JVC LT-26DE1BJ/AX User manual

SERVICE MANUAL
COPYRIGHT © 2009 Victor Company of Japan, Limited No.YA695<Rev.001>
2009/5
INTEGRATED DIGITAL TERRESTRIAL LCD TELEVISION
YA695<Rev.001>20095SERVICE MANUAL
LT-26DE1BJ/AX, LT-26DE1BU/AX
COPYRIGHT © 2009 Victor Company of Japan, Limited
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14

1-2 (No.YA695<Rev.001>)
SPECIFICATION
Design & specifications are subject to change without notice.
Items Contents
LT-26DE1BJ LT-26DE1BU
Dimensions ( W ×H ×D ) 66.0 cm ×48.83 cm ×27.86 cm [66.0 cm ×44.0 cm ×9.0 cm (Without stand)]
Mass 9.2 kg [8.2 kg (Without stand)]
Power Input AC220V - AC240 V, 50 Hz
Power Consumption 105 W (Standby: 0.9 W)
TV RF System Analog CCIR (B/G, I, D/K, L)
Digital DVB-T
Colour System PAL, SECAM, NTSC 3.58/4.43 [EXT only]
Stereo System NICAM (B/G, I, D/K, L), A2 (B/G, D/K)
Receiving
Frequency
Analog VHF: 45.25 MHz - 470MHz
UHF: 470 MHz - 855.25 MHz
CATV: 116MHz - 172MHz / 220MHz - 469MHz
Digital UHF:474 MHz - 858 MHz
Intermediate
Frequency
VIF 38.9MHz (B/G, I, D/K, L)
SIF 33.4MHz (5.5MHz:B/G)
32.9MHz (6.0MHz:I)
32.4MHz (6.5MHz:D/K)
Colour Sub
Carrier
Frequency
PAL 4.43MHz
SECAM 4.40625MHz / 4.25MHz
NTSC 3.58MHz / 4.43MHz
Teletext
System
Analog FLOF (Fastext), TOP
Digital MHEG 5 UK profile EBU TEXT
LCD panel 26-inch wide aspect (16 : 9)
Screen Size Diagonal : 66.0 cm (H: 57.8 cm ×V: 32.6 cm)
Display Pixels Horizontal : 1366 dots ×Vertical : 768 dots
Audio Power Output 5 W + 5 W
Speaker 3.5 cm ×11.5 cm, oval type ×2
Aerial terminal (VHF/UHF) 75 Ωunbalanced, coaxial ×1
EXT-1 / EXT-2 (Input/Output) 21-pin Euro connector (SCART socket ) ×2
EXT-3
(Input)
Component Video
750p / 1125i
625p / 525p / 625i / 525i
RCA pin jack ×3
Y: 1 V (p-p) (Sync signal: ±0.35V(p-p), 3-value sync.), 75Ω/ Pb/Pr: ±0.35V(p-p), 75 Ω
Y: 1 V (p-p), Positive (Negative sync.), 75 Ω/ Cb/Cr: 0.7V(p-p), 75 Ω
Audio 500 mV(rms) (-4dBs), high impedance, RCA pin jack ×2
EXT-4
(Input)
S-Video Mini-DIN 4 pin ×1
Y: 1 V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286 V (p-p) (Burst signal), 75 Ω
Video 1V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack ×1
Audio 500 mV (rms), High impedance, RCA pin jack ×2
EXT-5 / EXT-6
(Digital Input)
Video / Audio HDMI 2-row 19pin connector ×2
(Digital-input terminal is not compatible with picture signals of personal computer)
• 576i(625i),576p(625p),480i(525i),480p(525p),720p(750p),1080i(1125i) signals are avail-
able.
• All HDMI inputs support DVI video but only first HDMI input (EXT-5) supports DVI audio
through component audio input (EXT-2 or EXT-3).
Digital Audio Optical Output Digital SPDIF ×1
Headphone 3.5 mm stereo mini jack ×1
HDD 160GB
Remote Control Unit RM-C2111B (AA/R06 dry cell battery ×2)

(No.YA695<Rev.001>)1-3
SECTION 1
PRECAUTION
1.1 SAFETY PRECAUTIONS
(1) The design of this product contains special hardware,
many circuits and components specially for safety
purposes. For continued protection, no changes should be
made to the original design unless authorized in writing by
the manufacturer. Replacement parts must be identical to
those used in the original circuits. Service should be
performed by qualified personnel only.
(2) Alterations of the design or circuitry of the products should
not be made. Any design alterations or additions will void
the manufacturer's warranty and will further relieve the
manufacturer of responsibility for personal injury or
property damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These
characteristics are often not evident from visual inspection
nor can the protection afforded by them necessarily be
obtained by using replacement components rated for
higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in
the parts list of Service manual. Electrical components
having such features are identified by shading on the
schematics and by ( ) on the parts list in Service
manual. The use of a substitute replacement which does
not have the same safety characteristics as the
recommended replacement part shown in the parts list of
Service manual may cause shock, fire, or other hazards.
(4) Don't short between the LIVE side ground and
ISOLATED (NEUTRAL) side ground or EARTH side
ground when repairing.
Some model's power circuit is partly different in the GND.
The difference of the GND is shown by the LIVE : ( ) side
GND, the ISOLATED (NEUTRAL) : ( ) side GND and
EARTH : ( ) side GND.
Don't short between the LIVE side GND and ISOLATED
(NEUTRAL) side GND or EARTH side GND and never
measure the LIVE side GND and ISOLATED (NEUTRAL)
side GND or EARTH side GND at the same time with a
measuring apparatus (oscilloscope etc.). If above note will
not be kept, a fuse or any parts will be broken.
(5) When service is required, observe the original lead dress.
Extra precaution should be given to assure correct lead
dress in the high voltage circuit area. Where a short circuit
has occurred, those components that indicate evidence of
overheating should be replaced. Always use the
manufacturer's replacement components.
(6) Isolation Check (Safety for Electrical Shock Hazard)
After re-assembling the product, always perform an isola-
tion check on the exposed metal parts of the cabinet (an-
tenna terminals, video/audio input and output terminals,
Control knobs, metal cabinet, screw heads, earphone jack,
control shafts, etc.) to be sure the product is safe to operate
without danger of electrical shock.
a) Dielectric Strength Test
The isolation between the AC primary circuit and all metal
parts exposed to the user, particularly any exposed metal
part having a return path to the chassis should withstand a
voltage of 3000V AC (r.m.s.) for a period of one second. (.
. . . Withstand a voltage of 1100V AC (r.m.s.) to an appli-
ance rated up to 120V, and 3000V AC (r.m.s.) to an appli-
ance rated 200V or more, for a period of one second.)
This method of test requires a test equipment not generally
found in the service trade.
b) Leakage Current Check
Plug the AC line cord directly into the AC outlet (do not use
a line isolation transformer during this check.). Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal part of the cabinet, particularly
any exposed metal part having a return path to the chassis,
to a known good earth ground (water pipe, etc.). Any leak-
age current must not exceed 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.2mA AC
(r.m.s.).
Alternate Check Method
Plug the AC line cord directly into the AC outlet (do not
use a line isolation transformer during this check.). Use
an AC voltmeter having 1000Ωper volt or more
sensitivity in the following manner. Connect a 1500Ω
10W resistor paralleled by a 0.15µF AC-type capacitor
between an exposed metal part and a known good earth
ground (water pipe, etc.). Measure the AC voltage
across the resistor with the AC voltmeter. Move the
resistor connection to each exposed metal part,
particularly any exposed metal part having a return path
to the chassis, and measure the AC voltage across the
resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Any voltage measured must
not exceed 0.75V AC (r.m.s.). This corresponds to
0.7mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.35V
AC (r.m.s.). This corresponds to 0.3mA AC (r.m.s.).
AC VOLTMETER
(HAVING 1000 /V,
OR MORE SENSITIVITY)
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
1500 10W
0.15 F AC-TYPE
GOOD EARTH GROUND

1-4 (No.YA695<Rev.001>)
1.2 INSTALLATION
1.2.1 ATTACH THE STAND TO THE TV
When installing the unit on the floor, it is required to attach the
supplied stand.
To attach the stand to the TV, follow the procedure below.
To prevent scratches on the panel, lay a piece of soft cloth on an
even platform and place the TV onto it.
1.2.2 HEAT DISSIPATION
If the heat dissipation vent behind this unit is blocked, cooling
efficiency may deteriorate and temperature inside the unit will
rise. The temperature sensor that protects the unit will be
activated when internal temperature exceeds the pre-determined
level and power will be turned off automatically.Therefore,
please make sure pay attention not to block the heat dissipation
vent as well as the ventilation outlet behind the unit and ensure
that there is room for ventilation around it.
1.2.3 NOTES ON HANDLING
When taking the unit out of a packing case, do not grasp the
upper part of the unit. If you take the unit out while grasping the
upper part, the LCD PANEL may be damaged because of a
pressure. Instead of grasping the upper part, put your hands on
the lower backside or sides of the unit.
1.2.4 INSTALLATION REQUIREMENTS
Ensure that the minimal distance is maintained, as specified
below, between the unit with and the surrounding walls, as well
as the floor etc.Install the unit on stable flooring or stands.
To ensure safety in an emergency such as an earthquake, and
to prevent accidents, ensure that measures are taken to prevent
the TV dropping or falling over.
*Diagram differs from actual appearance.
Ventilation hole
*Diagram differs from actual appearance.
*Diagram differs from actual appearance.
200 mm
150 mm 50 mm 150 mm 50 mm
It fixes in a band.
TV STAND
*Diagram differs from actual appearance.

