JVC KW-AVX716 User manual

ENGLISHESPAÑOL
FRANÇAIS
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
For canceling the display demonstration, see page 8.
Para cancelar la demonstración en pantalla, consulte la página 8.
Pour annuler la démonstration des affichages, référez-vous à la page 8.
KW-ADV790
DVD RECEIVER WITH MONITOR KW-AVX710
For customer Use:
Enter below the Model No.
and Serial No. which are
located on the top or bottom
of the cabinet. Retain this
information for future
reference.
Model No.
Serial No.
KW-ADV790
RECEPTOR DVD CON MONITOR KW-AVX710
KW-ADV790
RÉCEPTEUR DVD ET MONITEUR KW-AVX710
LVT1778-001A
[J]
Cover_KW-AVX710J.indd 2Cover_KW-AVX710J.indd 2 07.11.27 8:20:33 PM07.11.27 8:20:33 PM

ENGLISH
2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: (For U.S.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
WARNINGS:
To prevent accidents and damage
• DO NOT install any unit or wire any cable in a
location where;
– it may obstruct the steering wheel and
gearshift lever operations.
– it may obstruct the operation of safety devices
such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
If you need to operate the unit while driving, be
sure to look around carefully.
• The driver must not watch the monitor while
driving.
INFORMATION (For U.S.A.)
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment
and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV
technician for help.
Caution
Changes or modifications not approved by JVC could
void the user’s authority to operate the equipment.
[European Union only]
CAUTION
This product has a fluorescent lamp that
contains mercury. Disposal of these materials
may be regulated in your community due to
environmental considerations. For disposal or
recycling information, please contact your local
authorities or for USA, the Electronic Industries
Alliance: http://www.eiae.org.
EN_KW-AVX710[J].indb 2EN_KW-AVX710[J].indb 2 07.12.5 11:58:46 AM07.12.5 11:58:46 AM

3
ENGLISH
INTRODUCTION
How to reset your unit
How to forcibly eject a disc
• If this does not work, reset the unit.
Cautions on the monitor:
• The monitor built in this unit has been produced
with high precision, but it may have some
ineffective dots. This is inevitable and is not
malfunction.
• Do not expose the monitor to direct sunlight.
• Do not operate the touch panel using a ball-point
pen or similar tool with the sharp tip.
Touch the buttons on the touch panel with your
finger directly (if you are wearing a glove, take it
off).
• When the temperature is very cold or very hot...
– Chemical changes occur inside, causing
malfunction.
– Pictures may not appear clearly or may move
slowly. Pictures may not be synchronized with
the sound or picture quality may decline in
such environments.
Contents
INTRODUCTION
Playable disc types .......................... 4
Basic operations—
Monitor panel/touch panel
............ 5
Basic operations—
Remote controller (RM-RK252) ...... 6
OPERATIONS
Before operating the unit ................ 8
Common operations ........................ 9
Listening to the radio ...................... 10
Disc operations................................ 13
EXTERNAL DEVICES
Bluetooth® operations—
Cellular phone/audio player .......... 27
Listening to the CD changer.............. 34
Listening to the satellite radio ......... 36
Listening to the HD Radio™ Broadcast .... 39
Listening to the iPod........................ 40
Using other external components..... 42
SETTINGS
Sound equalization.......................... 45
Assigning titles to the sources .......... 46
Menu operations ............................. 47
REFERENCES
Maintenance................................... 56
More about this unit ........................ 57
Troubleshooting.............................. 64
Specifications.................................. 68
NO EJECT?
EMERGENCY EJECT?
Exit
ENTER
Back
11
3
2
at the same time
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
• Your preset
adjustments will
also be erased.
EN_KW-AVX710[J].indb 3EN_KW-AVX710[J].indb 3 07.12.5 11:58:53 AM07.12.5 11:58:53 AM

