SERVICE MANUAL

2008/9

COMPACT COMPONENT SYSTEM

MB662<Rev.003>20089SERVICE MANUAL

NX-F3B, NX-F3E, NX-F3EN, NX-F3EV,

NX-F3A, NX-F3EE, NX-F3US, NX-F3UB,

NX-F3UW, NX-F3UX, NX-F3UG, NX-F3UA

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)

TABLE OF CONTENTS

1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-25

CA-NXF3

SP-NXF3W

SP-NXF3F SP-NXF3F

1-2 (No.MB662<Rev.003>)

SPECIFICATION

For Europe

Main unit

Speaker

Tuner

FM frequency 87.50 MHz - 108.00 MHz

AM frequency 522 kHz - 1 629 kHz

Terminal (front of the main unit)

Impedance 16 Ω- 1 kΩ

Terminal (rear of the main unit)

Left/right speakers Output power 200 W (50 W x 4) at 3 Ω(1 kHz/10 % THD)

Impedance 3 Ω- 16 Ω

Subwoofer Output power 150 W at 6 Ω100 Hz/10 % THD)

Impedance 6 Ω- 16 Ω

Optical digital input terminal -23 dBm to -15 dBm

Optical digital output terminal -23 dBm to -15 dBm

Component video output terminals Y: 1.0 Vp-p, 75 Ωterminated

PB: 0.7 Vp-p, 75 Ωterminated

PR: 0.7 Vp-p, 75 Ωterminated

Composite video output terminal 1.0 Vp-p, 75 Ωterminated

Audio input terminals 500 mV/47 kΩ

USB(Compatible with USB 2.0 Full-Speed)

Compatible device USB mass storage class device

Compatible file system FAT16, FAT32

Output power DC 5 V = 500 mA

HDMI

Output power DC 5 V = 55 mA

General

Power source AC 230 V~50 Hz

Power consumption (in operation) 90 W

Power consumption (on standby) 0.8 W

Dimensions (W x H x D) [including projecting parts]

300 mm x 95 mm x 295 mm

Mass 3.4 kg

Type 1-way bass reflex type Magnetically shielded type

Speaker driver Front ch 5.5 cm cone

Surround ch 5.5 cm cone

Power handling capacity Front ch 50W

Surround ch 50W

Impedance 3 Ω

Frequency range 80 Hz - 20 kHz

Sound pressure level 77 dB/W•m

Dimensions (W x H x D)[including projection parts]

88 m x 184 mm x 125 mm

Mass (1 speaker) 1.2 kg

(No.MB662<Rev.003>)1-3

Subwoofer

Designs and specifications are subject to change without notice.

NX-F3A/UB

Main unit

Type Bass reflex type

Speaker driver 16 cm cone

Power handling capacity 150 W

Impedance 6 Ω

Frequency range 30 Hz - 200 Hz

Sound pressure level 76 dB/W•m

Dimensions (W x H x D) 300 mm x 301 mm x 305 mm

Mass 8.2 kg

Tuner

FM frequency 87.50 MHz - 108.00 MHz

AM frequency 531 kHz - 1 710 kHz (9 kHz spacing)

530 kHz - 1 710 kHz (10 kHz spacing)

Terminal (front of the main unit)

USB digital input terminal x 1

Audio output headphone terminal x 1

Impedance 16 Ω- 1 kΩ

Terminal (rear of the main unit)

Audio

output speaker

terminals x 1

Left/Right speakers Output power 200 W (50 W x 4) at 3 Ω(1 kHz/10 % THD)

Impedance 3 Ω- 16 Ω

Subwoofer Output power 150 W at 6 Ω(100 Hz/10 % THD)

Impedance 6 Ω- 16 Ω

Optical digital input terminal x 1 -23 dBm to -15 dBm

Optical digital output terminal x 1 -23 dBm to -15 dBm

Component video output terminals x 1 Y 1.0 Vp-p, 75 Ωterminated

PB 0.7 Vp-p, 75 Ωterminated

PR 0.7 Vp-p, 75 Ωterminated

Composite video output terminal x 1 1.0 Vp-p, 75 Ωterminated

Audio input terminals x 1 500 mV/47 kΩ

HDMI monitor output terminal x 1

FM antenna terminal x 1

AM antenna terminal x 1

General

Power source (Australia) AC 240 V~, 50 Hz

Power source (Hong Kong) AC 220 V~, 50 Hz

Power consumption (in operation) 90 W

Power consumption (on standby) 0.8 W

Dimensions (W x H x D) [including projecting parts] 300 mm x 95 mm x 295 mm

Mass 3.4 kg

1-4 (No.MB662<Rev.003>)

Speaker (SP-NXF3F)

Subwoofer (SP-NXF3W)

Designs and specifications are subject to change without notice.

