JVC KS-FX650R User manual

Safety precaution ------------------------------------- 1-2
Instructions --------------------------------------------- 1-3 - 17
Location of main parts ------------------------------- 2-1
Disassembly method -------------------------------- 2-2
Adjustment method ---------------------------------- 2-8
Wiring connections ----------------------------------- 2-12
Description of major ICs ---------------------------- 2-13
Block diagram ----------------------------------------- 2-22
Standard schematic diagrams -------------------- 2-23
Printed circuit boards -------------------------------- 2-27
Parts list ------------------------------------------------- 3-1 - 16
Contents
CASSETTE RECEIVER
SERVICE MANUAL
KS-FX650R
KS-F550R
No.49547
Mar. 2000
COPYRIGHT 2000 VICTOR COMPANY OF JAPAN, LTD.
Area Suffix
E ..... Continental Europe
Detachable
KS-FX650R
KS-F550R
40Wx4
CD CHANGER CONTROL
TP
RDS
PTY
SCM
FM/AM TAPE
SSM
RPT
DAB
MO
RND
KS-FX650R
40Wx4
DETACHABLE CONTROL PANEL
TP
RDS
PTY
SCM
FM
AM TAPE
SSM
RPT
MO
KS-F550R
Multi
Music
Scan
KS-FX650R
KS-F550R

2-22
KS-FX650R
KS-F550R
Block Diagram
IC751
CHANGER CONTROL
HD74HC126FP-X
HEAD
IC401
PB EQ
CXA2559Q
IC941
POWER AMP.
HA13158
IC911
E.VOLUME
TEA6320T-X
IC701
SYSTEM CONTROL MICON
UPD178016AGC552
TU1
AM/FM TUNER PACK
QAU0156-001
SUB
MOTOR
IC402
DC MOTOR DRIVER
LB1641
LCD1
QLD0100-001
IC651
LCD DRIVER
LC75823E
KEY
S601
–
S619
MAIN
MOTOR
SWITCH
TAPE END.STANDBY
SEEK/STOP
SD/ST
SMETER
JBUS SI
JBUS SO
JBUS I/O
JBUS SCK
SCK SI/SO
CD RCH CD LCH
TUNER L/R
OUT LR OUT RR OUT LF OUT RF
L/R F ± L/R R ±LRO
RRO
CP501
J751 CP961 J931
KEY 0 –2
CJ701
LCDDA LCDCK LCDCE
S3 –S52
COM0 –COM3
CP701
TAPE L/R
F/R MODE STANDBY FF/REW MOTOR SUBMO ± TAPE IN DOLBY MS REEL
SUBMO+ SUBMO-
LCH RCH METAL
DOLBY
F/R
MS
LCH
RCH
FF/REW
MOTOR
TAPE IN
MODE
STANDBY
TAPE END
REEL
CJ401
CP403 CJ402
J1
AM
FM
TO CD CHANGER
KS-FX650R
TO SPEAKER
CONNECTOR TO REAR LINE OUT
KS-FX650R
Tuner.Power AMP.Changer/System Controller LCD DRIVER/KEY SWITCH CIRCUT
MECHANISM CONTROL
Block Diagrams

2-23
KS-FX650R
KS-F550R
ABCDEFG
3
4
5
2
1
Receiver & System control circuit section for KS-F550R
Standard Schematic Diagrams
FM Radio Signal/Radio Main Signal
Tape PB/Main Signal
AM Radio Signal
KS-F550RE/B/G/:FSDH3125-005RV:1/3
Note:/s/C/jes/3125ma.001

2-24
KS-FX650R
KS-F550R
ABCDEFG
3
4
5
2
1
Receiver & System control circuit section for KS-FX650R
FM Radio Signal/Radio Main Signal
Tape PB/Main Signal
CD Signal
AM Radio Signal
KS-FX650RE/B/G:FSDH3109-005RV:1/3
Note:/s/C/jes/3109ma.001

2-25
KS-FX650R
KS-F550R
ABCDEFG
3
4
5
2
1
LCD driver & Operation switch circuit section
KS-FX650RE:FSDH3109SW:2/3
Note:/s/C/jes/3109sw.001

2-26
KS-FX650R
KS-F550R
ABCDEFG
3
4
5
2
1
Mecha control circuit section
Tape PB/Main Signal
KS-FX650RE:FSDH3109MW:3/3
Note:/s/C/jes/3109me.001

3-2
KS-FX650R
KS-F550R
ABCD
3
4
5
2
1
Block: No. M 1 M M
Exploded view of general assembly and parts list
3
10
10
515
5
5
5
21
4
6
10
10
11
20 7
11
1
1-3
1-2
18
19
1-1
17
16
44
50
12
56
51 53
12
51
43
13
13
40
40
40
36
33
35
34
47
LCD1
45
49
46
48
39
9
8
41
26
2-1
30
29
24
27
25
55 28
31
32
38
37
Main board
Mecha control bord
Front board
57
2-2
2
42

