JVC KD-G322 User manual

CD RECEIVER
KD-G322/KD-G321
For installation and connections, refer to the separate manual.
INSTRUCTIONS
GET0344-003A
[EX/EU]
For canceling the display demonstration, see page 5.
KD-G322
KD-G321
Cover_KD-G322_003A_2.indd 2 10/14/05 4:29:55 PM

2
ENGLISH
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to
obtain the best possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
How to detach/attach the control
panel
Detaching...
Attaching...
Note: Only for [EX] model users in UK and
European countries
For security reasons, a numbered ID card
is provided with this unit, and the same ID
number is imprinted on the unit’s chassis.
Keep the card in a safe place, as it will help the
authorities to identify your unit if stolen.
Warn ng:
If you need to operate the unit while driving,
be sure to look ahead carefully or you may be
involved in a traffic accident.
Caut on on volume sett ng:
Discs produce very little noise compared
with other sources. Lower the volume
before playing a disc to avoid damaging
the speakers by the sudden increase of the
output level.
How to reset your un t
• Your preset adjustments will also be erased.
How to forc bly eject a d sc
• If this does not work, reset your unit.
• Be careful not to drop the disc when it ejects.
EN02-05_KD-G322_1[EX_EU]2.indd 2EN02-05_KD-G322_1[EX_EU]2.indd 2 10/13/05 8:00:59 PM10/13/05 8:00:59 PM

ENGLISH
3
How to read th s manual
• Button operations are mainly explained with
the illustrations in the table below.
• is used to indicate an indicator is
displayed for the corresponding operation.
• ome related tips and notes are explained in
“More about this unit” (see pages 15 – 17).
Press briefly.
Press repeatedly.
Press either
one.
Press and hold until your
desired response begins.
Press and hold both
buttons at the same time.
How to use the M MODE button
If you press M MODE, the unit goes into
functions mode, then the number buttons
and ¢/4 buttons work as different
function buttons.
Ex.: When number button 2 works as
MO (monaural) button.
To use these buttons for their original
functions again after pressing M MODE, wait
for 5 seconds without pressing any of these
buttons until the functions mode is cleared or
press M MODE again.
CONTENTS
Control panel — KD-G322 and KD-G321 ........ 4
Gett ng started ................................. 5
Basic operations .................................................... 5
Rad o operat ons .............................. 6
FM RDS operat ons ............................ 7
Searching for your favorite FM RDS programme ... 7
D sc operat ons ................................. 9
Playing a disc in the unit ...................................... 9
Sound adjustments ........................... 11
General sett ngs — PSM ................... 12
Ma ntenance .................................... 14
More about th s un t ......................... 15
Troubleshoot ng ............................... 17
Spec f cat ons ................................... 19
This unit is equipped with the steering wheel
remote control function.
• ee the Installation/Connection Manual
(separate volume) for connection.
For safety...
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• top the car before performing any
complicated operations.
Temperature ns de the car...
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in
the car becomes normal before operating the
unit.
ime countdown indicator
EN02-05_KD-G322_1[EX_EU]2.indd 3EN02-05_KD-G322_1[EX_EU]2.indd 3 10/13/05 8:01:02 PM10/13/05 8:01:02 PM

4
ENGLISH
Control panel — KD-G612/KD-G611/KD-G511
D splay w ndow
; Disc information indicators—TAG (ID3
Tag), (folder), (track/file)
a Disc type indicators—WMA, MP3
s DI C indicator
d Playback mode / item indicators—
RND (random), (disc), (folder),
RPT (repeat)
f LOUD (loudness) indicator
g EQ (equalizer) indicator
h ound mode (C-EQ: custom equalizer)
indicators—JAZZ, CLA IC, HIP HOP,
POP , ROCK, U ER
j Tr (track) indicator
k ource display / Volume level indicator /
Time countdown indicator
l Main display
/ RD indicators—TP, PTY, AF, REG
z Tuner reception indicators— T (stereo),
MO (monaural)
Parts dent f cat on
D splay w ndow
Control panel — KD-G322 and KD-G321
1 (standby/on/attenuator) button
2 OURCE button
3 BAND button
4 Loading slot
5 Display window
6 0 (eject) button
7 TP/PTY (traffic programme/programme
type) button
8 ¢/4 buttons
9 Control dial
p EL (select) button
q DI P (display) button
w EQ (equalizer) button
e MO (monaural) button
r M ( trong-station equential Memory)
button
t Number buttons
y RPT (repeat) button
u RND (random) button
i M MODE button
o (control panel release) button
EN02-05_KD-G322_1[EX_EU]2.indd 4EN02-05_KD-G322_1[EX_EU]2.indd 4 10/13/05 8:01:03 PM10/13/05 8:01:03 PM

