JVC DD-8 User manual

EnglishFrançais
NETWORK MEDIA SYSTEM
SYSTÈME MÉDIA RÉSEAU
INSTRUCTIONS
MANUEL D’INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1546-001A
[J]
DD-8
Consists of CA-DD8, SP-PWDD8,
SP-DD8F and SP-DD8S
Se compose de CA-DD8, SP-PWDD8,
SP-DD8F et SP-DD8S
DD-3
Consists of CA-DD3, SP-PWDD3,
SP-DD3F and SP-DD8S
Se compose de CA-DD3, SP-PWDD3,
SP-DD3F et SP-DD8S
DD-83[J]-frontcover.fm Page i Tuesday, October 10, 2006 6:55 PM

G-1
(For U.S.A.)
(For U.S.A.)
(For U.S.A.)
INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Changes or modifications not approved by JVC could void the user’s authority to operate the equipment.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMIS-
SIONS FROM DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT
STANDARD ENTITLED “DIGITAL APPARATUS”, ICES-003 OF THE DEPARTMENT OF COMMUNICA-
TIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICA-
BLES AUX APPAREILS NUMIRIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATE-
RIEL BROUILLEUR: “APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES
COMMUNICATIONS.
Warnings, cautions and others/
Mises en garde, précautions et indications diverses
DD-83[J]-gpage.fm Page 1 Thursday, October 12, 2006 9:01 AM

G-2
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution, d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le coffret de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à l’humidité.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able
to get out.)
• Do not place any naked flame sources, such as lighted candles, on the apparatus.
• When discarding batteries, environmental problems must be considered and local rules or laws gov-
erning the disposal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with liq-
uids, such as vases, shall be placed on the apparatus.
ATTENTION
• Ne bloquez pas les orifices ou les trous de ventilation.
(Si les orifices ou les trous de ventilation sont bloqués par un journal un tissu, etc., la chaleur peut ne
pas être évacuée correctement de l’appareil.)
• Ne placez aucune source de flamme nue, telle qu’une bougie, sur l’appareil.
• Lors de la mise au rebut des piles, veuillez prendre en considération les problèmes de l’environnement
et suivre strictement les règles et les lois locales sur la mise au rebut des piles.
• N’exposez pas cet appareil à la pluie, à l’humidité, à un égouttement ou à des éclaboussures et ne
placez pas des objets remplis de liquide, tels qu’un vase, sur l’appareil.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.
IMPORTANT POUR PRODUITS LASER
1. PRODUIT LASER CLASSE 1
2. ATTENTION: N’ouvrez pas le couvercle supérieur. Il n’y a aucune pièce réparable par l’utilisateur à
l’intérieur de l’appareil; confiez toute réparation à un personnel qualifié.
3. ATTENTION: Rayonnement laser visible et/ou invisible de classe 1M une fois ouvert. Ne pas regarder
directement dans le faisceau avec des instruments optiques.
4. REPRODUCTION DE L’ÉTIQUETTE: ÉTIQUETTE DE PRÉCAUTION PLACÉE À L’INTERIEUR DE
L’APPAREIL.
DD-83[J].book Page 2 Tuesday, October 10, 2006 3:25 PM

G-3
CAUTION: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage, place the apparatus on a level sur-
face. The minimal clearances are shown below:
MISE EN GARDE: Ventilation correcte
Pour éviter les risques d’électrochoc ou d’incendie, et de manière à éviter les dommages, placer l’appar-
eil sur une surface en hauteur. L’espace minimal est indiqué ci-dessous:
Main unit (CA-DD8/CA-DD3)
Unité principale (CA-DD8/CA-DD3)
Front view Side view
Façade Vue latérale
Subwoofer (SP-PWDD8/SP-PWDD3)
Caisson de grave (SP-PWDD8/SP-PWDD3)
Front view Side view
Façade Vue latérale
3 cm
15cm
8 cm
(1 ″)
316
(3 ″)
316
(5 ″)
15 16
3 cm
(1 ″)
316
Wall or obstructions
Mur ou encombrement
10 cm
(3 ″)
15 16
Wall or obstructions
Mur ou encombrement
Front
Façade
No obstructions
Pas d’encombrement
20 cm
15 cm 15 cm
(7 ″)
78
(5 ″)
1516
(5 ″)
1516
15 cm
(5 ″)
1516
Wall or obstructions
Mur ou encombrement
Wall or obstructions
Mur ou encombrement
Front
Façade
No obstructions
Pas d’encombrement
CAUTION — Fbutton! (CA-DD8/CA-DD3)
Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off). When installing
the apparatus, ensure that the plug is easily accessible.
The Fbutton in any position does not disconnect the mains line.
• When the system is on standby, the STANDBY lamp lights red.
• When the system is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
ATTENTION — Touche F! (CA-DD8/CA-DD3)
Déconnectez la fiche secteur pour mettre l’appareil complètement hors tension (le témoin STANDBY l
s’éteint). Lors de l’installation de l’appareil, assurez-vous que la fiche soit facilement accessilble.
La touche F, dans n’importe quelle position, ne déconnecte pas le système du secteur.
• Quand le système est en attente, le témoin STANDBY est allumé en rouge.
• Quand le système est sous tension, le témoin STANDBY s’éteint.
L’alimentation peut être télécommandée.
Warnings, cautions and others (continued)/
Mises en garde, précautions et indications diverses (suite)
DD-83[J]-gpage.fm Page 3 Thursday, October 12, 2006 9:03 AM

