TABLE OF CONTENTS
The following table indicates main different points between models HR-XV1EU-C and HR-XV1MS.
MODEL HR-XV1EU-C
ITEM
VIDEO SYSTEM PAL PAL/SECAM/MESECAM
RF OUT USED NOT USED
VPS USED NOT USED
21 PIN CABLE OPTIONAL PROVIDED
HR-XV1MS
DIFFERENT TABLE .............................................................................................................................................................................................. 1 only
WHEN REPLACING EEPROM(MEMORY) IC ...........................................................................................................................................
1 only
2. CHARTS AND DIAGRAMS (2-1 to 2-13)
Y/C/AUDIO/H.AMP SCHEMATIC DIAGRAM......................................................................................................................................... 2-1
MICOM SCHEMATIC DIAGRAM ........................................................................................................................................................... 2-3
TUNER/JACK SCHEMATIC DIAGRAM ................................................................................................................................................. 2-5
SUB MICOM/OSD/VPS SCHEMATIC DIAGRAM.................................................................................................................................. 2-7
PRINTED CIRCUIT BOARD VCR ......................................................................................................................................................... 2-9
3. PARTS LIST (3-1 to 3-7)
3.1 PACKING AND ACCESSORY ASSEMBLY <M1> ................................................................................................................................. 3-1
3.2 ELECTRICAL PART LIST
VCR BOARD ASSEMBLY<03>................................................................................................................................................................ 3-2
4. REFERENCE (4-1 to 4-6)
GENERAL SPECIFICATIONS ............................................................................................................................................................... 4-1
The following table indicates different parts number between models HR-XV1EU-C and HR-XV1MS.
PACKING AND ACCESSORY ASSEMBLY<M1>
PACKING AND ACCESSORYASSEMBLY<M1> is indicated on the parts list.
VCR BOARD ASSEMBLY<03>
REF
NO.
!MODEL
ITEM
PW1 VCR BOARD ASSY X-A2A735B010 X-A2A779D010B
HR-XV1EU-C HR-XV1MS
1
REF
NO.
!MODEL
ITEM
!601 CABINET,FRONTASSY X-A2A735B720 X-A2A779D720
608 CABINET,FRONT X-701WPJB706 X-701WPJ1135
HR-XV1EU-C HR-XV1MS
WHEN REPLACING EEPROM (MEMORY) IC
If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to
ensure correct data settings while making reference to TABLE 1.
NOTE: No need setting for after INI FD.
[TABLE 1]
1.
2.
3.
4.
5.
6.
7.
8.
The unit will now have the correct DATA for the new MEMORY IC.
Turn on the POWER.
Press both CH UP button on the set and the FF button on the set for more than 2 seconds.
ADDRESS and DATAwill appear on FIP as Fig 1.
ADDRESS is now selected and should “blink”. Using the SET + or - button on the remote,
step through theADDRESS until required ADDRESS to be changed is reached.
Press OK to select DATA. When DATA is selected, it will “blink”.
Again, step through the DATA using SET + or - button until required DATA value has been
selected.
Pressing OK will take you back to ADDRESS for further selection if necessary.
Repeat steps 3 to 6 until all data has been checked.
When satisfied correct DATA has been entered, turn POWER off (return to STANDBY
MODE) to finish DATA input.
Fig. 1
ADDRESS DATA
INI +0 +1 +2 +3 +4 +5 +6 +7 +8 +9 +A +B +C +D +E +F
B0 --- --- --- --- --- --- --- --- --- 8B C9 D2 71 62 76 08
C0 B2 17 90 50 60 F1 54 51 51 51 B2 9F 97 8E 04 FA
D0 D9 64 2A 08 02 FF 40 00 71 9F 82 02 42 35 63 5B
E0 76 5F 08 F0 0A FB 5F 08 F0 05 F2 5F 09 F0 05 F3
F0 16 2F 9F 42 42 80 3D 68 08 89 04 3A CC --- --- ---
FINAL ASSEMBLY<M2>
