SERVICE MANUAL
COPYRIGHT © 2004 Victor Company of Japan, Limited No.YD025
2004/6
DVD VIDEO RECORDER
YD02520046
DR-M10SAA, DR-M10SAG
DR-M10SAX
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
DVDTV
DVD
CH
TIMER
REC LINK
PROG/CHECK
G-CODE
SHOW VIEW
NEXTPREVIOUS
PAUSEREC
REC MODE LIVE CHECK
SET UP DISPLAY
ON SCREEN
OPEN/
CLOSE
AUDIO SUBTITLE ANGLE
PROGRESSIVE
SCAN
SLOWSLOW PLAY/SELECT
STOP/
CLEAR
NAVIGATIONTOP MENU
RETURN
ENTER
MENU
TV
STANDBY/ON
TV
MUTING TV/
VIDEO
TV VOLUME
ABC
JKLGHI MNO
TUVPQRS WXYZ
AUXCANCEL
MEMO/MARK
DBS
DEF
Area Suffix
AA ------------------ Australia
AG ----------- Universal Asia
AX -------------- Middle East
Since the whole mechanism assembly unit is replaced, the DVD recorder
mechanism of this unit need not be adjusted.
STANDBY/ON
S-VIDEO VIDEO
L(MONO)
-
AUDIO
-
R
DV
DV IN
F1
REC MODE
PULL - OPEN
REC
LINK
DR-M10SAA, DR-M10SAG, DR-M10SAX [D4R10]

1-2 (No.YD025)
SPECIFICATION
Specifications shown are for SP mode unless otherwise specified.
E.& O.E. Design and specifications subject to change without notice.
• Manufactured under licence from Dolby Laboratories. “Dolby” and double-D symbol are trademarks of Dolby Laboratories.
• “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
• G-CODE is a trademark of Gemstar Development Corporation and is registered in the following countries: Australia, China, Hong Kong, Japan,
South Korea, New Zealand, and Taiwan. SHOWVIEW is a trademark of Gemstar Development Corporation and is registered in the following coun-
tries: Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece, Hungary, Iceland, Italy, Luxembourg, Netherlands, Norway,
Poland, Portugal, Russia, Slovakia, South Africa, Spain, Sweden and Switzerland.
The G-CODE/SHOWVIEW system is manufactured under license from Gemstar Development Corporation.
G-CODE and SHOWVIEW are different trademarks used to represent the same easy recording feature. However, for simplicity, only the term G-
CODE will be used in the instructions. If you use SHOWVIEW system, follow the same steps listed for the G-CODE system.
• This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing users only unless otherwise authorized by Macrovision Corporation. Reverse engi-
neering or disassembly is prohibited.
DR-M10SAA DR-M10SAG,DR-M10SAX
GENERAL
Power requirement AC 220 V - 240 V~, 50 Hz/60 Hz AC 110 V -240V~, 50/60 Hz
Power consumption Power on : 33 W
Power off : 17.6 W
Temperature Operating : 5°C to 40°C
Storage : -20°C to 60°C
Operating position Horizontal only
Dimensions (W ×H ×D) 435 mm ×70 mm ×350 mm
Weight 4.3 kg
VIDEO/AUDIO
Recordable disc DVD-RAM 12 cm : (4.7 GB/9.4 GB)
DVD-RAM 8 cm : (1.4 GB/2.8 GB)
DVD-R 12 cm:( 4.7 GB, 8 cm: 1.4 GB for General Ver. 2.0)
DVD-RW 4.7 GB for Ver. 1.0/1.1
Recording format DVD-RAM DVD Video Recording format
DVD-R DVD-Video format
DVD-RW DVD-Video format, DVD Video Recording format
Recording time Maximum 8 hours (with 4.7 GB disc)
(XP) : Approx. 1 hour, (SP) : Approx. 2 hours, (LP) : Approx. 4 hours, (EP) : Approx. 6 hours, (FR) : Approx.
1 hour - 8 hours
Playable disc DVD-RAM 12 cm : (4.7 GB/9.4 GB)
DVD-RAM 8 cm : (1.4 GB/2.8 GB)
DVD-R 12 cm:( 4.7 GB, 8 cm: 1.4 GB for General Ver. 2.0)
DVD VIDEO,
DVD-RW
4.7 GB
Music CD (CD-DA)
Video CD
Super Video CD(SVCD)
CD-R/RW (CD-DA, Video CD/SVCD formatted discs)
Audio recording system Dolby Digital (2 ch)
Linear PCM (XP mode only)
Video recording compression system MPEG2 (CBR/VBR)
Input/Output
S-video input Y : 0.8 - 1.2 Vp-p, 75 Ω
C : 0.2 - 0.4 Vp-p, 75 Ω
S-video output Y : 1.0 Vp-p, 75 Ω
C : 0.3 Vp-p, 75 Ω
Video input 0.5 - 2.0 Vp-p, 75 Ω(pin jack)
Video output 1.0 Vp-p, 75 Ω(pin jack)
Audio input -8 dB, 50 kΩ(pin jack) Corresponding to mono (left)
Audio output -8 dB, 1 kΩ(pin jack)
i.Link 4-pin for DV input
Component video output Y : 1.0 Vp-p, 75 Ω
PB/PR : 0.7 Vp-p, 75 Ω
Corresponding to copy protection
Optical -18 dBm, 660 nm
Coaxial 0.5Vp-p,75ohms Corresponding to Dolby Digital and DTS Digital Surround
Bit stream
Selectable in digital audio output setting menu
TUNER/TIMER
Signal system PAL-type colour signal and CCIR monochrome signal, 625 lines 50 fields
TV channel storage capacity 99 positions (+AUX position)
Tuning system Frequency synthesized tuner
Channel coverage (low) 42 MHz - 175 MHz/(high) 175 MHz - 470 MHz
UHF 470 MHz - 870 MHz(Adjustable E28 - E60)
Memory backup time Approx. 60 min.
ACCESSORIES
Provided accessories RF cable, Audio/video cable,Input Cable Adapt-
er,Output Cable Adapter, Infrared remote control unit,
"R6" battery ×2
RF cable, Audio/video cable,Input Cable Adapter,Output
Cable Adapter, Infrared remote control unit, "R6" battery
×
2,Conversion plug