3-3
KS-FX650R
KS-F550R
Parts list (General assembly)
Item Parts number Parts name Area
Q'ty Description
Block No. M1MM
1
ZCKSFX250J-FB FRONT ASS'Y
1
KS-FX650R
ZCKSF550R-FB FRONT ASS'Y
1
KS-F550R
1-1 FSJC1052-001 FRONT CHASSIS
1
1-2 FSJC3014-003 CASSETTE LID
1
KS-FX650R
FSJC3014-002 CASSETTE LID
1
KS-F550R
1-3 VKW4947-002 DOOR SPRING
1
2
ZCKSFX650R-NPA FRONT PANEL ASS
1
KS-FX650R
ZCKSF550R-NPA FRONT PANEL ASS
1
KS-F550R
2-1 FSJC1050-002 FRONT PANEL
1
2-2 FSJD3020-01B FINDER ASSY
1
KS-FX650R
FSJD3020-01C FINDER LENS
1
KS-F550R
3
FSKL2001-001 MECHA BKT (L)
1
4
QYSDST2606Z SCREW
1
PCB+MECHA
5
QYSDST2606Z SCREW
4
MECHA+M.BKT
6
FSJC1056-002 TOP CHASSIS
1
7
FSMH3001-201 HEAT SINK
1
8
FSKM3011-002 BOTTOM COVER
1
9
FSMA3004-203 INSULATOR
1
10
QYSDST2604Z SCREW
4
CHASSIS+MECHA B
11
FSKZ4005-001 SCREW
3
12
QYSDST2606Z SCREW
2
CHASSIS+REAR BK
13
QYSDST2606Z SCREW
2
CHASSIS+MAIN PW
15
------------ CASSETTE MECHA
1
NEW COST DN MEC
16
FSKS3010-001 LOCK LEVER
1
17
FSKW4005-003 TORSION SPRING
1
18
FSXP3026-002 RLS KNOB
1
19
FSKW3002-004 COMP.SPRING
1
20
FSKL2002-001 MECHA BKT (R)
1
LEFT BKT
21
FSYH4036-050 SHEET
1
24
FSJK3014-001 LIGHT LENS
1
25
FSYH4036-031 BUTTON SHEET
1
26
FSXP3053-002 POWER BUTTON
1
27
FSXP3064-001 EJECT BUTTON
1
28
FSXP2038-001 DFUNC.BUTTON
1
KS-FX650R
FSXP2038-004 DFUNC.BUTTON
1
KS-F550R
29
FSXP4006-001 SCM BUTTON
1
30
FSXP2041-003 PUSH BUTTON(L)
1
31
FSXP3062-001 PUSH BUTTON(R)
1
KS-FX650R
FSXP3062-003 PUSH BUTTON(R)
1
KS-F550R
32
FSXP2043-001 UP DOWN BBUTTON
1
33
FSXK3003-005 VOLUME KNOB
1
34
FSXP3061-001 SELECT BUTTON
1
35
FSYH4036-032 BLIND SHEET
1
36
FSJK3027-001 RIM LENS
1
37
FSXP3063-001 DETACH BUTTON
1
38
FSKW3002-012 COMP. SPRING
1
FOR DETACH BUTT
39
FSJC1051-001 REAR COVER
1
40
VKZ4777-001 MINI SCREW
5
F.PANEL+REAR CO
41
FSYN3109-D005 NAME PLATE
1
KS-FX650R
FSYN3125-D005 NAME PLATE
1
KS-F550R

3-4
KS-FX650R
KS-F550R
Parts list (General assembly)
Item Parts number Parts name Area
Q'ty Description
Block No. M1MM
42 QMFZ021-100-J1 FUSE 1
43 VMA4652-001SS EARTH PLATE 1
44 FSKL4018-00B P.W.B.BRACKET 1
45 QNZ0440-001 RUBB.CONNECTOR 1
46 FSJK3033-001 L.C.D.LENS 1
47 FSYH3021-001 L.C.D.CASE 1
48 FSKS3020-001 LENS CASE 1
49 FSYH4075-001 BLIND SHEET 1
50 FSKM3012-011 REAR BRACKET 1KS-FX650R
FSKM3012-012 REAR BRACKET 1KS-F550R
51 QYSDST2606Z SCREW 3
53 QYSDSF3006Z SCREW 1 PIN
55 FSXP2045-002 PRESET BUTTON 11-6
56 FSKL4014-002 HEAT SINK 1
57 FSKL4023-001 REG.BRACKET 1
LCD1 QLD0100-001 L.C.DISPL PANEL 1

3-5
KS-FX650R
KS-F550R
ABCD
3
4
5
2
1
Cassette mechanism assembly and parts list
Block: No. M 2 M M
75
109
FG-84M
68
39
11
40
39
66
FG-84M
LEN-315Y2
2
FG-84M
23
FG-84M
47 59
FG-84M
99 100 101 102
9897
73
91
26
24
105
76 107
104
103
65
SW-902
FG-84M
41
10
SW-902
FG-84M
42
CFD-409
CFD-409
49
40
66
75
17
94
93
95
96
16
5
50
28
CFD-409
4
63
64
LEN-315Y2
LEN-315Y2
27
67
25
SW-522B
SW-522B
117
CFD-409
LEN-315Y2
107
48
30
3
FG-84M
FG-84M
12 108
46
FG-84M
FG-84M
FG-84M
FG-84M
44
34
55
SW-522B
21
38
114
22
33
111
85
82
84 86
71
113
43 110
113
32
111
51
61
37
74
35
60
36
72
9
13
FG-84M
FG-84M
CFD-409
106
87 45
1
106
CDS-801