(No.YA695<Rev.001>)1-5
1.3 HANDLING HARD DISK DRIVE (HDD)
The HDD is a precision device for use in reading and writing a
large amount of data on or from a disk rotating at a high speed.
If it is not handled carefully, either abnormal operation may result
or it may not be possible to read data. The HDD is sensitive to
the following items and special care is required in safeguarding
against them when handling an HDD. Also take care in handling
a set incorporating an HDD.
(1) Vibrations and impacts
(2) Static electricity
(3) Rough handling
1.3.1 HANDLING IN TRANSPORT, ETC.
• Be sure to place the HDD in the manufacturer's specified
package carton before transport.
• When receiving a package containing an HDD, check that the
package carton is not damaged (such as having holes in the
carton, crushed corners, etc.).
• Do not impact the packaging carton when loading or unloading it.
• It is not permitted to use the inner package carton only for
transporting an HDD.
• Do not stack package cartons one upon another.
1.3.2 HANDLING AN HDD IN THE STAND-ALONE STATUS
• When handling an HDD on a hard workbench, place an
antistatic mat (rubber sheet) or similar object on the hard
surface (to prevent any impacts occurring between the HDD
and bench).
• Do not stack the HDDs one upon another.
• Do not knock an HDD with a hard object (such as a
screwdriver).
• Do not place an HDD on its side panel without using a support
(do not place an HDD in an unstable position).
1.3.3 HANDLING THE INSTALLATION OF AN HDD
• Place antistatic mats or similar sheets on all of the surfaces on
which work is conducted or when the HDD is transported.
• Do not permit the HDD to knock against the set's brackets.
• When screwing the brackets, be careful not to knock the HDD.
When using a power screwdriver, use a low-shock model and
arrange the tightening torque properly.
• When mounting an HDD in a main body, take care not to apply
excessive force to the brackets.
1.4 HANDLING LCD PANEL
1.4.1 PRECAUTIONS FOR TRANSPORTATION
When transporting the unit, pressure exerted on the internal LCD
panel due to improper handling (such as tossing and dropping)
may cause damages even when the unit is carefully packed. To
prevent accidents from occurring during transportation, pay
careful attention before delivery, such as through explaining the
handling instructions to transporters.
Ensure that the following requirements are met during
transportation, as the LCD panel of this unit is made of glass and
therefore fragile:
(1) USE A SPECIAL PACKING CASE FOR THE LCD PANEL
When transporting the LCD panel of the unit, use a special
packing case (packing materials). A special packing case
is used when a LCD panel is supplied as a service spare
part.
(2) ATTACH PROTECTION SHEET TO THE FRONT
Since the front (display part) of the panel is vulnerable,
attach the protection sheet to the front of the LCD panel
before transportation. Protection sheet is used when a LCD
panel is supplied as a service spare part.
(3) AVOID VIBRATIONS AND IMPACTS
The unit may be broken if it is toppled sideways even when
properly packed. Continuous vibration may shift the gap of
the panel, and the unit may not be able to display images
properly. Ensure that the unit is carried by at least 2
persons and pay careful attention not to exert any vibration
or impact on it.
(4) DO NOT PLACE EQUIPMENT HORIZONTALLY
Ensure that it is placed upright and not horizontally during
transportation and storage as the LCD panel is very
vulnerable to lateral impacts and may break. During
transportation, ensure that the unit is loaded along the
traveling direction of the vehicle, and avoid stacking them
on one another. For storage, ensure that they are stacked
in 2 layers or less even when placed upright.
1.4.2 OPTICAL FILTER (ON THE FRONT OF THE LCD PANEL)
(1) Avoid placing the unit under direct sunlight over a
prolonged period of time. This may cause the optical filter
to deteriorate in quality and COLOUR.
(2) Clean the filter surface by wiping it softly and lightly with a
soft and lightly fuzz cloth (such as outing flannel).
(3) Do not use solvents such as benzene or thinner to wipe the
filter surface. This may cause the filter to deteriorate in
quality or the coating on the surface to come off. When
cleaning the filter, usually use the neutral detergent diluted
with water. When cleaning the dirty filter, use water-diluted
ethanol.
(4) Since the filter surface is fragile, do not scratch or hit it with
hard materials. Be careful enough not to touch the front
surface, especially when taking the unit out of the packing
case or during transportation.
1.4.3 PRECAUTIONS FOR REPLACEMENT OF EXTERIOR
PARTS
Take note of the following when replacing exterior parts (REAR
COVER, FRONT PANEL, etc.):
(1) Do not exert pressure on the front of the LCD panel (filter
surface). It may cause irregular COLOUR.
(2) Pay careful attention not to scratch or stain the front of the
LCD panel (filter surface) with hands.
(3) When replacing exterior parts, the front (LCD panel) should
be placed facing downward. Place a mat, etc. underneath
to avoid causing scratches to the front (filter surface).
HDD
Do not throw or
drop packages.
Be sure to package and
transport the HDDs correctly.

1-6 (No.YA695<Rev.001>)
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 FEATURES
DIGITAL TUNER
This TV can receive both DVB-T(Digital terrestrial broadcasting)
and Analogue terrestrial broadcasting.
HDMI INPUT
By connecting a HDMI compatible device, high definition
pictures can be displayed on your TV in their digital form.
BUILT-IN HARD DISK DRIVE
This television has PVR (Personal Video Recorder) function
that allows you to record a programme in the installed hard
disk drive.
PICTURE MODE
This function can adjust the picture settings automatically.
There are BRIGHT, STANDARD, SOFT and MANUAL in the
PICTURE MODE.
ZOOM
This function can change the screen size according to the
picture aspect ratio.
HYPER SOUND
You can enjoy sounds with a wider ambience.
2.2 21-PIN EURO CONNECTOR (SCART) : EXT-1 / EXT-2
(P-P= Peak to Peak, B-W= Blanking to white peak)
Pin No. Signal designation Matching value EXT-1 EXT-2
1 AUDIO R output 500mV(rms) (Nominal), Low impedance Used (TV OUT) Used (LINE OUT)
2 AUDIO R input 500mV(rms) (Nominal), High impedance Used (R1) Used (R2)
3 AUDIO L output 500mV(rms) (Nominal), Low impedance Used (TV OUT) Used (LINE OUT)
4 AUDIO GND Used Used
5 GND (B) Used Used
6 AUDIO L input 500mV(rms) (Nominal), High impedance Used (L1) Used (L2)
7 B input 700mV(B-W), 75ΩUsed Not used
8 FUNCTION SW
(SLOW SW)
Low : 0V-3V
High : 8V-12V, High impedance
Used Used
9 GND (G) Used Used
10 SCL Not used Used (SCL2)
11 G input 700mV(B-W), 75ΩUsed Not used
12 SDA Not used Used (SDA2)
13 GND (R) Used Used
14 GND (YS) Used Not used
15 R / C input R : 700mV(B-W), 75Ω
C : 300mV(P-P), 75ΩUsed (R) Used (C2)
16 Ys input (FAST SW) Low : 0V-0.4V, High : 1V-3V, 75ΩUsed Not used
17 GND (VIDEO output) Used Used
18 GND (VIDEO input) Used Used
19 VIDEO output 1V(P-P) (Negative sync), 75ΩUsed (TV OUT) Used (LINE OUT)
20 VIDEO / Y input 1V(P-P) (Negative sync), 75ΩUsed Used
21 COMMON GND Used Used
20 18 16 14 12 10 8 6 4 2
21 19 17 15 13 11 9 7 5 3 1
[Pin assignment]

