JVC KS-FX460R User manual

GET0039-001A
[E]
INSTRUCTIONS
BEDIENUNGSANLEITUNG
MANUEL D’INSTRUCTIONS
GEBRUIKSAANWIJZING
KS-FX463R/KS-FX460R
CASSETTE RECEIVER
CASSETTEN-RECEIVER
RADIOCASSETTE
RADIO/CASSETTESPELER
ENGLISH
DEUTSCH
NEDERLANDS
FRANÇAIS
For installation and connections, refer to the separate manual.
Angaben zu Einbau und Verkabelung entnehmen Sie bitte der gesonderten Anleitung.
Pour l’installation et les raccordements, se référer au manuel séparé.
Zie de afzonderlijke handleiding voor details aangaande het installeren en verbinden van het
toestel.
KS-FX460R
KS-FX463R
40Wx4
CD CHANGER CONTROL
AM
CD-
CH
FM
SOUND
PTY
SSM
TP
RDS
789101112
/I ATT
MO/FIND
DISP
SEL
KS-FX463R
PROG
40Wx4
CD CHANGER CONTROL
AM
CD-
CH
FM
SOUND
PTY
SSM
PROG
TP
RDS
789101112
/I ATT
MO/FIND
DISP
SEL
KS-FX460R
COVER 03/10/2000, 06:36 PM3

2
ENGLISH
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to
ensure your complete understanding and to obtain the best possible performance from the unit.
CONTENTS
BASIC OPERATIONS....................................................3
RADIO BASIC OPERATIONS.........................................4
Listening to the radio .....................................................................4
Storing stations in memory............................................................5
Tuning into a preset station ...........................................................7
RDS OPERATIONS.......................................................8
What you can do with RDS EON ..................................................8
Other convenient RDS functions and adjustments ...................14
TAPE OPERATIONS ...................................................16
Listening to a tape ........................................................................16
SOUND ADJUSTMENTS .............................................17
Selecting preset sound modes ......................................................17
Adjusting the sound......................................................................18
Storing your own sound adjustments .........................................19
OTHER MAIN FUNCTIONS.........................................20
Setting the clock............................................................................20
Changing the general settings .....................................................22
Detaching the control panel .........................................................25
CD CHANGER OPERATIONS ......................................26
Playing CDs ...................................................................................26
Selecting CD playback modes .....................................................28
MAINTENANCE ........................................................29
To extend the lifetime of the unit.................................................29
TROUBLESHOOTING .................................................30
SPECIFICATIONS .......................................................31
BEFORE USE
★For safety....
• Do not raise the volume level too much, as this
will block outside sounds, making driving
dangerous.
• Stop the car before performing any complicated
operations.
★Temperature inside the car....
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in the
car becomes normal before operating the unit.
Note:
For security reasons, a numbered ID card is provided with this unit, and the same ID number is
imprinted on the unit’s chassis. Keep the card in a safe place, as it will help the authorities to
identify your unit if stolen.
EN02-03.KS-FX463-460[E]/f 04/10/2000, 07:11 PM2

ENGLISH
3
BASIC OPERATIONS
Turn on the power.
Adjust the volume.
Adjust the sound as you want (see pages 17 – 19).
1
2
Play the source.
To operate the tuner, see pages 4 – 15.
To operate the tape deck, see page 16.
To operate the CD changer, see pages 26 – 28.
3
4
To drop the volume in a moment
Press briefly while listening to any source.“ATT”starts flashing on the display, and
the volume level will drop in a moment.
To resume the previous volume level, press the button briefly again.
To turn off the power
Press for more than 1 second.
1
3
2
AM
FM
CD –CH
Note:
When you use this unit for the first time, set the built-in clock correctly, see page 20.
/ I /ATT
Volume level appears
Note on One-Touch Operation:
• When you select tuner as a source in step 2 below, the power automatically
comes on. You do not have to press this button to turn on the power.
• If the cassette is already in the cassette compartment, tape play starts
automatically. However, it is not recommended to leave the cassette in the
compartment when turning off the power or ignition key. It may damage the
tape head and the cassette.
EN02-03.KS-FX463-460[E]/f 04/10/2000, 07:11 PM3