3-6
KS-FX650R
KS-F550R
Parts list (Cassette mechanism)
Item Parts number Parts name Area
Q'ty Description
Block No. M2MM
1 X-0801-1003S MAIN CHASSIS AS 1
2 X-0801-1002S SLIDE CHASSIS A 1
3 X-0801-1008S SIDE BKT ASS'Y 1
4 X-0801-1010S EJECT CAM LIMIT 1
5 X-0801-1013S CASSETTE HANGER 1
9 1-0801-6002S FLYWHEEL ASSY F 1
10 X-0801-2003S GEAR BASE ASS'Y 1
11 X-0801-2021S PINCH ARM F ASS 1
12 X-0801-2022S PINCH ARM R ASS 1
13 1-0801-6003S FLYWHEEL ASSY R 1
16 X-0801-7006S SUB MOTOR ASS'Y 1
17 X-0801-7057S MAIN MOTOR ASSY 1
21 1-0801-1003S DIRECTION PLATE 1
22 1-0801-1004S DIRECTION LINK 1
23 1-0801-1005S PINCH SPG ARM 1
24 1-0801-1006S CASSETTE GUIDE 1
25 1-0801-1007S LOAD ARM 1
26 1-0801-1009S HEAD SUPT SPG 1
27 1-0801-1011S EJECT CAM PLATE 1
28 1-0801-1012S CASSETTE HOLDER 1
30 1-0801-1020S REINFORCE BRKT 1
32 1-0101-2056S IDLE PULLEY(A1) 1
33 1-0801-2004S REDUCTION GEARA 1
34 1-0801-2005S REDUCTION GEARB 1
35 1-0801-2006S SPG HOLDER F 1
36 1-0801-2007S FRICTION GEARPL 1
37 1-0801-2008S FRICTION GEARFF 1
38 1-0801-2009S MODE GEAR 1
39 1-0801-2010S REEL SPINDLE 2
40 1-0801-2011S REEL DRIVER 2
41 1-0801-2014S GEAR BASE ARM 1
42 1-0801-2015S GEAR BASE LINK 1
43 1-0801-2016S TAKE UP GEAR 1
44 1-0801-2017S REFLECTOR GEAR 1
45 1-0801-2018S MODE RACK 1
46 1-0801-2019S MODE SW ACTUATR 1
47 1-0801-2020S TAPE GUIDE 1
48 1-0801-2023S LOAD RACK 1
49 1-0801-2024S RACK LINK 1
50 1-0801-2025S CASSETTE CATCH 1
51 1-0801-2030S SPG HOLDER R 1
55 1-0801-3005S RACK COLLAR 1
59 1-0801-4001S PINCH ARM SPG 1
60 1-0801-4002S TU SPG 1
61 1-0801-4003S FF SPG 1
63 1-0801-4005S EJECTCAM PLT SP 1
64 1-0801-4006S HOLDER CUSH SPG 1
65 1-0801-4007S GEAR BASE SPG 1
66 1-0801-4008S REEL DRIVER SPG 2
67 1-0801-4009S LOAD ARM SPG 1
68 1-0801-4011S HOLDER STAB SPG 1
71 1-0801-5001S BELT 1

3-7
KS-FX650R
KS-F550R
Parts list (Cassette mechanism)
Item Parts number Parts name Area
Q'ty Description
Block No. M2MM
72 1-0801-5002S FELT 17.5*18.5*1.0
73 1-0801-5003S AZIMUTH SCR 2
74 1-0801-5004S FELT 111*18.5*1.0
75 1-0801-5005S REEL WASHER 2
76 21732-6280-36S LUG PLATE 1
82 1-0801-7001S REEL PCB DL 1
84 1-0801-7003S SW(MATSUSHITA) 2(ESE22MH2L)
85 1-0801-7005S SW 1(ALPS SPPB64)
86 1-0801-7024S PHOTO SENSOR 1(ON2170-QR FS)
87 1-0801-7026S FLAT CABLE 10P 1
91 1-0801-7014S HEAD 1(MITSUMIP-5544)
93 10801-7009-0S M.MOTOR WIRE 1BLACK
94 10801-7009-1S M.MOTOR WIRE 1RED
95 10801-7010-0S S.MOTOR WIRE 1 ORANGE
96 10801-7010-1S S.MOTOR WIRE 1BROWN
97 10801-7015-0S HEAD WIRE BLACK 1
98 10801-7015-1S HEAD WIRE BROWN 1
99 10801-7015-2S HEAD WIRE RED 1
100 10801-7015-3S HEAD WIRE ORANG 1
101 10801-7015-4S HEAD WIRE YELLO 1
102 10801-7015-5S HEAD WIRE WHITE 1
103 1-0801-7016S HEAD PCB 1
104 1-0801-7025S CONN S6B-PH-K-S 1
105 21382-3060-C2S +PLAIN B-TYPE 1M2.3*6.0
106 2-1032-0025-C2S +SCREW PLAIN 2M2*2.5
107 21332-0035-P1S S-TYPE PRECISIO 2M2*3.5
108 21112-6035-C2S +SCREW PLAIN 1M2.6*3.5
109 2-1816-0032-E8S LMW-S 21.6*3.2*0.35
110 21812-0032-D2S PSW-S 11.2*3.2*0.25
111 1-0036-5024S PSW-S(REEL B) 21.5*3.2*0.25
113 2-1821-0040-D1S PSW 22.1*4.0*0.25
114 21821-0040-D2S PSW-S 12.1*4.0*0.25
117 2-1711-5040-16S E-RING 11.5

