JVC KD-SR83BT User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ENGLISH
FRANÇAIS
ESPAÑOL
B5A-1375-00 [K]
KD-SR83BT
CD RECEIVER
INSTRUCTION MANUAL
RÉCEPTEUR CD
MANUEL D’INSTRUCTIONS
RECEPTOR CON CD
MANUAL DE INSTRUCCIONES
For customer Use:
Enter below the Model No. and Serial No. which are
located on the top or bottom of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
JS_JVC_KD_SR83BT_K_C.indd 1JS_JVC_KD_SR83BT_K_C.indd 1 12/23/2016 12:13:27 PM12/23/2016 12:13:27 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
i
CAUTION
Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
In compliance with Federal Regulations, following are reproductions of labels on, or inside the product
relating to laser product safety.
JVC KENWOOD Corporation
2967-3, ISHIKAWA-MACHI,
HACHIOJI-SHI, TOKYO, JAPAN
THIS PRODUCT COMPLIES WITH DHHS RULES 21CFR
SUBCHAPTER J IN EFFECT AT DATE OF MANUFACTURE.
Location : Top Plate
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the modifications are expressly approved in the
instruction manual. The user could lose the authority to operate this equipment if an unauthorized
change or modification is made.
FCC NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment may cause harmful interference to
radio communications, if it is not installed and used in accordance with the instructions. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Información acerca de la eliminación de equipos eléctricos y electrónicos al final de la vida
útil (aplicable a los países que hayan adoptado sistemas independientes de recogida de
residuos)
Los productos con el símbolo de un contenedor con ruedas tachado no podrán ser
desechados como residuos domésticos. Los equipos eléctricos y electrónicos al final
de la vida útil, deberán ser reciclados en instalaciones que puedan dar el tratamiento
adecuado a estos productos y a sus subproductos residuales correspondientes.
Póngase en contacto con su administración local para obtener información sobre el
punto de recogida más cercano. Un tratamiento correcto del reciclaje y la eliminación
de residuos ayuda a conservar los recursos y evita al mismo tiempo efectos
perjudiciales en la salud y el medio ambiente.
JS_JVC_KD_SR83BT_K_C.indd iJS_JVC_KD_SR83BT_K_C.indd i 12/23/2016 12:13:29 PM12/23/2016 12:13:29 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ii
CAUTION
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to
comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be
installed and operated keeping the radiator at least 20cm or more away from person’s body.
ATTENTION
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un
environnement non contrôlé et respecte les règles les radioélectriques (RF) de la FCC lignes directrices
d’exposition et d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet
une énergie RF très faible qui est considérée comme conforme sans évaluation de l’exposition maximale
autorisée (MPE). Cependant, il est souhaitable qu’il devrait être installé et utilisé en gardant une
distance de 20 cm ou plus entre le radiateur et le corps humain.
IC (Industry Canada) Notice
This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Note de IC (Industrie Canada)
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence.
L’exploitation est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
Para cumplimiento de la IFT:
“La operación de este equipo está sujeta a las siguientes dos condiciones:
(1) es posible que este equipo o dispositivo no cause interferencia perjudicial y
(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su
operación no deseada”
Contains Bluetooth Module FCC ID: ZWY8811X
IC ID: 12033A-8811X
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
JS_JVC_KD_SR83BT_K_C.indd iiJS_JVC_KD_SR83BT_K_C.indd ii 12/23/2016 12:13:29 PM12/23/2016 12:13:29 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
iii
SOFTWARE LICENSE AGREEMENT
The software embedded in the Product (hereinafter the "Licensed Software") provided by Licensor is
copyrighted to or sublicensable by the Licensor, and this Agreement provides for the terms and conditions
which Users shall follow in order to use the Licensed Software.
The User shall use the Licensed Software by agreeing with the terms of this Software License Agreement.
This Agreement shall be deemed completed at the time the User (hereinafter the "User") initially used the
Product in which the "Licensed Software" is embedded.
The Licensed Software may include the software which has been licensed to the Licensor directly or
indirectly from any third party. In such case, some third parties require the Users to follow their conditions
for use separately from this Software License Agreement. Such software shall not be subject to this
Agreement, and the Users are urged to read the "Important Notice concerning the Software" to be provided
separately below.
Article 1 General Provision
The Licensor shall grant to the User a non-exclusive and non-transferable (other than the exceptional case
referred to in Article 3, Paragraph 1) licensed to use the Licensed Software within the country of the User.
(the country where the User bought the Product(hereinafter the "Country")
Article 2 License
1. The license granted under this Agreement shall be the right to use the Licensed Software in the
Product.
2. The User shall not duplicate, copy, modify, add, translate or otherwise alter, or lease the Licensed
Software and any related documents, whether in whole or in part.
3. The use of the Licensed Software shall be limited to personal purpose, and the Licensed Software shall
not be distributed, licensed or sub-licensed whether it is for commercial purpose or not.