ENGLISH
5
Basic settings
• See also “General settings — PSM” on pages
12 and 13.
1
2
1 Canceling the display
demonstrations
Select “DEMO,” then “DEMO O .”
2 Setting the clock
Select “CLOCK H” (hour), then adjust
the hour.
Select “CLOCK M” (minute), then
adjust the minute.
Select “24H/12H,” then “24H” (hour) or
“12H” (hour).
3 Finish the procedure.
To check the current clock time while...
The power is turned off
Listening to...
An M (non-RDS) or AM station:
Frequency Ô Clock
An M RDS station:
Station name (PS = Station Frequency =
Programme type (PTY = Clock = (back to
the beginning)
Getting started
Basic operations
~ Turn on the power.
Ÿ
* You cannot select “DISC” as the playback
source if there is no disc in the unit.
! For FM/AM tuner
⁄ Adjust the volume.
@ Adjust the sound as you want. (See
page .)
To drop the volume in a
moment (ATT
To restore the sound, press
it again.
To turn off the power
Volume level indicator
Volume level appears.
EN02-05_KD-G322_1[EX_EU]f.indd 5EN02-05_KD-G322_1[EX_EU]f.indd 5 10/18/05 3:29:25 PM10/18/05 3:29:25 PM

6
ENGLISH
When an FM stereo broadcast is hard to
receive
Reception improves, but stereo effect will be
lost.
To restore the stereo effect, repeat the same
procedure. “MONO OFF” appears and the MO
indicator goes off.
Storing stations in memory
You can preset si stations for each band.
FM station automatic presetting —
SSM (Strong-station Sequential
Memory)
1 Select the FM band (FM1 – FM3) you
want to store into.
2
3
“SSM” flashes, then disappears when
automatic presetting is over.
Local FM stations with the strongest signals are
searched and stored automatically in the FM
band.
Radio operations
~
Ÿ
! Start searching for a station.
When a station is received,
searching stops.
To stop searching, press the
same button again.
To tune in to a station manually
In step ! above...
1
2 Select the desired station fre uencies.
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
Selected band appears.
Lights up when monaural mode is activated.
EN06-11_KD-G322_1[EX_EU]2.indd 6EN06-11_KD-G322_1[EX_EU]2.indd 6 10/13/05 8:01:15 PM10/13/05 8:01:15 PM

7
ENGLISH
FM RDS operations
What you can do with RDS
RDS (Radio Data System) allows FM stations
to send an additional signal along with their
regular programme signals.
By receiving the RDS data, this unit can do the
following
• Programme Type (PTY) Search (see the
following)
• TA (Traffic Announcement) and PTY
Standby Receptions (see pages 8 and 13)
•
Tracing the same programme automatically
—Network-Tracking Reception (see page 9)
• Programme Search (see page 13)
Searching for your favorite
FM RDS programme
You can tune in to a station broadcasting your
favorite programme by searching for a PTY
code.
• To store your favorite programme types, see
page 8.
~ The last selected PTY
code appears.
Ÿ Select one of your favorite
programme types.
or
Select one of the PTY codes (see
page 8).
Manual presetting
Ex. Storing FM station of 92.5 MHz into preset
number 4 of the FM1 band.
1
2
3
Listening to a preset station
1
2 Select the preset station (1 – 6) you
ant.
To be continued...
Preset number flashes for a while.
EN06-11_KD-G322_1[EX_EU]f.indd 7EN06-11_KD-G322_1[EX_EU]f.indd 7 10/31/05 8:48:18 AM10/31/05 8:48:18 AM