4
ENGLISH
RADIO BASIC OPERATIONS
Listening to the radio
2
AM
FM
FM1 FM2
FM3
AM
1
Note on One-Touch Operation:
When you select a band in step 2 below, the power automatically comes on. You
do not have to press this button to turn on the power.
2
1
3
Turn on the power.
Select the band (FM1, FM2, FM3 or AM).
You can select any one of FM1, FM2, and FM3
to listen to an FM station.
Note:
When a cassette is in the cassette compartment, you cannot select the tuner. Be sure to eject the cassette
from the cassette compartment to listen to the radio.
3
To stop searching before a station is received, press the same button you have pressed
for searching.
To tune in a particular frequency manually:
1Select the band (FM or AM).
Press FM or AM.
2Press and hold ¢or 4until “M” starts flashing on the display.
Now you can manually change the frequency while “M” is flashing.
3Press ¢or 4repeatedly until the frequency you want is reached.
• If you hold down the button, the frequency keeps changing (in 50 kHz intervals for FM and
9 kHz intervals for AM — MW/LW) until you release the button.
Start searching a station.
When a station is received, searching stops.
SSM
To search stations of lower frequencies.
/ I /ATT
To search stations of higher frequencies.
EN04-07KS-FX463/460[E] 03/10/2000, 06:29 PM4

ENGLISH
5
Storing stations in memory
You can use one of the following two methods to store broadcasting stations in memory.
•Automatic preset of FM stations: SSM (Strong-station Sequential Memory)
•Manual preset of both FM and AM stations
FM station automatic preset: SSM
You can preset 6 local FM stations in each FM band (FM1, FM2, and FM3).
1
Select the FM band number (FM1, FM2
or FM3) you want to store FM stations
into.
FM1 FM2 FM3
FM
2
Press and hold both buttons for more than
2 seconds.
Local FM stations with the strongest signals are searched and stored automatically in the
band number you have selected (FM1, FM2 or FM3).These stations are preset in the number
buttons —No.1 (lowest frequency) to No. 6 (highest frequency).
When automatic preset is over, the station stored in number button 1 will be automatically
tuned in.
21
“SSM”appears, then disappears when automatic preset is over.
SSM
EN04-07KS-FX463/460[E] 03/10/2000, 06:29 PM5

6
ENGLISH
Manual preset
You can preset up to 6 stations in each band (FM1, FM2, FM3 and AM) manually.
EXAMPLE: Storing an FM station of 88.3 MHz into preset number 1 of the FM1 band
FM
Repeat the above procedure to store other stations into other
preset numbers.
Notes:
• A previously preset station is erased when a new station is stored in the same preset number.
• Preset stations are erased when the power supply to the memory circuit is interrupted (for example,
during battery replacement). If this occurs, preset the stations again.
SSM
1
Select the FM1 band.
2
Tune into a station of 88.3 MHz.
See page 4 to tune into a station.
3
4
21 3
Press and hold the button for more than 2
seconds.
“P1”flashes for a few seconds.
EN04-07KS-FX463/460[E] 03/10/2000, 06:29 PM6

ENGLISH
7
Tuning into a preset station
You can easily tune into a preset station.
Remember that you must store stations first. If you have not stored them yet, see pages 5
and 6.
1 Select the band (FM1, FM2, FM3
or AM) you want.
2
Selectthenumber(1–6)forthepresetstation
you want.
To change the display information while receiving an FM RDS
station
Press DISP. Each time you press the button, the display changes as follows:
AM
FM
FM1 FM2
FM3
AM
21
MO/RND
DISP
When an FM stereo broadcast is hard to receive:
PressMO/RND(mono/random)whilelisteningto anFMstereo broadcast.TheMO(mono)
indicator lights up on the display.The sound you hear becomes monaural but reception
will be improved.
To restore the stereo effect, press the button again.
MO/RND
Lights up when receiving an FM broadcast in stereo.
PS NAME (Station name)
PTY (Programme type)
FREQ (Station frequency)
CLOCK (Clock time)
EN04-07KS-FX463/460[E] 03/10/2000, 06:29 PM7