ENGLISH
4
Disc type Recording format, file type, etc. Playable
DVD DVD Video (Region Code: 1)*1
DVD Audio
DVD-ROM
DVD Recordable/Rewritable
(DVD-R/-RW*2, +R/+RW*3)
• DVD Video: UDF bridge
• DVD-VR
• DivX/MPEG1/MPEG2/JPEG/MP3/
WMA/WAV: ISO 9660 level 1,
level 2, Romeo, Joliet
DVD Video
DVD-VR
DivX/MPEG1/MPEG2
JPEG
MP3/WMA/WAV
AAC
MPEG4
DVD+VR
DVD-RAM
Dual Disc DVD side
Non-DVD side
CD/VCD Audio CD/CD Text (CD-DA)/DTS-CD
VCD (Video CD)
SVCD (Super Video CD)
CD-ROM
CD-I (CD-I Ready)
CD Recordable/Rewritable
(CD-R/-RW)
• ISO 9660 level 1, level 2, Romeo,
Joliet
CD-DA
MP3/WMA/WAV
JPEG
DivX/MPEG1/MPEG2
AAC
MPEG4
*1If you insert a DVD Video disc of an incorrect Region Code, “Region code error” appears on the screen.
*2DVD-R recorded in multi-border format is also playable (except for dual layer discs).
DVD-RW dual layer discs are not playable.
*3It is possible to play back finalized +R/+RW (Video format only) discs.
+RW double layer discs are not playable.
Playable disc types
Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product may not be recommended.
EN_KW-AVX710[J].indb 4EN_KW-AVX710[J].indb 4 07.12.5 11:58:54 AM07.12.5 11:58:54 AM

5
ENGLISH
INTRODUCTION
Basic operations — Monitor panel/touch panel
• Turn on the power.
• Turn off the power. [Hold]
• Attenuate the sound (if the power is on).
Change the sources.
Remote sensorAdjust the volume.
Reset the unit.
• Use only when the internal system malfunctions.
Display <AV Menu> screen.
Display and erase the Short Cut windows.
Available functions vary among the sources. For details, see each source operation
section.
Change the display information.
• [OPEN]: Open the monitor panel.
• [EJECT]: Eject the disc.
• [CLOSE]: Close the monitor panel.
• [TILT +/–]: Tilt the monitor panel.
• [Exit]: Erase this screen.
• Shaded icons cannot be used.
• In the explanation, buttons on the touch panel
are indicated inside [ ].
• For details on the touch panel operations, see
each source operation section.
Display <Source Menu> screen.
Display <AV Menu> screen.
☞page 47
• Display <Open/Tilt> menu.
• Eject the disc and display <Open/Tilt>
menu. [Hold]
• Close the monitor panel when <Open/Tilt>
menu is displayed.
☞page 47
☞page 9
☞page 9
<Open/Tilt> menu
EN_KW-AVX710[J].indb 5EN_KW-AVX710[J].indb 5 07.12.5 11:58:55 AM07.12.5 11:58:55 AM

ENGLISH
6
Basic operations — Remote controller (RM-RK252)
Main elements and features
1• Turns on the power.
• Attenuates the sound if the power is on.
• Turns off the power if pressed and held (while
the power is on).
2• Reverse search
• Reverse slow motion (during pause)
3Adjusts the volume level.
• Does not function as “2nd VOL.”
4• Displays <Dial Menu> screen.
• Displays <Redial> menu if pressed and held.
• Answers incoming calls.
5• DVD/DivX 6: Shows the disc menu.
• VCD: Resumes PBC playback.
• DVD-VR: Shows the Original Program screen.
6Shows the on-screen bar.
• Does not function as “ .“
R03/LR03/AAA
Installing the battery
Insert the batteries into the remote controller by
matching the polarity (+ and –) correctly.
Caution:
Battery shall not be exposed to excessive heat such
as sunshine, fire or the like.
• If the range or effectiveness of the remote controller
decreases, replace both batteries.
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
The unit is equipped with the steering wheel
remote control function.
• See the Installation/Connection Manual (separate
volume) for connection.
EN_KW-AVX710[J].indb 6EN_KW-AVX710[J].indb 6 07.12.5 11:58:55 AM07.12.5 11:58:55 AM