For asia

Main unit

USB(Compatible with USB 2.0 Full-Speed)

Compatible device USB mass storage class device

Compatible file system FAT16, FAT32

Output power DC 5 V=500 mA

HDMI

Output power DC 5 V=55 mA

Type 1-way bass reflex type Magnetically shielded type

Speaker driver Front ch 5.5 cm cone

Surround ch 5.5 cm cone

Power handling capacity Front ch 50W

Surround ch 50W

Impedance 3 Ω

Frequency range 80 Hz - 20 kHz

Sound pressure level 77 dB/W•m

Dimensions (W x H x D) [including projection parts] 88 mm x 184 mm x 125 mm

Mass (1 speaker) 1.2 kg

Type Bass reflex type

Speaker driver 16 cm cone

Power handling capacity 150 W

Impedance 6 Ω

Frequency range 30 Hz - 200 Hz

Sound pressure level 76 dB/W•m

Dimensions (W x H x D) 300 mm x 301 mm x 305 mm

Mass 8.2 kg

Tuner

FM frequency 87.50 MHz - 108.00 MHz

AM frequency (Middle Eastern countries and South Africa) 531 kHz - 1 602 kHz (9 kHz spacing)

530 kHz - 1 600 kHz (10 kHz spacing)

AM frequency (other countries/areas) 531 kHz - 1 710 kHz (9 kHz spacing)

530 kHz - 1 710 kHz (10 kHz spacing)

Terminal (front of the main unit)

Microphone input terminal x 2 3.0 mV/12 kΩ

USB digital input terminal x 1

Audio output headphone terminal x 1 Impedance 16 Ω- 1 kΩ

Terminal (rear of the main unit)

Audio output speaker

terminals x 1

Left/Right speakers Output power 200 W (50 W x 4) at 3 Ω(1 kHz/10 % THD)

Impedance 3 Ω- 16 Ω

Subwoofer Output power 150 W at 6 Ω(100 Hz/10 % THD)

Impedance 6 Ω- 16 Ω

Optical digital input terminal x 1 -23 dBm to -15 dBm

Optical digital output terminal x 1 -23 dBm to -15 dBm

(No.MB662<Rev.003>)1-5

Speaker (SP-NXF3F)

Subwoofer (SP-NXF3W)

Designs and specifications are subject to change without notice.

Component video output terminals x 1 Y 1.0 Vp-p, 75 Ωterminated

PB 0.7 Vp-p, 75 Ωterminated

PR 0.7 Vp-p, 75 Ωterminated

Composite video output terminal x 1 1.0 Vp-p, 75 Ωterminated

Audio input terminals x 1 500 mV/47 kΩ

HDMI monitor output terminal x 1

FM antenna terminal x 1

AM antenna terminal x 1

General

Power source (Thailand) AC 220 V~, 50 Hz

Power source (other countries/areas) AC 110 - 127/220 -240 V~,50/60 Hz

Power consumption (in operation) 90 W

Power consumption (on standby) 0.8 W

Dimensions (W x H x D) [including projecting parts] 300 mm x 95 mm x 295 mm

Mass 3.4 kg

USB (Compatible with USB 2.0 Full-Speed)

