make the display indications clear and
legible.
L D Type
Display type
Negative: [Initial]; Negative pattern of the display
except still images and animation).
Auto: Positive pattern will be selected during the
day time*4; while negative pattern will be
used during the night time*4.
Positive: Positive pattern of the display.
Font Type
Font type
You can select the font type used on the display.
1 [Initial] O 2
Tag
Tag display
On: [Initial]; Shows the Tag information display
while playing MP3/WMA tracks, [12].
Off: Cancels.
TUNER
IF Band
Intermediate
frequency filter
Auto: [Initial]; Increases the tuner selectivity to
reduce interference noises between close
stations. Stereo effect may be lost.)
Wide: Subject to the interference noises from
adjacent stations, but sound quality will
not be degraded and the stereo effect will
remain.
Area hange
Tuner channel
interval
US [Initial]; When using in North/Central/
South America. AM/FM intervals are set to
10 kHz/200 kHz.
SA When using in South American countries
where FM interval is 100 kHz. AM interval is
set to 10 kHz.
EU When using in any other areas. AM/FM
intervals are set to 9 kHz/50 kHz 100 kHz
during auto search).
Sirius ID*5
SIRIUS ID
The 12-digits SIRIUS identification number appears on the
display, [28].
EN16-27KD-AR870G820[J]1.indd 20EN16-27KD-AR870G820[J]1.indd 20 5/12/05 4:53:31 pm5/12/05 4:53:31 pm