7
ENGLISH
INTRODUCTION
p• Forward search
• Forward slow motion (during pause)
qSelects the source.
wFor disc operations:
Starts playback/pauses.
For Bluetooth operations:
• Answers incoming calls.
• Starts playback/pauses. (for audio player
operation).
eChanges the aspect ratio of the playback
pictures.
r“TUNER”/”SAT”/”HD Radio”: Selects the bands.
“DISC”: Stops playback.
“Bluetooth PHONE”: Ends the call.
“Bluetooth AUDIO”: Starts playback/pauses.
tVCD: Returns to the PBC menu.
y• DVD Video/DivX 6: Shows the disc menu.
• VCD: Resumes PBC playback.
• DVD-VR: Shows the Playlist screen.
u• Makes selection/settings.
• @/ #: Skips back or forward by five minutes
for DivX/MPEG1/MPEG2.
• %/ fi: Changes discs for “CD-CH.”
i*3• Switches number entry mode for “DISC.”
• Erases the misentry after entering a wrong
number.
• Does not function as “SURROUND.”
o*3Number buttons
• Enters numbers.
• “TUNER”/”SAT”/”HD Radio”: Selects the preset
station directly.
*1Functions as a number button only (see o).
*2Not used for this unit.
*3Functions when pressed with SHIFT.
7Functions with other buttons (see iand o).
8Changes the display information.
9For disc operations:
• 5/ ∞:
DVD: Selects the title.
DVD-VR: Selects the program/Playlist.
Other discs (except VCD/CD): Selects the
folders.
• 4/ ¢:
– Press briefly: reverse skip/forward skip
– Press and hold: reverse search/forward
search
For FM/AM and HD Radio operations:
• 5/ ∞:
FM/AM: Selects the preset stations.
HD Radio: Selects a multicast channel.
• 4/ ¢: Functions to search for stations.
– Press briefly: Auto Search
– Press and hold: Manual Search
For satellite tuner operations:
• 5/ ∞: Selects the categories.
• 4/ ¢:
– Selects a channel rapidly if pressed and held.
– Selects a channel if pressed.
For Apple iPod operations:
• ∞: Starts playback/pauses
• 5: Enters the main menu (then 5/ ∞
/ 4/ ¢work as menu selecting
buttons).
In the main menu:
• 5: Returns to the previous menu.
• ∞: Confirms the selection.
• 4/ ¢
– Press briefly: Selects an item.
– Press and hold: Skips ten items at a time.
For Bluetooth operations:
• 4/ ¢: reverse skip/forward skip (for
audio player operation)
EN_KW-AVX710[J].indb 7EN_KW-AVX710[J].indb 7 07.12.5 11:58:56 AM07.12.5 11:58:56 AM

8
ENGLISH
You can cancel the demonstration on the screen and set
the clock.
• Non-available items will be shaded on the AV Menu
screens.
Indication language:
In this manual, English indications are used
for purpose of explanation. You can select the
indication language. (☞page 49)
~Turn on the power.
ŸDisplay <AV Menu> screen.
!Display <Setup> menu.
⁄Cancel the demonstration.
Select <Off>.
@Set the clock settings.
¤Finish the procedure.
Before operating the unit
Moves to the succeeding menu page
Moves to the preceding menu page
Return to the previous screen.
EN_KW-AVX710[J].indb 8EN_KW-AVX710[J].indb 8 07.12.5 11:58:57 AM07.12.5 11:58:57 AM

OPERATIONS
9
ENGLISH
Changing the display
information
• Available display information varies among the
playback sources.
On the monitor panel only:
• Each time you press DISP, the display changes to
show the various information.
Ex. When the playback source is a DivX disc.
Selecting the playback source
• Available sources depend on the external
components you have connected, media you have
attached, and the <Input> settings you have made
(☞page 52).
On the touch panel:
On the monitor panel:
TUNER or HD Radio =SAT =DISC (DVD/VCD/CD)
=CD-CH, iPod, or EXT-IN =Bluetooth PHONE
=Bluetooth AUDIO =AV-IN =(back to the
beginning)
• You cannot select these sources if they are not ready.
Exit
Source information screen
Clock time in large numbers
Navigation screen
(When <Navigation> is
selected for <AV Input>)
(☞page 52)
Back to the beginning
Playback picture screen
(only for video sources)
Track list
Common operations
EN_KW-AVX710[J].indb 9EN_KW-AVX710[J].indb 9 07.12.5 11:58:57 AM07.12.5 11:58:57 AM