(No.YD025)1-3
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

1-4 (No.YD025)
1.5 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as DVD players.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.6 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long
a time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.

(No.YD025)1-5
1.7 Important for laser products
1.CLASS 1 LASER PRODUCT
2.DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
3.CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace
the complete Laser Unit if it malfunctions.
4.CAUTION : The CD,MD and DVD player uses invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
!
Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
REPRODUCTION AND POSITION OF LABEL and PRINT
WARNING LABEL and PRINT
On mechaism assembly

1-6 (No.YD025)
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

(No.YD025)1-7
SECTION 3
DISASSEMBLY
3.1 Main body section
3.1.1 Remove the top cover (See figure 1)
(1) Remove the four screws Aattaching the top cover on both
sides of the main body.
(2) Remove the five screws Battaching the top cover on the
back of the main body.
(3) Raise the both sides and lower part of the rear of the top
cover, with opening them slightly in an outward direction.
And the top cover will be removed.
Fig.1
3.1.2 Remove the front panel assembly (See figure 2, figure 3, and figure 4)
• Prior to performing the following procedure, remove the top
cover.
• There is no need to remove the mechanism assembly.
(1) Disconnect the card wires from connector CN3001,
CN3002, CN4001 on the main board.
(2) Hooks aand bare removed respectively, and the front
panel assembly is removed.
NOTE:
In case of attach a front panel assembly, please let a
card wire pass in the hole in the front part of a chassis,
respectively, and connect.
Fig.2
Fig.3
Fig.4
B
B
Ax 2
TOP COVER
TOP COVER
TOP COVER
B
Ax 2
B
B
CN3002CN4001 CN3001
Main board
Hook a
Hook a
Hook b
Hook b
Front panel
assembly
Front panel
assembly
Card wireCard wire
Chassis of front part
Card wire

1-8 (No.YD025)
3.1.3 Remove the mechanism assembly (See figure 5)
• Prior to performing the following procedure, remove the top
cover.
• There is no need to remove the front panel assembly.
(1) Disconnect the socket wire from connector CN5303 on the
switching regurator board.
(2) Disconnect the card wire from connector CN2201 on the
digital board.
(3) Remove the four screws Cattaching the mechanism as-
sembly.
Fig.5
3.1.4 Remove the digital board (See figure 6, figure 7)
• Prior to performing the following procedure, remove the top
cover.
(1) Disconnect the card wire from connector CN2201 on the
digital board.
(2) Remove the four screws Dand Eattaching the digital
board.
(3) Remove the one screw Fattaching the jack board.
(4) Lift the digital board up, and remove it. Then, the digital
board is removed from the connectors CN4101, CN4102
on the main board. In attaching the digital board, insert the
connector on the digital board in these connectors secure-
ly.
Fig.6
Fig.7
C
Mechanism assembly
C
CN2201 C C CN5303
Digital board
EF
D
D
CN2201
EDigital board
Jack board
Digital board
Main boardCN4101
CN4102