4. The User shall use the Licensed Software according to the directions described in the operation
manual or help file, and is prohibited to use or duplicate any data in a manner violating the Copyright
Law or any other laws and regulations by applying whole or a part of the Licensed Software.
Article 3 Conditions for Grant of License
1. When the User transfers the Product, it may also transfer the license to use the Licensed Software
embedded in the Product (including any related materials, updates and upgrades) on condition that
no original, copies or related materials continue in the possession of the User, and that the User shall
cause the transferee to comply with this Software License Agreement.
2. The User shall not carry out reverse engineering, disassembling, decompiling or any other code
analysis works in connection with the Licensed Software.
Article 4 Right pertaining to the Licensed Software
Any and all copyrights and other rights pertaining to the Licensed Software and related documents
shall belong to the Licensor or the original holder of the right who granted to the Licensor the license or
sublicense for the Licensed Software (hereinafter the "Original Rightholder"), and the User shall not be
entitled to any right other than the license granted hereunder, in respect of the Licensed Software and any
related documents.
Article 5 Indemnification of Licensor
1. Neither the Licensor nor the Original Rightholder shall be liable for any damage incurred by the User
or any third party due to the exercise of the license granted to the User under this Agreement, unless
otherwise restricted by law.
2. The Licensor will offer no guarantee for the merchantability, convertibility and consistency with
certain objective of the Licensed Software.
Article 6 Liability to Third Party
If any dispute has arisen with any third party due to an infringement upon a copyright, patent or any
other intellectual property right that was caused by the User's use of the Licensed Software, the User shall
settle such dispute at its own cost and hold the Licensor and the Original Rightholder harmless from any
inconvenience it may cause.
Article 7 Confidentiality
The User shall keep the confidentiality of such portion of the Licensed Software, related documents thereof
or any other information to be granted under this Agreement, as well as the conditions of this Agreement
as has not yet entered the public domain, and shall not disclose or divulge the same to any third party
without approval of the Licensor.
JS_JVC_KD_SR83BT_K_C.indd iiiJS_JVC_KD_SR83BT_K_C.indd iii 12/23/2016 12:13:29 PM12/23/2016 12:13:29 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
iv
Article 8 Termination
In case the User falls under any of the events described in the following items, the Licensor may immediately terminate this Agreement or
claim that the User compensates for the damage incurred by the Licensor due to such event:
(1) when the User violated any provision of this Agreement; or
(2) when a petition has been filed against the User for an attachment,
provisional attachment, provisional disposition or any other compulsory execution.
Article 9 Destruction of the Licensed Software
If this Agreement is terminated pursuant to the provision of Article 8, the User shall destroy the Licensed Software, any related documents
and copies thereof within two (2) weeks from such date of termination.
Article 10 Protection of Copyright
1. The copyright and all the other intellectual property rights relating to the Licensed Software shall belong to the Licensor and the
Original Rightholder, and in no event shall they be under the ownership of the User.
2. The User shall, whenever it uses the Licensed Software, comply with any laws relating to the copyright and other intellectual property
rights.
Article 11 Export Restriction
1. It is prohibited to export the Licensed Software and any related documents outside the country of the User (including transmission
thereof outside the country of the User via Internet of other communication tools).
2. The User shall understand that the Licensed Software shall be subject to the export restrictions adopted by the country of User and any
other countries.
3. The User shall agree that the software will be subject to any and all applicable international and domestic laws (including the export
control regulation of the country of User and any other countries, and any restrictions concerning the end-users, the use by end-users
and importing countries to be provided by the country of User and any other countries, and any other governmental authorities).
Article 12 Miscellaneous
1. In the event any part of this Agreement is invalidated by operation of law, the residual provisions shall continue in force.
2. Matters not stipulated in this Agreement or any ambiguity or question raised in the construction of this Agreement shall be provided or
settled upon good-faith consultation between the Licensor and the User.
3. The Licensor and the User hereby agree that this Agreement is governed by the laws of Japan, and any dispute arising from, and
relating to the rights and obligations under, this Agreement shall be submitted to the exclusive jurisdiction of the Tokyo District Court
for its first instance.
Important Notice concerning the
Software
-jansson
Copyright (c) 2009-2012 Petri Lehtinen <[email protected]>
Permission is hereby granted, free of charge, to any person obtaining a
copy of this software and associated documentation files (the "Software"),
to deal in the Software without restriction, including without limitation
the rights to use, copy, modify, merge, publish, distribute, sublicense,
and/or sell copies of the Software, and to permit persons to whom the
Software is furnished to do so, subject to the following conditions:
The above copyright notice and this permission notice shall be included in
all copies or substantial portions of the Software.
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT
HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY,
WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING
FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR
OTHER DEALINGS IN THE SOFTWARE.
JS_JVC_KD_SR83BT_K_C.indd ivJS_JVC_KD_SR83BT_K_C.indd iv 12/23/2016 12:13:29 PM12/23/2016 12:13:29 PM

ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2
CONTENTS BEFORE USE
IMPORTANT
• To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe
Warning and Caution in this manual.
