JVC KD-S29 User manual

CD RECEIVER / RECEPTOR CON CD / RÉCEPTEUR CD
For canceling the display demonstration, see page 4. /
Para cancelar la demostración en pantalla, consulte la página 4. /
Pour annuler la démonstration des affichages, référez-vous à la page 4.
ENGLISH
ESPAÑOL
FRANÇAIS
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
ʷʿʽʺƖʷʷʸ
ƾƿ
KD-S29
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel
séparé.
For Customer Use:
Enter below the
Model No. and Serial
No. which are located
on the top or bottom
of the cabinet. Retain
this information for
future reference.
Model No.
Serial No.

Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to
obtain the best possible performance from the unit.
For U.S.A.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
Caution:
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
In compliance with Federal Regulations, following
are reproductions of labels on, or inside the
product relating to laser product safety.
JVC KENWOOD Corporation
2967-3, ISHIKAWA-MACHI,
HACHIOJI-SHI, TOKYO, JAPAN
THIS PRODUCT COMPLIES WITH DHHS RULES
21CFR SUBCHAPTER J IN EFFECT AT DATE OF
MANUFACTURE.
Location: Bottom Plate
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit;
leave all servicing to qualified service personnel.
3. CAUTION: (For U.S.A.) Visible and/or invisible class II laser radiation when open. Do
not stare into beam.
(For Canada) Visible and/or invisible class 1M laser radiation when open. Do
not view directly with optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
[European Union only]
2|ޓENGLISH
2012/5/9ޓ10:23:59KD-S29_J_EN

Warning:
Stop the car before operating the unit.
Caution:
Adjust the volume so that you can hear sounds
outside the car. Driving with the volume too high
may cause an accident.
Avoid using the USB device if it might hinder
driving safety.
Caution on volume setting:
Digital devices (CD/USB) produce very little noise
compared with other sources. Lower the volume
before playing these digital sources to avoid
damaging the speakers by the sudden increase of
the output level.
Temperature inside the car:
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in the
car becomes normal before operating the unit.
Condensation:
When the car is air-conditioned, moisture may
collect on the laser lens. This may cause disc read
errors. In this case, remove the disc and wait for
the moisture to evaporate.
How to attach/detach the
control panel
How to reset your unit
Your preset adjustments will
also be erased.
How to forcibly eject a disc
(Hold)
Be careful not to drop the disc when it ejects.
If this does not work, reset your unit.
Contents
Preparation ............................................................ 4
Canceling the display demonstration
Setting the clock
Basic operations ................................................... 4
Radio ........................................................................ 6
CD/USB .................................................................... 7
External components ......................................... 8
Bluetooth姞 .............................................................. 8
Brightness adjustments .................................... 9
Sound adjustments ............................................. 9
Menu operations ............................................... 10
Remote controller
............................................... 12
Additional information ................................... 13
Troubleshooting ................................................ 15
Specifications ..................................................... 16
How to read this manual:
This manual mainly explains operations using
the buttons on the control panel.
< > indicates the displays on the control
panel.
[XX] indicates the initial setting of a menu
item.
Maintenance
Cleaning the unit
Wipe off the dirt on the panel with a dry silicon or
soft cloth. Failure to observe this precaution may
result in damage to the unit.
Cleaning the connector
Wipe off dirt on the connector of the unit and
panel. Use a cotton swab or cloth.
ENGLISHޓ|3
2012/5/9ޓ10:23:59KD-S29_J_EN

Canceling the display
demonstration
The display demonstration is always turned on
unless you cancel it.
(Hold)
1
(Initial setting)
2
3Select <DEMO OFF>.
4Press MENU to exit.
Setting the clock
(Hold)
1
2Select <CLOCK>.
3Select <CLOCK SET>.
4Adjust the hour.
5Adjust the minute.
6Press MENU to exit.
Basic operations
Display information
Changes the display information. (Press)
Scrolls the current display information. (Hold)
Source Display
Radio Frequency )Clock
CD/USB Album title/Artist* -Track title* -Track no./Playing time -
Track no./Clock -(back to the beginning)
*“NO NAME”appears for conventional CDs or if not recorded.
External Components (AUX) F-AUX or R-AUX)Clock
Bluetooth Audio BT AUDIO)Clock
Preparation
Preparation
4|ޓENGLISH
2012/5/9ޓ10:23:59KD-S29_J_EN

