SERVICE MANUAL
DVD VIDEO PLAYER
No.A0030
Jun. 2002
COPYRIGHT 2002 VICTOR COMPANY OF JAPAN, LTD.
XV-S300BK / XV-S332SL
XV-S402SL / XV-S403SG
XV-S300BK/XV-S332SL
XV-S402SL/XV-S403SG
Each difference point
XV-S300BK
XV-S332SL
XV-S402SL
XV-S403SG
Black
Silver
Silver
Silver
-
-
O
O
-
-
O
O
Multi-Brand remote
(Remote controller)
Model Body color Optical digital out
XV-S300BK
UJ
XV-S332SL
A,UB,UG,UP,US,UT,UW,UX
Area Suffix
UJ ------------ U.S.A.Militaly
A ------------------- Australia
UB -------------- Hong Kong
UG ---Turkey,South Africa,
Egypt
UP --------------------- Korea
US --------------- Singapore
UT -------------------- Taiwan
UW --- Brazil,Mexico,Peru
UX ------------ Saudi Arabia
XV-S402SL
A,UG,UP,US,UT
XV-S403SG
UB,UG,US,UT,UX
This illustration is XV-S402SL
OPEN/
CLOSE
STANDBY/ON
DVD
TV1
123
456
789
10 0 +10
TV2 TV3
TV4 TV5 TV6
TV7
SUB TITLE AUDIO
THEATER
POSITION
DIGEST ANGLE ZOOM
AMP VOL
- +
3D
PHONIC
TV8 TV9
TV
PREVIOUS
CLEAR SELECT STROBE
NEXT
RETURN
VOL
-
SLOW
-
SLOW
+
VOL
+
TV/VIDEO
CANCEL
TV0
ENTER
MUTING
TV DVD
RM-SXV007U
REMOTE CONTROL
D
I
S
P
L
A
Y
M
E
N
U
T
O
P
M
E
N
U
C
H
O
I
C
E
TV
PLAY
MODE
CH
+
CH
-
OPEN/CLOSE
STANDBY/ON
STANDBY
DOLBY
XV-S402 DVD/SUPER VCD/VCD/CD PLAYER
SKIP
PAUSEPLAYSTOP
D I G I T A L
(For XV-S402SL/XV-S403SG Only)
VIDEO CD
For except XV-S300BK

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
2
TABLE OF CONTENTS
1 Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Critical parts for safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5 Preventing static electricity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6 Handling the traverse unit (optical pickup) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.7 Importance admistering point on the safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.8 Precautions for Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Disassembly method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Main body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Loading assembly section. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Traverse mechanism assembly section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 Adjustment method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.1 Initialization method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.2 Display of "Laser current value" and "Jitter value" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3 Flap adjustment of the pick-up guide shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.4 Attention when pick-up is exchanged . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.5 Confirm method of operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.6 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.7 Check points for each error. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4 Description of major ICs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.1 74VHC00MTC-X (IC455,IC503) : 2-input nand gate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.2 74VHC74MTC-X (IC454) : ZIVA Wait . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.3 AN8703FH-V (IC101) : Frontend processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.4 BA5983FM-X (IC201) : 4CH Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.5 CY24203SC-X (IC571) : MPEG / Audio clock generator with VCXO . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.6 BA6664FM-X (IC251) : 3Phase Motor Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.7 74VHCT08ASJ-X (IC704) : 2-input AND gate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.8 K3N5V1000F-J001 (IC402) :P2 ROM of 1,048,576word x 16 bit / 2,097,152 word x 8 bit . . . . . . . . . . 31
4.9 K4S641632F-TC75 (IC504) :CMOS SDRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.10 MN101C35DLD (IC701) : System controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.11 MN102L62GLH (IC401) : Unit CPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.12 MN103S28EGA (IC301) : Super optical disc controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.13 MM1565AF-X (IC951) / MM1563DF-X (IC953) : 500mA Regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.14 MN35505-X (IC703) : DAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.15 S-93C66AFJ-X (IC451) : EEPROM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.16 STR-G6551-F8 (IC901) : Switch regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.17 ZIVA-4.1-PB0 (IC501) : Back end - Digital decoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
3
SECTION 1
Important Safety Precautions
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purposes.
For continued protection, no changes should be made to the
original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be
performed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by
using replacement components rated for higher voltage,
wattage, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Service
Manual. Electrical components having such features are
identified by shading on the schematics and by ( )
on the Parts List in the Service Manual. The use of a sub-
stitute replacement which does not have the same safety
characteristics as the recommended replacement parts
shown in the Parts List of Service Manual may create
shock, fire, or other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassembling.
(5) Leakage shock hazard testing)
After reassembling the product, always perform an isolation
check on the exposed metal parts of the product (antenna
terminals, knobs, metal cabinet, screw heads, headphone
jack, control shafts, etc.) to be sure the product is safe to
operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particu-
larly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage
current must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000 ohms per volt or more sen-
sitivity in the following manner. Connect a 1,500 10W
resistor paralleled by a 0.15 F AC-type capacitor be-
tween an exposed metal part and a known good earth
ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for lo-
cal voltage.
1.3 Caution
Burrs formed during molding may be left over on some
parts of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety.
When replacing them, be sure to use the parts of the same type
and rating as specified by the manufacturer. (Except the JC version)
G
ood earth ground
Place this
probe on
each expose
d
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
4
1.5 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged,
can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as DVD players.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
(1) In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement op-
tical pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
(2) Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can
easily destroy the laser diode.
1.6 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too
long a time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4)I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it
Conductive material
(conductive sheet) or iron pla
te
(
caption)
A
nti-static wrist strap