(No.YD025)1-9
3.1.5 Remove the switching regurator board (See figure 8)
• Prior to performing the following procedure, remove the top
cover.
(1) Disconnect the card wire from connector CN5301 on the
switching regurator board.
(2) Disconnect the socket wire from connector CN5302,
CN5303, CN5305 on the switching regurator board.
(3) Disconnect the power cord from connector CN5001 on the
switching regurator board.
(4) Remove the two screws Gattaching the switching regura-
tor board.
(5) Four fasteners are removed.
Fig.8
3.1.6 Remove the main board (See figure 9, figure 10)
• Prior to performing the following procedure, remove the top
cover, mechanism assembly, module board.
(1) Disconnect the card wire from connector CN3001,
CN3002, CN4001, CN5101, CN7301 on the main board
(2) Disconnect the socket wire from connector CN5302 on the
switching regurator board.
(3) Remove the two screws Hattaching the main board.
(4) Remove the seven screws Iattaching the rear panel with
main board.
Fig.9
Fig.10
Switching regurator
board
CN5001
CN5305 G
G
CN5303
Power cord
Fastener
Fastener
CN5301
Fastener
CN5302
switching regurator
board
CN5302CN3001H
CN5101
CN3002CN4001
Main board
H CN7301
I
Rear panel

1-10 (No.YD025)
SECTION 4
ADJUSTMENT
4.1 Timer clock adjustment
If an error comes to arise for a clock, the following procedure will adjust.
(1) Connect the frequency counter to the measuring point (D1).
(2) Connect the short wire between the short point (D2) and Vcc (5V).
(3) Short the leads of capacitor (D3) once in order to reset the microprocessor of the system controller.
(4) Disconnect the short wire between the short point (D2) and Vcc then connect it again.
(5) Adjust the Adjustment part (F) so that the output frequency becomes the specified value (G).
Signal (A1) No signal
Mode (B) EE
Equipment (C) Frequency counter
Measuring point (D1)
(D2)
(D3)
IC3001 pin 61
IC3001 pin 17
C3026 + and -
Adjustment part (F) C3025 (TIMER CLOCK)
Specified value (G1) 1024.008 ±0.001 Hz
(976.5549 ±0.0010 usec)

