JVC AV-P1000U User manual

AV-P1000U
SS961490-002
DIGITAL PRESENTER
MANUEL D’INSTRUCTIONS : PRESENTOIR NUMÉRIQUE
OPERATING INSTRUCTIONS
R
For Customer Use:
Enter below the Serial No. which
are located on the fram.
Retain this information for future
reference.
Model No. AV-P1000U
Serial No.
This instruction book is made from 100% recycled paper.
ENGLISH
FRANÇAIS

2
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to alert
the user to the presence of uninsulated “dan-
gerous voltage” within the product’s enclosure
that maybe of sufficient magnitude to consti-
tute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and main-
tenance (servicing) instructions in the litera-
ture accompanying the appliance.
WARNING: This equipment generates, uses, and can radiate
radio frequency energy. If not installed and used in accordance
with the instruction manual, it may cause interference to radio
communications.The rules with which it must comply afford rea-
sonable protection against such interference when it is used in
a commercial environment.Operation of this equipment in a resi-
dential area is likely to cause interference, in which case the
user will be required to correct the interference at his own ex-
pense.
Information for Canada
This product complies with D.O.C limits (C.R.C., C. 1374)
pertaining to class A digital apparatus.
Informations pour le Canada
Ce produit est en conformité avec les normes D.O.C (C.R.C.,
C. 1374) concernant les appareils numériques de classe A.
The instructions are given in two languages :
English from page 2 to 21 and French from page 22 to 42
Les instructions sont donnés en deux langues :
En anglais de la page 2 à 21 et en français de la page 22 à 42.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NOTE:
The rating plate (serial number plate) and safety caution
are on the bottom and/or the back of the main unit.
AVERTISSEMENT:
DE PREVENTION D'INCENDIE OU D'ELECTROCUTION,
NE PAS EXPOSER CET APPAREIL A LA PLUIE OU
L'HUMIDITE.
WARNING:
THIS IS A CLASS A PRODUCT. IN A DOMESTIC EN-
VIRONMENT THIS PRODUCT MAY CAUSE RADIO
INTERFERENCE IN WHICH CASE THE USER MAY
BE REQUIREDTOTAKE ADEQUATE MEASURES AT
HIS OWN EXPENSE.
AVERTISSEMENT:
CECI EST UN APPAREIL DE CLASSE A. DANS UN
ENVIRONNEMENT DOMESTIQUE CET APPAREIL PEUT
CAUSER UNE INTERFÉRENCE RADIO DANS QUEL CAS
L'UTILISATEUR PEUT AVOIR À PRENDRE DES
MESURES ADÉQUATES À SES PROPRES FRAIS.

3
ENGLISH
Thank you for purchasing the JVC AV-P1000U Digital Presenter. To make the most of this unit’s many features, please read this
booklet carefully. After reading, keep it handy for future reference.
Features ............................................................................................................................................................................................... 3
Handling precautions ......................................................................................................................................................................... 3
Part names and functions .................................................................................................................................................................. 4
Main unit ............................................................................................................................................................................................ 4
Control panel ..................................................................................................................................................................................... 4
Rear panel ......................................................................................................................................................................................... 5
Before use............................................................................................................................................................................................ 6
Storage ................................................................................................................................................................................................. 7
How to make presentations ............................................................................................................................................................... 8
Presenting material such as printed matter and 3-dimensional objects ............................................................................................ 8
Presenting slide films ......................................................................................................................................................................... 8
Presenting transparent material such as an OHP sheet ................................................................................................................... 9
Shooting nearby objects .................................................................................................................................................................... 9
Operation ........................................................................................................................................................................................... 10
ZOOM .............................................................................................................................................................................................. 10
DIGITAL ZOOM ............................................................................................................................................................................... 10
ZOOM PRESET............................................................................................................................................................................... 10
FOCUS ............................................................................................................................................................................................ 11
AUTO WHITE SET ........................................................................................................................................................................... 11
FREEZE........................................................................................................................................................................................... 11
PC .................................................................................................................................................................................................... 12
VIDEO OUT ..................................................................................................................................................................................... 12
LIGHTS ............................................................................................................................................................................................ 13
IRIS .................................................................................................................................................................................................. 13
ON-SCREEN ADJUSTMENTS........................................................................................................................................................ 14
Remote control unit .......................................................................................................................................................................... 16
Notes on using the remote control unit ............................................................................................................................................ 17
Effective presentations..................................................................................................................................................................... 18
System connections ......................................................................................................................................................................... 19
Troubleshooting ................................................................................................................................................................................ 20
Specifications .................................................................................................................................................................................... 21
TABLE OF CONTENTS
HANDLING PRECAUTIONS
●Do not expose this unit to direct sunlight or leave it near a heater.
●Do not place flammable objects such as cloth or paper on or near this unit during use.
●Clean this unit by wiping dirt off with a cloth moistened with detergent. Wipe dry with a dry cloth. Do not expose this unit to volatile
liquids such as thinner, benzene or insecticide. Damage or discoloration could result.
FEATURES
●High-precision presentation system capable of projecting images of a wide range of physical objects including 3-dimensional objects,
OHP sheets, slides, and printed matter.
●SXGA-equivalent high-resolution images ideal for input to a high-resolution projector.
●20x zoom (5x optical zoom & 4x digital zoom) capability for presentation of a wide range of material, from B4-size / 10 inch x 14 inch
documents to 35-mm slide film.
●Wireless remote control unit for trouble-free operation from a distance.
●Flat stage permits magnification of the corners of a vertical A4-size / LETTER-size object for optimum image capturing capability.
●5-position arm and rotatable camera head allow objects to be viewed from various angles.
●Can be connected to any type of projector or display (SXGA, XGA, SVGA, VGA) for video display.
●One-touch switching to an ordinary TV monitor is possible.
●This unit can be controlled via a personal computer.