3-8
KS-FX650R
KS-F550R
SW-902
SW-522B
FG-84M
CFD-409
LEN-315Y2
Grease point
FG-84M
FG-84M
SW-902
SW-902
FG-84M
FG-84M
SW-902
FG-84M
FG-84M
SW-902
SW-902

3-9
KS-FX650R
KS-F550R

3-10
KS-FX650R
KS-F550R
Electrical parts list
Main board Block No. 01
C 1 QERF1HM-104Z E CAPACITOR .10MF 20% 50V
C 6 NCB21EK-563X C CAPACITOR
C 7 NCB21EK-123X C CAPACITOR
C 9 QERF1CM-107Z E CAPACITOR 220MF 20% 10V
C 17 NCS21HJ-151X C CAPACITOR
C 18 QERF1HM-224Z E CAPACITOR .22MF 20% 50V
C 20 NCS21HJ-102X C CAPACITOR
C 21 QEQF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 24 NCB21EK-473X C CAPACITOR
C 25 NCB21EK-104X C CAPACITOR
C 29 NDC21HJ-100X C CAPACITOR
C 30 NDC21HJ-470X C CAPACITOR
C 111 QERF1HM-225Z E CAPACITOR KS-FX650R
C 112 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 113 QFLA1HJ-822Z M CAPACITOR 8200PF 5% 50V
C 114 QFV61HJ-154Z TF CAPACITOR .15MF 5% 50V
C 115 QERF1HM-224Z E CAPACITOR .22MF 20% 50V
C 116 QFV61HJ-333Z TF CAPACITOR .033MF 5% 50V
C 117 QFLA1HJ-562Z M CAPACITOR 5600PF 5% 50V
C 118 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 119 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 143 NCS21HJ-471X C CAPACITOR
C 144 NCS21HJ-471X C CAPACITOR
C 151 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 152 NCB21HK-122X C CAPACITOR
C 153 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 154 NCB21HK-153X C CAPACITOR
C 211 QERF1HM-225Z E CAPACITOR KS-FX650R
C 212 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 213 QFLA1HJ-822Z M CAPACITOR 8200PF 5% 50V
C 214 QFV61HJ-154Z TF CAPACITOR .15MF 5% 50V
C 215 QERF1HM-224Z E CAPACITOR .22MF 20% 50V
C 216 QFV61HJ-333Z TF CAPACITOR .033MF 5% 50V
C 217 QFLA1HJ-562Z M CAPACITOR 5600PF 5% 50V
C 218 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 219 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 243 NCS21HJ-471X C CAPACITOR
C 244 NCS21HJ-471X C CAPACITOR
C 245 NCB21EK-104X C CAPACITOR
C 246 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 247 NCB21EK-104X C CAPACITOR
C 251 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 252 NCB21HK-122X C CAPACITOR
C 253 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 254 NCB21HK-153X C CAPACITOR
C 301 NCB21HK-331X C.CAPA. C.M S
Q
USE
C 302 NCB21HK-103X C CAPACITOR S
Q
USE
C 303 NCB21EK-472X C CAPACITOR MARKET CLAIM
C 304 NCB21EK-104X C CAPACITOR S
Q
USE
C 305 QERF1HM-474Z E CAPACITOR S
Q
USE
C 701 NDC21HJ-270X C CAPACITOR
C 702 NDC21HJ-270X C CAPACITOR
C 703 NCB21EK-104X C CAPACITOR
C 704 NCB21EK-104X C CAPACITOR
C 705 NCB21HK-102X C CAPACITOR
C 707 NCB21EK-104X C CAPACITOR
C 708 QER41AM-227 E CAPACITOR 220MF 20% 10V
C 709 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 710 NCS21HJ-121X C CAPACITOR
C 711 NCB21CK-224X C CAPACITOR
C 712 NCB21HK-104X C CAPACITOR
C 751 NCB21EK-104X C CAPACITOR KS-FX650R
C 761 NCB21EK-223X C CAPACITOR
C 762 NCS21HJ-561X C CAPACITOR
C 763 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 764 NDC21HJ-820X C CAPACITOR
C 765 NDC21HJ-470X C CAPACITOR
C 766 QER41CM-476 E CAPACITOR 47MF 20% 16V
C 767 NCB21HK-103X C CAPACITOR
C 891 NCB21EK-104X C CAPACITOR
C 901 NCB11CK-225X C CAPACITOR
C 912 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 913 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 932 NCB21EK-104X C CAPACITOR
C 941 NCB21EK-104X C CAPACITOR
C 942 NCB21EK-104X C CAPACITOR
C 943 NCB21EK-104X C CAPACITOR
C 944 NCB21EK-104X C CAPACITOR
C 945 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 961 QETB1CM-228 E CAPACITOR 2200MF 20% 16V
C 962 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 963 QERF1HM-104Z E CAPACITOR .10MF 20% 50V
C 964 QETN0JM-228Z E CAPACITOR 2200MF 20% 6.3V
C 965 QER41AM-227 E CAPACITOR 220MF 20% 10V
C 966 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 967 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 968 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 969 NCB21EK-473X C CAPACITOR
C 970 NCB21EK-473X C CAPACITOR
C 977 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 978 QERF1AM-106Z E CAPACITOR 10MF 20% 10V
C 979 QER41CM-106 E CAPACITOR 10MF 20% 16V
CJ701 VMC0334-001 CONNECTOR
CP50 QGB1214J1-18S CONNECTOR
CP96 QNZ0112-001 CAR CONNECTOR
D 1 1SS119-041 SI DIODE
D 2 1SS119-041 SI DIODE
D 3 MA152WK-X SI DIODE
D 5 1SS119-041 SI DIODE
D 6 MTZJ9.1C-T2 Z DIODE I/M
D 241 1SS119-041 SI DIODE
D 242 1SS119-041 SI DIODE
D 243 MA152WK-X SI DIODE
D 701 MA152WK-X SI DIODE
D 741 1SS119-041 SI DIODE
D 742 1SS119-041 SI DIODE
D 891 MA152WA-X DIODE
D 931 MA152WA-X DIODE
D 951 1SS133-T2 SI DIODE
D 961 1N5401-TU-15 DIODE
D 963 1SS119-041 SI DIODE
D 965 CRS03-W SB DIODE
D 966 CRS03-W SB DIODE
D 977 MA152WK-X SI DIODE
D 978 MTZJ4.7C-T2 Z.DIODE I.M
D 979 MA152WK-X SI DIODE
D 981 MA152WA-X DIODE
D 982 MA152WK-X SI DIODE
IC701 UPD178018AGC552 IC
IC751 HD74HC126FP-X IC KS-FX650R
IC761 SAA6579T-X IC
IC911 TEA6320T-X IC
IC941 HA13158A IC
IC961 BA4905-V3 IC
J 1 QNZ0009-001 CAR ANT JACK
J 751 QNZ0095-001 CONNECTOR KS-FX650R
J 931 QNN0170-001 PIN JACK (REEL)
L 1 QQL231K-4R7Y INDUCTOR
L 701 QQL231K-470Y INDUCTOR
L 961 QQR0703-001 CHOKE COIL
Q
1 DTC114EKA-X TR
Q
2 DTC114EKA-X TR
Q
3 2SC2412K/R/-X TRANSISTOR
Q
4 DTA114EKA-X DIGITAL.TRANSIS
Q
5 2SA1037AK/RS/-X TRANSISTOR
Q
6 2SA1037AK/RS/-X TRANSISTOR
Q
7 2SC3661-X TRANSISTOR
Q
10 2SC3661-X TRANSISTOR
Q
11 2SC2412K/R/-X TRANSISTOR
Q
12 2SC2412K/R/-X TRANSISTOR
Q
131 2SC2412K/R/-X TRANSISTOR
Q
151 2SC2412K/R/-X TRANSISTOR
Q
231 2SC2412K/R/-X TRANSISTOR
Item Parts number Parts name Remaks Area Item Parts number Parts name Remaks Area
C 31 NCS21HJ-101X C CAPACITOR
C 713 NCS21HJ-121X C CAPACITOR
C 911 QER41CM-476 E CAPACITOR 47MF 20% 16V