Remote controller
USB input terminal
Front AUX input jack
DO NOT expose to bright sunlight.
Remote sensor
Detaches the panel
Ejects the disc
Display windowControl dial
Loading slot
Control panel
Aim the remote controller directly at the sensor.
When you press or hold the following button(s)...
Control panel Remote
controller General function
/SOURCE —
Turns on.
Turns off. (Hold)
Press the /SOURCE button on the control panel and turn
the control dial within 2 seconds to select the source.
SOURCE Press repeatedly to select the source.
Control dial
(turn)
VOL - / + Adjusts the volume level.
— Selects items.
Control dial
(press)
)
Mutes the sound or pauses playback.
Press the button again to cancel muting or resume
playback.
— Confirms selection.
—Enters <BRIGHTNESS>menu directly. ('page 9)
Number
buttons
(1- 6)—
Selects the preset stations.
Stores the current station into the selected number button.
(Hold) ('page 6)
EQ SOUND Selects the preset sound mode. ('page 9)
—Returns to the previous menu.
Exits from the menu. (Hold)
/ / Selects a preset station. ('page 6)
Selects MP3/WMA folder. ('page 7)
/ / 
Searches for a station automatically. ('page 6)
Searches for a station manually. (Hold)
Selects track. ('page 7)
Fast-forwards or reverses track. (Hold)
Basic operations
ENGLISHޓ|5
2012/5/9ޓ10:23:59KD-S29_J_EN

Searching for a station
A
B
Select <FM> or <AM>.
Auto search. (Press)
Manual search. (Hold)
“M”flashes, then press the button repeatedly.
“ST”lights up when receiving an FM stereo broadcast with sufficient signal strength.
Storing stations in memory
Manual presetting
You can preset up to 18 stations for FM and 6
stations for AM.
While listening to a station...
(Hold)
The preset number flashes and “MEMORY”
appears. The current station is stored to the
selected number button (1 - 6).
- - - - - - - - or - - - - - - - -
(Hold)
“PRESET MODE”flashes.
1
The preset number flashes and “MEMORY”
appears.
2Select preset number.
Auto presetting (FM only)
SSM (Strong-station Sequential Memory)
You can preset up to 18 stations for FM.
(Hold)
1
-<TUNER>
-<SSM>
-<SSM 01 – 06>
“SSM”flashes. When all the stations are stored,
“SSM”stops flashing.
2
To preset <SSM 07 – 12>/<SSM 13 – 18>,
repeat steps 1 and 2.
Selecting a preset station
- - - - - - - - or - - - - - - - -
You can also select a preset station using / .
Setting the Radio Timer
You can tune in to a preset station at a specific
time regardless of the current source.
(Hold)
1
-<TUNER>
-<RADIO TIMER>
-<OFF>/<ONCE>/
<DAILY>
[OFF] Cancels Radio Timer.
ONCE Activates once.
DAILY Activates daily.
2
-<FM>/<AM>
-<01>... <18>for FM/
<01>... <06>for AM
3Select the preset station.
4Set the activation time.
5Press MENU to exit.
lights up after the Radio Timer has been set.
Only one timer can be set. Setting a new timer
will override the previous setting.
The Radio Timer will not activate if the unit is
turned off or if <AM>is set to <OFF>after
selecting an AM station for the timer.
Radio
Radio
6|ޓENGLISH
2012/5/9ޓ10:23:59KD-S29_J_EN

Playing a CD/USB device
Label side
The source changes to “CD”and playback starts.
USB 2.0 cable
(not supplied)
USB input terminal
The source changes to “USB”and playback starts.
This unit can play MP3/WMA files stored in CD-R, CD-RW, and USB mass storage device (such as a USB
memory and Digital Audio Player).
Make sure all important data has been backed up. We shall bear no responsibility for any loss of data
in USB mass storage class device while using this system.
Ejected disc not removed within 15 seconds will reload automatically.
If the disc cannot be ejected, 'page 3.
Selecting a folder/track
Selects folder.
(For MP3/WMA)
Selects track. (Press)
Fast-forwards or reverses the
track. (Hold)
Selecting a track/folder from
the list
1
(For MP3/WMA)
2Select a folder.
For MP3/WMA
If the disc contains many folders or tracks, you
can fast search for desired folder or track by
turning the control dial quickly.
3Select a track.
Selecting the playback modes
You can select one of the following playback
modes at a time.
Press 1for REPEAT.
Press 2for RANDOM.
Press again to exit.
- - - - - - - - or - - - - - - - -
(Hold)
<REPEAT>)<RANDOM>
1
2
REPEAT 
RPT OFF Cancels repeat playback.
TRACK RPT Repeats current track.
FOLDER RPT * Repeats current folder.
RANDOM 
RND OFF Cancels random playback.
FOLDER RND *
Randomly plays all tracks of
current folder, then tracks of
next folders.
ALL RND Randomly plays all tracks.
* For MP3/WMA
CD/USB
CD/USB
ENGLISHޓ|7
2012/5/9ޓ10:23:59KD-S29_J_EN