G-4
CAUTION (SP-PWDD8/SP-PWDD3)
The power supply to the subwoofer is linked to the center unit.
Disconnect the mains plug to shut the power off completely (the POWER ON lamp goes off).
When installing the apparatus, ensure that the plug is easily accessible.
• When the system is turned on, the POWER ON lamp lights green.
ATTENTION (SP-PWDD8/SP-PWDD3)
L’alimentation du caisson de grave est reliée à l’unité centrale.
Déconnectez la fiche secteur pour mettre l’appareil complètement hors tension (le témoin POWER ON l
s’éteint). Lors de l’installation de l’appareil, assurez-vous que la fiche soit facilement accessible.
• Quand l’appareil est sous tension, le témoin POWER ON est allumé en vert.
CAUTION
To avoid personal injury or accidentally dropping the unit, have two persons unpack, carry, and install the
unit.
ATTENTION
Pour éviter toute blessure personnelle ou toute chute accidentelle de l’appareil, celui-ci doit être déballé,
transporté et installé par deux personnes.
DD-8: 48.5 kg (106.9 lbs)
DD-3: 22.7 kg (51 lbs)
[European Union only]
[Union européenne seulement]
DD-83[J]-gpage.fm Page 4 Monday, November 6, 2006 1:27 PM

English
Introduction
1
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain
the best possible performance from the unit.
Part description .............................3
Using the remote control ..............4
Preparation.....................................5
Connecting the antennas................................5
Connecting the speakers ................................6
Connecting a TV ...........................................11
Connecting a portable digital audio player....14
Connecting other digital audio devices .........15
Connecting other analog audio devices........15
Connecting the power cable .........................15
Basic operations..........................16
Using the number buttons.............................16
Turning on the main unit ...............................16
Adjusting the volume.....................................16
Turning off the sound temporarily .................16
Sharpening the voice sound .........................17
Adjusting the bass/treble sound....................17
Adjusting the volume of the
center surround speaker/subwoofer ........... 17
Adjusting the volume balance between
the left and right speakers ..........................17
Changing the brightness of the display
window........................................................18
Using the sleep timer ....................................18
Auto standby function ...................................19
Locking disc ejection.....................................19
Listening to radio broadcasts ....20
Selecting a radio station................................20
Tuning in to a preset radio station.................21
Basic operations of disc/file
playback .......................................22
Playing back a disc .......................................22
Playing back a file.........................................23
Display window on the main unit for
disc/file types ..............................................24
Stopping playback.........................................27
Resuming playback.......................................27
Pausing playback..........................................27
Advancing the picture frame by frame ..........27
Fast reverse/fast forward search ..................28
Playing back from a position 10 seconds
before..........................................................28
Slow motion playback ...................................28
Skipping to the beginning of a
chapter/track/file .........................................28
Selecting a chapter/track using the number
buttons........................................................29
Skipping at approximately 5 minute
intervals ......................................................29
Selecting a track from the menu screen .......29
Convenient functions of disc/file
playback .......................................30
Selecting the audio language, subtitle
language and view angle............................30
Playing back a disc/file in the desired order
(Program playback) ....................................31
Playing back a disc/file in a random order
(Random playback).....................................32
Magnifying the picture...................................32
Playing back a disc/file repeatedly
(Repeat playback).......................................33
Selecting the surround mode ........................33
Adjusting the picture quality (VFP)................34
Using the status bar and the
menu bar.......................................35
Playing back a specified part repeatedly
(A-B repeat playback) .................................36
Designating the time
(Time search)..............................................36
Changing the initial settings with
the preference screen .................37
Basic operations ...........................................37
LANGUAGE ..................................................37
PICTURE ......................................................38
AUDIO...........................................................39
OTHERS .......................................................39
Language codes ..........................40
Introduction
Preparation
Basic operations
Listening to radio broadcasts
Basic operations of disc/file
playback
Convenient functions of disc/
file playback
Table of contents
DD-83[J].book Page 1 Tuesday, October 10, 2006 3:25 PM