8
ENGLISH
Using the standby receptions
TA Standby Reception
TA Standby Reception allows the unit to switch
temporarily to Traffic Announcement (TA)
from any source other than AM.
The volume changes to the preset TA volume
level if the current level is lower than the preset
level (see page 1 ).
To activate TA Standby Reception
The TP (Traffic Programme)
indicator either lights up or
flashes.
• If the TP indicator lights up, TA Standby
Reception is activated.
• If the TP indicator flashes, TA Standby
Reception is not yet activated. (This occurs
when you are listening to an FM station
without the RDS signals required for TA
Standby Reception.)
To activate TA Standby Reception, tune in to
another station providing these signals. The
TP indicator will stop flashing and remain lit.
To deactivate the TA Standby Reception
The TP indicator goes off.
PTY Standby Reception
PTY Standby Reception allows the unit to
switch temporarily to your favorite PTY
programme from any source other than AM.
To activate and select your favorite PTY code
for PTY Standby Reception, see page 1 .
The PTY indicator either lights up or flashes.
• If the PTY indicator lights up, PTY Standby
Reception is activated.
• If the PTY indicator flashes, PTY Standby
Reception is not yet activated.
To activate PTY Standby Reception, tune in
to another station providing these signals. The
PTY indicator will stop flashing and remain lit.
To deactivate the PTY Standby Reception,
select “OFF” for the PTY code (see page 1 ).
The PTY indicator goes off.
! Start searching for your favorite
programme.
If there is a station
broadcasting a programme
of the same PTY code as you
have selected, that station is
tuned in.
Storing your favorite programme
types
You can store six favorite programme types.
Preset programme types in the number buttons
(1 to 6):
1 Select a PTY code (see page 7 .
2 Select the preset number (1 – 6 you
want to store into.
3 Repeat steps 1 and 2 to store other
PTY codes into other preset numbers.
4 Finish the procedure.
PTY codes
NEWS, AFFAIRS, INFO, SPORT, EDUCATE, DRAMA, CULTURE,
SCIENCE, VARIED, POP M (music), ROCK M (music), EASY
M (music), LIGHT M (music), CLASSICS, OTHER M (music),
WEATHER, FINANCE, CHILDREN, SOCIAL, RELIGION, PHONE
IN, TRAVEL, LEISURE, JA , COUNTRY, NATION M (music),
OLDIES, FOLK M (music), DOCUMENT
Ex.: When “ROCK M” is selected
EN06-11_KD-G322_1[EX_EU]f.indd 8EN06-11_KD-G322_1[EX_EU]f.indd 8 10/18/05 3:33:18 PM10/18/05 3:33:18 PM

9
ENGLISH
Tracing the same programme—
Network-Tracking Reception
When driving in an area where FM reception
is not sufficient enough, this unit automatically
tunes in to another FM RDS station of the
same network, possibly broadcasting the same
programme with stronger signals (see the
illustration below .
When shipped from the factory, Network-
Tracking Reception is activated.
To change the Network-Tracking Reception
setting, see “AF-REG” on page 12.
Programme A broadcasting on different frequency areas
(01 – 05)
Disc operations
Playing a disc in the unit
All tracks will be played repeatedly until you
change the source or eject the disc.
To stop play and eject
the disc
To fast-forward or
reverse the track
To go to the next or
previous tracks
To go to the next or previous folders (only
for P3 or W A discs)
To locate a particular track (for CD) or folder
(for P3 or W A discs) directly
To select a number from 01 – 06:
To select a number from 07 – 12:
• To use direct folder access on MP3/WMA
discs, it is required that folders are assigned
with 2-digit numbers at the beginning of their
folder names—01, 02, 03, and so on.
To select a particular track in
a folder (for MP3 or WMA
disc :
EN06-11_KD-G322_1[EX_EU]f.indd 9EN06-11_KD-G322_1[EX_EU]f.indd 9 10/18/05 3:33:55 PM10/18/05 3:33:55 PM