(No.YA695<Rev.001>)1-7
2.3 TECHNICAL INFORMATION
2.3.1 LCD PANEL
This unit uses the flat type panel LCD (Liquid Crystal Display) panel that occupies as little space as possible, instead of the
conventional CRT (Cathode Ray Tube), as a display unit.
Since the unit has the two polarizing filter that are at right angles to each other, the unit adopts "normally black" mode, where light
does not pass through the polarizing filter and the screen is black when no voltage is applied to the liquid crystals.
2.3.1.1 SPECIFICATIONS
The following table shows the specifications of this unit.
2.3.1.2 PIXEL FAULT
There are three pixel faults - bright fault , dark fault and flicker fault - that are respectively defined as follows.
BRIGHT FAULT
In this pixel fault, a cell that should not light originally is lighting on and off.
For checking this pixel fault, input ALL BLACK SCREEN and find out the cell that is lighting on and off.
DARK FAULT
In this pixel fault, a cell that should light originally is not lighting or lighting with the brightness twice as brighter as originally lighting.
For checking this pixel fault, input 100% of each R/G/B colour and find out the cell that is not lighting.
FLICKER FAULT
In the pixel fault, a cell that should light originally or not light originally is flashing on and off.
For checking this pixel fault, input ALL BLACK SCREEN signal or 100% of each RGB colour and find out the cell that is flashing on
and off.
Item Specifications
Maximum dimensions ( W ×H ×D ) 626.0 mm ×373.0mm ×45.0 mm
Weight 3.75 kg
Effective screen size Diagonal : 66.3 cm (H: 57.8 cm ×V: 32.6 cm)
Aspect ratio 16 : 9
Drive device / system a-Si-TFT active matrix system
Resolution Horizontally 1366 ×Vertically 768 ×RGB < W-XGA > 3147264 dots in total
Pixel pitch (pixel size) Horizontally: 0.4215 mm, Vertically: 0.4215 mm
Displayed color 16777216 colors 256 colors for R G and B
Brightness 450 cd/m2
Contrast ratio 3000 : 1
Response time ( G to G ) less than 6.5 ms
View angle (Horizontally) 178°
View angle (Vertically) 178°
Surface polarizer Anti-Glare type Low reflective coat
Color filter Vertical stripe
Backlight Cold cathode fluorescent lamp
Power supply voltage in LCD 12 V
Power supply voltage in inverter 24 V
Panel interface system LVDS (Low Voltage Differential Signaling)

1-8 (No.YA695<Rev.001>)
SECTION 3
DISASSEMBLY
3.1 CAUTION AT DISASSEMBLY
• Make sure that the power cord is disconnected from the outlet.
• Pay special attention not to break or damage the parts.
• Make sure that there is no bent or stain on the connectors before inserting, and firmly insert the connectors.
• Be sure to reattach the wire clamps removed during the procedure to the original positions. (Attaching the wire clamps in wrong
positions may affect the performance.)
REFERENCE:
When removing each board, remove the connector if necessary. The operation is easier if you write down the connection points
(connector numbers) of the connector. For connection of each board, refer to the "WIRING DIAGRAM" of the Standard Circuit
Diagram.
3.2 DISASSEMBLY PROCEDURE
3.2.1 REMOVING THE REAR COVER (Fig.3-1)
(1) Remove the 7 screws [A] and 2 screws [B].
(2) Remove the REAR COVER.
3.2.2 REMOVING THE POWER UNIT (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 4 screws [C].
(2) Remove the POWER UNIT.
3.2.3 REMOVING THE HDD (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 2 screws [D].
(2) Remove the HDD and HDD BRACKET together.
(3) Remove the 2 screws [E].
(4) Remove the HDD from the HDD BRACKET.
3.2.4 REMOVING THE MAIN PWB / MPEG PWB (Fig.3-1)
• Remove the REAR COVER.
• Remove the SMART DTV PWB.
(1) Remove the 2 screws [F] and 1 screw [G].
(2) Remove the SIDE SHIELD.
(3) Remove the 4 screws [H] and 4 screws [J].
(4) Remove the MAIN PWB and MPEG PWB together.
(5) Remove the connector connecting the MAIN PWB and
MPEG PWB to separate each board.
3.2.5 REMOVING THE KEY PWB (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 2 screws [K].
(2) Remove the CONTROL BASE and KEY PWB together.
(3) Remove the 2 screws [L].
(4) Remove the KEY PWB from the CONTROL BASE.
3.2.6 REMOVING THE INVERTER PWB (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 6 screws [M].
(2) Remove the INVERTER PWB COVER.
(3) Remove the INVERTER PWB.
3.2.7 REMOVING THE POWER BRACKET (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 2 screws [N].
(2) Remove the POWER BRACKET.
3.2.8 REMOVING THE SPEAKER (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 2 screws [O].
(2) Remove the SPEAKER.
(3) Follow the same steps when removing the other
SPEAKER.
3.2.9 REMOVING THE IR PWB (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 1 screw [P].
(2) Remove the IR PWB.
3.2.10 REMOVING THE STAND (Fig.3-1)
• Remove the 2 screws [B], if the REAR COVER is not removed.
(1) Remove the 2 screws [Q].
(2) Remove the STAND.
3.2.11 REMOVING THE BLUE LED MODULE (Fig.3-1)
• Remove the REAR COVER.
• Remove the STAND.
• Remove the MAIN PWB.
• Remove the MPEG PWB.
(1) Remove the 4 screws [R] and 4 screws [S].
(2) Remove the MAIN SHIELD.
(3) Remove the 2 screws [T].
(4) Remove the BLUE LED MODULE.
3.2.12 REMOVING THE LCD PANEL UNIT (Fig.3-1)
• Remove the REAR COVER.
• Remove the STAND.
• Remove the MAIN SHIELD.
(1) Remove the 2 screws [U].
(2) Remove the PANEL BRACKET.
(3) Remove the LCD PANEL UNIT.

(No.YA695<Rev.001>)1-9
Fig.3-1
F
F
G
J
H
R
P
T
T
K
L
A
B
N
S
U
FRONT
CABINET
LCD PANEL
SPEAKER
SPEAKER
MAIN PWB
HDD
HDD BRACKET
MPEG PWB
POWER UNIT
MAIN SHIELD
SIDE SHIELD
REAR COVER
BLUE LED MODULE
KEY PWB
CONTROL
KNOB
CONTROL
BASE
IR PWB
C
M
U
D
E
D
INVERTER
PWB
INVERTER
PWB COVER
POWER
BRACKET
PANEL
BRACKET
PANEL BRACKET
19
19
19
19
O
O
R
STAND

1-10 (No.YA695<Rev.001>)
3.3 MEMORY IC REPLACEMENT
• This model uses the memory IC.
• This memory IC stores data for proper operation of the video and drive circuits.
• When replacing, be sure to use an IC containing this (initial value) data.
3.3.1 MEMORY IC REPLACEMENT PROCEDURE
1. Power off
Switch off the power and disconnect the power plug from the AC outlet.
2. Replace the memory IC
Be sure to use the memory IC written with the initial setting values.
3. Power on
Connect the power plug to the AC outlet and switch on the power.
4. Receiving channel setting
Refer to the OPERATING INSTRUCTIONS and set the receive channels (Channels Preset) as described.
5. User setting
Check the user setting items according to the given in page later. Where these do not agree, refer to the OPERATING
INSTRUCTIONS and set the items as described.
6. FACTORY MODE setting
Verify what to set in the FACTORY MODE, and set whatever is necessary.
3.3.2 FACTORY MODE SETTING
FACTORY MODE SCREEN SETTING ITEM
FACTORY MODE SCREEN-1
FACTORY MODE SCREEN-2
Press [ ] key
Service
Service
Hardware Ver : REV X.X
Hardware Ver : REV X.X
Sub MCU SW Ver : REV X.X
Sub MCU SW Ver : REV X.X
ATV SW Ver : XXXXXX X.XX.XX
ATV SW Ver : XXXXXX X.XX.XX
DTV SW Ver : XXXXXX X.XX.XX
DTV SW Ver : XXXXXX X.XX.XX
Sub MCU Loader Ver : XX.XX
Sub MCU Loader Ver : XX.XX
DTV Loader Ver : XX.XX
DTV Loader Ver : XX.XX
ATV Loader Ver : X. X. X
ATV Loader Ver : X. X. X
System ID : XXXX.XXXX
System ID : XXXX.XXXX
Update Date : XXXX XX XXXX
Update Date : XXXX XX XXXX
Right:Enter Back:Return Exit:OK
Right:Enter Back:Return Exit:OK
Video Setup
Video Setup
White Balance
White Balance
Spread Spectrum
Spread Spectrum
Panel Select <XXXXX>
Panel Select <XXXXX>
Reset TV-set
Reset TV-set
Factory Default
Factory Default
DTV Tuner Test <OFF>
DTV Tuner Test <OFF>
Right:Enter Back:Return Exit:OK
Right:Enter Back:Return Exit:OK
Setting items Settings
Video Setup [Do not adjust]
White Balance Adjust
Spread Spectrum [Do not adjust]
Panel Select [Do not adjust]
Reset TV-set ---
Factory Default ---
DTV Tuner Test ---

(No.YA695<Rev.001>)1-11
3.3.3 SETTINGS OF FACTORY SHIPMENT
3.3.3.1 BUTTON OPERATION 3.3.3.2 REMOTE CONTROL DIRECT OPERATION
3.3.3.3 REMOTE CONTROL MENU OPERATION
(1) Picture
(2) Sound
(3) Install
(4) Feature
(5) APS (in Analog tV Mode only)
Setting item Setting position
POWER Off
CHANNEL PR1
VOLUME 10
AV TV
Setting item Setting position
CHANNEL PR1
VOLUME 10
ZOOM AUTO
SUB POWER OFF
Setting item Setting position
Mode Bright
Fleshtone Off
Colour Temperature Cool
Noise Reduction High
Backlight High
Setting item Setting position
Bass 0
Treble 0
Balance 0
AVL On
Hyper Sound Off
Setting item Setting position
Country BJ: UK
BU: Germany
Antenna Power Off
Auto Search ---
Manual Search ---
Edit Channels ---
Setting item Setting position
Language English
Time Setting
Power On Time Off
Power Off Time Off
Auto Power Off Off
Parental Control Disable
OSD Transparency 30
Blue Back Off
Power Lamp On
4 : 3 Aspect Setting Panoramic
Setting item Setting position
Language English
Antenna Power Off
Country BJ: UK
BU: Germany
Channel Search ---