2
English
Introduction
Playing back sources from other
devices..........................................41
Selecting other devices as the source .......... 41
Selecting the signal gain...............................41
QP LINK........................................................ 42
Operating other devices using
the remote control .......................43
Operating a TV using the remote control ...... 43
Operating a VCR/DBS using the
remote control............................................. 44
Using the AV COMPU LINK
function.........................................46
Preparation for the AV COMPU LINK
function ....................................................... 46
Operating the AV COMPU LINK function .....46
Notes on operation ......................47
Suitable locations for the main unit ............... 47
Condensation................................................ 47
Cleaning the main unit ..................................47
License and trademark ................................. 47
Notes on handling ......................................... 48
Notes on discs/files .....................49
Playable disc/file types.................................. 49
Data hierarchy............................................... 52
Handling discs............................................... 52
Troubleshooting ..........................53
Specifications ..............................54
Main unit (CA-DD8/CA-DD3) ........................ 54
Subwoofer for DD-8 (SP-PWDD8)................54
Subwoofer for DD-3 (SP-PWDD3)................55
Left and right speakers for DD-8
(SP-DD8F) .................................................. 55
Left and right speakers for DD-3
(SP-DD3F) .................................................. 55
Center surround speaker (SP-DD8S) ........... 56
Supplied accessories .................................... 56
Playing back sources from
other devices
Operating other devices
using the remote control
Reference
How to read this manual
• This manual explains operations assuming
that you will use the remote control. Some
buttons on the main unit are the same as
those on the remote control. You can use
either button in this case.
• Some diagrams in this manual are simplified
or exaggerated for the purpose of explana-
tion.
• You can operate some functions differently
from the explanation given in this manual.
• Depending on the disc/file, you may not
obtain the explained result even after follow-
ing the operation in this manual.
• The following marks refer to the usable
discs/files for the explained function.
DD-83[J]-01.fm Page 2 Thursday, October 12, 2006 9:04 AM

3
English
Introduction
The numbers refer to the pages in which the parts are explained.
*1 The [PHONES] terminal is for connecting a pair of headphones equipped with a stereo plug (not supplied).
When the headphones are connected, the speakers do not produce any sound. (“HEADPHONE” appears
in the display window.)
During playback, when you connect or disconnect headphones, sound from the [LINE OUT] and [LINE-
DIGITAL OUT] terminals may be intermittent. While recording sound to another device, do not connect or
disconnect headphones.
*2 Refer to the separate volume of the operation manual for the network function.
Refer to “Display window” shown below.
Front view
These terminals are available when
the front cover is open.
Remote control sensor
STANDBY lamp
Rear view
Display window
Part description
DD-83[J].book Page 3 Tuesday, October 10, 2006 3:25 PM

4
English
Introduction
The numbers refer to the pages in which the parts
are explained.
* Refer to the separate volume of the operation
manual for the network function.
• If the effective range of the remote control
decreases, replace both batteries.
■CAUTION
• Do not expose batteries to heat or flame.
Point the remote control directly at the
front of the main unit.
• Do not block the remote control sensor on the
main unit.
• Use the remote control at a position higher than
the main unit.
Inserting the batteries into the
remote control
R6P (SUM-3)/AA (15F) type dry-cell
batteries (supplied)
Operating the system from the
remote control
Using the remote control
DD-83[J].book Page 4 Tuesday, October 10, 2006 3:25 PM