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
5
1.7 Important for laser products
(1) CLASS 1 LASER PRODUCT
(2) DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
(3) CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace
the complete Laser Unit if it malfunctions.
(4) CAUTION : The compact disc player uses invisible laser
radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are de feated.
It is dangerous to defeat the safety switches.
(5) CAUTION : If safety switches malfunction, the laser is able
to function.
(6) CAUTION : Use of controls, adjustments or performance
of procedures other than those specified herein may result
in hazardous radiation exposure.
CAUTION Please use enough caution not to see the
beam directly or touch it in case of an
adjustment or operation check.
REPRODUCTION AND POSITION OF LABEL and PRINT
WARNING LABEL and PRINT
C L A SS 1
L A SE R P R O DUC T
CAU TIO N : Invisible laser
radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE
TO BEAM. (e)
AD V AR SEL : Usynlig laser-
stråling ved åbning, når
sikkerhedsafbrydere er ude
af funktion. Undgåudsæt-
telse for stråling (d)
V ARN I N G : Osynlig laser-
strålning när denna del är
öppnad och spärren är
urkopplad. Betrakta ej
strålen. (s)
V AR O : Avattaessa ja suo-
jalukitus ohitettaessa olet
alttiina näkym ätt ömälle
lasersäteilylle. Älä katso
säteeseen. (f)

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
6
1.8 Precautions for Service
1.8.1 Handling of Traverse Unit and Laser Pickup
(1) Do not touch any peripheral element of the pickup or the actuator.
(2) The traverse unit and the pickup are precision devices and therefore must not be subjected to strong shock.
(3) Do not use a tester to examine the laser diode. (The diode can easily be destroyed by the internal power supply of the tester.)
(4) To replace the traverse unit, pull out the metal short pin for protection from charging.
(5) When replacing the pickup, after mounting a new pickup, remove the solder on the short land which is provided at the center
of the flexible wire to open the circuit.
(6) Half-fixed resistors for laser power adjustment are adjusted in pairs at shipment to match the characteristics of the optical block.
Do not change the setting of these half-fixed resistors for laser power adjustment.
1.8.2 Destruction of Traverse Unit and Laser Pickup by Static Electricity
Laser diodes are easily destroyed by static electricity charged on clothing
or the human body. Before repairing peripheral elements of the traverse unit or pickup, be sure to take the following electrostatic
protection:
(1) Wear an antistatic wrist wrap.
(2) With a conductive sheet or a steel plate on the workbench on which the traverse unit or the pick up is to be repaired, ground
the sheet or the plate.
(3) After removing the flexible wire from the connector (CN101), short-circuit the flexible wire by the metal clip.
(4) Short-circuit the laser diode by soldering the land which is provided at the center of the flexible wire for the pickup. After com-
pleting the repair, remove the solder to open the circuit.
Please refer to "Fig.2-4" of "Disassembly
method" for details.
Short circu
it
CN101
Servo control
board
S
hort circuit