3-11
KS-FX650R
KS-F550R
Main board Block No. 01
Q
241 2SC2412K/R/-X TRANSISTOR
Q
251 2SC2412K/R/-X TRANSISTOR
Q
301 2SD601A/R/-X TRANSISTOR S
Q
USE
Q
302 2SD601A/R/-X TRANSISTOR S
Q
USE
Q
303 DTC114EKA-X TR
Q
750 2SC2412K/R/-X SI.TRANSISTOR
Q
891 UN2211-X TRANSISTOR
Q
951 DTA114EKA-X DIGITAL.TRANSIS
Q
962 2SB1322/RS/-T TRANSISTOR
Q
963 2SA1037AK/RS/-X TRANSISTOR
Q
964 DTC114EKA-X TR
Q
965 DTC114EKA-X TR
Q
966 DTC114EKA-X TR
Q
967 2SA1037AK/RS/-X TRANSISTOR
Q
978 DTC114EKA-X TR
Q
979 DTA114EKA-X DIGITAL.TRANSIS
R 3 NRSA02J-472X MG RESISTOR
R 4 NRSA02J-473X MG RESISTOR
R 5 NRSA02J-332X MG RESISTOR
R 7 NRSA02J-473X MG RESISTOR
R 8 NRSA02J-472X MG RESISTOR
R 9 NRSA02J-102X MG RESISTOR
R 10 NRSA02J-392X MG RESISTOR
R 12 NRSA02J-102X MG RESISTOR
R 14 NRS181J-330X MG RESISTOR
R 24 NRSA02J-102X MG RESISTOR
R 25 NRSA02J-102X MG RESISTOR
R 26 NRSA02J-103X MG RESISTOR
R 27 NRSA02J-102X MG RESISTOR
R 29 NRSA02J-152X MG RESISTOR
R 30 NRS181J-120X MG RESISTOR
R 32 NRSA02J-0R0X MG RESISTOR
R 34 NRSA02J-223X MG RESISTOR
R 112 NRSA02J-223X MG RESISTOR
R 113 NRSA02J-222X MG RESISTOR
R 115 NRS181J-334X MG RESISTOR
R 116 NRS181J-102X MG RESISTOR
R 132 NRSA02J-222X MG RESISTOR
R 135 NRSA02J-101X MG RESISTOR
R 136 NRSA02J-102X MG RESISTOR
R 141 NRSA02J-153X MG RESISTOR
R 142 NRSA02J-153X MG RESISTOR
R 143 NRSA02J-393X MG RESISTOR
R 144 NRSA02J-393X MG RESISTOR
R 151 NRSA02J-103X MG RESISTOR
R 152 NRSA02J-223X MG RESISTOR
R 153 NRSA02J-472X MG RESISTOR
R 212 NRSA02J-223X MG RESISTOR
R 213 NRSA02J-222X MG RESISTOR
R 215 NRS181J-334X MG RESISTOR
R 216 NRS181J-102X MG RESISTOR
R 232 NRSA02J-222X MG RESISTOR
R 235 NRS181J-101X MG RESISTOR
R 236 NRSA02J-102X MG RESISTOR
R 241 NRSA02J-153X MG RESISTOR
R 242 NRSA02J-153X MG RESISTOR
R 243 NRSA02J-393X MG RESISTOR
R 244 NRSA02J-393X MG RESISTOR
R 245 NRS181J-123X MG RESISTOR
R 246 NRSA02J-153X MG RESISTOR
R 247 NRSA02J-393X MG RESISTOR
R 251 NRSA02J-103X MG RESISTOR
R 252 NRSA02J-223X MG RESISTOR
R 253 NRSA02J-472X MG RESISTOR
R 301 NRSA02J-473X MG RESISTOR S
Q
USE
R 302 NRSA02J-473X MG RESISTOR S
Q
USE
R 303 NRSA02J-103X MG RESISTOR S
Q
USE
R 304 NRSA02J-222X MG RESISTOR S
Q
USE
R 305 NRSA02J-153X MG RESISTOR S
Q
USE
R 306 NRSA02J-471X MG RESISTOR S
Q
USE
R 307 NRSA02J-103X MG RESISTOR S
Q
USE
R 308 NRSA02J-473X MG RESISTOR
R 701 NRSA02J-271X MG RESISTOR
R 702 NRS181J-271X MG RESISTOR
R 703 NRS181J-271X MG RESISTOR
R 704 NRSA02J-271X MG RESISTOR
