JVC KD-G611 Administrator Guide

SCHEMATIC DIAGRAMS
No.MA148SCH
2005/2
COPYRIGHT 2005 Victor Company of Japan, Limited.
KD-G611,KD-G612
KD-G617
Area suffix
E ------------ Southern Europe
EX ------------ Northern Europe
EY ------------- Eastern Europe
KD-G612KD-G611 KD-G617
BLACK BLACKSILVER
STEERING CABLE
CONTROL PANEL
KD-G611, KD-G612
Area suffix
KD-G617
EE --------- Russian Federation
KD-G617
KD-G611/KD-G612
EU --------------------------Turkey
CD RECEIVER
CD-ROM No.SML200502
Contents
2-1
2-2
2-8
Block diagram (For E/EX/EY/EE/EU version)
Standard schematic diagrams (For E/EX/EY/EE/EU version)
Printed circuit boards (For E/EX/EY/EE/EU version)
2-9
2-10
2-16
Block diagram (For E2/EX2/EY2/EE2/EU2 version)
Standard schematic diagrams (For E2/EX2/EY2/EE2/EU2 version)
Printed circuit boards (For E2/EX2/EY2/EE2/EU2 version)

!Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
Safety precaution
!Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.

2-1
POSITION SET
SWITCH
LOAD&FEED
MOTOR
SPINDLE
MOTOR
SW1, SW2
PICK UP
PSW
SW1, SW2
CN501
IC501
CD
DRIVER
IC541
DSP
IC401
MP3& WMA
LSI
IC521
RF AMP
IC581
CD L.P.F.
IC481
DAC
VF1, VF2
VT1, VT2
MD, LD
DMO
FOO
FMO
TRO
BUS0 to 3
BUCK
CCE
RST
FE, TE
RFGC, RF
RFRP, RFDC
SEL, TEB
MP3REQ
MP3CLK
MP3DOUT
MP3DIN
MP3STBY
MP3RESET
CDRW
CN601 J601
S601 to S614
S616, S617
KEY MATRIC
KEY0
KEY1
KEY2
IC601
LCD DRIVER
LCD1
LCD DISPLAY
CN701
TU1
FM/AM
TUNER
IC701
CPU
IC161
E.VOLUME
Q781, Q782
MUTE
CIRCUIT
IC31
PLL
IC71
RDS DET
IC301
POWER
AMP.
IC901
REGULATOR
EACH BLOCK
TU.L
TU.R
DET OUT
OUTFL, OUTRL
OUTFR, OUTRR
CD.L
CD.R
A.L
A.R
FRONT LEFT (+)
FRONT LEFT (-)
FRONT RIGHT (+)
FRONT RIGHT (-)
REAR LEFT (+)
REAR LEFT (-)
REAR RIGHT (+)
REAR RIGHT (-)
COM1
COM2
COM3
S1 to S52
LCDCL
LCDDA
LCDCE
VOLDA
VOLCK
MUTE
ANT
SW1, SW2, PSW
LM0, LM1
FEED+
FEED-
SPINDLE+
SPINDLE-
VF1, VF2
VT1, VT2
LD, MD
SPINDLE+, SPINDLE-
FEED+, FEED-
TRACKING+, TRACKING-
FOCUS+, FOCUS-
SPK
BATTERY
CN901
SD/ST
MONO
SM
SQ
SEEK/STOP
MUTE
RDSCL
RDSDA
PLLCE
PLLDA
PLLCL
PLLDI
FM VT
AM VT
FM/AM OSC
KEY0 to KEY2
LCDCL
LCDDA
LCDCE
REMOCON
ENC1, ENC2
DIMOUT
IC602
REMOCON
REMOCON
BCK
LRCK
AOUT
BCK
LRCK
SDTI
AOUTL+
AOUTL-
AOUTR+
AOUTR-
DAC-CDTI
DAC-CCLK
DAC-CSN
DAC-PDN
EN601
ENCODER
D601 to D619
D645, D646
LIGHTING
DISPLAY
ENC1
ENC2
AUX.L
AUX.R
DIMOUT
FOCUS &
TRACKING
COIL
TRACKING+
TRACKING-
FOCUS+
FOCUS-
Main amplifier & CD servo control section
LCD & Key control section
IC771
EPROM
IC251
SUBWOOFER
AMP.
IC271
SUBWOOFER
SELECTOR
EPROMCK
EPROMDI
EPROMDO
CH.L
CH.R
IC801
JVC BUS
SI
SO
I/O
INT
SCK SCK
J801
CD CHANGER
CONTROL
CN251
SUB WOOFER
OUT
SI/SO
LPF1, LPF2
SUBOUT
Q321, Q331
Q341, Q351
LINE OUT
MUTING
FRONT L
FRONT R
FRONT
LINE OUT
REAR
LINE OUT
REAR L
REAR R
AUX
OUT
STEERING
CN702
STEERING
REMOTE
CABLE
ONLY USED
FOR KD-G611&KD-G612
IC702
RESET
RESET
J1
J321
Block diagram (For E/EX/EY/EE/EU version)

2-2
SHEET 1
