JVC XL-PG3S User manual

432
XL-PG3S/LVT1295-004A/B XL-PG3S/LVT1295-004A/B XL-PG3S/LVT1295-004A/B
p3 p4p2
4
3
VOLUME
6
VOLUME
1
5
RL
OFF ON
HOLD
01 02 53
2
ButtonOperation
To pause
To stop
To turn off the
unit
Fast forward/
reverse
Display/reference
0700 18
1044 48
Skip function
During play,
Search function
Keep depressed during play.
• Play stops automatically
when all the tracks have
been played.
For your reference:
“dISC”
his indication appears if 3/8 is pressed when no disc is loaded
or if the disc is not properly seated.
“– –”
Preparation period before playing the track
Flashes for several seconds after pressing 3/8 to play.
“OPEn”
his indication appears when the lid is open.
Removing discs
urn off the unit and, after the disc has stopped rotating, remove
the disc as shown below:
Auto power off
If the unit is left in stop mode for 30 seconds, the unit turns
itself off automatically to prevent the batteries from running
down.
Disc rotation noise
he portable CD player uses a power-saving operation method
so that disc rotation noise will intermittently be emitted. But, it
is not a failure.
• o skip back to the previous track, quickly press 4
twice.
• During Program play, the button is used to fast for-
ward or back through the programmed sequence of
tracks.
• During Random play, the skip button cannot be used
to skip back to tracks that were played previously in
the random sequence.
During play,
During play,
Reverse
Basic Play
otal number of tracks
otal playing time.
Label side
Elapsed playing time of
each track
No indication
Intro play
You can successively play the first 10 seconds of every track.
1While stopped,
MODE
INTRO
2
To cancel
Press MODE repeatedly until “IN RO” goes out.
Notes:
• You can also select Intro play during playback.
In this case, Intro play will start from the next track after the
current track has finished.
• You can also select Intro play during Program play mode.
Random play
During playback,
MODE
RAND
After playing all tracks, the unit stops.
To cancel
Press MODE until “RAND” goes out, or press 7 to stop the disc.
Notes:
• You can also select Random play in stop mode.
• During Program play, you can not select Random play.
Program play
You can program up to 32 tracks in any desired order including
the same tracks.
1While stopped,
PROGRAM
PROG
00 01
2Select the desired track.
PROG
03 01
3
PROGRAM
PROG
00 02
he track is registered.
4 Repeat steps 2 and 3.
When you program exceeding 32 tracks, the program se-
quence number returns to “01” and will overwrite the previ-
ous setting.
5
•To confirm the program
While stopped, press PROGRAM repeatedly. At this time, you
can change the program, if required.
•To delete the entire program
urn off the unit.
Program sequence
number
rack number to be programmed
00: Not programmed yet.
e.g. rack number 3
Repeat play
You can repeat one track or all tracks.
During playback,
MODE
ALL
To cancel
Press MODE repeatedly until the repeat indicator goes out.
Notes:
• You can also select Repeat play during Program play.
• You can also select Repeat play while stopped.
Hyper-Bass Sound effect
You can enjoy powerful bass sound.
OFF 21
HBS
HBS 1
Anti-Shock Protection EX
his function achieves excellent performance against sound inter-
ruption caused by vibrations. You will be able to enjoy listening
to music during (not vigorous) jogging.
By utilizing the high-performance servo circuit, audio data will be
stored in the memory ahead of time (up to 45 seconds worth).
Normally, this function is in effect.
ANTI
SHOCK
As the audio data is gradually stored, the indicator changes as follows:
To cancel
A.S.P
he “AN I SHOCK” indicator goes out.
To activate again
Press the ASP button.
Notes:
• During this operation, the disc rotates at a higher rate than usual
in order to collect extra audio data. his may cause the batteries
to run out faster and could result in a slight increase in disc rota-
tion noise.
• his function can be switched ON and OFF during playback.
However, this may cause a slight interruption in the sound be-
cause the disc’s rotational speed changes.