10
ENGLISH
Prohibiting disc ejection
You can lock a disc in the loading slot.
To cancel the prohibition, repeat the same
procedure.
Changing the display information
While playing an audio CD or a CD Text
While playing an MP3 or a WMA disc
• When “TAG DISP” is set to “TAG ON”
(see page 1 )
• When “TAG DISP” is set to “TAG OFF”
: Elapsed playing time with the current
track number
: Clock with the current track number
*1 If the current disc is an audio CD,
“NO NAME” appears.
*2 If an MP3/WMA fi e does not have ID3 tags,
fo der name and fi e name appear. In this
case, the TAG indicator wi not ight up.
Selecting the playbac modes
You can use only one of the following playback
modes at a time.
1
2 Select your desired playback mode.
7 Repeat play
Mode Plays repeatedly
TRK RPT : The current track.
FLDR RPT*3 : All tracks of the current
folder.
RPT OFF : Cancels.
7 Random play
Mode Plays at random
FLDR RND*3 : All tracks of the current
folder then tracks of the next
folder and so on.
DISC RND : All tracks of the current disc.
RND OFF : Cancels.
*3 On y whi e p aying an MP3 or a WMA
disc.
EN06-11_KD-G322_1[EX_EU]f.indd 10EN06-11_KD-G322_1[EX_EU]f.indd 10 10/19/05 6:56:23 PM10/19/05 6:56:23 PM

11
ENGLISH
Sound adjustments
You can select a preset sound mode suitable to
the music genre (C-EQ: custom equalizer).
1
2
Indication (For)
BAS T E LOUD
(bass) (treble) (loudness)
USER
(Flat sound) 00 00 OFF
ROCK
(Rock or disco music) +03 +01 ON
CLASSIC
(Classical music) +01 –02 OFF
POPS
(Light music) +04 +01 OFF
HIP HOP
(Funk or rap music) +02 00 ON
JAZZ
(Jazz music) +02 +03 OFF
Adjusting the sound
You can adjust the sound characteristics to your
preference.
1
2
Indication, [ ange]
BAS*4 (bass), [–06 to +06]
Adjust the bass.
TRE*4 (treble), [–06 to +06]
Adjust the treble.
FAD*5 (fader), [R06 to F06]
Adjust the front and rear speaker balance.
BAL (balance), [L06 to R06]
Adjust the left and right speaker balance.
LOUD*4 (loudness), [LOUD ON or LOUD OFF]
Boost low and high frequencies to produce a
well-balanced sound at low volume level.
VOL (volume), [00 to 30 or 50*6]
Adjust the volume.
*4 When you adjust the bass, treble, or loudness,
the adjustment you have made is stored for
the currently selected sound mode (C-EQ)
including “USER.”
*5 If you are using a two-speaker system, set the
fader level to “00.”
*6 Depending on the amplifier gain control
setting. (See page 13 for details.)
Preset values
Ex.: When “ROCK” is selected
EN06-11_KD-G322_1[EX_EU]2.indd 11EN06-11_KD-G322_1[EX_EU]2.indd 11 10/13/05 8:01:22 PM10/13/05 8:01:22 PM