R 705 NRSA02J-103X MG RESISTOR
R 706 NRSA02J-473X MG RESISTOR
R 707 NRS181J-473X MG RESISTOR REMOTE TO GND
R 708 NRSA02J-104X MG RESISTOR
R 709 NRS181J-104X MG RESISTOR
R 710 NRS181J-272X MG RESISTOR
R 711 NRSA02J-391X MG RESISTOR
R 712 NRS181J-103X MG RESISTOR
R 713 NRSA02J-103X MG RESISTOR
R 715 NRS181J-103X MG RESISTOR
R 716 NRS181J-103X MG RESISTOR
R 717 NRS181J-103X MG RESISTOR
R 718 NRS181J-472X MG RESISTOR
R 719 NRSA02J-472X MG RESISTOR
R 720 NRSA02J-472X MG RESISTOR
R 721 NRS181J-472X MG RESISTOR KS-FX650R
R 722 NRSA02J-472X MG RESISTOR KS-FX650R
R 723 NRS181J-472X MG RESISTOR KS-FX650R
R 724 NRS181J-472X MG RESISTOR
R 725 NRS181J-472X MG RESISTOR
R 726 NRS181J-472X MG RESISTOR
R 727 NRSA02J-472X MG RESISTOR
R 732 NRS181J-473X MG RESISTOR
R 733 NRSA02J-472X MG RESISTOR
R 734 NRSA02J-472X MG RESISTOR
R 736 NRSA02J-473X MG RESISTOR
R 737 NRSA02J-473X MG RESISTOR
R 738 NRS181J-473X MG RESISTOR
R 739 NRSA02J-473X MG RESISTOR
R 740 NRS181J-473X MG RESISTOR
R 741 NRSA02J-473X MG RESISTOR
R 743 NRSA02J-103X MG RESISTOR S
Q
USE
R 746 NRSA02J-473X MG RESISTOR
R 747 NRSA02J-473X M.G.RESISTOR KS-F550R
R 748 NRSA02J-473X MG RESISTOR KS-FX650R
R 750 NRSA02J-243X MG RESISTOR
R 751 NRSA02J-473X M.G.RESISTOR KS-F550R
R 752 NRSA02J-334X MG RESISTOR
R 753 NRSA02J-223X MG RESISTOR
R 754 NRSA02J-101X MG RESISTOR KS-FX650R
R 755 NRSA02J-103X MG RESISTOR KS-FX650R
R 756 NRSA02J-104X MG RESISTOR KS-FX650R
R 757 NRSA02J-104X MG RESISTOR
R 758 NRSA02J-101X MG RESISTOR KS-FX650R
R 759 NRSA02J-334X MG RESISTOR KS-FX650R
R 761 NRSA02J-222X MG RESISTOR
R 762 NRSA02J-222X MG RESISTOR
R 763 NRSA02J-222X MG RESISTOR
R 771 NRSA02J-223X M.G.RESISTOR KS-F550R
R 773 NRSA02J-473X MG RESISTOR KS-FX650R
R 891 NRSA02J-473X MG RESISTOR
R 892 NRSA02J-102X MG RESISTOR
R 911 NRSA02J-271X MG RESISTOR
R 912 NRSA02J-271X MG RESISTOR
R 913 NRS181J-100X MG RESISTOR
R 941 NRSA02J-473X MG RESISTOR
R 961 QRE141J-470Y C RESISTOR 47 5% 1/4W
R 962 NRSA02J-103X MG RESISTOR
R 963 NRSA02J-472X MG RESISTOR
R 966 NRSA02J-473X MG RESISTOR
R 967 NRSA02J-222X MG RESISTOR
R 969 NRSA02J-222X MG RESISTOR
R 970 NRSA02J-473X MG RESISTOR
R 974 NRS181J-123X MG RESISTOR
R 975 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 977 NRS181J-471X MG RESISTOR
R 978 NRS181J-682X MG RESISTOR
R 979 NRSA02J-103X MG RESISTOR
Item Parts number Parts name Remaks Area Item Parts number Parts name Remaks Area
Q
952 DTA114EKA-X DIGITAL.TRANSIS