[Fully stored]
AN I SHOCK
indicator
(Repeatedly)
Next program sequence number
(Repeatedly)
Other Play Methods
(Repeatedly)
Power Supply Preparations
Using dry-cell batteries
(not supplied)
Caution:
Do not forcibly open the battery lid too wide.
Battery indicator
his indicator appears when the batteries are almost out of power.
Power will be cut off a short while later.
Note:
urning off the Anti-Shock Protection EX will save the battery power
more or less. For details, see “Anti-shock Protection EX” on page 4.
Battery indicator
AC adaptor
Using the AC adaptor (not supplied)
Notes:
• Even if the unit is turned off, small power is consumed as long
as the AC adaptor is connected to the AC power outlet.
• When you want to purchase the AC adaptor, see page 5.
AC power outlet
• When the unit is in Hold mode, “HoLd” and “ ” lights as
follows.
Power on : “ ” stays lit.
Power off : “HoLd” and “ ” lights up for a few seconds
when 6 is pressed.
Note:
If the HOLD switch is set to the ON position, you cannot turn on
the unit.
his function causes the unit to ignore, accidental button presses.
Hold mode prevents the following:
• Powering on the unit accidentally (which can cause the batter-
ies to go dead).
• Play being cut off unexpectedly.
To use the Hold mode
OFF ON
HOLD
• o prevent the unit from powering on accidentally, set the
HOLD switch to the ON position while the unit is turned off.
• o prevent the unit from unexpected operation during play,
set the HOLD switch to the ON position after you starts play-
ing the disc.
Preventing Accidental Operation (Hold mode)
Follow the steps in the numerical order.
wo “LR6” alkaline batteries.
rack number in play
Firmly connect
Forward
While stopped,
Press again to restart play.
1 track repeat All track repeat

51 6
XL-PG3S/LVT1295-004A/B XL-PG3S/LVT1295-004A/B XL-PG3S/LVT1295-004A/B
p6 p1p5
XL-PG3S
LVT1295-004A [B]
EN
0205SKMCREORI
©2005 Victor Company of Japan, Limited
Unit
Wipe the unit with a soft cloth. Remove stubborn dirt using a cloth which has been dipped in wa-
ter or soapy water and wrung out, and then wipe dry.
• If you intend to use a chemically treated cleaning cloth, read its directions first.
• Do not use alcohol or paint thinners.
Lens
Maintenance
Air blower for
camera lens
Lens
Precautions
Safety
1. Care of AC adaptor - he cord of the AC adaptor should be
routed so that they are not likely to be walked on or pinched by
items placed upon or against them. Never take hold of the AC
adaptor if your hand is wet, and always grasp the plug when
connecting or disconnecting it.
2. Disconnect when not in use - When not in use, be sure to dis-
connect the AC adaptor from the AC power outlet.
3. Batteries - If the unit is not used for a long period of time or is
used only from an AC power source, remove all the batteries to
prevent potential damage due to battery leakage. Do not mix
(old and new ) batteries or different types of batteries.
Installation
■ Environment
1. Condensation - Moisture may form on the lens in the follow-
ing conditions…
• immediately after a heater has been turned on.
• in a steamy or very humid room.
• when the unit is suddenly moved from a cold environment to
a warm one. If moisture forms inside this unit, it may not op-
erate properly. o correct this problem wait about one hour
for the moisture to evaporate.
■ Placement
1. Foreign Material - Care should be taken so that objects do not
fall into and liquids are not spilled into the unit. Do not subject
this unit to excessive smoke, dust, mechanical vibration, or
shock.
2. Magnetism - he unit should be situated away from equipment
or devices that generate strong magnetic fields.
3. Stacking - Do not place any objects on top of the unit.
Maintenance
(See page 5 for details.)
Clean the cabinet, panel and controls with a soft cloth lightly
moistened with mild detergent solution.
Do not use any type of abrasive pad, scouring powder or solvent
such as alcohol or benzine.