For details, refer also to the instructions supplied with the external components.
Playing an external component from Front/Rear AUX
Portable audio
player, etc.
3.5 mm (1/8") stereo mini plug
(not supplied)
3.5 mm (1/8") stereo mini
plug (with“L”shaped
connector) (not supplied)
1Connect to F-AUX on the control panel
and/or R-AUX on the rear panel.
(Hold)
-<SRC SELECT>
-<F-AUX>/<R-AUX>
-<F-AUX ON>or
<R-AUX ON>
Press MENU to exit.


2Set the source as necessary.
3Select <F-AUX> or <R-AUX>.
4Turn on the connected component and
start playing the source.
Use a 3-terminal plug head stereo mini plug for optimum audio output. Otherwise, sound
may be interrupted or unclear while listening to an external component.
Bluetooth 姞
For Bluetooth operations, it is required to connect the Bluetooth adapter, KS-BTA100
(separately purchased) to the auxiliary input jack (R-AUX/BT ADAPTER) on the rear of
the unit. ('Installation/Connection Manual)
KS-BTA100 is not available in some countries. Please contact your dealer where you
purchased this unit.
Operations may be different depending on the connected Bluetooth device. For
details, refer also to the instructions supplied with the device.
Preparation
For details on registering and using the Bluetooth device, refer to the instructions manual supplied with
KS-BTA100.
1Register (pair) a Bluetooth device with KS-BTA100.
-<SRC SELECT>
-<R-AUX>
-<BT ADAPTER>
2Change the <SRC SELECT> settings of this unit.
(Hold)
3Press MENU to exit.
KS-BTA100
External components
External components
8|ޓENGLISH
2012/5/9ޓ10:23:59KD-S29_J_EN

You can select your preferred brightness for <BUTTON ZONE>,<DISP ZONE>separately.
1
BUTTON ZONE BUTTON 00 to 31
DISP ZONE DISP 00 to 31
2
3Press MENU to exit.
Sound adjustments
This unit memorizes sound settings adjusted for each individual source.
Selecting the preset sound
You can select a preset sound mode, for each
individual source, suitable for the music genre.
- - - - - - - - or - - - - - - - -
Press repeatedly.
DYNAMIC-VOCAL BOOST-BASS BOOST-
USER-FLAT-NATURAL-(back to the beginning)
Storing your own adjustments
While listening, you can adjust and store the tone
level for each individual source.
Easy Equalizer
(Hold)
1
(Initial: [XX])
SUB.W* 00 to 08 [08]
BASS LVL** -06 to +06 [+05]
MID LVL -06 to +06 [00]
TRE LVL -06 to +06 [+05]
The adjustments are stored and <USER>is
activated.
2Adjust the level.
Pro Equalizer
(Hold)
1
-<PRO EQ>
-<BASS>**/<MIDDLE>/
<TREBLE>
2
Adjust the sound elements of the selected tone.
BASS (Initial: [XX])
Frequency 60/80/[100]/200 Hz
Level LVL -06 to +06 [+05]
Q[Q1.0]/Q1.25/Q1.5/Q2.0
MIDDLE
Frequency 0.5/[1.0]/1.5/2.5 kHz
Level LVL -06 to +06 [00]
Q Q0.75/Q1.0/[Q1.25]
TREBLE
Frequency 10.0/[12.5]/15.0/17.5 kHz
Level LVL -06 to +06 [+05]
Q[Q FIX]
3
4Repeat steps 2 and 3 to adjust other tones.
The adjustments are stored and <USER>is
activated.
5Press MENU to exit.
* Available only when <L/O MODE> is set to
<SUB.W>. ('page 10)
** Available only when <HPF> is set to <OFF>.
('page 11)
Brightness adjustments
Brightness adjustments
ENGLISHޓ|9
2012/5/9ޓ10:23:59KD-S29_J_EN