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
7
SECTION 2
Disassembly method
There is a part different from the photograph
according to the model and the destination though
explains this disassembly method by using XV-S403SG for
Australia.
2.1 Main body
2.1.1 Removing the top cover (see Fig.2-1)
(1) Remove the two screws A attaching the top cover
on both sides of the body.
(2) Remove the three screws Battaching the top
cover on the back of the body.
(3) Remove the top cover from the body by lifting
the rear part of the top cover.
ATTENTION:
Do not break the front panel tab fitted to the top cover. Fig.2-1
2.1.2 Removing the mechanism assembly(see Fig.2-2,2-3)
• Prior to performing the following procedure, remove the top cover .
• There is no need to remove the front panel assembly.
(1) Remove the three screws C attaching the mechanism
assembly on the bottom chassis.
(2) The servo control board is removed from the connector CN961
and CN701 connected with the main board respectively.
(3) Remove the mechanism assembly by lifting the rear part
of the mechanism assembly.
Fig.2-2
Fig.2-3
2.1.3 Removing the servo control board (see Fig.2-4)
• Prior to performing the following procedure, remove
the top cover and mechanism assembly.
(1) Disconnect the card wire from connector CN201 and
CN202 on the servo control board respectively.
(2) Disconnect the flexible wire from connector CN101 on the
servo control board from pick-up.
< ATTENTION >
At this time, please extract the wire after short-circuit-
ed of two places on the w ire in part a with solder.
Please remove the solder two places of part a after
connecting the wire with CN101 when reassembling.
(3) Two places in hook b are removed, the servo control
board is lifted, and it is removed. Fig.2-4
A x 2
B
B
B
C
CN702 CN703
Main board
Mechanism assembly
CC
CN701 CN961
Servo control board
Main board
Mechanism
assembly
Hook b Hook b
Servo control
board
CN202
CN101
CN201
Part a

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
8
2.1.4 Removing the rear panel (see Fig.2-5)
• Prior to performing the following procedure, remove
the top cover.
(1) Remove the seven screws D attaching the rear panel
on the back of the body.
• As for the screw D, the number and the position are dif-
ferent according to the destination and model. Fig.2-5
2.1.5 Removing the front panel assembly (see Fig.2-6,2-7)
• Prior to performing the following procedure, remove
the top cover.
• There is no need to remove the mechanism assembly.
(1) Remove the one screw E attaching the front panel
assembly on the bottom chassis.
(2) Disconnect the wire from CN702 and CN703 on the
main board respectively.
(3) Hook cand dare removed respectively, and the front
panel assembly is removed.
Fig.2-6
Fig.2-7
2.1.6 Removing the main board (see Fig.2-8)
• Prior to performing the following procedure, remove the top
cover, mechanism assembly and rear panel.
(1) Disconnect the wire from CN702 and CN703 on the
main board respectively.
(2) Remove the four screws F attaching the main board
on the bottom chassis.
Fig.2-8
DDD
Rear panel
E
Hook c
Hook d
Hook d
Front panel
assembly
CN702
CN703
Main board
Mechanism assembly
CN702 CN703
F
F
F
F
Main board

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
9
2.2 Loading assembly section
2.2.1 Removing the clamper assembly (See Fig.2-9)
(1) Remove the four screws Aattaching the clamper assem-
bly.
(2) Move the clamper in the direction of the arrow to release
the two joints a on both sides.
ATTENTION:
When reattaching, fit the clamper to the two joints a.
Fig.2-9
2.2.2 Removing the tray (See Fig2-10. and 2-11)
• Prior to performing the following procedure, remove the
clamper assembly.
(1) Push b of the slide cam into the slot on the left side of the
loading base until it stops.
(2) Draw out the tray toward the front.
ATTENTION:
Before reattaching the tray, slide the part c of the slide
cam to theright as shownin Fig.2-11.
Fig.2-10
Fig.2-11
Joint a
Joint a
AA
A A
Push
b
Tray
Clamper base
Part c
Slide cam

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
10
2.2.3 Removing the traverse mechanism
assembly (See Fig.2-12 and 2-13)
• Prior to performing the following procedure, remove the
clamper assembly and the tray.
(1) Remove the four screws Battaching the traverse mecha-
nism assembly.
ATTENTION:
Before reattaching the traverse mechanism assembly,
pass the card wire extending from the spindle motor
board through the notch d of the elevator.
Fig.2-12
Fig.2-13
2.2.4 Removing the elevator (See Fig.2-14)
• Prior to performing the following procedure, remove
the clamper assembly, the tray and the traverse
mechanism assembly.
(1) Extend each bar einside of the loading base
outward and detach the elevator shaft.
ATTENTION:
When reattaching, first fit the two
shafts on the front of the elevator to
the slots f of the slide cam.
Fig.2-14
BB
B
BB
B
Traverse mechanism
assembly
B
BB
Traverse mechanism assembly
Elevator
Notch d
Elevator
Elevator
Elevato
r
e
e
Loading base
Elevator
Shafts
Slide cam
Slots f