1-12 (No.YA695<Rev.001>)
3.4 REPLACEMENT OF CHIP COMPONENT
3.4.1 CAUTIONS
(1) Avoid heating for more than 3 seconds.
(2) Do not rub the electrodes and the resist parts of the pattern.
(3) When removing a chip part, melt the solder adequately.
(4) Do not reuse a chip part after removing it.
3.4.2 SOLDERING IRON
(1) Use a high insulation soldering iron with a thin pointed end of it.
(2) A 30w soldering iron is recommended for easily removing parts.
3.4.3 REPLACEMENT STEPS
1. How to remove Chip parts
[Resistors, capacitors, etc.]
(1) As shown in the figure, push the part with tweezers and
alternately melt the solder at each end.
(2) Shift with the tweezers and remove the chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply extra solder to each lead.
(2) As shown in the figure, push the part with tweezers and
alternately melt the solder at each lead. Shift and remove
the chip part.
NOTE :
After removing the part, remove remaining solder from the
pattern.
2. How to install Chip parts
[Resistors, capacitors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder. Then heat and melt the solder at both ends of the
chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder.
(3) First solder lead Aas indicated in the figure.
(4) Then solder leads Band C.
SOLDER SOLDER
A
B
C
A
B
C

(No.YA695<Rev.001>)1-13
SECTION 4
ADJUSTMENT
4.1 ADJUSTMENT PREPARATION
(1) This TV is adjusted by using REMOTE CONTROL UNIT.
(2) The adjustment using the REMOTE CONTROL UNIT is made on the basis of the initial setting values. The setting values
which adjust the screen to the optimum condition can be different from the initial setting values.
(3) Make sure that connection is correctly made AC to AC power source.
(4) Turn on the power of the TV and measuring instruments for warming up for at least 30 minutes before starting adjustments.
(5) If the receive or input signal is not specified, use the most appropriate signal for adjustment.
(6) Never touch the parts (such as variable resistors, transformers and condensers) not shown in the adjustment items of this service
adjustment.
4.2 PRESET SETTING BEFORE ADJUSTMENTS
Unless otherwise specified in the adjustment items, preset the
following functions with the REMOTE CONTROL UNIT.
4.3 MEASURING INSTRUMENT AND FIXTURES
• Signal generator (Pattern generator)[PAL]
• Remote control unit
4.4 ADJUSTMENT ITEMS
VIDEO CIRCUIT
• WHITE BALANCE adjustment
4.5 BASIC OPERATION OF FACTORY MODE
4.5.1 HOW TO ENTER THE FACTORY MODE
(1) Press [INFORMATION] key and [MUTING] key on the
remote control unit simultaneously to enter the FACTORY
MODE SCREEN-1. (Fig.4-1)
(2) Press []key on the remote control unit simultaneously to
enter the FACTORY MODE SCREEN-2. (Fig.4-1)
4.5.2 HOW TO EXIT THE FACTORY MODE
Press the [OK] key to exit the factory mode.
Setting item Settings position
Picture Mode Standard
Colour Temperature Normal
Fig.4-1
DO NOT ADJUST
FACTORY MODE SCREEN-1
FACTORY MODE SCREEN-2
Press [ ] key
Service
Service
Hardware Ver : REV X.X
Hardware Ver : REV X.X
Sub MCU SW Ver : REV X.X
Sub MCU SW Ver : REV X.X
ATV SW Ver : XXXXXX X.XX.XX
ATV SW Ver : XXXXXX X.XX.XX
DTV SW Ver : XXXXXX X.XX.XX
DTV SW Ver : XXXXXX X.XX.XX
Sub MCU Loader Ver : XX.XX
Sub MCU Loader Ver : XX.XX
DTV Loader Ver : XX.XX
DTV Loader Ver : XX.XX
ATV Loader Ver : X. X. X
ATV Loader Ver : X. X. X
System ID : XXXX.XXXX
System ID : XXXX.XXXX
Update Date : XXXX XX XXXX
Update Date : XXXX XX XXXX
Right:Enter Back:Return Exit:OK
Right:Enter Back:Return Exit:OK
Video Setup
Video Setup
White Balance
White Balance
Spread Spectrum
Spread Spectrum
Panel Select <XXXXX>
Panel Select <XXXXX>
Reset TV-set
Reset TV-set
Factory Default
Factory Default
DTV Tuner Test <OFF>
DTV Tuner Test <OFF>
Right:Enter Back:Return Exit:OK
Right:Enter Back:Return Exit:OK

(No.YA695<Rev.001>)
VSE
Printed in Japan
4.5.3 CHANGE AND MEMORY OF SETTING VALUE
SELECTION OF SETTING ITEM
•[FUNCTION /] key.
For scrolling up / down the setting items.
•[FUNCTION /]key.
For select the setting items.
CHANGE OF SETTING VALUE (DATA)
•[FUNCTION /]key.
For scrolling up / down the setting values.
MEMORY OF SETTING VALUE (DATA)
The setting value will be stored automatically when release the
REMOTE CONTROL UNIT keys.
4.5.4 FACTORY MODE SELECT KEY LOCATION
4.6 ADJUSTMENT PROCEDURE
4.6.1 VIDEO CIRCUIT
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.
[FUNCTION /] key
[Function/] key
[MUTING] key +
[INFORMATION] key
Enter The Factry Mode.
Scrolling up / down the
setting value. Select the setting item.
Item Measuring
instrument Test point Adjustment part Description
WHITE
BALANCE
Remote
control unit
Signal
generator
[White Balance]
Normal R
Normal G
Normal B
(1) Set COLOUR TEMP. to "Normal".
(2) Select "White Balance" from the FACTORY
MODE.
(3) Receive a PAL 75% all white signal.
(4) Adjust the setting values of <Normal R>,
<Normal G> and <Normal B> so that the
screen becomes maximum white.
NOTE:
When the normal mode is adjusted, other modes
(cool/ warm) are automatically adjusted.
Victor Company of Japan, Limited
Display Division 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama-city, Kanagawa-prefecture, 221-8528, Japan

(No.YA695<Rev.001>)3-1
PARTS LIST
CAUTION
JThe parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the
safety.
JThe parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied.
JP.W. BOARD Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.
ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES
RESISTORS CAPACITORS
CR Carbon Resistor C CAP. Ceramic Capacitor
FR Fusible Resistor E CAP. Electrolytic Capacitor
PR Plate Resistor M CAP. Mylar Capacitor
VR Variable Resistor CH CAP. Chip Capacitor
HV R High Voltage Resistor HV CAP. High Voltage Capacitor
MF R Metal Film Resistor MF CAP. Metalized Film Capacitor
MG R Metal Glazed Resistor MM CAP. Metalized Mylar Capacitor
MP R Metal Plate Resistor MP CAP. Metalized Polystyrol Capacitor
OM R Metal Oxide Film Resistor PP CAP. Polypropylene Capacitor
CMF R Coating Metal Film Resistor PS CAP. Polystyrol Capacitor
UNF R Non-Flammable Resistor TF CAP. Thin Film Capacitor
CH V R Chip Variable Resistor MPP CAP. Metalized Polypropylene Capacitor
CH MG R Chip Metal Glazed Resistor TAN. CAP. Tantalum Capacitor
COMP. R Composition Resistor CH C CAP. Chip Ceramic Capacitor
LPTC R Linear Positive Temperature Coefficient Resistor BP E CAP. Bi-Polar Electrolytic Capacitor
CH AL E CAP. Chip Aluminum Electrolytic Capacitor
CH AL BP CAP. Chip Aluminum Bi-Polar Capacitor
CH TAN. E CAP. Chip Tantalum Electrolytic Capacitor
CH AL BP E CAP. Chip Tantalum Bi-Polar Electrolytic Capacitor
RESISTORS
FGJ KMNRHZP
±1% ±2% ±5% ±10% ±20% ±30% +30%
-10%
+50%
-10%
+80%
-20%
+100%
-0%