12
ENGLISH
Indications Selectable settings, [reference page]
DEMO
Display demonstration
DEMO ON : [Initial]; Display demonstration will be activated
automatically if no operation is done for about
20 seconds, [5].
DEMO OFF : Cancels.
CLOCK H
Hour adjustment
0 23 (1 12), [5]
[Initial: 0 (0:00)]
CLOCK M
Minute adjustment
00 59, [5]
[Initial: 00 (0:00)]
24H/12H
Time display mode
12H O 24H, [5]
[Initial: 24H]
CLK ADJ
Clock adjustment
AUTO : [Initial]; The built-in clock is automatically adjusted
using the CT (clock time) data in the RDS signal.
OFF : Cancels.
AF-REG
Alternative frequency/
regionalization reception
When the received signals from the current FM RDS station become
weak...
AF : [Initial]; Switches to another station (the programme
may differ from the one currently received), [9].
• The AF indicator lights up.
AF REG : Switches to another station broadcasting the same
programme.
• The AF and REG indicators light up.
OFF : Cancels.
You can change PSM (Preferred Setting Mode)
items listed in the table that follows.
1
2 Select a PSM item.
General settings — PSM
3 Adjust the PSM item selected.
4 Repeat steps 2 and 3 to adjust other
PSM items if necessary.
5 Finish the procedure.
EN12-19_KD-G322_1[EX_EU]2.indd 12EN12-19_KD-G322_1[EX_EU]2.indd 12 10/13/05 8:01:32 PM10/13/05 8:01:32 PM

ENGLISH
13
Indications Selectable settings, [reference page]
PTY-STBY
PTY standby
Activates PTY Standby Reception with one of the PTY codes, [8].
OFF [Initial]
= PTY codes, [8] = (back to the beginning
TA VOL
Traffic announcement
volume
[Initial: VOL 15]; VOL 00 — VOL 30 or 50*1, [8]
P-SEARCH
Programme search
ON : Using the AF data, the unit tunes in to another
frequency broadcasting the same programme as the
original preset RDS station is if the preset station signals
are not sufficient.
OFF : [Initial]; Cancels.
DIMMER
Dimmer
ON : Dims the display illumination of this unit.
OFF : [Initial]; Cancels.
TEL
Telephone muting
MUTING 1/MUTING 2 : Select either one which mutes the sounds
while using a cellular phone.
OFF : [Initial]; Cancels.
SCROLL*2
Scroll
ONCE : [Initial]; Scrolls the disc information once.
AUTO : Repeats scrolling (5-second intervals in between .
OFF : Cancels.
• Pressing DISP for more than one second can scroll the display
regardless of the setting.
TAG DISP
Tag display
TAG ON : [Initial]; Shows the ID3 tag while playing MP3/WMA
tracks, [10].
TAG OFF : Cancels.
AMP GAIN
Amplifier gain control
You can change the maximum volume level of this unit.
LOW PWR : VOL 00 – VOL 30 (Select this if the maximum power
of the speaker is less than 50 W to prevent them from
damaging the speaker.
HIGH PWR : [Initial]; VOL 00 – VOL 50
IF BAND
Intermediate frequency
band
AUTO : [Initial]; Increase the tuner selectivity to reduce
interference noises between close stations. (Stereo effect
may be lost.
WIDE : Subject to the interference noises from adjacent
stations, but sound quality will not be degraded and
maintains the stereo effect.
*1 Depends on the amplifier gain control.
*2 Some characters or sym ols will not e shown correctly (or will e lanked) on the display.
EN12-19_KD-G322_1[EX_EU]2.indd 13EN12-19_KD-G322_1[EX_EU]2.indd 13 10/18/05 11:26:26 AM10/18/05 11:26:26 AM

14
ENGLISH
Maintenance
How to clean the connectors
Frequent detachment will deteriorate the
connectors.
To minimize this possibility, periodically wipe
the connectors with a cotton swab or cloth
moistened with alcohol, being careful not to
damage the connectors.
Moisture condensation
Moisture may condense on the lens inside the
CD player in the following cases:
• After starting the heater in the car.
• If it becomes very humid inside the car.
Should this occur, the CD player may
malfunction. In this case, eject the disc and
leave the unit turned on for a few hours until
the moisture evaporates.
How to handle discs
When removing a disc from
its case, press down the center
holder of the case and lift the
disc out, holding it by the edges.
• Always hold the disc by the
edges. Do not touch its recording surface.
When storing a disc into its case, gently insert
the disc around the center holder (with the
printed surface facing up).
• Make sure to store discs into the cases after
use.
Center holder
To keep discs clean
A dirty disc may not play correctly.
If a disc does become dirty, wipe it
with a soft cloth in a straight line
from center to edge.
• Do not use any solvent (for example,
conventional record cleaner, spray, thinner,
benzine, etc.) to clean discs.
To play new discs
New discs may have some rough
spots around the inner and outer
edges. If such a disc is used, this
unit may reject the disc.
To remove these rough spots, rub the edges
with a pencil or ball-point pen, etc.
Warped disc
Sticker Sticker residue
Disc Stick-on label
Do not use the follo ing discs:
Connector
EN12-19_KD-G322_1[EX_EU]2.indd 14EN12-19_KD-G322_1[EX_EU]2.indd 14 10/13/05 8:01:37 PM10/13/05 8:01:37 PM