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
11
2.2.5 Removing the motor assembly (See Fig.2-15 and 2-16)
• Prior to performing the following procedure, remove the
clamper assembly, the tray, the traverse mechanism assem-
bly and the elevator.
(1) Remove the belt from the pulley.
(2) Remove the screw C attaching the motor assembly.
(3) Turn over the body and remove the screw D
attaching the motor assembly.
(4) Release the two tabs gretaining the motor board.
Fig.2-15
Fig.2-16
C
Motor assembly
Belt
Loading base
Motor assembly
D
Tabs g

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
12
Fig.2-17
2.2.6 Removing the Idle gear/pully gear/middle gear/
slide cam(See Fig.2-17 to 2-19)
• Prior to performing the followong procedure,remove
the clamper assembly,the tray,the traverse
mechanism assembly,the elevator and the motor
assembly.
(1) Press the two tabs h inward and pull out idle gear
(2) Remove the screw Eattaching the pulley gear bracket.
Slide the pulley gear bracket in the direction of the arrow
and pull out the pulley gear.
(3) Slide the side cam in the direction of the arrow to release
the two joins iand remove upward.
(4) Remove the middle gear. Fig.2-18
Fig.2-19
Motor assembly
Pulley gear
Pulley gear bracket
Pulley gear bracket
EIdle gear
Idle gear
Pulley gear
Tads h
Pulley gear
Middle gear
Joint i Joint i
Slide cam
Slide cam Middle gear
Loading base

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
13
2.3 Traverse mechanism assembly section
2.3.1 Removing the feed motor assembly (See Fig.2-20)
(1) Unsolder the two soldering j on the spindle motor board.
(2) Remove the two screws Fattaching the feed motor
assembly.
2.3.2 Removing the feed motor (See Fig.2-20 to 2-22)
• Prior to performing the following procedure, remove the feed
motor assembly.
(1) Remove the screw G attaching the thrust spring.
ATTENTION:
When reattaching the thrust spring, make sure that
the thrust spring presses the feed gear (M) and the
feed gear (E) reasonably.
(2) Remove the feed gear (M).
(3) Pull out the feed gear (E) and the lead screw.
(4) Remove the two screws Hattaching the feed motor.
ATTENTION:
When reattaching, pass the two cables extending
from the feed motor through the notch k of the feed
holder as shown in Fig2-20.
Fig.2-20
Fig.2-21
Fig.2-22
F
Soldering j
Notch k
F
Feed motor assembly
Spindle motor board
Spindle motor
Picku
p
Feed gear (M)
Thrust sprin
g
G
Feed gear (E)
Lead screw
Feed motor
Feed holder
H

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
14
2.3.3 Removing the pickup (See Fig.2-24 and 2-25)
(1) Remove the screw I attaching the T spring (S) and the
shaft holder. Remove also the plate.
ATTENTION:
When reattaching,make sure that the
T spring(S)presses the shaft.
(2) Pull out the part l of the shaft upward. Move the part m in
the direction of the arrow and detach from the spindle
base.
(3) Disengage the joint n of the pickup and the shaft in the
direction of the arrow.
(4) Pull out the shaft from the pickup.
(5) Remove the two screws J attaching the actuator.
(6) Disengage the joint of the actuator and the lead spring.
Pull out the lead spring.
Fig.2-23
The spring must be under the shaft when you
install pick-up.
Fig.2-24
Fig.2-25
2.3.4 Removing the shaft holder / shaft (See Fig.2-26)
(1) Remove the screw Kattaching the shaft holder.
(2) Remove the shaft.
Fig.2-26
Shaft
Spring
Pick-u
p
T
spring (S)
Plate
Joint n
Pickup
Part m
Shaft holder
Part l
I
Shaft
P
ickup
Lead spring
Actuator
JActuat
or
Lead sprin
g
Shaft
Shaft holder
K