10
ENGLISH
When an FM stereo broadcast is
hard to receive
1Press [AV MENU].
• You can also use AV MENU on the monitor panel.
2Press [Mode].
Listening to the radio
~Press [SOURCE], then press [TUNER]. (☞page 9)
• You can also use SOURCE on the monitor panel. Press it repeatedly.
ŸPress [BAND].
!Press [4] or [¢] to search for a station—Auto Search.
• Manual Search: Hold either [4]or [¢] until “Manual Search” appears on the screen, then press it
repeatedly.
• The ST indicator lights up when receiving an FM stereo broadcast with sufficient signal strength.
3
Reception improves, but stereo effect will be lost.
• The MONO indicator lights up.
To restore stereo effect, select <Off>.
Preset no.
Band
Tuner indicators
Assigned station name (☞page 46). If no name is assigned,
the frequency of the station is displayed instead.
☞page 9
Sound mode
(☞page 45)
☞page 45
: Buttons on the
touch panel. In
the explanation,
they are
indicated inside
[ ].
EN_KW-AVX710[J].indb 10EN_KW-AVX710[J].indb 10 07.12.5 11:58:58 AM07.12.5 11:58:58 AM

OPERATIONS
11
ENGLISH
FM station automatic presetting
—SSM (Strong-station
Sequential Memory)
This function works only for FM bands.
You can preset six stations for each band.
1Press [AV MENU].
• You can also use AV MENU on the monitor panel.
2Press [Mode].
3
Local FM stations with the strongest signals are
searched and stored automatically in the FM band.
Tuning in to stations with
sufficient signal strength
This function works only for FM bands. Once you have
activated this function (selected <Local>), it always
works when searching for FM stations.
1Press [AV MENU].
• You can also use AV MENU on the monitor panel.
2Press [Mode].
3
Only stations with sufficient signal strength will be
detected.
• The DX indicator goes off, then the LO indicator
lights up.
EN_KW-AVX710[J].indb 11EN_KW-AVX710[J].indb 11 07.12.5 11:58:59 AM07.12.5 11:58:59 AM

12
ENGLISH
Selecting a preset station
On the remote:
1
2
On the unit:
• To select directly on the touch panel
• To select from the Preset List
1
2
or
Hold
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset number
4 of the FM1 band.
1Display the Preset List.
2Tune in to a station you want to preset.
3Select a preset number.
The station selected in step 2is now stored in
preset number 4.
[Hold]
EN_KW-AVX710[J].indb 12EN_KW-AVX710[J].indb 12 07.12.5 11:58:59 AM07.12.5 11:58:59 AM

OPERATIONS
13
ENGLISH
~Open the monitor panel.
<Open/Tilt> menu is displayed.
• By pressing and holding the button, you can
open the monitor panel and eject the disc.
ŸPress [OPEN].
Disc operations
The disc type is automatically detected, and playback starts automatically (for some discs: automatic start depends
on its internal program).
If a disc does not have any disc menu, all tracks on it will be played repeatedly until you change the source or eject
the disc.
If “ ” appears on the screen, the unit cannot accept the operation you have tried to do.
• In some cases, without showing “ ,” operations will not be accepted.
Label side
Caution on volume setting:
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc
to avoid damaging the speakers by the sudden
increase of the output level.
When playing back a multi-channel encoded disc,
the multi-channel signals are downmixed.
• You can fully enjoy multi-channel sound by
connecting an amplifier or a decoder compatible
with these multi-channel sources. (☞also page
61)
!Insert a disc.
Monitor panel closes automatically.
If not, press [CLOSE].
Caution:
Do not place your finger behind the monitor panel.
EN_KW-AVX710[J].indb 13EN_KW-AVX710[J].indb 13 07.12.5 11:59:00 AM07.12.5 11:59:00 AM