• Please keep the manual in a safe and accessible place for future reference.
WARNING
• Do not operate any function that takes your attention away from safe driving.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of the output level.
General:
• Avoid using the external device if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit to prevent a short circuit.
• If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to evaporate.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Cancel the demonstration
2 Set the clock and date
3 Set the basic settings
RADIO 5
CD/USB/iPod/ANDROID 7
Pandora® 9
iHeartRadio® 10
BLUETOOTH® 11
AUX 18
AUDIO SETTINGS 19
DISPLAY SETTINGS 24
REFERENCES 25
Maintenance
More information
TROUBLESHOOTING 27
INSTALLATION/
CONNECTION 30
SPECIFICATIONS 32
How to read this manual
• Operations are explained mainly using buttons on the faceplate.
• English indications are used for the purpose of explanation. You can select the display language from the menu.
( 5)
• [XX] indicates the selected items.
•
( XX) indicates references are available on the stated page.
JS_JVC_KD_SR83BT_K_EN_1.indd 2JS_JVC_KD_SR83BT_K_EN_1.indd 2 12/23/2016 12:13:55 PM12/23/2016 12:13:55 PM

ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
3
BASICS
Attach
How to reset
Detach
Volume knob Loading slot
Detach button
Display window
Faceplate
To On the faceplate
Turn on the power Press .
• Press and hold to turn off the power.
Adjust the volume Turn the volume knob.
Press the volume knob to mute the sound or pause playback.
• Press again to cancel.
Select a source • Press repeatedly.
• Press , then turn the volume knob within 2 seconds.
Change the display information Press repeatedly.
( 26, 27)
JS_JVC_KD_SR83BT_K_EN_1.indd 3JS_JVC_KD_SR83BT_K_EN_1.indd 3 12/23/2016 12:13:57 PM12/23/2016 12:13:57 PM

ENGLISH
4
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Cancel the demonstration
When you turn on the power for the first time (or [FACTORY RESET] is set
to
[YES] , 5 ), the display shows: “CANCEL DEMO” “PRESS” “VOLUME
KNOB”
1 Press the volume knob.
[YES] is selected for the initial setup.
2 Press the volume knob again.
“DEMO OFF” appears.
Set the clock and date
1 Press and hold .
2 Turn the volume knob to select [CLOCK] , then press the knob.
To adjust the clock
3 Turn the volume knob to select [CLOCK ADJUST] , then press the knob.
4 Turn the volume knob to make the settings, then press the knob.
Hour Minute
5 Turn the volume knob to select [CLOCK FORMAT] , then press the knob.
6 Turn the volume knob to select [12H] or [24H] , then press the knob.
To set the date
7 Turn the volume knob to select [DATE SET] , then press the knob.
8 Turn the volume knob to make the settings, then press the knob.
Day Month Year
9 Press to exit.
To return to the previous setting item, press .
1
2
Set the basic settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
SYSTEM
KEY BEEP
(Not applicable when 3-way crossover is selected.)
ON :Activates the keypress tone.; OFF :Deactivates.
SOURCE SELECT
AM SRC
*
ON :Enables AM in source selection.; OFF :Disables. ( 5)
PANDORA SRC
*
ON :Enables PANDORA in source selection.; OFF :Disables. ( 9)
IHEART SRC
*
ON :Enables IHEARTRADIO in source selection.; OFF :Disables. ( 10)
BUILT-IN AUX
*
ON :Enables AUX in source selection.; OFF :Disables. ( 18)
F/W UPDATE
UPDATE SYSTEM
F/W UP xxxx YES
:Starts upgrading the firmware.; NO :Cancels (upgrading is not
activated).
For details on how to update the firmware, visit
<http://www.jvc.net/cs/car/>.
*
Not displayed when the corresponding source is selected.
3
JS_JVC_KD_SR83BT_K_EN_1.indd 4JS_JVC_KD_SR83BT_K_EN_1.indd 4 12/23/2016 12:13:59 PM12/23/2016 12:13:59 PM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
FACTORY
RESET
YES :Resets the settings to default (except the
stored station).;
NO :Cancels.
CLOCK
TIME SYNC ON
:The clock time is automatically set using the
Clock Time (CT) data in FM Radio Broadcast Data
System signal.;
OFF :Cancels.
CLOCK
DISPLAY
ON :The clock time is shown on the display even
when the unit is turned off.;
OFF :Cancels.
ENGLISH Select the display language for menu and music
information if applicable.
By default,
ENGLISH is selected.
ESPANOL
RADIO
“ST” lights up when receiving an FM stereo broadcast with sufficient signal strength.
Search for a station
1 Press repeatedly to select FM or AM.
2 Press to search for a station automatically.
(or)
Press and hold until “M” flashes, then press repeatedly to search for a station
manually.