Service
1.Damage Requiring Service - he unit should be serviced by
qualified service personnel when:
(a) he AC adaptor is damaged; or
(b) Objects have fallen or liquid has been spilled into the unit; or
(c) he unit has been exposed to rain; or
(d) he unit does not appear to operate normally or exhibits a
marked change in performance; or
(e) he unit has been dropped, or the enclosure damaged.
CAUTION!
HIS PRODUC U ILIZES A LASER.
USE OF CON ROLS OR ADJUS MEN S OR PERFORMANCE
OF PROCEDURES O HER HAN HOSE SPECIFIED HEREIN
MAY RESUL IN HAZARDOUS RADIA ION EXPOSURE.
DO NO OPEN COVERS AND DO NO REPAIR YOURSELF.
REFER SERVICING O QUALIFIED PERSONNEL.
WARNING:
O REDUCE HE RISK OF FIRE OR ELEC RIC SHOCK, DO
NO EXPOSE HIS APPLIANCE O RAIN OR MOIS URE.
CAUTION:
• Do not block the ventilation opening or holes. (If the venti-
lation openings of holes are blocked by a newspaper or
cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must
be considered and local rules or laws governing the dis-
posal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
Check this
• Is the AC adaptor securely connected?
• Is the HOLD switch set to OFF position?
Is the disc properly secured in place?
• Is the disc properly secured in place?
• Is there moisture condensation on the lens?
(Wait for about an hour and then try again.)
• Is the headphone plug inserted all the way?
• Is the plug dirty? (Wipe away dirt on the plug.)
Are you using the unit too near a V or tuner? (If the V or
tuner is connected to a simple indoor antenna, connect it to
an outdoor antenna.)
• Is the disc damaged?
• Is the disc playable on this player?
• Has the disc been inserted upside down?
Problem
Does not turn on.
Cannot close the lid.
Cannot play discs.
Cannot hear music—too
noisy.
TV picture is distorted.
Radio reception is noisy.
“dISC”or “Er”is displayed
when a disc is in the
player.
Troubleshooting
If the remedies indicated in the chart do not solve the problem, refer to the directory of Autho-
rized Service Centers (enclosed with this unit) to locate a convenient service center, or consult
your dealer for instructions.
Portable CD player
ype : Compact disc player
Signal detection system : Non-contact optical pickup (semiconductor laser)
Pickup system : 3 beam laser
Number of channels: : 2 channels (stereo)
Frequency response : 20 Hz to 20 kHz
Wow & flutter : Unmeasurable
Output : Headphones (3.5 mm dia. stereo × 1)
9 mW/ch at 10 % HD/16 Ω matching impedance (16 Ω to 1 kΩ)
Duration of battery : Approx. 20 hours when using two alkaline batteries (LR6)
(with Anti-Shock
Protection EX OFF)
Power requirements : DC 3 V (“LR6” size battery × 2)
DC 2.4V (rechargeable battery × 2)
DC IN 4.5 V
Dimensions (W×H×D) : 138mm ×26 mm ×138 mm
(Excluding buttons and controls)
Mass : 220 g
(without batteries)
AC adaptor (not supplied)
Input power source : AC 230 V, 50 Hz
Output voltage : DC 4.5 V, 600 mA
* Design and specifications are subject to change without notice.
Specifications
Cautions
Rechargeable batteries
• Rechargeable batteries (not supplied) can be used.
• o use the rechargeable batteries, follow the instruction manual
attached to the rechargeable batteries and charger (not sup-
plied).
Dry cell batteries
o prevent damage to the batteries and electrolyte leakage, heed
the following points.
• Align the , and . polarities properly when inserting the bat-
teries.
• Do not mix different types or makers of batteries or old and
new batteries.
• Remove the batteries if you do not plan to use the unit for a
long period of time.
• Do not throw batteries into a fire, and do not short-circuit, dis-
assemble or subject them to excessive heat.
• Do not attempt to recharge dry cell batteries.
Carrying dry cell batteries around
When putting dry cell batteries in a pocket or bag, ensure that no
other metal objects such as a necklace are placed together with
them. Contact with metal may cause short-circuiting which, in
turn, may cause a fire.