4
Main Unit
PART NAMES AND FUNCTIONS
Control Panel
1ZOOM buttons : Use to change picture size (p. 10).
2PRESET buttons : Use to store frequently used picture sizes (p. 10).
3DIGITAL ZOOM button : Use to change picture size electronically (p. 10).
4FOCUS buttons : Use to focus on a specified point (p. 11).
5AUTO WHITE SET button : Use to adjust white balance automatically (p. 11).
6FREEZE button : Use to freeze an output picture (p. 11).
7PC button : Use to switch between the camera picture input and the PC IN connector input (p. 12).
8ON-SCREEN ADJUSTMENTS buttons : Use to adjust and set the camera (p. 14).
9IRIS adjust buttons : Use to adjust picture brightness (p. 13).
0VIDEO OUT button : Use to switch between RGB output and video output (p. 12).
!LIGHTS button : Use to turn the side and back illumination on/off (p. 13).
@Power indicator : when power is switched on it will glow green.
Side Lamp
Camera arm
Camera head rotation knob
Side Lamp
Stage
Control panel
Rear panel
Remote control light reception section
Camera head
Slide film holder
Close-up lens
Lock release button
Power switch
Back illumination
Book holder
ON-SCREEN ADJUSTMENTS
DIGITAL PRESENTER AV-P1000
ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
POWER
356704
!
@
1
2
89

5
ENGLISH
Rear panel
4
3
RGB OUT1
R G B Hs/Cs Vs
RGB OUT2
COMMERCIAL
USE ONLY
PC IN
VIDEO OUT
SYNC.
REMOTE IN (RS-232C)
MODE
0
1
ABCD
12
AC OUTLET
AC100-120V 50/60Hz
AC100-
120V
50/60Hz
40W
(UNSWITCHED
MAX400W)
DC OUT 12V
400mA
1 2 3
45 6 7 9 8
! 0
1MODE switch : Sets the type of signal output to the RGB output connector from the camera. Set this switch according to the
specifications of the connected projector and display. When you want to change the mode, turn the unit off
and then turn it on again.
* Mode 1 picture quality is high-
est. Mode 4 is lowest.
* When the mode is set to 2, 3
or 4, resolution will be re-
duced and picture quality may
be degraded.
2SYNC. switch : Use to set the mode for the sync signal output to the RGB output connectors or turn the on-screen display on/off.
Set this switch according to the specifications of the connected projector and display.
When you want to change the mode, turn the unit off and then turn it on again.
Mode Connected projector/display Output signal
1 SXGA (1280 x 1024) 1280 x 960 equivalent
2 XGA (1024 x 768) 1024 x 768 equivalent
3 SVGA (800 x 600) 800 x 600 equivalent
4 VGA (640 x 480) 640 x 480 equivalent
ABCD
Horizontal sync signals
are output.
1 Sync signals are not
added to G signals.
On-screen signals are
output. Unused
Composite sync sig-
nals are output.
0 Sync signals are added
to G signals.
On-screen signals are
not output. Unused
A: Sets the type of sync signals output to the RGB OUT1 Hs/Cs connector and RGB OUT2 connector.
B: Sets whether or not sync signals are added to the video signal output at the RGB OUT1 G connector
and RGB OUT2 connector.
C: Sets whether or not the on-screen display signal is output to the video signal output at the RGB OUT1
and 2 connectors.
* On-screen signals are output to the VIDEO OUT connector regardless of the mode setting.
The default setting at the factory is: A = 1, B = 1, C = 1 and D = 1.
3REMOTE IN connector : Connect a personal computer to this connector for remote PC operation (p. 18).
4RGB OUT1 connectors: Output signals from the camera or PC IN connector and the sync signal (BNC connectors).
5RGB OUT2 connector : Outputs signals from the camera or PC IN connector and the sync signal (D-sub 15 pins).
* The RGB OUT1 and OUT2 connectors output the same picture and sync signal at the same time.
6PC IN connector : Input the RGB signal and sync signal from another device here. Signals can be output to the RGB OUT connectors.
Set the sync signal for the equipment connected to the PC IN connector according to the specifications
of the projector and display.
When connecting a personal computer, set its resolution to a suitable level.
7VIDEO OUT connector : Outputs the video composite signal from the camera.
Use the VIDEO OUT button to switch between video output and RGB output.
Note : When video signals from the camera are output to the VIDEO OUT connector, no signal is output to
the RGB OUT connectors.
8AC IN connector : Connect the power cord here.
9AC outlet : Supplies power of up to 400 W regardless of the power switch setting.
0DC OUT connector : Use this connector to supply DC power to the optional LCD monitor (TA-AV-Z7U).
!LCD monitor holder : Use to mount the optional LCD monitor (TA-AV-Z7U). For installation, refer to the LCD monitor’s operating
instructions.