Compatible device USB mass storage class device

Compatible file system FAT16, FAT32

Output power DC 5 V=500 mA

HDMI

Output power DC 5 V=55 mA

Type 1-way bass reflex type Magnetically shielded type

Speaker driver Front ch 5.5 cm cone

Surround ch 5.5 cm cone

Power handling capacity Front ch 50W

Surround ch 50W

Impedance 3 Ω

Frequency range 80 Hz - 20 kHz

Sound pressure level 77 dB/W•m

Dimensions (W x H x D) [including projection parts] 88 mm x 184 mm x 125 mm

Mass (1 speaker) 1.2 kg

Type Bass reflex type

Speaker driver 16 cm cone

Power handling capacity 150 W

Impedance 6 Ω

Frequency range 30 Hz - 200 Hz

Sound pressure level 76 dB/W•m

Dimensions (W x H x D) 300 mm x 301 mm x 305 mm

Mass 8.2 kg

1-6 (No.MB662<Rev.003>)

SECTION 1

PRECAUTION

1.1 Safety Precautions

(1) This design of this product contains special hardware and

many circuits and components specially for safety purpos-

es. For continued protection, no changes should be made

to the original design unless authorized in writing by the

manufacturer. Replacement parts must be identical to

those used in the original circuits. Services should be per-

formed by qualified personnel only.

(2) Alterations of the design or circuitry of the product should

not be made. Any design alterations of the product should

not be made. Any design alterations or additions will void

the manufacturers warranty and will further relieve the

manufacture of responsibility for personal injury or property

damage resulting therefrom.

(3) Many electrical and mechanical parts in the products have

special safety-related characteristics. These characteris-

tics are often not evident from visual inspection nor can the

protection afforded by them necessarily be obtained by us-

ing replacement components rated for higher voltage, watt-

age, etc. Replacement parts which have these special

safety characteristics are identified in the Parts List of Ser-

vice Manual. Electrical components having such features

are identified by shading on the schematics and by ( ) on

the Parts List in the Service Manual. The use of a substitute

replacement which does not have the same safety charac-

teristics as the recommended replacement parts shown in

the Parts List of Service Manual may create shock, fire, or

other hazards.

(4) The leads in the products are routed and dressed with ties,

clamps, tubings, barriers and the like to be separated from

live parts, high temperature parts, moving parts and/or

sharp edges for the prevention of electric shock and fire

hazard. When service is required, the original lead routing

and dress should be observed, and it should be confirmed

that they have been returned to normal, after reassem-

bling.

(5) Leakage shock hazard testing

After reassembling the product, always perform an isola-

tion check on the exposed metal parts of the product (an-

tenna terminals, knobs, metal cabinet, screw heads,

headphone jack, control shafts, etc.) to be sure the product

is safe to operate without danger of electrical shock.Do not

use a line isolation transformer during this check.

• Plug the AC line cord directly into the AC outlet. Using a

"Leakage Current Tester", measure the leakage current

from each exposed metal parts of the cabinet, particular-

ly any exposed metal part having a return path to the

chassis, to a known good earth ground. Any leakage cur-

rent must not exceed 0.5mA AC (r.m.s.).

• Alternate check method

Plug the AC line cord directly into the AC outlet. Use an

AC voltmeter having, 1,000Ωper volt or more sensitivity

in the following manner. Connect a 1,500Ω10W resistor

paralleled by a 0.15µF AC-type capacitor between an ex-

posed metal part and a known good earth ground.

Measure the AC voltage across the resistor with the AC

voltmeter.

Move the resistor connection to each exposed metal

part, particularly any exposed metal part having a return

path to the chassis, and measure the AC voltage across

the resistor. Now, reverse the plug in the AC outlet and

repeat each measurement. Voltage measured any must

not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5

mA AC (r.m.s.).

1.2 Warning

(1) This equipment has been designed and manufactured to

meet international safety standards.

(2) It is the legal responsibility of the repairer to ensure that

these safety standards are maintained.

(3) Repairs must be made in accordance with the relevant

safety standards.

(4) It is essential that safety critical components are replaced

by approved parts.

(5) If mains voltage selector is provided, check setting for local

voltage.

1.3 Caution

Burrs formed during molding may be left over on some parts

of the chassis.

Therefore, pay attention to such burrs in the case of pre-

forming repair of this system.

1.4 Critical parts for safety

In regard with component parts appearing on the silk-screen

printed side (parts side) of the PWB diagrams, the parts that are

printed over with black such as the resistor ( ), diode ( )

and ICP ( ) or identified by the " " mark nearby are critical

for safety. When replacing them, be sure to use the parts of the

same type and rating as specified by the manufacturer.