14
ENGLISH
While playing the following discs, press .
• Each time you press the button, the display changes to show the different information. (☞page 9)
Audio format
DVD Video: Title no./Chapter no./Playing time
DVD-VR: Program no. (or Playlist no.)/Chapter no./Playing time
Playback mode
Disc type *1Sampling frequency/Bit
rate/Recorded signal
channel no.
☞page 19
[3/ 8] Start and pause playback
[7] Stop playback
[4¢] Press: Select chapter
Hold: Reverse/forward search*2
[5∞] Select title/program/playlist
*1DVD-VR also indicates either PRG (program) or PLAY (playlist) playback.
*2Search speed: x2 ]x10
: Buttons on the touch panel. In the explanation, they are indicated inside [ ].
These buttons also work when they are not shown on the touch panel (while watching the playback pictures
on the screen).
Sound mode
(☞page 45)
EN_KW-AVX710[J].indb 14EN_KW-AVX710[J].indb 14 07.12.5 11:59:01 AM07.12.5 11:59:01 AM

OPERATIONS
15
ENGLISH
Track no./Playing time
[3/ 8] Start and pause playback
[7] Stop playback
[4¢] Press: Select track
Hold: Reverse/forward search*2
For DivX/MPEG1/MPEG2: Folder no./Track no./Playing time
For JPEG: Folder no./File no.
[3/ 8] Start and pause playback
[7] Stop playback
[4¢] Press: Select track
Hold: Reverse/forward search for DivX/MPEG1/MPEG2 *1
[5∞] Press: Select folder
Hold: Display Folder list
While playing the following discs, press .
• Each time you press the button, the display changes to show the different information (☞page 9).
Disc type
☞page 19
☞page 19
The PBC indicator
lights up when PBC is
in use.
Total track no.
included on the
disc
Total track no.
included on the
disc
Total playing time
Sound mode
(☞page 45)
Sound mode
(☞page 45)
*1Search speed: ¡1 ]¡2
*2Search speed: x2 ]x10
EN_KW-AVX710[J].indb 15EN_KW-AVX710[J].indb 15 07.12.5 11:59:01 AM07.12.5 11:59:01 AM

16
ENGLISH
Track no./Playing time
Only for CD Text *3
Folder no./Track no./Playing time
Audio format
(MP3/WMA/WAV)
☞page 19
*3“No Name” appears for conventional CDs.
*4Search speed: x2 ]x10
Tag data appears
only when it is
recorded.
Sound mode
(☞page 45)
☞page 19
[3/ 8] Start and pause playback
[7] Stop playback
[4¢] Press: Select track
Hold: Reverse/forward search*4
[5∞] Press: Select folder
Hold: Display Folder list
[3/ 8] Start and pause playback
[7] Stop playback
[4¢] Press: Select track
Hold: Reverse/forward search*4
Total track no.
included on the disc
Total playing time
Total track no. included on the disc
Sound mode
(☞page 45)
EN_KW-AVX710[J].indb 16EN_KW-AVX710[J].indb 16 07.12.5 11:59:02 AM07.12.5 11:59:02 AM

OPERATIONS
17
ENGLISH
Touch the screen (center portion).
Operation buttons on the screen
You can display the following operation buttons while watching the playback pictures on the screen.
• While the operation buttons are displayed, aspect ratio is fixed to <Full>. (☞page 49)
• If no operation is done for about five seconds, the operation buttons disappear (except when a disc menu is
displayed).
Touch [KEY].
☞pages 20 to 24 on how the operation buttons
particularly work for a variety of the discs
A
[SOURCE] Display <Source Menu> screen
[AV MENU] Display <AV Menu> screen
[SHORT CUT] Display the Short Cut buttons
[3/ 8] Start and pause playback
[7] Stop playback
[4¢] Press: Select track
Hold: Reverse/forward search
[5∞] Select folders
• The above buttons also work when they are not shown on
the screen (while watching the playback picture).
* While a disc menu is played back for DVD, [KEY] is
automatically displayed. On the disc menu, you can select a
menu item directly by touching it on the screen.
B
For DVD/VCD/DivX menu operation playback
[235∞] Select the menu items
[ENT] Confirm the selection
[TOP MENU] Display the disc menu
[MENU] Display the disc menu
[RETURN] Return to the previous menu or display the
menu (only for VCD with PBC)
C
For entering the numbers
[DIRECT CLR] • Switch between chapter/track entry and
title/group/folder entry
• Erase the last entry when you enter a
wrong number
[0]–[9]=[ENT]
Enter numbers
Ex.: To enter “105,” press [1], [0], [5], then [ENT]
*
Touch [KEY].
Touch [KEY].
To erase the operations, touch the screen again.
EN_KW-AVX710[J].indb 17EN_KW-AVX710[J].indb 17 07.12.5 11:59:02 AM07.12.5 11:59:02 AM