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
15
2.3.5 Removing the spindle motor assembly
(See Fig.2-27 to 2-29)
(1) Remove the three screws L attaching the spindle motor
on the bottom of the mechanism base.
ATTENTION:
When reattaching, pass the card wire extending from
the spindle motor board through the notch of the spin-
dle base.
(2) Remove the three screws M attaching the spindle base.
Fig.2-27
Fig.2-28
Fig.2-29
L
L
Spindle motor
Spindle motor assembly
Spindle base
L
M
M
Spindle bas
e
Mechanism base

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
16
SECTION 3
Adjustment method
3.1 Initialization method
If microprocessor (IC401,IC402,IC451) or pick-up is replaces, initialize the
DVD player in the following matter
(1) Take out the disc and close the tray.
(2) Unplug the power plug.
(3) Insert power plug into outlet while pressing both "PLAY" button and "OPEN/CLOSE" button.
(4) FL Display indicate "TEST * * #" , * * :Version, #" :Region code
(5) Press "3D-PHONIC" button of remote controller. and EEPROM initialize start.
(6) When indicate "DTS" on the display, initialize finishes.
(7) The power is turned OFF, and Unplug the power plug.
3.2 Display of "Laser current value" and "Jitter value"
"Laser current value" and "Jitter value" are displayed on the FL display by the undermentioned
method. Please refer to the failure diagnosis.
(1) Take out the disc and close the tray.
(2) Unplug the power plug.
(3) Insert power plug into outlet while pressing both "PLAY" button and "OPEN/CLOSE" button.
(4) FL Display indicate "TEST * * #" , * * :Version, #" ::Region code
(5) Press the "OPEN/CLOSE" button to move the tray outward.
Put the test disc (VT-501) on the tray and press "OPEN/CLOSE" button.
The tray should move inward (Note:Don't push to close the tray directly by hand etc.)
(6) Press the "PLAY" button.
(7) After a few seconds, the laser current value and the jitter value is displayed on the FL indicator as follows.
Fig.3-1
3.2.1 For Laser current value
The laser current value becomes 40mA for the above-mentioned.
Becomes a test mode by doing above-mentioned procedure 1) - 4). Afterwards, the laser current value can
be switched by pushing the button to remote controller without turning on the disk.
It can be judged it is simply good if the displayed current value of the laser is smaller than that of the undermentioned value.
Moreover, there must be a deteriorated possibility and the pick-up must exchange the pick-up more than the undermen-
tioned value. Laser current value of CD ------ 49 mA or less
Laser current value of DVD ---- 64 mA or less
Fig.3-2
Remote control "4" button --- Laser of CD *Returns to a usual test mode by the
Remote control "5" button --- Laser of DVD thing to push the "STOP" button of
remote controller.
0 0 3 5 1 8 B 6
FL Display(example)
Laser current value Jitter value
* The test mode is canceled whe
n
the power is turned off.
POWER Button
DTS Display part
(Initialize complete)
FL Display
OPEN/CLOSE
Button(Test mode)
PLAY Button
(Test mode & display of jitter)
3D PHONIC
Button (Initialize start)
5 Button
(Laser of DVD)
4 Button
(Laser of CD)

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
17
3.2.2 For Jitter value
The jitter value is displayed on the FL display referring to the previous page.
The jitter value is displayed by the hexadecimal number.
In the following cases, please "Flap adjustment of the pick-up guide shaft" referring to the following page.
Before using the TEST disc VT-501, careful check it if there is neither damage nor dirt on the read surface.
Returns to a usual test mode by the thing to push the "STOP" button ot remote controller.
< In the following cases, please adjustment >
•When you exchange the pick-up
•When you exchange the spindle motor
•When the reading accuracy of the signal is bad (There is a block noise in the screen etc..)
Fig.3-3
POWER Button
DTS Display part
(Initialize complete)
FL Display
OPEN/CLOSE
Button(Test mode)
PLAY Button
(Test mode & display of jitter)
3D PHONIC
Button (Initialize start)
5 Button
(Laser of DVD)
4 Button
(Laser of CD)