3-2(No.YA695<Rev.001>)
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................................... 3-2
EXPLODED VIEW PARTS LIST ................................................................................................................................. 3-2
EXPLODED VIEW ....................................................................................................................................................... 3-3
PRINTED WIRING BOARD PARTS LIST ................................................................................................................... 3-4
MAIN P.W. BOARD ASS'Y (HU-71100007) ...................................................................................................... 3-4
MPEG P.W. BOARD ASS'Y (HU-71100010) ..................................................................................................... 3-8
IR P.W. BOARD ASS'Y (HU-72200001) .......................................................................................................... 3-11
KEY P.W. BOARD ASS'Y (HU-72200002) ...................................................................................................... 3-11
PACKING ................................................................................................................................................................... 3-12
PACKING PARTS LIST ............................................................................................................................................. 3-12
USING P.W. BOARD & REMOTE CONTROL UNIT
EXPLODED VIEW PARTS LIST
P.W.B ASS'Y name
P.W.B ASS'Y No.
LT-26DE1BJ/AX LT-26DE1BU/AX
MAIN P.W.B HU-71100007 ←
MPEG P.W.B HU-71100010 ←
IR P.W.B HU-72200001 ←
KEY P.W.B HU-72200002 ←
REMOTE CONTROL UNIT HU-0320200008 ←
Ref.No. Part No. Part Name Description Local
LV1 HU-0130100060 DIGITAL(LVDS) CABLE MAIN-LCD PANEL UNIT
1 HU-014213231PN REAR COVER
2 HU-014213212PN FRONT CABINET
3 QLD0611-001-HUP LCD PANEL UNIT HU-0141300045/Inc.3B
3B AU-19.26T02.006 INVERTER PWB
5 HU-024000450 SPEAKER 8
Ω 5W 2pcs 1set/Inc.SPEAKER WIRE
8 HU-3010310001CO SIDE SHIELD
9 HU-3010119002CO MAIN SHIELD
16 HU-014214010CX STAND BASE
17 HU-3011906001CX SUPPORT BRACKET
21 HU-3025220001PN CONTROL KNOB
22 HU-3029406001PN GUIDE KNOB
29 HU-3029304001CO GUIDE CI
32 HU-0210000001 BLUE LED MODULE
33 HU-3011305001CO PANEL BRACKET (x2)
43 HU-014120180 HDD
44 HU-3011810001CO HDD BRACKET
45 HU-0120000001 AC INLET
46 HU-3011503001CO POWER BRACKET
47 HU-1013113002 SPACER (x4)
50 HU-M1305300817 SCREW M3x8(x8)
51 HU-M1010400817 SCREW M4x8(x4)
52 HU-M1118300615 SCREW M3x6(x2)
54 HU-0130100007 E-HARNESS ASSY MAIN-KEY
55 HU-0130100009 E-HARNESS ASSY MAIN-IR
56 HU-0130100005 E-HARNESS ASSY DIGITAL-HDD
57 HU-0130100022 E-HARNESS ASSY INVERTER-POWER UNIT
58 HU-0130100013 E-HARNESS ASSY MAIN-POWER UNIT
61 HU-M1308420815 SCREW M4x8(x4)
200 HU-014031300 POWER UNIT
202 HU-71100007 MAIN PWB
203 HU-72200002 KEY PWB
206 HU-71100010 MPEG PWB
210 HU-72200001 IR PWB

(No.YA695<Rev.001>)3-3
EXPLODED VIEW

202

206
LV1
55
54
56
51

50
1


58
200
45
32
5
5
210
22
21

2


203
52
52
9
33
33
57
8
46
61
61
43
44
47
47
29
50

3B
INVERTER
PWB COVER 
3
17
16
51

3-4(No.YA695<Rev.001>)
PRINTED WIRING BOARD PARTS LIST
MAIN P.W. BOARD ASS'Y (HU-71100007)
 Ref No. Part No. Part Name Description Local
U1 ------------ IC Not supply
U2 HU-004020013 FET
U60 HU-000010440 IC PROCESSOR
U61 ------------ IC Not supply
U120 CD4052BM-X IC MUX/DEMUX
U180 HU-000060019 IC OP AMP
U200 HU-000990180 IC SWITCH
U370 ------------ IC Not supply
U371 ------------ IC Not supply
U470 HU-000230270 IC HDMI RECEIVER
U560 HU-000140450 IC AUDIO DAC
U580 TPA3100D2PHP-W IC
U581 HU-000060510 IC HEADPHONE AMP
U630 HU-004020250 FET
U660 HU-000170030 IC RS232 DRIVER
U661 SN74LVC244APW-X IC CMOS
U720 HU-000140583 IC DC-DC CONV
U721 HU-000091100 IC REGULATOR
U723 HU-000091100 IC REGULATOR
U725 HU-000091100 IC REGULATOR
U726 BA50BC0WFP-X IC REGULATOR
U770 HU-014040950 TUNER ANALOG
U771 HU-000090090 IC REGULATOR
U772 HU-0009000001 IC POWER SW
U800 HU-000990055 IC VOLTAGE DETECTOR
U801 HU-000010610 IC MICOM
Q1 HU-004001001 TRANSISTOR
Q61 HU-004001001 TRANSISTOR
Q120 HU-004001001 TRANSISTOR
Q374 HU-004001001 TRANSISTOR
Q375 HU-004001001 TRANSISTOR
Q581 HU-004001001 TRANSISTOR
Q582 HU-004020030 MOS FET
Q583 HU-004001001 TRANSISTOR
Q631 HU-004001001 TRANSISTOR
Q632 HU-004001001 TRANSISTOR
Q634 HU-004000260 FET
Q660 HU-004001001 TRANSISTOR
Q661 HU-004000260 FET
Q662 HU-004000260 FET
Q680 HU-004000008 TRANSISTOR
Q681 HU-004001001 TRANSISTOR
Q686 HU-004000008 TRANSISTOR
Q773 HU-004001001 TRANSISTOR
Q800 HU-004000260 FET
Q802 HU-004000260 FET
Q803 HU-004001001 TRANSISTOR
D1 HU-003010046 Z DIODE
D370 HU-003040008 SI DIODE