Settings in memory
You can store up to 18 stations for FM and 6 stations for AM.
Store a station
While listening to a station....
Press and hold one of the number buttons (1to 6).
(or)
1 Press and hold the volume knob until “PRESETMODE” flashes.
2 Turn the volume knob to select a preset number, then press the knob.
The preset number flashes and “MEMORY” appears.
Select a stored station
Press one of the number buttons (1to6).
(or)
1 Press .
2 Turn the volume knob to select a preset number, then press the knob.
GETTING STARTED
JS_JVC_KD_SR83BT_K_EN_1.indd 5JS_JVC_KD_SR83BT_K_EN_1.indd 5 12/23/2016 12:14:05 PM12/23/2016 12:14:05 PM

ENGLISH
6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Other settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
TUNER SETTING
RADIO TIMER
Turns on the radio at a specific time regardless of the current source.
1 ONCE / DAILY / WEEKLY / OFF :Select how often the timer will be
turned on.
2 FM / AM :Select the source.
3 01 to 18 (for FM)/ 01 to 06 (for AM):Select the preset station.
4 Set the activation day
*1
and time.
“
M ” lights up when complete.
Radio Timer will not activate for the following cases.
• The unit is turned off.
•
[OFF] is selected for [AM SRC] in [SOURCE SELECT] after Radio Timer
for AM is selected.
( 4)
SSM SSM 01–06
/ SSM 07–12 / SSM 13–18 :Automatically presets up to 18
stations for FM. “SSM” stops flashing when the first 6 stations are stored.
Select
SSM 07–12 / SSM 13–18 to store the following 12 stations.
RADIO
IF BAND AUTO :Increases the tuner selectivity to reduce interference noises from
adjacent FM stations. (Stereo effect may be lost.);
WIDE :Subjects to
interference noises from adjacent FM stations, but sound quality will not
be degraded and the stereo effect will remain.
MONO SET ON :Improves the FM reception, but the stereo effect will be lost.;
OFF :Cancels.
AREA US : For North/Central/South America, AM/FM intervals:
10kHz/200kHz.;
SA :For some South American countries, AM/FM
intervals: 10kHz/50kHz.;
EU :For any other areas, AM/FM intervals:
9kHz/50kHz.
PTY SEARCH
*2
Select a PTY code (see below).
If there is a station broadcasting a program of the same PTY code as you
have selected, that station is tuned in.
*1
Selectable only when [ONCE] or [WEEKLY] is selected in step 1 .
*2
Only for FM source.
PTY code
NEWS , INFORM (information), SPORTS , TALK , ROCK , CLS ROCK (classic rock),
ADLT HIT (adult hits), SOFT RCK (softrock), TOP 40 , COUNTRY , OLDIES , SOFT ,
NOSTALGA (nostalgia), JAZZ , CLASSICL (classical), R & B (rhythm and blues),
SOFT R&B (soft rhythm and blues), LANGUAGE , REL MUSC (religious music),
REL TALK (religious talk), PERSNLTY (personality), PUBLIC , COLLEGE , HABL ESP
(Spanish talk),
MUSC ESP (Spanish music), HIP HOP , WEATHER
JS_JVC_KD_SR83BT_K_EN_1.indd 6JS_JVC_KD_SR83BT_K_EN_1.indd 6 12/23/2016 12:14:06 PM12/23/2016 12:14:06 PM

ENGLISH 7
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD/USB/iPod/ANDROID
To On the faceplate
Reverse/Fast-forward*3Press and hold .
Select a track/file Press .
Select a folder*4Press .
Repeat play*5Press repeatedly.
TRACK REPEAT / ALL REPEAT : Audio CD
TRACK REPEAT / FOLDER REPEAT / ALL REPEAT : MP3/WMA/AAC/WAV/
FLAC file
ONE REPEAT / ALL REPEAT / REPEAT OFF : iPod or ANDROID
Random play*5Press repeatedly.
ALL RANDOM / RANDOM OFF : Audio CD
FOLDER RANDOM / ALL RANDOM / RANDOM OFF : MP3/WMA/AAC/WAV/
FLAC file
SONG RANDOM / ALL RANDOM / RANDOM OFF : iPod or ANDROID
*1
Do not leave the cable inside the car when not using.
*2
When connecting an Android device, “Press [VIEW] to install JVC MUSIC PLAY APP” is shown. Follow the instructions
to install the application. You can also install the latest version of JVC MUSIC PLAY application on your Android device
before connecting. For more information, visit <http://www.jvc.net/cs/car/>.
*3
For ANDROID: Applicable only when [AUTO MODE] is selected. ( 8)
*4
For CD: Only for MP3/WMA/AAC files. This does not work for iPod/ANDROID.
*5
For iPod/ANDROID: Applicable only when [HEAD MODE] / [AUTO MODE] is selected. ( 8)
Start playback
The source changes automatically and playback
starts.