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
18
3.3 Flap adjustment of the pick-up guide shaft
3.3.1 Tool list for adjustment
•Hex wrench for adjustment
Off-the-shelf (1.3mm)
•Test disc
VT-501 or VT-502
•Stud (four pieces set)
Parts No. : JIGXVS40 (One is not used though there are four. )
Fig.3-4
•Assistance board and extension cord
Fig.3-5
3.3.2 Connection diagram
Fig.3-6
XV-S40 CONTROL CONNECT
XV-S40
MAIN CONNECT
EXTXVS40MK2CB-2 CONTROL CONNECT
EXTXVS40MK2CB-1 MAIN CONNECT
P a r t s N o . : EXTXVS 40 M K 2 CB
P a r t s N o . : EXTXVS 40 CB
P a r t s N o . : EXTXV 521 CB
These parts are not used
.
CN501 XV-521
CN706 XV-521
MAIN CONNECT
XV-521 CN502
CONT CONNECT
CN701 XV-521
MAIN CONNECT
CONT CONNECT
XV-521 CN601
MAIN CONNECT
XV-521 CN503
CONT CONNECT
12
3
4
5
6
EXTXVS40MK2CB-2 CONTROL CONNECT
EXTXVS40MK2CB-1 MAIN CONNECT
XV-521 CN601
MAIN CONNECT
XV-521 CN503
CONT CONNECT
1
2
3
4
5
6
To CN701 of main board
T
o CN503 of servo control board To CN502 of servo control boa
rd
To CN961 of main board

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
19
3.3.3 Adjustment preparation
(1) The mechanism assembly is made in the state from the main body from which is detached referring to the disassembly method.
(2) Three studs are installed in the mechanism assembly respectively.
(3) The servo control board is removed from the mechanism assembly, and puts into the state set up as shown in figure. (Each
wire connected by the servo control board this time leaves the connection maintained.)
Between shaft and hook of mechanism assembly of figure Board is put.
(4) The extension cord is inserted in the connector of the assistance board respectively.
The main board is connected with the servo control board as shown in figure.
Fig.3-7 Fig.3-8
3.3.4 Adjustment
(1) Puts into the state to display the jitter value on the FL display referring to "Display of the jitter value".
(2) The adjustment screw under the traverse mechanism is turned with hex wrench, and matches so that the jitter value displayed
on the FL display may become "maximum" value.
Fig.3-9
<POINT>
(1) Turns in the forward or the opposite direction,and
makes to the position where the jitter value is good
the half rotation of adjustment screw a and b(180 de-
grees) respectively.
(2) Afterwards, adjustment screw b and c are turned in
the same way, and makes to the best position.
Mechanism
assembly
Stud Stud
Servo control board
Assistance
board
Assistance
board
E
xtension
cord
Extension
cord
Main board
Shaft & hook Servo control boa
rd
Assistance
board
Assistance
board
Assistance
board Extension
cord
Extension
cord
Shaft & hook
Adjustment screw a Adjustment screw b
Adjustme
nt
screw c

XV-S300BK/XV-S332SL/XV-S402SL/XV-S403SG
20
3.4 Attention when pick-up is exchanged
(1) Flexible wire, pick-up spring, switch actuator, and lead
spring are removed from an old pick-up(broken the one).
< Guide >
Flexible wire, pick-up spring and switch actuator,
lead spring are removed without each decomposing
while assembled.
(2) The above-mentioned parts are installed in a new pick-up
(non-defective article).
(3) A flexible wire is inserted in the connector which has taken
side with the pick-up, and solder is put up to short land part
"a" two places on a flexible wire.
(4) The electrostatic breakdown protection circuit attached
to the pick-up is cut.
< ATTENTION >
Please cut the electrostatic breakdown protection cir-
cuit attached to the pick-up after solder is put up to
two places on a flexible wire short land part "a" of the
insertion of a flexible wire this time in the connector
without fail.
The procedure might be mistaken and if solder has
not surely adhered to two places on a flexible wire
short land part "a", the laser diode in the pick-up be
destroyed again.
Fig.3-10
Fig.3-11
(5) The pick-up is installed in the traverse mechanism.
(6) A flexible wire is connected with connector CN101 on the-
servo control board by installing the traverse mechanism
in the loading mechanism.
(7) Solder in two places on a flexible wire in part "a" is re-
moved.
< ATTENTION >
Please remove solder in two places in part "a" after
connecting a flexible wire with connector CN101 on
the servo control board without fail this time.
When the procedure is mistaken, the laser diode in
the pick-up might be destroyed.
Please remove solder in two places in part "a" surely. Fig.3-12
Fig.3-13
Switch actuator
Lead spring
Pick-up
Pick-up spring
Flexible wire
Flexible wire
Connector
Short lan
d
part "a"
Electrostatic breakdown
protection circuit
E
lectrostatic breakdown
protection circuit
Cutting pa
rt
CN101
Short land
part "a"
S
ervo control
board