(Hold)
If no operation is done for about 60 seconds, the
operation will be canceled.
1
2
3Repeat step 2 if necessary.
To return to the previous menu, press .
To exit from the menu, press DISP or MENU.
Menu item Selectable setting (Initial: [XX])
DEMO For settings, 'page 4.
CLOCK
DIMMER
DIMMER SET Selects the display and button illumination adjusted in the <BRIGHTNESS>/
<COLOR SETUP>setting.
[AUTO]: Changes between the Day and Night adjustments when you turn
off/on the car headlights. *1
ON: Selects the Night adjustments.
OFF: Selects the Day adjustments.
BRIGHTNESS DAY[31]/NIGHT[15]: Brightness settings for the display and button
illumination for day and night.
BUTTON ZONE/DISP ZONE: Sets the brightness levels 00 — 31.
DISPLAY
SCROLL *2 [ONCE]: Scrolls the display information once.
AUTO: Repeats scrolling (at 5-second intervals).
OFF: Cancels.
TAG DISPLAY [ON]: Shows the TAG information while playing MP3/WMA tracks.
OFF: Cancels.
PRO EQ For settings, 'page 9.
AUDIO
FADER *3*4 R06 — F06[00]: Adjusts the front and rear speaker output balance.
BALANCE *4 L06 — R06[00]: Adjusts the left and right speaker output balance.
LOUD
(Loudness)
ON: Boosts low and high frequencies to produce a well-balanced sound at
a low volume level.
[OFF]: Cancels.
VOL ADJUST
(Volume adjust) -05 — +05[00]: Presets the volume adjustment level of each source,
compared to the FM volume level. Before adjustment, select the source you
want to adjust. (“VOL ADJ FIX”appears if “FM”is selected.)
L/O MODE
(Line output
mode)
Select if the REAR/SW terminals are used for connecting the speakers or
subwoofer (through an external amplifier).
SUB.W: Subwoofer
[REAR]: Speakers
*1 The illumination control lead connection is required. (See “Installation/Connection Manual”.)
This setting may not work correctly on some vehicles (particularly on those having a control
dial for dimming). In this case, change the setting to other than <DIMMER AUTO>.
*2 Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*3 If you are using a two-speaker system, set the fader level to “00”.
*4 This adjustment will not affect the subwoofer output.
Menu operations
Menu operations
10 |ޓENGLISH
2012/5/9ޓ10:23:59KD-S29_J_EN

Menu item Selectable setting (Initial: [XX])
AUDIO
SUB. W *5
(Subwoofer)
OFF: Cancels.
[ON]: Turns on the subwoofer output.
SUB.W LPF *6
(Subwoofer low-
pass filter)
LOW 55Hz/MID 85Hz/[HIGH 120Hz]: Audio signals with frequencies
lower than 55 Hz/85 Hz/120 Hz are sent to the subwoofer.
SUB.W LEVEL *6
(Subwoofer level)
00 — 08[08]: Adjusts the subwoofer output level.
HPF *6
(High-pass filter)
ON: Activates the High Pass Filter. Low frequency signals are cut off from
the front/rear speakers.
[OFF]: Deactivates. (All signals are sent to the front/rear speakers.)
BEEP
(Keytouch tone)
[ON]/OFF: Activates or deactivates the keypress tone.
TEL MUTING *7
(Telephone
muting)
ON: Mutes the sounds while using the cellular phone (not connected
through KS-BTA100).
[OFF]: Cancels.
AMP GAIN
(Amplifier gain)
LOW POWER: Limits the maximum volume level to 30. (Select if the
maximum input power of each speaker is less than 50 W to prevent
damaging the speakers.)
[HIGH POWER]: The maximum volume level is 50.
TUNER
SSM For settings, 'page 6. (Displayed only when the source is “FM”.)
AREA
(Frequency
tuning interval)
[AREA US]: For North/Central/South America, AM/FM intervals: 10kHz/200kHz.
AREA EU: For any other areas, AM/FM intervals: 9kHz/50kHz.
AREA SA: For some South American countries, AM/FM intervals: 10kHz/50kHz.
MONO
(Monaural mode)
Displayed only when the source is “FM”.
[OFF]: Enables stereo FM reception.
ON: Improves the FM reception but stereo effect will be lost.
IF BAND
(Intermediate
frequency band)
[AUTO]: Increases the tuner selectivity to reduce interference noises
between adjacent stations. (Stereo effect may be lost.)
WIDE: Subject to interference noises from adjacent stations, but sound
quality will not be degraded and the stereo effect will remain.
RADIO TIMER For settings, 'page 6.
SRC SELECT
AM *8 [ON]/OFF: Enables or disables “AM”in source selection.
F-AUX *8
(Front auxiliary
input)
[ON]/OFF: Enables or disables “F-AUX”in source selection.
R-AUX *8
(Rear auxiliary
input)
ON/OFF: Enables or disables “R-AUX”in source selection.
[BT ADAPTER]: Select if the rear auxiliary input jack is connected to the
Bluetooth adapter, KS-BTA100 ('page 8). The source name will be
changed to “BT AUDIO”.
*5 Displayed only when <L/O MODE> is set to <SUB.W>.
*6 Displayed only when <SUB.W> is set to <ON>.
*7 This setting does not work if <BT ADAPTER> is selected for <R-AUX> of <SRC SELECT>.
*8 Displayed only when the unit is in any source other than the corresponding source “AM/
F-AUX/R-AUX/BT AUDIO”.
Menu operations
ENGLISHޓ|11
2012/5/9ޓ10:23:59KD-S29_J_EN