CD
Eject disc Label side
USB input terminal
USB 2.0 cable
*1
(commercially available)
Micro USB 2.0 cable
*1
(commercially available)
Accessory of the iPod/
iPhone
*1
USB
iPod/iPhone
ANDROID*2
JS_JVC_KD_SR83BT_K_EN_1.indd 7JS_JVC_KD_SR83BT_K_EN_1.indd 7 12/23/2016 12:14:08 PM12/23/2016 12:14:08 PM

ENGLISH
8
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Select control mode
While in iPodUSB source, press repeatedly.
HEAD MODE : Control iPod from this unit.
IPHONE MODE : Control iPod using the iPod itself. However, you can still
play/pause or file skip from this unit.
While in ANDROID source, press repeatedly.
AUTO MODE : Control Android device from this unit via JVC MUSIC PLAY
application installed in the Android device.
AUDIO MODE : Control Android device using the Android device itself via
other media player applications installed in the Android
device. However, you can still play/pause or file skip from
this unit.
Select music drive
While in USB source, press repeatedly.
Stored songs in the following drive will be played back.
• Selected internal or external memory of a smartphone (Mass Storage
Class).
• Selected drive of a multiple drives device.
Settings to use JVC Remote application
JVC Remote application is designed to control the JVC car receiver’s
operations from the iPhone/iPod (via USB input terminal).
Preparation:
Install the latest version of JVC Remote application on your device before
connecting. For more information, visit <http://www.jvc.net/cs/car/>.
You can make the settings in the same way as connection via Bluetooth.
( 17)
Select a file from a folder/list
For iPod/ANDROID, applicable only when [HEAD MODE] / [AUTO MODE] is
selected.
1 Press .
2 Turn the volume knob to select a folder/list, then press the knob.
3 Turn the volume knob to select a file, then press the knob.
Quick search (applicable only for CD, USB and ANDROID source)
If you have many files, you can search through them quickly.
Turn the volume knob quickly to browse through the list quickly.
Alphabet search (applicable only for iPod USB and ANDROID source)
You can search for a file according to the first character.
For iPodUSB source
Press or turn the volume knob quickly to select the
desired character (A to Z, 0to9, OTHERS).
• Select “OTHERS” if the first character is other than AtoZ, 0to9.
For ANDROID source
1Press to enter character search.
2Turn the volume knob to select the desired character.
^A^: Upper case letters (A to Z)
_A_: Lower case letters (a to z)
-0-: Numbers (0 to 9)
-OTHERS-: Character other than AtoZ, 0to9
3Press the volume knob to start searching.
• To return to the previous setting item, press .
• To cancel, press and hold .
CD/USB/iPod/ANDROID
JS_JVC_KD_SR83BT_K_EN_1.indd 8JS_JVC_KD_SR83BT_K_EN_1.indd 8 12/23/2016 12:14:12 PM12/23/2016 12:14:12 PM

ENGLISH 9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Pandora®
Preparation:
Install the latest version of the Pandora application on your device
(iPhone/iPod touch), then create an account and log in to Pandora.
• Select
[ON] for [PANDORA SRC] in [SOURCE SELECT] . ( 4)
Start listening
1 Open the Pandora application on your device.
2 Connect your device to the USB input terminal.
3 Press repeatedly to select PANDORA.
Broadcast starts automatically.
To On the faceplate
Playback/pause Press the volume knob.
Skip a track Press T.
Thumbs up or thumbs down*2Press .
*1
Do not leave the cable inside the car when not using.
*2
If thumbs down is selected, the current track is skipped.
Create and store a new station
1 Press .
2 Turn the volume knob to select [NEW STATION] , then press the knob.
3 Turn the volume knob to select [FROM TRACK] or [FROM ARTIST] , then
press the knob.
A new station is created based on the current song or artist.
4 Press and hold one of the number buttons (3, 4, 5or 6) to store.
To select a stored station: Press one of the number buttons (3, 4, 5or 6).
Search for a registered station
1 Press .
2 Turn the volume knob to select an item, then press the knob.
[BY DATE] : According to the registered date
[A-Z] : By alphabetical order
3 Turn the volume knob to select the desired station, then press the
knob.
To cancel, press and hold .
Bookmark current song information
Press and hold the volume knob.
“BOOKMARKED” appears and the information is stored to your device.
• The bookmark is available on your Pandora account but not on this
unit.
USB input terminal
Accessory of the iPod/iPhone
*1
JS_JVC_KD_SR83BT_K_EN_1.indd 9JS_JVC_KD_SR83BT_K_EN_1.indd 9 12/23/2016 12:14:14 PM12/23/2016 12:14:14 PM

ENGLISH
10
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
iHeartRadio®
Preparation:
Install the latest version of iHeartAuto application on your device
(iPhone/iPod touch), then create an account and log in to iHeartRadio.
• Select
[ON] for [IHEART SRC] in [SOURCE SELECT] . ( 4)
Start listening
1 Open the iHeartAuto application on your device.
2 Connect your device to the USB input terminal.
3 Press repeatedly to select IHEARTRADIO.
Broadcast starts automatically
*
Do not leave the cable inside the car when not using.