ENGLISH
15
• When Alternative Frequency Reception
is activated (with AF selected), Network-
Trackin Reception is also activated
automatically. On the other hand, Network-
Trackin Reception cannot be deactivated
without deactivatin Alternative Frequency
Reception. (See pa e 12.)
• If you want to know more about RDS, visit
«http://www.rds.or .uk».
Disc operations
Caution for DualDisc playback
• The Non-DVD side of a “DualDisc” does
not comply with the “Compact Disc Di ital
Audio” standard. Therefore, the use of Non-
DVD side of a DualDisc on this product may
not be recommended.
General
• This unit has been desi ned to reproduce
CDs/CD Texts, and CD-Rs (Recordable)/
CD-RWs (Rewritable) in audio CD (CD-DA),
MP3 and WMA formats.
• MP3 and WMA “tracks” (words “file”
and “track” are used interchan eably) are
recorded in “folders.”
• When a disc has been loaded, selectin
“DISC” for the playback source starts disc
play.
Inserting a disc
• When a disc is inserted upside down, the disc
automatically ejects.
• Do not insert 8 cm discs (sin le CD) and
unusual shape discs (heart, flower, etc.) into
the loadin slot.
Playing a disc
• While fast-forwardin or reversin on
an MP3 or WMA disc, you can only hear
intermittent sounds.
More about this unit
Basic operations
Turning on the power
• By pressin SOURCE on the unit, you can
also turn on the power. If the source is ready,
playback also starts.
Turning off the power
• If you turn off the power while listenin to a
disc, disc play will start from where playback
has been stopped previously, next time you
turn on the power.
Tuner operations
Storing stations in memory
• Durin SSM search...
– All previously stored stations are erased and
stations are stored newly.
– Received stations are preset in No. 1 (lowest
frequency) to No. 6 (hi hest frequency).
– When SSM is over, the station stored in
No. 1 will be automatically tuned in.
• When storin a station manually, the
previously preset station is erased when a new
station is stored in the same preset number.
F RDS operations
• Network-Trackin Reception requires
two types of RDS si nals—PI (Pro ramme
Identification) and AF (Alternative
Frequency) to work correctly. Without
receivin these data correctly, Network-
Trackin Reception will not operate correctly.
• If a Traffic Announcement is received by
TA Standby Reception, the volume level
automatically chan es to the preset level (TA
VOL) if the current level is lower than the
preset level.
To be continued...
EN12-19_KD-G322_1[EX_EU]f.indd 15EN12-19_KD-G322_1[EX_EU]f.indd 15 10/31/05 8:53:17 AM10/31/05 8:53:17 AM