Preparing
When you use the remote controller for the first
time, pull out the insulation sheet.
Insulation sheet
For USA-California Only:
This product contains a CR Coin Cell Lithium
Battery which contains Perchlorate Material—
special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
Replacing the lithium coin
battery
If the effectiveness of the remote controller
decreases, replace the battery.
CR2025
Caution:
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
Battery shall not be exposed to excessive heat
such as sunshine, fire, or the like.
Warning:
Do not install any battery other than CR2025 or
its equivalent.
Do not leave the remote controller in places
(such as dashboards) exposed to direct
sunlight for a long time.
Store the battery in places out of reach of
children.
Do not recharge, short, disassemble, heat the
battery, or dispose of it in a fire.
Do not place the battery with other metallic
materials.
Do not poke the battery with tweezers or
similar tools.
Insulate the battery by wrapping it with tape
when disposing or storing it.
Remote controller
Remote controller
12 |ޓENGLISH
2012/5/9ޓ10:23:59KD-S29_J_EN

About discs
This unit can only play the following CDs:
This unit can play back multi-session discs;
however, unclosed sessions will be skipped
during playback.
Unplayable discs
Discs that are not round.
Discs with coloring on the recording surface or
discs that are dirty.
Recordable/ReWritable disc that has not been
finalized. (For details on disc finalization, refer
to your disc writing software and your disc
recorder instruction manual.)
8 cm (3 inch) CD. Attempting to insert using an
adapter can cause malfunction. There may also
be problems ejecting the disc if inserted.
Handling discs
Do not touch the recording surface of the disc.
Do not stick tape etc. on the disc, or use a disc
with tape stuck on it.
Do not use any accessories for the disc.
Clean from the center of the disc and move
outwards.
Clean the disc with a dry silicon or soft cloth.
Do not use any solvents.
When removing discs from this unit, pull them
out horizontally.
Remove any burrs from the center hole and
disc edge before inserting a disc.
DualDisc playback
The Non-DVD side of a “DualDisc”does not
comply with the “Compact Disc Digital Audio”
standard. Therefore, the use of Non-DVD side of a
DualDisc on this product may not be
recommended.
About audio files
Playable files
File extensions: MP3(.mp3), WMA(.wma)
Bit rate:
MP3: 8 kbps - 320 kbps
WMA: 32 kbps - 192 kbps
Sampling frequency:
MP3: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz,
22.05kHz, 16 kHz, 12 kHz, 11.025 kHz, 8 kHz
WMA: 48 kHz, 44.1 kHz, 32 kHz
Variable bit rate (VBR) files. (The elapsed time
for VBR files will not be displayed correctly.)
Unplayable files
MP3 files:
- encoded in MP3i and MP3 PRO format
- encoded in an inappropriate format
- encoded with Layer 1/2
WMA files:
- encoded in lossless, professional, and voice
format
- not based upon Windows Media® Audio
- copy-protected with DRM
Files which include data such as AIFF, ATRAC3,
etc.
Maximum number of characters
for file/folder name
Varies depending on the disc format used
(includes 4 extension characters—<.mp3> or
<.wma>).
ISO 9660 Level 1 and 2: 64 characters
Romeo: 64 characters
Joliet: 32 characters
Windows long file name: 64 characters
Others
This unit can show WMA Tag and ID3 Tag
Version 1.0/1.1/2.2/2.3/2.4 (for MP3).
The search function works but search speed is
not constant.
Additional information
Additional information
ENGLISHޓ|13
2012/5/9ޓ10:23:59KD-S29_J_EN