To On the faceplate
Playback/pause Press the volume knob.
Skip a track for custom
station
Press T.
Thumbs up or thumbs
down
Press .
Create a new/custom
station
Press and hold the volume knob.
Scan for live station 1 Press 3to start scanning.
2 Press 3again to listen to the station.
Search and store a station
1 Press .
2 Turn the volume knob to select a category, then press the knob.
3 Turn the volume knob to select the desired station, then press the
knob.
When a city list appears, you can search cities in alphabetical order by
turning the volume knob quickly.
To cancel, press and hold .
To store a station: Press and hold one of the number buttons (4, 5or 6).
To select a stored station: Press one of the number buttons (4, 5or 6).
USB input terminal
Accessory of the iPod/iPhone
*
JS_JVC_KD_SR83BT_K_EN_1.indd 10JS_JVC_KD_SR83BT_K_EN_1.indd 10 12/23/2016 12:14:16 PM12/23/2016 12:14:16 PM

ENGLISH 11
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Pair and connect a Bluetooth device for the first time
1 Press to turn on the unit.
2 Search and select “KD-SR8 BT” on the Bluetooth device.
“BTPAIRING” flashes on the display.
• For some Bluetooth devices, you may need to enter the Personal Identification Number
(PIN) code immediately after searching.
3 Perform (A) or (B) depending on what appears on the display.
For some Bluetooth devices, pairing sequence may vary from the steps described below.
(A) “[Device Name]” “XXXXXX” “VOL–YES” “BACK–NO”
“XXXXXX” is a 6-digit passkey randomly generated during each pairing.
Ensure that the passkeys appear on the unit and Bluetooth device are the same.
Press the volume knob to confirm the passkey.
Operate the Bluetooth device to confirm the passkey.
(B) “[Device Name]” “VOL–YES” “BACK–NO”
Press the volume knob to start pairing.
• If “PAIRING” “PIN 0000” scrolls on the display, enter the PIN code “0000” into the
Bluetooth device.
You can change to a desired PIN code before pairing.
( 15)
• If only “PAIRING” appears, operate the Bluetooth device to confirm pairing.
“PAIRING COMPLETED” appears when pairing is completed and “ ” will light up when the
Bluetooth connection is established.
• This unit supports Secure Simple Pairing (SSP).
• Up to five devices can be registered (paired) in total.
• Once the pairing is completed, the Bluetooth device will remain registered in the unit even if
you reset the unit. To delete the paired device,
15 , [DEVICE DELETE] .
• A maximum of two Bluetooth phones and one Bluetooth audio device can be connected at
any time.
However, while in BT AUDIO source, you can connect to five Bluetooth audio devices and
switch between these five devices. (
16 )
• Some Bluetooth devices may not automatically connect to the unit after pairing. Connect the
device to the unit manually.
• Refer to the instruction manual of the Bluetooth device for more information.
BLUETOOTH®
BLUETOOTH — Connection
Supported Bluetooth profiles
– Hands-Free Profile (HFP)
– Advanced Audio Distribution Profile (A2DP)
– Audio/Video Remote Control Profile (AVRCP)
– Serial Port Profile (SPP)
– Phonebook Access Profile (PBAP)
Supported Bluetooth codecs
– Sub Band Codec (SBC)
– Advanced Audio Coding (AAC)
Connect the microphone
Adjust the microphone
angle Secure using cord clamps
(not supplied) if necessary.
Microphone input jack
Microphone (supplied)
Rear panel
JS_JVC_KD_SR83BT_K_EN_1.indd 11JS_JVC_KD_SR83BT_K_EN_1.indd 11 12/23/2016 12:14:17 PM12/23/2016 12:14:17 PM

ENGLISH
12
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Auto Pairing
When you connect the iPhone/iPod touch/
Android device to the USB input terminal,
pairing request (via Bluetooth) is automatically
activated.
Press the volume knob to pair once you have
confirmed the device name.
Automatic pairing request is activated only if:
– Bluetooth function of the connected devcie is
turned on.
–
[AUTO PAIRING] is set to [ON] . ( 15)
– JVC MUSIC PLAY application is installed on
the Android device
( 7) and [AUTO MODE] is
selected
( 8) .
BLUETOOTH — Mobile phone
Receive a call
When there is an incoming call:
• The buttons will blink in the blinking pattern you have selected in
[RING ILLUMI] . ( 13)
• The unit answers the call automatically if [AUTO ANSWER] is set to a selected time. ( 13)
During a call:
• The buttons stop blinking.
• If you turn off the unit or detach the faceplate, the Bluetooth connection is disconnected.
The following operations may differ or not available depending on the connected phone.
To On the faceplate
First incoming call...
Answer a call Press or the volume knob.
Reject a call Press and hold or the volume knob.