D371 HU-003040008 SI DIODE
Z330 HU-003010053 Z DIODE
Z331 HU-003010053 Z DIODE
C3 HU-001060286 C CAPACITOR 10uF 10V
C4 HU-001060250 C CAPACITOR 0.1uF 16V K
C5 HU-001060286 C CAPACITOR 10uF 10V
C6 HU-001060250 C CAPACITOR 0.1uF 16V K
C7 HU-001060250 C CAPACITOR 0.1uF 16V K
C8 HU-001060286 C CAPACITOR 10uF 10V
C9 HU-001060250 C CAPACITOR 0.1uF 16V K
C10 HU-001060236 C CAPACITOR 10uF 25V
C11 HU-001060250 C CAPACITOR 0.1uF 16V K
C12 HU-001060249 C CAPACITOR 100pF 50V J
C13 HU-001060286 C CAPACITOR 10uF 10V
C14 HU-001060250 C CAPACITOR 0.1uF 16V K
C15 HU-001060286 C CAPACITOR 10uF 10V
C16 HU-001060250 C CAPACITOR 0.1uF 16V K
C17 HU-001060286 C CAPACITOR 10uF 10V
C18 HU-001060250 C CAPACITOR 0.1uF 16V K
C19 HU-001060286 C CAPACITOR 10uF 10V
C20 HU-001060250 C CAPACITOR 0.1uF 16V K
C21 HU-001060286 C CAPACITOR 10uF 10V
C22 HU-001060250 C CAPACITOR 0.1uF 16V K
C23 HU-001060286 C CAPACITOR 10uF 10V
C24 HU-001060250 C CAPACITOR 0.1uF 16V K
C25 HU-001060286 C CAPACITOR 10uF 10V
C26 HU-001060250 C CAPACITOR 0.1uF 16V K
C27 HU-001060250 C CAPACITOR 0.1uF 16V K
C28 HU-001060286 C CAPACITOR 10uF 10V
C29 HU-001060286 C CAPACITOR 10uF 10V
C30 HU-001060219 C CAPACITOR 1000pF 50V K
C31 HU-001060219 C CAPACITOR 1000pF 50V K
C32 HU-001060250 C CAPACITOR 0.1uF 16V K
C33 HU-001060250 C CAPACITOR 0.1uF 16V K
C34 HU-001060250 C CAPACITOR 0.1uF 16V K
C35 HU-001060286 C CAPACITOR 10uF 10V
C36 HU-001060250 C CAPACITOR 0.1uF 16V K
C37 HU-001060286 C CAPACITOR 10uF 10V
C38 HU-001060250 C CAPACITOR 0.1uF 16V K
C39 HU-001060286 C CAPACITOR 10uF 10V
C40 HU-001060250 C CAPACITOR 0.1uF 16V K
C41 HU-001060250 C CAPACITOR 0.1uF 16V K
C42 HU-001060321 C CAPACITOR 10uF 10V K
C43 HU-001060250 C CAPACITOR 0.1uF 16V K
C44 HU-001060236 C CAPACITOR 10uF 25V
C45 HU-001060105 C CAPACITOR 0.1uF 50V
C46 HU-001060236 C CAPACITOR 10uF 25V
C47 HU-001060236 C CAPACITOR 10uF 25V
C60 HU-001060250 C CAPACITOR 0.1uF 16V K
C64 HU-001060250 C CAPACITOR 0.1uF 16V K
C66 HU-001063002 C CAPACITOR 14pF 50V
C67 HU-001063002 C CAPACITOR 14pF 50V
C120 HU-001060288 C CAPACITOR 1uF 25V
C121 HU-001060288 C CAPACITOR 1uF 25V
C122 HU-001060288 C CAPACITOR 1uF 25V
C123 HU-001060318 C CAPACITOR 0.1uF 50V
C124 HU-001060318 C CAPACITOR 0.1uF 50V
C125 HU-001060318 C CAPACITOR 0.1uF 50V
C126 HU-001060288 C CAPACITOR 1uF 25V
C127 HU-001060288 C CAPACITOR 1uF 25V
C128 HU-001060288 C CAPACITOR 1uF 25V
C129 HU-001060318 C CAPACITOR 0.1uF 50V
C130 HU-001060288 C CAPACITOR 1uF 25V
C131 HU-001060318 C CAPACITOR 0.1uF 50V
C132 HU-001060318 C CAPACITOR 0.1uF 50V
C133 HU-001060288 C CAPACITOR 1uF 25V
C134 HU-001060288 C CAPACITOR 1uF 25V
C135 HU-001060288 C CAPACITOR 1uF 25V
C136 HU-001060288 C CAPACITOR 1uF 25V
C137 HU-001060288 C CAPACITOR 1uF 25V
C138 HU-001060288 C CAPACITOR 1uF 25V
C145 HU-001060266 C CAPACITOR 56pF 50V J
C146 HU-001063035 C CAPACITOR 10pF 50V C
C147 HU-001060250 C CAPACITOR 0.1uF 16V K
C148 HU-001060266 C CAPACITOR 56pF 50V J
C149 HU-001060286 C CAPACITOR 10uF 10V
C150 HU-001060318 C CAPACITOR 0.1uF 50V
C151 HU-001060219 C CAPACITOR 1000pF 50V K
C152 HU-001060288 C CAPACITOR 1uF 25V
C153 HU-001060219 C CAPACITOR 1000pF 50V K
C154 HU-001060288 C CAPACITOR 1uF 25V
C155 HU-001060236 C CAPACITOR 10uF 25V
C156 HU-001060219 C CAPACITOR 1000pF 50V K
C158 HU-001060219 C CAPACITOR 1000pF 50V K
C159 HU-001060219 C CAPACITOR 1000pF 50V K
C160 HU-001060219 C CAPACITOR 1000pF 50V K
C161 HU-001060288 C CAPACITOR 1uF 25V
C162 HU-001060219 C CAPACITOR 1000pF 50V K
C163 HU-001060288 C CAPACITOR 1uF 25V
C164 HU-001060219 C CAPACITOR 1000pF 50V K
C166 HU-001060236 C CAPACITOR 10uF 25V
C180 HU-001071194 E CAPACITOR 100uF 25V
C181 HU-001060318 C CAPACITOR 0.1uF 50V
C182 HU-001060318 C CAPACITOR 0.1uF 50V
C183 HU-001071228 E CAPACITOR 470uF 16V
C186 HU-001071228 E CAPACITOR 470uF 16V
C200 HU-001060286 C CAPACITOR 10uF 10V
C201 HU-001060236 C CAPACITOR 10uF 25V
C202 HU-001060297 C CAPACITOR 0.01pF 50V K
C203 HU-001060250 C CAPACITOR 0.1uF 16V K
C204 HU-001060318 C CAPACITOR 0.1uF 50V
C205 HU-001060286 C CAPACITOR 10uF 10V
C206 HU-001060224 C CAPACITOR 0.47uF 16V
C207 HU-001060250 C CAPACITOR 0.1uF 16V K
C208 HU-001060250 C CAPACITOR 0.1uF 16V K
C209 HU-001060250 C CAPACITOR 0.1uF 16V K
C210 HU-001060250 C CAPACITOR 0.1uF 16V K
C211 HU-001060250 C CAPACITOR 0.1uF 16V K
C212 HU-001060250 C CAPACITOR 0.1uF 16V K
C213 HU-001060250 C CAPACITOR 0.1uF 16V K
C214 HU-001060250 C CAPACITOR 0.1uF 16V K
C215 HU-001060250 C CAPACITOR 0.1uF 16V K
C216 HU-001060288 C CAPACITOR 1uF 25V
C217 HU-001060288 C CAPACITOR 1uF 25V
C218 HU-001060288 C CAPACITOR 1uF 25V
C219 HU-001060288 C CAPACITOR 1uF 25V
C220 HU-001071210 E CAPACITOR 47uF 25V
C221 HU-001060318 C CAPACITOR 0.1uF 50V
 Ref No. Part No. Part Name Description Local