About USB device
When connecting a USB cable, use the USB 2.0
cable.
You cannot connect a computer or portable
HDD to the USB input terminal of the unit.
Connect only one USB device to the unit at a
time. Do not use a USB hub.
USB devices equipped with special functions
such as data security functions cannot be used
with the unit.
Do not use a USB device with 2 or more
partitions.
This unit cannot recognize a USB device whose
rating is other than 5 V and exceeds 1 A.
This unit may not recognize a memory card
inserted into the USB card reader.
This unit may not play back files in a USB
device properly when using a USB extension
cord.
Depending on the shape of the USB devices
and connection ports, some USB devices may
not be attached properly or the connection
might be loose.
Operation and power supply may not work as
intended for some USB devices.
The maximum number of characters for:
– Folder names: 63 characters
– File names: 63 characters
– MP3 Tag: 60 characters
– WMA Tag: 60 characters
This unit can recognize a total of 65 025 files,
255 folders (255 files per folder including folder
without unsupported files), and of 8
hierarchies.
Cautions
Do not pull out and attach the USB device
repeatedly while “READING”is shown on the
display.
Electrostatic shock at connecting a USB device
may cause abnormal playback of the device. In
this case, disconnect the USB device then reset
this unit and the USB device.
Do not leave a USB device in the car, expose to
direct sunlight, or high temperature. Failure to
do so may result in deformation or cause
damages to the device.
Trademark and license notice
Microsoft and Windows Media are either
registered trademarks or trademarks of
Microsoft Corporation in the United States
and/or other countries.
Additional information
14 |ޓENGLISH
2012/5/9ޓ10:23:59KD-S29_J_EN

Symptom Remedy/Cause
4General
No sound, sound interrupted or
static noise.
Check the cords, antenna and cable connections.
Check the condition of the disc, connected device and
recorded tracks.
“MISWIRING CHK WIRING THEN
RESET UNIT”/“WARNING CHK
WIRING THEN RESET UNIT”
appears on the display and no
operations can be done.
Ensure the terminals of the speaker leads are properly insulated
with tape before resetting the unit. ('page 3)
If the message does not disappear, consult your JVC car audio
dealer or kits supplying company.
The unit does not work at all. Reset the unit. ('page 3)
Source cannot be selected. Check the <SRC SELECT>setting. ('page 11)
The correct characters are not
displayed (e.g. album name).
This unit can only display letters (upper case), numbers, and a
limited number of symbols.
4FM/AM
SSM automatic presetting does
not work.
Store stations manually.
4CD/USB
“PLEASE”and “EJECT”appear
alternately on the display. Press [], then insert the disc correctly.
“IN DISC”appears on the display. The disc cannot be ejected properly. Make sure nothing is
blocking the loading slot.
“READING”keeps flashing on the
display.
A longer readout time is required. Do not use too many
hierarchical levels and folders.
Reload the disc or reattach the USB device.
Tracks/folders are not played
back in the order you have
intended.
The playback order is determined by the file name (USB) or the
order in which files were recorded (disc).
The elapsed playing time is not
correct.
This sometimes occurs during playback. This is caused by how
the tracks are recorded on the disc.
“NOT SUPPORT”appears on the
display and track skips.
Check whether the track is a playable file format.
“CANNOT PLAY”flashes on
the display.
The unit cannot detect the
connected device.
Check whether the connected device is compatible with this
unit. ('page 16)
Ensure that the device contains files in the supported
formats. ('page 13)
Reattach the device.
Troubleshooting
Troubleshooting
ENGLISHޓ|15
2012/5/9ޓ10:23:59KD-S29_J_EN