6
BEFORE USE
1. While pressing down the lock release button 1, hold the
camera arm with your hand and raise it in the direction
shown 2. When the camera arm stops, release the lock
release button.
Be sure to raise the camera arm until the lock release but-
ton is released and the camera arm is completely locked.
2
3
4
4
1
●To change the camera angle using the 5-position cam-
era arm function, press the lock release button again.
After changing the angle, fix the camera arm at the
position where the lock release button is released and
the camera arm is locked.
Note:
●Do not release the camera arm when the lock release
button is pressed. Otherwise, a malfunction or injury
may result.
2. To aim the camera head at the stage, turn it in the direction
shown 3until it clicks.
3. Fold out the side illumination arms in the direction 4.
Note:
●Do not move the side illumination arms in any direc-
tion other than that shown 4. Do not apply exces-
sive force to the lamps when changing the angle. Oth-
erwise, a malfunction or electric shock may result.
4. Check the type of input connector on the display or monitor
and make the appropriate connections.
●BNC Connection ●D-sub 15-pin Connection
4
3
RGB OUT1
R G B Hs/Cs Vs
RGB OUT2
SYNC.
REMOTE IN (RS-232C)
MODE
0
1
ABCD
12
To the RGB OUT1
connectors To video input connectors
RGB OUT1
Display
BNC-BNC cable
RGB OUT1
R G B Hs/Cs Vs
4
3
RGB OUT1
RGBHs/CsVs
RGB OUT2
SYNC.
REMOTE IN (RS-232C)
MODE
0
1
ABCD
12
(Male)
To the RGB OUT2
connector
(Male)
To the video
input connector
Display
D-sub 15-pin cable
RGB OUT2
●Composite Video Connection
4
3
RGB OUT1
R G B Hs/Cs Vs
RGB OUT2 PCIN
VIDEO OUT
SYNC.
REMOTE IN (RS-232C)
MODE
0
1
ABCD
12
Monitor
To the VIDEO OUT
connector
To the video
input connector
Provided video cable
VIDEO OUT
5. Connect the power cord connector to the AC IN connector
and plug the other end into an AC outlet. Press the power
switch to turn the power on.
Notes:
●Be sure to turn the power off to protect this unit and other
connected equipment.
●Do not connect any device with more than the indicated
power (400 W) to the AC outlet. Doing so could result in
overheating and produce smoke or fire.
* Use the shortest cable possible (3 m. max.) for RGB con-
nections.
Note: If the D-sub cable connector plugged into the RGB
OUT2 connector is too large, you won’t be able to con-
nect a cable to the PC input connector.

7
ENGLISH
STORAGE
3
1
1
2
5
4
1. Press the power switch off and unplug the power cord and
video cables.
Note:
●When plugging and unplugging the power cord and
video cables, hold the plugs.
2. Fold in the left and right side illumination arms in the direc-
tion shown 1(do not direct the side illumination lamps to-
wards the stage).
3. Turn the camera head in the direction shown 2until it stops.
4. When moving the camera arm in the direction shown 3,
press the lock release button 4. Then, fold the camera
arm down in the direction shown 5until it stops and lock it.
Notes:
●Do not release the camera arm when the lock release but-
ton is pressed in. Otherwise, a malfunction or injury may
result.
●When the camera arm is locked, do not apply excessive
force to it. Otherwise, a malfunction may occur.
●For storage, do not lean this unit against a wall, etc. If it
falls over, a malfunction or injury may result.
●For transportation, do not hold the unit by camera arm, side
illumination (lamp or arm), book holder, etc. This could apply
excessive force to the unit, resulting in a malfunction or
injury. Only use the carrying handle to lift the unit.

8
HOW TO MAKE PRESENTATIONS
1. Presenting material such as printed matter and 3-dimensional objects
●Put an object on the stage and adjust the picture size with
the ZOOM buttons 1while checking the screen. When
the picture size is determined, adjust the focus with the
FOCUS buttons 2.
* When using in a room, it is recommended to turn on the
side illumination (for switching on the illumination, refer to
p. 13).
●When shooting a 3D object, use the 5-position camera arm
function to add presence to the picture.
While moving the camera arm in the direction shown 3,
press the lock release button 4. Then, move the camera
arm in the direction shown 5and release the lock release
button 4to fix the arm at the lock position (5 steps).
●When capturing the image of a large object such as the
page of an encyclopedia, pull out the book holder in the
direction shown 6.
2. Presenting slide films
Turn on the side illumination and insert the film into the slide
film holder 7. Then, adjust the size of the picture with the
ZOOM buttons 1. When the picture size is determined, ad-
just the focus with the FOCUS buttons 2.
Notes:
●Do not apply excessive force to the book holder.
●Do not release the camera arm when the lock release
button is pressed. Otherwise, a malfunction or injury
may result.
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
2
!
1
3
6
6
5
4
●To use the slide film holder, turn the side illumination on
and direct the fluorescent lamp down.
●If the slide film (vertical) is magnified until the mount sec-
tion can no longer be seen, focusing is not possible. Use
the zoom at the tele side.
●Do not put any objects on the stage.
7

9
ENGLISH
3. Presenting transparent material such as an OHP sheet
Turn on the back illumination and put the transparent sheet
on the stage. Then, adjust the picture size with the ZOOM
buttons 1. When the picture size is determined, adjust the
focus with the FOCUS buttons 2. To present a negative
film, switch to the negative mode with the ON-SCREEN
ADJUSTMENTS (p. 14 and 15).
To shoot the face of a person or nearby objects such as a
blackboard, remove the close-up lens by turning it in the
direction shown 8. Then, direct the camera head in the di-
rection shown 9and turn the camera head rotation knob
180 degrees in the direction shown 0. If the brightness is
insufficient, adjust with the IRIS buttons !.
4. Shooting nearby objects
0
89
●To shoot the stage, set the close-up lens and set the cam-
era head rotation knob to the original position.
●Be careful not to get fingerprints or dust on the close-up
lens.