(This regulation dose not Except the J and C version)

Good earth ground

Place this

probe on

each exposed

metal part.

AC VOLTMETER

(Having 1000

ohms/volts,

or more sensitivity)

1500 10W

0.15 F AC TYPE

(No.MB662<Rev.003>)1-7

1.5 Preventing static electricity

Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser

diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.

1.5.1 Grounding to prevent damage by static electricity

Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.

Be careful to use proper grounding in the area where repairs are being performed.

(1) Ground the workbench

Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the

traverse unit (optical pickup) on it.

(2) Ground yourself

Use an anti-static wrist strap to release any static electricity built up in your body.

(3) Handling the optical pickup

• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical

pickup are shorted. After replacement, return the shorted parts to their original condition.

(Refer to the text.)

• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily

destroy the laser diode.

1.6 Handling the traverse unit (optical pickup)

(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.

(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the

replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a

time when attaching it to the connector.

(3) Handle the flexible cable carefully as it may break when subjected to strong force.

(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.

1.7 Attention when traverse unit is decomposed

*Please refer to "Disassembly method" in the text for the pickup unit.

• Apply solder to the short land sections before the card wire is disconnected from the connecto on the servo board. (If the card wire

is disconnected without applying solder, the pickup may be destroyed by static electricity.)

• In the assembly, be sure to remove solder from the short land sections after connecting the card wire.

Conductive material

(conductive sheet) or iron palate

(caption)

Anti-static wrist strap

Solder short land section

1-8 (No.MB662<Rev.003>)

1.8 Important for laser products

1.CLASS 1 LASER PRODUCT

2.CAUTION :

(For U.S.A.) Visible and/or invisible class II laser radiation

when open. Do not stare into beam.

(Others) Visible and/or invisible class 1M laser radiation

when open. Do not view directly with optical instruments.

3.CAUTION : Visible and/or invisible laser radiation when

open and inter lock failed or defeated. Avoid direct

exposure to beam.

4.CAUTION : This laser product uses visible and/or invisible

laser radiation and is equipped with safety switches which

prevent emission of radiation when the drawer is open and

the safety interlocks have failed or are defeated. It is

dangerous to defeat the safety switches.

5.CAUTION : If safety switches malfunction, the laser is able

to function.

6.CAUTION : Use of controls, adjustments or performance of

procedures other than those specified here in may result in

hazardous radiation exposure.

REPRODUCTION AND POSITION OF LABELS and PRINT

!Please use enough caution not to

see the beam directly or touch it

in case of an adjustment or operation

check.

WARNING LABEL and PRINT

(No.MB662<Rev.003>)1-9

SECTION 2

SPECIFIC SERVICE INSTRUCTIONS

This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

1-10 (No.MB662<Rev.003>)

SECTION 3

DISASSEMBLY

3.1 Main body (Used figure are NX-F3E)

3.1.1 Removing the Top panel (L) (See Fig.1)

(1) Remove the four screws Aattaching the Top panel (L).

(2) Slide to backward and then lift up side of the Top panel (L).

Fig.1

3.1.2 Removing the Top panel (R) (See Fig.2 to 6)

(1) Remove the Volume knob and Volume sheet.

(2) Remove the two screws Battaching the Volume ornament.

(See Fig.2)

(3) Remove the two screws Cattaching the Side panel. (See

Fig.3)

(4) Slide to backward and then remove the Side panel. (See

Fig.4)

(5) Disengage one hook aand one hook bengaged Top panel

(R). (See Fig.5. 6)

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

hook a

hook b

(No.MB662<Rev.003>)1-11

3.1.3 Removing the Front panel (See Fig.7 to 9)

(1) Remove the two screws Dattaching the Foot. (See Fig.7)

(2) Remove the three screws Eattaching the Front panel. (See

Fig.7)

(3) Remove the three screws F attaching the Front panel. (See

Fig.8)

(4) Disconnect the card wire from Micon board connected to

connector CN561 of the Front board. (See Fig.8)

(5) Disengage one hook cof the bottom side of Front panel

and two hooks dengaged both side of Front panel. (See

Fig.7, 9) Fig.7

Fig.8

Fig.9

Dhook cD

CN561

hook d

1-12 (No.MB662<Rev.003>)

3.1.4 Removing the Top chassis (See Fig.10 to 13)

(1) Remove the six screws Gattaching the Rear panel. (See

Fig.10)

(2) Remove the two screws H attaching the right side of Top

chassis. (See Fig.11)

(3) Remove the one screw Jand one screw Kattaching the left

side of Top chassis. (See Fig.12)

CAUTION:When remove the screw K, use screw driver is next.