AUDIO AMPLIFIER SECTION
Power Output 20 W RMS x 4 Channels at 4Ω and
≤1% THD+N
Load Impedance 4Ω (4Ω to 8Ω allowance)
Frequency Response 40 Hz to 20 000 Hz
Signal-to-Noise Ratio 80 dBA (reference: 1 W into 4Ω)
Line-Out, Subwoofer-Out Level/Impedance 2.5 V/20 kΩ load (full scale)
Output Impedance ≤ 600Ω
TUNER SECTION
FM Frequency Range 200 kHz step: 87.9 MHz to 107.9 MHz
50 kHz step: 87.5 MHz to 108.0 MHz
Usable Sensitivity 9.3 dBf (0.8 μV/75Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 μV/75Ω)
Alternate Channel
Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 40 dB
AM Frequency Range 10 kHz step: 530 kHz to 1 700 kHz
9 kHz step: 531 kHz to 1 611 kHz
Sensitivity/Selectivity 20 μV/40 dB
CD PLAYER SECTION
Signal Detection System Non-contact optical pickup (semiconductor
laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
USB SECTION
USB Standard USB 1.1, USB 2.0
Data Transfer Rate (Full Speed) Max. 12 Mbps
Compatible Device Mass storage class
Compatible File System FAT 32/16/12
Playable Audio Format MP3/WMA
Maximum Supply Current DC 5 V "1 A
Specifications
Specifications
16 |ޓENGLISH
2012/5/9ޓ10:23:59KD-S29_J_EN

GENERAL
Power Requirement (Operating Voltage) DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C (32°F to 104°F)
Dimensions
(W × H × D)
(approx.)
Installation Size 182 mm × 52 mm × 158 mm
(7-3/16" × 2-1/16" × 6-1/4")
Panel Size 188 mm × 59 mm × 14 mm
(7-7/16" × 2-3/8" × 9/16")
Mass 1.2 kJ(2.7 lbs) (excluding accessories)
Subject to changes without notice.
Specifications
ENGLISHޓ|17
2012/5/9ޓ10:23:59KD-S29_J_EN

Muchas gracias por la compra de un producto JVC.
Como primer paso, por favor lea detenidamente este manual para comprender a fondo todas las
instrucciones y obtener un máximo disfrute de esta unidad.
Para EE.UU.
Este equipo se ha sometido a todo tipo de pruebas y cumple con las normas establecidas para
dispositivos de Clase B, de conformidad con la Parte 15 de las reglas de la FCC (Comisión Federal
de Comunicaciones). Estas reglas están diseñadas para asegurar una protección razonable contra
este tipo de interferencias en las instalaciones residenciales. Este equipo genera y utiliza energía
de radiofrecuencia. Si no se instala y utiliza debidamente, es decir, conforme a las instrucciones,
podrían producirse interferencias en radiocomunicaciones. Sin embargo, no se garantiza que
estas interferencias no se produzcan en una instalación determinada. Si este equipo ocasiona
interferencias en la recepción de radio o televisión, lo cual puede comprobarse mediante la
conexión o desconexión del equipo, el problema podrá corregirse mediante una o una
combinación de las siguientes medidas:
– Reoriente la antena receptora o cámbiela de lugar.
– Aumente la separación entre el equipo y el aparato receptor.
– Enchufe el equipo a una toma de corriente situada en un circuito distinto del aparato receptor.
– Consulte a su distribuidor o a un técnico experto en radio/televisión.
Precaución:
Los cambios o modificaciones no aprobados por la parte responsable del funcionamiento
pueden anular la autoridad del usuario para utilizar el equipo.
El uso de controles o ajustes o procedimientos de
rendimiento que no sean los que se especifican
en este documento puede causar exposiciones
peligrosas a radiación.
En cumplimiento con las normativas federales, las
siguientes etiquetas son reproducciones de las
que aparecen en el producto o en su interior,
relativas a la seguridad del producto láser.
JVC KENWOOD Corporation
2967-3, ISHIKAWA-MACHI,
HACHIOJI-SHI, TOKYO, JAPAN
THIS PRODUCT COMPLIES WITH DHHS RULES
21CFR SUBCHAPTER J IN EFFECT AT DATE OF
MANUFACTURE.
Ubicación: placa inferior
IMPORTANTE PARA PRODUCTOS LÁSER
1. PRODUCTO LÁSER CLASE 1
2. PRECAUCIÓN: No abra la tapa superior. En el interior de la unidad no hay piezas que pueda
reparar el usuario; encargue el servicio a personal técnico cualificado.
3. PRECAUCIÓN: (Para EE.UU.) Radiación láser de clase II visible y/o invisible cuando
ésta abierto. No mirar fijamente hacia el haz.
(Para Canadá) Radiación láser de clase 1M visible y/o invisible
cuando ésta abierto. No mirar directamente con
instrumental óptico.
4. REPRODUCCIÓN DE LA ETIQUETA: ETIQUETA DE PRECAUCIÓN, COLOCADA EN EL EXTERIOR DE
LA UNIDAD.
[Sólo Unión Europea]
2|ޓESPAÑOL
2012/5/17ޓ17:20:36KD-S29_J_SP