(No.YD025)1-11
SECTION 5
TROUBLESHOOTING
5.1 JIG Mode
The following remote control units are required to set and cancel JIG mode.
For setting : a remote control unit attached to product.
For cancellation : JIG remote control unit (part number : PTU94023B)
When the main body is set to JIG mode and when the main body is under JIG mode, the remote control unit attached to product op-
erates only in "Remote Control Code 1". Since main body is in "Remote Control Code 3" when it is shipped and just after its batteries
are changed, "Remote Control Code 3" needs to be changed to "Remote Control Code 1."
< Changing Remote Control Code >
(1) If power save mode is turned ON, please tuen OFF.
(2) Switch TV/DVD Switch to "DVD"
(3) Press the numeric button "1" of the remote control unit while pressing the "SET UP" button of the remote control unit. Then,
press the "ENTER" button, and then release the "SET UP" button.
(4) Press the "PLAY" button of the main body for five seconds or longer while the main body is in stand-by mode, and a current
remote control code of the main body is displayed in FL indicator of the main body.
(5) While keeping the state of (3), press the "STOP" button of the remote control unit toward the main body.
(6) The code currently set on the remote blinks on the FL display for approximately 5 seconds, and applied to the unit.
When FL indicator displays "DVD1," it means that the Remote Control Code has been changed to "1."
Custom code
43:A Code
53:B Code
6F:C Code
7F:D Code
Data code
Initial mode
Remote control unit
attached to product JIG remote control unit
3
JIG remote control unit
[Data transmission]
Set the data code,
and then press the
" " button.
DVDTV
DVD
CH
TIMER
REC LINK
PROG/CHECK
G-CODE
SHOW VIEW
NEXTPREVIOUS
PAUSEREC
REC MODE LIVE CHECK
SET UP DISPLAY
ON SCREEN
OPEN/
CLOSE
AUDIO SUBTITLE ANGLE
PROGRESSIVE
SCAN
SLOWSLOW PLAY/SELECT
STOP/
CLEAR
NAVIGATIONTOP MENU
RETURN
ENTER
MENU
TV
STANDBY/ON
TV
MUTING TV/
VIDEO
TVVOLUME
ABC
JKLGHI MNO
TUVPQRS WXYZ
AUXCANCEL
MEMO/MARK
DBS
DEF
DVDTV
DVD
CH
TIMER
REC LINK
PROG/CHECK
G-CODE
SHOW VIEW
NEXTPREVIOUS
PAUSEREC
REC MODE LIVE CHECK
SET UP DISPLAY
ON SCREEN
OPEN/
CLOSE
AUDIO SUBTITLE ANGLE
PROGRESSIVE
SCAN
SLOWSLOW PLAY/SELECT
STOP/
CLEAR
NAVIGATIONTOP MENU
RETURN
ENTER
MENU
TV
STANDBY/ON
TV
MUTING TV/
VIDEO
TV VOLUME
ABC
JKLGHI MNO
TUVPQRS WXYZ
AUXCANCEL
MEMO/MARK
DBS
DEF
STANDBY/ON
S-VIDEO VIDEO
L(MONO)
-
AUDIO
-
R
DV
DV IN
F1
REC MODE
PULL - OPEN
REC
LINK
(1)
(2)b
(2)c
(2)a
(4)
(3)
(3),(5)
"(2) a-c" shows the order of pressing the buttons.
DVD 1

1-12 (No.YD025)
5.1.1 Setting JIG mode
To display SYSTEM INFO or to upgrade firmware, the main body needs to be set to JIG mode.
(1) Turn the main body ON.
(2) Press the buttons of the remote control unit attached to product in the following order : "SET UP" →"2" →"8" →"ENTER"
(3) When a colon ":" between "hour" and "minute" of a clock in FL indicator blink, it means that the main body has been set to JIG
mode properly.
(4) Turn the main body OFF, and then turn it ON again.
*Once the main body is set to JIG mode, the JIG mode cannot be cancelled even if the power cord is pulled out from the wall
socket.
5.1.2 Canceling JIG mode
(1) Transmit "43-9D" to the main body by using JIG remote control unit.
(2) A colon ":" between "hour" and "minute" of a clock in FL indicator light.
(3) Turn the main body OFF, and then turn it ON again.
NOTE:
After repair work, be sure to cancel JIG mode. Before returning product to a user, confirm that a colon ":" between "hour" and
"minute" of a clock in FL indicator light.
Not in JIG mode In JIG mode
[ Example ]
15 : 07 15 07
A colon blinks.
DVDTV
DVD
CH
TIMER
REC LINK
PROG/CHECK
G-CODE
SHOW VIEW
NEXTPREVIOUS
PAUSEREC
REC MODE LIVE CHECK
SET UP DISPLAY
ON SCREEN
OPEN/
CLOSE
AUDIO SUBTITLE ANGLE
PROGRESSIVE
SCAN
SLOWSLOW PLAY/SELECT
STOP/
CLEAR
NAVIGATIONTOP MENU
RETURN
ENTER
MENU
TV
STANDBY/ON
TV
MUTING TV/
VIDEO
TV VOLUME
ABC
JKLGHI MNO
TUVPQRS WXYZ
AUXCANCEL
MEMO/MARK
DBS
DEF
STANDBY/ON
S-VIDEO VIDEO
L(MONO)
-
AUDIO
-
R
DV
DV IN
F1
REC MODE
PULL - OPEN
REC
LINK
(2)b
(2)c
(2)d
(2)a
(3)
(1),(4)
"(2) a-d" shows the order of pressing the buttons.
15:07