AC adaptor
• Handle the AC adaptor carefully. Improper handling is dan-
gerous.
• Do not touch it with wet hands.
• Do not place heavy objects on top of it.
• Do not forcibly bend it.
• Be sure to connect only the specified AC adaptor with the unit.
• Disconnect the AC adaptor from the power outlet if the unit is
not going to be used for a long time.
Unit
No altering or remodeling
his can cause malfunctioning.
No dropping or strong impacts
his may damage the unit.
Locations to be avoided
Avoid using the unit in the following locations since they can
cause malfunctioning.
1. Bathrooms and other moisture-prone places.
2. Warehouses and other dusty places
3. Very hot places near heating appliances, etc.
Do not leave the unit exposed to direct sunlight for
long periods of time
his may deform or discolor the cabinet and may also cause mal-
functioning.
When purchasing AC adaptor
Be absolutely sure to purchase the AC adaptor designed espe-
cially for this unit.
AC adaptor: AA-R4515
For details, check with your dealer.
VARNING: Synlig Och
osynlig laserstrålning när
den öppnas och spärren är
urkopplad. Betrakta ej
strålen. (s)
CAUTION: Visible and invisible
laser radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE TO
BEAM. (e)
ADVARSEL: Synlig og usynlig
laserstråling når maskinen er
åben eller interlocken fejle.
Undgå direkte eksponering
til stråling. (d)
VARO: Avattaessa ja
Suojalukitus ohitettunatai
viallisena olet alttiina näkyvälle
ja näkymättömälle lasersäteilylle.
Vältä säteen kohdistumista
suoraan itseesi. (f)
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are
no user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation
when open and interlock failed or defeated. Avoid
direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED OUTSIDE THE UNIT.
Listening precautions
• Do not play your headphones at a high volume. Hearing ex-
perts advise against continuous extended play.
• If you experience a ringing in your ears, reduce volume or dis-
continue use.
• Do not use while operating a motorized vehicle. It may create a
traffic hazard and is illegal in many areas.
• You should use extreme caution or temporarily discontinue use
in potentially hazardous situations.
• Even if your headphones is an open-air type designed to let you
hear outside sounds, don’t turn up the volume so high that you
can’t hear what’s around you.
Concerning Compact Discs
Only compact discs bearing this mark can be used with this unit.
However, continued use of irregular shape CDs (heart-shape, octagonal, etc.) can damage
the unit.
If moisture has formed on a disc
When moisture has formed because the
disc was brought suddenly into a warm
room from a cold environment, wipe off
the moisture using a soft dry cloth.
When storing discs
Avoid locations which are
• Exposed to direct sunlight.
• Susceptible to high levels of humidity or
dust.
• Directly exposed to heat from a heating
appliance.
• On top of a car dashboard or near the
rear window.
Handling precautions
• On the label side (the side with writing)
Do not write anything using a pencil,
ball-point pen, etc. Do not use adhesive
paper or labels.
• On the disc (shiny) side
Handle this side carefully to keep it free
from fingerprints or scratches. Do not
use record cleaners, solvents, etc.
• Do not attach labels or stickers to CDs.
Do not use CDs with exposed adhesive
from tape or left over peeled off stickers.
• Do not use scratch-proof protectors or
covers other than those specified for use
with this unit.
If the disk surface is dirty
Wipe it with a damp cloth and then wipe dry.
Wipe from the center toward the outer edge.
How to hold a disc
CD-R and CD-RW discs recorded with the audio
CD format can be played back, though some may
not be played back because of the disc character-
istics or recording condition.
Play surface (shiny surface)
Stereo headphones .......................................................................................................................... 1 pc.
Supplied Accessories
PORTABLE CD PLAYER
INSTRUCTIONS
hank you for purchasing this JVC product. Please read these instructions carefully before starting
operation to be sure to obtain optimum performance and a longer service life from the unit.
he Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital
Audio” standard. herefore, the use of Non-DVD side of a DualDisc on this product may
not be recommended.