3-12
KS-FX650R
KS-F550R
Main board Block No. 01
R 980 NRSA02J-183X MG RESISTOR
R 981 NRS181J-102X MG RESISTOR
R 982 NRS181J-103X MG RESISTOR
R 983 NRS181J-103X MG RESISTOR
TU 1 QAU0156-001 TUNER MARKET CLAIM
X 701 QAX0406-001Z CRYSTAL
X 761 QAX0263-001Z CRYSTAL
Item Parts number Parts name Remaks Area

3-13
KS-FX650R
KS-F550R
Front board Block No. 02
C 651 NCB21HK-103X C CAPACITOR
C 652 NBE20JM-475X TS E CAPACITOR
C 653 NCB21HK-681X C CAPACITOR
CP70 VMC0335-001 CONNECTOR
D 601 SML-310LT/MN/-X LED
D 602 LNJ308G81/1-3/X LED
D 603 LNJ308G81/1-3/X LED
D 604 LNJ308G81/1-3/X LED
D 605 LNJ308G81/1-3/X LED
D 606 LNJ308G81/1-3/X LED
D 607 LNJ308G81/1-3/X LED
D 608 LNJ308G81/1-3/X LED
D 609 LNJ308G81/1-3/X LED
D 610 LNJ308G81/1-3/X LED
D 611 LNJ308G81/1-3/X LED
D 612 LNJ308G81/1-3/X LED
D 613 LNJ308G81/1-3/X LED
D 614 LNJ308G81/1-3/X LED
D 615 LNJ308G81/1-3/X LED
D 616 LNJ308G81/1-3/X LED
D 617 LNJ308G81/1-3/X LED
D 618 LNJ308G81/1-3/X LED
D 619 LNJ308G81/1-3/X LED
D 620 LNJ308G81/1-3/X LED
D 621 LNJ308G81/1-3/X LED
D 622 LNJ308G81/1-3/X LED
D 623 LNJ308G81/1-3/X LED
D 624 LNJ308G81/1-3/X LED
D 625 LNJ308G81/1-3/X LED
D 626 LNJ308G81/1-3/X LED
D 627 LNJ308G81/1-3/X LED
D 654 MA152WK-X SI DIODE
IC651 LC75823W IC
JS601 QSW0863-001 JOG SHUTTLE SW
PL601 QLL0033-003 LAMP BLUE CAP
PL603 QLL0033-003 LAMP BLUE CAP
R 601 NRSA02J-561X MG RESISTOR
R 602 NRSA02J-821X MG RESISTOR
R 603 NRSA02J-122X MG RESISTOR
R 604 NRSA02J-182X MG RESISTOR
R 605 NRSA02J-272X MG RESISTOR
R 606 NRSA02J-561X MG RESISTOR
R 607 NRSA02J-821X MG RESISTOR
R 608 NRSA02J-122X MG RESISTOR
R 609 NRSA02J-182X MG RESISTOR
R 610 NRSA02J-272X MG RESISTOR
R 611 NRSA02J-392X MG RESISTOR
R 612 NRSA02J-103X MG RESISTOR
R 613 NRSA02J-561X MG RESISTOR
R 614 NRSA02J-821X MG RESISTOR
R 615 NRSA02J-122X MG RESISTOR
R 616 NRSA02J-182X MG RESISTOR
R 617 NRSA02J-272X MG RESISTOR
R 631 NRSA02J-821X MG RESISTOR
R 632 NRSA02J-391X MG RESISTOR
R 634 NRSA02J-221X MG RESISTOR
R 635 NRSA02J-471X MG RESISTOR
R 636 NRSA02J-471X MG RESISTOR
R 637 NRSA02J-471X MG RESISTOR
R 638 NRSA02J-221X MG RESISTOR
R 639 NRSA02J-221X MG RESISTOR
R 640 NRSA02J-471X MG RESISTOR FOR KS-FX550
R 651 NRSA02J-152X MG RESISTOR
R 652 NRSA02J-473X MG RESISTOR
R 653 NRSA02J-184X MG RESISTOR
R 654 NRSA02J-103X MG RESISTOR
R 655 NRSA02J-103X MG RESISTOR
R 656 NRSA02J-103X MG RESISTOR
R 663 NRSA02J-101X MG RESISTOR
S 601 NSW0066-001X TACT SWITCH
S 602 NSW0066-001X TACT SWITCH
S 603 NSW0066-001X TACT SWITCH
S 604 NSW0066-001X TACT SWITCH
S 605 NSW0066-001X TACT SWITCH
S 606 NSW0066-001X TACT SWITCH
S 607 NSW0066-001X TACT SWITCH
S 608 NSW0066-001X TACT SWITCH
S 609 NSW0066-001X TACT SWITCH
S 610 NSW0066-001X TACT SWITCH
S 611 NSW0066-001X TACT SWITCH
S 612 NSW0066-001X TACT SWITCH
S 613 NSW0066-001X TACT SWITCH
S 614 NSW0066-001X TACT SWITCH
S 615 NSW0066-001X TACT SWITCH
S 616 NSW0066-001X TACT SWITCH
S 617 NSW0066-001X TACT SWITCH
S 618 NSW0066-001X TACT SWITCH
S 619 NSW0066-001X TACT SWITCH
S 620 NSW0066-001X TACT SWITCH
Item Parts number Parts name Remaks Area Item Parts number Parts name Remaks Area