5
English
Preparation
Setting up the AM loop antenna
Connecting the AM loop antenna
Turn the AM loop antenna to find the best position
for radio reception.
NOTE
• Make sure that the antenna conductors do not
touch any other terminals. This could cause poor
reception.
If reception is poor
NOTE
• A coaxial cable is recommended as it reduces
interference for FM reception.
Connecting the antennas
AM loop antenna (supplied)
If insulation covers the tips of the
antenna cable, twist and pull off
the insulation.
Main unit (rear view)
FM antenna (supplied)
Main unit (rear view) FM antenna
Stretch out the FM
antenna horizontally.
Main unit (rear view)
Outdoor FM antenna
cable (not supplied)
75 Ω coaxial connector
(not supplied)
Preparation Do not turn on the power until you complete the connection.
DD-83[J].book Page 5 Tuesday, October 10, 2006 3:25 PM

6
English
Preparation
The speakers for DD-8 must be assembled to the speaker stands before the speakers can be connected to
the subwoofer. Follow the diagrams below.
Left and right speakers
■CAUTION
• The left and right speakers for DD-8 are consid-
erably heavy. Care must be taken in carrying and
handling them. Injury to personnel or damage to
devices may result if the left/right speaker falls.
Mount the speaker body perpendicular to the
speaker stand. Use the supplied M4 x 25-mm (1 ″ )
screws (3) to fasten each speaker to its speaker
stand.
Center surround speaker
■CAUTION
• The center surround speaker for DD-8 can be
installed on a wall.
• Be sure to have the speaker installed on the wall
by qualified personnel.
• DO NOT install the speaker on the wall by your-
self to avoid unexpected damage from it falling
off the wall due to incorrect installation or weak-
ness in wall structure.
• Care must be taken in selecting a location for
speaker installation on a wall. Injury to personnel
or damage to devices may result if the installed
speaker interferes with daily activities.
Connecting the speakers
Assembling the speaker stands (DD-8)
Speaker body Speaker stand
Black line
Left/right speaker cable (supplied)
Remove the screw and the terminal cover. After
connecting the speaker cables, reattach the termi-
nal cover to the speaker body and tighten the screw.
Red
Black
Use the supplied
M5 x 14-mm ( ″ )
screws (2) to fasten
the speaker stand.
58
DD-83[J].book Page 6 Tuesday, October 10, 2006 3:25 PM

7
English
Preparation
Connecting the speakers to the subwoofer (DD-8)
Before connecting the
speaker cables, twist
and pull off the insula-
tion at the end of each
speaker cable.
Subwoofer
(SP-PWDD8)
Black
Rear view
Center surround speaker (SP-DD8S)
The speakers are shown assembled to the speaker
stands on page 6.
The left and right speakers are the same.
Black lines
Black
Gray Black
Blue
Black
Rear view
Gray Blue
LeftRight
The speaker is shown assembled to the speaker
stand on page 6.
NOTE
• When connecting the speaker cable to the termi-
nal on the center surround speaker, make sure
that the end of speaker cable does not touch any
other nearby metallic parts.
Right speaker
(SP-DD8F)
Left speaker
(SP-DD8F)
Center surround
speaker cable
(supplied)
Preparation (continued) Do not turn on the power until you complete the connection.
DD-83[J].book Page 7 Tuesday, October 10, 2006 3:25 PM

8
English
Preparation
The speakers for DD-3 must be assembled to the speaker stands before the speakers can be connected to
the subwoofer. Follow the diagrams below.
Left and right speakers
Center surround speaker
■CAUTION
• The left and right speakers and center surround
speaker for DD-3 can be installed on a wall.
• Be sure to have the speakers installed on the
wall by qualified personnel. Bottom covers (2)
are supplied with DD-3 for installing the left and
right speakers on the wall.
Affixing the bottom covers to the left and
right speakers
Peel off the sheet from the bottom cover, and
then affix the bottom cover to the left/right
speaker.
• DO NOT install the speakers on the wall by your-
self to avoid unexpected damage from them fall-
ing off the wall due to incorrect installation or
weakness in wall structure.
• Care must be taken in selecting a location for
speaker installation on a wall. Injury to personnel
or damage to devices may result if the installed
speakers interfere with daily activities.
Assembling the speaker stands (DD-3)
Black line
Use the supplied M4 x
16-mm ( ″) screws (3) to
fasten each speaker to its
speaker stand.
11 16
Left/right speaker cable
(supplied)
Use the supplied
M5 x 14-mm ( ″)
screws (2) to fasten
the speaker stand.
58
Left/right speaker
(bottom view)
Bottom cover (for
wall installation)
DD-83[J].book Page 8 Tuesday, October 10, 2006 3:25 PM