Advertencia:
Detenga el automóvil antes de operar la unidad.
Precaución:
Ajuste el volumen a un nivel que permita
escuchar el ruido del tráfico y otros sonidos
ambientales. La conducción con el volumen
demasiado alto puede causar un accidente.
Evite usar el dispositivo USB si puede amenazar la
seguridad de la conducción.
Precaución sobre el ajuste de volumen:
Los dispositivos digitales (CD/USB) producen muy
poco ruido al compararse con otras fuentes. Baje el
volumen antes de reproducir estas fuentes digitales
para evitar daños en los altavoces resultantes de un
repentino aumento del nivel de salida.
Temperatura dentro del automóvil:
Si ha dejado el automóvil estacionado durante largo
tiempo en un sitio cálido o frío, no opere la unidad
hasta que se normalice la temperatura del habitáculo.
Condensación:
Cuando se está usando el aire acondicionado, se
puede condensar humedad en la lente láser. Esto
puede ocasionar errores de lectura del disco. En
este caso, extraiga el disco y espere hasta que se
evapore la humedad.
Cómo montar/desmontar el
panel de control
Cómo reposicionar su unidad
También se borrarán los
ajustes preestablecidos por
usted.
Cómo expulsar el disco por la fuerza
(Sostener)
Tenga cuidado de no dejar caer el disco al ser
expulsado.
Si esto no funciona, intente reposicionar su receptor.
Índice
Preparativos ........................................................... 4
Cancelación de las demostraciones en
pantalla
Puesta en hora del reloj
Operaciones básicas ........................................... 4
Radio ........................................................................ 6
CD/USB .................................................................... 7
Componentes externos ..................................... 8
Bluetooth姞............................................................. 8
Ajustes de brillo ................................................... 9
Ajustes de sonido ................................................ 9
Operaciones de los menús ............................ 10
Control remoto .................................................. 12
Información adicional ..................................... 13
Localización de averías ................................... 15
Especificaciones ................................................ 16
Cómo leer este manual:
Este manual explica principalmente las
operaciones realizadas mediante los botones
del panel de control.
< > indica las pantallas del panel de control.
[XX] indica la configuración inicial de una
opción de menú.
Mantenimiento
Limpieza de la unidad
Limpie la suciedad del panel con un paño de
silicona seco o un paño suave. La negligencia en
la observación de esta precaución puede causar
daños a la unidad.
Limpieza del conector
Elimine la suciedad del conector de la unidad y
del panel. Utilice un paño o un palillo de algodón.
ESPAÑOLޓ|3
2012/5/17ޓ17:20:36KD-S29_J_SP

Cancelación de las
demostraciones en pantalla
La demostración en pantalla siempre se activa a
menos que la cancele.
(Sostener)
1
(Configuración inicial)
2
3Seleccione <DEMO OFF>.
4Pulse MENU para salir.
Puesta en hora del reloj
(Sostener)
1
2Seleccione <CLOCK>.
3Seleccione <CLOCK SET>.
4Ajuste la hora.
5Ajuste los minutos.
6Pulse MENU para salir.
Operaciones básicas
Información de pantalla
Cambia la información en pantalla. (Pulse)
Desplaza la información actual de la pantalla. (Sostener)
Fuente Pantalla
Radio Frecuencia )Reloj
CD/USB Título de álbum/Artista* -Título de pista* -N.º de pista/Tiempo de
reproducción -N.º de pista/Reloj -(vuelta al comienzo)
*“NO NAME”aparece para los CD convencionales, o en caso de que
no esté grabado.
Componentes externos
(AUX) F-AUX o R-AUX)Reloj
Audio a través de Bluetooth BT AUDIO)Reloj
Preparativos
Preparativos
4|ޓESPAÑOL
2012/5/17ޓ17:20:36KD-S29_J_SP