End a call Press and hold or the volume knob.
While talking on the first incoming call...
Answer another incoming call and
hold the current call
Press or the volume knob.
Reject another incoming call Press and hold or the volume knob.
BLUETOOTH®
JS_JVC_KD_SR83BT_K_EN_1.indd 12JS_JVC_KD_SR83BT_K_EN_1.indd 12 12/23/2016 12:14:22 PM12/23/2016 12:14:22 PM

ENGLISH 13
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
To On the faceplate
While having two active calls...
End current call and activate
held call
Press and hold or the volume knob.
Swap between the current
call and held call
Press .
Adjust the phone volume*1
[00] to [35] (Default: [15] )
Turn the volume knob during a call.
Switch between hands-free and
private talk modes*2Press during a call.
*1
This adjustment will not affect the volume of the other sources.
*2
Operations may vary according to the connected Bluetooth device.
Improve the voice quality
While talking on the phone....
1 Press and hold .
2 Turn the volume knob to select an item ( see the following table ) , then press
the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press to exit.
To return to the previous setting item, press .
Default: XX
MIC GAIN LEVEL –10 to LEVEL +10 ( LEVEL –04 ):The sensitivity of the
microphone increases as the number increased.
NR LEVEL LEVEL –05 to LEVEL +05 ( LEVEL 00 ):Adjust the noise
reduction level until the least noise is being heard during a
phone conversation.
ECHO CANCEL LEVEL –05 to LEVEL +05 ( LEVEL 00 ):Adjust the echo
cancellation delay time until the least echo is being heard
during a phone conversation.
Make the settings for receiving a call
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select an item (see the following
table), then press the knob.
3 Repeat step 2until the desired item is selected or activated.
To return to the previous setting item, press .
Default:
XX
SETTINGS
AUTO ANSWER 01 SEC
to 30 SEC :The unit answers incoming call
automatically in the selected time (in seconds).;
OFF :Cancels.
RING ILLUMI BLINK 01 to BLINK 05 ( BLINK 02 ): Selects the blinking
pattern for the buttons as notification when there is an
incoming call.;
OFF :Cancels.
BLUETOOTH®
JS_JVC_KD_SR83BT_K_EN_1.indd 13JS_JVC_KD_SR83BT_K_EN_1.indd 13 12/23/2016 12:14:25 PM12/23/2016 12:14:25 PM

ENGLISH
14
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Make a call
You can make a call from the call history, phonebook, or dialing the number. Call by
voice is also possible if your mobile phone has the feature.
1 Press to enter Bluetooth mode.
“(First device name)” appears.
• If two Bluetooth phones are connected, press again to switch to another
phone.
“(Second device name)” appears.
2 Turn the volume knob to select an item (see the following table), then press the
knob.
3 Repeat step 2until the desired item is selected/activated or follow the instructions
stated on the selected item.
To return to the previous setting item, press .
RECENT CALL (Applicable only if the phone supports PBAP.)
1 Press the volume knob to select a name or a phone number.
• “<” indicates call received, “>“ indicates call made, “M” indicates call missed.
• “NO HISTORY” appears if there is no recorded call history or call number.
2 Press the volume knob to call.
PHONEBOOK (Applicable only if the phone supports PBAP.)
1 Press to select the desired letter (A to Z, 0to9, and OTHERS).
• “OTHERS” appears if the first character is other than Ato Z, 0 to 9.
2 Turn the volume knob to select a name, then press the knob.
3 Turn the volume knob to select a phone number, then press the knob to call.
• The phonebook of the connected phone is automatically transferred to the unit when pairing.
• This unit can display only non-accent letters. (Accent letters such as “Ú” is showns as “U”.)
DIAL NUMBER 1 Turn the volume knob to select a number (0 to 9) or character ( , #, +).
2 Press to move the entry position.
Repeat steps
1 and 2 until you finish entering the phone number.
3 Press the volume knob to call.
VOICE Speak the name of the contact you want to call or the voice command to control the phone
functions.
( Make a call using voice recognition)
BLUETOOTH®
Make a call using voice recognition
1 Press and hold to activate the connected
phone.
2 Speak the name of the contact you want to call or
the voice command to control the phone functions.
• Supported Voice Recognition features vary for each
phone. Refer to the instruction manual of the connected
phone for details.
• This unit also supports the intelligent personal assistant
function of iPhone.
Settings in memory
Store a contact in memory
You can store up to 6 contacts into the number buttons
(1to 6).
1 Press to enter Bluetooth mode.
2 Turn the volume knob to select [RECENT CALL] ,
[PHONEBOOK] or [DIAL NUMBER] , then press the knob.
3 Turn the volume knob to select a contact or enter a
phone number.
If a contact is selected, press the volume knob to show
the phone number.
4 Press and hold one of the number buttons (1to 6).
“MEMORY P(selected preset number)” appears when
the contact is stored.
To erase a contact from the preset memory, select
[DIAL NUMBER] in step 2and store a blank number.