10
OPERATION
ZOOM
●Press the ZOOM TELE button to gradually enlarge the pic-
ture size and the ZOOM WIDE button to gradually reduce it.
●To increase the zooming speed, press the ZOOM button
continuously.
DIGITAL ZOOM
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
●This allows you to enlarge the picture size electronically.
●Pressing the DIGITAL ZOOM button enlarges the picture size
in increments from 2x to 3x, then 4x. The indicator lights.
●The picture size can be adjusted with the TELE or WIDE
button.
●Pressing the DIGITAL ZOOM button when the 4x picture is
displayed, returns the picture to its original size. The indi-
cator goes off.
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
* When the picture is enlarged electronically, resolution is low-
ered and noise appears.
* You can use the ON-SCREEN ADJUSTMENTS to change
the maximum magnification setting (p. 14 and 15).
Note : When video signals are output to the VIDEO OUT con-
nector, the picture cannot be enlarged with the digital
zoom function.
ZOOM PRESET
●Two frequently used picture sizes can be stored in memory.
●Set the required size and press the PRESET 1 or 2 button for
2 seconds or more. “P1”or “P2”appears in the upper left of
the display. When the preset information is stored, the indi-
cation goes out.
●To use one of the presets, press the PRESET 1 or 2 button.
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
* Preset data is retained when the power is turned off.
* Using the ON-SCREEN ADJUSTMENTS, the picture size
can be set from A4/LTR to A7/3 inches x 4 inches (p. 14 and
15). The initial setting is A4/LTR for PRESET 1 and A6/4 inches
x 6 inches for PRESET 2.
Note : The picture size cannot be preset when the FREEZE,
PICTURE MEMORY, or DIGITAL ZOOM function is
activated.
The indicator goes off.
Original picture 2 times 3 times 4 times
Press Lights up. Lights up. Lights up.

11
ENGLISH
AUTO WHITE SET
●This adjusts the picture tone.
●Shoot a white sheet of paper in full screen and press the
AUTO WHITE SET button. The indicator blinks until the white
balance is set. When the white balance setting is complete,
the indicator stops blinking and remains lit.
●Press the FOCUS buttons to adjust the focus.
●Press the NEAR button to focus on the upper (closer) part
of the object and the FAR button to focus on the lower
(farther) part.
FOCUS
●This freezes the picture from the camera and displays it as a
still image. The indicator lights.
●Press again to release the still mode.The indicator goes out.
●When the split mode is engaged using the ON-SCREEN AD-
JUSTMENTS, the screen is divided. The still picture is shown
on one side and the current camera picture on the other. The
indicator blinks.
FREEZE
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
Note : Focusing range is up to 100 mm from the stage sur-
face.
* Even though the auto white set mode is engaged, the tone
is not adjusted unless this button is pressed.
* When the lighting changes, perform the auto white set op-
eration again.
* The auto white set mode and the manual mode can be switched
with the ON-SCREEN ADJUSTMENTS (p. 14 and 15).
Note : In the manual white balance mode, this button has no
effect. In this case, “MANUAL WB”is shown briefly in
the upper left of the screen for confirmation.
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
* For the split mode setting, refer to p. 14 and 15.
Note : When the still mode is engaged, zoom, focus and iris
adjustments are not possible. Also, the VIDEO OUT
button has no effect.
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12

12
PC
●Use this button to output the PC signal (input from the PC IN
connector) to the RGB OUT connectors. The indicator lights.
●Press the button again to restore camera picture output. The
indicator goes out.
VIDEO OUT
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
●Press this button to output composite signals from the cam-
era to the VIDEO OUT connector. The indicator lights.
●Press again to output signals to the RGB OUT connectors.
The indicator goes out.
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
Notes: ●Signals received via the PC IN connector cannot
be output to the VIDEO OUT connector.
●Thin lines in the camera picture may flicker on the
monitor screen when the camera signal is output
via the VIDEO OUT connector.
●When digital zoom is activated, signals cannot be
output to the VIDEO OUT connector.
●During video output, the [FREEZE] button will not
operate.
●During video output, the [PICTURE MEMORY 1
to 3] buttons will not operate.
* Camera signals can be output from the VIDEO OUT con-
nector at the same time as signals from the PC IN connec-
tor are output from the RGB OUT connectors.
Note : Depending on the projector or display, the picture may
be distorted or it may take some time before the picture
appears after the signal is switched with this button.