(No.YA695<Rev.001>)3-5
C233 HU-001060219 C CAPACITOR 1000pF 50V K
C234 HU-001060219 C CAPACITOR 1000pF 50V K
C235 HU-001060236 C CAPACITOR 10uF 25V
C236 HU-001060219 C CAPACITOR 1000pF 50V K
C237 HU-001060236 C CAPACITOR 10uF 25V
C238 HU-001060219 C CAPACITOR 1000pF 50V K
C263 HU-001060219 C CAPACITOR 1000pF 50V K
C264 HU-001060219 C CAPACITOR 1000pF 50V K
C265 HU-001060236 C CAPACITOR 10uF 25V
C266 HU-001060219 C CAPACITOR 1000pF 50V K
C267 HU-001060236 C CAPACITOR 10uF 25V
C268 HU-001060219 C CAPACITOR 1000pF 50V K
C299 HU-001060250 C CAPACITOR 0.1uF 16V K
C370 HU-001060250 C CAPACITOR 0.1uF 16V K
C371 HU-001060250 C CAPACITOR 0.1uF 16V K
C372 HU-001060286 C CAPACITOR 10uF 10V
C373 HU-001060250 C CAPACITOR 0.1uF 16V K
C374 HU-001060286 C CAPACITOR 10uF 10V
C375 HU-001060250 C CAPACITOR 0.1uF 16V K
C470 HU-001060219 C CAPACITOR 1000pF 50V K
C471 HU-001060219 C CAPACITOR 1000pF 50V K
C472 HU-001060219 C CAPACITOR 1000pF 50V K
C473 HU-001060219 C CAPACITOR 1000pF 50V K
C474 HU-001060219 C CAPACITOR 1000pF 50V K
C475 HU-001060297 C CAPACITOR 0.01pF 50V K
C476 HU-001060297 C CAPACITOR 0.01pF 50V K
C477 HU-001060297 C CAPACITOR 0.01pF 50V K
C488 HU-001060250 C CAPACITOR 0.1uF 16V K
C489 HU-001060250 C CAPACITOR 0.1uF 16V K
C490 HU-001060250 C CAPACITOR 0.1uF 16V K
C491 HU-001060250 C CAPACITOR 0.1uF 16V K
C492 HU-001060250 C CAPACITOR 0.1uF 16V K
C493 HU-001060250 C CAPACITOR 0.1uF 16V K
C494 HU-001060250 C CAPACITOR 0.1uF 16V K
C495 HU-001060250 C CAPACITOR 0.1uF 16V K
C496 HU-001060250 C CAPACITOR 0.1uF 16V K
C497 HU-001060288 C CAPACITOR 1uF 25V
C498 HU-001060286 C CAPACITOR 10uF 10V
C499 HU-001060286 C CAPACITOR 10uF 10V
C500 HU-001060286 C CAPACITOR 10uF 10V
C501 HU-001060286 C CAPACITOR 10uF 10V
C502 HU-001060286 C CAPACITOR 10uF 10V
C503 HU-001060273 C CAPACITOR 24pF 50V
C504 HU-001060273 C CAPACITOR 24pF 50V
C505 HU-001063027 C CAPACITOR 2pF 50V
C560 HU-001060286 C CAPACITOR 10uF 10V
C561 HU-001060236 C CAPACITOR 10uF 25V
C562 HU-001060236 C CAPACITOR 10uF 25V
C563 HU-001060250 C CAPACITOR 0.1uF 16V K
C564 HU-001060236 C CAPACITOR 10uF 25V
C565 HU-001060236 C CAPACITOR 10uF 25V
C566 HU-001060250 C CAPACITOR 0.1uF 16V K
C567 HU-001060250 C CAPACITOR 0.1uF 16V K
C580 HU-001060219 C CAPACITOR 1000pF 50V K
C581 HU-001060288 C CAPACITOR 1uF 25V
C582 HU-001071082 E CAPACITOR 470uF 25V
C583 HU-001060288 C CAPACITOR 1uF 25V
C584 HU-001060288 C CAPACITOR 1uF 25V
C585 HU-001071082 E CAPACITOR 470uF 25V
C586 HU-001060288 C CAPACITOR 1uF 25V
C587 HU-001060219 C CAPACITOR 1000pF 50V K
C588 HU-001060199 C CAPACITOR 0.22uF 25V
C589 HU-001060199 C CAPACITOR 0.22uF 25V
C590 HU-001060288 C CAPACITOR 1uF 25V
C591 HU-001060288 C CAPACITOR 1uF 25V
C592 HU-001060224 C CAPACITOR 0.47uF 16V
C593 HU-001060288 C CAPACITOR 1uF 25V
C594 HU-001060219 C CAPACITOR 1000pF 50V K
C595 HU-001060288 C CAPACITOR 1uF 25V
C596 HU-001060199 C CAPACITOR 0.22uF 25V
C597 HU-001060199 C CAPACITOR 0.22uF 25V
C598 HU-001060199 C CAPACITOR 0.22uF 25V
C599 HU-001060199 C CAPACITOR 0.22uF 25V
C600 HU-001060224 C CAPACITOR 0.47uF 16V
C601 HU-001060199 C CAPACITOR 0.22uF 25V
C602 HU-001060199 C CAPACITOR 0.22uF 25V
C603 HU-001060230 C CAPACITOR 0.022uF 16V K
C604 HU-001060297 C CAPACITOR 0.01pF 50V K
C605 HU-001060288 C CAPACITOR 1uF 25V
C606 HU-001060230 C CAPACITOR 0.022uF 16V K
C607 HU-001060250 C CAPACITOR 0.1uF 16V K
C608 HU-001060288 C CAPACITOR 1uF 25V
C610 HU-001071191 E CAPACITOR 47uF 16V
C611 HU-001071191 E CAPACITOR 47uF 16V
C612 HU-001060288 C CAPACITOR 1uF 25V
C613 HU-001060288 C CAPACITOR 1uF 25V
C615 HU-001060286 C CAPACITOR 10uF 10V
C616 HU-001060288 C CAPACITOR 1uF 25V
C630 HU-001060288 C CAPACITOR 1uF 25V
 Ref No. Part No. Part Name Description Local
C631 HU-001060250 C CAPACITOR 0.1uF 16V K
C632 HU-001060236 C CAPACITOR 10uF 25V
C633 HU-001060105 C CAPACITOR 0.1uF 50V
C636 HU-001060236 C CAPACITOR 10uF 25V
C637 HU-0010600007 C CAPACITOR 0.22uF 10V
C660 HU-001060250 C CAPACITOR 0.1uF 16V K
C661 HU-001060250 C CAPACITOR 0.1uF 16V K
C662 HU-001060250 C CAPACITOR 0.1uF 16V K
C663 HU-001060250 C CAPACITOR 0.1uF 16V K
C664 HU-001060286 C CAPACITOR 10uF 10V
C665 HU-001060250 C CAPACITOR 0.1uF 16V K
C680 HU-001060250 C CAPACITOR 0.1uF 16V K
C681 HU-001071236 E CAPACITOR 470uF 16V
C682 HU-001060250 C CAPACITOR 0.1uF 16V K
C683 HU-001071236 E CAPACITOR 470uF 16V
C684 HU-001060318 C CAPACITOR 0.1uF 50V
C685 HU-001071236 E CAPACITOR 470uF 16V
C686 HU-001060250 C CAPACITOR 0.1uF 16V K
C687 HU-001060286 C CAPACITOR 10uF 10V
C688 HU-001060250 C CAPACITOR 0.1uF 16V K
C724 HU-0010700002 E CAPACITOR 100uF 16V
C726 HU-001060286 C CAPACITOR 10uF 10V
C728 HU-001060312 C CAPACITOR 22uF 6.3V M
C729 HU-001060312 C CAPACITOR 22uF 6.3V M
C730 HU-001060312 C CAPACITOR 22uF 6.3V M
C731 HU-001060250 C CAPACITOR 0.1uF 16V K
C732 HU-001071223 E CAPACITOR 100uF 16V
C733 HU-001060312 C CAPACITOR 22uF 6.3V M
C734 HU-001060297 C CAPACITOR 0.01pF 50V K
C737 HU-001060286 C CAPACITOR 10uF 10V
C738 HU-001060250 C CAPACITOR 0.1uF 16V K
C743 HU-001071223 E CAPACITOR 100uF 16V
C745 HU-001060286 C CAPACITOR 10uF 10V
C746 HU-001060250 C CAPACITOR 0.1uF 16V K
C747 HU-001071223 E CAPACITOR 100uF 16V
C748 HU-001060250 C CAPACITOR 0.1uF 16V K
C751 HU-001060250 C CAPACITOR 0.1uF 16V K
C752 HU-001060286 C CAPACITOR 10uF 10V
C753 HU-001060250 C CAPACITOR 0.1uF 16V K
C754 HU-001060274 C CAPACITOR 3300pF 50V
C770 HU-001060250 C CAPACITOR 0.1uF 16V K
C772 HU-001071228 E CAPACITOR 470uF 16V
C773 HU-001060309 C CAPACITOR 10uF 16V K
C774 HU-001060250 C CAPACITOR 0.1uF 16V K
C775 HU-001060309 C CAPACITOR 10uF 16V K
C776 HU-001060105 C CAPACITOR 0.1uF 50V
C777 HU-001060309 C CAPACITOR 10uF 16V K
C778 HU-001060250 C CAPACITOR 0.1uF 16V K
C779 HU-001060249 C CAPACITOR 100pF 50V J
C780 HU-001071225 E CAPACITOR 2.2uF 50V
C781 HU-001060171 C CAPACITOR 33pF 50V
C782 HU-001060171 C CAPACITOR 33pF 50V
C800 HU-001060250 C CAPACITOR 0.1uF 16V K
C801 HU-001060346 C CAPACITOR 1uF 16V K
C802 HU-001060286 C CAPACITOR 10uF 10V
C803 HU-001060250 C CAPACITOR 0.1uF 16V K
C804 HU-001060250 C CAPACITOR 0.1uF 16V K
C805 HU-001060250 C CAPACITOR 0.1uF 16V K
C807 HU-001060250 C CAPACITOR 0.1uF 16V K
C808 HU-001060250 C CAPACITOR 0.1uF 16V K
C809 HU-001063058 C CAPACITOR 18pF 50V J
C810 HU-001063058 C CAPACITOR 18pF 50V J
C840 HU-001060219 C CAPACITOR 1000pF 50V K
C841 HU-001060219 C CAPACITOR 1000pF 50V K
R1 HU-002000453 MG RESISTOR 470
Ω
R2 HU-002000453 MG RESISTOR 470 Ω
R3 HU-002000453 MG RESISTOR 470 Ω
R4 HU-002000453 MG RESISTOR 470 Ω
R5 HU-002000557 MG RESISTOR 6.2k Ω
R6 HU-002000436 MG RESISTOR 100k Ω
R7 HU-002000417 MG RESISTOR 4.7k Ω
R61 HU-002000437 MG RESISTOR 10k Ω
R62 HU-002000437 MG RESISTOR 10k Ω
R63 HU-002000437 MG RESISTOR 10k Ω
R64 HU-002000437 MG RESISTOR 10k Ω
R66 HU-002000448 MG RESISTOR 33 Ω
R68 HU-002000527 MG RESISTOR 100 Ω
R70 HU-002000405 MG RESISTOR 1k Ω
R71 HU-002000405 MG RESISTOR 1k Ω
R72 HU-002000405 MG RESISTOR 1k Ω
R73 HU-002000405 MG RESISTOR 1k Ω
R75 HU-002000405 MG RESISTOR 1k Ω
R76 HU-002000405 MG RESISTOR 1k Ω
R77 HU-002000405 MG RESISTOR 1k Ω
R80 HU-002000405 MG RESISTOR 1k Ω
R81 HU-002000405 MG RESISTOR 1k Ω
R82 HU-002000405 MG RESISTOR 1k Ω
R84 HU-002000417 MG RESISTOR 4.7k Ω
 Ref No. Part No. Part Name Description Local