TORX Driver: size T10

Parts number: DR-L70

(4) Slide to frontward, and then turnover the Top chassis.

(5) Disconnect the card wires from Micon board connected to

connectors CN101 and CN102 of the Amp board. (See

Fig.13)

(6) Disconnect the connector wire from Power board connect-

ed to connector CN103 of the Amp board. (See Fig.13)

Fig.10

Fig.11

Fig.12

Fig.13

CN101 CN102 CN103

(No.MB662<Rev.003>)1-13

3.1.5 Removing the Micon board (See Fig.14 to15)

(1) Disconnect the connector wire from Fan connected to con-

nector CN461 of the Micon board. (See Fig.14)

(2) Disconnect the card wire from SCART board connected to

connector CN601 of the Micon board. (See Fig.14)

(3) Disconnect the card wires from Front end board connected

to connectors CN701, CN481 and CN661 of the Micon

board. (See Fig.14)

(4) Disconnect the connector wire from Front end board con-

nected to connector CN702 of the Micon board. (See

Fig.14)

(5) Disconnect the card wire from Tuner pack connected to

connector CN421 of the Micon board. (See Fig.14)

(6) Disconnect the card wire from Loader board connected to

connector CN451 of the Micon board (See Fig.14)

(7) Disconnect the connector wire from power board connect-

ed to connector CN981 of the Micon board. (See Fig.14)

(8) Disconnect the card wire from USB jack board connected

to connector CN203 of the Micon board. (See Fig.14)

(9) Remove the four screws Lattaching the Micon board. (See

Fig.15)

Fig.14

Fig.15

3.1.6 Removing the USB jack board (See Fig.16)

(1) Disconnect the connector wire from Front end board con-

nected to connector CN301 of the USB jack board.

(2) Remove the one screw Mattaching the USB jack board.

(3) Lift up the right side, and then slide to leftward and remove

the USB jack board.

Fig.16

CN461

CN601

CN702

CN421

CN701

CN203 CN481

CN981

CN661

CN451

CN301

1-14 (No.MB662<Rev.003>)

3.1.7 Removing the SCART board (See Fig.17)

(1) Remove the two screws Nattaching the SCART board.

Fig.17

3.1.8 Removing the DVD mechanism (See Fig.18, 19)

(1) Remove the one screw Pattaching the HDMI jack. (See

Fig.18)

(2) Remove the two screws Qattaching the Front end board.

(See Fig.19)

(3) Remove the one screw Rattaching the DVD mechanism.

(See Fig.19)

Fig.18

Fig.19

(No.MB662<Rev.003>)1-15

3.1.9 Removing the Rear panel (See Fig.20)

(1) Remove the two screws Sattaching the Rear panel.

Fig.20

3.1.10 Removing the Power board (See Fig.21)

(1) Disconnect the power cord connected to connector CN1 of

the Power board.

(2) Remove the five screws Tattaching the Power board.

Fig.21

3.1.11 Removing the Amp board (See Fig.22)

(1) Remove the two screws Uattaching the Barrier.

(2) Remove the three screws Vattaching the Heat sink.

(3) Remove the two screws Wattaching the Amp board.

Fig.22

3.1.12 Removing the Front board (See Fig.23)

(1) Remove the eight screws Xattaching the Front board.

Fig.23

CN1

1-16 (No.MB662<Rev.003>)

3.2 DVD mechanism

3.2.1 Removing the traverse mechanism

(See Fig.1 to 4)

(1) Remove the one screw Aattaching the Front end board.