18
ENGLISH
1
• You can also use AV MENU on the monitor panel.
2
3
When one of the playback modes is selected, the
corresponding indicator lights up on the source
information screen.
To cancel, select <Off>.
Selecting playback modes
You can use the following playback modes—Repeat or Random.
Ex.: To select Track Repeat
Disc type Repeat Random
Chapter: Repeats current chapter
Title: Repeats current title —
Chapter: Repeats current chapter
Program:Repeats current program (not
available for Playlist playback)
—
Track: Repeats current track
Folder: Repeats current folder
Folder: Randomly plays all tracks of current
folder, then tracks of next folders
Disc (All): Randomly plays all tracks
Folder: Repeats current folder —
Track: Repeats current track (PBC not in
use)
Disc (All): Randomly plays all tracks (PBC not
in use)
Track: Repeats current track*1Disc (All): Randomly plays all tracks
Track: Repeats current track*1
Folder: Repeats all tracks of the current
folder
Folder: Randomly plays all tracks of current
folder, then tracks of next folders
Disc (All): Randomly plays all tracks
*1You can also use [SHORT CUT] to turn on and off Track Repeat.
EN_KW-AVX710[J].indb 18EN_KW-AVX710[J].indb 18 07.12.5 11:59:03 AM07.12.5 11:59:03 AM

OPERATIONS
19
ENGLISH
Prohibiting disc ejection
You can lock a disc in the loading slot.
To cancel the prohibition, repeat the same
procedure to select <EJECT OK?>.
Using Short Cut Icons
You can easily access the some frequently used
functions by using [SHORT CUT] on the touch panel.
1
2
• For video software:
• For audio software:
Selecting tracks on the list
If a disc includes folders, you can display the Folder/
Track (File) Lists, then start playback.
1
• You can also use AV MENU on the monitor panel.
2
3Select a folder (1), then a track (2).
Selected track starts playing. (* Press to move to
the previous/next pages of the list)
1Current folder list number/total folder list
number
2Current track list number/total track list
number of the current folder
You can easily access the Track List by pressing DISP
on the monitor panel.
Selected track starts playing.
at the same time
Sound mode
(☞page 45)
Turn on or off Track Repeat
(Repeat play: ☞page 18)
Aspect ratio
(☞page 49)
EN_KW-AVX710[J].indb 19EN_KW-AVX710[J].indb 19 07.12.5 11:59:04 AM07.12.5 11:59:04 AM

20
ENGLISH
Stop playback.
Start playback/pause (if pressed during playback).
Reverse/forward search*1(No sound can be heard.)
Slow motion during pause*2(No sound can be heard.)
Press: Select chapter (during playback or pause).
Hold: Reverse/forward search*3 (No sound can be heard.)
Select title (during playback or pause).
Select aspect ratio.
Select chapter.
Select title (when not playing).
Select title (during playback or pause).
Using menu driven features
1
2Select an item you want to start playback.
3
*1Search speed: x2 ]x5 ]x10 ]x20 ]x60
*2Slow motion speed: 1/32 ]1/16 ]1/8 ]1/4 ]1/2
*3Search speed: x2 ]x10
Operations using the remote controller—RM-RK252
Also functions as CLR (clear):
Erases a misentry if pressed
while holding SHIFT.
You can change the following items using the on-screen bar—audio language, audio stream, audio channel,
subtitle language, view angle, etc. (☞ pages 25 and 26)
twice
EN_KW-AVX710[J].indb 20EN_KW-AVX710[J].indb 20 07.12.5 11:59:05 AM07.12.5 11:59:05 AM