3-6(No.YA695<Rev.001>)
R85 HU-002000417 MG RESISTOR 4.7k Ω
R86 HU-002000417 MG RESISTOR 4.7k Ω
R87 HU-002000417 MG RESISTOR 4.7k Ω
R88 HU-002000405 MG RESISTOR 1k Ω
R89 HU-002000405 MG RESISTOR 1k Ω
R90 HU-002000405 MG RESISTOR 1k Ω
R91 HU-002000417 MG RESISTOR 4.7k Ω
R92 HU-002000417 MG RESISTOR 4.7k Ω
R95 HU-002000433 MG RESISTOR 0 Ω
R96 HU-002000436 MG RESISTOR 100k Ω
R99 HU-002000527 MG RESISTOR 100 Ω
R100 HU-002000433 MG RESISTOR 0 Ω
R101 HU-002000433 MG RESISTOR 0 Ω
R120 HU-002000405 MG RESISTOR 1k Ω
R141 HU-002000437 MG RESISTOR 10k Ω
R142 HU-002000433 MG RESISTOR 0 Ω
R143 HU-002000437 MG RESISTOR 10k Ω
R144 HU-002000405 MG RESISTOR 1k Ω
R147 HU-002000417 MG RESISTOR 4.7k Ω
R149 HU-002000405 MG RESISTOR 1k Ω
R154 HU-002001165 MG RESISTOR 75 Ω
R155 HU-002001165 MG RESISTOR 75 Ω
R156 HU-002001165 MG RESISTOR 75 Ω
R160 HU-002000433 MG RESISTOR 0 Ω
R161 HU-002000433 MG RESISTOR 0 Ω
R163 HU-002000433 MG RESISTOR 0 Ω
R164 HU-002000433 MG RESISTOR 0 Ω
R180 HU-002000433 MG RESISTOR 0 Ω
R182 HU-002000266 MG RESISTOR 470 Ω
R184 HU-002000266 MG RESISTOR 470 Ω
R186 HU-002000433 MG RESISTOR 0 Ω
R187 HU-002000266 MG RESISTOR 470 Ω
R189 HU-002000266 MG RESISTOR 470 Ω
R200 HU-002000910 MG RESISTOR 20k Ω
R201 HU-002000421 MG RESISTOR 75 Ω
R202 HU-002000421 MG RESISTOR 75 Ω
R203 HU-002000421 MG RESISTOR 75 Ω
R204 HU-002000421 MG RESISTOR 75 Ω
R205 HU-002000421 MG RESISTOR 75 Ω
R206 HU-002000421 MG RESISTOR 75 Ω
R207 HU-002000421 MG RESISTOR 75 Ω
R208 HU-002000421 MG RESISTOR 75 Ω
R209 HU-002000910 MG RESISTOR 20k Ω
R210 HU-002000910 MG RESISTOR 20k Ω
R211 HU-002000910 MG RESISTOR 20k Ω
R212 HU-002000499 MG RESISTOR 10k Ω
R213 HU-002000499 MG RESISTOR 10k Ω
R214 HU-002000499 MG RESISTOR 10k Ω
R215 HU-002000499 MG RESISTOR 10k Ω
R216 HU-002000527 MG RESISTOR 100 Ω
R217 HU-002000527 MG RESISTOR 100 Ω
R218 HU-002000421 MG RESISTOR 75 Ω
R219 HU-002000436 MG RESISTOR 100k Ω
R220 HU-002000421 MG RESISTOR 75 Ω
R221 HU-002000527 MG RESISTOR 100 Ω
R222 HU-002000527 MG RESISTOR 100 Ω
R230 HU-002000443 MG RESISTOR 22 Ω
R231 HU-002000421 MG RESISTOR 75 Ω
R232 HU-002000421 MG RESISTOR 75 Ω
R233 HU-002000421 MG RESISTOR 75 Ω
R234 HU-002000421 MG RESISTOR 75 Ω
R235 HU-002000421 MG RESISTOR 75 Ω
R238 HU-002000421 MG RESISTOR 75 Ω
R240 HU-002001060 MG RESISTOR 220k Ω
R244 HU-002001060 MG RESISTOR 220k Ω
R245 HU-002000527 MG RESISTOR 100 Ω
R246 HU-002000527 MG RESISTOR 100 Ω
R260 HU-002000443 MG RESISTOR 22 Ω
R261 HU-002000421 MG RESISTOR 75 Ω
R262 HU-002000421 MG RESISTOR 75 Ω
R263 HU-002000421 MG RESISTOR 75 Ω
R264 HU-002000421 MG RESISTOR 75 Ω
R265 HU-002000421 MG RESISTOR 75 Ω
R268 HU-002000421 MG RESISTOR 75 Ω
R270 HU-002001060 MG RESISTOR 220k Ω
R274 HU-002001060 MG RESISTOR 220k Ω
R275 HU-002000527 MG RESISTOR 100 Ω
R276 HU-002000527 MG RESISTOR 100 Ω
R313 HU-002000099 MG RESISTOR 4.7 Ω
R314 HU-002000433 MG RESISTOR 0 Ω
R330 HU-002000421 MG RESISTOR 75 Ω
R334 HU-002000433 MG RESISTOR 0 Ω
R335 HU-002000433 MG RESISTOR 0 Ω
R336 HU-002000433 MG RESISTOR 0 Ω
R338 HU-002000421 MG RESISTOR 75 Ω
R348 HU-002000421 MG RESISTOR 75 Ω
R351 HU-002001060 MG RESISTOR 220k Ω
R353 HU-002001060 MG RESISTOR 220k Ω
R355 HU-002000433 MG RESISTOR 0 Ω
 Ref No. Part No. Part Name Description Local
R356 HU-002000433 MG RESISTOR 0 Ω
R357 HU-002000433 MG RESISTOR 0 Ω
R370 HU-002000405 MG RESISTOR 1k Ω
R371 HU-002000437 MG RESISTOR 10k Ω
R372 HU-002000437 MG RESISTOR 10k Ω
R373 HU-002000437 MG RESISTOR 10k Ω
R374 HU-002000405 MG RESISTOR 1k Ω
R375 HU-002000437 MG RESISTOR 10k Ω
R376 HU-002000591 MG RESISTOR 18k Ω
R377 HU-002000591 MG RESISTOR 18k Ω
R378 HU-002000454 MG RESISTOR 47k Ω
R379 HU-002000454 MG RESISTOR 47k Ω
R382 HU-002000454 MG RESISTOR 47k Ω
R383 HU-002000454 MG RESISTOR 47k Ω
R386 HU-002000527 MG RESISTOR 100 Ω
R387 HU-002000527 MG RESISTOR 100 Ω
R388 HU-002000527 MG RESISTOR 100 Ω
R389 HU-002000527 MG RESISTOR 100 Ω
R400 HU-002000104 MG RESISTOR 22 Ω
R401 HU-002000104 MG RESISTOR 22 Ω
R470 HU-002000519 MG RESISTOR 10 Ω
R471 HU-002000519 MG RESISTOR 10 Ω
R472 HU-002000519 MG RESISTOR 10 Ω
R473 HU-002000519 MG RESISTOR 10 Ω
R474 HU-002000519 MG RESISTOR 10 Ω
R475 HU-002000519 MG RESISTOR 10 Ω
R476 HU-002000519 MG RESISTOR 10 Ω
R477 HU-002000519 MG RESISTOR 10 Ω
R484 HU-002000437 MG RESISTOR 10k Ω
R485 HU-002000519 MG RESISTOR 10 Ω
R486 HU-002000519 MG RESISTOR 10 Ω
R487 HU-002000519 MG RESISTOR 10 Ω
R489 HU-002000519 MG RESISTOR 10 Ω
R490 HU-002000519 MG RESISTOR 10 Ω
R491 HU-002001106 MG RESISTOR 390 Ω
R493 HU-002000519 MG RESISTOR 10 Ω
R494 HU-002000519 MG RESISTOR 10 Ω
R496 HU-002000519 MG RESISTOR 10 Ω
R497 HU-002000433 MG RESISTOR 0 Ω
R499 HU-002000527 MG RESISTOR 100 Ω
R500 HU-002000448 MG RESISTOR 33 Ω
R503 HU-002000448 MG RESISTOR 33 Ω
R504 HU-002000448 MG RESISTOR 33 Ω
R560 HU-002000417 MG RESISTOR 4.7k Ω
R561 HU-002000453 MG RESISTOR 470 Ω
R562 HU-002000453 MG RESISTOR 470 Ω
R563 HU-002000433 MG RESISTOR 0 Ω
R580 HU-002001028 MG RESISTOR 12.1k Ω
R581 HU-002001124 MG RESISTOR 47k Ω
R582 HU-002001028 MG RESISTOR 12.1k Ω
R583 HU-002001124 MG RESISTOR 47k Ω
R584 HU-002000454 MG RESISTOR 47k Ω
R585 HU-002000443 MG RESISTOR 22 Ω
R587 HU-002000433 MG RESISTOR 0 Ω
R590 HU-002000443 MG RESISTOR 22 Ω
R591 HU-002000436 MG RESISTOR 100k Ω
R592 HU-002000417 MG RESISTOR 4.7k Ω
R594 HU-002000433 MG RESISTOR 0 Ω
R595 HU-002000417 MG RESISTOR 4.7k Ω
R597 HU-002000910 MG RESISTOR 20k Ω
R598 HU-002001041 MG RESISTOR 16k Ω
R599 HU-002000437 MG RESISTOR 10k Ω
R600 HU-002000437 MG RESISTOR 10k Ω
R601 HU-002000910 MG RESISTOR 20k Ω
R602 HU-002001041 MG RESISTOR 16k Ω
R603 HU-002000437 MG RESISTOR 10k Ω
R604 HU-002000454 MG RESISTOR 47k Ω
R631 HU-002000602 MG RESISTOR 2k Ω
R632 HU-002000417 MG RESISTOR 4.7k Ω
R634 HU-002000405 MG RESISTOR 1k Ω
R635 HU-002000499 MG RESISTOR 10k Ω
R637 HU-002000417 MG RESISTOR 4.7k Ω
R638 HU-002000433 MG RESISTOR 0 Ω
R640 HU-002000417 MG RESISTOR 4.7k Ω
R641 HU-002000499 MG RESISTOR 10k Ω
R644 HU-002000433 MG RESISTOR 0 Ω
R645 HU-002000417 MG RESISTOR 4.7k Ω
R646 HU-002000417 MG RESISTOR 4.7k Ω
R647 HU-002001123 MG RESISTOR 470k Ω
R648 HU-002000433 MG RESISTOR 0 Ω
R660 HU-002000527 MG RESISTOR 100 Ω
R661 HU-002000417 MG RESISTOR 4.7k Ω
R662 HU-002000527 MG RESISTOR 100 Ω
R663 HU-002000417 MG RESISTOR 4.7k Ω
R664 HU-002000437 MG RESISTOR 10k Ω
R665 HU-002000417 MG RESISTOR 4.7k Ω
R666 HU-002000437 MG RESISTOR 10k Ω
R667 HU-002000417 MG RESISTOR 4.7k Ω
R668 HU-002000417 MG RESISTOR 4.7k Ω
 Ref No. Part No. Part Name Description Local