(No.YD025)1-13
5.1.3 Displaying SYSTEM INFO
SYSTEM INFO contains information on firmware version of the main body and the mechanism drive, and an initialize execution menu.
(1) Set the main body to JIG mode.
(2) Transmit "43-8B" to the main body by using JIG remote control unit.
(3) SYSTEM INFO menu is displayed in the television screen.
(4) To move cursor in SYSTEM INFO, use the "", "", "", and "" buttons of a remote control unit attached to product.
NOTE :
Items other than the ones described above are not used in service work.
(5) To quit the SYSTEM INFO menu, transmit "43-8B" to the main body by using JIG remote control unit.
(6) Cancel JIG mode.
5.1.4 Updating firmware of the main body
• Firmware update disk supports CD-R media.
(1) Download a compressed file of the latest firmware in "Digital Video Storage" page in JS-NET.
(2) Decompress the file, and a file "fwupdate.bin" is generated.
(3) Write "fwupdate.bin" in CD-R in ISO9660 format.(Don’t use Packet Write software. Write in UDF format.)
(4) Set the main body to JIG mode.
(5) Transmit "43-70" to the main body by using JIG remote control unit.
(6) "UPDATE" appears in FL indicator. Load disk for update on the tray, and close the tray.
(7) Update processing is started automatically.
(8) Then, "FW UPDATE" appears in FL indicator. It takes approx. 6 minutes at maximum to update firmware.
(9) The tray is ejected. Then, take out the disk and close the tray.
(10) Turn the main body OFF, and pull out the power cord from the wall socket. Then, plug the power cord into the wall socket.
(11) "LOADING" of FL indicator disappears. Then, turn the main body ON.
(12) Display the SYSTEM INFO menu, and check the version of the firmware.
(13) Cancel JIG mode.
ATTENTION :
Firmware may sometimes not be updated successfully.
If firmware is not updated successfully, the tray opens, and "ERROR" appears in FL indicator.
If firmware is updated successfully, the tray opens, and "OPEN" appears in FL indicator.
If the power cord is pulled out from the wall socket while "ERROR" appears, data in the flash memory is destroyed and the main
body cannot start: the flash memory needs to be replaced.
After updating procedure, pay enough attention to FL indicator when the tray opens.
When "ERROR" appears, update firmware again in the following way to restore the firmware.
(1) Transmit "43-70" to the main body by using JIG remote control unit while the tray opens.
(2) When "UPDATE" appears in FL indicator, close the tray and make the main body read the disk. Updating starts.
(3) After (2), perform updating procedure (4) - (10) of 5.1.4 Updating firmware of the main body above.
< VERSION >
SYSTEM INFO
VERSION INITIALIZE INFORMATION
CPRM Key Download
C-Ware / A-Ware
JVRI / Host
1394 / OSD
Analog / BE-R / FE-R
Done
PROD106 / 03_47
0092 / V0141AA1
0053E / MTEN04AA
003 / 4 / 4
Version of firmware
This part is updated after the firmware of the
main body is upgraded.
System controller version
/ Region code (Backend) / Region code (Frontend)
ENTER
SELECT
SELECT WITH [CURSORS]
THEN PRESS [ENTER]
SET UP

1-14 (No.YD025)
5.2 The setting method of a region code
A region code should be set after a DVD recorder mechanism unit is replaced.
While a DVD recorder mechanism unit is in a warehouse as a stock, a region code of the drive unit is not determined.
Only replacement of a DVD recorder mechanism unit may cause abnormal playback of Disc.
Set a region code of a DVD recorder mechanism unit in the following procedure.
(1) Replace a DVD recorder mechanism unit.
(2) Turn POWER switch of the unit ON.
(3) Set the main body to JIG mode.
(4) Insert a DVD-RAM disc in the unit to make the unit read the DVD-RAM disc.(The DVD-RAM disk used in this procedure is not a
disk for upgrade. If it is a DVD-RAM disk, it is good anything.)
(5) Send "43-F2" to the unit by using JIG remote control unit.
(6) "REGION 2" is displayed on FL display.
(7) Set the unit to STANDBY.
(8) Turn the POWER switch ON.
(9) To cancel JIG MODE, send "43-9D" to the unit by using JIG remote control unit.
(10) Colon is displayed on a clock on FL display.
(11) Setting is completed in the procedure above.
5.3 Taking out a disc
5.3.1 Method 1
(1) AC Plug is pulled out at once and inserted again.
(2) It is displayed on FL display as "LOADING", and while it blinks, pushing the EJECT button of a main body is continued.
(3) After a while, a tray opens (About 20 seconds).
(4) A disk is removed, the EJECT button of a main body is pushed, and a tray is made to close.
(5) The "LOADING" blink display of FL display disappears and it will be in a standby state.
(6) If the POWER button is pushed, it will usually be operating.
5.3.2 Method 2
When a disk is not able to be taken out by operation of "Method 1", a front door is opened manually, and the EJECT button in the lower
right of a DVD recorder mechanism is pushed directly.
5.3.3 Method 3
A Disc can be taken out manually even when the main body is turned off.
(1) Open the front door.
(2) Pass a thin wire through a hole in the DVD recorder mechanism unit.
(3) The disc tray comes out slightly. Take out the disc tray manually.
5.4 The exchange method of a tray fitting
When DVD recorder mechanism unit is exchanged, please transplant a tray fitting from an old drive, or change for a new tray fitting.
A tray is pulled out manually, as shown in a figure, it carries out, and a tray fitting is removed.
DVD recorder mechanism unit
Front door Hole
Disc tray Direct EJECT button
Tray fitting
Tray DVD recorder mechanism unit