13
ENGLISH
IRIS
●Press these buttons to adjust the brightness.
●The numeric value is shown in the screen’s upper left when
this button is pressed. Press the button to increase the
brightness and the button to decrease it.
●Press the and buttons simultaneously to reset the
iris to 0.
●Press to light either the side or back illumination.
●If the illumination does not light, press this button. The
indicator blinks for about 2 seconds and lights, then the
side illumination lights.
●When the side illumination is lit, press this button. The
indicator blinks for about 2 seconds and lights, then the
back illumination lights.
●When the back illumination is lit, press this button. The
indicator and the back illumination go out.
LIGHTS
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
Note : When the iris is set automatically with the ON-SCREEN
ADJUSTMENTS, the iris may not function or it may take
some time to function when the brightness is insuffi-
cient. In this case, turn on the side lights.
* To adjust the brightness, set the IRIS MODE to MANUAL
with the ON-SCREEN ADJUSTMENTS.

14
ON-SCREEN ADJUSTMENTS
 Operating procedure
●To adjust or set the camera
●The ON-SCREEN ADJUSTMENTS consists of 5 buttons
(the MENU/ENTER button 1to engage or disengage the
mode, the 2and 3buttons to select the item for
adjustment and 4and 5buttons for data setting).
Example:To switch the TEXT MODE setting
ON-SCREEN ADJUSTMENTS ZOOMFOCUS
FARNEAR
WIDETELE
LIGHTS IRIS MENU/ENTER
VIDEO
OUT
PC FREEZE AUTO WHITE
SET DIGITAL
PRESET12
23
45
1
1. Press the MENU/ENTER button to show the menu screen
on the monitor.
WHITE BALANCE
RED LEVEL
BLUE LEVEL
IRIS MODE
IRIS LEVEL
TEXT MODE
Info (AW SET, NORMAL)
AW SET
0
0
AUTO
0
OFF
Item
Menu screen
Set value

2. Press the or button to set the mark on the item for
adjustment and setting. Setting details are shown in re-
verse.
WHITE BALANCE
RED LEVEL
BLUE LEVEL
IRIS MODE
IRIS LEVEL
TEXT MODE
Info (OFF, ON)
AW SET
0
0
AUTO
0
OFF Shown in
reverse.
Set the mark. 
Item
Menu screen
Set value
3. Change the set value with the and buttons. At the
lowest line, the setting details and value range are shown.
WHITE BALANCE
RED LEVEL
BLUE LEVEL
IRIS MODE
IRIS LEVEL
TEXT MODE
Info (OFF, ON)
AW SET
0
0
AUTO
0
ON

Item
Menu screen
Set value
4. To set another item, press the or button to set the mark.
When the mark is set to DIGITAL ZOOM at the lowest line on
page 1, press the button to show the menu on page 2. When
the mark is set to ZOOM PRESET 1 at the top line, press the
button to go to the menu on page 1.
WHITE BALANCE
DIGITAL ZOOM
Info (X2, X3, X4)
AW SET
X2
Item
Menu screen page 1
Set value
Item
Menu screen page 2
Set value

Press the button.
Press the button. ZOOM PRESET 1
SAVE
Info (USER, A4   A7, SLIDE)
A4/LTR
CANCEL

* A 4-page menu screen is shown on the monitor connected to
the VIDEO OUT connector. The items on each page are shown
on the next page.
To save the changed set value, go to step 6.
5. Press the MENU/ENTER button to enter the displayed ad-
justments and store the settings. The menu screen goes
out to end the adjustments. (The set value entered is effec-
tive until the power is turned off.)
6. Press the button to set the mark to SAVE at the low-
est line on page 2. Set the set value to OK with the 
button and press the MENU/ENTER button. The displayed
adjustments and settings are entered and stored in the sta-
tus memory. The menu screen goes out to end the adjust-
ments.