(See Fig.1)

(2) Remove the two screws Battaching the tramecha holder

from top side of DVD mechanism assembly. (See Fig.2)

(3) Remove the four screws Cattaching the traverse mecha-

nism. (See Fig.3)

(4) Solder the solder part of DVD pick up. (See Fig.4)

(5) Disconnect the card wire from CN101 and CN201 on the

DVD module board. (See Fig. 1)

Caution:

• Solder the short land section on the DVD pickup before dis-

connecting the card wire from the connector on the DVD

pickup. If the card wire is disconnected without attaching sol-

ders, the pickup may be destroyed by static electricity.

• When attaching the DVD pickup, be sure to remove solders

from the short land section after connecting the card wire to

the connector on the DVD pickup.

Fig.1

Fig.2

Fig.3

Fig.4

CN101 CN201

Clamper base

DVD mechanism assembly

Traverse mechanism assembly

DVD mechanism assembly

Solder short land section

(No.MB662<Rev.003>)1-17

3.2.2 Removing the pickup assembly

(See Fig.5 to 9)

(1) Remove the two rod springs pressing the guide shaft. (See

Fig.5)

(2) Remove the screw Dand Eattaching the spring holder.

(See Fig.6)

(3) Remove the read screw from traverse mechanism assem-

bly. (See Fig.7)

Caution:

When remove the lead screw, do not loss the middle

gear. (See Fig.8 and 9)

(4) Remove the bar spring pressing the shaft. (See Fig.8)

(5) Take out the pickup assembly from traverse mechanism

chassis by order. (See Fig.9)

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

ROD SPRING ROD SPRING

Spring holder

Lead screw

Middle gear

(T.TABLE)

HOOK

(SHAFT)

(BAR SPRING)

order 1

order 2

order 3

1-18 (No.MB662<Rev.003>)

3.2.3 Removing the feed motor assembly

(See Fig.10)

(1) Remove the one screw Fattaching the feed motor assem-

bly.

(2) Remove the feed motor wires from solder part of spindle

motor board.

Fig.10

3.2.4 Removing the spindle motor assembly

(See Fig.11)

(1) Remove the three screws Gattaching the spindle motor

from spindle motor board.

Fig.11

Lead screw

Middle gear

Solder part

Spindle motor

(No.MB662<Rev.003>)1-19

3.2.5 Removing the tray assembly

(See Fig.12 & 13)

(1) Remove the two screws Hattaching the clamper base.

(See Fig.12)

(2) Remove the one screw Jattaching the shaft guide from

bottom side. (See Fig.12)

(3) Remove the two screws Kattaching the shaft guide from

top side. (See Fig.13)

Caution:

When attach the tray assembly, boss of loading sub assembly

should attach to guide of bottom side at tray assembly. (See

Fig.13)

Fig.12

Fig.13

order 1

order 2

clamper base

[bottom side]

1-20 (No.MB662<Rev.003>)

SECTION 4

ADJUSTMENT

4.1 ATTENTION IN SERVICE OF DVD SECTION

(1) When pickup, Flash ROM ,DVD module board were changed, initialize EEPROM by all means.

(2) When full initialization was executed, execute learning with a DVD test disc by all means.

Test disc : VT-501, VT-502

Learning method : It is adjusted automatically by normal playback of a DVD disc.

4.2 DVD TEST MODE

4.2.1 Content of correspondence TEST MODE

(1) Version, Region, Learning status check mode

(2) NORMAL initialize, FULL initialize

(3) Device key write(CPPM, CPRM)

(4) Device key checksum indication mode

(5) Micon version indication mode

(6) FL all on mode

(7) FRONT END check mode

4.2.2 Mode transition

TEST MODE into the press [OPEN/CLOSE key] and [PLAY key] together of main body, connect the AC power.

After into the TEST MODE, mode select by [MENU key].

4.2.3 Processing details

The communication of operated FL(LCD) display and DVD back end microcomputer is shown as follows.

*It is assumed to be OK to differ from the content of the specification because the number of digits is different according to the set for the FL(LCD) display.

It is assumed to be OK to differ from the content of the specification because it also has the relation between arrangement and presence by the set also for the key.

Version, Region, Learning

status indication mode

Micon version

indication mode

FRONT END

check mode

FL all on

mode

Device key

checksum

mode

NORMAL