9
English
Preparation
Connecting the speakers to the subwoofer (DD-3)
Before connecting the
speaker cables, twist
and pull off the insula-
tion at the end of each
speaker cable.
Subwoofer
(SP-PWDD3)
The speakers are shown assembled to the speaker
stands on page 8.
The left and right speakers are the same.
Center surround speaker (SP-DD8S)
Black lines
Black
Gray Black
Blue
Black
Black
Rear view
Gray Blue
Rear view
LeftRight
The speaker is shown assembled to the speaker
stand on page 8.
NOTE
• When connecting the speaker cable to the termi-
nal on the center surround speaker, make sure
that the end of speaker cable does not touch any
other nearby metallic parts.
Right speaker
(SP-DD3F)
Left speaker
(SP-DD3F)
Center surround
speaker cable (supplied)
Preparation (continued) Do not turn on the power until you complete the connection.
DD-83[J].book Page 9 Tuesday, October 10, 2006 3:25 PM

10
English
Preparation
■CAUTION
• An incorrect connection may damage the speak-
ers. Properly connect the cables to the speaker
terminals.
• Do not short-circuit the ªand ·speaker termi-
nals. Doing so may damage the main unit.
• The supplied speakers are manufactured exclu-
sively for use with the supplied main unit as
parts of the DD-8/DD-3 system. Do not connect
the supplied speakers to devices other than the
supplied main unit. Doing so may damage the
speakers.
• Do not connect other speakers together with the
supplied speakers. The change in impedance
may damage the main unit and the speakers.
• Improper speaker cable connection spoils the
stereo effect and sound quality.
• Most of the supplied speakers* are magnetically
shielded, but color irregularity may occur on the
TV depending on some conditions. To prevent
color irregularity, set up the speakers following
the instructions below.
1. Turn off the main power of the TV before
setting up the speakers.
2. Place the speakers enough distance from the
TV so that they do not cause color irregularity
on the TV.
3. Wait for approximately 30 minutes before
turning on the main power of the TV again.
* The subwoofer for DD-3 is not magnetically
shielded. With the exception of this
subwoofer, the supplied speakers are
magnetically shielded.
Connecting the subwoofer to the
main unit
Subwoofer
Rear view
Main unit
Rear view
System cable (supplied)
Align the 5marks on the terminals and the sys-
tem cable.
Peel off the protective
sheets from both sides of
the subwoofer.
Speaker layout
Left speaker
Subwoofer
Center surround speaker
Right speaker
DD-83[J].book Page 10 Tuesday, October 10, 2006 3:25 PM

11
English
Preparation
This system can output uncompressed digital
video signals to a TV compatible with HDMI (High
Definition Multimedia Interface).
Select “HDMI” for the monitor out type. (Refer to
page 13.)
Connecting a TV
Connecting a TV with the [VIDEO]
terminal
TV
To a video terminal
Composite video cable (supplied)
Main unit
(rear view)
Connecting a TV with the [S-VIDEO]
terminal
TV
To an S-video terminal
S-video cable (not supplied)
Main unit
(rear view)
Connecting a TV with the
[COMPONENT VIDEO OUT] terminals
TV
Main unit
(rear view)
To component
terminals
Component video cable (not supplied)
Connecting a TV with the [HDMI]
terminal
Main unit
(rear view)
TV
HDMI cable (not supplied)
To an HDMI terminal
Preparation (continued) Do not turn on the power until you complete the connection.
DD-83[J].book Page 11 Tuesday, October 10, 2006 3:25 PM

12
English
Preparation
NOTE
• This system supports up to HDMI version 1.0.
The HDMI video signal type can be checked with
the “HDMI” indicator in the display window.
(Refer to “Selecting the video signal type” shown
on the right.)
• If the picture is distorted while an HDMI TV is
connected, turn off the main unit and turn it on
again.
• A TV compatible with HDCP (High-Bandwidth
Digital Content Protection) can also be con-
nected to the [HDMI] terminal, so that the
uncompressed HD video signal type can be out-
put as well.
■CAUTION
• Do not connect an S-video cable and a compo-
nent video cable at the same time. Otherwise
the picture may not be played back properly.
• Connect the main unit directly to a TV (or a mon-
itor) without routing through a video cassette
recorder (VCR). Otherwise picture distortion
may occur during playback. (Routing the con-
nection through a VCR, however, does not affect
the audio quality.)
• Connecting the main unit to a VCR-built-in-TV
may also cause picture distortion during play-
back.
To view an image on the TV screen, select the
video signal type correctly according to the TV
after connecting the main unit to the TV.
1Turn on the main unit. (Refer to
“Connecting the power cable” on
page 15 and “Turning on the main
unit” on page 16.)
2Hold down [SCAN MODE] for 2 or
more seconds.
• The current video signal type flashes.
Example:
(Continued on the next page)
Main unit
Direct connection
TV
(or monitor)
VCR
Selecting the video signal type
DD-83[J]-03.fm Page 12 Thursday, October 12, 2006 6:08 PM