15
ENGLISH
Function description
Each function and set value for the ON-SCREEN ADJUSTMENTS are shown in the table below.
*1
Page 1Page 2
Page 1Page 2Page 3Page 4
*2 Items Function description Store settings Default value
WHITE BALANCE AW SET,
MANUAL
AW SET
AW SET : Allows automatic picture tone setting just by pressing the AUTO WHITE
SET button.
MANUAL : Allows manual picture tone setting with the [RED LEVEL] and [BLUE LEVEL] options.
IRIS MODE AUTO,
MANUAL
AUTO
AUTO : When the ambient brightness changes, picture brightness is automatically
adjusted.
MANUAL : Picture brightness is fixed.
TEXT MODE OFF, ON OFF
When ON is selected, characters are clearer and sharper. Effective when this is
used to show text-only documents.
NEGA/POSI POSI, NEGA POSI
Use to reverse the image when presenting e.g. a film negative.
DIGITAL ZOOM X2, X3, X4 X4
Use to obtain maximum magnification when the digital zoom function is used.
DETAIL*3 -10 to +10 (1-step) 0
Use to adjust video contours. The picture gets sharper as the setting increases from
-10 to +10.
BLACK LEVEL -10 to +10 (1-step) 0
Use to adjust the black level of the picture. Black areas in the picture become
sharper as the setting increases from -10 to +10.
POINTER SHAPE ARROW,
CROSS, PEN
ARROW
Use to select the desired on-screen pointer shape. The available shapes are
ARROW , CROSS and PEN .
POINTER
COLOR
WHITE, YELLOW,
CYAN, GREEN,
MAGENTA, RED, BLUE
WHITE
Use to set the pointer color. Available colors are WHITE (Wh), YELLOW (Ye), CYAN
(Cy), GREEN (G), MAGENTA (Mg), RED (R) and BLUE (B).
SPLIT MODE OFF, Hori.,
Verti.
OFF
Use to set the split mode.
Hori. : Upper; Camera image, Lower; Still picture, Division ratio; 1:1
Verti. : Left; Camera image, Right; Still picture, Division ratio; 1:1
LOAD CANCEL,
DEFAULT,
USER
CANCEL
DEFAULT (Defa.) : Restores the initial values instead of the current conditions*4
when ending the menu.
USER : Restores the values stored in the status memory instead of the current
conditions*4 when ending the menu.
SAVE CANCEL,
OK
CANCEL
When OK is selected and menu setting is complete, the current conditions* are
stored in the status memory.
ZOOM PRESET 1
ZOOM PRESET 2
Use to set the picture size to be called with the ZOOM PRESET buttons. Different
sizes can be set for 1 and 2.
Set this function to USER to save the specified size by pressing the ZOOM PRESET
1 or 2 for more than 2 seconds.
BW/COLOR COLOR, B/W COLOR
Use to show a picture in black and white. When this is used to show a black-and-
white document, the picture will be clearer.
0
0
When [AW SET] is selected, use to fine adjust the red level for the auto white set.
When [MANUAL] is selected, use to adjust the red level.
RED LEVEL
*5
-10 to +10 (1-step)
-30 to +30 (1-step)
0
0
When [AUTO] is selected, use to fine adjust the brightness.
When [MANUAL] is selected, use to adjust the brightness.
IRIS LEVEL
*5
-10 to +10 (1-step)
-30 to +30 (1-step)
0
0
When [AW SET] is selected, use to fine adjust the blue level for the auto white set.
When [MANUAL] is selected, use to adjust the blue level.
BLUE LEVEL
*5
-10 to +10 (1-step)
-30 to +30 (1-step)
A4/LTR
A6/4 x 6
USER, A4/LTR,
A5/6 x 8, A6/4 x 6,
A7/3 x 4, SLIDE
*1 The menu screen output to the RGB OUT connectors is shown on 2 pages.
*2 The menu screen output to the VIDEO OUT connector is shown on 4 pages.
*3 The higher the DETAIL set value, the more the noise.
*4 Current conditions means the current on-screen and front panel function settings. However, “DIGITAL ZOOM”, “FREEZE”, “PIC-
TURE MEMORY”and “POINTER”positions are not stored in memory. Thus, when current settings are restored, “DIGITAL ZOOM”,
“FREEZE”, “PICTURE MEMORY”and “POINTER”are set to OFF.
*5 When the picture is displayed on the screen, the colors vary conversely to each of the set values of the "NEGA" mode. This
phenomenon occurs because of the characteristics of the RED, BLUE and IRIS.
Notes:
●When the C of the SYNC. switch is set to 0, the on-screen signals are not output to the RGB OUT connectors (p. 5).
●While the on-screen display is available, the “IRIS”, “PC”, “FREEZE”, “VIDEO OUT”, “DIGITAL ZOOM”, “ZOOM PRESET”and
“PICTURE MEMORY”buttons have no effect. The pointer is not shown on the screen.
●When the power is turned on, the settings stored in the status memory are recalled. “DIGITAL ZOOM”, “FREEZE”, “PICTURE
MEMORY”and “POINTER”are set to OFF. If no data is stored in the status memory, the default settings are used.

16
Remote control unit
●The remote control unit should be operated by directing it toward the remote control light reception section of the main unit. The range of
the remote control unit is up to about 7 m on the front axis of the remote control light reception section (when new batteries are used).The
light reception range is up to 20˚to the left and right or up and down from the front axis.
●Before using for the first time, be sure to install the two provided batteries (AA). Open the battery case cover on the rear of the remote
control unit. Then, set the batteries in the correct direction by referring to the plus and minus indications shown in the case.
VIDEO
OUT
AUTO
WHITE
IRISIRIS
123
MEMORY
FREEZE PCLIGHTS D-ZOOM
NEAR FAR
FOCUS
WIDETELE
PRESET 21
ZOOM
MENU
POINTER
REMOTE CONTROL UNIT
SSV3789
2
1
%
#
0
9
8
7
3
4
5
@
$
!
6
VIDEO OUT (p. 12)
1
●Press to output composite signals from the camera to the VIDEO OUT connector.
●Press again to output signals to the RGB OUT connectors.
AUTO WHITE (p. 11)
2
●Adjusts the tone of a picture.
IRIS (p. 13)
3
●Use to adjust picture brightness. Press the button to brighten and the 
button to darken the picture.
●Press the and buttons simultaneously to set the iris value to 0.
PICTURE MEMORY
4
●Up to 3 pictures from the camera can be stored in memory as still images.
●When the picture you want to store is displayed, press one of the PICTURE
MEMORY buttons 1to 3for more than 2 seconds to store it in memory. In the
upper left of the screen, “M1”, “M2”, or “M3”will appear briefly to confirm the
image has been saved.
●To call a stored picture, press one of the PICTURE MEMORY buttons 1to 3.
●Press again to restore the previous picture.
LIGHTS (p. 13)
5
●Each time this button is pressed, the illumination switches as follows.
D-ZOOM (p. 10)
6
●Press to enlarge a picture electronically.
FREEZE (p. 11)
7
●Press to freeze a picture from the camera.
●Press again to release the picture freeze mode.
●When the split mode is engaged with the ON-SCREEN ADJUSTMENTS, a still
image and camera picture can be displayed on a divided screen.
Note:
●Pictures stored in memory are not saved when the power is turned off.
●When an image is output from the VIDEO OUT connector, the [PICTURE
MEMORY 1 to 3 ] buttons will not operate.
PC (p. 12)
8
●Press to output the signals from the equipment connected to the PC IN connec-
tor to the RGB OUT connectors.
●Press again to restore the previous signals.
FOCUS (p. 11)
9
●Press these buttons to adjust the focus.
ZOOM TELE/WIDE (p. 10)
0
●Press the TELE button to enlarge the picture size and the WIDE button to reduce it.
Side illumination lights. Back illumination lights. No illumination.