3-14
KS-FX650R
KS-F550R
Mecha control board Block No. 02
C 401 NDC21HJ-101X C CAPACITOR
C 402 NDC21HJ-101X C CAPACITOR
C 403 NDC21HJ-101X C CAPACITOR
C 404 NDC21HJ-101X C CAPACITOR
C 405 NDC21HJ-101X C CAPACITOR
C 406 NDC21HJ-101X C CAPACITOR
C 407 NDC21HJ-101X C CAPACITOR
C 408 NDC21HJ-101X C CAPACITOR
C 409 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 410 QFV61HJ-153Z TF CAPACITOR .015MF 5% 50V
C 411 QFV61HJ-153Z TF CAPACITOR .015MF 5% 50V
C 412 NCB21EK-104X C CAPACITOR
C 413 NCB21EK-104X C CAPACITOR
C 414 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 418 NDC21HJ-221X C CAPACITOR
C 419 QERF1HM-474Z E CAPACITOR .47MF 20% 50V
C 421 NCB21HK-103X C CAPACITOR
C 422 NCB21EK-104X C CAPACITOR
C 423 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 424 NCB21EK-104X C CAPACITOR
C 425 NCB21HK-103X C CAPACITOR
CN40 QGB1214K1-18S CONNECTOR
CN40 VMP3501-001 CONNECTOR
CN40 QGF1219F1-10S CONNECTOR
D 401 MA3047/H/-X
D 402 DSK10C-T1 DIODE
IC401 CXA2559Q IC
IC402 LB1641 IC
Q
402 DTC114EKA-X TR
Q
403 2SB1322/RS/-T TRANSISTOR
R 401 NRS181J-391X MG RESISTOR
R 402 NRSA02J-104X MG RESISTOR
R 403 NRSA02J-104X MG RESISTOR
R 404 NRSA02J-104X MG RESISTOR
R 405 NRSA02J-104X MG RESISTOR
R 406 NRSA02J-181X MG RESISTOR
R 407 NRSA02J-181X MG RESISTOR
R 408 NRSA02J-123X MG RESISTOR
R 409 NRSA02J-243X MG RESISTOR
R 410 NRSA02J-243X MG RESISTOR
R 411 NRSA02J-123X MG RESISTOR
R 412 NRSA02J-101X MG RESISTOR
R 413 NRSA02J-183X MG RESISTOR
R 414 NRSA02J-392X MG RESISTOR
R 415 NRSA02J-223X MG RESISTOR
R 416 NRSA02J-914X MG RESISTOR
R 417 NRSA02J-103X MG RESISTOR
R 418 NRSA02J-153X MG RESISTOR
R 422 NRSA02J-332X MG RESISTOR
R 423 NRS181J-473X MG RESISTOR
R 424 NRSA02J-332X MG RESISTOR
R 425 NRS181J-330X MG RESISTOR
R 426 QUY150-050Y BUS WIRE
Item Parts number Parts name Remaks Area

3-15
KS-FX650R
KS-F550R
Packing materials and accessories parts list
Block: No. M 3 M M
Block: No. M 4 M M
A9~A13
P1
P4
A17A14
A15
A19
A16
A18
P3
P5
P2
A1
13
9
10
11
12
14
15
19
P5 P1
A1,A2,A3,A4