(No.YD025)1-15

(No.YD025)
AV & MULTIMEDIA COMPANY DIGITAL VIDEO STORAGE CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
Victor Company of Japan, Limited
WPC
Printed in Japan

SCHEMATIC DIAGRAMS
DVD VIDEO RECORDER
No.YD025SCH
2004/06
COPYRIGHT 2004 Victor Company of Japan, Limited
DR-M10SAA, DR-M10SAG
DR-M10SAX
CD-ROM No.SML200406
p
DVDTV
DVD
CH
TIMER
REC LINK
PROG/CHECK
G-CODE
SHOW VIEW
NEXTPREVIOUS
PAUSEREC
REC MODE LIVE CHECK
SET UP DISPLAY
ON SCREEN
OPEN/
CLOSE
AUDIO SUBTITLE ANGLE
PROGRESSIVE
SCAN
SLOWSLOW PLAY/SELECT
STOP/
CLEAR
NAVIGATIONTOP MENU
RETURN
ENTER
MENU
TV
STANDBY/ON
TV
MUTING TV/
VIDEO
TV VOLUME
ABC
JKLGHI MNO
TUVPQRS WXYZ
AUXCANCEL
MEMO/MARK
DBS
DEF
Area Suffix
AA ------------------ Australia
AG ----------- Universal Asia
AX -------------- Middle East
Since the whole mechanism assembly unit is replaced, the DVD recorder
mechanism of this unit need not be adjusted.
STANDBY/ON
S-VIDEO VIDEO
L(MONO)
-
AUDIO
-
R
DV
DV IN
F1
REC MODE
PULL - OPEN
REC
LINK
DR-M10SAA, DR-M10SAG, DR-M10SAX [D4R10]


!
CHARTS AND DIAGRAMS
NOTES OF SCHEMATIC DIAGRAM
Safety precautions
The Components indentified by the symbol are
critical for safety. For continued safety, replace safety
critical components only with manufacturer's recom-
mended parts.
1. Units of components on the schematic diagram
Unless otherwise specified.
1) All resistance values are in ohm. 1/6 W, 1/8 W (refer to
parts list).
Chip resistors are 1/16 W.
K: KΩ(1000Ω), M: MΩ(1000KΩ)
2) All capacitance values are in µF, (P: PF).
3) All inductance values are in µH, (m: mH).
4) All diodes are 1SS133, MA165 or 1N4148M (refer to parts
list).
2. Indications of control voltage
AUX : Active at high.
AUX or AUX(L) : Active at low.
3. Interpreting Connector indications
Note: If the voltages are not indicated on the schematic
diagram, refer to the voltage charts.
12 3
2.5
(5.0) 1.8
PB and REC modes
(Voltage of PB and REC modes
are the same)
PB mode
REC mode
4. Voltage measurement
1) Regulator (DC/DC CONV) circuits
REC : Colour bar signal.
PB : Alignment tape (Colour bar).
— : Unmeasurable or unnecessary to measure.
2) Indication on schematic diagram
Voltage indications for REC and PB mode on the sche-
matic diagram are as shown below.
6. Indication of the parts for adjustments
The parts for the adjustments are surrounded with the circle
as shown below.
7. Indication of the parts not mounted on the circuit board
“OPEN” is indicated by the parts not mounted on the circuit
board.
R216
OPEN
1
2
3
1
2
3
1
2
3
1
4
2
3
Removable connector
Wire soldered directly on board
Non-removable Board connector
Board to Board
Connected pattern on board
The arrows indicate signal path
Note: The Parts Number, value and rated voltage etc. in
the Schematic Diagram are for references only.
When replacing the parts, refer to the Parts List.
Note: For the destination of each signal and further line
connections that are cut off from the diagram,
refer to "BOARD INTERCONNECTIONS"
CIRCUIT BOARD NOTES
1. Foil and Component sides
1) Foil side (B side) :
Parts on the foil side seen from foil face (pattern face)
are indicated.
2) Component side (A side) :
Parts on the component side seen from component face
(parts face) indicated.
2. Parts location guides
Parts location are indicated by guide scale on the circuit board.
rts location are indicated by guide scale on the circuit board.
Note: For general information in service manual, please
refer to the Service Manual of GENERAL INFORMA-
TION Edition 4 No. 82054D (January 1994).
LOCATION
REF No.
IC101 B C 6 A
IC Category : IC
Horizontal “A” zone
Vertical “6” zone
B : Foil side
(A : Component side)
C : Chip component
D : Discrete component)
2-1 2-2