Make a call from memory
1 Press to enter Bluetooth mode.
2 Press one of the number buttons (1to 6).
3 Press the volume knob to call.
“NO PRESET” appears if there is no contact stored.
JS_JVC_KD_SR83BT_K_EN_1.indd 14JS_JVC_KD_SR83BT_K_EN_1.indd 14 12/23/2016 12:14:26 PM12/23/2016 12:14:26 PM

ENGLISH 15
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Bluetooth mode settings
1 Press and hold .
2 Turn the volume knob to select an item ( see the following table ) , then press the knob.
3 Repeat step 2until the desired item is selected/activated or follow the instructions
stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
BT MODE
PHONE SELECT
*
Selects the phone or audio device to connect or disconnect.
“” appears in front of the device name when connected.
“” appears in front of the current playback audio device.
AUDIO SELECT
*
DEVICE DELETE 1 Turn the volume knob to select a device to delete, then press the knob.
2 Turn the volume knob to select [YES] or [NO] , then press the knob.
PIN CODE EDIT
(0000)
Changes the PIN code (up to 6 digits).
1 Turn the volume knob to select a number.
2 Press to move the entry position.
Repeat steps
1 and 2 until you finish entering the PIN code.
3 Press the volume knob to confirm.
RECONNECT ON :The unit automatically reconnect when the last connected Bluetooth device is within range.;
OFF :Cancels.
AUTO PAIRING ON :The unit automatically pair supported Bluetooth device (iPhone/iPod touch/Android device)
when it is connected through USB input terminal.Depending on the operating system of the
connected device, this function may not work. ;
OFF :Cancels.
INITIALIZE YES :Initializes all the Bluetooth settings (including stored pairing, phonebook, and etc.).;
NO :Cancels.
INFORMATION MY  BT  NAME : Displays the unit name (“KD-SR8 BT”).;
MY  ADDRESS : Shows address of this unit.
*
You can only connect a maximum of two Bluetooth phones and one Bluetooth audio device at any time.
BLUETOOTH®
Bluetooth compatibility check mode
You can check the connectivity of the supported
profile between the Bluetooth device and the unit.
• Make sure there is no Bluetooth device paired.
1 Press and hold .
“BLUETOOTH” “CHECK MODE” appears.
“SEARCH NOW USING PHONE” “PIN IS 0000”
scrolls on the display.
2 Search and select “KD-SR8 BT” on the Bluetooth
device within 3minutes.
3 Perform (A), (B) or (C) depending on what
appears on the display.
(A) “PAIRING” “XXXXXX” (6-digit passkey):
Ensure that the same passkey appears on the
unit and Bluetooth device, then operate the
Bluetooth device to confirm the passkey.
(B) “PAIRING” “PIN IS 0000”: Enter “0000” on
the Bluetooth device.
(C) “PAIRING”: Operate the Bluetooth device to
confirm pairing.
After pairing is successful, “PAIRING OK” “[Device
Name]” appears and Bluetooth compatibility check
starts.
If “CONNECT NOW USING PHONE” appears, operate
the Bluetooth device to allow phonebook access to
continue.
“TESTING” flashes on the display.
JS_JVC_KD_SR83BT_K_EN_1.indd 15JS_JVC_KD_SR83BT_K_EN_1.indd 15 12/23/2016 12:14:28 PM12/23/2016 12:14:28 PM

ENGLISH
16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
The connectivity result flashes on the display.
“PAIRING OK” and/or “HANDS-FREE OK”*1and/
or “AUD.STREAM OK”*2and/or “PBAP OK”*3:
Compatible
*1
Compatible with Hands-Free Profile (HFP)
*2
Compatible with Advanced Audio Distribution Profile (A2DP)
*3
Compatible with Phonebook Access profile (PBAP)
After 30 seconds, “PAIRING DELETED” appears to
indicate that pairing has been deleted, and the
unit exits check mode.
• To cancel, press and hold to turn off
the power, then turn on the power again.
BLUETOOTH®
BLUETOOTH — Audio
Audio player via Bluetooth
1 Press repeatedly to select BTAUDIO.
2 Operate the Bluetooth audio player to start playback.
To On the faceplate
Playback/pause Press the volume knob.
Select group or folder Press .
Reverse skip/Forward skip Press .
Reverse/Fast-forward Press and hold .
Repeat play Press repeatedly.
TRACK REPEAT , ALL REPEAT , REPEAT OFF
Random play Press repeatedly.
GROUP RANDOM , ALL RANDOM , RANDOM OFF
Select a file from a folder/list Refer to “Select a file from a folder/list” on page 8.
Switch between connected
Bluetooth audio devices
Press 5.*
*
Pressing the “Play” key on the connected device itself also causes switching of sound output from the device.
Operations and display indications may differ according to their availability on the connected
device.
While in BT AUDIO source, you can
connect to five Bluetooth audio
devices and switch between these
five devices.
