1
KW-XR616
Installation/Connection Manual
/
ENGLISH /
0110DTSMDTJEIN
EN, TH
© 2010 Victor Company of Japan, Limited
GET0666-010A
[UH]
INSTALLATION /
• To prevent short circuits:
–Disconnect the battery’s negative terminal and make all electrical connections before installing the unit.
–Cover the terminals of the UNUSED leads with insulating tape.
• Be sure to ground this unit to the car’s chassis again after installation.
• Replace the fuse with one of the specified rating.
• Connect speakers with a maximum power of more than 50 W (impedance of
4 Ω to 8 Ω). Otherwise, change the <AMP GAIN> setting. (See page 25 of the
INSTRUCTIONS.)
• The heat sink becomes very hot after use. Be careful not to touch it when
removing this unit.
• :
–
–
•
•
• 50 W ( 4 Ω 8 Ω) <AMP GAIN> (
25 )
•
12 V DC, NEGATIVE ground /
12 V,
To the car system /
You need the installation kits which corresponds to your car. /
Check the battery system in your car /
WARNINGS /
The following illustration shows a typical installation. If you have any questions or require information
regarding installation kits, consult your JVC car audio dealer or a company supplying kits.
JVC
PRECAUTIONS on power supply and speaker connections
• DO NOT connect the speaker leads of the power cord to the car battery; otherwise, the unit will be
seriously damaged.
• BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in
your car.
•
•
• The fuse blows.
]
Are the red and black leads connected correctly?
• Power cannot be turned on.
]
Is the yellow lead connected?
• No sound from the speakers.
]
Is the speaker output lead short-circuited?
• “PROTECT” appears on the display and no operation can be done.
]
Is the speaker output lead
short-circuited or touches the chassis of the car/head unit? ; Have you reset your unit?
• Sound is distorted.
]
Is the speaker output lead grounded? ; Are the “–” terminals of L and R speakers
grounded in common?
• Noise interfere with sounds.
]
Is the rear ground terminal connected to the car’s chassis using shorter
and thicker cords?
• This unit becomes hot.
]
Is the speaker output lead grounded? ; Are the “–” terminals of L and R
speakers grounded in common?
• This unit does not work at all.
]
Have you reset your unit?
TROUBLESHOOTING /
•
]
?
•
]
?
•
]
?
• “PROTECT”
]
/? ; ?
•
]
? ; “–” L () R ()
?
•
]
?
•
]
? ; “–” L () R ()
?
•
]
?
Heat sink /
In-dash mounting / In-dash
Audio system originally installed in the car /
Car dashboard /
If there is an interfering tab on
the mounting bracket, bent it
flat. /
Screw removed from the car /
Mounting bracket removed from the car /
Firmly attach the ground wire to the metallic body of the car using the screw originally
fixed to the metallic body of the car. /
Installing with the mounting brackets from the car /
Install the unit at an angle of less than 30˚.
30˚
Part list /
AFlat countersunk screws—M5 × 8 mm /
—M5 × 8 . (×8)
BRound head screws—M5 × 8 mm / —
M5 × 8 .(×8)
CPlate for use with a Nissan car /
(×1)
DPower cord / (×1)
When installing the unit in a Nissan
car /
Fix the supplied plate as illutrated. /
Install_KW-XR616_010A_f.indd 1Install_KW-XR616_010A_f.indd 1 2/1/10 12:53:27 PM2/1/10 12:53:27 PM
2
IMPORTANT: A custom wiring harness (separately purchased) which is suitable for your car is
recommanded for connection between the unit and your car.
• Consult your JVC car audio dealer or a company supplying kits for details.
: ()
• JVC
Black /
Fuse block /
Ignition switch /
Blue (white stripe) /
()
Orange with white stripe /
Red /
Yellow / *3
To the metallic body or chassis of the car /
To an accessory terminal /
To a live terminal (constant 12 V) /
(12 V)
To the automatic antenna if any (250 mA max.) /
( 250 mA)
To car light control switch /
White /
White (black stripe) / ()
Gray /
Gray (black stripe) / ()
Green /
Green (black stripe) / ()
Purple /
Purple (black stripe) / ()
Signal cord /
* 1
Signal cord /
* 1
Y-connector /
Y*1
Y-connector /
Y*1
Remote lead /
Remote lead /
To the blue (white stripe) lead
of the unit /
()
To the blue (white stripe) lead
of the unit /
()
Rear speakers or subwoofer (Make the <L/O MODE> setting accordingly,
see page 24 of the INSTRUCTIONS.) / (
<L/O MODE> 24 )
Front speakers /
Rear ground terminal /
15 A fuse / 15 A
Antenna input /
*1Not supplied for this unit.
*2Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated
with paint.
*3Before checking the operation of this unit prior to installation, this lead must be connected; otherwise,
the power cannot be turned on.
*4To use these components, set the external input setting correctly (see page 25 of the INSTRUCTIONS).
Front speaker (left) /
()
Front speaker (right) /
()
Rear speaker (left) /
()
Rear speaker (right) /
()
ELECTRICAL CONNECTIONS /
Reset the unit. /
JVC Amplifier /
JVC
JVC Amplifier /
JVC
Connecting the external amplifier or subwoofer /
To the remote lead of other equipment (200 mA max.) /
( 200 mA)
Blue
/
*1
*2—
*3
*4 ( 25 )
Connecting the external components in series /
When connecting the external components, refer also to the manuals supplied for the components and adapter. /
You can connect the following components through the various JVC adapters to the expansion port. / JVC
• Connection cords may need to be purchased separately. /
Component / Adapter / Model name /
Bluetooth device / Bluetooth Bluetooth adapter / Bluetooth KS-BTA200
Portable audio player with line output jacks /
Line input adapter / KS-U57
Portable audio player with 3.5 mm stereo mini jack /
3.5 .AUX input adapter / AUX KS-U58
AKS-BTA200
B*4KS-U57 / KS-U58
To disconnect... /
...
Expansion port of the unit /
Steering wheel remote input /
Expansion port /
Caution / :
Before connecting the external components, make sure that the unit is turned off. /
DPower cord (supplied) / ()
Install_KW-XR616_010A_f.indd 2Install_KW-XR616_010A_f.indd 2 2/1/10 11:46:17 AM2/1/10 11:46:17 AM