16
ENGLISH
Playing a CD-R or CD-RW
• Use only “finalized” CD-Rs or CD-RWs.
• This unit can play back only files of the sa e
type which are first detected if a disc includes
both audio CD (CD-DA) files and MP3/
WMA files.
• This unit can play back ulti-session discs;
however, unclosed sessions will be skipped
while playing.
• So e CD-Rs or CD-RWs ay not play
back on this unit because of their disc
characteristics, or for the following reasons:
– Discs are dirty or scratched.
– Moisture condensation occurs on the lens
inside the unit.
– The pickup lens inside the unit is dirty.
– CD-R/CD-RW on which the files are
written with “Packet Write” ethod.
– There are i proper recording conditions
( issing data, etc.) or edia conditions
(stained, scratched, warped, etc.).
• CD-RWs ay require a longer readout ti e
since the reflectance of CD-RWs is lower than
that of regular CDs.
• Do not use the following CD-Rs or CD-RWs:
– Discs with stickers, labels, or protective seal
stuck to the surface.
– Discs on which labels can be directly
printed by an ink jet printer.
Using these discs under high te peratures or
high hu idities ay cause alfunctions or
da age to the unit.
Playing an MP3/WMA disc
• This unit can play back MP3/WMA files
with the extension code <. p3> or <.w a>
(regardless of the letter case—upper/lower).
• This unit can show the na es of albu s,
artists (perfor er), and ID3 Tag (Version
1.0, 1.1, 2.2, 2.3, or 2.4) for MP3 files and for
WMA files.
• This unit can display only one-byte
characters. No other characters can be
correctly displayed.
• This unit can play back MP3/WMA files
eeting the conditions below:
– Bit rate: 8 kbps — 320 kbps
– Sa pling frequency:
48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)
24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)
– Disc for at: ISO 9660 Level 1/ Level 2,
Ro eo, Joliet, Windows long file na e
• The axi u nu ber of characters for file/
folder na es vary a ong the disc for at used
(includes 4 extension characters—<. p3> or
<.w a>).
– ISO 9660 Level 1: up to 12 characters
– ISO 9660 Level 2: up to 31 characters
– Ro eo: up to 128 characters
– Joliet: up to 64 characters
– Windows long file na e: up to 128
characters
• This unit can recognize a total of 512 files, of
200 folders, and of 8 hierarchies.
• This unit can play back files recorded in VBR
(variable bit rate).
Files recorded in VBR have a discrepancy
in elapsed ti e display, and do not show
the actual elapsed ti e. Especially, after
perfor ing the search function, this
difference beco es noticeable.
• This unit cannot play back the following files:
– MP3 files encoded with MP3i and
MP3 PRO for at.
– MP3 files encoded in an inappropriate
for at.
– MP3 files encoded with Layer 1/2.
– WMA files encoded with lossless,
professional, and voice for at.
– WMA files which are not based upon
Windows Media® Audio.
– WMA files copy-protected with DRM.
– Files which have the data such as WAVE,
ATRAC3, etc.
• The search function works but search speed is
not constant.
EN12-19_KD-G322_1[EX_EU]f.indd 16EN12-19_KD-G322_1[EX_EU]f.indd 16 11/7/05 10:46:59 AM11/7/05 10:46:59 AM

ENGLISH
17
Changing the source
• If you change the source, playback also stops
(without ejecting the disc).
Next time you select “DISC” for the playback
source, disc play starts from where it has been
stopped previously.
Ejecting a disc
• If the ejected disc is not removed within
15 seconds, the disc is automatically inserted
again into the loading slot to protect it from
dust. (Disc will not play this time.)
eneral settings—PSM
• If you change the “AMP GAIN” setting from
“HIGH PWR” to “LOW PWR” while the
volume level is set higher than “VOL 30,” the
unit automatically changes the volume level to
“VOL 30.”
Symptoms Remedies/Causes
eneral
• Sound cannot be heard from the
speakers.
• Adjust the volume to the optimum level.
• Check the cords and connections.
• The unit does not work at all. Reset the unit (see page 2).
FM/AM
• SSM automatic presetting does not
work.
Store stations manually.
• Static noise while listening to the radio. Connect the aerial firmly.
Disc playback
• Disc cannot be played back. Insert the disc correctly.
• CD-R/CD-RW cannot be played back.
• Tracks on the CD-R/CD-RW cannot be
skipped.
• Insert a finalized CD-R/CD-RW.
• Finalize the CD-R/CD-RW with the component
which you used for recording.
• Disc can be neither played back nor
ejected.
• Unlock the disc (see page 10).
• Eject the disc forcibly (see page 2).
• Disc sound is sometimes interrupted. • Stop playback while driving on rough roads.
• Change the disc.
• Check the cords and connections.
• “NO DISC” appears on the display. Insert a playable disc into the loading slot.
Troubleshooting
What appears to be trouble is not always serious. Check the following points before calling a service
center.
To be continued...
EN12-19_KD-G322_1[EX_EU]2.indd 17EN12-19_KD-G322_1[EX_EU]2.indd 17 10/13/05 8:01:42 PM10/13/05 8:01:42 PM