8
ENGLISH
What you can do with RDS EON
RDS (Radio Data System) allows FM stations to send an additional signal along with their
regular programme signals. For example, the station send their station names, as well as
information about what type of programme they broadcast, such as sports or music, etc.
Another advantage of RDS function is called “EON (Enhanced Other Networks).” The EON
indicator lights up while receiving an FM station with the EON data. By using the EON data
sent from a station, you can tune into a different station of a different network broadcasting
your favorite programme or traffic announcement while listening to another programme or to
another source such as tape.
By receiving the RDS data, this unit can do the following:
• Tracing the same programme automatically (Network-Tracking Reception)
• Standby Reception ofTA (Traffic Announcement) or your favorite programme
• PTY (Programme Type) search
• TP (Traffic Programme) search
• And some other functions
Tracing the same programme automatically (Network-
Tracking Reception)
Whendrivinginan areawhereFM receptionisnotgood,the tunerbuiltin thisunit automatically
tune in another RDS station, broadcasting the same programme with stronger signals. So,
you can continue to listen to the same programme in its finest reception, no matter where you
drive. (See the illustration on the next page.)
Two types of the RDS data are used to make Network-Tracking Reception work correctly —
PI (Programme Identification) and AF (Alternative Frequency).
Without receiving these data correctly from the RDS station you are listening to, Network-
Tracking Reception will not operate.
To use Network-Tracking Reception, press and holdTP/RDS
(TrafficProgramme/RadioData System) for morethan 1 second.
Each time you press and hold the button, Network-Tracking
Reception modes change as follows:
RDS OPERATIONS
TP
RDS
Mode 1 Mode 2 Mode 3
EN08-15KS-FX463/460[E] 03/10/2000, 06:30 PM8

9
ENGLISH
Mode 1
The AF indicator lights up but the REG indicator does not.
Network-Tracking is activated with Regionalization set to “off.”
Switches to another station within the same network when the receiving
signals from the current station become weak.
Note:
In this mode, the programme may differ from the one currently received.
Mode 2
Both the AF indicator and the REG indicator light up.
Network-Tracking is activated with Regionalization set to “on.”
Switchesto another station,within the samenetwork, broadcasting thesame
programmewhenthe receivingsignals fromthecurrent stationbecome weak.
Mode 3
Neither the AF indicator nor the REG indicator lights up.
Network-Tracking is deactivated.
The same programme can be received on different frequencies.
Programme 1 broadcasting
on frequency A
Programme 1 broadcasting on
frequency B
Programme 1 broadcasting on frequency E
Programme 1 broadcasting on frequency D
Programme 1 broadcasting on frequency C
EN08-15KS-FX463/460[E] 03/10/2000, 06:30 PM9

10
ENGLISH
Using Standby Reception
Standby Reception allows the unit to switch temporarily to your favorite programme (PTY:
Programme Type) and Traffic Announcement (TA) from the current source — another FM
station and Tape or CD changer.
Note:
Standby Reception will not work if you are listening to an AM station.
TA Standby Reception
• When you pressTP/RDS while listening to an FM station, theTP indicator
islit during receptionof aTP(TrafficProgramme)stationand theTA standby
mode is engaged.
Note:
When the station being received is not a TP station, the TP indicator flashes. Press
¢or 4to engage the TA standby mode. “SEARCH” appears on the
display, and TPstation search starts. When a TP station is tuned in, the TPindicator
is lit.
• If you are listening to a tape or CD changer, and wish to listen to a TP
station,pressTP/RDSorTPtoentertheTAstandbymode.(TheTPindicator
lights up.)
Ifatrafficprogrammestartsbroadcasting whiletheTAstandbymode isactive,
“TRAFFIC” appears and the playback source changes to the FM band.The
volume increases to the preset TA volume level and the traffic programme
can be heard (see page 14).
To deactivate theTA standby mode, press TP/RDS again.
PTY Standby Reception
• When you press PTY while listening to an FM station, the PTY indicator is
litduringreception ofa PTY station and the PTY standbymodeis engaged.
The selected PTY name stored on page 12 flashes for 5 seconds.
Note:
When the station being received is not a PTY station, the PTY indicator flashes.
Press ¢or 4to engage the PTY standby mode. “SEARCH” appears
on the display, and PTY station search starts. When a PTY station is tuned in, the
PTY indicator is lit.
• If you are listening to a tape or CD changer, and wish to listen to a selected
PTY broadcast, press PTY to enter the PTY standby mode. (The PTY
indicator lights up.)
If the selected PTY programme starts broadcasting while the PTY standby
mode is active, the selected PTY name appears and the playback source
changes to the FM band.The selected PTY programme can then be heard.
To deactivate the PTY standby mode, press PTY again.
PTY
TP
RDS
EN08-15KS-FX463/460[E] 03/10/2000, 06:30 PM10