A
1
2
3
4
5
BCDEFG
CN6901
CN7101
CN1901
CN3002
CN5102
CN1402
CN7301
CN2101
CN4102
CN4101
CN5305
CN5001
CN5306
CN4104
CN1401
CN7312
CN1202
AUDIO_IN
CH_SW
MOD_B[SW5V]
CONV.CTL[H]
VIDEO_IN
[RF_AGC]
AS
SCL
SDA
MB[SW5V]
TU[30V]
AUDIO_OUT
AFT
VIDEO_OUT
NC[OPEN]
BB[AL5V]
AUDIO_IN
MOD_SDA
MOD_B[AL5V]
MOD_SCL
VIDEO_IN
RF_AGC
AS
SCL
SDA
NC
MB[SW5V]
LOCK[L]
TU[30V]
SW1
SW2
AUDIO_OUT
SIF_OUT
AFT
VIDEO_OUT
JLIP_RX
GND
JLIP_TX
D3.3V
RSTSTA
GND
GND
GND
GND
GND
GND
GND
DASP-
CS3FX
CS1FX
ATA_A2
ATA_A0
PDIAG-
ATA_A1
IOCSI6-
INI_ATA
DMACK
CAB_SEL
IORDY
DIOR
DIOW
DMARQ
KEY
HD_AT[7]
HD_AT[8]
HD_AT[6]
HD_AT[9]
HD_AT[5]
HD_AT[10]
HA_AT[14]
HD_AT[4]
HD_AT[11]
HD_AT[3]
HD_AT[12]
HD_AT[2]
HD_AT[13]
HD_AT[0]
HD_AT[1]
HD_AT[15]
FAN8V
GND
BLU
BRN
GND
GND
D1.8V
D1.8V
D2.5V
D3.3V
RSTSTA
GND
GND
GND
GND
GND
GND
GND
DASP-
CS3FX
CS1FX
ATA_A2
ATA_A0
PDIAG-
ATA_A1
IOCSI6-
INI_ATA
DMACK
CAB_SEL
IORDY
DIOR
DIOW
DMARQ
KEY
HD_AT[7]
HD_AT[8]
HD_AT[6]
HD_AT[9]
HD_AT[5]
HD_AT[10]
HA_AT[14]
HD_AT[4]
HD_AT[11]
HD_AT[3]
HD_AT[12]
HD_AT[2]
HD_AT[13]
HD_AT[0]
HD_AT[1]
HD_AT[15]
Wiring diagram
S/RCA OUT
p10596001a_rev0
2-3 2-4
This manual suits for next models
2
Table of contents
Other JVC DVD Recorder manuals

JVC
JVC CUVD40 - HD Everio SHARE STATION DVD... User manual

JVC
JVC DR-MH50S User manual

JVC
JVC DR-DX5SU User manual

JVC
JVC BD-X200U - Dvd Authoring Recorder User manual

JVC
JVC BD-X201MS Installation instructions

JVC
JVC DR-MH300BE User manual

JVC
JVC HR-XVC24SUC User manual

JVC
JVC BD-X201M User manual

JVC
JVC HD-DH5US User manual

JVC
JVC SR-MV50US Administrator Guide