17
ENGLISH
ZOOM PRESET (p. 10)
!
●2 frequently used picture sizes can be stored in memory.
●Adjust the picture size as required and store it in memory by pressing the PRESET 1 or 2 button for more than 2 seconds.
●To recall the stored picture, press the PRESET 1 or 2 button.
MENU
@
#
●Use for ON-SCREEN ADJUSTMENTS (p. 14).
POINTER
$
%
●Press to show the pointer on the display. The pointer can be moved according to the direction of the arrows. Hold the buttons pressed to
increase the speed of the pointer movement.
* With the ON-SCREEN ADJUSTMENTS, the pointer shape and color can be set (p. 14 and 15).
Notes on using the remote control unit
●Applicable light reception range of the remote control unit
The applicable light reception range is a distance of approx.
7 m from the front axis of the remote control unit light recep-
tion section and approx. 20˚from the axis in the vertical and
horizontal plane. Please use the unit within this range.
●When direct sunlight or powerful illumination (inverter fluorescent light, flash light, etc.) hits the
remote control light reception section, the remote control may not work properly. In this case, change
the direction of this unit or the illumination.
●When there is a person or an object between the remote control and the light reception section,
signal reception may not be possible.
●If the remote control is dropped or a violent shock is applied to it, the internal mechanism and
electronic parts may be damaged. Be careful when handling it.
●When the batteries are close to depletion, the operating range will be reduced. In this case, replace
the batteries with new ones.
●When changing the batteries, always replace both batteries with new ones. Do not use a new
battery together with an old one. Otherwise, a fire or injury may result due to explosion or leakage
of the battery.
●When the remote control is not used for a long period (more than one month), remove the batteries.
Otherwise, a fire or injury may result due to leakage of the battery.
●Do not charge, disassemble or heat a battery nor throw it into a fire. Otherwise, a fire or injury may
result due to explosion or leakage of the battery.
Approx. 20˚
Approx. 20˚
Approx. 7m

18
Effective presentations
1. Use the FREEZE function when changing presentation items (p. 11).
1Press the FREEZE button to freeze the current picture.
2Switch the items on the stage and adjust the position as required. During this period, a still image of the previously shown item is
displayed.
3Press the FREEZE button again. The new item is shown on the display.
This method is especially useful when presenting consecutive items that are the same size (zoom or focus function is not used).
2. Use the PICTURE MEMORY buttons 1 to 3 (p. 16).
Example 1 : When comparing and examining three tables, store them in the PICTURE MEMORY (1 to 3). These three tables can be
switched with one button.
Example 2 : Shoot a 3D object at various angles using the 5-position camera arm function (p. 8) and store the different shots in
memory. These stored images can be used to enhance your presentation.
Example 3 : Store frequently used presentation material (documents, objects, etc.) to make your presentation run more smoothly.
To show a picture from the camera, press the same button (PICTURE MEMORY 1 to 3) again or press the "FREEZE" button. To show a still
picture with the "FREEZE" function when in the PICTURE MEMORY mode, press the "FREEZE" button once and press it once more to show a
picture from the camera.
3. Use the VIDEO OUT function when changing items (p. 12).
1Connect the optional LCD monitor (TA-AV-Z7U) etc. to the VIDEO OUT connector on the rear of this unit (p. 6).
2When switching items on the stage, press the VIDEO OUT button. The display screen goes black. However, the picture from the
camera can be checked on a local monitor.
3Change the items and adjust the zoom, iris, etc. by checking the picture on the local monitor.
4When you have completed all necessary adjustments, press the VIDEO OUT button again. The new item is shown on the display.
This method is recommended when showing items of different sizes and when using the zoom and iris, etc.
By taking advantage of this presenter’s many features, you can conduct a more effective presentations.
Notes:
●Depending on the type of projector, RGB output pictures may be distorted or may take time to appear when switching.
●Depending on the type of projector, indications such as “NO SYNC”may appear when signals are switched off.
4. Use the split mode of the FREEZE function (p. 11).
1Set the split mode with the ON-SCREEN ADJUSTMENTS. The screen can be divided horizontally (“Hori.”) or vertically (“Verti.”).
2Place the item on the lower half (“Hori.”is selected) or the right half (“Verti.”is selected) of the stage. Press the FREEZE button to
freeze the picture. (The indicator blinks.) For example, show an object with closed cover.
3The upper or left half of the stage is used to show a real time moving picture. Therefore, move the object to the upper or left half of
the stage and open the cover. Now, the object is shown with the cover opened and closed on the same screen.
This split mode is also useful to switch presentation materials continuously while keeping the contents fixed.
5. Give an explanation using the POINTER when a picture is frozen.
1Press the FREEZE button to freeze the current picture.
2Explain the item being viewed by moving the cursor around with the POINTER buttons to show your audience what you are talking
about. The pointer can be moved in the direction shown by the arrows on the remote control. As the picture is frozen with the
FREEZE function, the pointer does not shift from the item on the screen even if the material has moved.