13
English
Preparation
3Press 2or 3to select the video
signal type suitable for the TV.
• When the TV is connected to the [VIDEO]
terminal or the [S-VIDEO] terminal, the
video signal type can be selected as
instructed below.
- Select “480I” for a TV only compatible with
interlaced video siginal.
- Select “480P” for a TV equipped with a
component terminal and compatible with
progressive video signal.
• When the TV is connected to the [HDMI] ter-
minal, the video signal type can be selected
as instructed below.
- Select “AUTO” for normal usage (the initial
setting).
- Select “480P” or “720P” as needed.
NOTE
• “480” and “720” refer to the number of the scan-
ning lines. Generally, the larger the number, the
better picture that can be obtained.
• “I” refers to the interlaced format. “P” refers to
the progressive format. A better picture can be
obtained in the progressive format than in the
interlaced format.
• When an HDMI video signal is output, the
“HDMI” indicator lights up in the display window.
• When an HD video signal (720p) is output, the
“HD” indicator lights up.
• When “480P” or “720P” is selected, the “PRO-
GRESSIVE” indicator lights up in the display
window.
4Press [ENTER].
• The selected video signal type is displayed
in the display window for a short time.
NOTE
• The picture may be distorted when you press
[ENTER], but this is not a malfunction of the sys-
tem.
• To check the compatibility of your TV, contact
your local JVC customer service center.
• All JVC-manufactured progressive TVs and
high-definition TVs are fully compatible with this
system.
• Even if the main unit is turned off, the video sig-
nal type setting is stored.
To view an image on the TV, select the monitor out
type as well as the video signal type.
1Press [SETTING].
2Press 5or /to display “M.OUT”.
3Press 2or 3to select “HDMI” or
“NO HDMI”.
• When using an HDMI cable to connect a TV
to the main unit, select “HDMI”.
• When an HDMI cable is not connected,
select “NO HDMI” (the initial setting).
4Press [ENTER] or wait for a short
time.
Selecting the monitor out type
Preparation (continued)
For the locations of the remote
control buttons, refer to page 12.
Do not turn on the power until
you complete the connection.
DD-83[J].book Page 13 Tuesday, October 10, 2006 3:25 PM

14
English
Preparation
NOTE
• Signals input from the [LINE IN 1] and [LINE IN
2] terminals are not output to the [LINE OUT] ter-
minal.
■Selecting the analog output level of the
[LINE OUT] terminal
You can lower the analog output level to prevent
the system from producing unnecessarily loud
sound. Controlling the level may also be helpful for
recording sound from the system to other devices.
1Press [SETTING].
2Press 5or /to select “LINEOUT”
in the display window.
3Press 2or 3to select “L1” or
“L2”.
- “L1” for normal usage (the initial setting)
- “L2” for higher level
Connecting a portable digital
audio player
Listening to analog sound from a
portable digital audio player
Main unit (front view)
Input
Output Portable digital audio player or
other audio device
Audio cable
(not supplied)
To an audio output terminal
Outputting analog sound to a
portable digital audio player
Output
Main unit (front view)
Audio cable
(not supplied)
Input
Portable digital audio player or
other audio device
To an audio input terminal
DD-83[J].book Page 14 Tuesday, October 10, 2006 3:25 PM

15
English
Preparation
■Main unit
■Subwoofer
Connecting other digital
audio devices
AV amplifier with a
built-in decoder
To an optical digital
input terminal
Optical digital cable
(not supplied)
Input Output
Main unit
(rear view)
Optical digital cable
(not supplied)
Input
MD player or satel-
lite receiver
To an optical digital
output terminal
Output
Connecting other analog
audio devices
Connecting the power cable
Output
Audio device
Audio cable
(not supplied)
Input Main unit
(rear view)
Main unit
(rear view)
AC outlet
Subwoofer (rear view) AC outlet
Preparation (continued) Do not turn on the power until you complete the connection.
DD-83[J]-03.fm Page 15 Tuesday, October 10, 2006 6:57 PM