18
ENGLISH
Symptoms Remedies/Causes
MP3/WMA playback
• Disc cannot be played back. • Use a disc with MP3/WMA tracks recorded in
the format compliant with ISO 9660 Level 1,
Level 2, Romeo, or Joliet.
• Add the extension code <.mp3> or <.wma> to
the file names.
• Noise is generated. Skip to another track or change the disc. (Do not
add the extension code <.mp3> or <.wma> to non-
MP3 or WMA tracks.)
• A longer readout time is required
(“CHECK” keeps flashing on the
display).
Do not use too many hierarchies and folders.
• Tracks do not play back in the order
you have intended them to play.
Playback order is determined when the files are
recorded.
• Elapsed playing time is not correct. This sometimes occurs during play. This is caused
by how the tracks are recorded on the disc.
• “NO FILES” appears on the display. Insert a disc that contains MP3/WMA tracks.
• Correct characters are not displayed
(e.g. album name).
This unit can only display alphabets (upper case),
numbers, and a limited number of symbols.
• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
EN12-19_KD-G322_1[EX_EU]2.indd 18EN12-19_KD-G322_1[EX_EU]2.indd 18 10/13/05 8:01:43 PM10/13/05 8:01:43 PM

ENGLISH
19
Specifications
AUDIO AMPLIFIER SECTION
Maximum Power Output:
Front: 50 W per channel
Rear: 50 W per channel
Continuous Power Output (RMS):
Front: 1 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Rear: 1 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range:
Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-Out Level/Impedance:
2.5 V/20 kΩ load (full scale)
Output Impedance: 1 kΩ
Other terminals: Steering wheel remote input
TUNER SECTION
Frequency Range:
FM: 87.5 MHz to 108.0 MHz
AM: (MW) 522 kHz to 1 620 kHz
(LW) 144 kHz to 27 kHz
[FM Tuner]
Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω)
50 dB Quieting Sensitivity:
16.3 dBf (1.8 μV/75 Ω)
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB
Capture Ratio: 1.5 dB
[MW Tuner]
Sensitivity: 20 μV
Selectivity: 35 dB
[LW Tuner]
Sensitivity: 50 μV
CD PLAYER SECTION
Type: Compact disc player
Signal Detection System: Non-contact optical
pickup (semiconductor laser)
Number of Channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Range: 6 dB
Signal-to-Noise Ratio: 8 dB
Wow and Flutter: Less than measurable limit
MP3 Decoding Format:
MPEG1/2 Audio Layer 3
Max. Bit Rate: 320 kbps
WMA (Windows Media® Audio) Decoding
Format:
Max. Bit Rate: 1 2 kbps
GENERAL
Power Requirement:
Operating Voltage:
DC 14.4 V (11 V to 16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature:
0°C to +40°C
Dimensions (W × H × D):
Installation Size (approx.):
182 mm × 52 mm × 150 mm
Panel Size (approx.):
188 mm × 58 mm × 11 mm
Mass (approx.):
1.2 kg (excluding accessories)
Design and specifications are subject to change
without notice.
EN12-19_KD-G322_1[EX_EU]f.indd 19EN12-19_KD-G322_1[EX_EU]f.indd 19 10/31/05 8:49:17 AM10/31/05 8:49:17 AM

EN, FR
1105DTSMDTJEIN
Having TROUBLE with operation?
Please reset your unit
Refer to page of How to reset your unit
© 2005 Victor Company of Japan, Limited
Rear_KD-G322_003A_2.indd 2 10/13/05 8:00:53 PM