19
ENGLISH
Controlling this unit externally
The control panel and the ON-SCREEN ADJUSTMENTS functions can be controlled via an external device such as a personal
computer.
Information on communication protocols and commands is available separately. For details, consult your JVC dealer.
 Connection with a personal computer
1. Turn this unit and the personal computer off.
2. Connect the personal computer to the REMOTE IN connector on the rear panel of this unit with an RS-232C cable.
3. Turn this unit and the personal computer on.
4. Set the computer’s RS-232C communication settings as specified in the interface specifications.
5. Start up the control program on the computer.
 Interface specifications
•Communication method : Full duplex asynchronous
•Baud rate : 9600 bps
•Start bit : 1 bit
•Stop bit : 1 bit
•Data length : 8 bits
•Parity : Even parity
 RS-232C Cable
Connection to a serial port
(AV-P1000) (PC)
D-sub 9-pin female D-Sub 9-pin female
CD 1 ................................................... 1 CD
TXD 2 ................................................... 2 RD
RXD 3 ................................................... 3 TD
DTR 4 ................................................... 4 DTR
SG 5 ................................................... 5 SG
DSR 6 ................................................... 6 DSR
RTS 7 ................................................... 7 RTS
CTS 8 ................................................... 8 CTS
RI 9 ................................................... 9 RI
System connections
5
10
15
1
6
11
Pin No. 1
Signal name RED
2
GREEN
3
BLUE
4
NC
5
GND
6
GND
7
GND
8
GND
9
NC
10
GND
11
NC
12
NC
13
Hs/Cs
14
Vs
15
NC
(female)
 Connector pin assignments and signal name
RGB OUT2 connector
PC IN connector

20
No picture appears.
Focusing is not possible.
The picture is blurred.
Dust appears.
The picture is dark.
A stripe pattern appears
on the picture of a printed
matter.
The tone is strange.
Beats appear in the pic-
ture.
This unit does not operate
even when a button is
pressed.
The movement of the pic-
ture is slow.
The remote control does
not work.
The camera picture has
white or black spots.
A color reflection or grid
pattern appears.
TROUBLE SHOOTING
Problem Points to Check
●Is the power plug removed from the AC outlet?
●Is the power switch turned on?
●Is the cable connected correctly?
●Is the camera head positioned correctly?
●Is the iris set value appropriate (p. 13)?
●Is the RGB OUT or VIDEO OUT connector switched correctly?
●Are the MODE switch and SYNC. switch set appropriately (p. 5)?
●Did you store the picture in PICTURE MEMORY before recalling it? If you did not store it after
the power is turned on, a black screen is shown (p. 16).
●Is the close-up lens set?
●Is the object too close to the lens or is the top of the object at a height of more than 100 mm from
the stage surface?
●Has the film set in the slide film holder been enlarged too much?
●Did you shoot the surrounding objects with a camera on which the close-up lens is set (p. 9)?
●If this unit is connected to a projector, check if the projector is out of focus.
●Is the close-up lens or camera lens dirty? Clean it with a commercially available cleaner.
●Is the side illumination on?
●Is the iris set value appropriate?
●The dots in the printed matter interfere with the pixels in the camera image device and color
stripes may occur. In this case, change the picture size slightly with the ZOOM buttons.
●Did you adjust the tone with the AUTO WHITE SET (p. 11)?
●Is the set value for [RED LEVEL] and [BLUE LEVEL] of the ON-SCREEN ADJUSTMENTS opti-
mum?
●When this unit is used near equipment generating a strong electric wave or a digital device such as
a personal computer, beats may occur in the picture. Keep this unit away from such equipment.
●When two or more buttons are pressed simultaneously or the button is pressed many times
continuously, this unit may not operate correctly. When pressing buttons, leave an interval be-
tween presses.
●With some buttons, an on-screen display is shown and some buttons do not work when another
function is activated. Refer to the description on the buttons.
●As a high-pixel CCD is used in this unit, signal processing takes time. As a result, picture move-
ment is slow (about 4 to 5 frames/second).
●Are there batteries in the remote control unit?
●Are the batteries exhausted?
●Is the remote control unit being operated outside the effective range (p. 16)?
●Black or white spots may appear in rare cases due to the high-pixel CCD characteristics of a
moving picture. If the picture is enlarged with the DIGITAL ZOOM function and spots are particu-
larly noticeable, switch the DIGITAL ZOOM off.
●During the SVGA mode when a moving object is projected onto the screen, yellow or blue colors
may be reflected at its focal point or a grid pattern may appear. In either case use another mode.
If you encounter a problem, first check the following points to see if a solution is provided. If the problem persists, stop using the unit
and consult your JVC dealer.
